NestJS 作为企业级 Node.js 框架，凭借其模块化架构、依赖注入和装饰器特性，为 Socket.io 服务提供了更加结构化和可维护的实现方式。本文将前文中的原生 Socket.io 代码转换为 NestJS 最佳实践，构建一个高性能的 IM 通信服务。
项目结构与依赖配置
1.1 项目初始化与依赖安装
NestJS 项目需要安装核心依赖以及 Socket.io 相关包。在开始实现之前，需要初始化项目并安装必要的依赖包：
bash
# 创建 NestJS 项目
nest new im-socket-service
cd im-socket-service
# 安装 Socket.io 相关依赖
npm install @nestjs/platform-socket.io @nestjs/websockets socket.io
# 安装 Redis 适配器
npm install @socket.io/redis-adapter ioredis
# 安装性能监控依赖
npm install @willsoto/nestjs-prometheus prom-client
# 安装类验证和转换
npm install class-validator class-transformer项目采用模块化结构，将不同的功能域分离到独立模块中。主目录结构包含核心业务模块（用户、消息、会话）、基础设施模块（缓存、数据库）以及网关模块（Socket 连接）。每个模块拥有自己的控制器、服务和数据访问层，这种分层架构确保了代码的可测试性和可维护性。配置目录集中管理环境变量和全局配置，便于不同环境下的部署切换。
1.2 环境配置与常量定义
typescript
// config/constants.ts
export const SOCKET_CONFIG = {
// 心跳配置
PING_TIMEOUT: 10000,
PING_INTERVAL: 15000,
// 消息配置
MAX_MESSAGE_SIZE: 100 * 1024, // 100KB
MESSAGE_COMPRESSION: true,
// 连接配置
MAX_CONNECTIONS_PER_IP: 5,
CONNECTION_TIMEOUT: 30000,
// Redis 配置
REDIS_PREFIX: 'im:socket:',
REDIS_TTL: 3600,
// 限流配置
RATE_LIMIT: {
WINDOW_MS: 60000,
MAX_MESSAGES: 120,
},
} as const;
export const CONNECTION_TIERS = {
CRITICAL: {
name: 'critical',
weight: 100,
maxConnections: 10000,
heartbeatInterval: 30000,
messageBufferSize: 1000,
},
STANDARD: {
name: 'standard',
weight: 50,
maxConnections: 100000,
heartbeatInterval: 30000,
messageBufferSize: 500,
},
DEGRADED: {
name: 'degraded',
weight: 10,
maxConnections: 50000,
heartbeatInterval: 60000,
messageBufferSize: 100,
},
} as const;NestJS WebSocket 网关实现
2.1 网关基础架构
NestJS 的 WebSocket 网关是处理 Socket 连接的核心组件。通过 @WebSocketGateway 装饰器定义网关，使用 @WebSocketServer 注入 Server 实例，并通过 @SubscribeMessage 装饰器处理各种消息事件。NestJS 的网关还支持依赖注入，可以直接使用 Service 层的能力。
typescript
// gateways/im.gateway.ts
import {
WebSocketGateway,
WebSocketServer,
SubscribeMessage,
OnGatewayConnection,
OnGatewayDisconnect,
OnGatewayInit,
ConnectedSocket,
MessageBody,
} from '@nestjs/websockets';
import { Server, Socket } from 'socket.io';
import { Logger, UseGuards, UsePipes, ValidationPipe } from '@nestjs/common';
import { AuthGuard } from '../guards/ws-auth.guard';
import { RateLimitGuard } from '../guards/rate-limit.guard';
import { ConnectionTierGuard } from '../guards/connection-tier.guard';
import { ImService } from '../services/im.service';
import { MessageDto, TypingDto, ReadReceiptDto } from '../dto';
@WebSocketGateway({
namespace: '/im',
cors: {
origin: '*',
credentials: true,
},
transports: ['websocket'],
pingTimeout: 10000,
pingInterval: 15000,
})
export class ImGateway
implements OnGatewayInit, OnGatewayConnection, OnGatewayDisconnect
{
@WebSocketServer()
server: Server;
private readonly logger = new Logger(ImGateway.name);
constructor(private readonly imService: ImService) {}
afterInit(server: Server): void {
this.logger.log('WebSocket Gateway 初始化完成');
this.imService.setServer(server);
}
async handleConnection(client: Socket): Promise<void> {
try {
// 解析认证信息
const token = client.handshake.auth.token;
const user = await this.imService.verifyToken(token);
if (!user) {
client.emit('auth_error', { message: '认证失败' });
client.disconnect(true);
return;
}
// 检查连接限制
const tierResult = await this.imService.acceptConnection(client, user);
if (!tierResult.accepted) {
client.emit('connection_rejected', { reason: tierResult.reason });
client.disconnect(true);
return;
}
// 附加用户信息到 socket
client.data.userId = user.userId;
client.data.userTier = tierResult.tier;
client.data.tierConfig = tierResult.config;
client.data.connectedAt = Date.now();
// 加入用户房间
client.join(`user:${user.userId}`);
client.join(`tier:${tierResult.tier}`);
// 设置在线状态
await this.imService.setPresence(user.userId, 'online', {
deviceId: user.deviceId,
tier: tierResult.tier,
});
// 发送连接成功消息
client.emit('connected', {
socketId: client.id,
tier: tierResult.tier,
serverTime: Date.now(),
});
this.logger.log(`用户 ${user.userId} 连接成功 (Tier: ${tierResult.tier})`);
} catch (error) {
this.logger.error(`连接处理失败: ${error.message}`);
client.disconnect(true);
}
}
async handleDisconnect(client: Socket): Promise<void> {
const userId = client.data.userId;
if (userId) {
await this.imService.removeConnection(client.id, userId);
await this.imService.setPresence(userId, 'offline');
this.logger.log(`用户 ${userId} 断开连接`);
}
}
@UseGuards(AuthGuard, RateLimitGuard)
@SubscribeMessage('message')
async handleMessage(
@ConnectedSocket() client: Socket,
@MessageBody() data: MessageDto,
): Promise<void> {
const userId = client.data.userId;
try {
const result = await this.imService.handleMessage(userId, data);
client.emit('message_sent', result);
} catch (error) {
client.emit('message_error', {
clientMessageId: data.clientMessageId,
error: error.message,
});
}
}
@SubscribeMessage('typing')
async handleTyping(
@ConnectedSocket() client: Socket,
@MessageBody() data: TypingDto,
): Promise<void> {
const userId = client.data.userId;
await this.imService.handleTyping(userId, data);
}
@SubscribeMessage('read_receipt')
async handleReadReceipt(
@ConnectedSocket() client: Socket,
@MessageBody() data: ReadReceiptDto,
): Promise<void> {
const userId = client.data.userId;
await this.imService.handleReadReceipt(userId, data);
}
@SubscribeMessage('join_conversation')
async handleJoinConversation(
@ConnectedSocket() client: Socket,
@MessageBody() data: { conversationId: string },
): Promise<void> {
const userId = client.data.userId;
await this.imService.joinConversation(client, userId, data.conversationId);
}
@SubscribeMessage('leave_conversation')
async handleLeaveConversation(
@ConnectedSocket() client: Socket,
@MessageBody() data: { conversationId: string },
): Promise<void> {
const userId = client.data.userId;
await this.imService.leaveConversation(client, userId, data.conversationId);
}
}2.2 数据传输对象定义
NestJS 推荐使用 DTO（Data Transfer Object）进行请求数据验证。通过 class-validator 和 class-transformer，可以实现自动的数据转换和验证，确保进入网关的数据符合预期格式。
typescript
// dto/index.ts
import { IsString, IsNotEmpty, IsOptional, IsNumber, MaxLength, IsEnum } from 'class-validator';
export class MessageDto {
@IsString()
@IsNotEmpty()
clientMessageId: string;
@IsString()
@IsNotEmpty()
conversationId: string;
@IsString()
@IsNotEmpty()
@MaxLength(10000)
content: string;
@IsOptional()
@IsNumber()
messageType?: number;
@IsOptional()
metadata?: Record<string, any>;
}
export class TypingDto {
@IsString()
@IsNotEmpty()
conversationId: string;
@IsBoolean()
isTyping: boolean;
}
export class ReadReceiptDto {
@IsString()
@IsNotEmpty()
conversationId: string;
@IsString()
@IsNotEmpty()
