在AI应用快速发展的今天，不同AI系统之间的高效通信成为技术架构的关键挑战。MCP（Model Context Protocol）作为新一代AI应用通信协议，正在重新定义AI工具生态的构建方式。

想象一下，当你需要让ChatGPT调用外部API、访问数据库或执行复杂计算时，传统的插件机制往往面临兼容性差、扩展性有限的困境。MCP协议的出现，为这个问题提供了优雅的解决方案。通过标准化的通信接口和灵活的架构设计，MCP让AI应用能够无缝集成各种外部服务和工具，就像给AI装上了"万能工具箱"。无论是数据查询、文件处理还是复杂业务逻辑，MCP都能让AI应用以统一的方式调用和协作。

一、MCP协议概述

什么是MCP协议

MCP（Model Context Protocol）是一个开放标准协议，专门设计用于AI模型与外部工具和服务之间的通信。它采用JSON-RPC 2.0规范，通过标准化的消息格式实现AI应用与各种外部资源的无缝集成。

{
  "jsonrpc": "2.0",
  "id": 1,
  "method": "tools/list",
  "params": {}
}

MCP的核心思想是提供一个统一的接口层，让AI模型能够像调用本地函数一样调用远程服务，同时保持协议的简洁性和扩展性。

MCP的设计目标与核心价值

MCP的设计遵循几个核心原则：

1. 标准化：统一的协议规范，确保不同实现之间的互操作性
2. 安全性：内置认证和授权机制，保护敏感数据
3. 可扩展性：支持动态工具发现和注册
4. 性能优化：高效的序列化和传输机制

这些设计目标使得MCP成为构建AI工具生态的理想选择。

MCP在AI生态中的定位

在当前的AI技术栈中，MCP扮演着"连接器"的角色。它位于AI模型层和应用服务层之间，为两者提供标准化的通信桥梁。

AI模型层 (ChatGPT, Claude等)
    ↓
MCP协议层 (标准化通信接口)
    ↓
应用服务层 (数据库、API、文件系统等)

这种分层架构使得AI应用能够灵活地集成各种外部资源，而不需要为每种服务开发专门的适配器。

二、MCP的核心架构

协议层设计原理

MCP采用分层设计，每一层都有明确的职责：

• 传输层：处理底层网络通信，支持TCP、WebSocket等多种传输方式
• 协议层：实现JSON-RPC 2.0规范，处理消息的序列化和反序列化
• 应用层：定义具体的工具接口和业务逻辑

# MCP服务器基础实现示例
import json
import asyncio

class MCPServer:
    def __init__(self):
        self.tools = {}

    async def handle_request(self, request):
        """处理MCP请求"""
        try:
            method = request.get("method")
            params = request.get("params", {})

            if method == "tools/list":
                return {"result": list(self.tools.keys())}
            elif method == "tools/call":
                tool_name = params.get("name")
                tool_params = params.get("arguments", {})
                return await self.call_tool(tool_name, tool_params)
        except Exception as e:
            return {"error": {"code": -1, "message": str(e)}}

客户端-服务器模型

MCP采用经典的客户端-服务器架构，其中：

• 客户端：通常是AI模型或AI应用，发起工具调用请求
• 服务器：提供各种工具和服务，响应客户端的请求

# MCP客户端示例
class MCPClient:
    def __init__(self, server_url):
        self.server_url = server_url

    async def list_tools(self):
        """获取可用工具列表"""
        request = {
            "jsonrpc": "2.0",
            "id": 1,
            "method": "tools/list",
            "params": {}
        }
        return await self.send_request(request)

    async def call_tool(self, tool_name, arguments):
        """调用指定工具"""
        request = {
            "jsonrpc": "2.0",
            "id": 2,
            "method": "tools/call",
            "params": {
                "name": tool_name,
                "arguments": arguments
            }
        }
        return await self.send_request(request)

