设备照片
英伟达实验室默认配置
bash
ru# show running-config
!
hostname ru
!
aaa
enable crypt enjz9NkNiFXAs
root ssh permit enable
brute force attack protection disable
exit
!
interface eth0
no shutdown
mac-address e8:c7:cf:ac:58:37
ip address 192.168.1.1/24
ip dhcp client vendor-class-identifier o-ran-ru2/WNC/R1220-077L
exit
!
interface eth1
no shutdown
mac-address e8:c7:cf:ac:58:38
l2-mtu 9600
ip address 192.168.2.1/24
sfp rs0-high
no sfp rs1-high
ip dhcp client vendor-class-identifier o-ran-ru2/WNC/R1220-077L
sub-interface eth1.mplane encapsulation vlan 100
sub-interface eth1.ecpri encapsulation vlan 2
exit
!
interface eth1.mplane
no shutdown
mac-address e8:c7:cf:ac:58:38
ip address 192.168.100.1/24
ip dhcp client vendor-class-identifier o-ran-ru2/WNC/R1220-077L
exit
!
interface eth1.ecpri
no shutdown
mac-address e8:c7:cf:ac:58:38
ip dhcp client vendor-class-identifier o-ran-ru2/WNC/R1220-077L
exit
!
!
radio 1
no shutdown
center-freq 3750000
transmit-power 24
no lna shutdown
lna low-gain
eaxc-id downlink 0x0000
eaxc-id uplink 0x0000
eaxc-id prach 0x0004
transport interface eth1.ecpri
transport peer-mac 58:a2:e1:84:78:66
phase-compensation
bandwidth 100
sub-carrier 30
max-scs 30
transmit-power-scale -7.0
compress tx static bfp iq-bitwidth 9
compress rx static bfp iq-bitwidth 9
compress prach static bfp iq-bitwidth 9
compress oran-compliant
downlink-radio-frame-offset 0
downlink-sfn-offset 0
ul-gain-correction 0.0000
digital-power-scaling legacy
fs-offset tx 0
fs-offset rx 0
fs-offset prach 0
exit
!
radio 2
no shutdown
center-freq 3750000
transmit-power 24
no lna shutdown
lna low-gain
eaxc-id downlink 0x0001
eaxc-id uplink 0x0001
eaxc-id prach 0x0005
transport interface eth1.ecpri
transport peer-mac 58:a2:e1:84:78:66
phase-compensation
bandwidth 100
sub-carrier 30
max-scs 30
transmit-power-scale -7.0
compress tx static bfp iq-bitwidth 9
compress rx static bfp iq-bitwidth 9
compress prach static bfp iq-bitwidth 9
compress oran-compliant
downlink-radio-frame-offset 0
downlink-sfn-offset 0
ul-gain-correction 0.0000
digital-power-scaling legacy
fs-offset tx 0
fs-offset rx 0
fs-offset prach 0
exit
!
radio 3
no shutdown
center-freq 3750000
transmit-power 24
no lna shutdown
lna low-gain
eaxc-id downlink 0x0002
eaxc-id uplink 0x0002
eaxc-id prach 0x0006
transport interface eth1.ecpri
transport peer-mac 58:a2:e1:84:78:66
phase-compensation
bandwidth 100
sub-carrier 30
max-scs 30
transmit-power-scale -7.0
compress tx static bfp iq-bitwidth 9
compress rx static bfp iq-bitwidth 9
compress prach static bfp iq-bitwidth 9
compress oran-compliant
downlink-radio-frame-offset 0
downlink-sfn-offset 0
ul-gain-correction 0.0000
digital-power-scaling legacy
fs-offset tx 0
fs-offset rx 0
fs-offset prach 0
exit
!
radio 4
no shutdown
center-freq 3750000
transmit-power 24
no lna shutdown
lna low-gain
eaxc-id downlink 0x0003
eaxc-id uplink 0x0003
eaxc-id prach 0x0007
transport interface eth1.ecpri
transport peer-mac 58:a2:e1:84:78:66
phase-compensation
bandwidth 100
sub-carrier 30
max-scs 30
transmit-power-scale -7.0
compress tx static bfp iq-bitwidth 9
compress rx static bfp iq-bitwidth 9
compress prach static bfp iq-bitwidth 9
compress oran-compliant
downlink-radio-frame-offset 0
downlink-sfn-offset 0
ul-gain-correction 0.0000
digital-power-scaling legacy
fs-offset tx 0
fs-offset rx 0
fs-offset prach 0
exit
!
mgmt
no shutdown
interface eth1.mplane
master netconf-client-1 hostname 192.168.100.200:4334
no alarm history rotate duration
vlan-range 1-4094
exit
!
ptp
no shutdown
clock accept-list 6,7
clock domain 24
clock profile g.8275.1
interface eth1
master ip 192.168.2.100
message frequency announce 8
message frequency delay-req 16
message frequency sync 16
transport ethernet forwardable
max-frequency 500000
exit
!
line console alive 0
line ssh enable
line ssh alive 0
line ssh port 22
!
non-ontime packet calculation enable
non-ontime packet threshold 10
!
!
