Python 工具: Windows 带宽监控工具
-
- 环境
- 介绍
- [系统流量采集:用 psutil 获取网络数据](#系统流量采集:用 psutil 获取网络数据)
- [Flask Web框架:搭建后端服务](#Flask Web框架:搭建后端服务)
- 前端部分
-
- 交互逻辑(JavaScript)
-
- [1. fetch():异步请求后端数据](#1. fetch():异步请求后端数据)
- [2. Chart.js:绘制实时图表](#2. Chart.js:绘制实时图表)
- [3. 定时更新:setInterval()](#3. 定时更新:setInterval())
- [4. 辅助函数:格式转换](#4. 辅助函数:格式转换)
- 完整代码
-
-
- [完整 index 代码:](#完整 index 代码:)
- 完整后端代码
-
环境
Python 3.12.2
psutil 版本: 7.0.0
Flask 版本: 3.1.2
matplotlib 版本: 3.10.6
pip 安装指定版本
bash
pip install psutil==7.0.0 flask==3.1.2 matplotlib==3.10.6
介绍
做一个适用于 windows 的带宽监控工具,这个工具融合了Python后端开发、多线程、系统信息采集、Web框架、前端可视化等多个技术领域。
源码可以看开源地址:
bash
https://gitee.com/daolizhe/python_tool/tree/master/Windows%E5%B8%A6%E5%AE%BD%E7%9B%91%E6%8E%A7%E5%B7%A5%E5%85%B7

会使用的库
库名 | 核心作用 | 代码中的应用场景 |
---|---|---|
threading | 实现多线程编程,让程序"同时做多个任务" | 创建TrafficMonitor监控线程,与FlaskWeb服务并行运行 |
time | 提供时间相关功能(延迟、时间戳等) | time.sleep(1)实现每秒采集一次流量数据 |
datetime | 处理日期和时间,提供更丰富的时间格式 | 记录流量数据对应的时间戳(如datetime.now()) |
collections.deque | 双端队列,支持固定长度(自动丢弃旧数据) | 存储最近5分钟的流量数据(maxlen=300,每秒1条共300秒) |
io | 内存中的输入输出流,模拟文件操作 | 存储Matplotlib生成的图表(避免写入本地文件) |
base64 | 将二进制数据编码为文本格式 | 把图表二进制数据转为base64,方便前端HTML显示 |
json | 处理JSON数据(Python字典与JSON字符串互转) | 生成JSON格式的流量报告,供前端下载 |
os | 与操作系统交互(本代码中未实际使用,预留扩展) | 可用于获取系统信息、管理文件路径等 |
多线程关键代码:
python
class TrafficMonitor(threading.Thread):
def __init__(self, interface_name=None):
super().__init__() # 调用父类构造函数
self.daemon = True # 设置为守护线程
self.running = True # 控制线程循环的开关
def run(self):
# 1. 自动选择网络接口(优先非回环接口,且有发送数据的接口)
# 2. 初始化上次流量统计值(用于计算每秒增量)
# 3. 循环采集数据:
while self.running:
current_stats = psutil.net_io_counters(pernic=True)[self.interface_name]
incoming_rate = current_stats.bytes_recv - self.last_incoming # 每秒入站流量
outgoing_rate = current_stats.bytes_sent - self.last_outgoing # 每秒出站流量
# 更新全局变量(供Web端调用)
traffic_data['incoming'].append(incoming_rate)
time.sleep(1) # 每秒采集一次
def stop(self):
self.running = False # 关闭循环,线程退出
系统流量采集:用 psutil 获取网络数据
概念:网络流量的"增量"与"总量"
- 总量(bytes_recv/bytes_sent):从系统启动到当前,网络接口接收/发送的总字节数(不会重置)。
- 增量(每秒流量):当前总量 - 上次总量,即每秒的实际流量(如"100KB/s")。
代码中的流量采集逻辑
- 选择网络接口:
若未指定接口(如TrafficMonitor()),代码会自动遍历所有接口,排除回环接口(lo,本地测试用),选择有数据发送的接口(bytes_sent > 0)。 - 初始化上次总量:
self.last_incoming = interfaces[self.interface_name].bytes_recv,记录初始总量。 - 计算每秒增量:
每次循环中,用当前总量减去上次总量,得到每秒流量(如incoming_rate),再更新上次总量。 - 存储数据:
将每秒流量和对应的时间戳存入全局变量traffic_data(deque类型,自动保留最近300条)。
Flask Web框架:搭建后端服务
Flask是轻量级Web框架,
这部分有不明白的看下面链接地址
bash
https://blog.csdn.net/qq_36051316/article/details/136024400
前端部分
交互逻辑(JavaScript)
前端的核心是"实时获取后端数据并更新页面",主要通过以下函数实现:
1. fetch():异步请求后端数据
fetch('/traffic-data')会向后端/traffic-data路由发送请求,获取JSON格式的流量数据,再用这些数据更新图表。
2. Chart.js:绘制实时图表
Chart.js是轻量级前端绘图库,代码中用它绘制入站/出站流量曲线:
- 初始化图表:指定canvas元素、图表类型(line折线图)、初始数据(空)、坐标轴配置。
- 更新图表:每次fetch到新数据后,修改chart.data.labels(时间戳)和chart.data.datasets(流量数据),再调用chart.update()刷新图表。
3. 定时更新:setInterval()
用setInterval实现周期性更新:
- setInterval(updateChart, 1000):每秒更新一次图表(与后端采集频率一致)。
- setInterval(updateTotalStats, 5000):每5秒更新一次总流量(总流量变化较慢,无需频繁更新)。