消息传递机制

MCP使用JSON-RPC 2.0作为消息传递协议，支持三种消息类型：

1. 请求消息：客户端向服务器发送的调用请求
2. 响应消息：服务器返回的处理结果
3. 通知消息：单向消息，不需要响应

// 请求消息示例
{
  "jsonrpc": "2.0",
  "id": 1,
  "method": "tools/call",
  "params": {
    "name": "database/query",
    "arguments": {
      "sql": "SELECT * FROM users WHERE age > 18"
    }
  }
}

// 响应消息示例
{
  "jsonrpc": "2.0",
  "id": 1,
  "result": {
    "data": [
      {"id": 1, "name": "张三", "age": 25},
      {"id": 2, "name": "李四", "age": 30}
    ]
  }
}

错误处理与容错机制

MCP定义了标准的错误码和错误处理机制：

# 错误处理示例
class MCPError(Exception):
    def __init__(self, code, message, data=None):
        self.code = code
        self.message = message
        self.data = data

# 标准错误码
ERROR_CODES = {
    -32700: "解析错误",
    -32600: "无效请求",
    -32601: "方法未找到",
    -32602: "无效参数",
    -32603: "内部错误"
}

def handle_error(error_code, message):
    """统一错误处理"""
    return {
        "jsonrpc": "2.0",
        "error": {
            "code": error_code,
            "message": message
        }
    }

三、MCP协议详解

请求-响应模式

MCP采用同步的请求-响应模式，每个请求都有唯一的ID，确保响应的正确匹配：

class RequestManager:
    def __init__(self):
        self.pending_requests = {}
        self.request_id = 0

    def create_request(self, method, params):
        """创建新请求"""
        self.request_id += 1
        request = {
            "jsonrpc": "2.0",
            "id": self.request_id,
            "method": method,
            "params": params
        }
        self.pending_requests[self.request_id] = request
        return request

    def handle_response(self, response):
        """处理响应"""
        request_id = response.get("id")
        if request_id in self.pending_requests:
            del self.pending_requests[request_id]
            return response
        return None

数据格式与序列化

MCP使用JSON作为数据交换格式，支持复杂的数据结构：

# 数据类型示例
class MCPDataTypes:
    @staticmethod
    def serialize_tool_result(data):
        """序列化工具调用结果"""
        if isinstance(data, (dict, list)):
            return json.dumps(data, ensure_ascii=False)
        return str(data)

    @staticmethod
    def deserialize_tool_params(params_str):
        """反序列化工具参数"""
        try:
            return json.loads(params_str)
        except json.JSONDecodeError:
            raise MCPError(-32700, "参数格式错误")

认证与安全机制

MCP支持多种认证方式，确保通信安全：

# 认证机制示例
class MCPAuth:
    def __init__(self):
        self.api_keys = {}

    def authenticate(self, headers):
        """验证请求身份"""
        api_key = headers.get("Authorization")
        if not api_key:
            raise MCPError(-32001, "缺少认证信息")

        if api_key not in self.api_keys:
            raise MCPError(-32002, "无效的API密钥")

        return True

    def add_api_key(self, key, permissions):
        """添加API密钥"""
        self.api_keys[key] = permissions

版本兼容性策略

MCP采用语义化版本控制，确保向后兼容：

# 版本兼容性处理
class MCPVersionManager:
    def __init__(self):
        self.supported_versions = ["1.0", "1.1", "1.2"]

    def check_compatibility(self, client_version):
        """检查版本兼容性"""
        major, minor = client_version.split(".")
        for supported in self.supported_versions:
            s_major, s_minor = supported.split(".")
            if major == s_major and int(minor) <= int(s_minor):
                return True
        return False

    def negotiate_version(self, client_versions):
        """协商最佳版本"""
        for version in client_versions:
            if version in self.supported_versions:
                return version
        return self.supported_versions[0]

