上一篇介绍了FFmpeg解码视频数据后，用ANativeWindow进行视频的播放。以此为基础拓展到OpenGL Texture纹理进行视频的播放。
FFmpeg解码视频数据OpenGL Texture播放
一、GL C++层运行环境：
在前面所写的博客 OpenGL 自定义SurfaceView Texture C++预览Camera视频 中已经分析了GLSurfaceView的源码，感兴趣的可以查阅。
GLSurfaceView源码分析：
在setRenderer()方法着手分析，在这个方法中创建了EGLConfigChooser、EGLContextFactory、EGLWindowSurfaceFactory、GLThread。
EGLConfigChooser： 选择一个具有指定r、g、b、a尺寸以及至少指定深度和模具尺寸的配置；
EGLContextFactory：创建GLConext的环境，这里的GLConext就是OpenGL运行所需的上下文。
EGLWindowSurfaceFactory：在surface中EGLDisplay与显示NativeWindow创建相关联的联系。
GLThread： GLThread其核心就是维护一个子线程，在子线程中运行着与OpenGL相关的操作，其中GLConext一定要在这个线程中保持唯一。在线程采用弱应用的方式来维护着GLSurfaceView的持有。
C++层面的GL运行环境：
EglCore.cpp：
维护创建出EGLDisplay、EGLConfig、EGLConext的创建、上下文切换的操作类，代码如下：
cpp
// Author : wangyongyao https://github.com/wangyongyao1989
// Created by MMM on 2024/10/11.
// 来源于google开源项目https://github.com/google/grafika 中的EglCore.java类的改造。
#include "EglCore.h"
#include <assert.h>
EglCore::EglCore() {
init(NULL, 0);
}
EglCore::~EglCore() {
release();
}
/**
* 构造方法
* @param sharedContext
* @param flags
*/
EglCore::EglCore(EGLContext sharedContext, int flags) {
init(sharedContext, flags);
}
/**
* 初始化
* @param sharedContext
* @param flags
* @return
*/
bool EglCore::init(EGLContext sharedContext, int flags) {
assert(mEGLDisplay == EGL_NO_DISPLAY);
if (mEGLDisplay != EGL_NO_DISPLAY) {
LOGE("EGL already set up");
return false;
}
if (sharedContext == NULL) {
sharedContext = EGL_NO_CONTEXT;
}
mEGLDisplay = eglGetDisplay(EGL_DEFAULT_DISPLAY);
assert(mEGLDisplay != EGL_NO_DISPLAY);
if (mEGLDisplay == EGL_NO_DISPLAY) {
LOGE("unable to get EGL14 display.\n");
return false;
}
if (!eglInitialize(mEGLDisplay, 0, 0)) {
mEGLDisplay = EGL_NO_DISPLAY;
LOGE("unable to initialize EGL14");
return false;
}
// 尝试使用GLES3
if ((flags & FLAG_TRY_GLES3) != 0) {
EGLConfig config = getConfig(flags, 3);
if (config != NULL) {
int attrib3_list[] = {
EGL_CONTEXT_CLIENT_VERSION, 3,
EGL_NONE
};
EGLContext context = eglCreateContext(mEGLDisplay, config,
sharedContext, attrib3_list);
checkEglError("eglCreateContext");
if (eglGetError() == EGL_SUCCESS) {
mEGLConfig = config;
mEGLContext = context;
mGlVersion = 3;
}
}
}
// 如果GLES3没有获取到，则尝试使用GLES2
if (mEGLContext == EGL_NO_CONTEXT) {
EGLConfig config = getConfig(flags, 2);
assert(config != NULL);
int attrib2_list[] = {
EGL_CONTEXT_CLIENT_VERSION, 2,
EGL_NONE
};
EGLContext context = eglCreateContext(mEGLDisplay, config,
sharedContext, attrib2_list);
checkEglError("eglCreateContext");
if (eglGetError() == EGL_SUCCESS) {
mEGLConfig = config;
mEGLContext = context;
mGlVersion = 2;
}
}
// 获取eglPresentationTimeANDROID方法的地址
eglPresentationTimeANDROID = (EGL_PRESENTATION_TIME_ANDROIDPROC)
eglGetProcAddress("eglPresentationTimeANDROID");
if (!eglPresentationTimeANDROID) {
LOGE("eglPresentationTimeANDROID is not available!");
}
int values[1] = {0};
eglQueryContext(mEGLDisplay, mEGLContext, EGL_CONTEXT_CLIENT_VERSION, values);
LOGD("EGLContext created, client version %d", values[0]);
return true;
}
/**
* 获取合适的EGLConfig
* @param flags
* @param version
* @return
*/
EGLConfig EglCore::getConfig(int flags, int version) {
int renderableType = EGL_OPENGL_ES2_BIT;
if (version >= 3) {
renderableType |= EGL_OPENGL_ES3_BIT_KHR;
}
int attribList[] = {
EGL_RED_SIZE, 8,
EGL_GREEN_SIZE, 8,
EGL_BLUE_SIZE, 8,
EGL_ALPHA_SIZE, 8,
//EGL_DEPTH_SIZE, 16,
//EGL_STENCIL_SIZE, 8,
EGL_RENDERABLE_TYPE, renderableType,
EGL_NONE, 0, // placeholder for recordable [@-3]
EGL_NONE
};
int length = sizeof(attribList) / sizeof(attribList[0]);
if ((flags & FLAG_RECORDABLE) != 0) {
attribList[length - 3] = EGL_RECORDABLE_ANDROID;
attribList[length - 2] = 1;
}
EGLConfig configs = NULL;
int numConfigs;
if (!eglChooseConfig(mEGLDisplay, attribList, &configs, 1, &numConfigs)) {
LOGW("unable to find RGB8888 / %d EGLConfig", version);
return NULL;
}
return configs;
}
/**
* 释放资源
*/
void EglCore::release() {
if (mEGLDisplay != EGL_NO_DISPLAY) {
eglMakeCurrent(mEGLDisplay, EGL_NO_SURFACE, EGL_NO_SURFACE, EGL_NO_CONTEXT);
eglDestroyContext(mEGLDisplay, mEGLContext);
eglReleaseThread();
eglTerminate(mEGLDisplay);
}
mEGLDisplay = EGL_NO_DISPLAY;
mEGLContext = EGL_NO_CONTEXT;
mEGLConfig = NULL;
}
/**
* 获取EGLContext
* @return
*/
EGLContext EglCore::getEGLContext() {
return mEGLContext;
}
/**
* 销毁EGLSurface
* @param eglSurface
*/
void EglCore::releaseSurface(EGLSurface eglSurface) {
eglDestroySurface(mEGLDisplay, eglSurface);
}
/**
* 创建EGLSurface
* @param surface
* @return
*/
EGLSurface EglCore::createWindowSurface(ANativeWindow *surface) {
assert(surface != NULL);
if (surface == NULL) {
LOGE("ANativeWindow is NULL!");
return NULL;
}
int surfaceAttribs[] = {
EGL_NONE
};
ANativeWindow_acquire(surface);
ANativeWindow_setBuffersGeometry(surface, 0, 0, AHARDWAREBUFFER_FORMAT_R8G8B8A8_UNORM);
LOGD("eglCreateWindowSurface start");
EGLSurface eglSurface = eglCreateWindowSurface(mEGLDisplay, mEGLConfig, surface, surfaceAttribs);
checkEglError("eglCreateWindowSurface");
assert(eglSurface != NULL);
if (eglSurface == NULL) {
LOGE("EGLSurface is NULL!");
return NULL;
}
return eglSurface;
}
/**
* 创建离屏渲染的EGLSurface
* @param width
* @param height
* @return
*/
EGLSurface EglCore::createOffscreenSurface(int width, int height) {
int surfaceAttribs[] = {
EGL_WIDTH, width,
EGL_HEIGHT, height,
EGL_NONE
};
EGLSurface eglSurface = eglCreatePbufferSurface(mEGLDisplay, mEGLConfig, surfaceAttribs);
assert(eglSurface != NULL);
if (eglSurface == NULL) {
LOGE("Surface was null");
return NULL;
}
return eglSurface;
}
/**
* 切换到当前的上下文
* @param eglSurface
*/
void EglCore::makeCurrent(EGLSurface eglSurface) {
if (mEGLDisplay == EGL_NO_DISPLAY) {
LOGD("Note: makeCurrent w/o display.\n");
}
if (!eglMakeCurrent(mEGLDisplay, eglSurface, eglSurface, mEGLContext)) {
// TODO 抛出异常
LOGD("Note: eglMakeCurrent error.\n");
}
}
/**
* 切换到某个上下文
* @param drawSurface
* @param readSurface
*/
void EglCore::makeCurrent(EGLSurface drawSurface, EGLSurface readSurface) {
if (mEGLDisplay == EGL_NO_DISPLAY) {
LOGD("Note: makeCurrent w/o display.\n");
}
if (!eglMakeCurrent(mEGLDisplay, drawSurface, readSurface, mEGLContext)) {
// TODO 抛出异常
}
}
/**
*
*/
void EglCore::makeNothingCurrent() {
if (!eglMakeCurrent(mEGLDisplay, EGL_NO_SURFACE, EGL_NO_SURFACE, EGL_NO_CONTEXT)) {
// TODO 抛出异常
}
}
/**
* 交换显示
* @param eglSurface
* @return
*/
bool EglCore::swapBuffers(EGLSurface eglSurface) {
return eglSwapBuffers(mEGLDisplay, eglSurface);
}
/**
* 设置显示时间戳pts
* @param eglSurface
* @param nsecs
*/
void EglCore::setPresentationTime(EGLSurface eglSurface, long nsecs) {
eglPresentationTimeANDROID(mEGLDisplay, eglSurface, nsecs);
}
/**
* 是否处于当前上下文
* @param eglSurface
* @return
*/
bool EglCore::isCurrent(EGLSurface eglSurface) {
return mEGLContext == eglGetCurrentContext() &&
eglSurface == eglGetCurrentSurface(EGL_DRAW);
}
/**
* 查询surface
* @param eglSurface
* @param what
* @return
*/
int EglCore::querySurface(EGLSurface eglSurface, int what) {
int value;
eglQuerySurface(mEGLContext, eglSurface, what, &value);
return value;
}
/**
* 查询字符串
* @param what
* @return
*/
const char* EglCore::queryString(int what) {
return eglQueryString(mEGLDisplay, what);
}
/**
* 获取GLES版本号
* @return
*/
int EglCore::getGlVersion() {
return mGlVersion;
}
/**
* 检查是否出错
* @param msg
*/
void EglCore::checkEglError(const char *msg) {
int error;
if ((error = eglGetError()) != EGL_SUCCESS) {
// TODO 抛出异常
LOGE("%s: EGL error: %x", msg, error);
}
}EglSurfaceBase.cpp:
维护着Surface的创建显示、EGLContext的切换、交换到前台显示、释放EGLSurface具体操作，代码如下：
cpp
// Author : wangyongyao https://github.com/wangyongyao1989
// Created by MMM on 2024/10/11.
