AR1interface GigabitEthernet 0/0/0
AR1-GigabitEthernet0/0/0ip address 192.168.100.254 255.255.255.0
AR1interface LoopBack 0
AR1-LoopBack0ip address 1.1.1.1 255.255.255.255
AR1ip route-static 0.0.0.0 0.0.0.0 192.168.100.1
SW1vlan batch 10 20 100SW1interface GigabitEthernet 0/0/1
SW1-GigabitEthernet0/0/1port link-type trunk
SW1-GigabitEthernet0/0/1port trunk allow-pass vlan 10 20 100
SW1interface GigabitEthernet 0/0/2
SW1-GigabitEthernet0/0/2port link-type trunk
SW1-GigabitEthernet0/0/2port trunk pvid vlan 100
SW1-GigabitEthernet0/0/2port trunk allow-pass vlan 10 100
SW1interface GigabitEthernet 0/0/3
SW1-GigabitEthernet0/0/3port link-type trunk
SW1-GigabitEthernet0/0/3port trunk pvid vlan 100
SW1-GigabitEthernet0/0/3port trunk allow-pass vlan 10 100
SW1interface GigabitEthernet 0/0/4
SW1-GigabitEthernet0/0/4port link-type trunk
SW1-GigabitEthernet0/0/4port trunk pvid vlan 100
SW1-GigabitEthernet0/0/4port trunk allow-pass vlan 20 100
AC6605vlan batch 100 10 20
AC6605interface GigabitEthernet 0/0/1
AC6605-GigabitEthernet0/0/1port link-type trunk
AC6605-GigabitEthernet0/0/1port trunk allow-pass vlan 100
AC6605interface GigabitEthernet 0/0/2
AC6605-GigabitEthernet0/0/2port link-type trunk
AC6605-GigabitEthernet0/0/2port trunk pvid vlan 100
AC6605-GigabitEthernet0/0/2port trunk allow-pass vlan 100 10 20
AC6605interface Vlanif 100
AC6605-Vlanif100ip address 192.168.100.1 255.255.255.0
AC6605-Vlanif100dhcp select global
AC6605interface Vlanif 10
AC6605-Vlanif10ip address 192.168.10.1 255.255.255.0
AC6605-Vlanif10dhcp select global
AC6605interface Vlanif 20
AC6605-Vlanif20ip address 192.168.20.1 255.255.255.0
AC6605-Vlanif20dhcp select global
AC6605dhcp enableAC6605ip pool vlan100
AC6605-ip-pool-vlan100network 192.168.100.0 mask 24
AC6605-ip-pool-vlan100gateway-list 192.168.100.1
AC6605ip pool vlan10
AC6605-ip-pool-vlan10network 192.168.10.0 mask 24
AC6605-ip-pool-vlan10gateway-list 192.168.10.1
AC6605ip pool vlan20
AC6605-ip-pool-vlan20network 192.168.20.0 mask 24
AC6605-ip-pool-vlan20gateway-list 192.168.20.1
AC6605ip route-static 0.0.0.0 0.0.0.0 192.168.100.254
AC6605capwap source interface Vlanif 100
------配置SSID模板
AC6605wlan
AC6605-wlan-viewssid-profile name ssid-openlab-1
AC6605-wlan-ssid-prof-ssid-openlab-1ssid openlab-1
AC6605-wlan-ssid-prof-ssid-openlab-1quit
AC6605-wlan-viewssid-profile name ssid-openlab-2
AC6605-wlan-ssid-prof-ssid-openlab-2ssid openlab-2
AC6605-wlan-ssid-prof-ssid-openlab-2quit
------配置安全模板AC6605-wlan-viewsecurity-profile name sec-openlab-1
AC6605-wlan-sec-prof-sec-openlab-1security wpa2 psk pass-phrase admin123 aes
AC6605-wlan-sec-prof-sec-openlab-1quit
AC6605-wlan-viewsecurity-profile name sec-openlab-2
AC6605-wlan-sec-prof-sec-openlab-2security security wpa2 psk pass-phrase admin456 aes
AC6605-wlan-sec-prof-sec-openlab-2quit
配置vap模板AC6605-wlan-viewvap-profile name vap-group-1
AC6605-wlan-vap-prof-vap-group-1service-vlan vlan-id 10
AC6605-wlan-vap-prof-vap-group-1ssid-profile ssid-openlab-1
AC6605-wlan-vap-prof-vap-group-1security-profile sec-openlab-1
AC6605-wlan-vap-prof-vap-group-1forward-mode tunnel
AC6605-wlan-viewvap-profile name vap-group-2
AC6605-wlan-vap-prof-vap-group-2service-vlan vlan-id 20
AC6605-wlan-vap-prof-vap-group-2ssid-profile ssid-openlab-2
AC6605-wlan-vap-prof-vap-group-2security-profile sec-openlab-2
AC6605-wlan-vap-prof-vap-group-2forward-mode tunnel
调用vap模板
AC6605-wlan-viewap-group name group-1
AC6605-wlan-ap-group-group-1vap-profile vap-group-1 wlan 1 radio all
AC6605-wlan-viewap-group name group-2
AC6605-wlan-ap-group-group-2vap-profile vap-group-2 wlan 1 radio all
绑定ap组AC6605-wlan-viewap-id 0 ap-mac 00e0-fc93-04c0
AC6605-wlan-ap-1ap-name AP1
AC6605-wlan-ap-1ap-group group-1
AC6605-wlan-viewap-id 1 ap-mac 00e0-fc6d-65a0
AC6605-wlan-ap-2ap-name AP2
AC6605-wlan-ap-2ap-group group-1
AC6605-wlan-viewap-id 2 ap-mac 00e0-fc56-3f70
AC6605-wlan-ap-3ap-name AP3
AC6605-wlan-ap-3ap-group group-2
