MVC 与 WebFlux 关系

SpringSecurity 设置要采用响应式配置，基于 WebFlux 中 WebFilter 实现，与 Spring MVC 的 Security 是通过 Servlet 的 Filter 实现类似，也是一系列 filter 组成的过滤链。

Reactor 与传统 MVC 配置对应：

webflux mvc 作用
@EnableWebFluxSecurity @EnableWebSecurity 开启 security 配置
ServerAuthenticationSuccessHandler AuthenticationSuccessHandler 登录成功 Handler
ServerAuthenticationFailureHandler AuthenticationFailureHandler 登录失败 Handler
ServerLogoutSuccessHandler LogoutSuccessHandler 注销成功Handler
ServerSecurityContextRepository SecurityContextHolder 认证信息存储管理
ReactiveUserDetailsService UserDetailsService 用户登录逻辑处理
ReactiveAuthenticationManager AuthorizationManager 认证管理
ReactiveAuthorizationManager AccessDecisionManager 鉴权管理
ServerAuthenticationEntryPoint AuthenticationEntryPoint 未认证 Handler
ServerAccessDeniedHandler AccessDeniedHandler 鉴权失败 Handler
AuthenticationWebFilter FilterSecurityInterceptor 拦截器

快速入门

xml 复制代码
<dependency>
    <groupId>org.springframework.cloud</groupId>
    <artifactId>spring-cloud-starter-security</artifactId>
    <version>2.2.5.RELEASE</version>
</dependency>
<dependency>
    <groupId>org.springframework.cloud</groupId>
    <artifactId>spring-cloud-starter-gateway</artifactId>
    <version>2.2.6.RELEASE</version>
</dependency>
<dependency>
    <groupId>com.alibaba</groupId>
    <artifactId>fastjson</artifactId>
    <version>2.0.38</version>
</dependency>
<dependency>
    <groupId>org.projectlombok</groupId>
    <artifactId>lombok</artifactId>
</dependency>

内存管理用户信息

java 复制代码
@EnableWebFluxSecurity
@Configuration
public class SecurityConfig {

    @Bean
    public SecurityWebFilterChain filterChain(ServerHttpSecurity http) {
       http.httpBasic()
               .and()
               .authorizeExchange()
               .anyExchange()
               .authenticated();
        return http.build();
    }

    /**
     * 内存管理用户信息
     */
    @Bean
    public MapReactiveUserDetailsService userDetailsService() {
        UserDetails user = User.withDefaultPasswordEncoder()
                .username("user")
                .password("password")
                .roles("USER")
                .build();
        return new MapReactiveUserDetailsService(user);
    }
}

自定义登录、注销处理器

  1. 自定义登录成功处理器
java 复制代码
@Component
public class LoginSuccessHandler implements ServerAuthenticationSuccessHandler {

    @Override
    public Mono<Void> onAuthenticationSuccess(WebFilterExchange webFilterExchange, Authentication authentication) {
        return Mono.defer(() -> Mono.just(webFilterExchange.getExchange().getResponse()).flatMap(response -> {
            DataBufferFactory dataBufferFactory = response.bufferFactory();
            DataBuffer dataBuffer = dataBufferFactory.wrap("登录成功".getBytes());
            return response.writeWith(Mono.just(dataBuffer));
        }));
    }
}
  1. 自定义登录失败处理器
java 复制代码
@Component
public class LoginFailHandler implements ServerAuthenticationFailureHandler {

    @Override
    public Mono<Void> onAuthenticationFailure(WebFilterExchange webFilterExchange, AuthenticationException exception) {
        return Mono.defer(() -> Mono.just(webFilterExchange.getExchange().getResponse()).flatMap(response -> {
            DataBufferFactory dataBufferFactory = response.bufferFactory();
            DataBuffer dataBuffer = dataBufferFactory.wrap("登录失败".getBytes());
            return response.writeWith(Mono.just(dataBuffer));
        }));
    }
}
  1. 自定义注销成功处理器
java 复制代码
@Component
public class LogoutSuccessHandler implements ServerLogoutSuccessHandler {

