一、项目概述
1.1 背景与目标
为服刑人员家属提供其亲人所在监狱的实时天气信息，结合用户设备与环境数据，实现精准、关怀化的天气服务体验。
核心目标矩阵：
┌─────────────────┬─────────────────────────────┐
│ 数据维度 │ 技术实现目标 │
├─────────────────┼─────────────────────────────┤
│ 手机型号分析 │ 设备适配与推送优化 │
│ IP位置定位 │ 用户位置智能识别 │
│ 监狱地理信息 │ 精准天气数据匹配 │
│ 用户行为数据 │ 个性化天气关怀 │
└─────────────────┴─────────────────────────────┘1.2 核心价值
温度感知 → 情感连接 → 心理关怀
1. 知道亲人所在地天气冷暖
2. 根据天气发送关怀提醒
3. 建立情感连接桥梁
4. 提供实用生活建议二、技术架构设计
2.1 系统整体架构
┌─────────────────────────────────────────┐
│ 数据采集层 │
│ 设备信息 → IP定位 → 监狱数据库 → 天气API │
└──────────────┬──────────────────────────┘
│
▼
┌─────────────────────────────────────────┐
│ 智能分析引擎 │
│ 位置匹配 → 天气解析 → 关怀规则 → 个性化生成 │
└──────────────┬──────────────────────────┘
│
▼
┌─────────────────────────────────────────┐
│ 服务输出层 │
│ 天气卡片 → 关怀提醒 → 穿衣建议 → 预警通知 │
└─────────────────────────────────────────┘2.2 数据流向图
三、核心技术实现
3.1 设备与位置智能识别
# 智能位置识别服务
class SmartLocationService:
"""多维度位置识别引擎"""
def __init__(self):
self.ip_service = IPLocationService()
self.device_parser = DeviceParser()
self.prison_db = PrisonDatabase()
async def analyze_user_context(self, request) -> dict:
"""分析用户上下文环境"""
analysis_result = {}
# 1. 设备信息解析
device_info = self.parse_device_info(request.headers)
analysis_result['device'] = device_info
# 2. IP地理位置识别
ip_location = await self.ip_service.locate(request.remote_addr)
analysis_result['ip_location'] = ip_location
# 3. 监狱信息匹配（基于用户选择的监狱）
prison_info = await self.get_prison_info(request.user.prison_id)
analysis_result['prison_location'] = prison_info['location']
# 4. 位置关系分析
location_relation = self.analyze_location_relation(
ip_location,
prison_info['location']
)
analysis_result['relation'] = location_relation
return analysis_result
def parse_device_info(self, headers: dict) -> dict:
"""解析设备信息（支持多厂商）"""
user_agent = headers.get('User-Agent', '')
# iOS设备解析
if 'iPhone' in user_agent or 'iPad' in user_agent:
return self._parse_ios_device(user_agent)
# 安卓设备解析
elif 'Android' in user_agent:
return self._parse_android_device(user_agent)
# 华为鸿蒙设备
elif 'HarmonyOS' in user_agent:
return self._parse_harmony_device(user_agent)
# 小米设备
elif 'Mi' in user_agent or 'XiaoMi' in user_agent:
return self._parse_xiaomi_device(user_agent)
# 其他设备
else:
return self._parse_generic_device(user_agent)
def _parse_android_device(self, ua: str) -> dict:
"""解析安卓设备信息"""
# 示例UA：Mozilla/5.0 (Linux; Android 13; SM-S9180) AppleWebKit/537.36
device_info = {
'os': 'Android',
'os_version': '',
'brand': '',
'model': '',
'screen_size': '',
'push_service': 'FCM' # 默认推送服务
}
# 提取安卓版本
if 'Android' in ua:
import re
version_match = re.search(r'Android (\d+)', ua)
if version_match:
device_info['os_version'] = version_match.group(1)
# 识别品牌和型号
brands = {
'SM-': 'Samsung',
'MI ': 'Xiaomi',
'Redmi': 'Xiaomi',
'HUAWEI': 'Huawei',
'OPPO': 'OPPO',
'PEDM': 'OPPO', # OPPO某些型号
'VOG': 'Huawei', # P30系列
'VCE': 'Vivo',
'ONE': 'OnePlus'
}
for prefix, brand in brands.items():
if prefix in ua:
device_info['brand'] = brand
# 提取具体型号
model_match = re.search(r'\([^)]*?([A-Z]+-[A-Z0-9]+)\)', ua)
if model_match:
device_info['model'] = model_match.group(1)
break
# 根据品牌设置推送服务
push_services = {
'Huawei': 'HMS',
'Xiaomi': 'MiPush',
'OPPO': 'OPPOPush',
'Vivo': 'VivoPush',
'Samsung': 'FCM',
'default': 'FCM'
}
device_info['push_service'] = push_services.get(
device_info['brand'],
push_services['default']
)
return device_info
def _parse_ios_device(self, ua: str) -> dict:
"""解析iOS设备信息"""
# 示例UA：Mozilla/5.0 (iPhone; CPU iPhone OS 16_6 like Mac OS X)
device_info = {
'os': 'iOS',
'os_version': '',
'brand': 'Apple',
'model': '',
'push_service': 'APNs'
}
# 提取iOS版本
import re
version_match = re.search(r'CPU (?:iPhone )?OS (\d+_\d+)', ua)
if version_match:
device_info['os_version'] = version_match.group(1).replace('_', '.')
# 识别iPhone型号
if 'iPhone' in ua:
# 根据分辨率等特征识别具体型号
if 'iPhone15,3' in ua or 'iPhone15,4' in ua:
device_info['model'] = 'iPhone 14 Pro'
elif 'iPhone14,7' in ua:
device_info['model'] = 'iPhone 14'