// 来源于google开源项目https://github.com/google/grafika 中的 EglSurfaceBase.java 类的改造。
#include "EglSurfaceBase.h"
#include <assert.h>
#include <GLES2/gl2.h>
EglSurfaceBase::EglSurfaceBase(EglCore *eglCore) : mEglCore(eglCore) {
mEglSurface = EGL_NO_SURFACE;
}
/**
* 创建显示的Surface
* @param nativeWindow
*/
void EglSurfaceBase::createWindowSurface(ANativeWindow *nativeWindow) {
assert(mEglSurface == EGL_NO_SURFACE);
if (mEglSurface != EGL_NO_SURFACE) {
LOGI("surface already created\n");
return;
}
mEglSurface = mEglCore->createWindowSurface(nativeWindow);
}
/**
* 创建离屏surface
* @param width
* @param height
*/
void EglSurfaceBase::createOffscreenSurface(int width, int height) {
assert(mEglSurface == EGL_NO_SURFACE);
if (mEglSurface != EGL_NO_SURFACE) {
LOGE("surface already created\n");
return;
}
mEglSurface = mEglCore->createOffscreenSurface(width, height);
mWidth = width;
mHeight = height;
}
/**
* 获取宽度
* @return
*/
int EglSurfaceBase::getWidth() {
if (mWidth < 0) {
return mEglCore->querySurface(mEglSurface, EGL_WIDTH);
} else {
return mWidth;
}
}
/**
* 获取高度
* @return
*/
int EglSurfaceBase::getHeight() {
if (mHeight < 0) {
return mEglCore->querySurface(mEglSurface, EGL_HEIGHT);
} else {
return mHeight;
}
}
/**
* 释放EGLSurface
*/
void EglSurfaceBase::releaseEglSurface() {
mEglCore->releaseSurface(mEglSurface);
mEglSurface = EGL_NO_SURFACE;
mWidth = mHeight = -1;
}
/**
* 切换到当前EGLContext
*/
void EglSurfaceBase::makeCurrent() {
mEglCore->makeCurrent(mEglSurface);
}
/**
* Makes our EGL context and surface current for drawing, using the supplied surface
* for reading.
*/
void EglSurfaceBase::makeCurrentReadFrom(EglSurfaceBase readSurface) {
mEglCore->makeCurrent(mEglSurface,readSurface.mEglSurface);
}
/**
* 交换到前台显示
* @return
*/
bool EglSurfaceBase::swapBuffers() {
bool result = mEglCore->swapBuffers(mEglSurface);
if (!result) {
LOGD("WARNING: swapBuffers() failed");
}
return result;
}
/**
* 设置当前时间戳
* @param nsecs
*/
void EglSurfaceBase::setPresentationTime(long nsecs) {
mEglCore->setPresentationTime(mEglSurface, nsecs);
}
/**
* 获取当前像素
* @return
*/
char* EglSurfaceBase::getCurrentFrame() {
char *pixels = NULL;
glReadPixels(0, 0, getWidth(), getHeight(), GL_RGBA, GL_UNSIGNED_BYTE, pixels);
return pixels;
}WindowSurface.cpp:
对EglSurfaceBase.cpp的封装，只提供创建Surface、销毁Surface、重建Surface三个方法对外使用，代码如下：
cpp
// Author : wangyongyao https://github.com/wangyongyao1989
// Created by MMM on 2024/10/11.
// 来源于google开源项目 https://github.com/google/grafika WindowSurface.java类的改造。
#include "WindowSurface.h"
#include <assert.h>
WindowSurface::WindowSurface(EglCore *eglCore, ANativeWindow *window, bool releaseSurface)
: EglSurfaceBase(eglCore) {
mSurface = window;
createWindowSurface(mSurface);
mReleaseSurface = releaseSurface;
}
WindowSurface::WindowSurface(EglCore *eglCore, ANativeWindow *window)
: EglSurfaceBase(eglCore) {
createWindowSurface(window);
mSurface = window;
}
void WindowSurface::release() {
releaseEglSurface();
if (mSurface != NULL) {
ANativeWindow_release(mSurface);
mSurface = NULL;
}
}
void WindowSurface::recreate(EglCore *eglCore) {
assert(mSurface != NULL);
if (mSurface == NULL) {
LOGE("not yet implemented ANativeWindow");
return;
}
mEglCore = eglCore;
createWindowSurface(mSurface);
}二、GL Render渲染环境：
关于OpenGL相关的基础有兴趣可查阅我的相关博客：LearnOpenGL之入门基础
Looper:
维护一个类handler的消息机制，实现线程间的消息交互。
Looper.h代码如下：
cpp
// Author : wangyongyao https://github.com/wangyongyao1989
// Created by MMM on 2024/10/14.
//
#ifndef MYYFFMPEG_LOOPER_H
#define MYYFFMPEG_LOOPER_H
#include <pthread.h>
#include <sys/types.h>
#include <semaphore.h>
#include "LogUtils.h"
struct LooperMessage {
int what;
int arg1;
int arg2;
void *obj;
LooperMessage *next;
bool quit;
};
class Looper {
public:
Looper();
Looper &operator=(const Looper &) = delete;
Looper(Looper &) = delete;
virtual ~Looper();
void postMessage(int what, bool flush = false);
void postMessage(int what, void *obj, bool flush = false);
void postMessage(int what, int arg1, int arg2, bool flush = false);
void postMessage(int what, int arg1, int arg2, void *obj, bool flush = false);
void quit();
virtual void handleMessage(LooperMessage *msg);
private:
void addMessage(LooperMessage *msg, bool flush);
static void *trampoline(void *p);
void loop(void);
LooperMessage *head;
pthread_t worker;
sem_t headWriteProtect;
sem_t headDataAvailable;
bool running;
};
#endif //MYYFFMPEG_LOOPER_HLooper.cpp代码如下：
cpp
#include "Looper.h"
#include <jni.h>
#include <pthread.h>
#include <stdio.h>
#include <string.h>
#include <unistd.h>
#include <sys/stat.h>
#include <fcntl.h>
#include <semaphore.h>
struct LooperMessage;
typedef struct LooperMessage LooperMessage;
void *Looper::trampoline(void *p) {
((Looper *) p)->loop();
return NULL;
}
Looper::Looper() {
head = NULL;
sem_init(&headDataAvailable, 0, 0);
sem_init(&headWriteProtect, 0, 1);
pthread_attr_t attr;
pthread_attr_init(&attr);
pthread_create(&worker, &attr, trampoline, this);
running = true;
}
Looper::~Looper() {
if (running) {
LOGE("Looper deleted while still running. Some messages will not be processed");
quit();
}
}
void Looper::postMessage(int what, bool flush) {
postMessage(what, 0, 0, NULL, flush);
}
void Looper::postMessage(int what, void *obj, bool flush) {
postMessage(what, 0, 0, obj, flush);
}
void Looper::postMessage(int what, int arg1, int arg2, bool flush) {
postMessage(what, arg1, arg2, NULL, flush);
}
void Looper::postMessage(int what, int arg1, int arg2, void *obj, bool flush) {
LooperMessage *msg = new LooperMessage();
msg->what = what;
msg->obj = obj;
msg->arg1 = arg1;
msg->arg2 = arg2;
msg->next = NULL;
msg->quit = false;
addMessage(msg, flush);
}
void Looper::addMessage(LooperMessage *msg, bool flush) {
sem_wait(&headWriteProtect);
LooperMessage *h = head;
if (flush) {
while (h) {
LooperMessage *next = h->next;
delete h;
h = next;
}
h = NULL;
}
if (h) {
while (h->next) {
h = h->next;
}
h->next = msg;
} else {
head = msg;
}
// LOGE("Looper::addMessage msg->what=%d", msg->what);
sem_post(&headWriteProtect);
sem_post(&headDataAvailable);
}
void Looper::loop() {
while (true) {
// wait for available message
sem_wait(&headDataAvailable);
// get next available message
sem_wait(&headWriteProtect);
LooperMessage *msg = head;
if (msg == NULL) {
LOGE("Looper::loop() no msg");
sem_post(&headWriteProtect);
continue;
}
head = msg->next;
sem_post(&headWriteProtect);
if (msg->quit) {
LOGE("Looper::loop() quitting");
delete msg;
return;
}
// LOGE("Looper::loop() processing msg.what=%d", msg->what);
handleMessage(msg);
delete msg;
}
}
void Looper::quit() {
LOGE("Looper::quit()");
LooperMessage *msg = new LooperMessage();
msg->what = 0;
msg->obj = NULL;
msg->next = NULL;
msg->quit = true;
addMessage(msg, false);
void *retval;
pthread_join(worker, &retval);
sem_destroy(&headDataAvailable);
sem_destroy(&headWriteProtect);
running = false;
}
void Looper::handleMessage(LooperMessage *msg) {
// LOGE("Looper::handleMessage [what, obj]=[%d, %p]", msg->what, msg->obj);
}线程间消息传递：
在渲染的过程中把其他的线程中的操作过程及参数通过Looper消息的方式传递到类似于GLThread子线程（GL运行环境）中。代码如下：
cpp
void EGLSurfaceViewVideoRender::handleMessage(LooperMessage *msg) {
Looper::handleMessage(msg);
switch (msg->what) {
case MSG_SurfaceCreated: {
LOGE("EGLSurfaceViewVideoRender::handleMessage MSG_SurfaceCreated");
OnSurfaceCreated();
}
break;
case MSG_SurfaceChanged:
LOGE("EGLSurfaceViewVideoRender::handleMessage MSG_SurfaceChanged");
OnSurfaceChanged(msg->arg1, msg->arg2);
break;
case MSG_DrawFrame:
// LOGE("EGLSurfaceViewVideoRender::handleMessage MSG_DrawFrame");
OnDrawFrame();
break;
case MSG_SurfaceDestroyed:
LOGE("EGLSurfaceViewVideoRender::handleMessage MSG_SurfaceDestroyed");
OnSurfaceDestroyed();
break;
default:
break;
}
}OpenGL着色器的编译、程序对象及链接：
顶点着色器代码：
cpp
#version 320 es
out vec2 v_texcoord;
in vec4 position;
in vec2 texcoord;
void main() {
v_texcoord = texcoord;
gl_Position = position;
}片元着色器代码：
cpp
#version 320 es
precision mediump float;
in vec2 v_texcoord;
uniform lowp sampler2D s_textureY;
uniform lowp sampler2D s_textureU;
uniform lowp sampler2D s_textureV;
// https://stackoverflow.com/questions/26695253/when-switching-to-glsl-300-met-the-following-error
//The predefined variable gl_FragColor does not exist anymore in GLSL ES 3.00.
