springboot+vue 如何实现海康摄像头喊话功能

我来为您介绍在SpringBoot + Vue项目中实现海康摄像头喊话功能的完整方案：

一、技术架构

前端(Vue) → 后端(SpringBoot) → 海康SDK/ISAPI → 海康摄像头

二、后端实现（SpringBoot）

1. 添加依赖

<!-- 可选：WebSocket支持实时语音流 -->
<dependency>
    <groupId>org.springframework.boot</groupId>
    <artifactId>spring-boot-starter-websocket</artifactId>
</dependency>

2. 海康SDK集成（基于HCNetSDK）

VoiceBroadcastService.java

@Service
public class VoiceBroadcastService {

    // 加载海康SDK
    static {
        System.loadLibrary("hcnetsdk");
        System.loadLibrary("PlayCtrl");
        System.loadLibrary("HCNetSDK");
    }

    public boolean startBroadcast(String cameraIp, String text) {
        HCNetSDK hCNetSDK = HCNetSDK.INSTANCE;
        IntByReference loginHandle = new IntByReference(0);

        // 1. 登录设备
        HCNetSDK.NET_DVR_DEVICEINFO_V30 deviceInfo = new HCNetSDK.NET_DVR_DEVICEINFO_V30();
        loginHandle.setValue(hCNetSDK.NET_DVR_Login_V30(
            cameraIp, (short)8000, "admin", "password",
            deviceInfo, null
        ));

        if (loginHandle.getValue() < 0) {
            return false;
        }

        try {
            // 2. 开启语音对讲
            HCNetSDK.NET_DVR_VOICECOM_START voiceStart = new HCNetSDK.NET_DVR_VOICECOM_START();
            voiceStart.dwSize = voiceStart.size();
            voiceStart.dwVoiceChan = 1; // 通道号
            voiceStart.byVoiceMode = 0; // 0-客户端发起

            int voiceHandle = hCNetSDK.NET_DVR_StartVoiceCom_V30(
                loginHandle.getValue(), voiceStart, null, null
            );

            if (voiceHandle < 0) {
                return false;
            }

            // 3. 发送语音数据（这里需要音频输入）
            // 实际实现需要从麦克风获取音频流

            // 4. 停止对讲
            hCNetSDK.NET_DVR_StopVoiceCom(voiceHandle);

            return true;
        } finally {
            // 5. 注销登录
            hCNetSDK.NET_DVR_Logout(loginHandle.getValue());
        }
    }
}

3. 基于ISAPI的文本转语音方案（推荐）

HikvisionISAPIService.java

@Service
public class HikvisionISAPIService {

    @Value("${hikvision.username}")
    private String username;

    @Value("${hikvision.password}")
    private String password;

    /**
     * 文本转语音广播
     */
    public boolean textToSpeech(String cameraIp, String text) {
        String url = String.format("http://%s/ISAPI/System/Audio/channels/1/audioData", cameraIp);

        try {
            // 1. 构建语音数据（需要将文本转为G.711/G.726等格式）
            byte[] audioData = convertTextToAudio(text);

            // 2. 发送HTTP PUT请求
            HttpHeaders headers = new HttpHeaders();
            headers.setBasicAuth(username, password);
            headers.setContentType(MediaType.APPLICATION_OCTET_STREAM);

            HttpEntity<byte[]> entity = new HttpEntity<>(audioData, headers);
            RestTemplate restTemplate = new RestTemplate();

            ResponseEntity<String> response = restTemplate.exchange(
                url, HttpMethod.PUT, entity, String.class
            );

            return response.getStatusCode() == HttpStatus.OK;
        } catch (Exception e) {
            e.printStackTrace();
            return false;
        }
    }

    /**
     * 获取音频通道信息
     */
    public String getAudioChannels(String cameraIp) {
        String url = String.format("http://%s/ISAPI/System/Audio/channels", cameraIp);

        try {
            RestTemplate restTemplate = new RestTemplate();
            HttpHeaders headers = new HttpHeaders();
            headers.setBasicAuth(username, password);

            HttpEntity<String> entity = new HttpEntity<>(headers);
            ResponseEntity<String> response = restTemplate.exchange(
                url, HttpMethod.GET, entity, String.class
            );

            return response.getBody();
        } catch (Exception e) {
            return null;
        }
    }
}

4. WebSocket实现实时语音流

WebSocketConfig.java

@Configuration
@EnableWebSocket
public class WebSocketConfig implements WebSocketConfigurer {

