手搓科技感弹窗与事件流程图

手写科技感弹窗，流程样式：

布局代码：

// index.tsx

import scrollstyles from './index.less';

 		<div
          className={`${scrollstyles.detailModalOverlay} ${scrollstyles.detailModalVisible}`}
          onClick={handleCloseModal}
        >
          <div
            className={scrollstyles.detailModalContent}
            onClick={(e) => e.stopPropagation()}
          >
            {/* 装饰边框 */}
            <div className={scrollstyles.detailModalBorder}>
              <div className={scrollstyles.detailCornerTopLeft}></div>
              <div className={scrollstyles.detailCornerTopRight}></div>
              <div className={scrollstyles.detailCornerBottomLeft}></div>
              <div className={scrollstyles.detailCornerBottomRight}></div>
              <div className={scrollstyles.detailBorderLineTop}></div>
              <div className={scrollstyles.detailBorderLineBottom}></div>
              <div className={scrollstyles.detailBorderLineLeft}></div>
              <div className={scrollstyles.detailBorderLineRight}></div>
            </div>

            {/* 弹窗头部 */}
            <div className={scrollstyles.detailModalHeader}>
              <div className={scrollstyles.detailModalTitle}>
                <span className={scrollstyles.detailTitleIcon}>◆</span>
                异常详情 - {selectedData.id}
              </div>
              <div
                className={scrollstyles.detailModalClose}
                onClick={handleCloseModal}
              >
                ✕
              </div>
            </div>

            {/* 弹窗主体 - 时间线布局 */}
            <div className={scrollstyles.detailModalBody}>
              <div className={scrollstyles.detailModalInfo}>
                <div className={scrollstyles.detailInfoItem}>
                  <span className={scrollstyles.detailInfoLabel}>异常ID</span>
                  <span className={scrollstyles.detailInfoValue}>
                    {selectedData.id}
                  </span>
                </div>
                <div className={scrollstyles.detailInfoItem}>
                  <span className={scrollstyles.detailInfoLabel}>类型</span>
                  <span className={scrollstyles.detailInfoValue}>
                    {selectedData.type}
                  </span>
                </div>
                <div className={scrollstyles.detailInfoItem}>
                  <span className={scrollstyles.detailInfoLabel}>异常详情</span>
                  <span className={scrollstyles.detailInfoValue}>
                    {selectedData.detail}
                  </span>
                </div>
              </div>

              {/* 时间线 */}
              <div className={scrollstyles.detailTimeline}>
                {selectedData.stages.map((stage, index) => (
                  <div key={index} className={scrollstyles.detailTimelineItem}>
                    <div className={scrollstyles.detailTimelineDot}>
                      <span className={scrollstyles.detailDotInner}></span>
                    </div>
                    {index < selectedData.stages.length - 1 && (
                      <div className={scrollstyles.detailTimelineLine}></div>
                    )}
                    <div className={scrollstyles.detailTimelineContent}>
                      <div className={scrollstyles.detailTimelineHeader}>
                        <span className={scrollstyles.detailTimelineName}>
                          {stage.name}
                        </span>
                        <span className={scrollstyles.detailTimelineStatus}>
                          {stage.status && (
                            <span className={scrollstyles.detailStatusTag}>
                              {stage.status}
                            </span>
                          )}
                        </span>
                      </div>
                      <div className={scrollstyles.detailTimelineDesc}>
                        {stage.description}
                      </div>
                      <div className={scrollstyles.detailTimelineTime}>
                        {stage.time}
                      </div>
                    </div>
                  </div>
                ))}
              </div>

              {/* 底部操作按钮 */}
              <div className={scrollstyles.detailModalFooter}>
                <div
                  className={scrollstyles.detailReportBtn}
                  onClick={handleGenerateReport}
                >
                  <span className={scrollstyles.detailBtnIcon}>📄</span>
                  生成处置报告
                  <span className={scrollstyles.detailBtnGlow}></span>
                </div>
              </div>
            </div>
          </div>
        </div>

// index/less
// 弹窗遮罩层
.detailModalOverlay {
  position: fixed;
  top: 0;
  left: 0;
  right: 0;
  bottom: 0;
  background: rgba(0, 0, 0, 70%);
  backdrop-filter: blur(8px);
  display: flex;
  align-items: center;
  justify-content: center;
  z-index: 9998;
  opacity: 0;
  visibility: hidden;
  transition: all 0.3s ease;

  &.detailModalVisible {
    opacity: 1;
    visibility: visible;
  }
}

// 弹窗内容
.detailModalContent {
  position: relative;
  width: 600px;
  max-height: 80vh;
  background: linear-gradient(
    145deg,
    rgba(0, 20, 50, 95%),
    rgba(0, 10, 30, 98%)
  );
  border: 1px solid rgba(0, 180, 255, 30%);
  border-radius: 12px;
  padding: 24px 28px 28px;
  box-shadow: 0 0 60px rgba(0, 100, 255, 15%),
    inset 0 0 60px rgba(0, 100, 255, 5%);
  overflow-y: auto;
  transform: scale(0.95) translateY(20px);
  transition: all 0.3s ease;

