Kubernetes完全指南：从集群搭建到生产部署

前言

当Docker容器数量从10个增长到1000个时，手动管理就变成了噩梦。我们迫切需要一个容器编排平台。

选择了Kubernetes后，我们实现了自动扩展、自我修复和灰度发布。这篇文章总结了我们的K8s实践。

一、为什么需要Kubernetes？

1.1 容器编排的需求

复制代码

手动管理的痛点：❌ 容器宕机无法自动重启❌ 无法自动扩展应对流量高峰❌ 无法实现零停机更新❌ 资源分配不均❌ 网络通信复杂❌ 存储管理困难Kubernetes解决方案：✅ 自动恢复：容器故障自动重启✅ 自动扩展：根据资源自动伸缩✅ 灰度发布：零停机更新✅ 负载均衡：智能调度✅ 服务发现：自动服务注册✅ 存储编排：多种存储支持

1.2 Kubernetes架构

复制代码

┌─────────────────────────────────────────┐│         Kubernetes Cluster              │├─────────────────────────────────────────┤│ Master Node (Control Plane)             ││ ├─ API Server                           ││ ├─ Scheduler                            ││ ├─ Controller Manager                   ││ └─ etcd (键值存储)                      │├─────────────────────────────────────────┤│ Worker Node 1      │ Worker Node 2      ││ ├─ Kubelet        │ ├─ Kubelet         ││ ├─ Container Runtime│ ├─ Container Runtime│ └─ Pods           │ └─ Pods            │└─────────────────────────────────────────┘

二、本地Kubernetes开发环境

2.1 安装Minikube

复制代码

bash

复制代码

# macOS安装Minikubebrew install minikube# 启动集群minikube start --cpus=4 --memory=8192# 查看集群状态kubectl cluster-infokubectl get nodes# 访问Kubernetes Dashboardminikube dashboard# 停止集群minikube stop# 删除集群minikube delete

2.2 安装kubectl

复制代码

bash

复制代码

# macOSbrew install kubectl# 验证安装kubectl version --client# 配置自动补全source <(kubectl completion bash)

三、Pod基础

3.1 创建第一个Pod

复制代码

yaml

复制代码

# pod.yamlapiVersion: v1kind: Podmetadata:  name: nginx-pod  labels:    app: web    tier: frontendspec:  containers:  - name: nginx    image: nginx:1.21    ports:    - containerPort: 80    resources:      requests:        cpu: 100m        memory: 128Mi      limits:        cpu: 500m        memory: 512Mi

复制代码

bash

复制代码

# 创建Podkubectl apply -f pod.yaml# 查看Podkubectl get podskubectl describe pod nginx-pod# 查看Pod日志kubectl logs nginx-pod# 进入Pod容器kubectl exec -it nginx-pod -- /bin/bash# 端口转发kubectl port-forward nginx-pod 8080:80# 删除Podkubectl delete pod nginx-pod

3.2 Pod生命周期

复制代码

yaml

复制代码

apiVersion: v1kind: Podmetadata:  name: lifecycle-podspec:  containers:  - name: app    image: myapp:latest        # 启动探针：检查容器是否启动成功    startupProbe:      httpGet:        path: /health/startup        port: 8000      initialDelaySeconds: 0      periodSeconds: 10      failureThreshold: 30        # 存活探针：检查容器是否仍在运行    livenessProbe:      httpGet:        path: /health/live        port: 8000      initialDelaySeconds: 10      periodSeconds: 10      failureThreshold: 3        # 就绪探针：检查容器是否已准备好接收流量    readinessProbe:      httpGet:        path: /health/ready        port: 8000      initialDelaySeconds: 5      periodSeconds: 5      failureThreshold: 1        # 启动时执行    lifecycle:      postStart:        exec:          command: ["/bin/sh", "-c", "echo 'Pod started' > /tmp/started.txt"]            # 停止前执行      preStop:        exec:          command: ["/bin/sh", "-c", "sleep 15"]  # 优雅关闭