四、MCP的实际应用场景

AI应用集成外部API

MCP最常见的应用场景是让AI模型调用外部API服务：

# 天气API集成示例
class WeatherTool:
    def __init__(self, api_key):
        self.api_key = api_key

    async def get_weather(self, city):
        """获取城市天气信息"""
        url = f"https://api.weatherapi.com/v1/current.json"
        params = {
            "key": self.api_key,
            "q": city,
            "aqi": "no"
        }

        async with aiohttp.ClientSession() as session:
            async with session.get(url, params=params) as response:
                data = await response.json()
                return {
                    "city": city,
                    "temperature": data["current"]["temp_c"],
                    "condition": data["current"]["condition"]["text"]
                }

# 注册到MCP服务器
mcp_server = MCPServer()
weather_tool = WeatherTool("your_api_key")
mcp_server.tools["weather/get"] = weather_tool.get_weather

数据库连接与查询

MCP可以安全地让AI模型访问数据库：

# 数据库工具示例
class DatabaseTool:
    def __init__(self, connection_string):
        self.connection_string = connection_string

    async def query_database(self, sql, params=None):
        """执行数据库查询"""
        try:
            async with asyncpg.connect(self.connection_string) as conn:
                result = await conn.fetch(sql, *params or [])
                return [dict(row) for row in result]
        except Exception as e:
            raise MCPError(-32603, f"数据库查询错误: {str(e)}")

    async def execute_sql(self, sql, params=None):
        """执行SQL语句"""
        try:
            async with asyncpg.connect(self.connection_string) as conn:
                result = await conn.execute(sql, *params or [])
                return {"affected_rows": result}
        except Exception as e:
            raise MCPError(-32603, f"SQL执行错误: {str(e)}")

# 注册数据库工具
db_tool = DatabaseTool("postgresql://user:pass@localhost/db")
mcp_server.tools["database/query"] = db_tool.query_database
mcp_server.tools["database/execute"] = db_tool.execute_sql

文件系统操作

MCP支持安全的文件系统操作：

# 文件系统工具示例
class FileSystemTool:
    def __init__(self, base_path):
        self.base_path = Path(base_path)

    async def read_file(self, file_path):
        """读取文件内容"""
        full_path = self.base_path / file_path
        if not full_path.exists():
            raise MCPError(-32003, "文件不存在")

        try:
            with open(full_path, 'r', encoding='utf-8') as f:
                return {"content": f.read(), "path": str(full_path)}
        except Exception as e:
            raise MCPError(-32603, f"文件读取错误: {str(e)}")

    async def write_file(self, file_path, content):
        """写入文件内容"""
        full_path = self.base_path / file_path
        try:
            full_path.parent.mkdir(parents=True, exist_ok=True)
            with open(full_path, 'w', encoding='utf-8') as f:
                f.write(content)
            return {"success": True, "path": str(full_path)}
        except Exception as e:
            raise MCPError(-32603, f"文件写入错误: {str(e)}")

# 注册文件系统工具
fs_tool = FileSystemTool("/safe/path")
mcp_server.tools["filesystem/read"] = fs_tool.read_file
mcp_server.tools["filesystem/write"] = fs_tool.write_file

自定义工具开发

开发者可以创建自定义工具来扩展AI的能力：

# 自定义计算工具示例
class CalculatorTool:
    def __init__(self):
        self.supported_operations = ['+', '-', '*', '/', '**']

    async def calculate(self, expression):
        """安全计算数学表达式"""
        try:
            # 安全检查，只允许基本数学运算
            allowed_chars = set('0123456789+-*/.() ')
            if not all(c in allowed_chars for c in expression):
                raise ValueError("表达式包含不允许的字符")

            result = eval(expression)
            return {"expression": expression, "result": result}
        except Exception as e:
            raise MCPError(-32602, f"计算错误: {str(e)}")

    async def get_statistics(self, numbers):
        """计算统计信息"""
        try:
            nums = [float(n) for n in numbers]
            return {
                "mean": sum(nums) / len(nums),
                "max": max(nums),
                "min": min(nums),
                "count": len(nums)
            }
        except Exception as e:
            raise MCPError(-32602, f"统计计算错误: {str(e)}")

