跨三层环境（交换机vlan/vlanif配置）

芝麻馅汤圆儿2026-07-09 12:59

目录

0.背景

1.目标Tology

2.SW(辅测端)调整

[2.1 调整辅测端交换机vlan](#2.1 调整辅测端交换机vlan)

[2.2 调整辅测端交换机vlanif](#2.2 调整辅测端交换机vlanif)

[2.3 调整辅测端mac0 口IP](#2.3 调整辅测端mac0 口IP)

[2.4 辅测添加route配置](#2.4 辅测添加route配置)

[3. SW(主测端)调整](#3. SW(主测端)调整)

[3.1 调整主测端交换机vlanif](#3.1 调整主测端交换机vlanif)

3.2主测添加route配置

[4. 恢复SW 配置](#4. 恢复SW 配置)

[4.1 delete Vlanif IP](#4.1 delete Vlanif IP)

[4.2 恢复vlan 端口](#4.2 恢复vlan 端口)

[5. 查看vlan info](#5. 查看vlan info)

0.背景

两层环境，修改为跨三层环境。调整交换机vlan 并配置Vlanif

1.目标Tology

2.SW(辅测端)调整

2.1 调整辅测端交换机vlan

复制代码
1. 调整前查看SW vlan
# dis vlan


<BJS2-B05-SW02>dis vlan
The total number of VLANs is: 45
--------------------------------------------------------------------------------
U: Up;         D: Down;         TG: Tagged;         UT: Untagged;
MP: Vlan-mapping;               ST: Vlan-stacking;
#: ProtocolTransparent-vlan;    *: Management-vlan;
--------------------------------------------------------------------------------

VID  Type    Ports
--------------------------------------------------------------------------------
1    common  UT:100GE0/0/1(D)   100GE0/0/2(D)   100GE0/0/3(D)   100GE0/0/4(D)
                25GE0/0/13(D)   25GE0/0/14(D)
             TG:25GE0/0/7(U)    25GE0/0/8(U)    25GE0/0/17(U)   25GE0/0/18(U)
2    common
4    common
6    common
10   common  TG:25GE0/0/7(U)    25GE0/0/8(U)    25GE0/0/17(U)   25GE0/0/18(U)
20   common
100  common  TG:25GE0/0/8(U)    25GE0/0/18(U)
110  common  TG:25GE0/0/7(U)    25GE0/0/8(U)    25GE0/0/17(U)   25GE0/0/18(U)
112  common  TG:25GE0/0/7(U)    25GE0/0/8(U)    25GE0/0/17(U)   25GE0/0/18(U)
120  common  TG:25GE0/0/7(U)    25GE0/0/8(U)    25GE0/0/17(U)   25GE0/0/18(U)
126  common
151  common
152  common
200  common  TG:25GE0/0/7(U)    25GE0/0/8(U)    25GE0/0/17(U)   25GE0/0/18(U)
201  common
666  common  UT:25GE0/0/9(D)    25GE0/0/10(D)   25GE0/0/11(D)   25GE0/0/12(D)
                25GE0/0/15(D)   25GE0/0/16(D)
888  common
985  common  TG:25GE0/0/7(U)    25GE0/0/8(U)    25GE0/0/18(U)
999  common
1000 common
1001 common  UT:25GE0/0/8(U)    25GE0/0/18(U)   25GE0/0/24(D)
1002 common  UT:25GE0/0/7(U)    25GE0/0/17(U)
1003 common  UT:25GE0/0/19(U)   25GE0/0/20(U)
             TG:25GE0/0/13(D)   25GE0/0/14(D)
1004 common  UT:25GE0/0/23(D)
1006 common
1007 common
1011 common  UT:25GE0/0/26(U)   25GE0/0/27(U)
1012 common  UT:25GE0/0/25(U)   25GE0/0/28(U)
1021 common  UT:25GE0/0/1(U)    25GE0/0/5(U)
1022 common  UT:25GE0/0/2(U)    25GE0/0/6(U)
1023 common  UT:25GE0/0/3(U)    25GE0/0/4(U)
1188 common
1189 common
1266 common