    @Override
    public void registerWebSocketHandlers(WebSocketHandlerRegistry registry) {
        registry.addHandler(voiceHandler(), "/voice")
                .setAllowedOrigins("*");
    }

    @Bean
    public WebSocketHandler voiceHandler() {
        return new VoiceWebSocketHandler();
    }
}

VoiceWebSocketHandler.java

@Component
public class VoiceWebSocketHandler extends BinaryWebSocketHandler {

    @Autowired
    private VoiceBroadcastService voiceService;

    @Override
    protected void handleBinaryMessage(WebSocketSession session, BinaryMessage message) {
        // 接收前端发送的音频流，转发给摄像头
        ByteBuffer payload = message.getPayload();
        byte[] audioData = new byte[payload.remaining()];
        payload.get(audioData);

        // 这里实现将音频流发送给摄像头
        voiceService.sendAudioToCamera(audioData);
    }
}

三、前端实现（Vue3 + TypeScript）

1. 音频录制组件

VoiceBroadcast.vue

<template>
  <div class="voice-broadcast">
    <!-- 文本喊话 -->
    <div v-if="mode === 'text'">
      <el-input
        v-model="textMessage"
        type="textarea"
        placeholder="输入要喊话的内容"
        :rows="4"
      />
      <el-button @click="sendText" :loading="loading">
        发送喊话
      </el-button>
    </div>

    <!-- 实时语音 -->
    <div v-else>
      <el-button
        @mousedown="startRecording"
        @mouseup="stopRecording"
        :disabled="recording"
        type="primary"
        size="large"
      >
        🎤 {{ recording ? '正在喊话...' : '按住说话' }}
      </el-button>

      <div v-if="recordingTime > 0" class="recording-indicator">
        录音时长: {{ recordingTime }}秒
      </div>
    </div>

    <!-- 模式切换 -->
    <div class="mode-switch">
      <el-radio-group v-model="mode" size="small">
        <el-radio-button label="text">文本喊话</el-radio-button>
        <el-radio-button label="voice">实时语音</el-radio-button>
      </el-radio-group>
    </div>

    <!-- 设备选择 -->
    <div class="device-select">
      <el-select v-model="selectedCamera" placeholder="选择摄像头">
        <el-option
          v-for="camera in cameras"
          :key="camera.id"
          :label="camera.name"
          :value="camera.ip"
        />
      </el-select>
    </div>
  </div>
</template>

<script setup lang="ts">
import { ref, onMounted, onUnmounted } from 'vue'
import { ElMessage } from 'element-plus'
import { textToSpeech, startVoiceStream, stopVoiceStream } from '@/api/broadcast'

// 状态
const mode = ref<'text' | 'voice'>('text')
const textMessage = ref('')
const selectedCamera = ref('')
const cameras = ref<any[]>([])
const loading = ref(false)
const recording = ref(false)
const recordingTime = ref(0)
let recorder: MediaRecorder | null = null
let audioChunks: Blob[] = []
let timer: number | null = null
let ws: WebSocket | null = null

// 发送文本喊话
const sendText = async () => {
  if (!textMessage.value.trim()) {
    ElMessage.warning('请输入喊话内容')
    return
  }

  if (!selectedCamera.value) {
    ElMessage.warning('请选择摄像头')
    return
  }

  loading.value = true
  try {
    const res = await textToSpeech(selectedCamera.value, textMessage.value)
    if (res.success) {
      ElMessage.success('喊话发送成功')
      textMessage.value = ''
    } else {
      ElMessage.error('喊话失败')
    }
  } catch (error) {
    ElMessage.error('发送失败')
  } finally {
    loading.value = false
  }
}

// 开始录音
const startRecording = async () => {
  try {
    const stream = await navigator.mediaDevices.getUserMedia({
      audio: {
        sampleRate: 8000, // 8kHz适合语音
        channelCount: 1,
        echoCancellation: true,
        noiseSuppression: true
      }
    })

    recorder = new MediaRecorder(stream, {
      mimeType: 'audio/webm;codecs=opus' // 或 'audio/ogg;codecs=opus'
    })

    recorder.ondataavailable = (event) => {
      if (event.data.size > 0) {
        audioChunks.push(event.data)
        // 通过WebSocket发送音频数据
        sendAudioData(event.data)
      }
    }

    recorder.start(100) // 每100ms发送一次数据
    recording.value = true
    recordingTime.value = 0

    // 计时器
    timer = setInterval(() => {
      recordingTime.value++
    }, 1000)