# 注册计算工具
calc_tool = CalculatorTool()
mcp_server.tools["calculator/compute"] = calc_tool.calculate
mcp_server.tools["calculator/stats"] = calc_tool.get_statistics

五、MCP与其他协议的对比

与OpenAI插件协议的差异

MCP相比OpenAI插件协议具有以下优势：

1. 标准化程度更高：MCP是开放标准，不依赖特定厂商
2. 扩展性更强：支持动态工具发现和注册
3. 安全性更好：内置认证和授权机制

# OpenAI插件 vs MCP对比示例
# OpenAI插件方式
class OpenAIPlugin:
    def __init__(self):
        self.manifest = {
            "schema_version": "v1",
            "name_for_model": "weather_plugin",
            "name_for_human": "天气查询插件",
            "description_for_model": "获取城市天气信息",
            "description_for_human": "查询指定城市的天气情况",
            "auth": {"type": "none"},
            "api": {"type": "openapi", "url": "https://api.example.com/openapi.yaml"},
            "logo_url": "https://example.com/logo.png",
            "contact_email": "support@example.com",
            "legal_info_url": "https://example.com/legal"
        }

# MCP方式
class MCPTool:
    def __init__(self):
        self.tool_info = {
            "name": "weather/get",
            "description": "获取城市天气信息",
            "parameters": {
                "type": "object",
                "properties": {
                    "city": {"type": "string", "description": "城市名称"}
                },
                "required": ["city"]
            }
        }

与REST API的对比分析

MCP相比传统REST API的优势：

1. 统一接口：所有工具通过相同的协议调用
2. 类型安全：支持强类型参数定义
3. 错误处理：标准化的错误码和错误信息

# REST API vs MCP对比
# 传统REST API调用
async def rest_api_call():
    async with aiohttp.ClientSession() as session:
        # 需要为每个API维护不同的调用方式
        weather_response = await session.get("https://api.weather.com/current?city=北京")
        db_response = await session.post("https://api.database.com/query",
                                       json={"sql": "SELECT * FROM users"})
        file_response = await session.get("https://api.files.com/read?path=/data.txt")

# MCP统一调用
async def mcp_call():
    client = MCPClient("mcp://localhost:3000")

    # 所有工具使用相同的调用方式
    weather = await client.call_tool("weather/get", {"city": "北京"})
    users = await client.call_tool("database/query", {"sql": "SELECT * FROM users"})
    content = await client.call_tool("filesystem/read", {"path": "/data.txt"})

性能与扩展性优势

MCP在性能和扩展性方面的优势：

# 性能对比示例
import time
import asyncio

class PerformanceTest:
    def __init__(self):
        self.mcp_client = MCPClient("mcp://localhost:3000")

    async def test_mcp_performance(self):
        """测试MCP性能"""
        start_time = time.time()

        # 并发调用多个工具
        tasks = [
            self.mcp_client.call_tool("weather/get", {"city": "北京"}),
            self.mcp_client.call_tool("database/query", {"sql": "SELECT * FROM users"}),
            self.mcp_client.call_tool("calculator/compute", {"expression": "2+2*3"})
        ]

        results = await asyncio.gather(*tasks)
        end_time = time.time()

        return {
            "total_time": end_time - start_time,
            "results": results
        }

    async def test_scalability(self):
        """测试扩展性"""
        # 动态添加新工具
        new_tool = {
            "name": "custom/process",
            "description": "自定义数据处理工具",
            "handler": lambda data: {"processed": data.upper()}
        }

        # 无需重启服务器即可使用新工具
        result = await self.mcp_client.call_tool("custom/process", {"data": "hello world"})
        return result

六、MCP开发实践指南

环境搭建与配置

开始MCP开发需要搭建基础环境：

# 环境配置示例
# requirements.txt
mcp==1.0.0
aiohttp==3.8.5
asyncpg==0.28.0
pydantic==2.0.0

# 基础配置文件
import yaml

class MCPConfig:
    def __init__(self, config_path="mcp_config.yaml"):
        with open(config_path, 'r', encoding='utf-8') as f:
            self.config = yaml.safe_load(f)

