前言
本章我们继续使用 Jetpack 来完善音乐播放器，今天我们来晚上 播放 能力，也就是 PlayerFragment；
PlayerFragment
播放器我们使用了一个开源的：
arduino
implementation 'com.kunminx.player:player:1.1.6'PlayerManager
我们来定义一个 PlayerManager 来管理我们的播放能力；
kotlin
class PlayerManager private constructor() : IPlayController<TestAlbum, TestMusic?> {
private val mController: PlayerController<TestAlbum, TestMusic>
private var mContext: Context? = null
fun init(context: Context) {
init(context, null)
}
override fun init(context: Context, iServiceNotifier: IServiceNotifier?) {
mContext = context.applicationContext
mController.init(mContext, null) { startOrStop: Boolean ->
val intent = Intent(mContext, PlayerService::class.java)
if (startOrStop) {
// 后台播放
mContext?.startService(intent)
} else {
// 停止后台播放
mContext?.stopService(intent)
}
}
}
override fun loadAlbum(musicAlbum: TestAlbum) {
mController.loadAlbum(mContext, musicAlbum)
}
override fun loadAlbum(musicAlbum: TestAlbum, playIndex: Int) {
mController.loadAlbum(mContext, musicAlbum, playIndex)
}
override fun playAudio() {
mController.playAudio(mContext)
}
// 下标的播放
override fun playAudio(albumIndex: Int) {
// 在这里只需要知道，调用此 playAudio函数，就能够播放音乐了
mController.playAudio(mContext, albumIndex)
}
// 下一首播放
override fun playNext() {
mController.playNext(mContext)
}
// 上一首播放
override fun playPrevious() {
mController.playPrevious(mContext)
}
override fun playAgain() {
mController.playAgain(mContext)
}
// 暂停播放
override fun pauseAudio() {
mController.pauseAudio()
}
override fun resumeAudio() {
mController.resumeAudio()
}
// 清除歌曲下标的标记
override fun clear() {
mController.clear(mContext)
}
override fun changeMode() {
mController.changeMode()
}
override fun isPlaying(): Boolean {
return mController.isPlaying
}
override fun isPaused(): Boolean {
return mController.isPaused
}
override fun isInited(): Boolean {
return mController.isInited
}
override fun requestLastPlayingInfo() {
mController.requestLastPlayingInfo()
}
override fun setSeek(progress: Int) {
mController.setSeek(progress)
}
override fun getTrackTime(progress: Int): String {
return mController.getTrackTime(progress)
}
override fun getAlbum(): TestAlbum? {
return mController.album
}
override fun getAlbumMusics(): List<TestMusic?> {
return mController.albumMusics
}
override fun setChangingPlayingMusic(changingPlayingMusic: Boolean) {
mController.setChangingPlayingMusic(mContext, changingPlayingMusic)
}
override fun getAlbumIndex(): Int {
return mController.albumIndex
}
// 返回音乐播放的 ld，上一首，下一首
override fun getChangeMusicLiveData(): MutableLiveData<ChangeMusic<*, *, *>> {
return mController.changeMusicLiveData
}
// 音乐数据，也需要观察
override fun getPlayingMusicLiveData(): MutableLiveData<PlayingMusic<*, *>> {
return mController.playingMusicLiveData
}
override fun getPauseLiveData(): MutableLiveData<Boolean> {
return mController.pauseLiveData
}
// 播放模式：列表循环，单曲循环，随机播放
override fun getPlayModeLiveData(): MutableLiveData<Enum<*>> {
return mController.playModeLiveData
}
override fun getRepeatMode(): Enum<*> ? {
return mController.repeatMode
}
override fun togglePlay() {
mController.togglePlay(mContext)
}
override fun getCurrentPlayingMusic(): TestMusic {
return mController.currentPlayingMusic
}
companion object {
// 单例模式
@SuppressLint("StaticFieldLeak")
val instance = PlayerManager() // 单例相关的
}
init {
mController = PlayerController()
}
}PlayerService
我们再来定一个 PlayerService 用来支持后台播放的能力；
kotlin
