顶部区域固定,左侧区域滚动,右侧区域滚动,彼此独立

顶部固定,左侧滚动,右侧滚动,彼此独立

实现一个网页功能。

顶部区域,左右布局。

顶部的内容固定不变(始终在最顶部),左侧内容超出滚动,右侧内容超过滚动,左右2侧的滚动互不影响

实现滚动的2个条件:

1,滚动的容器需要设置固定的高度

2,设置overflow-y: auto;

xml 复制代码
<!DOCTYPE html>
<html lang="en">
<head>
    <meta charset="UTF-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <title>Document</title>
    <style>
        *{
            padding: 0;
            margin: 0;
        }
        .top-cont{
            height: 100px;
            background-color: aqua;
        }
        .cont-box{
            display: flex;
        }
        .left-box{
            scrollbar-width:none;
            overflow-y: auto;
            width: 300px;
            background-color: antiquewhite;
        }
        .right-box{
            flex: 1;
            overflow-y: auto;
            background-color: aquamarine;
        }
        .item-box{
            height: 400px;
            background-color: #fff;
            margin-bottom: 10px;
        }
         .item-box2{
            height: 400px;
            background-color: pink;
            margin-bottom: 10px;
        }
    </style>
</head>
<body>
    <div class="top-cont" id="topCont">
        顶部区域
    </div>
    <div class="cont-box">
        <div class="left-box" id="leftBox">
            <div class="item-box">AAA1</div>
            <div class="item-box">AAA2</div>
            <div class="item-box">AAA3</div>
            <div class="item-box">AAA4</div>
            <div class="item-box">AAA5</div>
            <div class="item-box">AAA6</div>

        </div>
        <div class="right-box" id="rightBox">
            <div class="item-box2">AAA1</div>
            <div class="item-box2">AAA2</div>
            <div class="item-box2">AAA3</div>
            <div class="item-box2">AAA4</div>
            <div class="item-box2">AAA5</div>
            <div class="item-box2">AAA6</div>
        </div>
    </div>

    <script></script>
</body>
<script>
// 动态获取顶部区域的高度
const topCont = document.getElementById('topCont')
const topContNodeHeight = topCont.offsetHeight
console.log('获取顶部元素的高度', topContNodeHeight)

// 设置左侧的区域,设置固定高度
const leftBox = document.getElementById('leftBox')
leftBox.style.height =  `calc(100vh - ${topContNodeHeight }px)`

// 设置右侧的区域,设置固定高度
const rightBox = document.getElementById('rightBox')
rightBox.style.height =  `calc(100vh - ${topContNodeHeight }px)`
</script>
</html>

为啥顶部没有设置固定定位

顶部区域固定位置,确实可以设置固定定位,也是实现的一种办法。

还有一种办法就是:让这个页面的高度始终不超过body的高度(文中就是使用的这种办法)

页面如何不产生滚动条

子元素的高度不超出了父元素的高度,就不会产生滚动条。

也就是说:如果页面产生滚动条,就说明子元素的高度超出了父元素的高度了。

如何隐藏左侧的滚动条

css 复制代码
.left-box{
    // 隐藏左侧的滚动条
    scrollbar-width:none;
    overflow-y: auto;
    width: 300px;
}

offsetHeight

offsetHeight 返回元素的高度(整数,四舍五入),它包含以下部分:

offsetHeight = content + padding + border + 水平滚动条(如果有就会包含)

也就是是不包含margin哈。在说一次,不包含margin。