  .detailModalOverlay.detailModalVisible & {
    transform: scale(1) translateY(0);
  }

  &::-webkit-scrollbar {
    width: 4px;
  }

  &::-webkit-scrollbar-track {
    background: rgba(0, 40, 80, 30%);
    border-radius: 2px;
  }

  &::-webkit-scrollbar-thumb {
    background: rgba(0, 180, 255, 40%);
    border-radius: 2px;
  }
}

// ===== 装饰边框 =====
.detailModalBorder {
  position: absolute;
  top: 0;
  left: 0;
  right: 0;
  bottom: 0;
  pointer-events: none;
  border-radius: 12px;
  overflow: hidden;

  .detailCornerTopLeft,
  .detailCornerTopRight,
  .detailCornerBottomLeft,
  .detailCornerBottomRight {
    position: absolute;
    width: 20px;
    height: 20px;
    border-color: rgba(0, 180, 255, 60%);
    border-style: solid;
    border-width: 0;
  }

  .detailCornerTopLeft {
    top: 6px;
    left: 6px;
    border-top-width: 2px;
    border-left-width: 2px;
  }

  .detailCornerTopRight {
    top: 6px;
    right: 6px;
    border-top-width: 2px;
    border-right-width: 2px;
  }

  .detailCornerBottomLeft {
    bottom: 6px;
    left: 6px;
    border-bottom-width: 2px;
    border-left-width: 2px;
  }

  .detailCornerBottomRight {
    bottom: 6px;
    right: 6px;
    border-bottom-width: 2px;
    border-right-width: 2px;
  }

  .detailBorderLineTop,
  .detailBorderLineBottom,
  .detailBorderLineLeft,
  .detailBorderLineRight {
    position: absolute;
    background: linear-gradient(
      90deg,
      transparent,
      rgba(0, 180, 255, 30%),
      transparent
    );
  }

  .detailBorderLineTop {
    top: 6px;
    left: 30px;
    right: 30px;
    height: 1px;
  }

  .detailBorderLineBottom {
    bottom: 6px;
    left: 30px;
    right: 30px;
    height: 1px;
  }

  .detailBorderLineLeft {
    left: 6px;
    top: 30px;
    bottom: 30px;
    width: 1px;
    background: linear-gradient(
      180deg,
      transparent,
      rgba(0, 180, 255, 30%),
      transparent
    );
  }

  .detailBorderLineRight {
    right: 6px;
    top: 30px;
    bottom: 30px;
    width: 1px;
    background: linear-gradient(
      180deg,
      transparent,
      rgba(0, 180, 255, 30%),
      transparent
    );
  }
}

// ===== 弹窗头部 =====
.detailModalHeader {
  display: flex;
  justify-content: space-between;
  align-items: center;
  padding-bottom: 16px;
  border-bottom: 1px solid rgba(0, 180, 255, 20%);
  margin-bottom: 20px;

  .detailModalTitle {
    color: #00d4ff;
    font-size: 18px;
    font-weight: 600;
    text-shadow: 0 0 20px rgba(0, 180, 255, 30%);
    letter-spacing: 2px;

    .detailTitleIcon {
      color: #00d4ff;
      margin-right: 10px;
      font-size: 14px;
      animation: pulse 2s ease-in-out infinite;
    }
  }

  .detailModalClose {
    background: none;
    border: 1px solid rgba(0, 180, 255, 30%);
    color: #00d4ff;
    width: 32px;
    height: 32px;
    border-radius: 50%;
    cursor: pointer;
    font-size: 16px;
    transition: all 0.3s ease;
    display: flex;
    align-items: center;
    justify-content: center;

    &:hover {
      background: rgba(0, 180, 255, 15%);
      border-color: rgba(0, 180, 255, 60%);
      transform: rotate(90deg);
    }
  }
}

// ===== 弹窗主体 =====
.detailModalBody {
  .detailModalInfo {
    display: grid;
    grid-template-columns: 1fr 1fr 1fr;
    gap: 12px;
    margin-bottom: 20px;
    padding: 16px;
    background: rgba(0, 40, 80, 30%);
    border-radius: 8px;
    border: 1px solid rgba(0, 180, 255, 10%);

    .detailInfoItem {
      display: flex;
      flex-direction: column;

      .detailInfoLabel {
        color: rgba(0, 180, 255, 60%);
        font-size: 11px;
        text-transform: uppercase;
        letter-spacing: 1px;
        margin-bottom: 8px;
      }

