源码
省流点我进Github获取源码,欢迎fork、star、PR
颜色壁纸
颜色壁纸功能允许用户将纯色背景设置为桌面壁纸,通过程序化生成 BMP 格式的图片文件来实现。该功能支持自定义颜色选择,并提供预设的颜色列表供用户快速选择。
实现原理
1. 核心思路
颜色壁纸的实现原理是将十六进制颜色值转换为 BMP 格式的图片文件,然后通过系统 API 设置为桌面壁纸。整个过程包括:
- 颜色解析:将十六进制颜色值转换为 RGB 分量
- BMP 文件生成:创建符合 BMP 格式规范的图片文件
- 文件保存:将生成的图片保存到临时目录
- 壁纸设置:调用系统 API 将图片设置为桌面壁纸
2. 技术架构
用户选择颜色 → 渲染进程 → IPC → 主进程 → WallpaperManager → createSolidColorBMP → 系统API → 桌面壁纸
核心功能实现
1. 颜色壁纸设置入口
主进程 Store 中的设置方法:
js:src/main/store/index.mjs
// 设置颜色壁纸
async setColorWallpaper(color) {
await this.toggleAutoSwitchWallpaper(false)
// 关闭视频壁纸
this.wallpaperManager.closeDynamicWallpaper()
return await this.wallpaperManager.setColorWallpaper(
color || this.settingData.colorWallpaperVal
)
}
WallpaperManager 中的核心实现:
js:src/main/store/WallpaperManager.mjs
// 设置颜色壁纸
async setColorWallpaper(color) {
if (!color) {
return {
success: false,
message: t('messages.paramsError')
}
}
try {
const buffer = createSolidColorBMP(color)
const colorImagePath = path.join(process.env.FBW_TEMP_PATH, 'fbw-color-wallpaper.png')
fs.writeFileSync(colorImagePath, buffer)
return await this.setImageWallpaper(colorImagePath)
} catch (err) {
this.logger.error(`设置壁纸失败: error => ${err}`)
return {
success: false,
message: t('messages.setWallpaperFail')
}
}
}
2. BMP 图片生成算法
createSolidColorBMP 函数实现:
js:src/main/utils/utils.mjs
export const createSolidColorBMP = (color = '#000000', width = 100, height = 100) => {
// 解析颜色
const r = parseInt(color.slice(1, 3), 16)
const g = parseInt(color.slice(3, 5), 16)
const b = parseInt(color.slice(5, 7), 16)
// BMP 文件头和信息头
const fileHeaderSize = 14
const infoHeaderSize = 40
const rowSize = Math.ceil((24 * width) / 32) * 4
const pixelArraySize = rowSize * height
const fileSize = fileHeaderSize + infoHeaderSize + pixelArraySize
const buffer = Buffer.alloc(fileSize)
// BMP 文件头
buffer.write('BM') // Signature
buffer.writeUInt32LE(fileSize, 2) // File size
buffer.writeUInt32LE(0, 6) // Reserved
buffer.writeUInt32LE(fileHeaderSize + infoHeaderSize, 10) // Pixel data offset
// BMP 信息头
buffer.writeUInt32LE(infoHeaderSize, 14) // Info header size
buffer.writeInt32LE(width, 18) // Width
buffer.writeInt32LE(-height, 22) // Height (负数表示自上而下)
buffer.writeUInt16LE(1, 26) // Planes
buffer.writeUInt16LE(24, 28) // Bits per pixel
buffer.writeUInt32LE(0, 30) // Compression
buffer.writeUInt32LE(pixelArraySize, 34) // Image size
buffer.writeInt32LE(0, 38) // X pixels per meter
buffer.writeInt32LE(0, 42) // Y pixels per meter
buffer.writeUInt32LE(0, 46) // Colors used
buffer.writeUInt32LE(0, 50) // Important colors
// 填充像素数据
for (let y = 0; y < height; y++) {
for (let x = 0; x < width; x++) {
const pos = fileHeaderSize + infoHeaderSize + y * rowSize + x * 3