2. 修改0/0/5 口vlan
# interface 25GE 0/0/5    # 进入0/0/5 口
[BJS2-B05-SW02]interface 25GE 0/0/5
[BJS2-B05-SW02-25GE0/0/5]dis th
#
interface 25GE0/0/5
 description vlan 1021
 port link-type access
 port default vlan 1021
 jumboframe enable 12288
#
return
[BJS2-B05-SW02-25GE0/0/5]

3. 修改0/0/5 口 vlan 为vlan 1188
[BJS2-B05-SW02-25GE0/0/5]port default vlan 1188
[BJS2-B05-SW02-25GE0/0/5]dis th
#
interface 25GE0/0/5
 description vlan 1021
 port link-type access
 port default vlan 1188
 jumboframe enable 12288
#
return
[BJS2-B05-SW02-25GE0/0/5]

4. 修改后再次查看SW vlan

[BJS2-B05-SW02-25GE0/0/5]dis vlan
The total number of VLANs is: 45
--------------------------------------------------------------------------------
U: Up;         D: Down;         TG: Tagged;         UT: Untagged;
MP: Vlan-mapping;               ST: Vlan-stacking;
#: ProtocolTransparent-vlan;    *: Management-vlan;
--------------------------------------------------------------------------------

VID  Type    Ports
--------------------------------------------------------------------------------
1    common  UT:100GE0/0/1(D)   100GE0/0/2(D)   100GE0/0/3(D)   100GE0/0/4(D)
                25GE0/0/13(D)   25GE0/0/14(D)
             TG:25GE0/0/7(U)    25GE0/0/8(U)    25GE0/0/17(U)   25GE0/0/18(U)
2    common
4    common
6    common
10   common  TG:25GE0/0/7(U)    25GE0/0/8(U)    25GE0/0/17(U)   25GE0/0/18(U)
20   common
100  common  TG:25GE0/0/8(U)    25GE0/0/18(U)
110  common  TG:25GE0/0/7(U)    25GE0/0/8(U)    25GE0/0/17(U)   25GE0/0/18(U)
112  common  TG:25GE0/0/7(U)    25GE0/0/8(U)    25GE0/0/17(U)   25GE0/0/18(U)
120  common  TG:25GE0/0/7(U)    25GE0/0/8(U)    25GE0/0/17(U)   25GE0/0/18(U)
126  common
151  common
152  common
200  common  TG:25GE0/0/7(U)    25GE0/0/8(U)    25GE0/0/17(U)   25GE0/0/18(U)
201  common
666  common  UT:25GE0/0/9(D)    25GE0/0/10(D)   25GE0/0/11(D)   25GE0/0/12(D)
                25GE0/0/15(D)   25GE0/0/16(D)
888  common
985  common  TG:25GE0/0/7(U)    25GE0/0/8(U)    25GE0/0/18(U)
999  common
1000 common
1001 common  UT:25GE0/0/8(U)    25GE0/0/18(U)   25GE0/0/24(D)
1002 common  UT:25GE0/0/7(U)    25GE0/0/17(U)
1003 common  UT:25GE0/0/19(U)   25GE0/0/20(U)
             TG:25GE0/0/13(D)   25GE0/0/14(D)
1004 common  UT:25GE0/0/23(D)
1006 common
1007 common
1011 common  UT:25GE0/0/26(U)   25GE0/0/27(U)
1012 common  UT:25GE0/0/25(U)   25GE0/0/28(U)
1021 common  UT:25GE0/0/1(U)
1022 common  UT:25GE0/0/2(U)    25GE0/0/6(U)
1023 common  UT:25GE0/0/3(U)    25GE0/0/4(U)
1188 common  UT:25GE0/0/5(U)
1189 common