    @property
    def server_host(self):
        return self.config.get("server", {}).get("host", "localhost")

    @property
    def server_port(self):
        return self.config.get("server", {}).get("port", 3000)

    @property
    def auth_token(self):
        return self.config.get("auth", {}).get("token")

    @property
    def tools_config(self):
        return self.config.get("tools", {})

# mcp_config.yaml
server:
  host: localhost
  port: 3000
  debug: true

auth:
  token: "your_secret_token"
  enabled: true

tools:
  weather:
    api_key: "your_weather_api_key"
    enabled: true
  database:
    connection_string: "postgresql://user:pass@localhost/db"
    enabled: true
  filesystem:
    base_path: "/safe/path"
    enabled: true

基础客户端开发

开发MCP客户端的基本步骤：

# 基础MCP客户端实现
import asyncio
import aiohttp
import json
from typing import Dict, Any

class MCPClient:
    def __init__(self, server_url: str, auth_token: str = None):
        self.server_url = server_url
        self.auth_token = auth_token
        self.session = None
        self.request_id = 0

    async def __aenter__(self):
        """异步上下文管理器入口"""
        self.session = aiohttp.ClientSession()
        return self

    async def __aexit__(self, exc_type, exc_val, exc_tb):
        """异步上下文管理器出口"""
        if self.session:
            await self.session.close()

    async def send_request(self, method: str, params: Dict[str, Any] = None) -> Dict[str, Any]:
        """发送MCP请求"""
        self.request_id += 1
        request = {
            "jsonrpc": "2.0",
            "id": self.request_id,
            "method": method,
            "params": params or {}
        }

        headers = {"Content-Type": "application/json"}
        if self.auth_token:
            headers["Authorization"] = f"Bearer {self.auth_token}"

        async with self.session.post(
            self.server_url,
            json=request,
            headers=headers
        ) as response:
            result = await response.json()

            if "error" in result:
                raise MCPError(
                    result["error"]["code"],
                    result["error"]["message"]
                )

            return result["result"]

    async def list_tools(self) -> list:
        """获取可用工具列表"""
        return await self.send_request("tools/list")

    async def call_tool(self, tool_name: str, arguments: Dict[str, Any]) -> Dict[str, Any]:
        """调用指定工具"""
        return await self.send_request("tools/call", {
            "name": tool_name,
            "arguments": arguments
        })

# 使用示例
async def main():
    async with MCPClient("http://localhost:3000", "your_token") as client:
        # 获取可用工具
        tools = await client.list_tools()
        print(f"可用工具: {tools}")

        # 调用天气工具
        weather = await client.call_tool("weather/get", {"city": "北京"})
        print(f"天气信息: {weather}")

        # 调用数据库工具
        users = await client.call_tool("database/query", {
            "sql": "SELECT * FROM users LIMIT 5"
        })
        print(f"用户数据: {users}")

if __name__ == "__main__":
    asyncio.run(main())

自定义工具实现

创建自定义MCP工具的完整示例：

# 自定义工具实现
from typing import Dict, Any, Optional
import asyncio
import json

class CustomTool:
    """自定义MCP工具基类"""

    def __init__(self, name: str, description: str):
        self.name = name
        self.description = description
        self.parameters = {}

    def add_parameter(self, name: str, param_type: str, description: str, required: bool = False):
        """添加工具参数"""
        self.parameters[name] = {
            "type": param_type,
            "description": description,
            "required": required
        }

    async def execute(self, arguments: Dict[str, Any]) -> Dict[str, Any]:
        """执行工具逻辑（子类需要重写）"""
        raise NotImplementedError("子类必须实现execute方法")

    def get_info(self) -> Dict[str, Any]:
        """获取工具信息"""
        return {
            "name": self.name,
            "description": self.description,
            "parameters": {
                "type": "object",
                "properties": self.parameters,
                "required": [name for name, param in self.parameters.items()
                           if param.get("required", False)]
            }
        }