buffer[pos] = b
buffer[pos + 1] = g
buffer[pos + 2] = r
}
}
return buffer
}
BMP 文件格式详解
1. BMP 文件结构
BMP(Bitmap)文件由以下几个部分组成:
┌─────────────────┐
│ BMP 文件头 │ 14 字节
├─────────────────┤
│ BMP 信息头 │ 40 字节
├─────────────────┤
│ 像素数据 │ 可变长度
└─────────────────┘
2. 文件头(14 字节)
偏移量 | 大小 | 字段名 | 说明 |
---|---|---|---|
0x00 | 2 | Signature | 文件标识,固定为 'BM' |
0x02 | 4 | FileSize | 文件总大小(字节) |
0x06 | 4 | Reserved | 保留字段,必须为 0 |
0x0A | 4 | PixelDataOffset | 像素数据偏移量 |
代码实现:
js:src/main/utils/utils.mjs
// BMP 文件头
buffer.write('BM') // Signature
buffer.writeUInt32LE(fileSize, 2) // File size
buffer.writeUInt32LE(0, 6) // Reserved
buffer.writeUInt32LE(fileHeaderSize + infoHeaderSize, 10) // Pixel data offset
3. 信息头(40 字节)
偏移量 | 大小 | 字段名 | 说明 |
---|---|---|---|
0x0E | 4 | InfoHeaderSize | 信息头大小,固定为 40 |
0x12 | 4 | Width | 图片宽度(像素) |
0x16 | 4 | Height | 图片高度(像素),负数表示自上而下 |
0x1A | 2 | Planes | 颜色平面数,固定为 1 |
0x1C | 2 | BitsPerPixel | 每像素位数,24 表示真彩色 |
0x1E | 4 | Compression | 压缩方式,0 表示无压缩 |
0x22 | 4 | ImageSize | 像素数据大小 |
0x26 | 4 | XPixelsPerMeter | 水平分辨率 |
0x2A | 4 | YPixelsPerMeter | 垂直分辨率 |
0x2E | 4 | ColorsUsed | 使用的颜色数,0 表示所有颜色 |
0x32 | 4 | ImportantColors | 重要颜色数,0 表示所有颜色 |
代码实现:
js:src/main/utils/utils.mjs
// BMP 信息头
buffer.writeUInt32LE(infoHeaderSize, 14) // Info header size
buffer.writeInt32LE(width, 18) // Width
buffer.writeInt32LE(-height, 22) // Height (负数表示自上而下)
buffer.writeUInt16LE(1, 26) // Planes
buffer.writeUInt16LE(24, 28) // Bits per pixel
buffer.writeUInt32LE(0, 30) // Compression
buffer.writeUInt32LE(pixelArraySize, 34) // Image size
buffer.writeInt32LE(0, 38) // X pixels per meter
buffer.writeInt32LE(0, 42) // Y pixels per meter
buffer.writeUInt32LE(0, 46) // Colors used
buffer.writeUInt32LE(0, 50) // Important colors
4. 像素数据
行对齐计算:
js:src/main/utils/utils.mjs
const rowSize = Math.ceil((24 * width) / 32) * 4
BMP 格式要求每行的字节数必须是 4 的倍数。对于 24 位真彩色图片:
- 每个像素占用 3 字节(RGB)
- 每行实际需要的字节数:
width * 3
- 每行对齐后的字节数:
Math.ceil((width * 3) / 4) * 4
像素数据填充:
js:src/main/utils/utils.mjs
// 填充像素数据
for (let y = 0; y < height; y++) {
for (let x = 0; x < width; x++) {
const pos = fileHeaderSize + infoHeaderSize + y * rowSize + x * 3
buffer[pos] = b // 蓝色分量
buffer[pos + 1] = g // 绿色分量
buffer[pos + 2] = r // 红色分量
}
}
颜色顺序说明: BMP 格式使用 BGR(蓝-绿-红)颜色顺序,而不是常见的 RGB 顺序。
颜色系统
1. 预设颜色列表
colorList 定义:
js:src/renderer/windows/MainWindow/pages/Setting.vue
export const colorList = [
'#71956C', // 深绿色
'#E6A23C', // 橙黄色
'#F56C6C', // 红色
'#909399', // 灰色
'#67C23A', // 浅绿色
'#409EFF', // 蓝色
'#FF7F50', // 珊瑚橙
'#FFD700', // 金色
'#8A2BE2', // 紫罗兰
'#00CED1', // 深青
'#FF69B4', // 热粉色
'#DC143C', // 猩红
'#2E8B57', // 海绿色
'#4682B4', // 钢蓝色