//out vec4 gl_FragColor;
out vec4 FragColor;
void main() {
float y, u, v, r, g, b;
y = texture(s_textureY, v_texcoord).r;
u = texture(s_textureU, v_texcoord).r;
v = texture(s_textureV, v_texcoord).r;
u = u - 0.5;
v = v - 0.5;
r = y + 1.403 * v;
g = y - 0.344 * u - 0.714 * v;
b = y + 1.770 * u;
FragColor = vec4(r, g, b, 1.0f);
// gl_FragColor = vec4(r, g, b, 1.0);
}GL的着色器加载、程序编译：
OpenGLShader为着色器加载、程序编译提供必要的方法。
OpenGLShader.h代码：
cpp
//
// Created by MMM on 2024/8/8.
//
#ifndef ANDROIDLEARNOPENGL_OPENGLSHADER_H
#define ANDROIDLEARNOPENGL_OPENGLSHADER_H
#include <GLES3/gl3.h> //导入的包为GL3对应的顶点程序和片元程序为：#version 320 es
#include <GLES3/gl3ext.h>
#include <fstream>
#include <sstream>
#include "iostream"
#include "LogUtils.h"
//glm库
#include <glm/glm.hpp>
#include <glm/gtc/matrix_transform.hpp>
#include <glm/gtc/type_ptr.hpp>
using namespace std;
class OpenGLShader {
private:
//顶点着色器代码
const char *gVertexShaderCode = nullptr;
//片段着色器代码
const char *gFragmentShaderCode = nullptr;
string vertexCode;
string fragmentCode;
GLuint loadShader(GLenum shaderType, const char *pSource);
void printGLString(const char *name, GLenum s);
void checkGlError(const char *op);
public:
GLuint shaderId;
GLuint vertexShader; //顶点着色器
GLuint fraShader; //片段着色器
OpenGLShader();
~OpenGLShader();
bool getSharderPath(const char *vertexPath, const char *fragmentPath);
bool getSharderStringPath(string vertexPath, string fragmentPath);
GLuint createProgram();
void use() const {
glUseProgram(shaderId);
}
// utility uniform functions
// ------------------------------------------------------------------------
void setBool(const string &name, bool value) const {
glUniform1i(glGetUniformLocation(shaderId, name.c_str()), (int) value);
}
// ------------------------------------------------------------------------
void setInt(const string &name, int value) const {
glUniform1i(glGetUniformLocation(shaderId, name.c_str()), value);
}
// ------------------------------------------------------------------------
void setFloat(const string &name, float value) const {
glUniform1f(glGetUniformLocation(shaderId, name.c_str()), value);
}
// ------------------------------------------------------------------------
void setVec2(const string &name, const glm::vec2 &value) const {
glUniform2fv(glGetUniformLocation(shaderId, name.c_str()), 1, &value[0]);
}
void setVec2(const string &name, float x, float y) const {
glUniform2f(glGetUniformLocation(shaderId, name.c_str()), x, y);
}
// ------------------------------------------------------------------------
void setVec3(const string &name, const glm::vec3 &value) const {
glUniform3fv(glGetUniformLocation(shaderId, name.c_str()), 1, &value[0]);
}
void setVec3(const string &name, float x, float y, float z) const {
glUniform3f(glGetUniformLocation(shaderId, name.c_str()), x, y, z);
}
// ------------------------------------------------------------------------
void setVec4(const string &name, const glm::vec4 &value) const {
glUniform4fv(glGetUniformLocation(shaderId, name.c_str()), 1, &value[0]);
}
void setVec4(const string &name, float x, float y, float z, float w) const {
glUniform4f(glGetUniformLocation(shaderId, name.c_str()), x, y, z, w);
}
// ------------------------------------------------------------------------
void setMat2(const string &name, const glm::mat2 &mat) const {
glUniformMatrix2fv(glGetUniformLocation(shaderId, name.c_str()), 1, GL_FALSE, &mat[0][0]);
}
// ------------------------------------------------------------------------
void setMat3(const string &name, const glm::mat3 &mat) const {
glUniformMatrix3fv(glGetUniformLocation(shaderId, name.c_str()), 1, GL_FALSE, &mat[0][0]);
}
// ------------------------------------------------------------------------
void setMat4(const string &name, const glm::mat4 &mat) const {
glUniformMatrix4fv(glGetUniformLocation(shaderId, name.c_str()), 1, GL_FALSE, &mat[0][0]);
}
};
#endif //ANDROIDLEARNOPENGL_OPENGLSHADER_HOpenGLShader.cpp代码：
cpp
//
// Created by MMM on 2024/8/8.
//
#include "OpenGLShader.h"
GLuint
OpenGLShader::createProgram() {
vertexShader = loadShader(GL_VERTEX_SHADER, gVertexShaderCode);
LOGI("=====gVertexShaderCode :%s", gVertexShaderCode);
LOGI("======gFragmentShaderCode :%s", gFragmentShaderCode);
if (!vertexShader) {
checkGlError("loadShader GL_VERTEX_SHADER");
return 0;
}
fraShader = loadShader(GL_FRAGMENT_SHADER, gFragmentShaderCode);
if (!fraShader) {
checkGlError("loadShader GL_FRAGMENT_SHADER");
return 0;
}
shaderId = glCreateProgram(); //创建一个着色程序对象
if (shaderId) {
glAttachShader(shaderId, vertexShader); //把着色器附加到了程序对象上
checkGlError("glAttachShader");
glAttachShader(shaderId, fraShader);
checkGlError("glAttachShader");
glLinkProgram(shaderId); //链接程序对象
GLint linkStatus = GL_FALSE;
glGetProgramiv(shaderId, GL_LINK_STATUS, &linkStatus); //检测链接着色器程序是否失败
if (linkStatus != GL_TRUE) {
GLint bufLength = 0;
glGetProgramiv(shaderId, GL_INFO_LOG_LENGTH, &bufLength);
if (bufLength) {
char *buf = (char *) malloc(bufLength);
if (buf) {
glGetProgramInfoLog(shaderId, bufLength, NULL, buf);
LOGE("Could not link shaderId:\n%s\n", buf);
free(buf);
}
}
glDeleteProgram(shaderId); //
shaderId = 0;
}
}
return shaderId;
}
/**
* 加载着色器
* @param shaderType
* @param pSource
* @return
*/
GLuint OpenGLShader::loadShader(GLenum shaderType, const char *pSource) {
GLuint shader = glCreateShader(shaderType); //创建着色器
if (shader) {
glShaderSource(shader, 1, &pSource, NULL); //着色器源码附加到着色器对象上
glCompileShader(shader); //编译着着色器
GLint compiled = 0;
glGetShaderiv(shader, GL_COMPILE_STATUS, &compiled);
if (!compiled) {
GLint infoLen = 0;
glGetShaderiv(shader, GL_INFO_LOG_LENGTH, &infoLen);
if (infoLen) {
char *buf = (char *) malloc(infoLen);
if (buf) {
glGetShaderInfoLog(shader, infoLen, NULL, buf);
LOGE("Could not compile shader %d:\n%s\n",
shaderType, buf);
free(buf);
}
glDeleteShader(shader); //删除着色器对象
shader = 0;
}
}
}
return shader;
}
bool OpenGLShader::getSharderPath(const char *vertexPath, const char *fragmentPath) {
ifstream vShaderFile;
ifstream fShaderFile;
// ensure ifstream objects can throw exceptions:
vShaderFile.exceptions(ifstream::failbit | ifstream::badbit);
fShaderFile.exceptions(ifstream::failbit | ifstream::badbit);
try {
// open files
vShaderFile.open(vertexPath);
fShaderFile.open(fragmentPath);
stringstream vShaderStream, fShaderStream;
// read file's buffer contents into streams
vShaderStream << vShaderFile.rdbuf();
fShaderStream << fShaderFile.rdbuf();
// close file handlers
vShaderFile.close();
fShaderFile.close();
// convert stream into string
vertexCode = vShaderStream.str();
fragmentCode = fShaderStream.str();
}
catch (ifstream::failure &e) {
LOGE("Could not getSharderPath error :%s", e.what());
return false;
}
gVertexShaderCode = vertexCode.c_str();
gFragmentShaderCode = fragmentCode.c_str();
return true;
}
bool OpenGLShader::getSharderStringPath(string vertexPath, string fragmentPath) {
ifstream vShaderFile;
ifstream fShaderFile;
const char *cVertexPath = vertexPath.c_str();
const char *cFragmentPath = fragmentPath.c_str();
// ensure ifstream objects can throw exceptions:
vShaderFile.exceptions(ifstream::failbit | ifstream::badbit);
fShaderFile.exceptions(ifstream::failbit | ifstream::badbit);
try {
// open files
vShaderFile.open(vertexPath);
fShaderFile.open(fragmentPath);
stringstream vShaderStream, fShaderStream;
// read file's buffer contents into streams
vShaderStream << vShaderFile.rdbuf();
fShaderStream << fShaderFile.rdbuf();
// close file handlers
vShaderFile.close();
fShaderFile.close();
// convert stream into string
vertexCode = vShaderStream.str();
fragmentCode = fShaderStream.str();
}
catch (ifstream::failure &e) {
LOGE("Could not getSharderPath error :%s", e.what());
return false;
}
gVertexShaderCode = vertexCode.c_str();
gFragmentShaderCode = fragmentCode.c_str();
return true;
}
void OpenGLShader::printGLString(const char *name, GLenum s) {
const char *v = (const char *) glGetString(s);
LOGI("OpenGL %s = %s\n", name, v);
}
void OpenGLShader::checkGlError(const char *op) {
for (GLint error = glGetError(); error; error = glGetError()) {
LOGI("after %s() glError (0x%x)\n", op, error);
}
}
OpenGLShader::~OpenGLShader() {
if (vertexShader) {
glDeleteShader(vertexShader);
}