# 图像处理工具示例
class ImageProcessingTool(CustomTool):
    def __init__(self):
        super().__init__("image/process", "图像处理工具")
        self.add_parameter("image_url", "string", "图像URL", required=True)
        self.add_parameter("operation", "string", "处理操作(resize/rotate/filter)", required=True)
        self.add_parameter("parameters", "object", "处理参数")

    async def execute(self, arguments: Dict[str, Any]) -> Dict[str, Any]:
        """执行图像处理"""
        image_url = arguments["image_url"]
        operation = arguments["operation"]
        params = arguments.get("parameters", {})

        # 模拟图像处理
        if operation == "resize":
            width = params.get("width", 800)
            height = params.get("height", 600)
            return {
                "status": "success",
                "operation": "resize",
                "new_size": f"{width}x{height}",
                "processed_url": f"{image_url}_resized"
            }
        elif operation == "rotate":
            angle = params.get("angle", 90)
            return {
                "status": "success",
                "operation": "rotate",
                "angle": angle,
                "processed_url": f"{image_url}_rotated"
            }
        else:
            raise MCPError(-32602, f"不支持的操作: {operation}")

# 数据分析工具示例
class DataAnalysisTool(CustomTool):
    def __init__(self):
        super().__init__("data/analyze", "数据分析工具")
        self.add_parameter("data", "array", "要分析的数据", required=True)
        self.add_parameter("analysis_type", "string", "分析类型(statistics/trend/correlation)", required=True)

    async def execute(self, arguments: Dict[str, Any]) -> Dict[str, Any]:
        """执行数据分析"""
        data = arguments["data"]
        analysis_type = arguments["analysis_type"]

        if not isinstance(data, list):
            raise MCPError(-32602, "数据必须是数组格式")

        if analysis_type == "statistics":
            return self._calculate_statistics(data)
        elif analysis_type == "trend":
            return self._analyze_trend(data)
        elif analysis_type == "correlation":
            return self._calculate_correlation(data)
        else:
            raise MCPError(-32602, f"不支持的分析类型: {analysis_type}")

    def _calculate_statistics(self, data: list) -> Dict[str, Any]:
        """计算统计信息"""
        if not data:
            return {"error": "数据为空"}

        numeric_data = [float(x) for x in data if isinstance(x, (int, float))]
        if not numeric_data:
            return {"error": "没有有效的数值数据"}

        return {
            "count": len(numeric_data),
            "sum": sum(numeric_data),
            "mean": sum(numeric_data) / len(numeric_data),
            "min": min(numeric_data),
            "max": max(numeric_data),
            "median": sorted(numeric_data)[len(numeric_data) // 2]
        }

    def _analyze_trend(self, data: list) -> Dict[str, Any]:
        """分析趋势"""
        if len(data) < 2:
            return {"error": "数据点不足，无法分析趋势"}

        numeric_data = [float(x) for x in data if isinstance(x, (int, float))]
        if len(numeric_data) < 2:
            return {"error": "数值数据点不足"}

        # 简单趋势分析
        first_half = numeric_data[:len(numeric_data)//2]
        second_half = numeric_data[len(numeric_data)//2:]

        first_avg = sum(first_half) / len(first_half)
        second_avg = sum(second_half) / len(second_half)

        trend = "上升" if second_avg > first_avg else "下降" if second_avg < first_avg else "平稳"

        return {
            "trend": trend,
            "change_rate": (second_avg - first_avg) / first_avg * 100,
            "first_half_avg": first_avg,
            "second_half_avg": second_avg
        }

    def _calculate_correlation(self, data: list) -> Dict[str, Any]:
        """计算相关性（简化版）"""
        if len(data) < 4:
            return {"error": "数据点不足，无法计算相关性"}