messageId: string;
}
export class JoinConversationDto {
@IsString()
@IsNotEmpty()
conversationId: string;
}2.3 Socket 认证守卫
守卫是 NestJS 管道/守卫/拦截器体系中的重要组成部分。Socket 认证守卫在消息处理之前验证用户身份，支持从握手信息或 Socket 数据中提取认证凭证。
typescript
// guards/ws-auth.guard.ts
import { CanActivate, ExecutionContext, Injectable, Logger } from '@nestjs/common';
import { WsException } from '@nestjs/websockets';
import { Socket } from 'socket.io';
import { JwtService } from '../services/jwt.service';
@Injectable()
export class AuthGuard implements CanActivate {
private readonly logger = new Logger(AuthGuard.name);
constructor(private readonly jwtService: JwtService) {}
async canActivate(context: ExecutionContext): Promise<boolean> {
const client: Socket = context.switchToWs().getClient();
// 优先从 socket.data 获取已验证的用户信息
if (client.data.userId) {
return true;
}
// 否则从握手信息中验证
const token = this.extractToken(client);
if (!token) {
throw new WsException('未提供认证令牌');
}
try {
const user = await this.jwtService.verifySocketToken(token);
client.data.userId = user.userId;
client.data.userTier = user.tier;
return true;
} catch (error) {
throw new WsException('认证失败');
}
}
private extractToken(client: Socket): string | null {
// 尝试从多个位置提取 token
return (
client.handshake.auth.token ||
client.handshake.headers.authorization?.replace('Bearer ', '') ||
this.extractTokenFromQuery(client)
);
}
private extractTokenFromQuery(client: Socket): string | null {
const token = client.handshake.query.token;
if (Array.isArray(token)) {
return token[0];
}
return token || null;
}
}2.4 限流守卫实现
typescript
// guards/rate-limit.guard.ts
import { CanActivate, ExecutionContext, Injectable } from '@nestjs/common';
import { WsException } from '@nestjs/websockets';
import { Socket } from 'socket.io';
import { RateLimiterService } from '../services/rate-limiter.service';
@Injectable()
export class RateLimitGuard implements CanActivate {
constructor(private readonly rateLimiterService: RateLimiterService) {}
async canActivate(context: ExecutionContext): Promise<boolean> {
const client: Socket = context.switchToWs().getClient();
const userId = client.data.userId;
if (!userId) {
return true; // 认证守卫会处理未认证的情况
}
const result = await this.rateLimiterService.check(userId);
if (!result.allowed) {
client.emit('rate_limited', {
retryAfter: result.retryAfter,
message: `发送频率超限，请在 ${result.retryAfter} 秒后重试`,
});
throw new WsException('发送频率超限');
}
return true;
}
}2.5 连接分级守卫
typescript
// guards/connection-tier.guard.ts
import { CanActivate, ExecutionContext, Injectable } from '@nestjs/common';
import { WsException } from '@nestjs/websockets';
import { Socket } from 'socket.io';
import { ConnectionTierService } from '../services/connection-tier.service';
@Injectable()
export class ConnectionTierGuard implements CanActivate {
constructor(private readonly tierService: ConnectionTierService) {}
async canActivate(context: ExecutionContext): Promise<boolean> {
const client: Socket = context.switchToWs().getClient();
const tier = client.data.userTier;
// 根据连接级别应用不同的限制
const tierConfig = this.tierService.getTierConfig(tier);
if (!tierConfig) {
throw new WsException('无效的连接级别');
}
// 将级别配置附加到 socket
client.data.tierConfig = tierConfig;
return true;
}
}核心服务层实现
3.1 IM 主服务
主服务是整个 Socket 业务的核心，负责协调各个子服务的功能，处理业务逻辑并与网关通信。
typescript
// services/im.service.ts
import { Injectable, Logger, OnModuleInit } from '@nestjs/common';
import { Server, Socket } from 'socket.io';
import { MessageDto, TypingDto, ReadReceiptDto } from '../dto';
import { ConnectionTierService } from './connection-tier.service';
import { PresenceService } from './presence.service';
import { MessageService } from './message.service';
import { StateAggregatorService } from './state-aggregator.service';
import { MessageStormControllerService } from './message-storm-controller.service';
import { JwtService } from './jwt.service';
import { RedisService } from './redis.service';
export interface AuthUser {
userId: string;
tier: string;
deviceId: string;
isPremium: boolean;
isAdmin: boolean;
}
export interface ConnectionResult {
accepted: boolean;
tier?: string;
config?: any;
reason?: string;
}
@Injectable()
export class ImService implements OnModuleInit {
private readonly logger = new Logger(ImService.name);
private server: Server;
constructor(
private readonly tierService: ConnectionTierService,
private readonly presenceService: PresenceService,
private readonly messageService: MessageService,
private readonly stateAggregator: StateAggregatorService,
private readonly stormController: MessageStormControllerService,
private readonly jwtService: JwtService,
private readonly redisService: RedisService,
) {}
onModuleInit(): void {
this.stateAggregator.setServer(this.server);
this.stormController.setServer(this.server);
}
setServer(server: Server): void {
this.server = server;
this.stateAggregator.setServer(server);
this.stormController.setServer(server);
}
async verifyToken(token: string): Promise<AuthUser | null> {
return this.jwtService.verifySocketToken(token);
}
async acceptConnection(
client: Socket,
user: AuthUser,
): Promise<ConnectionResult> {
return this.tierService.acceptConnection(client, user);
}
async removeConnection(socketId: string, userId: string): Promise<void> {
this.tierService.removeConnection(socketId, userId);
}
async setPresence(
userId: string,
status: string,
metadata?: Record<string, any>,
): Promise<void> {
await this.presenceService.setPresence(userId, status, metadata);
// 广播状态变更
this.stateAggregator.recordUpdate(`presence:${userId}`, {
type: 'presence',
userId,
status,
timestamp: Date.now(),
room: 'presence',
});
}
async handleMessage(userId: string, data: MessageDto): Promise<any> {
const message = await this.messageService.createMessage({
...data,
senderId: userId,
});
// 获取会话成员并广播消息
const members = await this.messageService.getConversationMembers(
data.conversationId,
);
for (const memberId of members) {
if (memberId !== userId) {
this.stormController.enqueue({
targetRoom: `user:${memberId}`,
event: 'new_message',
data: message,
senderId: userId,
});
}
}
return {
clientMessageId: data.clientMessageId,
serverMessageId: message.id,
timestamp: message.createdAt,
};
}
async handleTyping(userId: string, data: TypingDto): Promise<void> {
this.stateAggregator.recordUpdate(`typing:${data.conversationId}`, {
type: 'typing',
userId,
conversationId: data.conversationId,
isTyping: data.isTyping,
timestamp: Date.now(),
room: `conversation:${data.conversationId}`,
});
}
async handleReadReceipt(