    @Override
    public Mono<Void> onLogoutSuccess(WebFilterExchange exchange, Authentication authentication) {
        return Mono.defer(() -> Mono.just(exchange.getExchange().getResponse()).flatMap(response -> {
            DataBufferFactory dataBufferFactory = response.bufferFactory();
            DataBuffer dataBuffer = dataBufferFactory.wrap("logout success".getBytes());
            return response.writeWith(Mono.just(dataBuffer));
        }));
    }
}
java 复制代码
@EnableWebFluxSecurity
@Configuration
public class SecurityConfig {

    @Resource
    private LoginSuccessHandler loginSuccessHandler;
    @Resource
    private LoginFailHandler loginFailHandler;
    @Resource
    private LogoutSuccessHandler logoutSuccessHandler;

    @Bean
    public SecurityWebFilterChain filterChain(ServerHttpSecurity http) {
        http.httpBasic()
                .and()
                .authorizeExchange()
                .anyExchange()
                .authenticated();

        http.formLogin()
            .authenticationSuccessHandler(loginSuccessHandler)
            .authenticationFailureHandler(loginFailHandler)
            .and()
            .logout()
            .logoutSuccessHandler(logoutSuccessHandler);
        return http.build();
    }

    /**
     * 内存管理用户信息
     */
    @Bean
    public MapReactiveUserDetailsService userDetailsService() {
        UserDetails user = User.withDefaultPasswordEncoder()
                .username("user")
                .password("password")
                .roles("USER")
                .build();
        return new MapReactiveUserDetailsService(user);
    }
}

自定义用户信息

  1. 仿照 MapReactiveUserDetailsService 编写获取用户认证类
java 复制代码
@Component
public class UserDetailService implements ReactiveUserDetailsService, ReactiveUserDetailsPasswordService {

    private final Map<String, UserDetails> users = new HashMap<>();

    @Resource
    private PasswordEncoder passwordEncoder;

    @Override
    public Mono<UserDetails> findByUsername(String username) {
        User user = null;
        if ("user".equals(username)) {
            user = new User("user", passwordEncoder.encode("123456"), true, true, true, true, new ArrayList<>());
        }
        return Mono.justOrEmpty(user);
    }

    @Override
    public Mono<UserDetails> updatePassword(UserDetails user, String newPassword) {
        return Mono.just(user)
                .map(u ->
                        User.withUserDetails(u)
                                .password(newPassword)
                                .build()
                )
                .doOnNext(u -> {
                    this.users.put(user.getUsername().toLowerCase(), u);
                });
    }
}
  1. 仿照 AbstractUserDetailsReactiveAuthenticationManager 编写用户认证管理类
java 复制代码
@Component
public class UserAuthenticationManager extends AbstractUserDetailsReactiveAuthenticationManager {

    @Resource
    private PasswordEncoder passwordEncoder;
    @Resource
    private ReactiveUserDetailsService userDetailService;
    @Resource
    private ReactiveUserDetailsPasswordService userDetailsPswService;

    private Scheduler scheduler = Schedulers.boundedElastic();

    private UserDetailsChecker preAuthenticationChecks = user -> {
        if (!user.isAccountNonLocked()) {
            logger.debug("User account is locked");

            throw new LockedException(this.messages.getMessage(
                    "AbstractUserDetailsAuthenticationProvider.locked",
                    "User account is locked"));
        }

        if (!user.isEnabled()) {
            logger.debug("User account is disabled");

            throw new DisabledException(this.messages.getMessage(
                    "AbstractUserDetailsAuthenticationProvider.disabled",
                    "User is disabled"));
        }

        if (!user.isAccountNonExpired()) {
            logger.debug("User account is expired");

            throw new AccountExpiredException(this.messages.getMessage(
                    "AbstractUserDetailsAuthenticationProvider.expired",
                    "User account has expired"));
        }
    };

    private UserDetailsChecker postAuthenticationChecks = user -> {
        if (!user.isCredentialsNonExpired()) {
            logger.debug("User account credentials have expired");

            throw new CredentialsExpiredException(this.messages.getMessage(
                    "AbstractUserDetailsAuthenticationProvider.credentialsExpired",
                    "User credentials have expired"));
        }
    };