if (fraShader) {
glDeleteShader(fraShader);
}
vertexCode.clear();
fragmentCode.clear();
gVertexShaderCode = nullptr;
gFragmentShaderCode = nullptr;
}
OpenGLShader::OpenGLShader() {
}OpenGL程序创建及Uniform参数的获取：
cpp
int
EGLSurfaceViewVideoRender::createProgram() {
m_program = openGlShader->createProgram();
m_vertexShader = openGlShader->vertexShader;
m_pixelShader = openGlShader->fraShader;
LOGI("EGLSurfaceViewVideoRender createProgram m_program:%d", m_program);
if (!m_program) {
LOGE("Could not create program.");
return 0;
}
//Get Uniform Variables Location
m_vertexPos = (GLuint) glGetAttribLocation(m_program, "position");
m_textureYLoc = glGetUniformLocation(m_program, "s_textureY");
m_textureULoc = glGetUniformLocation(m_program, "s_textureU");
m_textureVLoc = glGetUniformLocation(m_program, "s_textureV");
m_textureLoc = (GLuint) glGetAttribLocation(m_program, "texcoord");
m_textureSize = glGetUniformLocation(m_program, "texSize");
return m_program;
}纹理Texture的附着：
cpp
GLuint EGLSurfaceViewVideoRender::useProgram() {
if (!m_program && !createProgram()) {
LOGE("Could not use program.");
return 0;
}
if (isProgramChanged) {
glUseProgram(m_program);
glVertexAttribPointer(m_vertexPos, 2, GL_FLOAT, GL_FALSE, 0, EGLVerticek);
glEnableVertexAttribArray(m_vertexPos);
glUniform1i(m_textureYLoc, 0);
glUniform1i(m_textureULoc, 1);
glUniform1i(m_textureVLoc, 2);
glVertexAttribPointer(m_textureLoc, 2, GL_FLOAT, GL_FALSE, 0, EGLTextureCoord);
glEnableVertexAttribArray(m_textureLoc);
if (m_textureSize >= 0) {
GLfloat size[2];
size[0] = m_width;
size[1] = m_height;
glUniform2fv(m_textureSize, 1, &size[0]);
}
isProgramChanged = false;
}
return m_program;
}纹理Texture创建：
cpp
bool EGLSurfaceViewVideoRender::createTextures() {
auto widthY = (GLsizei) m_width;
auto heightY = (GLsizei) m_height;
glActiveTexture(GL_TEXTURE0);
glGenTextures(1, &m_textureIdY);
glBindTexture(GL_TEXTURE_2D, m_textureIdY);
glTexParameterf(GL_TEXTURE_2D, GL_TEXTURE_WRAP_S, GL_CLAMP_TO_EDGE);
glTexParameterf(GL_TEXTURE_2D, GL_TEXTURE_WRAP_T, GL_CLAMP_TO_EDGE);
glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MIN_FILTER, GL_LINEAR);
glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MAG_FILTER, GL_LINEAR);
glTexImage2D(GL_TEXTURE_2D, 0, GL_LUMINANCE, widthY, heightY, 0, GL_LUMINANCE, GL_UNSIGNED_BYTE,
nullptr);
if (!m_textureIdY) {
LOGE("OpenGL Error Create Y texture");
return false;
}
GLsizei widthU = (GLsizei) m_width / 2;
GLsizei heightU = (GLsizei) m_height / 2;
glActiveTexture(GL_TEXTURE1);
glGenTextures(1, &m_textureIdU);
glBindTexture(GL_TEXTURE_2D, m_textureIdU);
glTexParameterf(GL_TEXTURE_2D, GL_TEXTURE_WRAP_S, GL_CLAMP_TO_EDGE);
glTexParameterf(GL_TEXTURE_2D, GL_TEXTURE_WRAP_T, GL_CLAMP_TO_EDGE);
glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MIN_FILTER, GL_LINEAR);
glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MAG_FILTER, GL_LINEAR);
glTexImage2D(GL_TEXTURE_2D, 0, GL_LUMINANCE, widthU, heightU, 0, GL_LUMINANCE, GL_UNSIGNED_BYTE,
nullptr);
if (!m_textureIdU) {
LOGE("OpenGL Error Create U texture");
return false;
}
GLsizei widthV = (GLsizei) m_width / 2;
GLsizei heightV = (GLsizei) m_height / 2;
glActiveTexture(GL_TEXTURE2);
glGenTextures(1, &m_textureIdV);
glBindTexture(GL_TEXTURE_2D, m_textureIdV);
glTexParameterf(GL_TEXTURE_2D, GL_TEXTURE_WRAP_S, GL_CLAMP_TO_EDGE);
glTexParameterf(GL_TEXTURE_2D, GL_TEXTURE_WRAP_T, GL_CLAMP_TO_EDGE);
glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MIN_FILTER, GL_LINEAR);
glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MAG_FILTER, GL_LINEAR);
glTexImage2D(GL_TEXTURE_2D, 0, GL_LUMINANCE, widthV, heightV, 0, GL_LUMINANCE, GL_UNSIGNED_BYTE,
nullptr);
if (!m_textureIdV) {
LOGE("OpenGL Error Create V texture");
return false;
}
return true;
}纹理Texture数据更新：
cpp
bool EGLSurfaceViewVideoRender::updateTextures() {
if (!m_textureIdY && !m_textureIdU && !m_textureIdV /*&& !createTextures()*/) return false;
// LOGE("updateTextures m_textureIdY:%d,m_textureIdU:%d,m_textureIdV:%d,===isDirty:%d",
// m_textureIdY,
// m_textureIdU, m_textureIdV, isDirty);
if (isDirty) {
glActiveTexture(GL_TEXTURE0);
glBindTexture(GL_TEXTURE_2D, m_textureIdY);
glTexImage2D(GL_TEXTURE_2D, 0, GL_LUMINANCE, (GLsizei) m_width, (GLsizei) m_height, 0,
GL_LUMINANCE, GL_UNSIGNED_BYTE, m_pDataY.get());
glActiveTexture(GL_TEXTURE1);
glBindTexture(GL_TEXTURE_2D, m_textureIdU);
glTexImage2D(GL_TEXTURE_2D, 0, GL_LUMINANCE, (GLsizei) m_width / 2, (GLsizei) m_height / 2,
0,
GL_LUMINANCE, GL_UNSIGNED_BYTE, m_pDataU);
glActiveTexture(GL_TEXTURE2);
glBindTexture(GL_TEXTURE_2D, m_textureIdV);
glTexImage2D(GL_TEXTURE_2D, 0, GL_LUMINANCE, (GLsizei) m_width / 2, (GLsizei) m_height / 2,
0,
GL_LUMINANCE, GL_UNSIGNED_BYTE, m_pDataV);
isDirty = false;
return true;
}
return false;
}GL渲染环境的集成：
上面已经介绍了渲染环境所需的必要流程，现在把整个渲染的过程封装在一个类中。该类提供了OpenGL的运行环境的创建及维护其内部状态，供外给出surfaceCreated、surfaceChanged、render、updateFrame、release、draw、setSharderStringPath方法使用。
EGLSurfaceViewVideoRender.h代码如下：
cpp
// Author : wangyongyao https://github.com/wangyongyao1989
// Created by MMM on 2024/9/6.
//
#ifndef MYYFFMPEG_EGLSurfaceViewVideoRender_H
#define MYYFFMPEG_EGLSurfaceViewVideoRender_H
#endif //MYYFFMPEG_EGLSurfaceViewVideoRender_H
#include <cstdint>
#include <memory>
#include <android/native_window.h>
#include <android/asset_manager.h>
#include "OpenGLShader.h"
#include <EGL/egl.h>
#include <GLES3/gl3.h>
#include "EglCore.h"
#include "WindowSurface.h"
#include "Looper.h"
enum {
MSG_SurfaceCreated,
MSG_SurfaceChanged,
MSG_DrawFrame,
MSG_SurfaceDestroyed,
};
struct egl_surface_video_frame {
size_t width;
size_t height;
size_t stride_y;
size_t stride_uv;
uint8_t *y;
uint8_t *u;
uint8_t *v;
};
// Vertices for a full screen quad.
static const float EGLVerticek[8] = {
-1.f, 1.f,
-1.f, -1.f,
1.f, 1.f,
1.f, -1.f
};
// Texture coordinates for mapping entire texture.
static const float EGLTextureCoord[8] = {
0, 0,
0, 1,
1, 0,
1, 1
};
static const size_t BIT_RATE = 4000000; // 4Mbps
static const size_t VIDEO_WIDTH = 1280;
static const size_t VIDEO_HEIGHT = 720;
class EGLSurfaceViewVideoRender : public Looper {
public:
EGLSurfaceViewVideoRender();
~EGLSurfaceViewVideoRender();
void surfaceCreated(ANativeWindow *window, AAssetManager *assetManager);
void surfaceChanged(size_t width, size_t height);
void render();
void updateFrame(const egl_surface_video_frame &frame);
void release();
void draw(uint8_t *buffer, size_t length, size_t width, size_t height, float rotation);
void setParameters(uint32_t params);
uint32_t getParameters();
bool setSharderPath(const char *vertexPath, const char *fragmentPath);
bool setSharderStringPath(string vertexPath, string fragmentPath);
void startEncoder(const char *recordPath);
void stopEncoder();
private:
void handleMessage(LooperMessage *msg);
void OnSurfaceCreated();
void OnSurfaceChanged(int w, int h);
void OnDrawFrame();
void OnSurfaceDestroyed();
bool CreateFrameBufferObj();
bool createTextures();
bool updateTextures();
void deleteTextures();
int createProgram();
GLuint useProgram();
void printGLString(const char *name, GLenum s);
void checkGlError(const char *op);
bool isProgramChanged = true;
void delete_program(GLuint &program);
GLuint m_program = 0;
GLuint m_vertexShader = 0;
GLuint m_pixelShader = 0;
std::unique_ptr<uint8_t[]> m_pDataY = nullptr;
uint8_t *m_pDataU = nullptr;
uint8_t *m_pDataV = nullptr;
__unused size_t m_length = 0;
size_t m_sizeY = 0;
size_t m_sizeU = 0;
size_t m_sizeV = 0;
GLuint m_textureIdY = 0;
GLuint m_textureIdU = 0;
GLuint m_textureIdV = 0;
GLuint m_vertexPos = 0;
GLuint m_textureLoc = 0;
GLint m_textureYLoc = 0;
GLint m_textureULoc = 0;
GLint m_textureVLoc = 0;
GLint m_textureSize = 0;
size_t m_width = 0;
size_t m_height = 0;
size_t m_backingWidth = 0;
size_t m_backingHeight = 0;
uint32_t m_params = 0;
float m_rotation = 0;
bool isDirty;
OpenGLShader *openGlShader = nullptr;
EGLDisplay display = nullptr;
EGLSurface winsurface = nullptr;
EglCore *m_EglCore = nullptr;
WindowSurface *m_WindowSurface = nullptr;
ANativeWindow *m_ANWindow = nullptr;
size_t offX;
size_t offY;
size_t off_right;
size_t off_bottom;
};EGLSurfaceViewVideoRender.cpp代码如下：
cpp
// Author : wangyongyao https://github.com/wangyongyao1989
// Created by MMM on 2024/10/13.
