第二十节:3D文本渲染 - 字体几何体生成与特效
TextGeometry深度解析与高级文字效果实现

1. 核心概念解析
1.1 3D文字渲染技术对比
技术 | 原理 | 优点 | 缺点 |
---|---|---|---|
TextGeometry | 将字体轮廓转换为3D网格 | 真实3D效果,支持材质 | 性能开销大,内存占用高 |
Canvas纹理 | 将文字渲染到纹理并应用到平面 | 性能好,支持复杂字体 | 无真实3D深度,边缘锯齿 |
Signed Distance Fields | 使用距离场纹理渲染 | 缩放无损,效果锐利 | 需要预处理,特效有限 |
MSDF | 多通道距离场技术 | 高质量,支持小字号 | 实现复杂,兼容性问题 |
1.2 3D文字生成流程
字体文件加载 轮廓解析 几何体生成 材质应用 场景添加 挤出深度 斜面处理 UV映射 基础材质 描边效果 发光特效
2. 基础文字几何体创建
2.1 字体加载与解析
javascript
import { FontLoader } from 'three/addons/loaders/FontLoader';
import { TextGeometry } from 'three/addons/geometries/TextGeometry';
// 初始化字体加载器
const fontLoader = new FontLoader();
let font;
// 加载字体文件
fontLoader.load('/fonts/helvetiker_regular.typeface.json', (loadedFont) => {
font = loadedFont;
createText(); // 字体加载完成后创建文字
});
// 创建3D文字
function createText() {
const textGeometry = new TextGeometry('Hello Three.js', {
font: font,
size: 1, // 字体大小
height: 0.2, // 挤出深度
curveSegments: 12, // 曲线分段数
bevelEnabled: true, // 启用斜面
bevelThickness: 0.03, // 斜面厚度
bevelSize: 0.02, // 斜面大小
bevelOffset: 0, // 斜面偏移
bevelSegments: 5 // 斜面分段数
});
// 居中文字几何体
textGeometry.computeBoundingBox();
const centerOffset = -0.5 * (
textGeometry.boundingBox.max.x - textGeometry.boundingBox.min.x
);
textGeometry.translate(centerOffset, 0, 0);
// 创建材质
const textMaterial = new THREE.MeshStandardMaterial({
color: 0xffffff,
metalness: 0.5,
roughness: 0.2
});
// 创建网格
const textMesh = new THREE.Mesh(textGeometry, textMaterial);
textMesh.castShadow = true;
scene.add(textMesh);
}
2.2 文字几何体优化
javascript
// 优化文字几何体性能
function optimizeTextGeometry(geometry) {
// 合并顶点(减少draw calls)
geometry.mergeVertices();
// 计算法线(确保正确光照)
geometry.computeVertexNormals();
// 使用BufferGeometry提高性能
const bufferGeometry = new THREE.BufferGeometry().fromGeometry(geometry);
return bufferGeometry;
}
// 使用优化后的几何体
const optimizedGeometry = optimizeTextGeometry(textGeometry);
const textMesh = new THREE.Mesh(optimizedGeometry, textMaterial);
3. 高级文字特效
3.1 描边效果实现
javascript
// 创建描边文字效果
function createOutlinedText() {
const text = "Three.js";
// 主文字几何体
const mainGeometry = new TextGeometry(text, {
font: font,
size: 1,
height: 0.3,
bevelEnabled: true,
bevelThickness: 0.03,
bevelSize: 0.02
});
// 描边几何体(稍大一些)
const outlineGeometry = new TextGeometry(text, {
font: font,
size: 1.05, // 比主文字稍大
height: 0.3,
bevelEnabled: true,
bevelThickness: 0.03,
bevelSize: 0.02
});
// 居中处理
centerGeometry(mainGeometry);
centerGeometry(outlineGeometry);
// 创建材质
const mainMaterial = new THREE.MeshStandardMaterial({
color: 0x00ff88,
metalness: 0.7,
roughness: 0.2
});
const outlineMaterial = new THREE.MeshBasicMaterial({
color: 0x000000,
side: THREE.BackSide // 只渲染背面作为描边
});
// 创建组合网格
const mainText = new THREE.Mesh(mainGeometry, mainMaterial);
const outlineText = new THREE.Mesh(outlineGeometry, outlineMaterial);
// 将描边稍微向后移动以避免z-fighting
outlineText.position.z = -0.01;
// 创建组并添加
const textGroup = new THREE.Group();
textGroup.add(mainText);
textGroup.add(outlineText);
scene.add(textGroup);
return textGroup;
}
// 几何体居中函数
function centerGeometry(geometry) {
geometry.computeBoundingBox();
const center = new THREE.Vector3();
geometry.boundingBox.getCenter(center);
geometry.translate(-center.x, -center.y, -center.z);
}
3.2 发光文字效果
javascript