# 更多型号识别...
return device_info3.2 IP智能定位引擎
# IP定位与监狱匹配服务
class IntelligentIPLocator:
"""智能IP定位与监狱匹配"""
def __init__(self):
# IP定位服务（多源冗余）
self.ip_services = [
{'name': 'ipapi', 'url': 'https://ipapi.co/{ip}/json/'},
{'name': 'ipinfo', 'url': 'https://ipinfo.io/{ip}/json'},
{'name': 'taobao', 'url': 'https://ip.taobao.com/service/getIpInfo.php?ip={ip}'}
]
# 监狱地理位置数据库
self.prison_locations = self.load_prison_geodata()
async def locate_with_fallback(self, ip_address: str) -> dict:
"""多源IP定位（带降级策略）"""
location_data = None
# 尝试第一个服务
try:
location_data = await self.query_ip_service(0, ip_address)
if location_data and self.validate_location(location_data):
return self.format_location_data(location_data)
except Exception:
pass
# 尝试第二个服务
try:
location_data = await self.query_ip_service(1, ip_address)
if location_data and self.validate_location(location_data):
return self.format_location_data(location_data)
except Exception:
pass
# 尝试第三个服务
try:
location_data = await self.query_ip_service(2, ip_address)
if location_data and self.validate_location(location_data):
return self.format_location_data(location_data)
except Exception:
pass
# 所有服务都失败，返回默认位置（北京）
return {
'city': '北京',
'province': '北京',
'country': '中国',
'latitude': 39.9042,
'longitude': 116.4074,
'accuracy': 'low'
}
async def find_nearest_prisons(self, user_location: dict, limit: int = 3) -> list:
"""查找用户附近的监狱"""
from geopy.distance import geodesic
user_coords = (user_location['latitude'], user_location['longitude'])
prisons_with_distance = []
for prison in self.prison_locations:
prison_coords = (prison['latitude'], prison['longitude'])
distance = geodesic(user_coords, prison_coords).kilometers
prisons_with_distance.append({
'prison': prison,
'distance_km': round(distance, 1),
'direction': self.calculate_direction(user_coords, prison_coords)
})
# 按距离排序
prisons_with_distance.sort(key=lambda x: x['distance_km'])
return prisons_with_distance[:limit]
def calculate_direction(self, from_coords, to_coords) -> str:
"""计算方位角"""
import math
lat1, lon1 = math.radians(from_coords[0]), math.radians(from_coords[1])
lat2, lon2 = math.radians(to_coords[0]), math.radians(to_coords[1])
d_lon = lon2 - lon1
y = math.sin(d_lon) * math.cos(lat2)
x = math.cos(lat1) * math.sin(lat2) - math.sin(lat1) * math.cos(lat2) * math.cos(d_lon)
bearing = math.degrees(math.atan2(y, x))
bearing = (bearing + 360) % 360
# 转换为中文方位
directions = ['北', '东北', '东', '东南', '南', '西南', '西', '西北']
idx = round(bearing / 45) % 8
return directions[idx]3.3 监狱天气智能匹配
# 监狱天气服务
class PrisonWeatherService:
"""监狱天气智能服务"""
def __init__(self):
self.weather_api = WeatherAPI()
self.prison_db = PrisonDatabase()
self.care_rules = CareRules()
async def get_prison_weather(self, prison_id: str, user_context: dict = None) -> dict:
"""获取监狱天气信息（带智能分析）"""
# 1. 获取监狱基本信息
prison_info = await self.prison_db.get_prison(prison_id)
# 2. 获取监狱所在地天气
weather_data = await self.weather_api.get_weather(
city=prison_info['city'],
province=prison_info['province']
)
# 3. 如果有用户上下文，进行对比分析
if user_context:
user_weather = await self.get_user_weather(user_context)
comparison = self.compare_weathers(user_weather, weather_data)
else:
comparison = None
# 4. 生成关怀建议
care_suggestions = self.generate_care_suggestions(
weather_data,
prison_info,
user_context
)
# 5. 构建响应
return {
'prison_info': {
'name': prison_info['name'],
'city': prison_info['city'],
'province': prison_info['province'],
'address': prison_info.get('address', ''),
'climate_zone': prison_info.get('climate_zone', '') # 气候带
},
'weather': {
'current': self.format_current_weather(weather_data),
'forecast': self.format_forecast(weather_data),
'alerts': self.extract_alerts(weather_data)
},
'comparison': comparison,
'care_suggestions': care_suggestions,
'updated_at': datetime.now().isoformat()
}
def generate_care_suggestions(self, weather: dict, prison: dict, user_context: dict = None) -> dict:
"""生成关怀建议"""
suggestions = {
'dressing': [],
'health': [],
'emotional': [],
'practical': []
}
# 基于温度的建议
temp = weather.get('temperature', 20)
if temp < 0:
suggestions['dressing'].append('监狱所在地气温低于0°C，建议提醒亲人添加厚衣物')
suggestions['health'].append('严寒天气，注意防寒保暖，预防感冒')
elif temp < 10:
suggestions['dressing'].append('气温较低，建议穿羽绒服或厚外套')
elif temp > 30:
suggestions['dressing'].append('气温较高，建议穿轻薄透气的衣物')
suggestions['health'].append('高温天气，注意防暑降温，多补充水分')
# 基于天气现象的建议
weather_desc = weather.get('description', '').lower()
if '雨' in weather_desc:
suggestions['practical'].append('监狱所在地有雨，邮寄物品请注意防水包装')
suggestions['emotional'].append('雨天易让人情绪低落，可以多写一些鼓励的话语')
if '雪' in weather_desc:
suggestions['dressing'].append('下雪天气，道路湿滑，注意安全')
suggestions['emotional'].append('雪景虽美，但天气寒冷，提醒亲人注意保暖')
if '雾' in weather_desc or '霾' in weather_desc:
suggestions['health'].append('空气质量较差，建议减少户外活动')
# 基于季节的建议
current_month = datetime.now().month
if current_month in [12, 1, 2]: # 冬季
suggestions['emotional'].append('寒冬时节，一封家书最能温暖人心')
elif current_month in [6, 7, 8]: # 夏季
suggestions['practical'].append('夏季炎热，可以邮寄一些清凉用品')
# 基于用户距离的建议
if user_context and 'distance_km' in user_context:
distance = user_context['distance_km']
if distance > 500:
suggestions['emotional'].append(f'您距离亲人{distance}公里，虽然遥远，但心在一起')
return suggestions
def compare_weathers(self, user_weather: dict, prison_weather: dict) -> dict:
"""对比用户所在地与监狱所在地天气"""
comparison = {
'temperature_diff': prison_weather.get('temperature', 0) - user_weather.get('temperature', 0),
'weather_similarity': self.calculate_weather_similarity(user_weather, prison_weather),
'season_same': self.check_same_season(user_weather, prison_weather),
'notable_differences': []
}
# 温度差异提醒
temp_diff = abs(comparison['temperature_diff'])
if temp_diff > 10:
comparison['notable_differences'].append(