//
#include "EGLSurfaceViewVideoRender.h"
#include "OpenGLShader.h"
void EGLSurfaceViewVideoRender::surfaceCreated(ANativeWindow *window, AAssetManager *assetManager) {
m_ANWindow = window;
postMessage(MSG_SurfaceCreated, false);
}
void EGLSurfaceViewVideoRender::surfaceChanged(size_t width, size_t height) {
postMessage(MSG_SurfaceChanged, width, height);
}
void EGLSurfaceViewVideoRender::render() {
postMessage(MSG_DrawFrame, false);
}
void EGLSurfaceViewVideoRender::release() {
postMessage(MSG_SurfaceDestroyed, false);
}
void EGLSurfaceViewVideoRender::updateFrame(const egl_surface_video_frame &frame) {
m_sizeY = frame.width * frame.height;
m_sizeU = frame.width * frame.height / 4;
m_sizeV = frame.width * frame.height / 4;
if (m_pDataY == nullptr || m_width != frame.width || m_height != frame.height) {
m_pDataY = std::make_unique<uint8_t[]>(m_sizeY + m_sizeU + m_sizeV);
m_pDataU = m_pDataY.get() + m_sizeY;
m_pDataV = m_pDataU + m_sizeU;
isProgramChanged = true;
}
m_width = frame.width;
m_height = frame.height;
if (m_width == frame.stride_y) {
memcpy(m_pDataY.get(), frame.y, m_sizeY);
} else {
uint8_t *pSrcY = frame.y;
uint8_t *pDstY = m_pDataY.get();
for (int h = 0; h < m_height; h++) {
memcpy(pDstY, pSrcY, m_width);
pSrcY += frame.stride_y;
pDstY += m_width;
}
}
if (m_width / 2 == frame.stride_uv) {
memcpy(m_pDataU, frame.u, m_sizeU);
memcpy(m_pDataV, frame.v, m_sizeV);
} else {
uint8_t *pSrcU = frame.u;
uint8_t *pSrcV = frame.v;
uint8_t *pDstU = m_pDataU;
uint8_t *pDstV = m_pDataV;
for (int h = 0; h < m_height / 2; h++) {
memcpy(pDstU, pSrcU, m_width / 2);
memcpy(pDstV, pSrcV, m_width / 2);
pDstU += m_width / 2;
pDstV += m_width / 2;
pSrcU += frame.stride_uv;
pSrcV += frame.stride_uv;
}
}
isDirty = true;
}
void
EGLSurfaceViewVideoRender::draw(uint8_t *buffer, size_t length, size_t width, size_t height,
float rotation) {
egl_surface_video_frame frame{};
frame.width = width;
frame.height = height;
frame.stride_y = width;
frame.stride_uv = width / 2;
frame.y = buffer;
frame.u = buffer + width * height;
frame.v = buffer + width * height * 5 / 4;
updateFrame(frame);
}
void EGLSurfaceViewVideoRender::setParameters(uint32_t params) {
m_params = params;
}
uint32_t EGLSurfaceViewVideoRender::getParameters() {
return m_params;
}
bool EGLSurfaceViewVideoRender::createTextures() {
auto widthY = (GLsizei) m_width;
auto heightY = (GLsizei) m_height;
glActiveTexture(GL_TEXTURE0);
glGenTextures(1, &m_textureIdY);
glBindTexture(GL_TEXTURE_2D, m_textureIdY);
glTexParameterf(GL_TEXTURE_2D, GL_TEXTURE_WRAP_S, GL_CLAMP_TO_EDGE);
glTexParameterf(GL_TEXTURE_2D, GL_TEXTURE_WRAP_T, GL_CLAMP_TO_EDGE);
glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MIN_FILTER, GL_LINEAR);
glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MAG_FILTER, GL_LINEAR);
glTexImage2D(GL_TEXTURE_2D, 0, GL_LUMINANCE, widthY, heightY, 0, GL_LUMINANCE, GL_UNSIGNED_BYTE,
nullptr);
if (!m_textureIdY) {
LOGE("OpenGL Error Create Y texture");
return false;
}
GLsizei widthU = (GLsizei) m_width / 2;
GLsizei heightU = (GLsizei) m_height / 2;
glActiveTexture(GL_TEXTURE1);
glGenTextures(1, &m_textureIdU);
glBindTexture(GL_TEXTURE_2D, m_textureIdU);
glTexParameterf(GL_TEXTURE_2D, GL_TEXTURE_WRAP_S, GL_CLAMP_TO_EDGE);
glTexParameterf(GL_TEXTURE_2D, GL_TEXTURE_WRAP_T, GL_CLAMP_TO_EDGE);
glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MIN_FILTER, GL_LINEAR);
glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MAG_FILTER, GL_LINEAR);
glTexImage2D(GL_TEXTURE_2D, 0, GL_LUMINANCE, widthU, heightU, 0, GL_LUMINANCE, GL_UNSIGNED_BYTE,
nullptr);
if (!m_textureIdU) {
LOGE("OpenGL Error Create U texture");
return false;
}
GLsizei widthV = (GLsizei) m_width / 2;
GLsizei heightV = (GLsizei) m_height / 2;
glActiveTexture(GL_TEXTURE2);
glGenTextures(1, &m_textureIdV);
glBindTexture(GL_TEXTURE_2D, m_textureIdV);
glTexParameterf(GL_TEXTURE_2D, GL_TEXTURE_WRAP_S, GL_CLAMP_TO_EDGE);
glTexParameterf(GL_TEXTURE_2D, GL_TEXTURE_WRAP_T, GL_CLAMP_TO_EDGE);
glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MIN_FILTER, GL_LINEAR);
glTexParameteri(GL_TEXTURE_2D, GL_TEXTURE_MAG_FILTER, GL_LINEAR);
glTexImage2D(GL_TEXTURE_2D, 0, GL_LUMINANCE, widthV, heightV, 0, GL_LUMINANCE, GL_UNSIGNED_BYTE,
nullptr);
if (!m_textureIdV) {
LOGE("OpenGL Error Create V texture");
return false;
}
return true;
}
bool EGLSurfaceViewVideoRender::updateTextures() {
if (!m_textureIdY && !m_textureIdU && !m_textureIdV /*&& !createTextures()*/) return false;
// LOGE("updateTextures m_textureIdY:%d,m_textureIdU:%d,m_textureIdV:%d,===isDirty:%d",
// m_textureIdY,
// m_textureIdU, m_textureIdV, isDirty);
if (isDirty) {
glActiveTexture(GL_TEXTURE0);
glBindTexture(GL_TEXTURE_2D, m_textureIdY);
glTexImage2D(GL_TEXTURE_2D, 0, GL_LUMINANCE, (GLsizei) m_width, (GLsizei) m_height, 0,
GL_LUMINANCE, GL_UNSIGNED_BYTE, m_pDataY.get());
glActiveTexture(GL_TEXTURE1);
glBindTexture(GL_TEXTURE_2D, m_textureIdU);
glTexImage2D(GL_TEXTURE_2D, 0, GL_LUMINANCE, (GLsizei) m_width / 2, (GLsizei) m_height / 2,
0,
GL_LUMINANCE, GL_UNSIGNED_BYTE, m_pDataU);
glActiveTexture(GL_TEXTURE2);
glBindTexture(GL_TEXTURE_2D, m_textureIdV);
glTexImage2D(GL_TEXTURE_2D, 0, GL_LUMINANCE, (GLsizei) m_width / 2, (GLsizei) m_height / 2,
0,
GL_LUMINANCE, GL_UNSIGNED_BYTE, m_pDataV);
isDirty = false;
return true;
}
return false;
}
int
EGLSurfaceViewVideoRender::createProgram() {
m_program = openGlShader->createProgram();
m_vertexShader = openGlShader->vertexShader;
m_pixelShader = openGlShader->fraShader;
LOGI("EGLSurfaceViewVideoRender createProgram m_program:%d", m_program);
if (!m_program) {
LOGE("Could not create program.");
return 0;
}
//Get Uniform Variables Location
m_vertexPos = (GLuint) glGetAttribLocation(m_program, "position");
m_textureYLoc = glGetUniformLocation(m_program, "s_textureY");
m_textureULoc = glGetUniformLocation(m_program, "s_textureU");
m_textureVLoc = glGetUniformLocation(m_program, "s_textureV");
m_textureLoc = (GLuint) glGetAttribLocation(m_program, "texcoord");
m_textureSize = glGetUniformLocation(m_program, "texSize");
return m_program;
}
GLuint EGLSurfaceViewVideoRender::useProgram() {
if (!m_program && !createProgram()) {
LOGE("Could not use program.");
return 0;
}
if (isProgramChanged) {
glUseProgram(m_program);
glVertexAttribPointer(m_vertexPos, 2, GL_FLOAT, GL_FALSE, 0, EGLVerticek);
glEnableVertexAttribArray(m_vertexPos);
glUniform1i(m_textureYLoc, 0);
glUniform1i(m_textureULoc, 1);
glUniform1i(m_textureVLoc, 2);
glVertexAttribPointer(m_textureLoc, 2, GL_FLOAT, GL_FALSE, 0, EGLTextureCoord);
glEnableVertexAttribArray(m_textureLoc);
if (m_textureSize >= 0) {
GLfloat size[2];
size[0] = m_width;
size[1] = m_height;
glUniform2fv(m_textureSize, 1, &size[0]);
}
isProgramChanged = false;
}
return m_program;
}
bool
EGLSurfaceViewVideoRender::setSharderPath(const char *vertexPath, const char *fragmentPath) {
openGlShader->getSharderPath(vertexPath, fragmentPath);
return 0;
}
bool EGLSurfaceViewVideoRender::setSharderStringPath(string vertexPath, string fragmentPath) {
openGlShader->getSharderStringPath(vertexPath, fragmentPath);
return 0;
}
EGLSurfaceViewVideoRender::EGLSurfaceViewVideoRender() {
openGlShader = new OpenGLShader();
}
EGLSurfaceViewVideoRender::~EGLSurfaceViewVideoRender() {
deleteTextures();
delete_program(m_program);
m_vertexShader = 0;
m_pixelShader = 0;
if (m_pDataY) {
m_pDataY = nullptr;
}
if (m_pDataU) {
delete m_pDataU;
m_pDataU = nullptr;
}
if (m_pDataV) {
delete m_pDataV;
m_pDataV = nullptr;
}
if (openGlShader) {
delete openGlShader;
openGlShader = nullptr;
}
if (display) {
display = nullptr;
}
if (winsurface) {
winsurface = nullptr;
}
if (m_EglCore) {
delete m_EglCore;
m_EglCore = nullptr;
}
if (m_WindowSurface) {
delete m_WindowSurface;
m_WindowSurface = nullptr;
}
quit();
}
void EGLSurfaceViewVideoRender::delete_program(GLuint &program) {
if (program) {
glUseProgram(0);
glDeleteProgram(program);
program = 0;
}
}
void EGLSurfaceViewVideoRender::deleteTextures() {