    @Override
    public Mono<Authentication> authenticate(Authentication authentication) {
        final String username = authentication.getName();
        final String presentedPassword = (String) authentication.getCredentials();
        return retrieveUser(username)
                .doOnNext(this.preAuthenticationChecks::check)
                .publishOn(this.scheduler)
                .filter(u -> this.passwordEncoder.matches(presentedPassword, u.getPassword()))
                .switchIfEmpty(Mono.defer(() -> Mono.error(new BadCredentialsException("Invalid Credentials"))))
                .flatMap(u -> {
                    boolean upgradeEncoding = this.userDetailsPswService != null
                            && this.passwordEncoder.upgradeEncoding(u.getPassword());
                    if (upgradeEncoding) {
                        String newPassword = this.passwordEncoder.encode(presentedPassword);
                        return this.userDetailsPswService.updatePassword(u, newPassword);
                    }
                    return Mono.just(u);
                })
                .doOnNext(this.postAuthenticationChecks::check)
                .map(u -> new UsernamePasswordAuthenticationToken(u, u.getPassword(), u.getAuthorities()) );
    }


    @Override
    protected Mono<UserDetails> retrieveUser(String username) {
        return userDetailService.findBysername(username);
    }
}
java 复制代码
@EnableWebFluxSecurity
@Configuration
public class SecurityConfig {

    @Resource
    private LoginSuccessHandler loginSuccessHandler;
    @Resource
    private LoginFailHandler loginFailHandler;
    @Resource
    private LogoutSuccessHandler logoutSuccessHandler;
    @Resource
    private UserAuthenticationManager userAuthenticationManager;

    @Bean
    public SecurityWebFilterChain filterChain(ServerHttpSecurity http) {
        http.httpBasic()
                .and()
                .authorizeExchange()
                .anyExchange()
                .authenticated();

        http.formLogin()
                .authenticationManager(authenticationManager())
                .authenticationSuccessHandler(loginSuccessHandler)
                .authenticationFailureHandler(loginFailHandler)
				.and()
                .logout()
                .logoutSuccessHandler(logoutSuccessHandler);
        return http.build();
    }

    /**
     * 注册用户信息验证管理器，可按需求添加多个按顺序执行
     */
    @Bean
    public ReactiveAuthenticationManager authenticationManager() {
        LinkedList<ReactiveAuthenticationManager> managers = new LinkedList<>();
        managers.add(userAuthenticationManager);
        return new DelegatingReactiveAuthenticationManager(managers);
    }

    @Bean
    public PasswordEncoder passwordEncoder() {
        return new BCryptPasswordEncoder();
    }
}

权限注解

java 复制代码
@EnableWebFluxSecurity
@EnableReactiveMethodSecurity
@Configuration
public class SecurityConfig {
	// ....
}
java 复制代码
@RestController
public class TestController {

    /**
     * 无效
     */
    @Secured({"ROLE_ADMIN"})
    @RequestMapping(value = "/test")
    public Mono<String> test() {
        return Mono.just("test");
    }

    /**
     * 有效
     */
    @PreAuthorize("hasRole('ADMIN')")
    @RequestMapping(value = "/test1")
    public Mono<String> test1() {
        return Mono.just("test1");
    }

    @Secured({"ROLE_TEST"})
    @RequestMapping(value = "/test2")
    public Mono<String> test2() {
        return Mono.just("test2");
    }
}

自定义权限处理器

java 复制代码
@Component
public class AccessDeniedHandler implements ServerAccessDeniedHandler {

    @Override
    public Mono<Void> handle(ServerWebExchange exchange, AccessDeniedException denied) {
        return Mono.defer(() -> Mono.just(exchange.getResponse()).flatMap(response -> {
            DataBufferFactory dataBufferFactory = response.bufferFactory();
            DataBuffer dataBuffer = dataBufferFactory.wrap("permission denied".getBytes());
            return response.writeWith(Mono.just(dataBuffer));
        }));
    }
}
java 复制代码
@EnableWebFluxSecurity
@EnableReactiveMethodSecurity
@Configuration
public class SecurityConfig {

