SWB：
<H3C>sys
System View: return to User View with Ctrl+Z.
H3Csysn SWB
SWBvlan 10
SWB-vlan10port g1/0/1 to g1/0/5
SWB-vlan10vlan 20
SWB-vlan20port g1/0/6 to g1/0/10
SWB-vlan20int g1/0/24
SWB-GigabitEthernet1/0/24p l t
SWB-GigabitEthernet1/0/24p t p v a
SWB-GigabitEthernet1/0/24end
<SWB>save
SWA:
<H3C>sys
System View: return to User View with Ctrl+Z.
H3Csysn SWASWAvlan 10
SWA-vlan10vlan 20
SWA-vlan20int vlan 10
SWA-Vlan-interface10ip add 192.168.10.254 24
SWA-Vlan-interface10int vlan 20
SWA-Vlan-interface20ip add 192.168.20.254 24
SWA-Vlan-interface20exit
SWAdhcp ena
SWAdhcp server forbidden-ip 192.168.10.254
SWAdhcp server forbidden-ip 192.168.20.254
SWAdhcp server ip-pool vlan10
SWA-dhcp-pool-vlan10network 192.168.10.0 mask 255.255.255.0
SWA-dhcp-pool-vlan10gateway-list 192.168.10.254
SWA-dhcp-pool-vlan10dns-list 8.8.8.8
SWA-dhcp-pool-vlan10exit
SWAdhcp server ip-pool vlan20
SWA-dhcp-pool-vlan20network 192.168.20.0 mask 255.255.255.0
SWA-dhcp-pool-vlan20gateway-list 192.168.20.254
SWA-dhcp-pool-vlan20dns-list 114.114.114.114SWA-dhcp-pool-vlan20expired day 8
SWA-dhcp-pool-vlan20int g1/0/24
SWA-GigabitEthernet1/0/24p l t
SWA-GigabitEthernet1/0/24p t p v a
SWA-GigabitEthernet1/0/24end
<SWA>save
