Playwright02-CDP

playwright自动化开发记录，学习BrowserUse的时候涉及到playwright和udp-use的知识点

1-核心知识点

1-运行playwright第一个demo

2-参考网址

1-用Playwright实现接口自动化测试：https://www.cnblogs.com/wzzkaifa/p/19113578
2-playwright开源仓库：https://github.com/microsoft/playwright

3-动手实操

1-UV环境搭建

bash 复制代码

# 1-uv环境搭建
uv python pin 3.11.4
uv init python_playwright && cd python_playwright
uv venv && source .venv/bin/activate
uv add python-dotenv pydantic playwright

# 2-安装playwright-刷新应用
uv add playwright
source .venv/bin/activate

# 3-playwright安装chromium(当前只安装了chrome浏览器)
playwright install chromium

2-CDP接口开发

cdp-use 是一个为 Chrome DevTools Protocol（CDP）生成的 类型安全 Python 客户端库

方案 A：完全交给 Playwright

不关心真实 WebSocket 地址，只拿到"默认上下文里已有的页面"

python 复制代码

import time

from playwright.sync_api import sync_playwright

with sync_playwright() as p:
    # 1. 启动浏览器，并强制开启远程调试端口
    browser = p.chromium.launch(
        headless=False,
        args=["--remote-debugging-port=9222"]  # 开启 CDP 端口
    )
    # 2. 新建标签页
    page = browser.new_page()
    # 3. 打开目标网址
    web_url = "https://www.baidu.com/"

    try:
        # 设置更长的超时时间，并添加异常处理
        page.goto(web_url, timeout=60000)
        print("浏览器 成功打开浏览器：", web_url)
    except Exception as e:
        print(f"页面加载失败: {e}")
        browser.close()
        exit(1)

    # 4. 简单等待，方便肉眼观察
    time.sleep(3)

    # 5. 直接通过 playwright 自己的连接拿到同一浏览器
    try:
        browser2 = p.chromium.connect_over_cdp("http://localhost:9222")
        browser_contexts = browser2.contexts[0]
        print("=======browser_contexts响应数据结构========")
        print(browser_contexts)
        print("=======browser_contexts响应数据结构========\n")
        default_ctx_page = browser_contexts.pages[0]  # 默认上下文里已有的页面
        print("默认页面标题：", default_ctx_page.title())
        # 5. 关闭
        browser2.close()
    except Exception as e:
        print(f"连接到CDP时出错: {e}")
    finally:
        browser.close()

运行结果示例：

复制代码

已连接到 pydev 调试器(内部版本号 231.9225.15)浏览器 成功打开浏览器： https://www.baidu.com/
=======browser_contexts响应数据结构========
<BrowserContext browser=<Browser type=<BrowserType name=chromium executable_path=/Users/rong/Library/Caches/ms-playwright/chromium-1194/chrome-mac/Chromium.app/Contents/MacOS/Chromium> version=141.0.7390.37>>
=======browser_contexts响应数据结构========

方案 B：Playwright 控制+WebSocket 地址

既要 Playwright 控制，也要"真实的 WebSocket 地址"

python 复制代码

import json
import time
import requests
from playwright.sync_api import sync_playwright

with sync_playwright() as p:
    # 1. 启动浏览器，并强制开启远程调试端口
    browser = p.chromium.launch(
        headless=False,
        args=["--remote-debugging-port=9222"]  # 开启 CDP 端口
    )
    # 2. 新建标签页
    page = browser.new_page()
    # 3. 打开目标网址
    web_url = "https://www.baidu.com/"

    try:
        # 设置更长的超时时间，并添加异常处理
        page.goto(web_url, timeout=60000)
        print("浏览器 成功打开浏览器：", web_url)
    except Exception as e:
        print(f"页面加载失败: {e}")
        browser.close()
        exit(1)

    # 4. 简单等待，方便肉眼观察
    time.sleep(3)

    # 5. 自己取一次 /json/version 拿到 webSocketDebuggerUrl
    try:
        resp = requests.get("http://localhost:9222/json/version", timeout=5)
        print("=======json_version响应数据结构========")
        print(json.dumps(resp.json(), indent=2, ensure_ascii=False))
        print("=======json_version响应数据结构========\n")
        ws_url = resp.json()["webSocketDebuggerUrl"]
        print("浏览器 WebSocket 地址：", ws_url)

        # 如果还想继续用 playwright 操纵同一浏览器
        browser2 = p.chromium.connect_over_cdp("http://localhost:9222")
        default_page = browser2.contexts[0].pages[0]
        print("默认页面标题：", default_page.title())

        browser2.close()
    except requests.exceptions.RequestException as e:
        print(f"无法连接到调试地址: {e}")
    except Exception as e:
        print(f"处理调试连接时出错: {e}")
    finally:
        browser.close()

运行结果示例：

复制代码

已连接到 pydev 调试器(内部版本号 231.9225.15)浏览器 成功打开浏览器： https://www.baidu.com/
=======json_version响应数据结构========
{
  "Browser": "Chrome/141.0.7390.37",
  "Protocol-Version": "1.3",
  "User-Agent": "Mozilla/5.0 (Macintosh; Intel Mac OS X 10_15_7) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/141.0.0.0 Safari/537.36",
  "V8-Version": "14.1.146.11",
  "WebKit-Version": "537.36 (@9f043f63b0e5b728c8d09f3e3ddfc1681a4bd58e)",
  "webSocketDebuggerUrl": "ws://localhost:9222/devtools/browser/27e882e5-8999-4a81-8d1f-9092e6698d61"
}
=======json_version响应数据结构========

浏览器 WebSocket 地址： ws://localhost:9222/devtools/browser/27e882e5-8999-4a81-8d1f-9092e6698d61
默认页面标题： 百度一下，你就知道

至此，你既拿到了"真实的 CDP WebSocket 地址"，也通过 Playwright 取得了"默认上下文里已有的页面"。