    @Resource
    private LoginSuccessHandler loginSuccessHandler;
    @Resource
    private LoginFailHandler loginFailHandler;
    @Resource
    private LogoutSuccessHandler logoutSuccessHandler;
    @Resource
    private UserAuthenticationManager userAuthenticationManager;
    @Resource
    private AccessDeniedHandler accessDeniedHandler;

    @Bean
    public SecurityWebFilterChain filterChain(ServerHttpSecurity http) {
        http.httpBasic()
                .and()
                .authorizeExchange()
                .anyExchange()
                .authenticated();

        http.formLogin()
                .authenticationManager(authenticationManager())
                .authenticationSuccessHandler(loginSuccessHandler)
                .authenticationFailureHandler(loginFailHandler)
                .and()
                .logout()
                .logoutSuccessHandler(logoutSuccessHandler)
                .and()
                .exceptionHandling()
                .accessDeniedHandler(accessDeniedHandler);
        return http.build();
    }

    /**
     * 注册用户信息验证管理器，可按需求添加多个按顺序执行
     */
    @Bean
    public ReactiveAuthenticationManager authenticationManager() {
        LinkedList<ReactiveAuthenticationManager> managers = new LinkedList<>();
        managers.add(userAuthenticationManager);
        return new DelegatingReactiveAuthenticationManager(managers);
    }

    @Bean
    public PasswordEncoder passwordEncoder() {
        return new BCryptPasswordEncoder();
    }
}

自定义认证处理器

java 复制代码
@Component
public class AuthenticationEntryPoint implements ServerAuthenticationEntryPoint {

    @Override
    public Mono<Void> commence(ServerWebExchange exchange, AuthenticationException e) {
        return Mono.defer(() -> Mono.just(exchange.getResponse()).flatMap(response -> {
            DataBufferFactory dataBufferFactory = response.bufferFactory();
            DataBuffer dataBuffer = dataBufferFactory.wrap("Authentication fail".getBytes());
            return response.writeWith(Mono.just(dataBuffer));
        }));
    }
}
java 复制代码
@EnableWebFluxSecurity
@EnableReactiveMethodSecurity
@Configuration
public class SecurityConfig {

    @Resource
    private LoginSuccessHandler loginSuccessHandler;
    @Resource
    private LoginFailHandler loginFailHandler;
    @Resource
    private LogoutSuccessHandler logoutSuccessHandler;
    @Resource
    private UserAuthenticationManager userAuthenticationManager;
    @Resource
    private AccessDeniedHandler accessDeniedHandler;
    @Resource
    private AuthenticationEntryPoint authenticationEntryPoint;

    @Bean
    public SecurityWebFilterChain filterChain(ServerHttpSecurity http) {
        http.httpBasic()
                .and()
                .authorizeExchange()
                .anyExchange()
                .authenticated();

        http.formLogin()
                .authenticationManager(authenticationManager())
                .authenticationSuccessHandler(loginSuccessHandler)
                .authenticationFailureHandler(loginFailHandler)
                .and()
                .logout()
                .logoutSuccessHandler(logoutSuccessHandler)
                .and()
                .exceptionHandling()
                .accessDeniedHandler(accessDeniedHandler)
                .authenticationEntryPoint(authenticationEntryPoint);
        return http.build();
    }

    /**
     * 注册用户信息验证管理器，可按需求添加多个按顺序执行
     */
    @Bean
    public ReactiveAuthenticationManager authenticationManager() {
        LinkedList<ReactiveAuthenticationManager> managers = new LinkedList<>();
        managers.add(userAuthenticationManager);
        return new DelegatingReactiveAuthenticationManager(managers);
    }

    @Bean
    public PasswordEncoder passwordEncoder() {
        return new BCryptPasswordEncoder();
    }
}