[BJS2-B05-SW02-25GE0/0/5]quit    # 退出vlan

2.2 调整辅测端交换机vlanif

复制代码
1. 查看vlan 1188 的 Vlanif info
[BJS2-B05-SW02]interface Vlanif 1188
[BJS2-B05-SW02-Vlanif1188]dis th
#
interface Vlanif1188
#
return
[BJS2-B05-SW02-Vlanif1188]



2. 配置Vlanif IP

[BJS2-B05-SW02-Vlanif1188]ip address 33.33.33.119 255.255.255.0
[BJS2-B05-SW02-Vlanif1188]dis th
#
interface Vlanif1188
 ip address 33.33.33.119 255.255.255.0
#
return

2.3 调整辅测端mac0 口IP

复制代码
辅测端mac0 口IP 应该与 mac0 口连接的SW 口所在的vlanIf IP 同网段，
所以删除辅测端mac0 口IP，并重新配置辅测端mac0 口IP

1. 修改mac0 iP 前查看
[root@localhost network-scripts]# ifconfig swift150f0
swift150f0: flags=4163<UP,BROADCAST,RUNNING,MULTICAST>  mtu 1500
        inet 11.11.11.219  netmask 255.255.255.0  broadcast 11.11.11.255
        ether 74:3e:39:10:02:57  txqueuelen 1000  (Ethernet)
        RX packets 13444487183  bytes 11717176270925 (10.6 TiB)
        RX errors 0  dropped 105467  overruns 148176  frame 0
        TX packets 6664048343  bytes 3725548201653 (3.3 TiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

[root@localhost network-scripts]#


2. 修改mac0 IP
[root@localhost network-scripts]# cat  /etc/sysconfig/network-scripts/ifcfg-swift150f0
HWADDR=74:3E:39:10:02:57
TYPE=Ethernet
PROXY_METHOD=none
BROWSER_ONLY=no
BOOTPROTO=none
IPADDR=33.33.33.219             # 修改IP为33.33.33.219
PREFIX=24
DEFROUTE=yes
IPV4_FAILURE_FATAL=no
IPV4_DNS_PRIORITY=100
IPV6INIT=no
NAME=swift150f0
UUID=a8bd1d0a-be3d-4fc2-a3fb-fe027e17e7bd
DEVICE=swift150f0
ONBOOT=yes
[root@localhost network-scripts]#


3. 修改后使iPv4 生效
[root@localhost network-scripts]# systemctl restart network
[root@localhost network-scripts]# ifconfig swift150f0
swift150f0: flags=4163<UP,BROADCAST,RUNNING,MULTICAST>  mtu 1500
        inet 33.33.33.219  netmask 255.255.255.0  broadcast 33.33.33.255
        ether 74:3e:39:10:02:57  txqueuelen 1000  (Ethernet)
        RX packets 13444487241  bytes 11717176277760 (10.6 TiB)
        RX errors 0  dropped 105488  overruns 148176  frame 0
        TX packets 6664048344  bytes 3725548201713 (3.3 TiB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

[root@localhost network-scripts]#

2.4 辅测添加route配置

复制代码
e

3. SW(主测端)调整

3.1 调整主测端交换机vlanif

复制代码
#因为mac0 连接SW 0/0/1 口，所在vlan:1021

1. 查看vlan 1021 的 Vlanif info


[BJS2-B05-SW02-Vlanif1188]interface Vlanif 1021
[BJS2-B05-SW02-Vlanif1021]dis th
#
interface Vlanif1021
#
return
[BJS2-B05-SW02-Vlanif1021




2. 配置Vlanif IP

[BJS2-B05-SW02-Vlanif1021]ip address 11.11.11.118 24
[BJS2-B05-SW02-Vlanif1021]dis th
#
interface Vlanif1021
 ip address 11.11.11.118 255.255.255.0
#
return
[BJS2-B05-SW02-Vlanif1021]