userId: string,
data: ReadReceiptDto,
): Promise<void> {
await this.messageService.markAsRead(
userId,
data.conversationId,
data.messageId,
);
// 广播已读回执
this.server
.to(`user:${userId}`)
.emit('read_receipt', {
conversationId: data.conversationId,
messageId: data.messageId,
readBy: userId,
readAt: Date.now(),
});
}
async joinConversation(
client: Socket,
userId: string,
conversationId: string,
): Promise<void> {
client.join(`conversation:${conversationId}`);
await this.presenceService.subscribeToConversation(
userId,
conversationId,
);
// 获取当前会话在线成员
const onlineMembers = await this.presenceService.getConversationPresence(
conversationId,
);
client.emit('conversation_members', {
conversationId,
onlineMembers,
});
}
async leaveConversation(
client: Socket,
userId: string,
conversationId: string,
): Promise<void> {
client.leave(`conversation:${conversationId}`);
await this.presenceService.unsubscribeFromConversation(
userId,
conversationId,
);
}
async getOnlineUsers(userIds: string[]): Promise<Map<string, string>> {
return this.presenceService.getMultiplePresence(userIds);
}
}3.2 连接分级服务
连接分级服务实现了用户连接的分级管理和资源分配策略，确保高优先级用户获得更好的服务质量。
typescript
// services/connection-tier.service.ts
import { Injectable, Logger } from '@nestjs/common';
import { Socket } from 'socket.io';
import { CONNECTION_TIERS, SOCKET_CONFIG } from '../../config/constants';
export interface ConnectionTierConfig {
name: string;
weight: number;
maxConnections: number;
heartbeatInterval: number;
messageBufferSize: number;
}
export interface UserConnection {
socket: Socket;
tier: string;
userId: string;
connectedAt: number;
config: ConnectionTierConfig;
}
@Injectable()
export class ConnectionTierService {
private readonly logger = new Logger(ConnectionTierService.name);
private connections: Map<string, UserConnection> = new Map();
private tierConnections: Map<string, Set<string>> = new Map([
['critical', new Set()],
['standard', new Set()],
['degraded', new Set()],
]);
private totalConnections = 0;
private readonly maxTotalConnections = 200000;
constructor() {
// 初始化各等级配置
Object.entries(CONNECTION_TIERS).forEach(([, config]) => {
this.tierConnections.set(config.name, new Set());
});
}
private determineTier(authData: any): string {
if (authData.isPremium || authData.isAdmin) {
return 'critical';
}
if (authData.isActive || authData.lastLoginWithin(7, 'days')) {
return 'standard';
}
return 'degraded';
}
private getTierConfig(tierName: string): ConnectionTierConfig | null {
const tier = Object.values(CONNECTION_TIERS).find(
(t) => t.name === tierName,
);
return tier || null;
}
async acceptConnection(
client: Socket,
authData: any,
): Promise<{ accepted: boolean; tier?: string; config?: any; reason?: string }> {
const tierName = this.determineTier(authData);
const tierConfig = this.getTierConfig(tierName);
if (!tierConfig) {
return { accepted: false, reason: '无效的连接级别' };
}
// 检查全局连接数限制
if (this.totalConnections >= this.maxTotalConnections) {
const evicted = await this.evictLowestPriority();
if (!evicted) {
return { accepted: false, reason: '系统繁忙，请稍后重试' };
}
}
const currentTierCount = this.tierConnections.get(tierName).size;
// 检查当前级别连接数限制
if (currentTierCount >= tierConfig.maxConnections) {
// 尝试降级到下一级
const lowerTier = tierName === 'critical' ? 'standard' :
tierName === 'standard' ? 'degraded' : null;
if (lowerTier) {
const lowerConfig = this.getTierConfig(lowerTier);
if (lowerConfig && this.tierConnections.get(lowerTier).size < lowerConfig.maxConnections) {
return this.createConnection(client, authData, lowerTier, lowerConfig);
}
}
return { accepted: false, reason: `${tierName} 连接已满` };
}
return this.createConnection(client, authData, tierName, tierConfig);
}
private createConnection(
client: Socket,
authData: any,
tierName: string,
config: ConnectionTierConfig,
): { accepted: boolean; tier: string; config: any } {
const connection: UserConnection = {
socket: client,
tier: tierName,
userId: authData.userId,
connectedAt: Date.now(),
config,
};
this.connections.set(client.id, connection);
this.tierConnections.get(tierName).add(client.id);
this.totalConnections++;
this.logger.debug(
`连接建立: ${authData.userId} -> ${tierName} (总计: ${this.totalConnections})`,
);
return { accepted: true, tier: tierName, config };
}
private async evictLowestPriority(): Promise<boolean> {
const degradedConnections = this.tierConnections.get('degraded');
if (degradedConnections.size > 0) {
let oldestSocketId: string | null = null;
let oldestTime = Infinity;
for (const socketId of degradedConnections) {
const conn = this.connections.get(socketId);
if (conn && conn.connectedAt < oldestTime) {
oldestTime = conn.connectedAt;
oldestSocketId = socketId;
}
}
if (oldestSocketId) {
const conn = this.connections.get(oldestSocketId);
if (conn) {
conn.socket.emit('forced_disconnect', {
reason: '系统资源紧张',
});
conn.socket.disconnect(true);
return true;
}
}
}
return false;
}
async removeConnection(socketId: string, userId: string): Promise<void> {
const connection = this.connections.get(socketId);
if (connection) {
this.tierConnections.get(connection.tier).delete(socketId);
this.connections.delete(socketId);
this.totalConnections--;
this.logger.debug(
`连接移除: ${userId} -> ${connection.tier} (总计: ${this.totalConnections})`,
);
}
}
getTierConfig(tierName: string): ConnectionTierConfig | null {
return this.getTierConfig(tierName);
}
getStats(): any {
const stats = {
total: this.totalConnections,
byTier: {} as Record<string, number>,
limits: {} as Record<string, number>,
};
for (const [tier, sockets] of this.tierConnections.entries()) {
stats.byTier[tier] = sockets.size;
const config = this.getTierConfig(tier);
stats.limits[tier] = config?.maxConnections || 0;
}
return stats;
}
}3.3 消息风暴控制器
消息风暴控制器是保护系统在高峰期稳定运行的关键组件，通过令牌桶算法控制消息发送速率。
typescript
// services/message-storm-controller.service.ts
import { Injectable, Logger, OnModuleInit } from '@nestjs/common';
import { Server } from 'socket.io';
export interface QueuedMessage {
targetRoom: string;
event: string;
data: any;
senderId: string;
}
@Injectable()
export class MessageStormControllerService implements OnModuleInit {
private readonly logger = new Logger(MessageStormControllerService.name);
private server: Server;
private tokenBucket: TokenBucket;
private messageQueue: QueuedMessage[] = [];
private processingInterval: NodeJS.Timeout;
private readonly maxMessagesPerSecond = 50000;
private readonly maxBurstSize = 1000;
private readonly batchSize = 100;
onModuleInit(): void {
this.tokenBucket = new TokenBucket({