4. 辅助函数:格式转换
- formatBytes():将字节数(如102400)转为易读格式(如100 KB),支持B/KB/MB/GB/TB。
- formatBytesPerSec():在formatBytes()基础上添加/s,如100 KB/s。
完整代码
完整 index 代码:
bash
<!DOCTYPE html>
<html>
<head>
<title>Windows带宽监控</title>
<script src="https://cdn.jsdelivr.net/npm/chart.js"></script>
<style>
body { font-family: Arial, sans-serif; margin: 20px; background-color: #f5f5f5; }
.container { max-width: 1200px; margin: 0 auto; background: white; padding: 20px; border-radius: 8px; box-shadow: 0 2px 4px rgba(0,0,0,0.1); }
.header { text-align: center; margin-bottom: 20px; }
.stats-container { display: flex; justify-content: space-around; margin-bottom: 20px; }
.stat-card { background: #f0f0f0; padding: 15px; border-radius: 5px; text-align: center; min-width: 200px; }
.stat-value { font-size: 24px; font-weight: bold; }
.chart-container { position: relative; height: 400px; margin-bottom: 20px; }
.controls { margin-bottom: 20px; text-align: center; }
button { background: #4CAF50; color: white; border: none; padding: 10px 15px; border-radius: 4px; cursor: pointer; }
button:hover { background: #45a049; }
</style>
</head>
<body>
<div class="container">
<div class="header">
<h1>Windows带宽监控工具</h1>
<p>实时监控网络接口流量</p>
</div>
<div class="stats-container">
<div class="stat-card">
<div class="stat-title">当前入站流量</div>
<div class="stat-value" id="current-in">0 B/s</div>
</div>
<div class="stat-card">
<div class="stat-title">当前出站流量</div>
<div class="stat-value" id="current-out">0 B/s</div>
</div>
<div class="stat-card">
<div class="stat-title">总入站流量</div>
<div class="stat-value" id="total-in">0 MB</div>
</div>
<div class="stat-card">
<div class="stat-title">总出站流量</div>
<div class="stat-value" id="total-out">0 MB</div>
</div>
</div>
<div class="controls">
<button onclick="downloadReport()">下载报表</button>
<button onclick="changeView('minute')">最近1分钟</button>
<button onclick="changeView('hour')">最近1小时</button>
<button onclick="changeView('day')">最近24小时</button>
</div>
<div class="chart-container">
<canvas id="trafficChart"></canvas>
</div>
<div id="report"></div>
</div>
<script>
// 创建图表
const ctx = document.getElementById('trafficChart').getContext('2d');
const chart = new Chart(ctx, {
type: 'line',
data: {
labels: [],
datasets: [
{
label: '入站流量 (KB/s)',
data: [],
borderColor: 'rgba(75, 192, 192, 1)',
backgroundColor: 'rgba(75, 192, 192, 0.2)',
fill: true,
tension: 0.4
},
{
label: '出站流量 (KB/s)',
data: [],
borderColor: 'rgba(255, 99, 132, 1)',
backgroundColor: 'rgba(255, 99, 132, 0.2)',
fill: true,
tension: 0.4
}
]
},
options: {
responsive: true,
maintainAspectRatio: false,
scales: {
y: {
beginAtZero: true,
title: {
display: true,
text: '流量 (KB/秒)'
}
},
x: {
title: {
display: true,
text: '时间'
}
}
},
plugins: {
legend: {
position: 'top',
},
title: {
display: true,
text: '网络流量监控'
}
}
}
});
// 格式化字节大小为易读格式
function formatBytes(bytes, decimals = 2) {
if (bytes === 0) return '0 B';
const k = 1024;
const dm = decimals < 0 ? 0 : decimals;