f"温度差异较大（相差{temp_diff}°C），请注意气候变化"
)
# 天气状况差异
if user_weather.get('description') != prison_weather.get('description'):
comparison['notable_differences'].append(
f"您这里{user_weather.get('description', '')}，监狱那边{prison_weather.get('description', '')}"
)
return comparison3.4 天气数据智能缓存
# 天气数据缓存与更新策略
class WeatherCacheManager:
"""天气数据智能缓存"""
def __init__(self):
self.redis_client = redis.Redis(
host='localhost',
port=6379,
db=0,
decode_responses=True
)
# 缓存策略配置
self.cache_policies = {
'current_weather': {
'ttl': 600, # 10分钟
'key_pattern': 'weather:current:{city_code}'
},
'forecast': {
'ttl': 3600, # 1小时
'key_pattern': 'weather:forecast:{city_code}'
},
'alerts': {
'ttl': 300, # 5分钟
'key_pattern': 'weather:alerts:{city_code}'
}
}
# 城市到监狱的映射关系
self.city_prison_map = self.build_city_prison_map()
async def get_weather_with_cache(self, city_code: str, weather_type: str = 'current') -> dict:
"""获取带缓存的天气数据"""
policy = self.cache_policies.get(weather_type)
if not policy:
return await self.fetch_fresh_weather(city_code, weather_type)
cache_key = policy['key_pattern'].format(city_code=city_code)
# 尝试从缓存获取
cached_data = self.redis_client.get(cache_key)
if cached_data:
try:
data = json.loads(cached_data)
# 检查数据新鲜度
if self.is_data_fresh(data, policy['ttl']):
return data
except:
pass
# 缓存未命中或过期，获取新数据
fresh_data = await self.fetch_fresh_weather(city_code, weather_type)
# 存入缓存
if fresh_data:
cache_data = {
'data': fresh_data,
'timestamp': datetime.now().isoformat(),
'source': 'api'
}
self.redis_client.setex(
cache_key,
policy['ttl'],
json.dumps(cache_data)
)
# 更新相关监狱的缓存
await self.update_related_prisons_cache(city_code, fresh_data)
return fresh_data
async def update_related_prisons_cache(self, city_code: str, weather_data: dict):
"""更新相关监狱的天气缓存"""
# 查找该城市的所有监狱
prisons = self.city_prison_map.get(city_code, [])
for prison_id in prisons:
prison_key = f"prison:weather:{prison_id}"
# 获取现有监狱天气数据
cached_prison_weather = self.redis_client.get(prison_key)
if cached_prison_weather:
try:
prison_weather = json.loads(cached_prison_weather)
# 更新天气部分
prison_weather['data']['weather'] = weather_data
prison_weather['timestamp'] = datetime.now().isoformat()
# 重新保存
self.redis_client.setex(
prison_key,
600, # 10分钟
json.dumps(prison_weather)
)
except:
pass
def build_city_prison_map(self) -> dict:
"""构建城市到监狱的映射关系"""
# 从数据库获取所有监狱信息
prisons = Prison.objects.all().values('id', 'city_code')
city_map = {}
for prison in prisons:
city_code = prison['city_code']
prison_id = prison['id']
if city_code not in city_map:
city_map[city_code] = []
city_map[city_code].append(prison_id)
return city_map四、前端展示方案
4.1 天气关怀卡片设计
<!-- 监狱天气关怀卡片组件 -->
<template>
<div class="weather-care-card" :class="weatherClass">
<!-- 头部：监狱信息 -->
<div class="card-header">
<div class="prison-info">
<h3>{{ prisonName }}</h3>
<p class="prison-location">
<i class="icon-location"></i>
{{ province }} {{ city }}
<span v-if="distance" class="distance">(距您{{ distance }}km)</span>
</p>
</div>
<div class="weather-icon">
<i :class="weatherIconClass"></i>
</div>
</div>
<!-- 主体：天气信息 -->
<div class="card-body">
<div class="current-weather">
<div class="temperature">
<span class="temp-value">{{ currentTemp }}</span>
<span class="temp-unit">°C</span>
</div>
<div class="weather-desc">
<p>{{ weatherDescription }}</p>
<p class="feels-like">体感温度 {{ feelsLike }}°C</p>
</div>
</div>
<!-- 天气详情 -->
<div class="weather-details">
<div class="detail-item">
<i class="icon-humidity"></i>
<span>湿度 {{ humidity }}%</span>
</div>
<div class="detail-item">
<i class="icon-wind"></i>
<span>{{ windDirection }}风 {{ windSpeed }}级</span>
</div>
<div class="detail-item">
<i class="icon-pressure"></i>
<span>气压 {{ pressure }}hPa</span>
</div>
</div>
<!-- 天气对比（如果有关联用户） -->
<div v-if="weatherComparison" class="weather-comparison">
<div class="comparison-title">
<i class="icon-comparison"></i>
<span>与您所在地对比</span>
</div>
<div class="comparison-content">
<p v-if="temperatureDiff > 0">
监狱比您这里温暖{{ Math.abs(temperatureDiff) }}°C
</p>
<p v-else-if="temperatureDiff < 0">
监狱比您这里寒冷{{ Math.abs(temperatureDiff) }}°C
</p>
<p v-else>
两地温度相近
</p>
</div>
</div>
</div>
<!-- 底部：关怀建议 -->
<div class="card-footer">
<div class="care-suggestions">
<h4><i class="icon-care"></i> 关怀建议</h4>
<ul>
<li v-for="(suggestion, index) in careSuggestions" :key="index">
{{ suggestion }}
</li>
</ul>
</div>
<!-- 快捷操作 -->
<div class="quick-actions">
<button @click="shareWeather" class="btn-share">
<i class="icon-share"></i> 分享天气
</button>
<button @click="sendCareMessage" class="btn-care">
<i class="icon-message"></i> 发送关怀
</button>
<button @click="setReminder" class="btn-reminder">
<i class="icon-reminder"></i> 天气提醒
</button>
</div>
</div>
<!-- 更新时间 -->
<div class="card-updated">
更新时间: {{ updatedTime }}
</div>
</div>
</template>
<script>
export default {
name: 'PrisonWeatherCard',
props: {
prisonData: {
type: Object,
required: true
},
userLocation: {
type: Object,
default: null
}
},
data() {
return {
// 从props中提取数据
prisonName: this.prisonData.prison_info.name,
province: this.prisonData.prison_info.province,
city: this.prisonData.prison_info.city,
weather: this.prisonData.weather,
careSuggestions: this.extractCareSuggestions(this.prisonData.care_suggestions),
distance: this.calculateDistance(),
weatherComparison: this.prisonData.comparison
}
},
computed: {
currentTemp() {
return this.weather.current.temperature || 20
},
weatherDescription() {
return this.weather.current.description || '晴'
},
feelsLike() {
return this.weather.current.feels_like || this.currentTemp
},
humidity() {
return this.weather.current.humidity || 50
},
windSpeed() {
return this.weather.current.wind_speed || 2
},
windDirection() {
return this.weather.current.wind_direction || '东'
},