capacity: this.maxBurstSize,
refillRate: this.maxMessagesPerSecond / 1000,
});
this.startProcessing();
}
setServer(server: Server): void {
this.server = server;
}
enqueue(message: QueuedMessage): void {
const result = this.tokenBucket.tryConsume(1);
if (result.consumed) {
this.processMessage(message);
} else {
// 消息入队等待
this.messageQueue.push(message);
// 限制队列长度
if (this.messageQueue.length > 10000) {
this.messageQueue.shift(); // 丢弃最旧的消息
this.logger.warn('消息队列已满，丢弃最旧消息');
}
}
}
private processMessage(message: QueuedMessage): void {
const { targetRoom, event, data, senderId } = message;
if (!this.server) {
this.logger.error('Server 未初始化');
return;
}
this.server.to(targetRoom).volatile.emit(event, {
...data,
senderId,
sentAt: Date.now(),
});
}
private startProcessing(): void {
this.processingInterval = setInterval(async () => {
// 每秒补充的令牌数
await this.processQueue();
}, 100);
}
private async processQueue(): Promise<void> {
if (this.messageQueue.length === 0) return;
// 每 100ms 处理最多 batchSize 条消息
const batch = this.messageQueue.splice(0, this.batchSize);
for (const message of batch) {
const result = this.tokenBucket.tryConsume(1);
if (result.consumed) {
this.processMessage(message);
} else {
// 放回队列头部
this.messageQueue.unshift(message);
break;
}
}
}
getQueueSize(): number {
return this.messageQueue.length;
}
getTokenBucketStatus(): { tokens: number; capacity: number } {
return {
tokens: this.tokenBucket.getTokens(),
capacity: this.tokenBucket.getCapacity(),
};
}
}
// 令牌桶算法实现
class TokenBucket {
private tokens: number;
private lastRefill: number;
private readonly capacity: number;
private readonly refillRate: number;
constructor(options: { capacity: number; refillRate: number }) {
this.capacity = options.capacity;
this.refillRate = options.refillRate;
this.tokens = options.capacity;
this.lastRefill = Date.now();
}
private refill(): void {
const now = Date.now();
const elapsed = now - this.lastRefill;
const tokensToAdd = elapsed * this.refillRate;
this.tokens = Math.min(this.capacity, this.tokens + tokensToAdd);
this.lastRefill = now;
}
tryConsume(tokens: number): { consumed: boolean; remaining: number } {
this.refill();
if (this.tokens >= tokens) {
this.tokens -= tokens;
return { consumed: true, remaining: this.tokens };
}
return { consumed: false, remaining: this.tokens };
}
getTokens(): number {
this.refill();
return this.tokens;
}
getCapacity(): number {
return this.capacity;
}
}3.4 状态聚合服务
状态聚合服务通过批量处理和合并状态更新，减少网络传输量并提高系统响应速度。
typescript
// services/state-aggregator.service.ts
import { Injectable, Logger, OnModuleInit } from '@nestjs/common';
import { Server } from 'socket.io';
export interface StateUpdate {
type: string;
userId?: string;
conversationId?: string;
timestamp: number;
room: string;
[key: string]: any;
}
export interface AggregatedUpdate {
type: string;
updates: StateUpdate[];
timestamp: number;
}
@Injectable()
export class StateAggregatorService implements OnModuleInit {
private readonly logger = new Logger(StateAggregatorService.name);
private server: Server;
private pendingUpdates: Map<string, {
updates: StateUpdate[];
flushAt: number;
scheduled: boolean;
}> = new Map();
private readonly flushInterval = 100; // 100ms 聚合窗口
onModuleInit(): void {
// 定期清理过期的待处理更新
setInterval(() => {
this.cleanupExpired();
}, 60000);
}
setServer(server: Server): void {
this.server = server;
}
recordUpdate(key: string, update: StateUpdate): void {
if (!this.pendingUpdates.has(key)) {
this.pendingUpdates.set(key, {
updates: [],
flushAt: Date.now() + this.flushInterval,
scheduled: false,
});
}
const pending = this.pendingUpdates.get(key);
// 对于 typing 状态，合并同一用户的状态
if (update.type === 'typing') {
const existingIndex = pending.updates.findIndex(
(u) => u.type === 'typing' && u.userId === update.userId,
);
if (existingIndex >= 0) {
pending.updates[existingIndex] = {
...update,
timestamp: Date.now(),
};
return;
}
}
pending.updates.push(update);
// 调度刷新
if (!pending.scheduled) {
this.scheduleFlush(key);
}
}
private scheduleFlush(key: string): void {
const pending = this.pendingUpdates.get(key);
if (!pending) return;
pending.scheduled = true;
setTimeout(() => {
this.flushUpdates(key);
}, pending.flushAt - Date.now());
}
private flushUpdates(key: string): void {
const pending = this.pendingUpdates.get(key);
if (!pending || pending.updates.length === 0) {
this.pendingUpdates.delete(key);
return;
}
// 按房间分组
const groupedUpdates = this.groupByRoom(pending.updates);
// 广播更新
for (const [room, updates] of Object.entries(groupedUpdates)) {
if (this.server) {
this.server.to(room).emit('state_batch', {
updates,
timestamp: Date.now(),
} as AggregatedUpdate);
}
}
this.pendingUpdates.delete(key);
}
private groupByRoom(updates: StateUpdate[]): Map<string, StateUpdate[]> {
const grouped = new Map<string, StateUpdate[]>();
for (const update of updates) {
const room = update.room || 'global';
if (!grouped.has(room)) {
grouped.set(room, []);
}
grouped.get(room).push(update);
}
return grouped;
}
private cleanupExpired(): void {
const now = Date.now();
for (const [key, pending] of this.pendingUpdates.entries()) {
if (pending.flushAt < now - 60000) {
this.pendingUpdates.delete(key);
}
}
}
flushAll(): void {
for (const key of this.pendingUpdates.keys()) {
this.flushUpdates(key);
}
}
getPendingCount(): number {
return this.pendingUpdates.size;
}
}3.5 限流服务
限流服务采用滑动窗口算法，对用户的消息发送频率进行控制，防止恶意刷屏和资源滥用。
typescript
// services/rate-limiter.service.ts
import { Injectable, Logger } from '@nestjs/common';
import { SOCKET_CONFIG } from '../../config/constants';
export interface RateLimitResult {
allowed: boolean;
remaining: number;
currentCount: number;
retryAfter?: number;
}
@Injectable()
export class RateLimiterService {
private readonly logger = new Logger(RateLimiterService.name);
private windowData: Map<string, number[]> = new Map();
private readonly windowMs = SOCKET_CONFIG.RATE_LIMIT.WINDOW_MS;
private readonly maxMessages = SOCKET_CONFIG.RATE_LIMIT.MAX_MESSAGES;
constructor() {
// 定期清理过期数据
setInterval(() => {
this.cleanup();
}, this.windowMs);
}
async check(userId: string): Promise<RateLimitResult> {
const now = Date.now();
const windowStart = now - this.windowMs;
if (!this.windowData.has(userId)) {
this.windowData.set(userId, []);
}
const timestamps = this.windowData.get(userId);
// 清理过期时间戳
while (timestamps.length > 0 && timestamps[0] < windowStart) {
timestamps.shift();
}
if (timestamps.length >= this.maxMessages) {
const oldestTimestamp = timestamps[0];
const retryAfter = Math.ceil(