const sizes = ['B', 'KB', 'MB', 'GB', 'TB'];
const i = Math.floor(Math.log(bytes) / Math.log(k));
return parseFloat((bytes / Math.pow(k, i)).toFixed(dm)) + ' ' + sizes[i];
}
// 格式化字节/秒为易读格式
function formatBytesPerSec(bytes, decimals = 2) {
return formatBytes(bytes, decimals) + '/s';
}
// 更新图表数据
function updateChart() {
fetch('/traffic-data')
.then(response => response.json())
.then(data => {
// 转换数据为KB/s
const incomingKB = data.incoming.map(value => (value / 1024).toFixed(2));
const outgoingKB = data.outgoing.map(value => (value / 1024).toFixed(2));
chart.data.labels = data.timestamps;
chart.data.datasets[0].data = incomingKB;
chart.data.datasets[1].data = outgoingKB;
chart.update();
// 更新当前流量显示
if (incomingKB.length > 0) {
const currentIn = incomingKB[incomingKB.length - 1];
document.getElementById('current-in').textContent = formatBytesPerSec(currentIn * 1024);
}
if (outgoingKB.length > 0) {
const currentOut = outgoingKB[outgoingKB.length - 1];
document.getElementById('current-out').textContent = formatBytesPerSec(currentOut * 1024);
}
});
}
// 更新总流量统计
function updateTotalStats() {
fetch('/total-traffic')
.then(response => response.json())
.then(data => {
document.getElementById('total-in').textContent = formatBytes(data.total_incoming);
document.getElementById('total-out').textContent = formatBytes(data.total_outgoing);
});
}
// 更新报告
function updateReport() {
fetch('/report')
.then(response => response.text())
.then(data => {
document.getElementById('report').innerHTML = data;
});
}
// 下载报表
function downloadReport() {
fetch('/download-report')
.then(response => response.blob())
.then(blob => {
const url = window.URL.createObjectURL(blob);
const a = document.createElement('a');
a.style.display = 'none';
a.href = url;
a.download = 'bandwidth_report.json';
document.body.appendChild(a);
a.click();
window.URL.revokeObjectURL(url);
});
}
// 切换视图
function changeView(range) {
fetch('/change-view?range=' + range)
.then(response => response.json())
.then(data => {
// 重新加载页面数据
updateChart();
updateReport();
});
}
// 初始加载
updateChart();
updateTotalStats();
updateReport();
// 定时更新
setInterval(updateChart, 1000);
setInterval(updateTotalStats, 5000);
setInterval(updateReport, 10000);
</script>
</body>
</html>
完整后端代码
bash
import threading
import time
import psutil
from datetime import datetime
from collections import deque
import matplotlib.pyplot as plt
import matplotlib.dates as mdates
from flask import Flask, render_template, jsonify, request
import io
import base64
import json
import os
app = Flask(__name__)
# 全局变量存储流量数据
traffic_data = {
'incoming': deque(maxlen=300), # 存储最近5分钟的入站流量(每秒一个数据点)
'outgoing': deque(maxlen=300), # 存储最近5分钟的出站流量
'timestamps': deque(maxlen=300) # 存储对应的时间戳
}
# 流量统计类
class TrafficMonitor(threading.Thread):
def __init__(self, interface_name=None):
super().__init__()
self.daemon = True
self.last_incoming = 0
self.last_outgoing = 0
self.interface_name = interface_name
self.running = True
def run(self):
print("开始监控网络流量...")