四、Deployment管理应用

4.1 基础Deployment

复制代码

yaml

复制代码

# deployment.yamlapiVersion: apps/v1kind: Deploymentmetadata:  name: nginx-deployment  namespace: defaultspec:  replicas: 3  selector:    matchLabels:      app: nginx  template:    metadata:      labels:        app: nginx    spec:      containers:      - name: nginx        image: nginx:1.21        ports:        - containerPort: 80        resources:          requests:            cpu: 100m            memory: 128Mi          limits:            cpu: 500m            memory: 512Mi        volumeMounts:        - name: config          mountPath: /etc/nginx/conf.d      volumes:      - name: config        configMap:          name: nginx-config

复制代码

bash

复制代码

# 创建Deploymentkubectl apply -f deployment.yaml# 查看Deploymentkubectl get deploymentkubectl describe deployment nginx-deployment# 查看ReplicaSetkubectl get replicaset# 查看所有Podkubectl get pods -o wide# 扩展副本数kubectl scale deployment nginx-deployment --replicas=5# 更新镜像kubectl set image deployment/nginx-deployment nginx=nginx:1.22# 查看更新历史kubectl rollout history deployment/nginx-deployment# 回滚到上一个版本kubectl rollout undo deployment/nginx-deployment# 回滚到指定版本kubectl rollout undo deployment/nginx-deployment --to-revision=2

4.2 更新策略

复制代码

yaml

复制代码

apiVersion: apps/v1kind: Deploymentmetadata:  name: app-deploymentspec:  replicas: 10  strategy:    # 滚动更新（默认）    type: RollingUpdate    rollingUpdate:      maxSurge: 2        # 最多超出2个Pod      maxUnavailable: 1  # 最多有1个Pod不可用    # 或者使用蓝绿部署  # type: Recreate  # 先删除所有旧Pod，再启动新Pod    selector:    matchLabels:      app: myapp  template:    metadata:      labels:        app: myapp    spec:      containers:      - name: app        image: myapp:v1

五、Service服务发现

5.1 ClusterIP服务

复制代码

yaml

复制代码

# service.yamlapiVersion: v1kind: Servicemetadata:  name: nginx-servicespec:  type: ClusterIP  selector:    app: nginx  ports:  - port: 80              # 服务端口    targetPort: 80        # Pod端口    protocol: TCP

5.2 NodePort服务

复制代码

yaml

复制代码

apiVersion: v1kind: Servicemetadata:  name: nginx-nodeportspec:  type: NodePort  selector:    app: nginx  ports:  - port: 80              # 集群内端口    targetPort: 80        # Pod端口    nodePort: 30080       # 节点端口（30000-32767）

复制代码

bash

复制代码

# 访问服务# 从Pod内访问kubectl exec -it pod-name -- curl http://nginx-service# 从外部访问NodePortcurl http://node-ip:30080

5.3 LoadBalancer服务

复制代码

yaml

复制代码

apiVersion: v1kind: Servicemetadata:  name: nginx-lbspec:  type: LoadBalancer  selector:    app: nginx  ports:  - port: 80    targetPort: 80

六、Ingress流量管理

6.1 安装Ingress Controller

复制代码

bash

复制代码

# 安装Nginx Ingress Controllerkubectl apply -f https://raw.githubusercontent.com/kubernetes/ingress-nginx/controller-v1.0.0/deploy/static/provider/cloud/deploy.yaml# 验证安装kubectl get pods -n ingress-nginx