(oldestTimestamp + this.windowMs - now) / 1000,
);
return {
allowed: false,
retryAfter,
remaining: 0,
currentCount: timestamps.length,
};
}
timestamps.push(now);
return {
allowed: true,
remaining: this.maxMessages - timestamps.length,
currentCount: timestamps.length,
};
}
private cleanup(): void {
const now = Date.now();
const windowStart = now - this.windowMs;
for (const [userId, timestamps] of this.windowData.entries()) {
// 移除过期的数据
while (timestamps.length > 0 && timestamps[0] < windowStart) {
timestamps.shift();
}
// 清理空数据
if (timestamps.length === 0) {
this.windowData.delete(userId);
}
}
}
getStats(): { totalTracked: number; averageLoad: number } {
const allTimestamps = Array.from(this.windowData.values());
const totalCount = allTimestamps.reduce((sum, arr) => sum + arr.length, 0);
return {
totalTracked: this.windowData.size,
averageLoad: allTimestamps.length > 0
? totalCount / allTimestamps.length
: 0,
};
}
}3.6 在线状态服务
在线状态服务管理用户的在线状态，支持按用户、按会话查询当前在线成员列表。
typescript
// services/presence.service.ts
import { Injectable, Logger } from '@nestjs/common';
export interface PresenceState {
userId: string;
status: 'online' | 'away' | 'busy' | 'offline';
lastSeen: number;
metadata?: Record<string, any>;
}
@Injectable()
export class PresenceService {
private readonly logger = new Logger(PresenceService.name);
private presenceCache: Map<string, PresenceState> = new Map();
private conversationSubscribers: Map<string, Set<string>> = new Map();
private readonly ttl = 300; // 5 分钟离线判定
constructor() {
// 定期检查超时用户
setInterval(() => {
this.checkTimeouts();
}, this.ttl * 1000 / 2);
}
async setPresence(
userId: string,
status: string,
metadata?: Record<string, any>,
): Promise<void> {
const state: PresenceState = {
userId,
status: status as PresenceState['status'],
lastSeen: Date.now(),
metadata,
};
this.presenceCache.set(userId, state);
}
getPresence(userId: string): PresenceState {
const state = this.presenceCache.get(userId);
if (!state) {
return { userId, status: 'offline', lastSeen: 0 };
}
// 检查是否超时
if (Date.now() - state.lastSeen > this.ttl * 1000) {
return { userId, status: 'offline', lastSeen: state.lastSeen };
}
return state;
}
async subscribeToConversation(
userId: string,
conversationId: string,
): Promise<void> {
if (!this.conversationSubscribers.has(conversationId)) {
this.conversationSubscribers.set(conversationId, new Set());
}
this.conversationSubscribers.get(conversationId).add(userId);
}
async unsubscribeFromConversation(
userId: string,
conversationId: string,
): Promise<void> {
const subscribers = this.conversationSubscribers.get(conversationId);
if (subscribers) {
subscribers.delete(userId);
if (subscribers.size === 0) {
this.conversationSubscribers.delete(conversationId);
}
}
}
async getConversationPresence(
conversationId: string,
): Promise<PresenceState[]> {
const subscribers = this.conversationSubscribers.get(conversationId);
if (!subscribers) {
return [];
}
const presence: PresenceState[] = [];
for (const userId of subscribers) {
presence.push(this.getPresence(userId));
}
return presence;
}
async getMultiplePresence(
userIds: string[],
): Promise<Map<string, string>> {
const result = new Map<string, string>();
for (const userId of userIds) {
const state = this.getPresence(userId);
result.set(userId, state.status);
}
return result;
}
private checkTimeouts(): void {
const now = Date.now();
for (const [userId, state] of this.presenceCache.entries()) {
if (
state.status !== 'offline' &&
now - state.lastSeen > this.ttl * 1000
) {
state.status = 'offline';
this.logger.debug(`用户 ${userId} 状态变更为离线`);
}
}
}
getStats(): { totalOnline: number; conversations: number } {
let onlineCount = 0;
for (const state of this.presenceCache.values()) {
if (state.status !== 'offline') {
onlineCount++;
}
}
return {
totalOnline: onlineCount,
conversations: this.conversationSubscribers.size,
};
}
}NestJS 模块编排
4.1 消息模块
消息模块负责消息的创建、存储和查询，是 IM 服务的数据核心。
typescript
// modules/message/message.module.ts
import { Module, forwardRef } from '@nestjs/common';
import { MessageService } from './message.service';
import { MessageController } from './message.controller';
import { DatabaseModule } from '../database/database.module';
import { CacheModule } from '../cache/cache.module';
@Module({
imports: [
DatabaseModule,
forwardRef(() => CacheModule),
],
controllers: [MessageController],
providers: [MessageService],
exports: [MessageService],
})
export class MessageModule {}
typescript
// modules/message/message.service.ts
import { Injectable, Logger } from '@nestjs/common';
import { InjectRepository } from '@nestjs/typeorm';
import { Repository } from 'typeorm';
import { Message } from './entities/message.entity';
import { CacheService } from '../cache/cache.service';
export interface CreateMessageDto {
clientMessageId: string;
conversationId: string;
senderId: string;
content: string;
messageType?: number;
metadata?: Record<string, any>;
}
@Injectable()
export class MessageService {
private readonly logger = new Logger(MessageService.name);
constructor(
@InjectRepository(Message)
private readonly messageRepository: Repository<Message>,
private readonly cacheService: CacheService,
) {}
async createMessage(dto: CreateMessageDto): Promise<Message> {
const message = this.messageRepository.create({
clientMessageId: dto.clientMessageId,
conversationId: dto.conversationId,
senderId: dto.senderId,
content: dto.content,
messageType: dto.messageType || 1,
metadata: dto.metadata,
status: 'sent',
});
const saved = await this.messageRepository.save(message);
// 更新缓存中的未读计数
await this.incrementUnreadCount(dto.conversationId, dto.senderId);
return saved;
}
async getConversationMembers(conversationId: string): Promise<string[]> {
// 从缓存或数据库获取会话成员
const cacheKey = `conversation:members:${conversationId}`;
const cached = await this.cacheService.get<string[]>(cacheKey);
if (cached) {
return cached;
}
// 从数据库查询
// 实际实现中应该查询会话成员关系表
const members = await this.getMembersFromDatabase(conversationId);
await this.cacheService.set(cacheKey, members, { ttl: 300 });
return members;
}
async markAsRead(
userId: string,
conversationId: string,
messageId: string,
): Promise<void> {
// 更新消息的已读状态
await this.messageRepository.update(
{ id: messageId },
{ readBy: userId, readAt: new Date() },
);
// 更新缓存中的未读计数
await this.decrementUnreadCount(conversationId, userId);
}
private async getMembersFromDatabase(
conversationId: string,
): Promise<string[]> {
// 实际实现中查询会话成员关系表
return [];
}
private async incrementUnreadCount(