# 获取网络接口
interfaces = psutil.net_io_counters(pernic=True)
# 如果没有指定接口,使用第一个活动接口
if not self.interface_name:
for name in interfaces:
if name != 'lo' and interfaces[name].bytes_sent > 0:
self.interface_name = name
break
if not self.interface_name:
print("未找到可用的网络接口")
return
print(f"监控接口: {self.interface_name}")
# 初始化计数器
self.last_incoming = interfaces[self.interface_name].bytes_recv
self.last_outgoing = interfaces[self.interface_name].bytes_sent
# 开始监控循环
while self.running:
try:
# 获取当前流量统计
current_stats = psutil.net_io_counters(pernic=True)[self.interface_name]
current_incoming = current_stats.bytes_recv
current_outgoing = current_stats.bytes_sent
# 计算每秒流量
incoming_rate = current_incoming - self.last_incoming
outgoing_rate = current_outgoing - self.last_outgoing
# 更新计数器
self.last_incoming = current_incoming
self.last_outgoing = current_outgoing
# 更新全局流量数据
now = datetime.now()
traffic_data['timestamps'].append(now)
traffic_data['incoming'].append(incoming_rate)
traffic_data['outgoing'].append(outgoing_rate)
# 每秒更新一次
time.sleep(1)
except Exception as e:
print(f"监控出错: {e}")
time.sleep(5)
def stop(self):
self.running = False
# 创建并启动流量监控线程
monitor = TrafficMonitor()
# Flask路由
@app.route('/')
def index():
return render_template('index.html')
@app.route('/traffic-data')
def get_traffic_data():
# 返回JSON格式的流量数据
data = {
'timestamps': [ts.strftime('%H:%M:%S') for ts in traffic_data['timestamps']],
'incoming': list(traffic_data['incoming']),
'outgoing': list(traffic_data['outgoing'])
}
return jsonify(data)
@app.route('/total-traffic')
def get_total_traffic():
# 获取总流量统计
interfaces = psutil.net_io_counters(pernic=True)
interface_name = monitor.interface_name
total_incoming = interfaces[interface_name].bytes_recv if interface_name in interfaces else 0
total_outgoing = interfaces[interface_name].bytes_sent if interface_name in interfaces else 0
return jsonify({
'total_incoming': total_incoming,
'total_outgoing': total_outgoing
})
@app.route('/traffic-plot')
def get_traffic_plot():
# 生成流量图表并返回base64编码的图像
if not traffic_data['timestamps']:
return "暂无数据"
plt.figure(figsize=(10, 6))
# 转换数据为KB/s
incoming_kb = [x / 1024 for x in traffic_data['incoming']]
outgoing_kb = [x / 1024 for x in traffic_data['outgoing']]
plt.plot(traffic_data['timestamps'], incoming_kb, label='入站流量 (KB/s)')
plt.plot(traffic_data['timestamps'], outgoing_kb, label='出站流量 (KB/s)')
# 格式化图表
plt.xlabel('时间')
plt.ylabel('流量 (KB/秒)')
plt.title('实时网络流量监控')
plt.legend()
plt.grid(True)
plt.gcf().autofmt_xdate()
plt.gca().xaxis.set_major_formatter(mdates.DateFormatter('%H:%M:%S'))
# 将图表转换为base64编码
img = io.BytesIO()
plt.savefig(img, format='png')
img.seek(0)
plot_url = base64.b64encode(img.getvalue()).decode()
plt.close()
@app.route('/report')
def generate_report():
# 生成带宽使用报告
if not traffic_data['timestamps']:
return "<p>暂无数据可生成报告</p>"
# 计算统计信息
total_in = sum(traffic_data['incoming'])
total_out = sum(traffic_data['outgoing'])
avg_in = total_in / len(traffic_data['incoming'])
avg_out = total_out / len(traffic_data['outgoing'])
max_in = max(traffic_data['incoming'])