pressure() {
return this.weather.current.pressure || 1013
},
weatherIconClass() {
const desc = this.weatherDescription.toLowerCase()
if (desc.includes('晴')) return 'icon-sunny'
if (desc.includes('云')) return 'icon-cloudy'
if (desc.includes('雨')) return 'icon-rainy'
if (desc.includes('雪')) return 'icon-snowy'
if (desc.includes('雾') || desc.includes('霾')) return 'icon-foggy'
return 'icon-default'
},
weatherClass() {
const temp = this.currentTemp
if (temp < 0) return 'weather-freezing'
if (temp < 10) return 'weather-cold'
if (temp < 25) return 'weather-comfortable'
if (temp < 35) return 'weather-warm'
return 'weather-hot'
},
temperatureDiff() {
return this.weatherComparison?.temperature_diff || 0
},
updatedTime() {
return new Date(this.prisonData.updated_at).toLocaleString('zh-CN')
}
},
methods: {
extractCareSuggestions(suggestionsObj) {
const allSuggestions = []
Object.values(suggestionsObj).forEach(category => {
allSuggestions.push(...category)
})
return allSuggestions.slice(0, 3) // 只显示前3条
},
calculateDistance() {
if (!this.userLocation || !this.prisonData.prison_info.coordinates) {
return null
}
// 计算距离的逻辑
return this.calcDistance(
this.userLocation.latitude,
this.userLocation.longitude,
this.prisonData.prison_info.coordinates.latitude,
this.prisonData.prison_info.coordinates.longitude
)
},
calcDistance(lat1, lon1, lat2, lon2) {
// 简化版距离计算（Haversine公式）
const R = 6371 // 地球半径（公里）
const dLat = this.toRad(lat2 - lat1)
const dLon = this.toRad(lon2 - lon1)
const a =
Math.sin(dLat/2) * Math.sin(dLat/2) +
Math.cos(this.toRad(lat1)) * Math.cos(this.toRad(lat2)) *
Math.sin(dLon/2) * Math.sin(dLon/2)
const c = 2 * Math.atan2(Math.sqrt(a), Math.sqrt(1-a))
return Math.round(R * c)
},
toRad(degrees) {
return degrees * (Math.PI/180)
},
shareWeather() {
// 分享天气信息
const shareData = {
title: `${this.prisonName}天气情况`,
text: `${this.prisonName}（${this.province}${this.city}）现在${this.weatherDescription}，温度${this.currentTemp}°C`,
url: window.location.href
}
if (navigator.share) {
navigator.share(shareData)
} else {
// 降级处理
this.copyToClipboard(shareData.text)
this.$toast.success('已复制天气信息到剪贴板')
}
},
sendCareMessage() {
// 跳转到写信页面，并预填充天气相关关怀内容
const message = `最近${this.city}天气${this.weatherDescription}，温度${this.currentTemp}°C，${this.careSuggestions[0] || '请注意身体'}`
this.$router.push({
path: '/write-letter',
query: {
preset_message: message,
prison_id: this.prisonData.prison_info.id
}
})
},
setReminder() {
// 设置天气变化提醒
this.$emit('set-reminder', {
prisonId: this.prisonData.prison_info.id,
prisonName: this.prisonName,
currentWeather: this.weatherDescription,
currentTemp: this.currentTemp
})
}
}
}
</script>
<style scoped>
.weather-care-card {
background: linear-gradient(135deg, #667eea 0%, #764ba2 100%);
border-radius: 20px;
color: white;
padding: 20px;
margin: 15px;
box-shadow: 0 10px 30px rgba(0,0,0,0.2);
position: relative;
overflow: hidden;
}
.weather-care-card.weather-freezing {
background: linear-gradient(135deg, #74b9ff 0%, #0984e3 100%);
}
.weather-care-card.weather-cold {
background: linear-gradient(135deg, #a8e6cf 0%, #56CCF2 100%);
}
.weather-care-card.weather-comfortable {
background: linear-gradient(135deg, #667eea 0%, #764ba2 100%);
}
.weather-care-card.weather-warm {
background: linear-gradient(135deg, #f093fb 0%, #f5576c 100%);
}
.weather-care-card.weather-hot {
background: linear-gradient(135deg, #f6d365 0%, #fda085 100%);
}
.card-header {
display: flex;
justify-content: space-between;
align-items: flex-start;
margin-bottom: 20px;
}
.prison-info h3 {
margin: 0;
font-size: 1.3em;
font-weight: bold;
}
.prison-location {
margin: 5px 0 0 0;
font-size: 0.9em;
opacity: 0.9;
}
.distance {
font-size: 0.8em;
opacity: 0.7;
}
.weather-icon {
font-size: 2.5em;
}
.current-weather {
display: flex;
align-items: center;
margin-bottom: 20px;
}
.temperature {
font-size: 3em;
font-weight: bold;
margin-right: 20px;
}
.temp-unit {
font-size: 0.5em;
vertical-align: super;
}
.weather-desc p {
margin: 5px 0;
}
.feels-like {
font-size: 0.9em;
opacity: 0.8;
}
.weather-details {
display: flex;
justify-content: space-around;
margin: 20px 0;
padding: 15px;
background: rgba(255,255,255,0.1);
border-radius: 10px;
}
.detail-item {
display: flex;
flex-direction: column;
align-items: center;
font-size: 0.9em;
}
.detail-item i {
font-size: 1.2em;
margin-bottom: 5px;
}
.weather-comparison {
background: rgba(255,255,255,0.15);
border-radius: 10px;
padding: 15px;
margin: 20px 0;
}
.comparison-title {
display: flex;
align-items: center;
margin-bottom: 10px;
}
.comparison-title i {
margin-right: 8px;
}
.card-footer {
margin-top: 20px;
}
.care-suggestions h4 {
margin: 0 0 10px 0;
display: flex;
align-items: center;
}
.care-suggestions h4 i {
margin-right: 8px;
}
.care-suggestions ul {
margin: 0;
padding-left: 20px;
}
.care-suggestions li {
margin-bottom: 5px;
font-size: 0.9em;
}
.quick-actions {
display: flex;
justify-content: space-between;
margin-top: 20px;
}
.quick-actions button {
flex: 1;
margin: 0 5px;
padding: 10px;
border: none;
border-radius: 8px;
background: rgba(255,255,255,0.2);
color: white;
font-size: 0.9em;
cursor: pointer;
transition: background 0.3s;
display: flex;
justify-content: center;
align-items: center;
}
.quick-actions button:hover {
background: rgba(255,255,255,0.3);
}
.quick-actions button i {
margin-right: 5px;
}
.card-updated {
text-align: center;
margin-top: 15px;
font-size: 0.8em;
opacity: 0.7;
}
</style>4.2 监狱天气地图组件
<!-- 监狱天气地图视图 -->
<template>
<div class="weather-map-container">
<!-- 地图区域 -->
<div class="map-area" ref="mapContainer"></div>
<!-- 侧边栏：监狱列表 -->
<div class="sidebar">
<div class="sidebar-header">
<h3>监狱天气列表</h3>
<div class="search-box">
<input
v-model="searchQuery"
placeholder="搜索监狱或城市..."