// 创建发光文字效果
function createGlowingText() {
const geometry = new TextGeometry('GLOW', {
font: font,
size: 1,
height: 0.2,
curveSegments: 24 // 更高分段数以获得更平滑的效果
});
centerGeometry(geometry);
// 使用ShaderMaterial创建发光效果
const material = new THREE.ShaderMaterial({
uniforms: {
time: { value: 0 },
glowColor: { value: new THREE.Color(0x00ffff) },
glowIntensity: { value: 1.5 }
},
vertexShader: `
varying vec2 vUv;
varying vec3 vNormal;
void main() {
vUv = uv;
vNormal = normal;
gl_Position = projectionMatrix * modelViewMatrix * vec4(position, 1.0);
}
`,
fragmentShader: `
uniform float time;
uniform vec3 glowColor;
uniform float glowIntensity;
varying vec2 vUv;
varying vec3 vNormal;
void main() {
// 基础颜色
vec3 baseColor = glowColor;
// 边缘发光效果(基于法线方向)
float intensity = pow(0.7 - dot(vNormal, vec3(0.0, 0.0, 1.0)), 4.0);
// 添加脉动效果
float pulse = sin(time * 2.0) * 0.5 + 0.5;
intensity += pulse * 0.3;
// 最终颜色
vec3 finalColor = baseColor * intensity * glowIntensity;
gl_FragColor = vec4(finalColor, 1.0);
}
`,
side: THREE.DoubleSide,
blending: THREE.AdditiveBlending,
transparent: true
});
const textMesh = new THREE.Mesh(geometry, material);
// 更新uniforms的动画
function animate() {
requestAnimationFrame(animate);
material.uniforms.time.value += 0.01;
renderer.render(scene, camera);
}
animate();
return textMesh;
}
3.3 渐变文字效果
javascript
// 创建渐变色彩文字
function createGradientText() {
const geometry = new TextGeometry('GRADIENT', {
font: font,
size: 1,
height: 0.3,
bevelEnabled: true,
bevelSegments: 3
});
centerGeometry(geometry);
// 为每个顶点计算颜色
const positionAttribute = geometry.getAttribute('position');
const colorArray = new Float32Array(positionAttribute.count * 3);
for (let i = 0; i < positionAttribute.count; i++) {
const x = positionAttribute.getX(i);
const y = positionAttribute.getY(i);
// 基于位置计算颜色
const r = (x + 2) / 4; // 从-2到2映射到0-1
const g = (y + 1) / 2; // 从-1到1映射到0-1
const b = 0.5;
colorArray[i * 3] = r;
colorArray[i * 3 + 1] = g;
colorArray[i * 3 + 2] = b;
}
geometry.setAttribute('color', new THREE.BufferAttribute(colorArray, 3));
// 使用顶点着色器实现渐变
const material = new THREE.ShaderMaterial({
uniforms: {
time: { value: 0 }
},
vertexShader: `
attribute vec3 color;
varying vec3 vColor;
void main() {
vColor = color;
gl_Position = projectionMatrix * modelViewMatrix * vec4(position, 1.0);
}
`,
fragmentShader: `
uniform float time;
varying vec3 vColor;
void main() {
// 添加动态效果
vec3 finalColor = vColor;
finalColor.r += sin(time) * 0.1;
finalColor.g += cos(time * 0.7) * 0.1;
gl_FragColor = vec4(finalColor, 1.0);
}
`
});
return new THREE.Mesh(geometry, material);
}
4. 性能优化与大批量文字处理
4.1 实例化文字渲染
javascript
// 使用InstancedMesh渲染大量文字
function createInstancedText() {
const text = "A";
const count = 1000; // 实例数量
// 创建基础文字几何体
const geometry = new TextGeometry(text, {
font: font,
size: 0.3,
height: 0.05
});
centerGeometry(geometry);
// 创建实例化网格
const instancedMesh = new THREE.InstancedMesh(
geometry,
new THREE.MeshStandardMaterial({ color: 0xffffff }),
count
);
// 创建变换矩阵和颜色
const matrix = new THREE.Matrix4();
const color = new THREE.Color();
for (let i = 0; i < count; i++) {
// 随机位置
const x = (Math.random() - 0.5) * 50;
const y = (Math.random() - 0.5) * 50;
const z = (Math.random() - 0.5) * 50;
// 随机旋转
