route
interface GigabitEthernet0/0
port link-mode route
combo enable copper
ip address X.X.X.X 255.255.255.0
nat outbound 2000
interface GigabitEthernet0/1
port link-mode route
combo enable copper
ip address 1.1.1.1 255.255.255.0
switch:
interface Vlan-interface1
ip address 172.16.10.254 255.255.255.0
interface Vlan-interface100
ip address 1.1.1.2 255.255.255.0