type="text"
/>
</div>
</div>
<div class="prison-list">
<div
v-for="prison in filteredPrisons"
:key="prison.id"
class="prison-item"
:class="{ active: activePrisonId === prison.id }"
@click="selectPrison(prison)"
>
<div class="prison-item-main">
<div class="prison-name">{{ prison.name }}</div>
<div class="prison-location">{{ prison.city }}, {{ prison.province }}</div>
<div class="prison-weather">
<span class="weather-temp">{{ prison.weather?.current?.temperature || '--' }}°C</span>
<span class="weather-desc">{{ prison.weather?.current?.description || '未知' }}</span>
</div>
</div>
<div class="prison-distance" v-if="prison.distance">
{{ prison.distance }}km
</div>
</div>
</div>
</div>
<!-- 底部工具栏 -->
<div class="toolbar">
<div class="toolbar-left">
<button @click="locateUser" class="toolbar-btn">
<i class="icon-location"></i> 定位我
</button>
<button @click="toggleTemperatureLayer" class="toolbar-btn">
<i class="icon-temperature"></i> {{ showTemperature ? '隐藏' : '显示' }}温度
</button>
<button @click="toggleWeatherLayer" class="toolbar-btn">
<i class="icon-weather"></i> {{ showWeather ? '隐藏' : '显示' }}天气
</button>
</div>
<div class="toolbar-right">
<button @click="refreshWeather" class="toolbar-btn refresh-btn">
<i class="icon-refresh"></i> 刷新天气
</button>
</div>
</div>
</div>
</template>
<script>
import AMapLoader from '@amap/amap-jsapi-loader'
export default {
name: 'PrisonWeatherMap',
data() {
return {
map: null,
markers: [],
searchQuery: '',
activePrisonId: null,
showTemperature: true,
showWeather: true,
userLocation: null,
prisons: []
}
},
computed: {
filteredPrisons() {
if (!this.searchQuery) return this.prisons
const query = this.searchQuery.toLowerCase()
return this.prisons.filter(prison => {
return (
prison.name.toLowerCase().includes(query) ||
prison.city.toLowerCase().includes(query) ||
prison.province.toLowerCase().includes(query)
)
})
}
},
async mounted() {
await this.initMap()
await this.loadPrisonData()
await this.getUserLocation()
this.renderPrisonMarkers()
},
methods: {
async initMap() {
try {
// 加载高德地图
const AMap = await AMapLoader.load({
key: 'your-amap-key',
version: '2.0',
plugins: ['AMap.Weather', 'AMap.Geolocation']
})
// 创建地图实例
this.map = new AMap.Map(this.$refs.mapContainer, {
zoom: 5,
center: [116.397428, 39.90923], // 北京中心
viewMode: '3D'
})
// 添加天气插件
this.weatherPlugin = new AMap.Weather()
// 添加定位控件
const geolocation = new AMap.Geolocation({
enableHighAccuracy: true,
timeout: 10000,
buttonOffset: new AMap.Pixel(10, 20),
panToLocation: true,
zoomToAccuracy: true
})
this.map.addControl(geolocation)
// 监听地图点击
this.map.on('click', (e) => {
this.activePrisonId = null
})
} catch (error) {
console.error('地图初始化失败:', error)
}
},
async loadPrisonData() {
try {
// 从API获取监狱数据
const response = await this.$api.get('/api/prisons/weather')
this.prisons = response.data
// 为每个监狱获取天气信息
for (const prison of this.prisons) {
const weather = await this.$api.get(`/api/weather/prison/${prison.id}`)
prison.weather = weather.data
}
} catch (error) {
console.error('加载监狱数据失败:', error)
}
},
async getUserLocation() {
try {
const position = await new Promise((resolve, reject) => {
navigator.geolocation.getCurrentPosition(resolve, reject, {
enableHighAccuracy: true,
timeout: 5000,
maximumAge: 0
})
})
this.userLocation = {
latitude: position.coords.latitude,
longitude: position.coords.longitude
}
// 在地图上标记用户位置
if (this.map) {
const AMap = await AMapLoader.load()
const userMarker = new AMap.Marker({
position: [this.userLocation.longitude, this.userLocation.latitude],
title: '我的位置',
icon: '//a.amap.com/jsapi_demos/static/demo-center/icons/poi-marker-default.png',
offset: new AMap.Pixel(-13, -30)
})
userMarker.setMap(this.map)
// 计算每个监狱与用户的距离
this.calculateDistances()
}
} catch (error) {
console.warn('获取用户位置失败:', error)
}
},
calculateDistances() {
if (!this.userLocation) return
const AMap = window.AMap
if (!AMap) return
this.prisons.forEach(prison => {
if (prison.longitude && prison.latitude) {
const distance = AMap.GeometryUtil.distance(
[this.userLocation.longitude, this.userLocation.latitude],
[prison.longitude, prison.latitude]
)
prison.distance = Math.round(distance / 1000) // 转换为公里
}
})
// 按距离排序
this.prisons.sort((a, b) => (a.distance || Infinity) - (b.distance || Infinity))
},
renderPrisonMarkers() {
if (!this.map || !window.AMap) return
// 清除现有标记
this.markers.forEach(marker => marker.setMap(null))
this.markers = []
const AMap = window.AMap
// 为每个监狱创建标记
this.prisons.forEach(prison => {
if (!prison.longitude || !prison.latitude) return
// 根据天气设置标记颜色
const temp = prison.weather?.current?.temperature || 20
let color = '#4CAF50' // 默认绿色
if (temp < 0) color = '#2196F3' // 蓝色，寒冷
if (temp > 30) color = '#FF9800' // 橙色，炎热
// 创建标记
const marker = new AMap.Marker({
position: [prison.longitude, prison.latitude],
title: `${prison.name}\n温度: ${temp}°C`,
map: this.map,
icon: this.createCustomIcon(color, prison.weather?.current?.description),
extData: prison
})
// 添加点击事件
marker.on('click', (e) => {
this.selectPrison(prison)
this.map.setCenter([prison.longitude, prison.latitude])
this.map.setZoom(12)
})
this.markers.push(marker)
})
},
createCustomIcon(color, weatherDesc) {
// 创建自定义图标
const size = 40
const svg = `
<svg width="${size}" height="${size}" viewBox="0 0 ${size} ${size}">
<circle cx="${size/2}" cy="${size/2}" r="${size/2 - 2}"
fill="${color}" stroke="white" stroke-width="2"/>
<text x="${size/2}" y="${size/2 + 4}"
text-anchor="middle" fill="white" font-size="12">
${this.getWeatherIcon(weatherDesc)}
</text>
</svg>
`
return new window.AMap.Icon({
size: new window.AMap.Size(size, size),
imageSize: new window.AMap.Size(size, size)
})
},
getWeatherIcon(desc) {
if (!desc) return '☀️'
const descLower = desc.toLowerCase()
if (descLower.includes('晴')) return '☀️'
if (descLower.includes('云')) return '☁️'
if (descLower.includes('雨')) return '🌧️'
if (descLower.includes('雪')) return '❄️'
if (descLower.includes('雷')) return '⛈️'
if (descLower.includes('雾') || descLower.includes('霾')) return '🌫️'
return '🌤️'
},
selectPrison(prison) {
this.activePrisonId = prison.id
// 聚焦到选中的监狱
if (this.map) {
this.map.setCenter([prison.longitude, prison.latitude])
this.map.setZoom(12)
}
// 触发父组件事件
this.$emit('prison-selected', prison)
},
locateUser() {
if (this.userLocation && this.map) {
this.map.setCenter([this.userLocation.longitude, this.userLocation.latitude])
this.map.setZoom(12)
} else {
this.$toast.info('正在获取您的位置...')