const rx = Math.random() * Math.PI;
const ry = Math.random() * Math.PI;
const rz = Math.random() * Math.PI;
// 设置位置和旋转
matrix.compose(
new THREE.Vector3(x, y, z),
new THREE.Quaternion().setFromEuler(new THREE.Euler(rx, ry, rz)),
new THREE.Vector3(1, 1, 1)
);
instancedMesh.setMatrixAt(i, matrix);
// 随机颜色
color.setHSL(Math.random(), 0.7, 0.5);
instancedMesh.setColorAt(i, color);
}
scene.add(instancedMesh);
return instancedMesh;
}
4.2 文字LOD系统
javascript
// 实现文字细节层次系统
class TextLODSystem {
constructor() {
this.lodLevels = new Map();
this.currentLOD = 'high';
}
// 为文字创建不同细节级别
createLODLevels(text, font) {
const levels = {
high: this.createTextGeometry(text, font, 0.5, 32),
medium: this.createTextGeometry(text, font, 0.5, 16),
low: this.createTextGeometry(text, font, 0.5, 8),
verylow: this.createTextGeometry(text, font, 0.5, 4)
};
this.lodLevels.set(text, levels);
return levels;
}
createTextGeometry(text, font, size, segments) {
const geometry = new TextGeometry(text, {
font: font,
size: size,
height: size * 0.1,
curveSegments: segments,
bevelEnabled: segments > 8,
bevelThickness: size * 0.02,
bevelSize: size * 0.01,
bevelSegments: Math.floor(segments / 2)
});
centerGeometry(geometry);
return geometry;
}
// 根据距离选择LOD级别
updateLOD(cameraPosition, textPosition) {
const distance = cameraPosition.distanceTo(textPosition);
if (distance > 50) {
this.currentLOD = 'verylow';
} else if (distance > 25) {
this.currentLOD = 'low';
} else if (distance > 10) {
this.currentLOD = 'medium';
} else {
this.currentLOD = 'high';
}
}
// 获取当前LOD级别的几何体
getCurrentLODGeometry(text) {
const levels = this.lodLevels.get(text);
return levels ? levels[this.currentLOD] : null;
}
}
// 使用示例
const lodSystem = new TextLODSystem();
const textLevels = lodSystem.createLODLevels('LOD Text', font);
// 在渲染循环中更新LOD
function animate() {
requestAnimationFrame(animate);
lodSystem.updateLOD(camera.position, textMesh.position);
const currentGeometry = lodSystem.getCurrentLODGeometry('LOD Text');
if (currentGeometry) {
textMesh.geometry = currentGeometry;
}
renderer.render(scene, camera);
}
5. 完整案例:动态文字展示系统
javascript
class DynamicTextSystem {
constructor(scene, font) {
this.scene = scene;
this.font = font;
this.textMeshes = new Map();
this.animations = [];
}
// 创建文字元素
createText(text, options = {}) {
const {
size = 1,
position = new THREE.Vector3(0, 0, 0),
color = 0xffffff,
bevelEnabled = true,
animation = null
} = options;
const geometry = new TextGeometry(text, {
font: this.font,
size: size,
height: size * 0.2,
curveSegments: 12,
bevelEnabled: bevelEnabled,
bevelThickness: size * 0.03,
bevelSize: size * 0.02,
bevelSegments: 5
});
centerGeometry(geometry);
const material = new THREE.MeshStandardMaterial({
color: color,
metalness: 0.3,
roughness: 0.4
});
const textMesh = new THREE.Mesh(geometry, material);
textMesh.position.copy(position);
textMesh.userData.originalPosition = position.clone();
textMesh.castShadow = true;
this.scene.add(textMesh);
this.textMeshes.set(text, textMesh);
// 添加动画
if (animation) {
this.addAnimation(textMesh, animation);
}
return textMesh;
}
// 添加文字动画
addAnimation(textMesh, type) {
switch (type) {
case 'float':
this.animations.push(() => {
textMesh.position.y = textMesh.userData.originalPosition.y +