自定义鉴权处理器

java 复制代码
@Slf4j
@Component
public class AuthorizeConfigManager implements ReactiveAuthorizationManager<AuthorizationContext> {

    private final AntPathMatcher antPathMatcher = new AntPathMatcher();

    @Override
    public Mono<AuthorizationDecision> check(Mono<Authentication> authentication,
                                             AuthorizationContext authorizationContext) {
        return authentication.map(auth -> {
            ServerWebExchange exchange = authorizationContext.getExchange();
            ServerHttpRequest request = exchange.getRequest();

            Collection<? extends GrantedAuthority> authorities = auth.getAuthorities();
            for (GrantedAuthority authority : authorities) {
                String authorityAuthority = authority.getAuthority();
                String path = request.getURI().getPath();
                if (antPathMatcher.match(authorityAuthority, path)) {
                    log.info(String.format("用户请求API校验通过，GrantedAuthority:{%s}  Path:{%s} ", authorityAuthority, path));
                    return new AuthorizationDecision(true);
                }
            }
            return new AuthorizationDecision(false);
        }).defaultIfEmpty(new AuthorizationDecision(false));
    }

    @Override
    public Mono<Void> verify(Mono<Authentication> authentication, AuthorizationContext object) {
        return check(authentication, object)
                .filter(AuthorizationDecision::isGranted)
                .switchIfEmpty(Mono.defer(() -> Mono.error(new AccessDeniedException("Access Denied"))))
                .flatMap(d -> Mono.empty());
    }
}
java 复制代码
@EnableWebFluxSecurity
@EnableReactiveMethodSecurity
@Configuration
public class SecurityConfig {

    @Resource
    private LoginSuccessHandler loginSuccessHandler;
    @Resource
    private LoginFailHandler loginFailHandler;
    @Resource
    private LogoutSuccessHandler logoutSuccessHandler;
    @Resource
    private UserAuthenticationManager userAuthenticationManager;
    @Resource
    private AccessDeniedHandler accessDeniedHandler;
    @Resource
    private AuthenticationEntryPoint authenticationEntryPoint;
    @Resource
    private AuthorizeConfigManager authorizeConfigManager;

    @Bean
    public SecurityWebFilterChain filterChain(ServerHttpSecurity http) {
        http.httpBasic()
                .and()
                .authorizeExchange(e -> e
                        .anyExchange()
                        .access(authorizeConfigManager));

        http.formLogin()
                .authenticationManager(authenticationManager())
                .authenticationSuccessHandler(loginSuccessHandler)
                .authenticationFailureHandler(loginFailHandler)
                .and()
                .logout()
                .logoutSuccessHandler(logoutSuccessHandler)
                .and()
                .exceptionHandling()
                .accessDeniedHandler(accessDeniedHandler)
                .authenticationEntryPoint(authenticationEntryPoint);
        return http.build();
    }

    /**
     * 注册用户信息验证管理器，可按需求添加多个按顺序执行
     */
    @Bean
    public ReactiveAuthenticationManager authenticationManager() {
        LinkedList<ReactiveAuthenticationManager> managers = new LinkedList<>();
        managers.add(userAuthenticationManager);
        return new DelegatingReactiveAuthenticationManager(managers);
    }

    @Bean
    public PasswordEncoder passwordEncoder() {
        return new BCryptPasswordEncoder();
    }
}
热门推荐
01我决定放弃搞 Java 了02RAG 实践- Ollama+RagFlow 部署本地知识库03DeepSeek各版本说明与优缺点分析04Mogao=Seedream 3.0？霸榜数天，神秘文生图模型曝光（附技术报告）05DeepSeek RAGFlow构建本地知识库系统06如何在WPS和Word/Excel中直接使用DeepSeek功能07第 9 关 | 心有灵犀的二分查找与中序遍历：1.青铜挑战——逢试必考的二分查找08汽车上的各种质量：整备质量、总质量、装载质量、簧上质量、簧下质量09本地化部署AI知识库：基于Ollama+DeepSeek+AnythingLLM保姆级教程10一键私有化部署Dify，轻松搞定 AI 智能客服机器人