this.getUserLocation()
}
},
toggleTemperatureLayer() {
this.showTemperature = !this.showTemperature
// 切换温度图层显示
},
toggleWeatherLayer() {
this.showWeather = !this.showWeather
// 切换天气图层显示
},
async refreshWeather() {
this.$toast.loading('正在更新天气数据...')
try {
await this.loadPrisonData()
this.renderPrisonMarkers()
this.$toast.success('天气数据更新成功')
} catch (error) {
this.$toast.error('更新天气数据失败')
}
}
}
}
</script>
<style scoped>
.weather-map-container {
position: relative;
width: 100%;
height: 600px;
border-radius: 10px;
overflow: hidden;
}
.map-area {
width: 100%;
height: 100%;
}
.sidebar {
position: absolute;
top: 20px;
left: 20px;
width: 320px;
background: white;
border-radius: 10px;
box-shadow: 0 4px 20px rgba(0,0,0,0.15);
max-height: calc(100% - 40px);
display: flex;
flex-direction: column;
}
.sidebar-header {
padding: 20px;
border-bottom: 1px solid #eee;
}
.sidebar-header h3 {
margin: 0 0 15px 0;
color: #333;
}
.search-box input {
width: 100%;
padding: 10px 15px;
border: 1px solid #ddd;
border-radius: 8px;
font-size: 14px;
outline: none;
}
.search-box input:focus {
border-color: #667eea;
}
.prison-list {
flex: 1;
overflow-y: auto;
max-height: 400px;
}
.prison-item {
padding: 15px 20px;
border-bottom: 1px solid #f5f5f5;
cursor: pointer;
transition: background-color 0.2s;
}
.prison-item:hover {
background-color: #f9f9f9;
}
.prison-item.active {
background-color: #eef2ff;
border-left: 4px solid #667eea;
}
.prison-item-main {
flex: 1;
}
.prison-name {
font-weight: bold;
color: #333;
margin-bottom: 5px;
}
.prison-location {
font-size: 12px;
color: #666;
margin-bottom: 8px;
}
.prison-weather {
display: flex;
align-items: center;
gap: 10px;
}
.weather-temp {
font-size: 16px;
font-weight: bold;
color: #f39c12;
}
.weather-desc {
font-size: 12px;
color: #666;
background: #f5f5f5;
padding: 2px 8px;
border-radius: 10px;
}
.prison-distance {
font-size: 12px;
color: #888;
background: #f0f0f0;
padding: 2px 8px;
border-radius: 10px;
}
.toolbar {
position: absolute;
bottom: 20px;
left: 0;
right: 0;
display: flex;
justify-content: space-between;
padding: 0 20px;
}
.toolbar-left, .toolbar-right {
display: flex;
gap: 10px;
}
.toolbar-btn {
padding: 10px 15px;
background: white;
border: none;
border-radius: 8px;
box-shadow: 0 2px 8px rgba(0,0,0,0.1);
cursor: pointer;
display: flex;
align-items: center;
gap: 5px;
font-size: 14px;
transition: all 0.2s;
}
.toolbar-btn:hover {
background: #f5f5f5;
transform: translateY(-1px);
box-shadow: 0 4px 12px rgba(0,0,0,0.15);
}
.refresh-btn {
background: #667eea;
color: white;
}
.refresh-btn:hover {
background: #5a67d8;
}
</style>五、智能推送策略
5.1 天气关怀推送引擎
# 智能天气推送服务
class WeatherCarePushService:
"""天气关怀智能推送"""
def __init__(self):
self.push_clients = {
'ios': APNsClient(),
'android_fcm': FCMClient(),
'huawei': HMSClient(),
'xiaomi': MiPushClient(),
'oppo': OPPOPushClient(),
'vivo': VivoPushClient()
}
self.push_rules = self.load_push_rules()
async def send_weather_care_push(self, user_id: str, prison_weather: dict):
"""发送天气关怀推送"""
# 1. 获取用户设备信息
user_device = await self.get_user_device(user_id)
if not user_device:
return
# 2. 获取推送客户端
push_client = self.get_push_client(user_device)
# 3. 生成个性化推送内容
push_content = self.generate_push_content(
user_id,
prison_weather,
user_device
)
# 4. 发送推送
try:
result = await push_client.send(
device_token=user_device['device_token'],
title=push_content['title'],
body=push_content['body'],
data=push_content['data'],
badge=push_content.get('badge', 1)
)
# 5. 记录推送日志
await self.log_push_activity(
user_id=user_id,
push_type='weather_care',
content=push_content,
result=result,
prison_id=prison_weather['prison_info']['id']
)
return result
except Exception as e:
logger.error(f"推送发送失败: {str(e)}")
return None
def generate_push_content(self, user_id: str, prison_weather: dict, device_info: dict) -> dict:
"""生成个性化推送内容"""
prison_name = prison_weather['prison_info']['name']
weather = prison_weather['weather']['current']
# 根据天气情况选择推送模板
temp = weather.get('temperature', 20)
description = weather.get('description', '')
# 温度相关推送
if temp < 0:
title = "❄️ 天寒地冻，牵挂更暖"
body = f"{prison_name}现在零下{abs(temp)}°C，提醒亲人注意防寒保暖"
elif temp < 10:
title = "🧥 天气转凉，添衣保暖"
body = f"{prison_name}气温{temp}°C，记得提醒亲人加衣"
elif temp > 30:
title = "☀️ 炎炎夏日，注意防暑"
body = f"{prison_name}高温{temp}°C，提醒亲人多喝水防中暑"
elif '雨' in description:
title = "🌧️ 雨天关怀，温暖问候"
body = f"{prison_name}正在下雨，温度{temp}°C，送去您的问候"
elif '雪' in description:
title = "❄️ 雪花纷飞，牵挂更浓"
body = f"{prison_name}正在下雪，温度{temp}°C，提醒亲人注意保暖"
else:
title = "🌤️ 天气晴好，送去问候"
body = f"{prison_name}天气{description}，温度{temp}°C，一切安好"
# 添加关怀建议
care_suggestions = prison_weather['care_suggestions']
if care_suggestions.get('dressing'):
body += f"，{care_suggestions['dressing'][0]}"
# 构建推送数据
push_data = {
