C语言需要掌握的基础知识点之树

在C语言中，树（Tree）是一种非常重要的非线性数据结构，它由n（n≥0）个有限节点组成的一个具有层次关系的集合。以下是树的详细介绍：

树的基本概念

树的定义

根节点：树的最顶层节点

父节点、子节点：节点之间的关系

叶子节点：没有子节点的节点

度：节点拥有的子树数

深度：从根节点到该节点的路径长度

高度：从该节点到最远叶子节点的路径长度

二叉树

二叉树节点定义

c 复制代码

typedef struct TreeNode {
    int data;
    struct TreeNode* left;
    struct TreeNode* right;
} TreeNode;

创建新节点

c 复制代码

TreeNode* createNode(int data) {
    TreeNode* newNode = (TreeNode*)malloc(sizeof(TreeNode));
    newNode->data = data;
    newNode->left = NULL;
    newNode->right = NULL;
    return newNode;
}

树的遍历

深度优先遍历

c 复制代码

// 前序遍历：根->左->右
void preOrder(TreeNode* root) {
    if (root != NULL) {
        printf("%d ", root->data);
        preOrder(root->left);
        preOrder(root->right);
    }
}

// 中序遍历：左->根->右
void inOrder(TreeNode* root) {
    if (root != NULL) {
        inOrder(root->left);
        printf("%d ", root->data);
        inOrder(root->right);
    }
}

// 后序遍历：左->右->根
void postOrder(TreeNode* root) {
    if (root != NULL) {
        postOrder(root->left);
        postOrder(root->right);
        printf("%d ", root->data);
    }
}

广度优先遍历（层次遍历）

c 复制代码

void levelOrder(TreeNode* root) {
    if (root == NULL) return;

    TreeNode* queue[100];
    int front = 0, rear = 0;

    queue[rear++] = root;

    while (front < rear) {
        TreeNode* current = queue[front++];
        printf("%d ", current->data);

        if (current->left != NULL)
            queue[rear++] = current->left;
        if (current->right != NULL)
            queue[rear++] = current->right;
    }
}

二叉搜索树（BST）

插入节点

c 复制代码

TreeNode* insertBST(TreeNode* root, int data) {
    if (root == NULL) {
        return createNode(data);
    }

    if (data < root->data) {
        root->left = insertBST(root->left, data);
    } else if (data > root->data) {
        root->right = insertBST(root->right, data);
    }

    return root;
}

查找节点

c 复制代码

TreeNode* searchBST(TreeNode* root, int key) {
    if (root == NULL || root->data == key) {
        return root;
    }

    if (key < root->data) {
        return searchBST(root->left, key);
    } else {
        return searchBST(root->right, key);
    }
}

删除节点

c 复制代码

TreeNode* deleteBST(TreeNode* root, int key) {
    if (root == NULL) return root;

    if (key < root->data) {
        root->left = deleteBST(root->left, key);
    } else if (key > root->data) {
        root->right = deleteBST(root->right, key);
    } else {
        // 节点有一个或没有子节点
        if (root->left == NULL) {
            TreeNode* temp = root->right;
            free(root);
            return temp;
        } else if (root->right == NULL) {
            TreeNode* temp = root->left;
            free(root);
            return temp;
        }

        // 节点有两个子节点：找到右子树的最小值
        TreeNode* temp = root->right;
        while (temp && temp->left != NULL) {
            temp = temp->left;
        }

        root->data = temp->data;
        root->right = deleteBST(root->right, temp->data);
    }
    return root;
}

树的常用操作

计算树的高度

c 复制代码

int treeHeight(TreeNode* root) {
    if (root == NULL) {
        return 0;
    }

    int leftHeight = treeHeight(root->left);
    int rightHeight = treeHeight(root->right);

    return (leftHeight > rightHeight ? leftHeight : rightHeight) + 1;
}

计算节点总数

c 复制代码

int countNodes(TreeNode* root) {
    if (root == NULL) {
        return 0;
    }

    return 1 + countNodes(root->left) + countNodes(root->right);
}

检查是否为完全二叉树

c 复制代码

int isCompleteTree(TreeNode* root) {
    if (root == NULL) return 1;

    TreeNode* queue[100];
    int front = 0, rear = 0;
    int flag = 0; // 标记是否遇到空节点

    queue[rear++] = root;

    while (front < rear) {
        TreeNode* current = queue[front++];

        if (current == NULL) {
            flag = 1;
        } else {
            if (flag) return 0; // 如果已经遇到空节点，又遇到非空节点

            queue[rear++] = current->left;
            queue[rear++] = current->right;
        }
    }
    return 1;
}

完整示例

c 复制代码

#include <stdio.h>
#include <stdlib.h>

typedef struct TreeNode {
    int data;
    struct TreeNode* left;
    struct TreeNode* right;
} TreeNode;

// 创建新节点
TreeNode* createNode(int data) {
    TreeNode* newNode = (TreeNode*)malloc(sizeof(TreeNode));
    newNode->data = data;
    newNode->left = newNode->right = NULL;
    return newNode;
}

// 中序遍历
void inOrder(TreeNode* root) {
    if (root != NULL) {
        inOrder(root->left);
        printf("%d ", root->data);
        inOrder(root->right);
    }
}

// 插入BST节点
TreeNode* insertBST(TreeNode* root, int data) {
    if (root == NULL) return createNode(data);

    if (data < root->data)
        root->left = insertBST(root->left, data);
    else if (data > root->data)
        root->right = insertBST(root->right, data);

    return root;
}

int main() {
    TreeNode* root = NULL;
    int values[] = {50, 30, 70, 20, 40, 60, 80};
    int n = sizeof(values) / sizeof(values[0]);

    // 构建BST
    for (int i = 0; i < n; i++) {
        root = insertBST(root, values[i]);
    }

    printf("中序遍历结果: ");
    inOrder(root);
    printf("\n");

    return 0;
}