if (m_textureIdY) {
glActiveTexture(GL_TEXTURE0);
glBindTexture(GL_TEXTURE_2D, 0);
glDeleteTextures(1, &m_textureIdY);
m_textureIdY = 0;
}
if (m_textureIdU) {
glActiveTexture(GL_TEXTURE1);
glBindTexture(GL_TEXTURE_2D, 0);
glDeleteTextures(1, &m_textureIdU);
m_textureIdU = 0;
}
if (m_textureIdV) {
glActiveTexture(GL_TEXTURE2);
glBindTexture(GL_TEXTURE_2D, 0);
glDeleteTextures(1, &m_textureIdV);
m_textureIdV = 0;
}
}
void EGLSurfaceViewVideoRender::handleMessage(LooperMessage *msg) {
Looper::handleMessage(msg);
switch (msg->what) {
case MSG_SurfaceCreated: {
LOGE("EGLSurfaceViewVideoRender::handleMessage MSG_SurfaceCreated");
OnSurfaceCreated();
}
break;
case MSG_SurfaceChanged:
LOGE("EGLSurfaceViewVideoRender::handleMessage MSG_SurfaceChanged");
OnSurfaceChanged(msg->arg1, msg->arg2);
break;
case MSG_DrawFrame:
// LOGE("EGLSurfaceViewVideoRender::handleMessage MSG_DrawFrame");
OnDrawFrame();
break;
case MSG_SurfaceDestroyed:
LOGE("EGLSurfaceViewVideoRender::handleMessage MSG_SurfaceDestroyed");
OnSurfaceDestroyed();
break;
default:
break;
}
}
void EGLSurfaceViewVideoRender::OnSurfaceCreated() {
m_EglCore = new EglCore(eglGetCurrentContext(), FLAG_RECORDABLE);
if (!m_EglCore) {
LOGE("new EglCore failed!");
return;
}
LOGE("OnSurfaceCreated m_ANWindow:%p", m_ANWindow);
m_WindowSurface = new WindowSurface(m_EglCore, m_ANWindow);
if (!m_EglCore) {
LOGE("new WindowSurface failed!");
return;
}
m_WindowSurface->makeCurrent();
}
void EGLSurfaceViewVideoRender::OnSurfaceChanged(int w, int h) {
m_backingWidth = w;
m_backingHeight = h;
LOGE("OnSurfaceChanged m_backingWidth:%d,m_backingHeight:%d", m_backingWidth, m_backingHeight);
float windowAspect = (float) m_backingHeight / (float) m_backingWidth;
size_t outWidth, outHeight;
if (VIDEO_HEIGHT > VIDEO_WIDTH * windowAspect) {
// limited by narrow width; reduce height
outWidth = VIDEO_WIDTH;
outHeight = (int) (VIDEO_WIDTH * windowAspect);
} else {
// limited by short height; restrict width
outHeight = VIDEO_HEIGHT;
outWidth = (int) (VIDEO_HEIGHT / windowAspect);
}
LOGE(" outWidth:%d,outHeight:%d", outWidth, outHeight);
offX = (VIDEO_WIDTH - outWidth) / 2;
offY = (VIDEO_HEIGHT - outHeight) / 2;
off_right = offX + outWidth;
off_bottom = offY + outHeight;
//Adjusting window 1920x1104 to +14,+0 1252x720
LOGE("Adjusting window offX:%d,offY:%d,off_right:%d,off_bottom:%d", offX, offY, off_right,
off_bottom);
useProgram();
createTextures();
}
void EGLSurfaceViewVideoRender::OnDrawFrame() {
glClear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT);
glClearColor(0.0f, 0.0f, 0.0f, 1.0f);
if (!updateTextures() || !useProgram()) return;
//窗口显示
glDrawArrays(GL_TRIANGLE_STRIP, 0, 4);
LOGE("OnDrawFrame thread:%ld", pthread_self());
//切换到m_WindowSurface
m_WindowSurface->makeCurrent();
m_WindowSurface->swapBuffers();
}
void EGLSurfaceViewVideoRender::OnSurfaceDestroyed() {
m_vertexShader = 0;
m_pixelShader = 0;
if (m_pDataY) {
m_pDataY = nullptr;
}
if (m_pDataU) {
m_pDataU = nullptr;
}
if (m_pDataV) {
m_pDataV = nullptr;
}
if (openGlShader) {
delete openGlShader;
openGlShader = nullptr;
}
if (display) {
display = nullptr;
}
if (winsurface) {
winsurface = nullptr;
}
if (m_EglCore) {
delete m_EglCore;
m_EglCore = nullptr;
}
if (m_WindowSurface) {
delete m_WindowSurface;
m_WindowSurface = nullptr;
}
quit();
}
void EGLSurfaceViewVideoRender::printGLString(const char *name, GLenum s) {
const char *v = (const char *) glGetString(s);
LOGI("OpenGL %s = %s\n", name, v);
}
void EGLSurfaceViewVideoRender::checkGlError(const char *op) {
for (GLint error = glGetError(); error; error = glGetError()) {
LOGI("after %s() glError (0x%x)\n", op, error);
}
}三、FFmpeg解码视频数据OpenGL Texture播放：
承接上一篇文章 FFmpeg解码视频数据ANativeWindow播放 中的FFmpeg解码及渲染分开两个线程的思路，把OpenGL Texture的初始化及对获取到队列中的AVFrame进行渲染的过程进行替换平替。
initEGLRender()替换原有的initANativeWindow()，sendFrameDataToEGL()替换原因的sendFrameDataToANativeWindow()，不用改变其他的流程来实现。
FFmpeg初始化：
代码如下：
cpp
bool FFGLPlayer::initFFmpeg(const std::string &filePath) {
if (avformat_open_input(&mFormatContext, filePath.c_str(), nullptr, nullptr) != 0) {
LOGE("Could not open file: %s", filePath.c_str());
return false;
}
if (avformat_find_stream_info(mFormatContext, nullptr) < 0) {
LOGE("Could not find stream information");
avformat_close_input(&mFormatContext);
return false;
}
mVideoStreamIndex = -1;
for (unsigned int i = 0; i < mFormatContext->nb_streams; i++) {
if (mFormatContext->streams[i]->codecpar->codec_type == AVMEDIA_TYPE_VIDEO) {
mVideoStreamIndex = i;
break;
}
}
if (mVideoStreamIndex == -1) {
LOGE("Could not find video stream");
avformat_close_input(&mFormatContext);
return false;
}
AVCodecParameters *codecParams = mFormatContext->streams[mVideoStreamIndex]->codecpar;
const AVCodec *codec = avcodec_find_decoder(codecParams->codec_id);
if (!codec) {
LOGE("Unsupported codec");
avformat_close_input(&mFormatContext);
return false;
}
mCodecContext = avcodec_alloc_context3(codec);
if (!mCodecContext) {
LOGE("Could not allocate codec context");
avformat_close_input(&mFormatContext);
return false;
}
if (avcodec_parameters_to_context(mCodecContext, codecParams) < 0) {
LOGE("Could not copy codec parameters");
cleanupFFmpeg();
return false;
}
if (avcodec_open2(mCodecContext, codec, nullptr) < 0) {
LOGE("Could not open codec");
cleanupFFmpeg();
return false;
}
mWidth = mCodecContext->width;
mHeight = mCodecContext->height;
mSampleFormat = mCodecContext->sample_fmt;
mDuration = mFormatContext->duration;
LOGI("GLPlay FFmpeg initialized width: %d, height: %d, duration: %lld",
mWidth, mHeight, mDuration);
playMediaInfo = "FFmpeg initialized, width:" + std::to_string(mWidth) +
", height:" + std::to_string(mHeight) +
", duration:" + std::to_string(mDuration) + "\n";
PostStatusMessage(playMediaInfo.c_str());
return true;
}GL环境的初始化：
代码如下：
cpp
bool FFGLPlayer::initEGLRender(const string &fragPath, const string &vertexPath) {
mNativeWindow = ANativeWindow_fromSurface(mEnv, androidSurface);
if (!mNativeWindow) {
LOGE("Couldn't get native window from surface");
return false;
}
eglsurfaceViewRender->surfaceCreated(mNativeWindow, nullptr);
eglsurfaceViewRender->setSharderStringPath(vertexPath, fragPath);
eglsurfaceViewRender->surfaceChanged(mWidth, mHeight);
return true;
}解码线程：
代码如下：
cpp
void FFGLPlayer::decodeThread() {
AVPacket packet;
AVFrame *frame = av_frame_alloc();
int ret;
if (!frame) {
LOGE("Could not allocate frame");
return;
}
LOGI("Decode thread started");
PostStatusMessage("Decode thread started");
while (!mStopRequested && mIsPlaying) {
pthread_mutex_lock(&mDecodeMutex);
// 当队列达到最大时，解码等待。
while (videoFrameQueue.size() >= maxVideoFrames && !mStopRequested && mIsPlaying) {
LOGD("Waiting for buffer slot, queued: %zu", videoFrameQueue.size());
playMediaInfo =
"Waiting for buffer slot, queued:" + to_string(videoFrameQueue.size()) + " \n";
PostStatusMessage(playMediaInfo.c_str());
pthread_cond_wait(&mBufferMaxCond, &mDecodeMutex);
}
if (mStopRequested || !mIsPlaying) {
pthread_mutex_unlock(&mDecodeMutex);
break;
}
ret = av_read_frame(mFormatContext, &packet);
if (ret < 0) {
pthread_mutex_unlock(&mDecodeMutex);
if (ret == AVERROR_EOF) {
LOGI("End of file reached");
break;
} else {
LOGE("Error reading frame: %d", ret);
usleep(10000);
continue;
}
}
if (packet.stream_index == mVideoStreamIndex) {
ret = avcodec_send_packet(mCodecContext, &packet);
if (ret < 0) {
LOGE("Error sending packet to decoder: %d", ret);
av_packet_unref(&packet);
pthread_mutex_unlock(&mDecodeMutex);
continue;
}
while (avcodec_receive_frame(mCodecContext, frame) == 0) {
AVFrame *frameCopy = av_frame_alloc();
if (!frameCopy) {
LOGE("Could not allocate frame copy");
continue;
}
if (av_frame_ref(frameCopy, frame) >= 0) {
videoFrameQueue.push(frameCopy);
pthread_cond_signal(&mRenderCond);
} else {
av_frame_free(&frameCopy);
pthread_mutex_unlock(&mDecodeMutex);
}
}
}
av_packet_unref(&packet);
pthread_mutex_unlock(&mDecodeMutex);
}
av_frame_free(&frame);
LOGI("Decode thread finished");
}渲染线程：
代码如下：
cpp