class PlayerService : Service() {
private var mPlayerCallHelper: PlayerCallHelper? = null
override fun onStartCommand(intent: Intent, flags: Int, startId: Int): Int {
// 在播放的时候来电话了
if (mPlayerCallHelper == null) {
mPlayerCallHelper = PlayerCallHelper(object : PlayerCallHelperListener {
override fun playAudio() {
PlayerManager.instance.playAudio()
}
override val isPlaying: Boolean
get() = PlayerManager.instance.isPlaying
override val isPaused: Boolean
get() = PlayerManager.instance.isPaused
override fun pauseAudio() {
PlayerManager.instance.pauseAudio()
}
})
}
val results = PlayerManager.instance.currentPlayingMusic
if (results == null) {
stopSelf()
return START_NOT_STICKY
}
mPlayerCallHelper?.bindCallListener(applicationContext)
createNotification(results)
return START_NOT_STICKY
}
// 创建通知
private fun createNotification(testMusic: TestMusic) {
try {
val title = testMusic.title
val album = PlayerManager.instance.album
val summary = album?.summary
val simpleContentView = RemoteViews(
applicationContext.packageName, R.layout.notify_player_small
)
val expandedView: RemoteViews
expandedView = RemoteViews(
applicationContext.packageName, R.layout.notify_player_big
)
val intent = Intent(applicationContext, MainActivity::class.java)
intent.action = "showPlayer"
val contentIntent = PendingIntent.getActivity(
this, 0, intent, 0
)
if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.O) {
val notificationManager =
getSystemService(NOTIFICATION_SERVICE) as NotificationManager
val playGroup = NotificationChannelGroup(GROUP_ID, getString(R.string.play))
notificationManager.createNotificationChannelGroup(playGroup)
val playChannel = NotificationChannel(
CHANNEL_ID,
getString(R.string.notify_of_play), NotificationManager.IMPORTANCE_DEFAULT
)
playChannel.group = GROUP_ID
notificationManager.createNotificationChannel(playChannel)
}
val notification = NotificationCompat.Builder(
applicationContext, CHANNEL_ID
)
.setSmallIcon(R.drawable.ic_player)
.setContentIntent(contentIntent)
.setOnlyAlertOnce(true)
.setContentTitle(title).build()
notification.contentView = simpleContentView
notification.bigContentView = expandedView
setListeners(simpleContentView)
setListeners(expandedView)
notification.contentView.setViewVisibility(R.id.player_progress_bar, View.GONE)
notification.contentView.setViewVisibility(R.id.player_next, View.VISIBLE)
notification.contentView.setViewVisibility(R.id.player_previous, View.VISIBLE)
notification.bigContentView.setViewVisibility(R.id.player_next, View.VISIBLE)
notification.bigContentView.setViewVisibility(R.id.player_previous, View.VISIBLE)
notification.bigContentView.setViewVisibility(R.id.player_progress_bar, View.GONE)
val isPaused = PlayerManager.instance.isPaused
notification.contentView.setViewVisibility(
R.id.player_pause,
if (isPaused) View.GONE else View.VISIBLE
)
notification.contentView.setViewVisibility(
R.id.player_play,
if (isPaused) View.VISIBLE else View.GONE
)
notification.bigContentView.setViewVisibility(
R.id.player_pause,
if (isPaused) View.GONE else View.VISIBLE
)
notification.bigContentView.setViewVisibility(
R.id.player_play,
if (isPaused) View.VISIBLE else View.GONE
)
notification.contentView.setTextViewText(R.id.player_song_name, title)
notification.contentView.setTextViewText(R.id.player_author_name, summary)
notification.bigContentView.setTextViewText(R.id.player_song_name, title)