Math.sin(Date.now() * 0.001) * 0.3;
});
break;
case 'rotate':
this.animations.push(() => {
textMesh.rotation.y += 0.01;
});
break;
case 'pulse':
this.animations.push(() => {
const scale = 1 + Math.sin(Date.now() * 0.002) * 0.1;
textMesh.scale.set(scale, scale, scale);
});
break;
}
}
// 更新所有动画
update() {
this.animations.forEach(animation => animation());
}
// 更改文字内容
updateText(oldText, newText) {
const textMesh = this.textMeshes.get(oldText);
if (!textMesh) return;
this.textMeshes.delete(oldText);
this.scene.remove(textMesh);
const newMesh = this.createText(newText, {
size: textMesh.scale.x,
position: textMesh.position,
color: textMesh.material.color.getHex()
});
return newMesh;
}
// 批量创建文字
createTextGrid(texts, rows, cols, spacing) {
const group = new THREE.Group();
const count = Math.min(texts.length, rows * cols);
for (let i = 0; i < count; i++) {
const row = Math.floor(i / cols);
const col = i % cols;
const x = (col - cols / 2) * spacing;
const y = (rows / 2 - row) * spacing;
const textMesh = this.createText(texts[i], {
position: new THREE.Vector3(x, y, 0),
size: spacing * 0.4
});
group.add(textMesh);
}
this.scene.add(group);
return group;
}
}
// 使用示例
const textSystem = new DynamicTextSystem(scene, font);
// 创建单个文字
textSystem.createText('Hello', {
size: 1.5,
position: new THREE.Vector3(0, 2, 0),
color: 0xff6b6b,
animation: 'float'
});
// 创建文字网格
const texts = ['One', 'Two', 'Three', 'Four', 'Five', 'Six'];
textSystem.createTextGrid(texts, 2, 3, 3);
// 在渲染循环中更新
function animate() {
requestAnimationFrame(animate);
textSystem.update();
renderer.render(scene, camera);
}
6. 注意事项与重点核心
6.1 字体加载与性能
字体文件选择:
- 使用
.typeface.json
格式的字体文件 - 避免使用中文字体(文件过大),或使用子集化字体
- 考虑使用系统字体+Canvas纹理的方案替代
加载性能优化:
javascript
// 预加载字体
function preloadFonts(fontUrls) {
const loader = new FontLoader();
const promises = fontUrls.map(url => {
return new Promise((resolve) => {
loader.load(url, resolve);
});
});
return Promise.all(promises);
}
// 使用示例
const fontUrls = [
'/fonts/helvetiker_regular.typeface.json',
'/fonts/gentilis_regular.typeface.json'
];
preloadFonts(fontUrls).then(fonts => {
const [mainFont, secondaryFont] = fonts;
// 字体加载完成后的初始化
});
6.2 内存管理
几何体清理:
javascript
// 正确释放文字几何体内存
function disposeTextGeometry(textMesh) {
if (textMesh.geometry) {
textMesh.geometry.dispose();
}
if (textMesh.material) {
if (Array.isArray(textMesh.material)) {
textMesh.material.forEach(material => material.dispose());
} else {
textMesh.material.dispose();
}
}
scene.remove(textMesh);
}
// 批量清理
function cleanupTextMeshes() {
textSystem.textMeshes.forEach((mesh, text) => {
disposeTextGeometry(mesh);
});
textSystem.textMeshes.clear();
}
6.3 移动端适配
性能优化策略:
- 减少曲线分段数 :设置
curveSegments: 4-8
- 禁用斜面 :设置
bevelEnabled: false
- 使用简单字体:避免复杂轮廓的字体
- 限制文字数量:同一场景不超过50个文字网格
- 使用Canvas纹理:对静态文字使用纹理替代几何体
触控交互优化:
javascript
// 为文字添加交互
function makeTextInteractive(textMesh) {
textMesh.userData.interactive = true;
// 射线检测
raycaster.setFromCamera(mouse, camera);
const intersects = raycaster.intersectObject(textMesh);
if (intersects.length > 0) {
// 文字被点击或悬停
textMesh.material.color.set(0xff0000);
}
}
下一节预告:环境贴图与PBR材质
第二十一节:HDRI光照与金属粗糙度工作流
核心内容:
- HDR环境贴图加载与处理
- PBR材质原理与参数调节
- 金属度/粗糙度工作流实战
- 环境反射与折射效果实现
重点掌握:创建逼真的物理渲染材质,掌握现代3D渲染的核心技术。