void FFGLPlayer::renderVideoThread() {
LOGI("Render thread started");
PostStatusMessage("Render thread started \n");
AVRational timeBase = mFormatContext->streams[mVideoStreamIndex]->time_base;
int64_t lastPts = AV_NOPTS_VALUE;
while (!mStopRequested && mIsPlaying) {
pthread_mutex_lock(&mRenderMutex);
while (videoFrameQueue.empty() && !mStopRequested && mIsPlaying) {
pthread_cond_wait(&mRenderCond, &mRenderMutex);
}
if (mStopRequested || !mIsPlaying) {
pthread_mutex_unlock(&mRenderMutex);
break;
}
if (!videoFrameQueue.empty()) {
std::shared_ptr<AVFrame *> framePtr = videoFrameQueue.pop();
AVFrame *frame = *framePtr;
pthread_mutex_unlock(&mRenderMutex);
// 基于时间戳的帧率控制
if (lastPts != AV_NOPTS_VALUE && frame->pts != AV_NOPTS_VALUE) {
int64_t ptsDiff = frame->pts - lastPts;
double timeDiff = av_q2d(timeBase) * ptsDiff * 1000000; // 转换为微秒
if (timeDiff > 0 && timeDiff < 1000000) { // 合理的帧间隔
usleep(static_cast<useconds_t>(timeDiff));
}
}
lastPts = frame->pts;
sendFrameDataToEGL(frame);
// 通知解码线程
if (videoFrameQueue.size() < maxVideoFrames / 2) {
pthread_cond_signal(&mBufferMaxCond);
}
} else {
pthread_mutex_unlock(&mRenderMutex);
}
}
LOGI("Render thread finished");
}sendFrameDataToEGL方法：
这里要做一个数据转换把AVFrame转换成 EGLSurfaceViewVideoRender渲染时draw()方法所需要的uint8_t *buffer数据。
数据转换过程如下：
cpp
int FFGLPlayer::yuv420p_frame_to_buffer(AVFrame *frame, uint8_t **buffer, int *length) {
if (!frame || frame->format != AV_PIX_FMT_YUV420P) return -1;
int width = frame->width;
int height = frame->height;
int y_size = width * height;
int uv_size = y_size / 4;
*length = y_size + uv_size * 2;
*buffer = (uint8_t *) av_malloc(*length);
if (!*buffer) return -1;
uint8_t *dst = *buffer;
// 复制Y平面
for (int y = 0; y < height; y++) {
memcpy(dst, frame->data[0] + y * frame->linesize[0], width);
dst += width;
}
// 复制U平面
for (int y = 0; y < height / 2; y++) {
memcpy(dst, frame->data[1] + y * frame->linesize[1], width / 2);
dst += width / 2;
}
// 复制V平面
for (int y = 0; y < height / 2; y++) {
memcpy(dst, frame->data[2] + y * frame->linesize[2], width / 2);
dst += width / 2;
}
return 0;
}sendFrameDataToEGL()方法代码如下：
cpp
int FFGLPlayer::sendFrameDataToEGL(AVFrame *frame) {
if (!mNativeWindow || !frame) {
return -1;
}
LOGI("sendFrameDataToEGL");
uint8_t *buffer;
int length;
yuv420p_frame_to_buffer(frame, &buffer, &length);
eglsurfaceViewRender->draw(buffer, length, mWidth, mHeight, 90);
eglsurfaceViewRender->render();
return 0;
}FFGLPlayer完整代码：
FFGLPlayer.h代码：
cpp
// Author : wangyongyao https://github.com/wangyongyao1989
// Created by MMM on 2025/12/6.
//
#ifndef FFMPEGPRACTICE_FFGLPLAYER_H
#define FFMPEGPRACTICE_FFGLPLAYER_H
#include <pthread.h>
#include <atomic>
#include <string>
#include "ThreadSafeQueue.h"
#include "BasicCommon.h"
#include "jni.h"
#include "android/native_window.h"
#include "android/native_window_jni.h"
#include "EGLSurfaceViewVideoRender.h"
class FFGLPlayer {
public:
FFGLPlayer(JNIEnv *env, jobject thiz);
~FFGLPlayer();
// 初始化播放器
bool
init(const string &filePath, const string &fragPath, const string &vertexPath, jobject surface);
// 开始播放
bool start();
// 暂停播放
bool pause();
// 停止播放
void stop();
// 获取播放状态
bool isPlaying() const { return mIsPlaying; }
bool isInitialized() const { return mInitialized; }
private:
string playMediaInfo;
JavaVM *mJavaVm = nullptr;
jobject mJavaObj = nullptr;
JNIEnv *mEnv = nullptr;
int mWidth;
int mHeight;
uint8_t *mOutbuffer;
jobject androidSurface = NULL;
// NativeWindow;
ANativeWindow *mNativeWindow = nullptr;
// EGLRender
EGLSurfaceViewVideoRender *eglsurfaceViewRender;
// FFmpeg 相关
AVFormatContext *mFormatContext;
AVCodecContext *mCodecContext;
int mVideoStreamIndex;
int64_t mDuration;
AVSampleFormat mSampleFormat;
// 播放状态
std::atomic<bool> mIsPlaying;
std::atomic<bool> mInitialized;
std::atomic<bool> mStopRequested;
// 视频帧队列
ThreadSafeQueue<AVFrame *> videoFrameQueue;
int maxVideoFrames = 50;
// 线程同步
pthread_t mDecodeThread;
pthread_t mRenderThread;
pthread_mutex_t mDecodeMutex;
pthread_cond_t mBufferMaxCond;
pthread_cond_t mRenderCond;
pthread_mutex_t mRenderMutex;
// 私有方法
bool initFFmpeg(const std::string &filePath);
bool initEGLRender(const string &fragPath, const string &vertexPath);
static void *decodeThreadWrapper(void *context);
void decodeThread();
static void *renderVideoFrame(void *context);
void renderVideoThread();
int sendFrameDataToEGL(AVFrame *frame);
int yuv420p_frame_to_buffer(AVFrame *frame, uint8_t **buffer, int *length);
void cleanup();
void cleanupFFmpeg();
JNIEnv *GetJNIEnv(bool *isAttach);
void PostStatusMessage(const char *msg);
};
#endif //FFMPEGPRACTICE_FFGLPLAYER_HFFGLPlayer.cpp代码：
cpp
// Author : wangyongyao https://github.com/wangyongyao1989
// Created by MMM on 2025/12/6.
//
#include "FFGLPlayer.h"
#include <unistd.h>
FFGLPlayer::FFGLPlayer(JNIEnv *env, jobject thiz)
: mEnv(nullptr), mJavaObj(nullptr), mFormatContext(nullptr),
mCodecContext(nullptr), mVideoStreamIndex(-1), mDuration(0),
mSampleFormat(AV_SAMPLE_FMT_NONE), mWidth(0), mHeight(0),
mIsPlaying(false), mInitialized(false), mStopRequested(false),
mNativeWindow(nullptr),
mOutbuffer(nullptr), mDecodeThread(0), mRenderThread(0) {
mEnv = env;
env->GetJavaVM(&mJavaVm);
mJavaObj = env->NewGlobalRef(thiz);
eglsurfaceViewRender = new EGLSurfaceViewVideoRender();
pthread_mutex_init(&mDecodeMutex, nullptr);
pthread_mutex_init(&mRenderMutex, nullptr);
pthread_cond_init(&mBufferMaxCond, nullptr);
pthread_cond_init(&mRenderCond, nullptr);
}
FFGLPlayer::~FFGLPlayer() {
stop();
cleanup();
pthread_mutex_destroy(&mDecodeMutex);
pthread_mutex_destroy(&mRenderMutex);
pthread_cond_destroy(&mBufferMaxCond);
pthread_cond_destroy(&mRenderCond);
if (androidSurface) {
mEnv->DeleteLocalRef(androidSurface);
}
if (mNativeWindow) {
ANativeWindow_release(mNativeWindow);
mNativeWindow = nullptr;
}
if (mOutbuffer) {
av_free(mOutbuffer);
mOutbuffer = nullptr;
}
if (eglsurfaceViewRender) {
eglsurfaceViewRender = nullptr;
}
mEnv->DeleteGlobalRef(mJavaObj);
}
bool FFGLPlayer::init(const string &filePath, const string &fragPath, const string &vertexPath,
jobject surface) {
if (mInitialized) {
LOGI("Already initialized");
return true;
}
androidSurface = mEnv->NewGlobalRef(surface);
if (!initFFmpeg(filePath)) {
LOGE("Failed to initialize FFmpeg");
PostStatusMessage("Failed to initialize FFmpeg");
return false;
}
if (!initEGLRender(fragPath, vertexPath)) {
LOGE("Failed to initialize initEGLRender");
PostStatusMessage("Failed to initialize initEGLRender");
cleanupFFmpeg();
return false;
}
mInitialized = true;
LOGI("FFGLPlayer initialized successfully");
PostStatusMessage("FFGLPlayer initialized successfully");
return true;
}
bool FFGLPlayer::initFFmpeg(const std::string &filePath) {
if (avformat_open_input(&mFormatContext, filePath.c_str(), nullptr, nullptr) != 0) {
LOGE("Could not open file: %s", filePath.c_str());
return false;
}
if (avformat_find_stream_info(mFormatContext, nullptr) < 0) {
LOGE("Could not find stream information");
avformat_close_input(&mFormatContext);
return false;
}
mVideoStreamIndex = -1;
for (unsigned int i = 0; i < mFormatContext->nb_streams; i++) {
if (mFormatContext->streams[i]->codecpar->codec_type == AVMEDIA_TYPE_VIDEO) {
mVideoStreamIndex = i;
break;
}
}
if (mVideoStreamIndex == -1) {
LOGE("Could not find video stream");
avformat_close_input(&mFormatContext);
return false;
}
AVCodecParameters *codecParams = mFormatContext->streams[mVideoStreamIndex]->codecpar;
const AVCodec *codec = avcodec_find_decoder(codecParams->codec_id);
if (!codec) {
LOGE("Unsupported codec");
avformat_close_input(&mFormatContext);
return false;
}
mCodecContext = avcodec_alloc_context3(codec);
if (!mCodecContext) {
LOGE("Could not allocate codec context");
avformat_close_input(&mFormatContext);
return false;
}
if (avcodec_parameters_to_context(mCodecContext, codecParams) < 0) {
LOGE("Could not copy codec parameters");
cleanupFFmpeg();
return false;
}
if (avcodec_open2(mCodecContext, codec, nullptr) < 0) {
LOGE("Could not open codec");