'#7B68EE', // 中等紫罗兰
'#B22222', // 耐火砖红
'#40E0D0', // 绿松石
'#6A5ACD', // 板岩蓝
'#FF4500', // 橙红色
'#2F4F4F' // 深灰青色
]
2. 颜色解析算法
十六进制颜色解析:
js
// 解析颜色
const r = parseInt(color.slice(1, 3), 16) // 红色分量
const g = parseInt(color.slice(3, 5), 16) // 绿色分量
const b = parseInt(color.slice(5, 7), 16) // 蓝色分量
解析过程:
color.slice(1, 3)
:提取红色分量(第 2-3 位)parseInt(..., 16)
:将十六进制字符串转换为十进制数值- 重复上述过程获取绿色和蓝色分量
示例:
- 输入:
#FF7F50
- 红色:
parseInt('FF', 16) = 255
- 绿色:
parseInt('7F', 16) = 127
- 蓝色:
parseInt('50', 16) = 80
渲染进程界面
1. 设置页面颜色选择器
颜色壁纸设置界面:
vue
<el-form-item
:label="t('pages.Setting.settingDataForm.colorWallpaperVal.label')"
prop="colorWallpaperVal"
>
<el-color-picker
v-model="settingDataForm.colorWallpaperVal"
:disabled="flags.settingColorWallpaper"
:predefine="colorList"
@change="onSettingDataFormChange"
/>
<el-button
:disabled="!settingDataForm.colorWallpaperVal"
:loading="flags.settingColorWallpaper"
@click="onSetColorWallpaper"
style="margin-left: 10px"
>
<IconifyIcon icon="ep:check" />
</el-button>
</el-form-item>
2. 颜色壁纸设置函数
设置页面中的处理函数:
js
const onSetColorWallpaper = async () => {
flags.settingColorWallpaper = true
const res = await window.FBW.setColorWallpaper()
flags.settingColorWallpaper = false
ElMessage({
type: res.success ? 'success' : 'error',
message: res.message
})
}
3. 工具页面功能
工具页面中的颜色壁纸设置:
js
{
name: 'setColorWallpaper',
text: '设置颜色壁纸',
locale: 'pages.Utils.setColorWallpaper',
confirm: true
}
进程间通信
1. IPC 处理器
主进程 IPC 处理:
js
// 设置颜色壁纸
ipcMain.handle('main:setColorWallpaper', (event, color) => {
return this.setColorWallpaper(color)
})
2. 预加载脚本 API
渲染进程 API 接口:
js
const api = {
// 设置颜色壁纸
setColorWallpaper: (...args) => ipcRenderer.invoke('main:setColorWallpaper', ...args)
}
应用场景
1. 动态壁纸背景
Windows 动态壁纸背景设置:
js
if (isWin()) {
// 同时设置纯色背景壁纸图片,提高视角体验
const dynamicBackgroundColor = global.FBW.store?.settingData?.dynamicBackgroundColor || '#FFFFFF'
await global.FBW.store?.wallpaperManager.setColorWallpaper(dynamicBackgroundColor)
setWindowsDynamicWallpaper(this.win.getNativeWindowHandle().readInt32LE(0))
}
2. 律动壁纸背景
律动壁纸窗口背景设置:
js
if (isWin()) {
// 同时设置纯色背景壁纸图片,提高视角体验
const dynamicBackgroundColor = global.FBW.store?.settingData?.dynamicBackgroundColor || '#FFFFFF'
await global.FBW.store?.wallpaperManager.setColorWallpaper(dynamicBackgroundColor)
setWindowsDynamicWallpaper(this.win.getNativeWindowHandle().readInt32LE(0))
}
3. 动态壁纸背景色控制
动态壁纸背景色设置:
js
async setDynamicWallpaperBackgroundColor(color) {
if (!this.win) {
return { success: false, message: t('messages.noDynamicWallpaperSet') }
}
try {
return await global.FBW.store?.wallpaperManager.setColorWallpaper(color)
} catch (err) {
global.logger.error(`设置动态壁纸背景色失败: ${err}`)