3.2主测添加route配置

复制代码
1. 添加route 前查看
[root@localhost wangkatool]# route
Kernel IP routing table
Destination     Gateway         Genmask         Flags Metric Ref    Use Iface
10.0.108.0      192.168.2.1     255.255.252.0   UG    0      0        0 eno1
10.0.130.0      192.168.2.1     255.255.254.0   UG    0      0        0 eno1
10.1.22.0       192.168.2.1     255.255.255.0   UG    0      0        0 eno1
10.1.30.0       192.168.2.1     255.255.254.0   UG    0      0        0 eno1
11.11.11.0      0.0.0.0         255.255.255.0   U     104    0        0 swift150f0
12.12.12.0      0.0.0.0         255.255.255.0   U     106    0        0 swift150f1
13.13.13.0      0.0.0.0         255.255.255.0   U     107    0        0 swift171f0
14.14.14.0      0.0.0.0         255.255.255.0   U     108    0        0 swift171f1
15.15.15.0      0.0.0.0         255.255.255.0   U     108    0        0 swift171f1
16.16.16.0      0.0.0.0         255.255.255.0   U     108    0        0 swift171f1
192.168.2.0     192.168.2.1     255.255.255.0   UG    0      0        0 eno1
192.168.2.0     0.0.0.0         255.255.255.0   U     100    0        0 eno1
192.168.4.0     192.168.2.1     255.255.252.0   UG    0      0        0 eno1
192.168.22.0    192.168.2.1     255.255.255.0   UG    0      0        0 eno1
192.168.30.0    192.168.2.1     255.255.255.0   UG    0      0        0 eno1
192.168.100.0   192.168.2.1     255.255.255.0   UG    0      0        0 eno1
[root@localhost wangkatool]#



2. 添加route
#  route add -net <三层环境vlanif 网段>/24 gw <本机SW 口所在vlanif IP>
e.g:  route add -net 33.33.33.0/24 gw 11.11.11.118


[root@localhost wangkatool]# route add -net 33.33.33.0/24 gw 11.11.11.118
[root@localhost wangkatool]# route
Kernel IP routing table
Destination     Gateway         Genmask         Flags Metric Ref    Use Iface
10.0.108.0      192.168.2.1     255.255.252.0   UG    0      0        0 eno1
10.0.130.0      192.168.2.1     255.255.254.0   UG    0      0        0 eno1
10.1.22.0       192.168.2.1     255.255.255.0   UG    0      0        0 eno1
10.1.30.0       192.168.2.1     255.255.254.0   UG    0      0        0 eno1
11.11.11.0      0.0.0.0         255.255.255.0   U     104    0        0 swift150f0
12.12.12.0      0.0.0.0         255.255.255.0   U     106    0        0 swift150f1
13.13.13.0      0.0.0.0         255.255.255.0   U     107    0        0 swift171f0
14.14.14.0      0.0.0.0         255.255.255.0   U     108    0        0 swift171f1
15.15.15.0      0.0.0.0         255.255.255.0   U     108    0        0 swift171f1
16.16.16.0      0.0.0.0         255.255.255.0   U     108    0        0 swift171f1
33.33.33.0      11.11.11.118    255.255.255.0   UG    0      0        0 swift150f0
192.168.2.0     192.168.2.1     255.255.255.0   UG    0      0        0 eno1
192.168.2.0     0.0.0.0         255.255.255.0   U     100    0        0 eno1
192.168.4.0     192.168.2.1     255.255.252.0   UG    0      0        0 eno1
192.168.22.0    192.168.2.1     255.255.255.0   UG    0      0        0 eno1
192.168.30.0    192.168.2.1     255.255.255.0   UG    0      0        0 eno1
192.168.100.0   192.168.2.1     255.255.255.0   UG    0      0        0 eno1
[root@localhost wangkatool]#
[root@localhost wangkatool]#

4. 恢复SW 配置

4.1 delete Vlanif IP

复制代码
以上操作共修改如下：
1. 将SW 0/0/5 口从vlan 1021 更改为vlan1188
2. 将SW 0/0/6口从vlan 1022 更改为vlan1189
3. 为vlan1188 配置Vlanif IP
4. 将vlan1021 配置Vlanif IP
5. 将vlan1022 配置Vlanif IP