OKWNC 出厂默认配置
bash
ru# show running-config
!
hostname ru
!
aaa
enable crypt enjz9NkNiFXAs
username root privilege 15 crypt DfG9fuSCickMcybYSOohLz8aPrh4/AArpXrJvi48.P2
root ssh permit enable
brute force attack protection disable
exit
!
interface eth0
no shutdown
mac-address 10:e8:a7:ef:8d:c6
ip address 192.168.1.1/24
ip dhcp client vendor-class-identifier o-ran-ru2/WNC/R1220-078L
exit
!
interface eth1
no shutdown
mac-address 10:e8:a7:ef:8d:c7
l2-mtu 9600
ip address 192.168.2.1/24
sfp rs0-high
sfp rs1-high
ip dhcp client vendor-class-identifier o-ran-ru2/WNC/R1220-078L
sub-interface eth1.ecpri encapsulation vlan 564
sub-interface eth1.mplane encapsulation vlan 100
exit
!
interface eth1.ecpri
no shutdown
mac-address 00:aa:ff:bb:ff:cc
ip dhcp client vendor-class-identifier o-ran-ru2/WNC/R1220-078L
exit
!
interface eth1.mplane
no shutdown
mac-address 10:e8:a7:ef:8d:c7
ip address 192.168.131.51/24
ip dhcp client vendor-class-identifier o-ran-ru2/WNC/R1220-078L
exit
!
!
radio 1
shutdown
center-freq 3499980
transmit-power 24
lna shutdown
lna low-gain
eaxc-id downlink 0x0000
eaxc-id uplink 0x0000
eaxc-id prach 0x0004
transport interface eth1.ecpri
transport peer-mac 00:11:22:33:44:66
phase-compensation
bandwidth 100
sub-carrier 30
max-scs 60
transmit-power-scale 0.0
compress tx static bfp iq-bitwidth 9
compress rx static bfp iq-bitwidth 9
compress prach static bfp iq-bitwidth 9
compress oran-compliant
downlink-radio-frame-offset 0
downlink-sfn-offset 0
ul-gain-correction 0.0000
digital-power-scaling legacy
fs-offset tx 0
fs-offset rx 0
fs-offset prach 0
exit
!
radio 2
shutdown
center-freq 3499980
transmit-power 24
lna shutdown
lna low-gain
eaxc-id downlink 0x0001
eaxc-id uplink 0x0001
eaxc-id prach 0x0005
transport interface eth1.ecpri
transport peer-mac 00:11:22:33:44:66
phase-compensation
bandwidth 100
sub-carrier 30
max-scs 60
transmit-power-scale 0.0
compress tx static bfp iq-bitwidth 9
compress rx static bfp iq-bitwidth 9
compress prach static bfp iq-bitwidth 9
compress oran-compliant
downlink-radio-frame-offset 0
downlink-sfn-offset 0
ul-gain-correction 0.0000
digital-power-scaling legacy
fs-offset tx 0
fs-offset rx 0
fs-offset prach 0
exit
!
radio 3
shutdown
center-freq 3499980
transmit-power 24
lna shutdown
lna low-gain
eaxc-id downlink 0x0002
eaxc-id uplink 0x0002
eaxc-id prach 0x0006
transport interface eth1.ecpri
transport peer-mac 00:11:22:33:44:66
phase-compensation
bandwidth 100
sub-carrier 30
max-scs 60
transmit-power-scale 0.0
compress tx static bfp iq-bitwidth 9
compress rx static bfp iq-bitwidth 9
compress prach static bfp iq-bitwidth 9
compress oran-compliant
downlink-radio-frame-offset 0
downlink-sfn-offset 0
ul-gain-correction 0.0000
digital-power-scaling legacy
fs-offset tx 0
fs-offset rx 0
fs-offset prach 0
exit
!
radio 4
shutdown
center-freq 3499980
transmit-power 24
lna shutdown
lna low-gain
eaxc-id downlink 0x0003
eaxc-id uplink 0x0003
eaxc-id prach 0x0007
transport interface eth1.ecpri
transport peer-mac 00:11:22:33:44:66
phase-compensation
bandwidth 100
sub-carrier 30
max-scs 60
transmit-power-scale 0.0
compress tx static bfp iq-bitwidth 9
compress rx static bfp iq-bitwidth 9
compress prach static bfp iq-bitwidth 9
compress oran-compliant
downlink-radio-frame-offset 0
downlink-sfn-offset 0
ul-gain-correction 0.0000
digital-power-scaling legacy
fs-offset tx 0
fs-offset rx 0
fs-offset prach 0
exit
!
mgmt
no shutdown
interface eth1.mplane
master netconf-client-1 hostname 192.168.100.200:4334
no alarm history rotate duration
vlan-range 1-4094
exit
!
ptp
no shutdown
clock accept-list 6,7,135,140,150,160,165,248
clock domain 24
clock profile g.8275.1
interface eth1
master ip 192.168.2.100
message frequency announce 8
message frequency delay-req 16
message frequency sync 16
transport ethernet forwardable
max-frequency 500000
exit
!
line console alive 0
line ssh enable
line ssh alive 0
line ssh port 22
!
non-ontime packet calculation enable
non-ontime packet threshold 10
!
!
OK设备代理商
东枫电子科技
15652687913