conversationId: string,
userId: string,
): Promise<void> {
const key = `unread:${conversationId}:${userId}`;
await this.cacheService.incr(key);
}
private async decrementUnreadCount(
conversationId: string,
userId: string,
): Promise<void> {
const key = `unread:${conversationId}:${userId}`;
await this.cacheService.decr(key);
}
async getUnreadCount(
conversationId: string,
userId: string,
): Promise<number> {
const key = `unread:${conversationId}:${userId}`;
return this.cacheService.get<number>(key) || 0;
}
}
typescript
// modules/message/entities/message.entity.ts
import {
Entity,
PrimaryGeneratedColumn,
Column,
CreateDateColumn,
Index,
} from 'typeorm';
@Entity('messages')
@Index(['conversationId', 'createdAt'])
export class Message {
@PrimaryGeneratedColumn('uuid')
id: string;
@Column({ name: 'client_message_id' })
clientMessageId: string;
@Column({ name: 'conversation_id' })
@Index()
conversationId: string;
@Column({ name: 'sender_id' })
@Index()
senderId: string;
@Column('text')
content: string;
@Column({ name: 'message_type', default: 1 })
messageType: number;
@Column('jsonb', { nullable: true })
metadata: Record<string, any>;
@Column({ default: 'sent' })
status: string;
@Column({ name: 'read_by', nullable: true })
readBy: string;
@Column({ name: 'read_at', type: 'timestamp', nullable: true })
readAt: Date;
@CreateDateColumn({ name: 'created_at' })
createdAt: Date;
}4.2 Redis 适配器模块
Redis 模块封装了 Socket.io 的 Redis 适配器，支持集群部署。
typescript
// modules/adapters/redis-adapter.module.ts
import { Module, Global } from '@nestjs/common';
import { RedisService } from './redis.service';
import { RedisAdapterProvider } from './redis-adapter.provider';
@Global()
@Module({
providers: [RedisService, RedisAdapterProvider],
exports: [RedisService, RedisAdapterProvider],
})
export class RedisModule {}
typescript
// modules/adapters/redis-adapter.provider.ts
import { Provider } from '@nestjs/common';
import { createAdapter } from '@socket.io/redis-adapter';
import { Redis } from 'ioredis';
import { ServerOptions } from 'socket.io';
export const REDIS_ADAPTER = 'REDIS_ADAPTER';
export class RedisAdapterProvider {
private pubClient: Redis;
private subClient: Redis;
private adapterCreator: any;
async createAdapter(): Promise<any> {
this.pubClient = new Redis({
host: process.env.REDIS_HOST || 'localhost',
port: parseInt(process.env.REDIS_PORT || '6379'),
password: process.env.REDIS_PASSWORD,
maxRetriesPerRequest: 3,
lazyConnect: true,
});
this.subClient = new Redis({
host: process.env.REDIS_HOST || 'localhost',
port: parseInt(process.env.REDIS_PORT || '6379'),
password: process.env.REDIS_PASSWORD,
maxRetriesPerRequest: 3,
lazyConnect: true,
});
await Promise.all([
this.pubClient.connect(),
this.subClient.connect(),
]);
this.adapterCreator = createAdapter(this.pubClient, this.subClient, {
requestsTimeout: 5000,
heartbeatInterval: 5000,
maxRetries: 3,
});
return this.adapterCreator;
}
getPubClient(): Redis {
return this.pubClient;
}
getSubClient(): Redis {
return this.subClient;
}
}4.3 Redis 服务
typescript
// modules/adapters/redis.service.ts
import { Injectable, Logger, OnModuleDestroy } from '@nestjs/common';
import { Redis } from 'ioredis';
import { SOCKET_CONFIG } from '../../config/constants';
@Injectable()
export class RedisService implements OnModuleDestroy {
private readonly logger = new Logger(RedisService.name);
private client: Redis;
constructor() {
this.client = new Redis({
host: process.env.REDIS_HOST || 'localhost',
port: parseInt(process.env.REDIS_PORT || '6379'),
password: process.env.REDIS_PASSWORD,
db: 0,
maxRetriesPerRequest: 3,
retryStrategy: (times) => {
const delay = Math.min(times * 50, 2000);
return delay;
},
});
this.client.on('connect', () => {
this.logger.log('Redis 连接成功');
});
this.client.on('error', (err) => {
this.logger.error(`Redis 连接错误: ${err.message}`);
});
}
async onModuleDestroy(): Promise<void> {
await this.client.quit();
}
async get<T>(key: string): Promise<T | null> {
const value = await this.client.get(`${SOCKET_CONFIG.REDIS_PREFIX}${key}`);
if (value) {
try {
return JSON.parse(value) as T;
} catch {
return value as unknown as T;
}
}
return null;
}
async set(
key: string,
value: any,
options?: { ttl?: number },
): Promise<void> {
const prefixedKey = `${SOCKET_CONFIG.REDIS_PREFIX}${key}`;
const serialized =
typeof value === 'string' ? value : JSON.stringify(value);
if (options?.ttl) {
await this.client.setex(prefixedKey, options.ttl, serialized);
} else {
await this.client.set(prefixedKey, serialized);
}
}
async del(key: string): Promise<void> {
await this.client.del(`${SOCKET_CONFIG.REDIS_PREFIX}${key}`);
}
async incr(key: string): Promise<number> {
return this.client.incr(`${SOCKET_CONFIG.REDIS_PREFIX}${key}`);
}
async decr(key: string): Promise<number> {
return this.client.decr(`${SOCKET_CONFIG.REDIS_PREFIX}${key}`);
}
async mget<T>(keys: string[]): Promise<(T | null)[]> {
const prefixedKeys = keys.map(
(k) => `${SOCKET_CONFIG.REDIS_PREFIX}${k}`,
);
const values = await this.client.mget(...prefixedKeys);
return values.map((v) => {
if (v) {
try {
return JSON.parse(v) as T;
} catch {
return v as unknown as T;
}
}
return null;
});
}
async expire(key: string, seconds: number): Promise<void> {
await this.client.expire(`${SOCKET_CONFIG.REDIS_PREFIX}${key}`, seconds);
}
async hset(key: string, field: string, value: any): Promise<void> {
const prefixedKey = `${SOCKET_CONFIG.REDIS_PREFIX}${key}`;
const serialized =
typeof value === 'string' ? value : JSON.stringify(value);
await this.client.hset(prefixedKey, field, serialized);
}
async hget<T>(key: string, field: string): Promise<T | null> {
const prefixedKey = `${SOCKET_CONFIG.REDIS_PREFIX}${key}`;
const value = await this.client.hget(prefixedKey, field);
if (value) {
try {
return JSON.parse(value) as T;
} catch {
return value as unknown as T;
}
}
return null;
}
async hgetall<T>(key: string): Promise<Record<string, T>> {
const prefixedKey = `${SOCKET_CONFIG.REDIS_PREFIX}${key}`;
const hash = await this.client.hgetall(prefixedKey);
const result: Record<string, T> = {};
for (const [field, value] of Object.entries(hash)) {
try {
result[field] = JSON.parse(value) as T;
} catch {
result[field] = value as unknown as T;
}
}
return result;
}
async sadd(key: string, ...members: string[]): Promise<number> {
return this.client.sadd(
`${SOCKET_CONFIG.REDIS_PREFIX}${key}`,
...members,
);
}
async srem(key: string, ...members: string[]): Promise<number> {
return this.client.srem(
`${SOCKET_CONFIG.REDIS_PREFIX}${key}`,