        # 假设数据是成对的
        if len(data) % 2 != 0:
            return {"error": "数据必须是成对的"}

        pairs = [(data[i], data[i+1]) for i in range(0, len(data), 2)]
        x_values = [pair[0] for pair in pairs if isinstance(pair[0], (int, float))]
        y_values = [pair[1] for pair in pairs if isinstance(pair[1], (int, float))]

        if len(x_values) != len(y_values) or len(x_values) < 2:
            return {"error": "有效的数据对不足"}

        # 简化的相关系数计算
        n = len(x_values)
        sum_x = sum(x_values)
        sum_y = sum(y_values)
        sum_xy = sum(x * y for x, y in zip(x_values, y_values))
        sum_x2 = sum(x * x for x in x_values)
        sum_y2 = sum(y * y for y in y_values)

        numerator = n * sum_xy - sum_x * sum_y
        denominator = ((n * sum_x2 - sum_x * sum_x) * (n * sum_y2 - sum_y * sum_y)) ** 0.5

        if denominator == 0:
            correlation = 0
        else:
            correlation = numerator / denominator

        return {
            "correlation_coefficient": correlation,
            "data_points": n,
            "interpretation": "强正相关" if correlation > 0.7 else
                            "中等正相关" if correlation > 0.3 else
                            "弱正相关" if correlation > 0 else
                            "强负相关" if correlation < -0.7 else
                            "中等负相关" if correlation < -0.3 else
                            "弱负相关" if correlation < 0 else "无相关"
        }

# 注册自定义工具
def register_custom_tools(mcp_server: MCPServer):
    """注册自定义工具到MCP服务器"""
    # 注册图像处理工具
    image_tool = ImageProcessingTool()
    mcp_server.tools[image_tool.name] = image_tool.execute

    # 注册数据分析工具
    data_tool = DataAnalysisTool()
    mcp_server.tools[data_tool.name] = data_tool.execute

    return mcp_server

调试与测试技巧

MCP开发的调试和测试策略：

# 调试和测试工具
import logging
import unittest
from unittest.mock import Mock, patch

class MCPDebugger:
    def __init__(self):
        self.logger = logging.getLogger("mcp_debugger")
        self.logger.setLevel(logging.DEBUG)

        # 添加控制台处理器
        handler = logging.StreamHandler()
        formatter = logging.Formatter(
            '%(asctime)s - %(name)s - %(levelname)s - %(message)s'
        )
        handler.setFormatter(formatter)
        self.logger.addHandler(handler)

    def log_request(self, request: Dict[str, Any]):
        """记录请求日志"""
        self.logger.info(f"发送请求: {json.dumps(request, ensure_ascii=False, indent=2)}")

    def log_response(self, response: Dict[str, Any]):
        """记录响应日志"""
        self.logger.info(f"收到响应: {json.dumps(response, ensure_ascii=False, indent=2)}")

    def log_error(self, error: Exception):
        """记录错误日志"""
        self.logger.error(f"发生错误: {str(error)}", exc_info=True)

# MCP测试框架
class MCPTestCase(unittest.TestCase):
    def setUp(self):
        """测试设置"""
        self.mcp_server = MCPServer()
        self.mcp_client = MCPClient("http://localhost:3000")
        self.debugger = MCPDebugger()

    async def test_tool_registration(self):
        """测试工具注册"""
        # 注册测试工具
        async def test_tool(arguments):
            return {"result": "test_success", "input": arguments}

        self.mcp_server.tools["test/tool"] = test_tool

        # 验证工具列表
        tools = await self.mcp_client.list_tools()
        self.assertIn("test/tool", tools)

    async def test_tool_execution(self):
        """测试工具执行"""
        # 注册测试工具
        async def calculator(arguments):
            a = arguments.get("a", 0)
            b = arguments.get("b", 0)
            operation = arguments.get("operation", "+")