  } catch (error) {
    ElMessage.error('无法访问麦克风')
  }
}

// 停止录音
const stopRecording = () => {
  if (recorder && recording.value) {
    recorder.stop()
    recorder.stream.getTracks().forEach(track => track.stop())
    recording.value = false

    if (timer) {
      clearInterval(timer)
      timer = null
    }

    // 关闭WebSocket连接
    if (ws) {
      ws.close()
      ws = null
    }
  }
}

// 通过WebSocket发送音频数据
const sendAudioData = (audioBlob: Blob) => {
  if (!ws) {
    // 建立WebSocket连接
    ws = new WebSocket(`ws://${location.host}/voice?cameraIp=${selectedCamera.value}`)

    ws.onopen = () => {
      console.log('WebSocket连接已建立')
    }

    ws.onerror = (error) => {
      console.error('WebSocket错误:', error)
    }
  }

  // 转换为ArrayBuffer发送
  const reader = new FileReader()
  reader.onload = () => {
    if (ws && ws.readyState === WebSocket.OPEN) {
      ws.send(reader.result as ArrayBuffer)
    }
  }
  reader.readAsArrayBuffer(audioBlob)
}

// 加载摄像头列表
const loadCameras = async () => {
  // 这里调用API获取摄像头列表
  cameras.value = [
    { id: 1, name: '大门摄像头', ip: '192.168.1.100' },
    { id: 2, name: '停车场摄像头', ip: '192.168.1.101' }
  ]
}

onMounted(() => {
  loadCameras()
})

onUnmounted(() => {
  if (recorder) {
    recorder.stop()
  }
  if (ws) {
    ws.close()
  }
})
</script>

<style scoped>
.voice-broadcast {
  padding: 20px;
  max-width: 500px;
  margin: 0 auto;
}

.recording-indicator {
  margin-top: 10px;
  color: #f56c6c;
  font-weight: bold;
  animation: blink 1s infinite;
}

@keyframes blink {
  0%, 100% { opacity: 1; }
  50% { opacity: 0.5; }
}

.mode-switch, .device-select {
  margin-top: 20px;
}
</style>

2. API接口封装

broadcast.ts

import request from '@/utils/request'

// 文本转语音喊话
export const textToSpeech = (cameraIp: string, text: string) => {
  return request.post('/api/broadcast/text-to-speech', {
    cameraIp,
    text
  })
}

// 开始语音流
export const startVoiceStream = (cameraIp: string) => {
  return request.post('/api/broadcast/voice/start', { cameraIp })
}

// 停止语音流
export const stopVoiceStream = (cameraIp: string) => {
  return request.post('/api/broadcast/voice/stop', { cameraIp })
}

// 获取摄像头列表
export const getCameras = () => {
  return request.get('/api/cameras')
}

四、配置说明

application.yml

hikvision:
  default-username: admin
  default-password: 123456
  isapi-port: 80
  audio:
    format: G711  # 音频格式：G711, G726, AAC
    sample-rate: 8000

五、音频格式转换工具类

AudioConverter.java

@Component
public class AudioConverter {

    /**
     * 将文本转为语音音频
     * 需要集成TTS引擎，如讯飞、百度、阿里云等
     */
    public byte[] textToAudio(String text, AudioFormat format) {
        // 这里调用第三方TTS服务
        // 1. 调用TTS API获取音频流
        // 2. 转换为摄像头支持的格式（G.711/G.726）
        // 3. 返回音频字节数组

        return convertToG711(text);
    }

    /**
     * PCM转G.711
     */
    private byte[] convertToG711(byte[] pcmData) {
        // 实现PCM到G.711的转换逻辑
        // 可以使用Jave、FFmpeg等库
        return pcmData;
    }
}

六、安全注意事项

1. 认证加密：使用HTTPS和WSS协议
2. 权限控制：限制用户喊话权限
3. 频率限制：防止恶意频繁喊话
4. 日志记录：记录所有喊话操作
5. 音频压缩：减少带宽占用

七、常见问题解决

1. 编码格式问题：确保音频格式为摄像头支持的格式
2. 网络延迟：使用UDP协议传输实时音频
3. 兼容性问题：不同型号摄像头API可能有差异
4. 防火墙：确保端口（8000, 554, 80）开放

这个方案提供了两种喊话方式：文本转语音和实时语音。文本转语音更简单稳定，实时语音体验更好但实现复杂度高。您可以根据实际需求选择合适的方案。