6.2 配置Ingress规则

复制代码

yaml

复制代码

# ingress.yamlapiVersion: networking.k8s.io/v1kind: Ingressmetadata:  name: app-ingressspec:  ingressClassName: nginx  rules:  # 基于主机名的路由  - host: api.example.com    http:      paths:      - path: /        pathType: Prefix        backend:          service:            name: api-service            port:              number: 8000    # 基于路径的路由  - host: example.com    http:      paths:      - path: /api        pathType: Prefix        backend:          service:            name: api-service            port:              number: 8000      - path: /web        pathType: Prefix        backend:          service:            name: web-service            port:              number: 80    # HTTPS配置  tls:  - hosts:    - example.com    - api.example.com    secretName: example-tls

复制代码

bash

复制代码

# 创建TLS证书kubectl create secret tls example-tls \  --cert=path/to/tls.crt \  --key=path/to/tls.key# 查看Ingresskubectl get ingresskubectl describe ingress app-ingress

七、ConfigMap和Secret

7.1 ConfigMap配置管理

复制代码

yaml

复制代码

# configmap.yamlapiVersion: v1kind: ConfigMapmetadata:  name: app-configdata:  # 简单的键值对  DATABASE_HOST: postgres  DATABASE_PORT: "5432"    # 文件内容  nginx.conf: |    server {      listen 80;      location / {        proxy_pass http://backend;      }    }

复制代码

bash

复制代码

# 从文件创建ConfigMapkubectl create configmap app-config --from-file=./config/# 从键值对创建kubectl create configmap app-config \  --from-literal=DB_HOST=postgres \  --from-literal=DB_PORT=5432# 在Pod中使用ConfigMap

复制代码

yaml

复制代码

apiVersion: v1kind: Podmetadata:  name: app-podspec:  containers:  - name: app    image: myapp:latest        # 方式1：作为环境变量    env:    - name: DB_HOST      valueFrom:        configMapKeyRef:          name: app-config          key: DATABASE_HOST        # 方式2：挂载为文件    volumeMounts:    - name: config      mountPath: /etc/config    volumes:  - name: config    configMap:      name: app-config

7.2 Secret敏感信息管理

复制代码

yaml

复制代码

# secret.yamlapiVersion: v1kind: Secretmetadata:  name: app-secrettype: OpaquestringData:  # 注意：stringData中的值会自动Base64编码  DATABASE_PASSWORD: "secure-password"  API_KEY: "secret-key"

复制代码

bash

复制代码

# 从文件创建Secretkubectl create secret generic app-secret \  --from-file=./secrets/# 从键值对创建kubectl create secret generic app-secret \  --from-literal=db_password=secure-password# 查看Secret内容kubectl get secret app-secret -o yaml# 解码Secretkubectl get secret app-secret -o jsonpath='{.data.DATABASE_PASSWORD}' | base64 -d

复制代码

yaml

复制代码

apiVersion: v1kind: Podmetadata:  name: app-podspec:  containers:  - name: app    image: myapp:latest    env:    - name: DB_PASSWORD      valueFrom:        secretKeyRef:          name: app-secret          key: DATABASE_PASSWORD

八、持久化存储

8.1 PersistentVolume和PersistentVolumeClaim

复制代码

yaml

复制代码

# pv.yamlapiVersion: v1kind: PersistentVolumemetadata:  name: app-pvspec:  capacity:    storage: 10Gi  accessModes:    - ReadWriteOnce  storageClassName: standard  hostPath:    path: /data/app

复制代码

yaml

复制代码

# pvc.yamlapiVersion: v1kind: PersistentVolumeClaimmetadata:  name: app-pvcspec:  accessModes:    - ReadWriteOnce  storageClassName: standard  resources:    requests:      storage: 5Gi

复制代码

yaml

复制代码

# pod-with-pv.yamlapiVersion: v1kind: Podmetadata:  name: app-podspec:  containers:  - name: app    image: myapp:latest    volumeMounts:    - name: data      mountPath: /data  volumes:  - name: data    persistentVolumeClaim:      claimName: app-pvc