notification.bigContentView.setTextViewText(R.id.player_author_name, summary)
notification.flags = notification.flags or Notification.FLAG_ONGOING_EVENT
val coverPath = Configs.COVER_PATH + File.separator + testMusic.musicId + ".jpg"
val bitmap = ImageUtils.getBitmap(coverPath)
if (bitmap != null) {
notification.contentView.setImageViewBitmap(R.id.player_album_art, bitmap)
notification.bigContentView.setImageViewBitmap(R.id.player_album_art, bitmap)
} else {
requestAlbumCover(testMusic.coverImg, testMusic.musicId)
notification.contentView.setImageViewResource(
R.id.player_album_art,
R.drawable.bg_album_default
)
notification.bigContentView.setImageViewResource(
R.id.player_album_art,
R.drawable.bg_album_default
)
}
startForeground(5, notification)
mPlayerCallHelper?.bindRemoteController(applicationContext)
mPlayerCallHelper?.requestAudioFocus(title, summary)
} catch (e: Exception) {
e.printStackTrace()
}
}
// 设置监听器
fun setListeners(view: RemoteViews) {
try {
var pendingIntent = PendingIntent.getBroadcast(
applicationContext,
0, Intent(NOTIFY_PREVIOUS).setPackage(packageName),
PendingIntent.FLAG_UPDATE_CURRENT
)
view.setOnClickPendingIntent(R.id.player_previous, pendingIntent)
pendingIntent = PendingIntent.getBroadcast(
applicationContext,
0, Intent(NOTIFY_CLOSE).setPackage(packageName),
PendingIntent.FLAG_UPDATE_CURRENT
)
view.setOnClickPendingIntent(R.id.player_close, pendingIntent)
pendingIntent = PendingIntent.getBroadcast(
applicationContext,
0, Intent(NOTIFY_PAUSE).setPackage(packageName),
PendingIntent.FLAG_UPDATE_CURRENT
)
view.setOnClickPendingIntent(R.id.player_pause, pendingIntent)
pendingIntent = PendingIntent.getBroadcast(
applicationContext,
0, Intent(NOTIFY_NEXT).setPackage(packageName),
PendingIntent.FLAG_UPDATE_CURRENT
)
view.setOnClickPendingIntent(R.id.player_next, pendingIntent)
pendingIntent = PendingIntent.getBroadcast(
applicationContext,
0, Intent(NOTIFY_PLAY).setPackage(packageName),
PendingIntent.FLAG_UPDATE_CURRENT
)
view.setOnClickPendingIntent(R.id.player_play, pendingIntent)
} catch (e: Exception) {
e.printStackTrace()
}
}
// 请求专辑封面
private fun requestAlbumCover(coverUrl: String, musicId: String) {
// todo
}
// 解绑监听等操作
override fun onDestroy() {
super.onDestroy()
mPlayerCallHelper?.unbindCallListener(applicationContext)
mPlayerCallHelper?.unbindRemoteController()
}
override fun onBind(intent: Intent): IBinder? {
return null
}
// 此标记 与 广播接受者 AndroidManifest.xml 里面的标记保持一致
companion object {
const val NOTIFY_PREVIOUS = "pure_music.llc_mars.previous"
const val NOTIFY_CLOSE = "pure_music.llc_mars.close"
const val NOTIFY_PAUSE = "pure_music.llc_mars.pause"
const val NOTIFY_PLAY = "pure_music.llc_mars.play"
const val NOTIFY_NEXT = "pure_music.llc_mars.next"
private const val GROUP_ID = "group_001"
private const val CHANNEL_ID = "channel_001"
}
}PlayerReceiver
接下来，我们来创建一个广播，用于接收某些改变（系统发出来的信息，断网了），对音乐做出对应操作；
kotlin
class PlayerReceiver : BroadcastReceiver() {
// 广播接受者
override fun onReceive(context: Context, intent: Intent) {
if (intent.action == Intent.ACTION_MEDIA_BUTTON) {
if (intent.extras == null) {
return
}
val keyEvent = intent.extras?[Intent.EXTRA_KEY_EVENT] as KeyEvent? ?: return
if (keyEvent.action != KeyEvent.ACTION_DOWN) {
return
}
when (keyEvent.keyCode) {
KeyEvent.KEYCODE_HEADSETHOOK, KeyEvent.KEYCODE_MEDIA_PLAY_PAUSE -> PlayerManager.instance
.togglePlay()
KeyEvent.KEYCODE_MEDIA_PLAY -> PlayerManager.instance.playAudio() // 播放音频