'type': 'weather_care',
'prison_id': prison_weather['prison_info']['id'],
'prison_name': prison_name,
'temperature': temp,
'weather': description,
'timestamp': int(time.time()),
'deep_link': f"weiaibang://weather/prison/{prison_weather['prison_info']['id']}"
}
return {
'title': title,
'body': body,
'data': push_data,
'sound': 'default',
'badge': 1
}
def get_push_client(self, device_info: dict):
"""根据设备信息获取推送客户端"""
platform = device_info.get('platform', '').lower()
brand = device_info.get('brand', '').lower()
# 安卓设备根据品牌选择推送服务
if platform == 'android':
if 'huawei' in brand:
return self.push_clients['huawei']
elif 'xiaomi' in brand or 'redmi' in brand:
return self.push_clients['xiaomi']
elif 'oppo' in brand:
return self.push_clients['oppo']
elif 'vivo' in brand:
return self.push_clients['vivo']
else:
return self.push_clients['android_fcm']
# iOS设备
elif platform == 'ios':
return self.push_clients['ios']
# 默认使用FCM
else:
return self.push_clients['android_fcm']
async def schedule_daily_weather_push(self):
"""安排每日天气推送"""
# 获取所有关注了监狱天气的用户
users = await self.get_weather_subscribed_users()
for user in users:
# 获取用户关注的监狱
prisons = await self.get_user_subscribed_prisons(user['id'])
for prison in prisons:
# 获取监狱天气
weather_service = PrisonWeatherService()
prison_weather = await weather_service.get_prison_weather(prison['id'])
# 检查是否需要推送（根据天气变化或特殊天气）
should_push = self.should_send_push(user, prison, prison_weather)
if should_push:
# 发送推送
await self.send_weather_care_push(user['id'], prison_weather)
# 避免短时间内发送过多推送
await asyncio.sleep(0.1)
def should_send_push(self, user: dict, prison: dict, weather: dict) -> bool:
"""判断是否需要发送推送"""
# 检查用户推送设置
if not user.get('weather_push_enabled', True):
return False
# 检查推送频率限制
last_push = self.get_last_push_time(user['id'], prison['id'])
if last_push and time.time() - last_push < 3600: # 1小时内不重复推送
return False
# 检查天气变化是否需要推送
weather_changes = self.check_weather_changes(prison['id'], weather)
if weather_changes['significant_change']:
return True
# 特殊天气推送
current_weather = weather['weather']['current']
if self.is_special_weather(current_weather):
return True
# 定时推送（如每日早上8点）
if self.is_scheduled_push_time():
return True
return False
def is_special_weather(self, weather: dict) -> bool:
"""判断是否为特殊天气"""
temp = weather.get('temperature', 20)
description = weather.get('description', '').lower()
# 极端温度
if temp < -5 or temp > 35:
return True
# 恶劣天气
severe_keywords = ['暴雨', '大雪', '冰雹', '台风', '沙尘', '雾霾']
for keyword in severe_keywords:
if keyword in description:
return True
return False六、数据监控与分析
6.1 天气服务监控
# 天气服务监控器
class WeatherServiceMonitor:
"""天气服务质量监控"""
def __init__(self):
self.metrics = {
'api_calls': Counter(),
'cache_hits': Counter(),
'response_times': [],
'error_rates': [],
'user_satisfaction': []
}
self.alert_rules = self.load_alert_rules()
async def monitor_weather_service(self):
"""监控天气服务运行状态"""
while True:
try:
# 1. 收集服务指标
metrics = await self.collect_metrics()
# 2. 分析服务质量
quality_score = self.analyze_service_quality(metrics)
# 3. 检查告警条件
alerts = self.check_alerts(metrics, quality_score)
# 4. 发送告警通知
if alerts:
await self.send_alerts(alerts)
# 5. 生成监控报告
report = self.generate_monitor_report(metrics, quality_score)
self.save_report(report)
# 6. 等待下一次监控
await asyncio.sleep(60) # 每分钟监控一次
except Exception as e:
logger.error(f"监控任务异常: {str(e)}")
await asyncio.sleep(30)
async def collect_metrics(self) -> dict:
"""收集服务指标"""
metrics = {
'timestamp': datetime.now().isoformat(),
'api': {
'total_calls': self.metrics['api_calls'].value(),
'success_rate': self.calculate_success_rate(),
'avg_response_time': self.calculate_avg_response_time(),
'error_codes': self.get_error_codes()
},
'cache': {
'hit_rate': self.calculate_cache_hit_rate(),
'miss_rate': self.calculate_cache_miss_rate(),
'avg_cache_time': self.calculate_avg_cache_time()
},
'user': {
'active_users': await self.get_active_users_count(),
'satisfaction_score': self.calculate_satisfaction_score(),
'feature_usage': await self.get_feature_usage()
},
'performance': {
'memory_usage': psutil.virtual_memory().percent,
'cpu_usage': psutil.cpu_percent(),
'disk_usage': psutil.disk_usage('/').percent
}
}
return metrics
def analyze_service_quality(self, metrics: dict) -> float:
"""分析服务质量"""
quality_factors = {
'api_success_rate': {
'weight': 0.3,
'value': metrics['api']['success_rate'],
'threshold': 0.95 # 成功率需达到95%
},
'avg_response_time': {
'weight': 0.25,
'value': metrics['api']['avg_response_time'],
'threshold': 2000 # 平均响应时间需小于2秒
},
'cache_hit_rate': {
'weight': 0.2,
'value': metrics['cache']['hit_rate'],
'threshold': 0.7 # 缓存命中率需达到70%
},
'user_satisfaction': {
'weight': 0.25,
'value': metrics['user']['satisfaction_score'],
'threshold': 4.0 # 用户满意度需达到4分（5分制）
}
}
# 计算质量得分
total_score = 0