      .detailInfoValue {
        color: #b8d4e8;
        font-size: 14px;
        font-weight: 500;
      }
    }
  }

  // ===== 时间线 =====
  .detailTimeline {
    position: relative;
    padding-left: 28px;

    .detailTimelineItem {
      position: relative;
      padding-bottom: 24px;

      &:last-child {
        padding-bottom: 0;
      }

      .detailTimelineDot {
        position: absolute;
        left: -28px;
        top: 4px;
        width: 16px;
        height: 16px;
        background: rgba(0, 180, 255, 15%);
        border: 2px solid rgba(0, 180, 255, 40%);
        border-radius: 50%;
        display: flex;
        align-items: center;
        justify-content: center;

        .detailDotInner {
          width: 6px;
          height: 6px;
          background: #00d4ff;
          border-radius: 50%;
          box-shadow: 0 0 12px rgba(0, 180, 255, 50%);
        }
      }

      .detailTimelineLine {
        position: absolute;
        left: -21px;
        top: 20px;
        width: 2px;
        height: calc(100% - 4px);
        background: linear-gradient(
          180deg,
          rgba(0, 180, 255, 30%),
          transparent
        );
      }

      .detailTimelineContent {
        padding-left: 12px;

        .detailTimelineHeader {
          display: flex;
          align-items: center;
          gap: 12px;
          margin-bottom: 4px;

          .detailTimelineName {
            color: #00d4ff;
            font-size: 14px;
            font-weight: 500;
          }

          .detailTimelineStatus {
            .detailStatusTag {
              display: inline-block;
              padding: 1px 10px;
              border-radius: 10px;
              font-size: 11px;
              background: rgba(255, 200, 0, 15%);
              color: #fc0;
              border: 1px solid rgba(255, 200, 0, 30%);
            }
          }
        }

        .detailTimelineDesc {
          color: #b8d4e8;
          font-size: 13px;
          margin-bottom: 8px;
          margin-top: 8px;
        }

        .detailTimelineTime {
          color: rgba(0, 180, 255, 50%);
          font-size: 12px;
          font-family: 'Courier New', monospace;
        }
      }
    }
  }

  // ===== 底部操作按钮 =====
  .detailModalFooter {
    display: flex;
    justify-content: center;
    align-items: center;
    padding-top: 20px;
    margin-top: 16px;
    border-top: 1px solid rgba(0, 180, 255, 15%);
    position: relative;

    .detailReportBtn {
      position: relative;
      display: flex;
      align-items: center;
      justify-content: center;
      gap: 10px;
      padding: 10px 36px;
      background: linear-gradient(
        135deg,
        rgba(0, 180, 255, 15%),
        rgba(0, 100, 255, 15%)
      );
      border: 1px solid rgba(0, 180, 255, 40%);
      border-radius: 8px;
      color: #00d4ff;
      font-size: 15px;
      font-weight: 500;
      cursor: pointer;
      transition: all 0.35s ease;
      letter-spacing: 2px;
      text-shadow: 0 0 20px rgba(0, 180, 255, 20%);
      overflow: hidden;
      user-select: none;

      .detailBtnIcon {
        font-size: 18px;
        position: relative;
        z-index: 1;
      }

      .detailBtnGlow {
        position: absolute;
        top: -50%;
        left: -50%;
        width: 200%;
        height: 200%;
        background: radial-gradient(
          circle at center,
          rgba(0, 180, 255, 10%) 0%,
          transparent 60%
        );
        opacity: 0;
        transition: opacity 0.5s ease;
        pointer-events: none;
      }

      &::before {
        content: '';
        position: absolute;
        inset: -1px;
        border-radius: 8px;
        padding: 1px;
        background: linear-gradient(
          135deg,
          rgba(0, 180, 255, 30%),
          rgba(0, 100, 255, 10%),
          rgba(0, 180, 255, 30%)
        );
        mask: linear-gradient(#fff 0 0) content-box, linear-gradient(#fff 0 0);
        mask-composite: xor;
        mask-composite: exclude;
        opacity: 0;
        transition: opacity 0.4s ease;
      }

      &:hover {
        background: linear-gradient(
          135deg,
          rgba(0, 180, 255, 25%),
          rgba(0, 100, 255, 25%)
        );
        border-color: rgba(0, 180, 255, 70%);
        box-shadow: 0 0 30px rgba(0, 180, 255, 15%),
          inset 0 0 30px rgba(0, 180, 255, 5%);
        transform: translateY(-2px) scale(1.02);

        &::before {
          opacity: 1;
        }

        .detailBtnGlow {
          opacity: 1;
          animation: glow-pulse 1.5s ease-in-out infinite;
        }
      }

      &:active {
        transform: translateY(0) scale(0.98);
      }
    }
  }
}