KeyEvent.KEYCODE_MEDIA_PAUSE -> PlayerManager.instance.pauseAudio() // 暂停音频
KeyEvent.KEYCODE_MEDIA_STOP -> PlayerManager.instance.clear() // 清除记录
KeyEvent.KEYCODE_MEDIA_NEXT -> PlayerManager.instance.playNext() // 下一首音频播放
KeyEvent.KEYCODE_MEDIA_PREVIOUS -> PlayerManager.instance.playPrevious() // 上一首音频播放
else -> {
}
}
} else {
if (Objects.requireNonNull(intent.action) == PlayerService.NOTIFY_PLAY) {
PlayerManager.instance.playAudio() // 播放音频
} else if (intent.action == PlayerService.NOTIFY_PAUSE || intent.action == AudioManager.ACTION_AUDIO_BECOMING_NOISY) {
PlayerManager.instance.pauseAudio() // 暂停音频
} else if (intent.action == PlayerService.NOTIFY_NEXT) {
PlayerManager.instance.playNext() // 下一首音频播放
} else if (intent.action == PlayerService.NOTIFY_CLOSE) {
PlayerManager.instance.clear() // 清除记录
} else if (intent.action == PlayerService.NOTIFY_PREVIOUS) {
PlayerManager.instance.playPrevious() // 上一首音频播放
}
}
}
}接下来，我们需要完善下我们的 MainFragment，用来调用 PlayerManager 来实现播放；
kotlin
override fun onViewCreated(view: View, savedInstanceState: Bundle?) {
super.onViewCreated(view, savedInstanceState)
.... 省略上一章的部分代码
adapter = object : SimpleBaseBindingAdapter<TestAlbum.TestMusic?, AdapterPlayItemBinding?>(context, R.layout.adapter_play_item) {
override fun onSimpleBindItem(
binding: AdapterPlayItemBinding?,
item: TestAlbum.TestMusic?,
holder: RecyclerView.ViewHolder?) {
.... 省略上一章的部分代码
// 歌曲下标记录
val currentIndex = PlayerManager.instance.albumIndex // 歌曲下标记录
// 播放的标记
binding.ivPlayStatus.setColor(
if (currentIndex == holder ?.adapterPosition) resources.getColor(R.color.colorAccent) else Color.TRANSPARENT
) // 播放的时候，右变状态图标就是红色， 如果对不上的时候，就是没有
// 点击Item
binding.root.setOnClickListener { v ->
Toast.makeText(mContext, "播放音乐", Toast.LENGTH_SHORT).show()
PlayerManager.instance.playAudio(holder?.adapterPosition)
}
}
}
.... 省略上一章的部分代码
// 播放相关业务的数据（如果这个数据发生了改变，为了更好的体验）
PlayerManager.instance.changeMusicLiveData.observe(viewLifecycleOwner, {
// 刷新适配器，这里也可以改成局部刷新，使用 DiffUtil 来完成局部刷新
adapter?.notifyDataSetChanged()
})
// 请求数据
// 保证我们列表没有数据（music list）
if (PlayerManager.instance.album == null) {
musicRequestViewModel?.requestFreeMusics()
}
// 音乐资源的 VM getFreeMusicsLiveData变化了，如果变化就执行
musicRequestViewModel?.freeMusicesLiveData?.observe(viewLifecycleOwner, { musicAlbum: TestAlbum? ->
if (musicAlbum != null && musicAlbum.musics != null) {
.... 省略上一章的部分代码
// 播放相关的业务需要这个数据
if (PlayerManager.instance.album == null ||
PlayerManager.instance.album?.albumId != musicAlbum.albumId) {
PlayerManager.instance.loadAlbum(musicAlbum)
}
}
})
}PlayerViewModel
我们接下来完善下 PlayerFramgent 对应的 PlayerViewModel，用来控制播放；
less
class PlayerViewModel : ViewModel() {
// 为什么要使用 ObservableField(DataBinding) 为什么不用LiveData
// 不需要 LiveData 可见才能观察的能力，反而会导致有bug，因为灭屏、可见都要播放；
// 歌曲名称
@JvmField // 剔除 getXXX 函数
val title = ObservableField<String>()
// 歌手
@JvmField
val artist = ObservableField<String>()
// 歌曲图片的地址：htpp:xxxx/img0.jpg
@JvmField
val coverImg = ObservableField<String>()
// 歌曲正方形图片
@JvmField
val placeHolder = ObservableField<Drawable>()
// 歌曲的总时长，会显示在拖动条后面
@JvmField
val maxSeekDuration = ObservableInt()
// 当前拖动条的进度值
@JvmField
val currentSeekPosition = ObservableInt()
// 播放按钮，状态的改变(播放和暂停)
@JvmField
val isPlaying = ObservableBoolean()
// 这个是播放图标的状态，也都是属于状态的改变
@JvmField
val playModeIcon = ObservableField<MaterialDrawableBuilder.IconValue>()
// 构造代码块，默认初始化