            if operation == "+":
                return {"result": a + b}
            elif operation == "-":
                return {"result": a - b}
            elif operation == "*":
                return {"result": a * b}
            elif operation == "/":
                if b == 0:
                    raise MCPError(-32602, "除数不能为零")
                return {"result": a / b}
            else:
                raise MCPError(-32602, f"不支持的操作: {operation}")

        self.mcp_server.tools["calculator/compute"] = calculator

        # 测试各种运算
        test_cases = [
            ({"a": 10, "b": 5, "operation": "+"}, 15),
            ({"a": 10, "b": 5, "operation": "-"}, 5),
            ({"a": 10, "b": 5, "operation": "*"}, 50),
            ({"a": 10, "b": 5, "operation": "/"}, 2),
        ]

        for args, expected in test_cases:
            result = await self.mcp_client.call_tool("calculator/compute", args)
            self.assertEqual(result["result"], expected)

    async def test_error_handling(self):
        """测试错误处理"""
        # 注册会抛出错误的工具
        async def error_tool(arguments):
            raise MCPError(-32602, "测试错误")

        self.mcp_server.tools["test/error"] = error_tool

        # 测试错误处理
        with self.assertRaises(MCPError) as context:
            await self.mcp_client.call_tool("test/error", {})

        self.assertEqual(context.exception.code, -32602)
        self.assertEqual(context.exception.message, "测试错误")

# 性能测试
class MCPPerformanceTest:
    def __init__(self):
        self.mcp_client = MCPClient("http://localhost:3000")

    async def benchmark_tool_calls(self, tool_name: str, arguments: Dict[str, Any], iterations: int = 100):
        """基准测试工具调用性能"""
        import time

        start_time = time.time()

        # 并发执行多次调用
        tasks = [
            self.mcp_client.call_tool(tool_name, arguments)
            for _ in range(iterations)
        ]

        results = await asyncio.gather(*tasks)
        end_time = time.time()

        total_time = end_time - start_time
        avg_time = total_time / iterations

        return {
            "total_time": total_time,
            "iterations": iterations,
            "average_time": avg_time,
            "throughput": iterations / total_time,
            "success_rate": len([r for r in results if "error" not in r]) / len(results)
        }

    async def stress_test(self, concurrent_requests: int = 50):
        """压力测试"""
        async def make_request(request_id: int):
            try:
                result = await self.mcp_client.call_tool("test/stress", {"id": request_id})
                return {"id": request_id, "status": "success", "result": result}
            except Exception as e:
                return {"id": request_id, "status": "error", "error": str(e)}

        tasks = [make_request(i) for i in range(concurrent_requests)]
        results = await asyncio.gather(*tasks)

        success_count = len([r for r in results if r["status"] == "success"])
        error_count = len([r for r in results if r["status"] == "error"])

        return {
            "total_requests": concurrent_requests,
            "successful_requests": success_count,
            "failed_requests": error_count,
            "success_rate": success_count / concurrent_requests
        }

# 使用示例
async def run_tests():
    """运行所有测试"""
    # 单元测试
    test_case = MCPTestCase()
    await test_case.test_tool_registration()
    await test_case.test_tool_execution()
    await test_case.test_error_handling()

    # 性能测试
    perf_test = MCPPerformanceTest()
    benchmark_result = await perf_test.benchmark_tool_calls(
        "calculator/compute",
        {"a": 10, "b": 5, "operation": "+"},
        100
    )
    print(f"性能测试结果: {benchmark_result}")

    stress_result = await perf_test.stress_test(50)
    print(f"压力测试结果: {stress_result}")

if __name__ == "__main__":
    asyncio.run(run_tests())

通过以上完整的MCP开发指南，你可以看到MCP协议不仅是一个技术标准，更是一个完整的生态系统。它通过标准化的接口、灵活的架构设计和丰富的工具生态，为AI应用开发提供了强大的基础设施支持。

无论是简单的API调用，还是复杂的业务逻辑处理，MCP都能提供统一、安全、高效的解决方案。随着AI技术的不断发展，MCP协议将继续演进，为构建更智能、更强大的AI应用生态系统贡献力量。