8.2 StatefulSet用于有状态应用

复制代码

yaml

复制代码

# statefulset.yamlapiVersion: apps/v1kind: StatefulSetmetadata:  name: mysqlspec:  serviceName: mysql  replicas: 3  selector:    matchLabels:      app: mysql  template:    metadata:      labels:        app: mysql    spec:      containers:      - name: mysql        image: mysql:8.0        ports:        - containerPort: 3306        env:        - name: MYSQL_ROOT_PASSWORD          valueFrom:            secretKeyRef:              name: mysql-secret              key: password        volumeMounts:        - name: data          mountPath: /var/lib/mysql    volumeClaimTemplates:  - metadata:      name: data    spec:      accessModes: [ "ReadWriteOnce" ]      resources:        requests:          storage: 10Gi

九、自动扩展

9.1 水平Pod自动扩展（HPA）

复制代码

yaml

复制代码

# hpa.yamlapiVersion: autoscaling/v2kind: HorizontalPodAutoscalermetadata:  name: app-hpaspec:  scaleTargetRef:    apiVersion: apps/v1    kind: Deployment    name: app-deployment  minReplicas: 2  maxReplicas: 10  metrics:  # CPU利用率  - type: Resource    resource:      name: cpu      target:        type: Utilization        averageUtilization: 70  # 内存利用率  - type: Resource    resource:      name: memory      target:        type: Utilization        averageUtilization: 80    behavior:    scaleDown:      stabilizationWindowSeconds: 300      policies:      - type: Percent        value: 50        periodSeconds: 60    scaleUp:      stabilizationWindowSeconds: 0      policies:      - type: Percent        value: 100        periodSeconds: 30      - type: Pods        value: 2        periodSeconds: 30      selectPolicy: Max

复制代码

bash

复制代码

# 查看HPA状态kubectl get hpakubectl describe hpa app-hpa# 模拟负载测试kubectl run -i --tty load-generator --rm --image=busybox --restart=Never -- /bin/sh -c "while sleep 0.01; do wget -q -O- http://app-deployment; done"

9.2 垂直Pod自动扩展（VPA）

复制代码

yaml

复制代码

apiVersion: autoscaling.k8s.io/v1kind: VerticalPodAutoscalermetadata:  name: app-vpaspec:  targetRef:    apiVersion: apps/v1    kind: Deployment    name: app-deployment  updatePolicy:    updateMode: "Auto"  resourcePolicy:    containerPolicies:    - containerName: app      minAllowed:        cpu: 100m        memory: 128Mi      maxAllowed:        cpu: 2        memory: 1Gi

十、监控和日志

10.1 部署Prometheus和Grafana

复制代码

yaml

复制代码

# prometheus-deployment.yamlapiVersion: apps/v1kind: Deploymentmetadata:  name: prometheus  namespace: monitoringspec:  replicas: 1  selector:    matchLabels:      app: prometheus  template:    metadata:      labels:        app: prometheus    spec:      containers:      - name: prometheus        image: prom/prometheus:latest        ports:        - containerPort: 9090        volumeMounts:        - name: config          mountPath: /etc/prometheus        - name: storage          mountPath: /prometheus      volumes:      - name: config        configMap:          name: prometheus-config      - name: storage        emptyDir: {}

10.2 日志聚合

复制代码

bash

复制代码

# 安装EFK stack (Elasticsearch, Fluentd, Kibana)kubectl apply -f https://raw.githubusercontent.com/fluent/fluent-kubernetes-daemonset/master/fluentd-daemonset-elasticsearch-rbac.yaml# 查看Fluentd日志kubectl logs -n kube-system -l app=fluentd

十一、跨时区团队技术会议

我们公司的Kubernetes团队分布在美国、德国和中国，定期在线上进行技术讨论会议，涉及集群架构设计、部署策略和故障排查等深度技术话题。考虑到团队成员的语言差异，我们使用**同言翻译（Transync AI）**进行实时同声传译，该工具不仅提供准确的实时翻译，还能自动生成会议纪要，确保每位工程师都能准确理解技术细节，同时为后续参考提供了完整的会议记录。这大幅提升了全球团队的技术协作效率。