init {
title.set(Utils.getApp().getString(R.string.app_name)) // 默认信息
artist.set(Utils.getApp().getString(R.string.app_name)) // 默认信息
placeHolder.set(Utils.getApp().resources.getDrawable(R.drawable.bg_album_default)) // 默认的播放图标
if (PlayerManager.instance.repeatMode === PlayingInfoManager.RepeatMode.LIST_LOOP) { // 如果等于"列表循环"
playModeIcon.set(MaterialDrawableBuilder.IconValue.REPEAT)
} else if (PlayerManager.instance.repeatMode === PlayingInfoManager.RepeatMode.ONE_LOOP) { // 如果等于"单曲循环"
playModeIcon.set(MaterialDrawableBuilder.IconValue.REPEAT_ONCE)
} else {
playModeIcon.set(MaterialDrawableBuilder.IconValue.SHUFFLE) // 随机播放
}
}
}接下来，我们在 PlayerFragment 中初始化这个 ViewModel；
PlayerFramgent
接下来，我们来晚上 PlayerFragment 用来展示画面，控制播放；
kotlin
class PlayerFragment : BaseFragment(){
private var binding: FragmentPlayerBinding? = null
private var playerViewModel: PlayerViewModel? = null
override fun onCreate(savedInstanceState: Bundle?) {
super.onCreate(savedInstanceState)
// 初始化 VM
playerViewModel = getFragmentViewModelProvider(this).get<PlayerViewModel>(PlayerViewModel::class.java)
}
// DataBinding + ViewModel
override fun onCreateView(
inflater: LayoutInflater,
container: ViewGroup?,
savedInstanceState: Bundle?): View {
// 加载界面
val view: View = inflater.inflate(R.layout.fragment_player, container, false)
// 绑定 Binding
binding = FragmentPlayerBinding.bind(view)
binding?.click = ClickProxy() // 布局控制 点击事件的
binding?.event = EventHandler() // 布局控制 拖动条的
binding?.vm = playerViewModel // ViewModel与布局关联
return view
}
// 观察变化
// 观察到数据的变化，就变化
override fun onViewCreated(view: View, savedInstanceState: Bundle?) {
super.onViewCreated(view, savedInstanceState)
// 观察：此字段只要发生了改变，就会添加监听（可以弹上来的监听）
sharedViewModel.timeToAddSlideListener.observe(viewLifecycleOwner, {
if (view.parent.parent is SlidingUpPanelLayout) {
val sliding = view.parent.parent as SlidingUpPanelLayout
// 添加监听（可以弹上来的监听）
bingding?.let {
sliding.addPanelSlideListener(PlayerSlideListener(it, sliding))
}
}
})
// 我是播放条，我要去变化，我成为观察者 ---> 播放相关的类 PlayerManager
PlayerManager.instance.changeMusicLiveData.observe(viewLifecycleOwner, { changeMusic ->
// 例如 ：理解切歌的时候，音乐的标题，作者，封面，状态等改变
playerViewModel?.title.set(changeMusic.title)
playerViewModel?.artist.set(changeMusic.summary)
playerViewModel?.coverImg.set(changeMusic.img)
})
// 我是播放条，我要去变化，我成为观察者 -----> 播放相关的类PlayerManager
PlayerManager.instance.playingMusicLiveData.observe(viewLifecycleOwner, { playingMusic ->
// 例如 ：理解 切歌的时候， 播放进度的改变 按钮图标的改变
playerViewModel?.maxSeekDuration.set(playingMusic.duration) // 总时长
playerViewModel?.currentSeekPosition.set(playingMusic.playerPosition) // 拖动条
})
// 播放/暂停是一个控件 图标的 true 和 false
PlayerManager.instance.pauseLiveData.observe(viewLifecycleOwner, { aBoolean ->
// 播放时显示暂停，暂停时显示播放
aBoolean?.let {
playerViewModel?.isPlaying.set(!it)
}
})
// 列表循环，单曲循环，随机播放 模式
PlayerManager.instance.playModeLiveData.observe(viewLifecycleOwner, { anEnum ->
val resultID = if (anEnum === PlayingInfoManager.RepeatMode.LIST_LOOP) {
// 列表循环
playerViewModel?.playModeIcon.set(MaterialDrawableBuilder.IconValue.REPEAT)
R.string.play_repeat
} else if (anEnum === PlayingInfoManager.RepeatMode.ONE_LOOP) {
// 单曲循环
playerViewModel?.playModeIcon.set(MaterialDrawableBuilder.IconValue.REPEAT_ONCE)
R.string.play_repeat_once
} else {
// 随机循环
playerViewModel?.playModeIcon.set(MaterialDrawableBuilder.IconValue.SHUFFLE)
R.string.play_shuffle
}