...members,
);
}
async smembers<T>(key: string): Promise<T[]> {
const members = await this.client.smembers(
`${SOCKET_CONFIG.REDIS_PREFIX}${key}`,
);
return members as T[];
}
}4.4 缓存模块
缓存模块提供多级缓存能力，支持进程内缓存和 Redis 分布式缓存。
typescript
// modules/cache/cache.module.ts
import { Module, Global } from '@nestjs/common';
import { CacheService } from './cache.service';
import { RedisModule } from '../adapters/redis-adapter.module';
@Global()
@Module({
imports: [RedisModule],
providers: [CacheService],
exports: [CacheService],
})
export class CacheModule {}
typescript
// modules/cache/cache.service.ts
import { Injectable, Logger } from '@nestjs/common';
import { RedisService } from '../adapters/redis.service';
// 简单的 LRU 缓存实现
class LRUCache<K, V> {
private cache = new Map<K, V>();
private readonly maxSize: number;
constructor(maxSize: number) {
this.maxSize = maxSize;
}
get(key: K): V | undefined {
const value = this.cache.get(key);
if (value !== undefined) {
// 移动到末尾表示最近使用
this.cache.delete(key);
this.cache.set(key, value);
}
return value;
}
set(key: K, value: V): void {
if (this.cache.has(key)) {
this.cache.delete(key);
} else if (this.cache.size >= this.maxSize) {
// 删除最旧的条目
const firstKey = this.cache.keys().next().value;
this.cache.delete(firstKey);
}
this.cache.set(key, value);
}
delete(key: K): boolean {
return this.cache.delete(key);
}
clear(): void {
this.cache.clear();
}
size(): number {
return this.cache.size;
}
}
@Injectable()
export class CacheService {
private readonly logger = new Logger(CacheService.name);
// L1: 进程内 LRU 缓存
private l1Cache = new LRUCache<string, any>(10000);
// L1 缓存的最大生命周期
private l1Ttl = 60000; // 1 分钟
constructor(private readonly redisService: RedisService) {}
async get<T>(key: string): Promise<T | null> {
// L1 查找
const l1Value = this.l1Cache.get(key);
if (l1Value !== undefined) {
return l1Value as T;
}
// L2 查找
const l2Value = await this.redisService.get<T>(key);
if (l2Value !== null) {
// 回填 L1
this.l1Cache.set(key, l2Value);
}
return l2Value;
}
async set<T>(
key: string,
value: T,
options?: { ttl?: number; l1Only?: boolean },
): Promise<void> {
// L1 缓存
this.l1Cache.set(key, value);
// L2 缓存
if (!options?.l1Only) {
await this.redisService.set(key, value, {
ttl: options?.ttl || 300,
});
}
}
async invalidate(key: string): Promise<void> {
this.l1Cache.delete(key);
await this.redisService.del(key);
}
async mget<T>(keys: string[]): Promise<(T | null)[]> {
const results: (T | null)[] = [];
const missingKeys: string[] = [];
// L1 批量查找
for (const key of keys) {
const value = this.l1Cache.get(key);
if (value !== undefined) {
results.push(value as T);
} else {
results.push(null);
missingKeys.push(key);
}
}
// L2 批量查找
if (missingKeys.length > 0) {
const l2Results = await this.redisService.mget<T>(missingKeys);
let resultIndex = 0;
for (let i = 0; i < keys.length; i++) {
if (results[i] === null) {
const l2Value = l2Results[resultIndex++];
results[i] = l2Value;
// 回填 L1
if (l2Value !== null) {
this.l1Cache.set(keys[i], l2Value);
}
}
}
}
return results;
}
async mset(
entries: Array<{ key: string; value: any; ttl?: number }>,
): Promise<void> {
for (const entry of entries) {
await this.set(entry.key, entry.value, { ttl: entry.ttl });
}
}
async incr(key: string): Promise<number> {
const value = await this.redisService.incr(key);
return value;
}
async decr(key: string): Promise<number> {
const value = await this.redisService.decr(key);
return value;
}
getL1Stats(): { size: number; maxSize: number } {
return {
size: this.l1Cache.size(),
maxSize: 10000,
};
}
}4.5 应用模块组装
typescript
// app.module.ts
import { Module } from '@nestjs/common';
import { TypeOrmModule } from '@nestjs/typeorm';
import { ImModule } from './modules/im/im.module';
import { MessageModule } from './modules/message/message.module';
import { CacheModule } from './modules/cache/cache.module';
import { RedisModule } from './modules/adapters/redis-adapter.module';
@Module({
imports: [
TypeOrmModule.forRoot({
type: 'postgres',
host: process.env.DB_HOST || 'localhost',
port: parseInt(process.env.DB_PORT || '5432'),
username: process.env.DB_USER || 'postgres',
password: process.env.DB_PASSWORD,
database: process.env.DB_NAME || 'im_db',
entities: [__dirname + '/**/*.entity{.ts,.js}'],
synchronize: process.env.NODE_ENV === 'development',
logging: process.env.NODE_ENV === 'development',
}),
RedisModule,
CacheModule,
MessageModule,
ImModule,
],
})
export class AppModule {}4.6 IM 核心模块
typescript
// modules/im/im.module.ts
import { Module } from '@nestjs/common';
import { ImGateway } from '../../gateways/im.gateway';
import { ImService } from './services/im.service';
import { ConnectionTierService } from './services/connection-tier.service';
import { PresenceService } from './services/presence.service';
import { MessageService } from '../message/message.service';
import { StateAggregatorService } from './services/state-aggregator.service';
import { MessageStormControllerService } from './services/message-storm-controller.service';
import { RateLimiterService } from './services/rate-limiter.service';
import { JwtService } from './services/jwt.service';
import { CacheModule } from '../cache/cache.module';
import { MessageModule } from '../message/message.module';
@Module({
imports: [CacheModule, MessageModule],
providers: [
ImGateway,
ImService,
ConnectionTierService,
PresenceService,
StateAggregatorService,
MessageStormControllerService,
RateLimiterService,
JwtService,
],
exports: [ImService],
})
export class ImModule {}JWT 认证服务
typescript
// modules/im/services/jwt.service.ts
import { Injectable, Logger } from '@nestjs/common';
import { JwtService as NestJwtService } from '@nestjs/jwt';
export interface JwtPayload {
userId: string;
tier: string;
deviceId: string;
isPremium: boolean;
isAdmin: boolean;
iat?: number;
exp?: number;
}
@Injectable()
export class JwtService {
private readonly logger = new Logger(JwtService.name);
constructor(private readonly nestJwtService: NestJwtService) {}
async verifySocketToken(token: string): Promise<JwtPayload | null> {
try {
const payload = await this.nestJwtService.verifyAsync<JwtPayload>(token);
return {
userId: payload.userId,
tier: payload.tier || 'standard',
deviceId: payload.deviceId,
isPremium: payload.isPremium || false,
isAdmin: payload.isAdmin || false,
};
} catch (error) {
this.logger.warn(`Token 验证失败: ${error.message}`);
return null;
}
}
generateToken(payload: Omit<JwtPayload, 'iat' | 'exp'>): string {
return this.nestJwtService.sign(payload);
}