十二、生产环保最佳实践

12.1 资源配额管理

复制代码

yaml

复制代码

# namespace-quota.yamlapiVersion: v1kind: Namespacemetadata:  name: production---apiVersion: v1kind: ResourceQuotametadata:  name: prod-quota  namespace: productionspec:  hard:    requests.cpu: "100"    requests.memory: "200Gi"    limits.cpu: "200"    limits.memory: "400Gi"    pods: "1000"    services: "100"

12.2 网络策略

复制代码

yaml

复制代码

# network-policy.yamlapiVersion: networking.k8s.io/v1kind: NetworkPolicymetadata:  name: app-network-policyspec:  podSelector:    matchLabels:      app: web  policyTypes:  - Ingress  - Egress  ingress:  - from:    - namespaceSelector:        matchLabels:          name: production    ports:    - protocol: TCP      port: 8080  egress:  - to:    - namespaceSelector:        matchLabels:          name: production    ports:    - protocol: TCP      port: 5432

12.3 Pod安全策略

复制代码

yaml

复制代码

apiVersion: policy/v1beta1kind: PodSecurityPolicymetadata:  name: restrictedspec:  privileged: false  allowPrivilegeEscalation: false  requiredDropCapabilities:  - ALL  volumes:  - 'configMap'  - 'emptyDir'  - 'projected'  - 'secret'  - 'downwardAPI'  - 'persistentVolumeClaim'  hostNetwork: false  hostIPC: false  hostPID: false  runAsUser:    rule: 'MustRunAsNonRoot'  seLinux:    rule: 'MustRunAs'    seLinuxOptions:      level: "s0:c123,c456"

十三、故障排查

13.1 常见问题诊断

复制代码

bash

复制代码

# 查看Pod状态kubectl get pods -o widekubectl describe pod <pod-name># 查看Pod日志kubectl logs <pod-name>kubectl logs <pod-name> --previous  # 查看上一个Pod的日志# 进入容器调试kubectl exec -it <pod-name> -- /bin/bash# 查看事件kubectl get eventskubectl describe node <node-name># 查看资源使用情况kubectl top nodeskubectl top pods# 检查DNSkubectl run -it --rm debug --image=nicolaka/netshoot --restart=Never -- nslookup kubernetes.default

13.2 查看集群状态

复制代码

bash

复制代码

# 集群信息kubectl cluster-infokubectl get nodeskubectl describe node <node-name># API服务器状态kubectl get componentstatuses# Pod事件kubectl get events --sort-by='.lastTimestamp'# 资源使用总结kubectl describe nodes | grep -A 5 "Allocated resources"

十四、性能对比

指标	Docker Compose	Kubernetes	提升
自动故障恢复	❌	✅	100%
自动扩展	手动	自动	显著
更新方式	停机更新	零停机	100%
服务发现	手动配置	自动化	显著
存储管理	复杂	简化	显著
跨主机编排	困难	简单	显著

十五、推荐工具

复制代码

kubectl       - CLI工具Kubeadm       - 集群初始化Helm          - 包管理器Kustomize     - 配置管理Lens          - IDE for K8skubectx       - 上下文切换Stern         - 日志查看Velero        - 备份恢复

十六、学习资源

复制代码

官方文档：https://kubernetes.io/docs/Kubernetes教程：https://kubernetes.io/docs/tutorials/Helm文档：https://helm.sh/docs/CNCF景观：https://landscape.cncf.io/

十七、结语

Kubernetes虽然学习曲线陡峭，但一旦掌握，它提供的价值是巨大的。从自动扩展、自我修复到灰度发布，它极大地简化了容器编排。

核心理念：声明式配置 → 自动化执行 → 持续优化

这正是Kubernetes的威力所在。希望这篇文章能帮助你踏上Kubernetes之旅。欢迎在评论区分享你的K8s实践经验！