// 提示改变
if (view.parent.parent is SlidingUpPanelLayout) {
val sliding = view.parent.parent as SlidingUpPanelLayout
// 展开状态
if (sliding.panelState == SlidingUpPanelLayout.PanelState.EXPANDED) {
// 弹出："列表循环" or "单曲循环" or "随机播放"，这里可以进行各种扩展
showShortToast(resultID)
}
}
})
// 可以控制 播放详情 点击 back 收起
sharedViewModel.closeSlidePanelIfExpanded.observe(viewLifecycleOwner, {
if (view.parent.parent is SlidingUpPanelLayout) {
val sliding = view.parent.parent as SlidingUpPanelLayout
// 如果是扩大，也就是，详情页面展示出来的
if (sliding.panelState == SlidingUpPanelLayout.PanelState.EXPANDED) {
// 缩小了（掉下来了）
sliding.panelState = SlidingUpPanelLayout.PanelState.COLLAPSED
// 活动关闭的一些记录（播放条 缩小一条 与 扩大展开）
sharedViewModel.activityCanBeClosedDirectly.setValue(true)
} else {
// 活动关闭的一些记录（播放条 缩小一条 与 扩大展开）
sharedViewModel.activityCanBeClosedDirectly.setValue(false)
}
} else {
// 活动关闭的一些记录（播放条 缩小一条 与 扩大展开）
sharedViewModel.activityCanBeClosedDirectly.setValue(false)
}
})
}
/**
* 当我们点击的时候，触发
*/
inner class ClickProxy {
// 上一首
fun previous() = PlayerManager.instance.playPrevious()
// 下一首
operator fun next() = PlayerManager.instance.playNext()
// 左手边的滑落，点击缩小的，可以控制播放详情点击 back 掉下来
fun slideDown() = sharedViewModel.closeSlidePanelIfExpanded.setValue(true)
// 更多的
fun more() = Toast.makeText(mActivity, "你能不能不要乱点", Toast.LENGTH_SHORT).show()
// 切换播放状态
fun togglePlay() = PlayerManager.instance.togglePlay()
// 播放
fun playMode() = PlayerManager.instance.changeMode()
// 提示
fun showPlayList() = showShortToast("最近播放的细节，我没有搞...")
}
// 内部类的好处，方便获取当前 Fragment 的环境
/**
* 更新 拖动条进度相关
*/
inner class EventHandler : SeekBar.OnSeekBarChangeListener {
override fun onProgressChanged(seekBar: SeekBar, progress: Int, fromUser: Boolean) {}
override fun onStartTrackingTouch(seekBar: SeekBar) {}
// 一拖动松开手把当前进度值通知给 PlayerManager
override fun onStopTrackingTouch(seekBar: SeekBar) = PlayerManager.instance.setSeek(seekBar.progress)
}
}fragment_player.xml
接下来，我们开始 PlayerFragment 的布局编写，依然使用 DataBinding 来完成编写；
ini
<layout
xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:app="http://schemas.android.com/apk/res-auto"
xmlns:playpauseview="http://schemas.android.com/apk/res-auto"
xmlns:tools="http://schemas.android.com/tools">
<data>
<!-- 点击的时候触发 -->
<variable
name="click"
type="com.llc.puremusic.ui.page.PlayerFragment.ClickProxy" />
<!-- 更新拖动条进度相关 -->
<variable
name="event"
type="com.llc.puremusic.ui.page.PlayerFragment.EventHandler" />
<!-- 底部播放条的 ViewModel -->
<variable
name="vm"
type="com.llc.puremusic.bridge.state.PlayerViewModel" />
</data>
<androidx.coordinatorlayout.widget.CoordinatorLayout
android:id="@+id/topContainer"
android:layout_width="match_parent"
android:layout_height="match_parent"
android:layout_gravity="top">
<!-- 看起来是 "播放条" 实际上责任很大，非常重要，管控了整个 -->
<com.llc.puremusic.ui.view.ForegroundImageView
android:id="@+id/album_art"
imageUrl="@{vm.coverImg}"
placeHolder="@{vm.placeHolder}"
android:layout_width="@dimen/sliding_up_header"
android:layout_height="@dimen/sliding_up_header"
android:scaleType="centerCrop"
android:src="@drawable/bg_album_default"
android:visibility="visible"/>
<!-- 下面的都属于播放详情了 -->
<RelativeLayout
android:id="@+id/custom_toolbar"
android:layout_width="match_parent"
android:layout_height="?attr/actionBarSize"
android:layout_gravity="top"
android:layout_marginTop="37dp"
android:orientation="horizontal"
android:visibility="invisible">
<!-- 左手边的滑落 -->