decodeToken(token: string): JwtPayload | null {
try {
return this.nestJwtService.decode(token) as JwtPayload;
} catch {
return null;
}
}
}健康检查与监控
5.1 健康检查模块
typescript
// modules/health/health.module.ts
import { Module } from '@nestjs/common';
import { TerminusModule } from '@nestjs/terminus';
import { HealthController } from './health.controller';
@Module({
imports: [TerminusModule],
controllers: [HealthController],
})
export class HealthModule {}
typescript
// modules/health/health.controller.ts
import { Controller, Get } from '@nestjs/common';
import {
HealthCheck,
HealthCheckService,
TypeOrmHealthIndicator,
DiskHealthIndicator,
MemoryHealthIndicator,
} from '@nestjs/terminus';
import { ConnectionTierService } from '../im/services/connection-tier.service';
import { PresenceService } from '../im/services/presence.service';
import { RateLimiterService } from '../im/services/rate-limiter.service';
@Controller('health')
export class HealthController {
constructor(
private readonly health: HealthCheckService,
private readonly db: TypeOrmHealthIndicator,
private readonly disk: DiskHealthIndicator,
private readonly memory: MemoryHealthIndicator,
private readonly tierService: ConnectionTierService,
private readonly presenceService: PresenceService,
private readonly rateLimiterService: RateLimiterService,
) {}
@Get()
@HealthCheck()
check() {
return this.health.check([
// 数据库健康检查
() => this.db.pingCheck('database'),
// 内存健康检查
() =>
this.memory.checkHeap('memory_heap', 1500 * 1024 * 1024), // 1.5GB
// 磁盘健康检查
() => this.disk.checkStorage('disk', { thresholdPercent: 0.9 }),
// 自定义 Socket 服务健康检查
async () => {
const tierStats = this.tierService.getStats();
const presenceStats = this.presenceService.getStats();
const rateLimitStats = this.rateLimiterService.getStats();
return {
socket: {
status: 'up',
totalConnections: tierStats.total,
byTier: tierStats.byTier,
onlineUsers: presenceStats.totalOnline,
rateLimitTracked: rateLimitStats.totalTracked,
},
};
},
]);
}
@Get('ready')
@HealthCheck()
readiness() {
return this.health.check([
() => this.db.pingCheck('database'),
]);
}
@Get('live')
@HealthCheck()
liveness() {
return this.health.check([
async () => ({
api: { status: 'up' },
}),
]);
}
}性能指标导出
typescript
// modules/metrics/metrics.module.ts
import { Module } from '@nestjs/common';
import { PrometheusModule } from '@willsoto/nestjs-prometheus';
import { MetricsService } from './metrics.service';
@Module({
imports: [
PrometheusModule.register({
path: '/metrics',
defaultMetrics: {
enabled: true,
},
}),
],
providers: [MetricsService],
exports: [MetricsService],
})
export class MetricsModule {}
typescript
// modules/metrics/metrics.service.ts
import { Injectable, OnModuleInit } from '@nestjs/common';
import { Counter, Gauge, Histogram, Registry } from 'prom-client';
import { InjectMetric } from '@willsoto/nestjs-prometheus';
import { ConnectionTierService } from '../im/services/connection-tier.service';
import { PresenceService } from '../im/services/presence.service';
import { RateLimiterService } from '../im/services/rate-limiter.service';
@Injectable()
export class MetricsService implements OnModuleInit {
private readonly registry: Registry;
// 自定义指标
private readonly activeConnections: Gauge;
private readonly messagesSent: Counter;
private readonly messagesReceived: Counter;
private readonly connectionLatency: Histogram;
private readonly rateLimitHits: Counter;
constructor(
@InjectMetric('im_active_connections') activeConnections: Gauge,
@InjectMetric('im_messages_sent') messagesSent: Counter,
@InjectMetric('im_messages_received') messagesReceived: Counter,
private readonly tierService: ConnectionTierService,
private readonly presenceService: PresenceService,
private readonly rateLimiterService: RateLimiterService,
) {
this.activeConnections = activeConnections;
this.messagesSent = messagesSent;
this.messagesReceived = messagesReceived;
this.registry = new Registry();
}
onModuleInit(): void {
// 定期更新指标
setInterval(() => {
this.updateMetrics();
}, 5000);
}
private updateMetrics(): void {
const tierStats = this.tierService.getStats();
const presenceStats = this.presenceService.getStats();
// 更新连接数指标
this.activeConnections.set({
tier: 'total',
}, tierStats.total);
for (const [tier, count] of Object.entries(tierStats.byTier)) {
this.activeConnections.set({ tier }, count as number);
}
}
recordMessageSent(conversationId: string): void {
this.messagesSent.inc({ conversation: conversationId });
}
recordMessageReceived(conversationId: string): void {
this.messagesReceived.inc({ conversation: conversationId });
}
recordConnectionLatency(duration: number): void {
this.connectionLatency.observe(duration);
}
recordRateLimitHit(): void {
this.rateLimitHits.inc();
}
getRegistry(): Registry {
return this.registry;
}
}主入口配置
typescript
// main.ts
import { NestFactory } from '@nestjs/core';
import { ValidationPipe, Logger } from '@nestjs/common';
import { IoAdapter } from '@nestjs/platform-socket.io';
import { AppModule } from './app.module';
import { RedisAdapterProvider } from './modules/adapters/redis-adapter.provider';
async function bootstrap() {
const logger = new Logger('Bootstrap');
const app = await NestFactory.create(AppModule);
// 全局管道
app.useGlobalPipes(
new ValidationPipe({
transform: true,
whitelist: true,
forbidNonWhitelisted: true,
}),
);
// CORS 配置
app.enableCors({
origin: '*',
credentials: true,
});
// 初始化 Redis 适配器
const redisAdapterProvider = app.get(RedisAdapterProvider);
const redisAdapter = await redisAdapterProvider.createAdapter();
// 自定义 Socket.io 适配器
app.useWebSocketAdapter(new RedisIoAdapter(app, redisAdapter));
const port = process.env.PORT || 3000;
await app.listen(port);
logger.log(`IM Socket 服务运行在端口 ${port}`);
}
class RedisIoAdapter extends IoAdapter {
private adapterConstructor: any;
constructor(app: any, adapter: any) {
super(app);
this.adapterConstructor = adapter;
}
createIOServer(port: number, options?: any): any {
const server = super.createIOServer(port, {
...options,
cors: {
origin: '*',
credentials: true,
},
transports: ['websocket'],
pingTimeout: 10000,
pingInterval: 15000,
});
return this.adapterConstructor(server);
}
}
bootstrap();总结
NestJS 框架为 Socket.io 服务提供了更加结构化和企业级的实现方式。通过模块化架构，业务逻辑被清晰地分离到不同的模块中，每个模块专注于特定的功能域。依赖注入机制使得服务之间的协作变得简单可控，而守卫、管道、拦截器等装饰器提供的 AOP 能力，则让我们能够优雅地处理横切关注点如认证、限流和验证。
在 IM 通信文档协同场景下，通过连接分级管理实现资源的差异化分配，通过消息风暴控制器防止系统在高峰期过载，通过状态聚合服务减少无效的网络传输，通过多级缓存保护数据库，这些优化策略在 NestJS 框架下得以用更加声明式和可维护的方式实现。整体架构既保持了高性能，又提供了良好的可扩展性和可测试性，适合作为企业级 IM 服务的基础框架。