需要恢复以上配置
//************************************************************************
1. 删除vlan 1188配置Vlanif IP

[BJS2-B05-SW02]interface Vlanif 1188
[BJS2-B05-SW02-Vlanif1188]dis th
#
interface Vlanif1188
 ip address 33.33.33.119 255.255.255.0
#
return
[BJS2-B05-SW02-Vlanif1188]undo ip address 33.33.33.119 255.255.255.0
[BJS2-B05-SW02-Vlanif1188]
[BJS2-B05-SW02-Vlanif1188]dis th
#
interface Vlanif1188
#
return
[BJS2-B05-SW02-Vlanif1188]q


//************************************************************************
2. 删除vlan 1021 配置Vlanif IP

[BJS2-B05-SW02]interface Vlanif 1021   # 进入Vlanif 1021
[BJS2-B05-SW02-Vlanif1021]dis th
#
interface Vlanif1021
 ip address 11.11.11.118 255.255.255.0
#
return
[BJS2-B05-SW02-Vlanif1021]undo ip address 11.11.11.118 255.255.255.0   # 删除vlanif IP
[BJS2-B05-SW02-Vlanif1021]
[BJS2-B05-SW02-Vlanif1021]dis th
#
interface Vlanif1021
#
return
[BJS2-B05-SW02-Vlanif1021]
[BJS2-B05-SW02-Vlanif1021]q
[BJS2-B05-SW02]

//************************************************************************
3. 删除vlan 1022 配置Vlanif IP
[BJS2-B05-SW02]interface Vlanif 1022
[BJS2-B05-SW02-Vlanif1022]dis th
#
interface Vlanif1022
 ip address 12.12.12.118 255.255.255.0
#
return
[BJS2-B05-SW02-Vlanif1022]undo ip address 12.12.12.118 255.255.255.0   # 删除vlanif IP
[BJS2-B05-SW02-Vlanif1022]
[BJS2-B05-SW02-Vlanif1022]dis th
#
interface Vlanif1022
#
return
[BJS2-B05-SW02-Vlanif1022]

4.2 恢复vlan 端口

复制代码
以上操作共修改如下：
1. 将SW 0/0/5 口从vlan 1021 更改为vlan1188
2. 将SW 0/0/6口从vlan 1022 更改为vlan1189
3. 为vlan1188 配置Vlanif IP
4. 将vlan1021 配置Vlanif IP
5. 将vlan1022 配置Vlanif IP


需要恢复以上配置

//************************************************************************
1. 将0/0/5 口从vlan 1188 恢复为 vlan 1021

[BJS2-B05-SW02]interface 25GE 0/0/5
[BJS2-B05-SW02-25GE0/0/5]dis th
#
interface 25GE0/0/5
 description vlan 1021
 port link-type access
 port default vlan 1188
 jumboframe enable 12288
#
return
[BJS2-B05-SW02-25GE0/0/5]
[BJS2-B05-SW02-25GE0/0/5]port default vlan 1021   # 恢复为vlan 1021
[BJS2-B05-SW02-25GE0/0/5]dis th                   # 查看vlan info
#
interface 25GE0/0/5
 description vlan 1021
 port link-type access
 port default vlan 1021
 jumboframe enable 12288
#
return
[BJS2-B05-SW02-25GE0/0/5]



2. 将0/0/6 口从vlan 1189 恢复为 vlan 1022

[BJS2-B05-SW02]interface 25GE 0/0/6
[BJS2-B05-SW02-25GE0/0/6]dis th
#
interface 25GE0/0/6
 port link-type access
 port default vlan 1189
 jumboframe enable 12288
#
return
[BJS2-B05-SW02-25GE0/0/6]port default vlan 1022
[BJS2-B05-SW02-25GE0/0/6]
[BJS2-B05-SW02-25GE0/0/6]dis th
#
interface 25GE0/0/6
 port link-type access
 port default vlan 1022
 jumboframe enable 12288
#
return
[BJS2-B05-SW02-25GE0/0/6]
[BJS2-B05-SW02-25GE0/0/6]q