<net.steamcrafted.materialiconlib.MaterialIconView
android:id="@+id/btn_close"
android:layout_width="36dp"
android:layout_height="36dp"
android:layout_alignParentStart="true"
android:layout_centerVertical="true"
android:layout_marginStart="16dp"
android:background="?attr/selectableItemBackgroundBorderless"
android:onClick="@{()->click.slideDown()}"
android:scaleType="center"
app:materialIcon="chevron_down"
app:materialIconColor="@color/white"
app:materialIconSize="28dp"
android:visibility="visible"/>
<!-- 右手边的更多 -->
<net.steamcrafted.materialiconlib.MaterialIconView
android:id="@+id/popup_menu"
android:layout_width="36dp"
android:layout_height="36dp"
android:layout_alignParentEnd="true"
android:layout_centerVertical="true"
android:layout_marginEnd="16dp"
android:background="?attr/selectableItemBackgroundBorderless"
android:onClick="@{()->click.more()}"
android:scaleType="center"
app:materialIcon="dots_vertical"
app:materialIconColor="@color/white"
app:materialIconSize="28dp"
android:visibility="visible"/>
</RelativeLayout>
<!-- 歌词控件 -->
<com.llc.puremusic.ui.view.LyricView
android:id="@+id/lyric_view"
android:layout_width="match_parent"
android:layout_height="32dp"
android:visibility="gone" />
<!-- 歌手，描述，暂无歌词 等信息 -->
<LinearLayout
android:id="@+id/summary"
android:layout_width="match_parent"
android:layout_height="@dimen/sliding_up_header"
android:layout_gravity="top"
android:layout_marginStart="@dimen/sliding_up_header"
android:orientation="vertical">
<ProgressBar
android:id="@+id/song_progress_normal"
style="@style/Widget.AppCompat.ProgressBar.Horizontal"
android:layout_width="match_parent"
android:layout_height="wrap_content"
android:layout_gravity="top"
android:max="@{vm.maxSeekDuration}"
android:minHeight="4dp"
android:progress="@{vm.currentSeekPosition}"
android:progressDrawable="@drawable/progressbar_color"
android:progressTint="?colorAccent" />
<TextView
android:id="@+id/title"
style="@style/TextAppearance.AppCompat.Body1"
android:layout_width="wrap_content"
android:layout_height="wrap_content"
android:layout_marginStart="12dp"
android:layout_marginEnd="42dp"
android:ellipsize="end"
android:maxLines="1"
android:text="@{vm.title}"
android:textSize="16sp"
tools:text="title" />
<TextView
android:id="@+id/artist"
style="@style/TextAppearance.AppCompat.Widget.ActionMode.Subtitle"
android:layout_width="wrap_content"
android:layout_height="wrap_content"
android:layout_marginStart="12dp"
android:ellipsize="end"
android:maxLength="20"
android:maxLines="1"
android:text="@{vm.artist}"
android:textColor="?android:textColorSecondary"
android:textSize="14sp"
tools:text="artist" />
</LinearLayout>
<!-- 五个控件 -->
<RelativeLayout
android:id="@+id/icon_container"
android:layout_width="match_parent"
android:layout_height="wrap_content"
android:layout_gravity="top"
android:layout_marginTop="10dp">
<net.steamcrafted.materialiconlib.MaterialIconView
android:id="@+id/next"
android:layout_width="36dp"
android:layout_height="36dp"
android:layout_alignParentEnd="true"
android:layout_marginEnd="16dp"
android:background="?attr/selectableItemBackgroundBorderless"
android:onClick="@{()->click.next()}"
android:scaleType="center"
app:materialIcon="skip_next"
app:materialIconColor="@android:color/black"
app:materialIconSize="28dp" />
<com.llc.puremusic.ui.view.PlayPauseView
android:id="@+id/play_pause"
isPlaying="@{vm.isPlaying}"
android:layout_width="36dp"