for factor_name, factor in quality_factors.items():
factor_score = min(1.0, factor['value'] / factor['threshold'])
total_score += factor_score * factor['weight']
return total_score * 100 # 转换为百分比
def check_alerts(self, metrics: dict, quality_score: float) -> list:
"""检查告警条件"""
alerts = []
# API成功率告警
if metrics['api']['success_rate'] < 0.9:
alerts.append({
'level': 'critical',
'type': 'api_success_rate',
'message': f'API成功率低于90%: {metrics["api"]["success_rate"]:.2%}',
'value': metrics['api']['success_rate']
})
# 响应时间告警
if metrics['api']['avg_response_time'] > 5000:
alerts.append({
'level': 'warning',
'type': 'response_time',
'message': f'平均响应时间超过5秒: {metrics["api"]["avg_response_time"]}ms',
'value': metrics['api']['avg_response_time']
})
# 服务质量告警
if quality_score < 80:
alerts.append({
'level': 'warning',
'type': 'service_quality',
'message': f'服务质量评分低于80分: {quality_score:.1f}',
'value': quality_score
})
# 系统资源告警
if metrics['performance']['memory_usage'] > 90:
alerts.append({
'level': 'critical',
'type': 'memory_usage',
'message': f'内存使用率超过90%: {metrics["performance"]["memory_usage"]}%',
'value': metrics['performance']['memory_usage']
})
return alerts七、部署与维护
7.1 部署架构
# docker-compose.yml 天气服务部署配置
version: '3.8'
services:
# 天气API服务
weather-api:
image: weiaibang/weather-service:latest
container_name: weather-api
ports:
- "8080:8080"
environment:
- REDIS_URL=redis://redis:6379
- DATABASE_URL=postgresql://user:pass@postgres:5432/weather
- AMAP_API_KEY=${AMAP_API_KEY}
- WEATHER_API_KEY=${WEATHER_API_KEY}
volumes:
- ./logs:/app/logs
healthcheck:
test: ["CMD", "curl", "-f", "http://localhost:8080/health"]
interval: 30s
timeout: 10s
retries: 3
networks:
- weiaibang-network
# Redis缓存
redis:
image: redis:7-alpine
container_name: weather-redis
ports:
- "6379:6379"
volumes:
- redis-data:/data
command: redis-server --appendonly yes
networks:
- weiaibang-network
# PostgreSQL数据库
postgres:
image: postgres:15-alpine
container_name: weather-db
environment:
- POSTGRES_USER=weather_user
- POSTGRES_PASSWORD=${DB_PASSWORD}
- POSTGRES_DB=weather_db
volumes:
- postgres-data:/var/lib/postgresql/data
ports:
- "5432:5432"
networks:
- weiaibang-network
# 监控服务
monitor:
image: weiaibang/weather-monitor:latest
container_name: weather-monitor
environment:
- WEATHER_API_URL=http://weather-api:8080
- ALERT_WEBHOOK=${ALERT_WEBHOOK}
volumes:
- ./monitor-config:/app/config
networks:
- weiaibang-network
networks:
weiaibang-network:
driver: bridge
volumes:
redis-data:
postgres-data:7.2 监控面板配置
// Grafana监控面板配置
const weatherDashboard = {
dashboard: {
title: "微爱帮天气服务监控",
panels: [
{
title: "API调用成功率",
type: "stat",
targets: [
{
expr: 'sum(rate(weather_api_calls_total{status="success"}[5m])) / sum(rate(weather_api_calls_total[5m]))',
legendFormat: "成功率"
}
],
fieldConfig: {
thresholds: {
steps: [
{ value: 0, color: "red" },
{ value: 0.9, color: "yellow" },
{ value: 0.95, color: "green" }
]
}
}
},
{
title: "平均响应时间",
type: "timeseries",
targets: [
{
expr: 'rate(weather_api_duration_seconds_sum[5m]) / rate(weather_api_duration_seconds_count[5m])',
legendFormat: "响应时间"
}
],
fieldConfig: {
unit: "s",
decimals: 2
}
},
{
title: "缓存命中率",
type: "stat",
targets: [
{
expr: 'sum(rate(weather_cache_hits_total[5m])) / sum(rate(weather_cache_total[5m]))',
legendFormat: "命中率"
}
],
fieldConfig: {
unit: "percentunit",
decimals: 2
}
},
{
title: "活跃用户数",
type: "timeseries",
targets: [
{
expr: 'sum(weather_active_users)',
legendFormat: "活跃用户"
}
]
},
{
title: "用户满意度",
type: "gauge",
targets: [
{
expr: 'avg(weather_user_satisfaction)',
legendFormat: "满意度"
}
],
fieldConfig: {
min: 0,
max: 5,
thresholds: {
steps: [
{ value: 0, color: "red" },
{ value: 3, color: "yellow" },
{ value: 4, color: "green" }
]
}
}
}
]
}
};八、技术指标与效果
8.1 性能指标
性能目标:
响应时间:
- 天气查询平均响应: < 500ms
- 缓存命中响应: < 100ms
- 推送发送延迟: < 1s
可用性:
- 服务可用性: > 99.9%
- API成功率: > 99%
- 数据新鲜度: < 10分钟
扩展性:
- 支持并发用户: > 10,000
- 日请求处理: > 1,000,000
- 数据存储: > 1TB8.2 业务效果
# 业务效果评估
class BusinessImpactAnalysis:
"""业务影响分析"""
def analyze_weather_feature_impact(self):
"""分析天气功能对业务的影响"""
impact_metrics = {
'user_engagement': {
'description': '用户参与度提升',
'before': 65, # 使用前
'after': 82, # 使用后
'improvement': '+26%'
},
'retention_rate': {
'description': '用户留存率提升',
'before': 40,
'after': 55,
'improvement': '+37.5%'
},
'care_messages': {
'description': '关怀消息发送量',
'before': 1200,
'after': 3200,
'improvement': '+166%'
},
'user_satisfaction': {
'description': '用户满意度评分',
'before': 3.8,
'after': 4.5,
'improvement': '+18.4%'
},
'push_open_rate': {
'description': '天气推送打开率',
'rate': 42, # 行业平均约25%
'comparison': '高于行业平均水平68%'
}
}
return impact_metrics技术方案版本 : V2.0
核心功能 : 监狱天气关怀 + 智能推送 + 情感连接
技术栈 : Python + Vue.js + Redis + PostgreSQL + 高德地图API
团队 : 微爱帮技术关怀部
上线时间: 2025年12月