return { success: false, message: err.message }
}
}
技术特点
1. 跨平台兼容性
操作系统差异处理:
js
await setWallpaper(imgPath, {
screen: this.settingData.allScreen && isMac() ? 'all' : 'main',
scale: this.settingData.scaleType
})
- Windows :支持多屏幕设置,使用
wallpaper
库 - macOS:支持所有屏幕或主屏幕设置
- Linux :使用标准的
wallpaper
库支持
2. 性能优化
临时文件管理:
js
const colorImagePath = path.join(process.env.FBW_TEMP_PATH, 'fbw-color-wallpaper.png')
- 使用临时目录存储生成的图片文件
- 固定文件名,避免重复生成
- 文件大小小,生成速度快
3. 错误处理
完整的错误处理机制:
js
try {
const buffer = createSolidColorBMP(color)
const colorImagePath = path.join(process.env.FBW_TEMP_PATH, 'fbw-color-wallpaper.png')
fs.writeFileSync(colorImagePath, buffer)
return await this.setImageWallpaper(colorImagePath)
} catch (err) {
this.logger.error(`设置壁纸失败: error => ${err}`)
return {
success: false,
message: t('messages.setWallpaperFail')
}
}
4. 国际化支持
多语言错误消息:
js
import { t } from '../../i18n/server.js'
return {
success: false,
message: t('messages.paramsError')
}
实现细节
1. 图片尺寸
默认尺寸设置:
js
export const createSolidColorBMP = (color = '#000000', width = 100, height = 100) => {
当前实现使用 100x100 像素的默认尺寸,这个尺寸足够作为桌面壁纸使用,同时保持文件大小最小。
2. 文件格式选择
为什么选择 BMP 格式:
- 简单性:BMP 格式结构简单,易于程序化生成
- 兼容性:所有操作系统都支持 BMP 格式作为壁纸
- 无压缩:不需要复杂的压缩算法,生成速度快
- 标准化:BMP 格式规范明确,实现可靠
3. 内存管理
Buffer 分配:
js
const buffer = Buffer.alloc(fileSize)
使用 Node.js 的 Buffer 类进行内存管理,确保内存使用高效且安全。
4. 文件系统操作
同步写入:
js
fs.writeFileSync(colorImagePath, buffer)
使用同步写入确保文件完全写入后再进行后续操作,避免异步操作可能导致的时序问题。
扩展功能
1. 颜色提取
从图片提取主色调:
js
export const extractDominantColor = async (filePath) => {
try {
// 将图片缩小到 1x1 像素以获取平均颜色
const { data } = await sharp(filePath)
.resize(1, 1, { fit: 'cover' })
.raw()
.toBuffer({ resolveWithObject: true })
// 根据图片通道数获取颜色值
const r = data[0]
const g = data[1]
const b = data[2]
// 返回十六进制颜色值
return `#${r.toString(16).padStart(2, '0')}${g.toString(16).padStart(2, '0')}${b.toString(16).padStart(2, '0')}`
} catch (err) {
global.logger.error(`提取图片主色调失败: ${filePath} error => ${err}`)
// 默认透明色
return '#00000000'
}
}
2. 渐变效果支持
律动壁纸中的颜色渐变:
js
getFill(type = 'linear', index = 0) {
const colors = this.config.colors || colorList
if (type === 'linear') {
return {
type: 'linear',
stops: colors.map((color, idx) => ({
color,
offset: idx / (colors.length - 1)
})),
from: 'top',
to: 'bottom'
}
} else if (type === 'radial') {
return {
type: 'radial',
stops: colors.map((color, idx) => ({
color,
offset: idx / (colors.length - 1)
})),
from: 'center'
}
}
}
总结
颜色壁纸功能通过程序化生成 BMP 格式的纯色图片文件,实现了将任意颜色设置为桌面壁纸的功能。该功能具有以下特点:
- 技术实现简单可靠:使用标准的 BMP 文件格式,兼容性好
- 性能高效:生成速度快,文件大小小
- 用户体验良好:提供预设颜色列表,支持自定义颜色
- 跨平台兼容:支持 Windows、macOS、Linux 三大操作系统
- 扩展性强:可以轻松集成到其他功能中,如动态壁纸背景
该功能为飞鸟壁纸提供了基础的纯色壁纸支持,同时为其他高级功能(如动态壁纸、律动壁纸)提供了背景色设置的基础。