5. 查看vlan info

复制代码
1. 查看指定vlan info


<BJS2-B05-SW02>dis vlan 1021
--------------------------------------------------------------------------------
U: Up;         D: Down;         TG: Tagged;         UT: Untagged;
MP: Vlan-mapping;               ST: Vlan-stacking;
#: ProtocolTransparent-vlan;    *: Management-vlan;
--------------------------------------------------------------------------------

VID  Type    Ports
--------------------------------------------------------------------------------
1021 common  UT:25GE0/0/1(U)    25GE0/0/5(U)

VID  Status  Property      MAC-LRN Statistics Description
--------------------------------------------------------------------------------
1021 enable  default       enable  disable    VLAN 1021
<BJS2-B05-SW02>


# 查看vlan 1022
<BJS2-B05-SW02>dis vlan 1022
--------------------------------------------------------------------------------
U: Up;         D: Down;         TG: Tagged;         UT: Untagged;
MP: Vlan-mapping;               ST: Vlan-stacking;
#: ProtocolTransparent-vlan;    *: Management-vlan;
--------------------------------------------------------------------------------

VID  Type    Ports
--------------------------------------------------------------------------------
1022 common  UT:25GE0/0/2(U)    25GE0/0/6(U)

VID  Status  Property      MAC-LRN Statistics Description
--------------------------------------------------------------------------------
1022 enable  default       enable  disable    VLAN 1022
<BJS2-B05-SW02>



//*********************************************************************
查看vlan 1188

<BJS2-B05-SW02>dis vlan 1188
--------------------------------------------------------------------------------
U: Up;         D: Down;         TG: Tagged;         UT: Untagged;
MP: Vlan-mapping;               ST: Vlan-stacking;
#: ProtocolTransparent-vlan;    *: Management-vlan;
--------------------------------------------------------------------------------

VID  Type    Ports
--------------------------------------------------------------------------------
1188 common

VID  Status  Property      MAC-LRN Statistics Description
--------------------------------------------------------------------------------
1188 enable  default       enable  disable    VLAN 1188
<BJS2-B05-SW02>
相关推荐
wjql22 小时前
手机远程操控另一台手机的方法 手机可以远程操控手机吗
网络
奶油话梅糖2 小时前
锐捷常用命令速查表
java·网络·windows
rcms152702692182 小时前
AMAT 0190-32401 通讯模块
网络
范纹杉想快点毕业2 小时前
嵌入式串口通信协议设计与解析完全教程
网络
chh5633 小时前
C++--string
java·开发语言·网络·c++·学习
ZhengO_Oz3 小时前
虚拟机CentOS 网络配置【实操】
运维·服务器·网络
fei_sun3 小时前
网卡、网关、网桥、交换机、路由器
linux·服务器·网络
阿成学长_Cain4 小时前
Linux grpck命令超全详解｜校验组文件完整性、修复/etc/group错误实战
linux·运维·服务器·网络
量子罐头4 小时前
光润通发布LYSH-LAN-V1.0家庭版智能安全路由器 主打国密级硬件加密
网络·安全·智能路由器
热门推荐
012026 AI 编程工具终极实战指南：Cursor vs Claude Code vs Copilot，开发者该怎么选？022026 年 AI 编程工具终极横评：Cursor vs Claude Code vs Copilot vs Windsurf03AI 编程 IDE 全景解析 2026：Agent 全面接管开发链路042026 年 AI 大模型 & AI 编程工具实战全总结05GitHub 镜像站点06AI科技热点日报 | 2026年07月01日07【AI】2026 年具身智能模型和世界模型总结082026 AI 编程工具选型横评：Cursor / Claude Code / Trae / Copilot 到底选谁（建议收藏·避坑版）09Claude Code、Codex、Cursor三分天下：2026年AI编程Agent生态全景剖析102026年7月AI圈大地震：GPT-5.6被政府限制、Claude入驻Slack、Anthropic自研芯片