cleanupFFmpeg();
return false;
}
mWidth = mCodecContext->width;
mHeight = mCodecContext->height;
mSampleFormat = mCodecContext->sample_fmt;
mDuration = mFormatContext->duration;
LOGI("GLPlay FFmpeg initialized width: %d, height: %d, duration: %lld",
mWidth, mHeight, mDuration);
playMediaInfo = "FFmpeg initialized, width:" + std::to_string(mWidth) +
", height:" + std::to_string(mHeight) +
", duration:" + std::to_string(mDuration) + "\n";
PostStatusMessage(playMediaInfo.c_str());
return true;
}
bool FFGLPlayer::initEGLRender(const string &fragPath, const string &vertexPath) {
mNativeWindow = ANativeWindow_fromSurface(mEnv, androidSurface);
if (!mNativeWindow) {
LOGE("Couldn't get native window from surface");
return false;
}
eglsurfaceViewRender->surfaceCreated(mNativeWindow, nullptr);
eglsurfaceViewRender->setSharderStringPath(vertexPath, fragPath);
eglsurfaceViewRender->surfaceChanged(mWidth, mHeight);
return true;
}
bool FFGLPlayer::start() {
if (!mInitialized) {
LOGE("Player not initialized");
PostStatusMessage("Player not initialized \n");
return false;
}
pthread_mutex_lock(&mDecodeMutex);
if (mIsPlaying) {
return true;
}
mStopRequested = false;
mIsPlaying = true;
videoFrameQueue.clear();
if (pthread_create(&mDecodeThread, nullptr, decodeThreadWrapper, this) != 0) {
LOGE("Failed to create decode thread");
PostStatusMessage("Failed to create decode thread");
mIsPlaying = false;
return false;
}
if (pthread_create(&mRenderThread, nullptr, renderVideoFrame, this) != 0) {
LOGE("Failed to create render thread");
PostStatusMessage("Failed to create render thread");
mIsPlaying = false;
mStopRequested = true;
pthread_join(mDecodeThread, nullptr);
mDecodeThread = 0;
return false;
}
pthread_mutex_unlock(&mDecodeMutex);
LOGI("Playback started");
PostStatusMessage("Playback started");
return true;
}
void FFGLPlayer::stop() {
if (!mInitialized) {
return;
}
mStopRequested = true;
mIsPlaying = false;
// 通知所有等待的线程
pthread_cond_broadcast(&mBufferMaxCond);
pthread_cond_broadcast(&mRenderCond);
// 等待解码线程结束
if (mDecodeThread) {
pthread_join(mDecodeThread, nullptr);
mDecodeThread = 0;
}
// 等待解码线程结束
if (mRenderThread) {
pthread_join(mRenderThread, nullptr);
mRenderThread = 0;
}
videoFrameQueue.clear();
LOGI("Playback stopped");
PostStatusMessage("Playback stopped");
}
void *FFGLPlayer::decodeThreadWrapper(void *context) {
FFGLPlayer *player = static_cast<FFGLPlayer *>(context);
player->decodeThread();
return nullptr;
}
void FFGLPlayer::decodeThread() {
AVPacket packet;
AVFrame *frame = av_frame_alloc();
int ret;
if (!frame) {
LOGE("Could not allocate frame");
return;
}
LOGI("Decode thread started");
PostStatusMessage("Decode thread started");
while (!mStopRequested && mIsPlaying) {
pthread_mutex_lock(&mDecodeMutex);
// 当队列达到最大时，解码等待。
while (videoFrameQueue.size() >= maxVideoFrames && !mStopRequested && mIsPlaying) {
LOGD("Waiting for buffer slot, queued: %zu", videoFrameQueue.size());
playMediaInfo =
"Waiting for buffer slot, queued:" + to_string(videoFrameQueue.size()) + " \n";
PostStatusMessage(playMediaInfo.c_str());
pthread_cond_wait(&mBufferMaxCond, &mDecodeMutex);
}
if (mStopRequested || !mIsPlaying) {
pthread_mutex_unlock(&mDecodeMutex);
break;
}
ret = av_read_frame(mFormatContext, &packet);
if (ret < 0) {
pthread_mutex_unlock(&mDecodeMutex);
if (ret == AVERROR_EOF) {
LOGI("End of file reached");
break;
} else {
LOGE("Error reading frame: %d", ret);
usleep(10000);
continue;
}
}
if (packet.stream_index == mVideoStreamIndex) {
ret = avcodec_send_packet(mCodecContext, &packet);
if (ret < 0) {
LOGE("Error sending packet to decoder: %d", ret);
av_packet_unref(&packet);
pthread_mutex_unlock(&mDecodeMutex);
continue;
}
while (avcodec_receive_frame(mCodecContext, frame) == 0) {
AVFrame *frameCopy = av_frame_alloc();
if (!frameCopy) {
LOGE("Could not allocate frame copy");
continue;
}
if (av_frame_ref(frameCopy, frame) >= 0) {
videoFrameQueue.push(frameCopy);
pthread_cond_signal(&mRenderCond);
} else {
av_frame_free(&frameCopy);
pthread_mutex_unlock(&mDecodeMutex);
}
}
}
av_packet_unref(&packet);
pthread_mutex_unlock(&mDecodeMutex);
}
av_frame_free(&frame);
LOGI("Decode thread finished");
}
void *FFGLPlayer::renderVideoFrame(void *context) {
FFGLPlayer *player = static_cast<FFGLPlayer *>(context);
player->renderVideoThread();
return nullptr;
}
void FFGLPlayer::renderVideoThread() {
LOGI("Render thread started");
PostStatusMessage("Render thread started \n");
AVRational timeBase = mFormatContext->streams[mVideoStreamIndex]->time_base;
int64_t lastPts = AV_NOPTS_VALUE;
while (!mStopRequested && mIsPlaying) {
pthread_mutex_lock(&mRenderMutex);
while (videoFrameQueue.empty() && !mStopRequested && mIsPlaying) {
pthread_cond_wait(&mRenderCond, &mRenderMutex);
}
if (mStopRequested || !mIsPlaying) {
pthread_mutex_unlock(&mRenderMutex);
break;
}
if (!videoFrameQueue.empty()) {
std::shared_ptr<AVFrame *> framePtr = videoFrameQueue.pop();
AVFrame *frame = *framePtr;
pthread_mutex_unlock(&mRenderMutex);
// 基于时间戳的帧率控制
if (lastPts != AV_NOPTS_VALUE && frame->pts != AV_NOPTS_VALUE) {
int64_t ptsDiff = frame->pts - lastPts;
double timeDiff = av_q2d(timeBase) * ptsDiff * 1000000; // 转换为微秒
if (timeDiff > 0 && timeDiff < 1000000) { // 合理的帧间隔
usleep(static_cast<useconds_t>(timeDiff));
}
}
lastPts = frame->pts;
sendFrameDataToEGL(frame);
// 通知解码线程
if (videoFrameQueue.size() < maxVideoFrames / 2) {
pthread_cond_signal(&mBufferMaxCond);
}
} else {
pthread_mutex_unlock(&mRenderMutex);
}
}
LOGI("Render thread finished");
}
int FFGLPlayer::sendFrameDataToEGL(AVFrame *frame) {
if (!mNativeWindow || !frame) {
return -1;
}
LOGI("sendFrameDataToEGL");
uint8_t *buffer;
int length;
yuv420p_frame_to_buffer(frame, &buffer, &length);
eglsurfaceViewRender->draw(buffer, length, mWidth, mHeight, 90);
eglsurfaceViewRender->render();
return 0;
}
void FFGLPlayer::cleanup() {
cleanupFFmpeg();
mIsPlaying = false;
mInitialized = false;
}
void FFGLPlayer::cleanupFFmpeg() {
if (mCodecContext) {
avcodec_close(mCodecContext);
avcodec_free_context(&mCodecContext);
mCodecContext = nullptr;
}
if (mFormatContext) {
avformat_close_input(&mFormatContext);
mFormatContext = nullptr;
}
mVideoStreamIndex = -1;
}
JNIEnv *FFGLPlayer::GetJNIEnv(bool *isAttach) {
if (!mJavaVm) {
LOGE("GetJNIEnv mJavaVm == nullptr");
return nullptr;
}
JNIEnv *env;
int status = mJavaVm->GetEnv((void **) &env, JNI_VERSION_1_6);
if (status == JNI_EDETACHED) {
status = mJavaVm->AttachCurrentThread(&env, nullptr);
if (status != JNI_OK) {
LOGE("Failed to attach current thread");
return nullptr;
}
*isAttach = true;
} else if (status != JNI_OK) {
LOGE("Failed to get JNIEnv");
return nullptr;
} else {
*isAttach = false;
}
return env;
}
void FFGLPlayer::PostStatusMessage(const char *msg) {
bool isAttach = false;
JNIEnv *env = GetJNIEnv(&isAttach);
if (!env) {
return;
}
jmethodID mid = env->GetMethodID(env->GetObjectClass(mJavaObj),
"CppStatusCallback", "(Ljava/lang/String;)V");
if (mid) {
jstring jMsg = env->NewStringUTF(msg);
env->CallVoidMethod(mJavaObj, mid, jMsg);
env->DeleteLocalRef(jMsg);
}
if (isAttach) {
mJavaVm->DetachCurrentThread();
}
}
int FFGLPlayer::yuv420p_frame_to_buffer(AVFrame *frame, uint8_t **buffer, int *length) {
if (!frame || frame->format != AV_PIX_FMT_YUV420P) return -1;
int width = frame->width;
int height = frame->height;
int y_size = width * height;
int uv_size = y_size / 4;
*length = y_size + uv_size * 2;
*buffer = (uint8_t *) av_malloc(*length);
if (!*buffer) return -1;
uint8_t *dst = *buffer;
// 复制Y平面
for (int y = 0; y < height; y++) {
memcpy(dst, frame->data[0] + y * frame->linesize[0], width);
dst += width;
}
// 复制U平面
for (int y = 0; y < height / 2; y++) {
memcpy(dst, frame->data[1] + y * frame->linesize[1], width / 2);
dst += width / 2;
}
// 复制V平面
for (int y = 0; y < height / 2; y++) {
memcpy(dst, frame->data[2] + y * frame->linesize[2], width / 2);
dst += width / 2;
}
return 0;
}四、效果展示：
五、源码地址：
以上的代码放在本人的GitHub项目 ：
https://github.com/wangyongyao1989/FFmpegPractices