max_out = max(traffic_data['outgoing'])
# 转换为更友好的单位
def format_bytes(bytes):
for unit in ['B', 'KB', 'MB', 'GB']:
if bytes < 1024.0:
return f"{bytes:.2f} {unit}"
bytes /= 1024.0
return f"{bytes:.2f} TB"
def format_bps(bytes_per_sec):
return format_bytes(bytes_per_sec) + "/s"
report = f"""
<h2>带宽使用报告</h2>
<p>统计时间段: {traffic_data['timestamps'][0]} 到 {traffic_data['timestamps'][-1]}</p>
<p>监控时长: {len(traffic_data['timestamps'])} 秒</p>
<p>总入站流量: {format_bytes(total_in)}</p>
<p>总出站流量: {format_bytes(total_out)}</p>
<p>平均入站速率: {format_bps(avg_in)}</p>
<p>平均出站速率: {format_bps(avg_out)}</p>
<p>最大入站速率: {format_bps(max_in)}</p>
<p>最大出站速率: {format_bps(max_out)}</p>
"""
return report
@app.route('/download-report')
def download_report():
# 生成并下载JSON格式的详细报告
if not traffic_data['timestamps']:
return "暂无数据", 404
# 准备报告数据
report_data = {
"generated_at": datetime.now().isoformat(),
"time_period": {
"start": traffic_data['timestamps'][0].isoformat() if traffic_data['timestamps'] else None,
"end": traffic_data['timestamps'][-1].isoformat() if traffic_data['timestamps'] else None,
"duration_seconds": len(traffic_data['timestamps'])
},
"traffic_data": {
"timestamps": [ts.isoformat() for ts in traffic_data['timestamps']],
"incoming_bytes_per_sec": list(traffic_data['incoming']),
"outgoing_bytes_per_sec": list(traffic_data['outgoing'])
},
"statistics": {
"total_incoming_bytes": sum(traffic_data['incoming']),
"total_outgoing_bytes": sum(traffic_data['outgoing']),
"avg_incoming_bytes_per_sec": sum(traffic_data['incoming']) / len(traffic_data['incoming']),
"avg_outgoing_bytes_per_sec": sum(traffic_data['outgoing']) / len(traffic_data['outgoing']),
"max_incoming_bytes_per_sec": max(traffic_data['incoming']) if traffic_data['incoming'] else 0,
"max_outgoing_bytes_per_sec": max(traffic_data['outgoing']) if traffic_data['outgoing'] else 0
}
}
# 转换为JSON字符串
report_json = json.dumps(report_data, indent=2)
# 创建响应
from flask import Response
response = Response(
report_json,
mimetype="application/json",
headers={"Content-Disposition": "attachment;filename=bandwidth_report.json"}
)
return response
@app.route('/change-view')
def change_view():
# 改变数据视图范围
range = request.args.get('range', 'minute')
# 根据范围调整数据保留数量
if range == 'minute':
new_maxlen = 60 # 1分钟
elif range == 'hour':
new_maxlen = 3600 # 1小时
elif range == 'day':
new_maxlen = 86400 # 24小时
else:
new_maxlen = 300 # 默认5分钟
# 创建新的deque并复制现有数据
def resize_deque(old_deque, new_maxlen):
new_deque = deque(maxlen=new_maxlen)
for item in old_deque:
new_deque.append(item)
return new_deque
traffic_data['incoming'] = resize_deque(traffic_data['incoming'], new_maxlen)
traffic_data['outgoing'] = resize_deque(traffic_data['outgoing'], new_maxlen)
traffic_data['timestamps'] = resize_deque(traffic_data['timestamps'], new_maxlen)
return jsonify({"status": "success", "new_maxlen": new_maxlen})
if __name__ == '__main__':
# 启动流量监控线程
monitor.start()
# 启动Flask应用
print("启动带宽监控Web界面...")
print("请访问 http://localhost:5000")
app.run(debug=True, host='0.0.0.0', port=5000, use_reloader=False)