android:layout_height="36dp"
android:layout_marginEnd="16dp"
android:layout_toStartOf="@id/next"
android:clickable="true"
android:focusable="true"
android:foreground="?attr/selectableItemBackground"
android:onClick="@{()->click.togglePlay()}"
playpauseview:circleAlpha="0"
playpauseview:isCircleDraw="true" />
<net.steamcrafted.materialiconlib.MaterialIconView
android:id="@+id/previous"
android:layout_width="36dp"
android:layout_height="36dp"
android:layout_alignParentTop="true"
android:layout_marginEnd="16dp"
android:layout_toStartOf="@+id/play_pause"
android:alpha="0"
android:background="?attr/selectableItemBackgroundBorderless"
android:onClick="@{()->click.previous()}"
android:scaleType="center"
app:materialIcon="skip_previous"
app:materialIconColor="@android:color/black"
app:materialIconSize="28dp" />
<net.steamcrafted.materialiconlib.MaterialIconView
android:id="@+id/mark"
mdIcon="@{vm.playModeIcon}"
android:layout_width="36dp"
android:layout_height="36dp"
android:layout_marginEnd="16dp"
android:layout_toStartOf="@id/previous"
android:alpha="0"
android:background="?attr/selectableItemBackgroundBorderless"
android:onClick="@{()->click.playMode()}"
android:scaleType="center"
app:materialIconColor="@android:color/black"
app:materialIconSize="28dp" />
<net.steamcrafted.materialiconlib.MaterialIconView
android:id="@+id/ic_play_list"
android:layout_width="36dp"
android:layout_height="36dp"
android:layout_marginStart="16dp"
android:layout_toEndOf="@id/next"
android:background="?attr/selectableItemBackgroundBorderless"
android:onClick="@{()->click.showPlayList()}"
android:scaleType="center"
app:materialIcon="playlist_play"
app:materialIconColor="@android:color/black"
app:materialIconSize="28dp" />
</RelativeLayout>
<!-- 拖动条 -->
<SeekBar
android:id="@+id/seek_bottom"
android:layout_width="match_parent"
android:layout_height="wrap_content"
android:layout_gravity="bottom"
android:background="@color/transparent"
android:clickable="true"
android:focusable="true"
android:max="@{vm.maxSeekDuration}"
android:minHeight="6dp"
android:paddingTop="24dp"
android:progress="@{vm.currentSeekPosition}"
android:progressDrawable="@drawable/progressbar_color"
android:thumb="@null"
android:visibility="visible"
app:onSeekBarChangeListener="@{event}" />
</androidx.coordinatorlayout.widget.CoordinatorLayout>
</layout>这里又涉及到了几个 BindingAdapter，一个是 isPlaying：
一个是 mdIcon：
我们来完善下这两个 BindingAdapter
kotlin
object IconBindingAdapter {
// 调用播放暂停功能
@JvmStatic
@BindingAdapter(value = ["isPlaying"], requireAll = false)
fun isPlaying(pauseView: PlayPauseView, isPlaying: Boolean) {
if (isPlaying) {
pauseView.play()
} else {
pauseView.pause()
}
}
@JvmStatic
@BindingAdapter(value = ["mdIcon"], requireAll = false)
fun setIcon(view: MaterialIconView, iconValue: IconValue?) {
view.setIcon(iconValue)
}
}还有一个是 imageUrl 和 placeHolder
less
object CommonBindingAdapter {
@JvmStatic
@BindingAdapter(value = ["imageUrl", "placeHolder"], requireAll = false)
fun loadUrl(view: ImageView, url: String?, placeHolder: Drawable?) {
Glide.with(view.context).load(url).placeholder(placeHolder).into(view)
}
}然后，我们在 Application 中初始化 PlayerManager
kotlin
class App : Application(), ViewModelStoreOwner {
override fun onCreate() {
super.onCreate()
// 这里必须初始化一下，是为了保证播放音乐管理类（PlayerManager.java） 不会为null，从而不引发空指针异常
PlayerManager.instance.init(this)
}
}
好了，播放能力就讲到这里吧~
欢迎三连
来都来了，点个关注，点个赞吧，你的支持是我最大的动力~
