创建一个完整的Flask Web应用，用于管理和可视化Neo4j知识图谱。
1. 项目结构
text
flask_kg_app/
│
├── app.py # 主应用文件
├── requirements.txt # 依赖包
├── config.py # 配置文件
├── .env # 环境变量
│
├── static/ # 静态文件
│ ├── css/
│ ├── js/
│ └── images/
│
├── templates/ # HTML模板
│ ├── base.html
│ ├── index.html
│ ├── query.html
│ ├── visualize.html
│ ├── manage.html
│ └── dashboard.html
│
├── utils/ # 工具模块
│ ├── neo4j_connector.py
│ ├── kg_builder.py
│ └── visualizer.py
│
└── data/ # 数据文件
├── sample_data.csv
└── imports/2. 配置文件
python
import os
from dotenv import load_dotenv
load_dotenv()
class Config:
"""应用配置"""
# 基础配置
SECRET_KEY = os.getenv('SECRET_KEY', 'your-secret-key-here')
# Neo4j配置
NEO4J_URI = os.getenv('NEO4J_URI', 'bolt://localhost:7687')
NEO4J_USER = os.getenv('NEO4J_USER', 'neo4j')
NEO4J_PASSWORD = os.getenv('NEO4J_PASSWORD', 'password')
# 应用配置
UPLOAD_FOLDER = os.path.join(os.path.dirname(__file__), 'data/uploads')
MAX_CONTENT_LENGTH = 16 * 1024 * 1024 # 16MB
# 允许的文件扩展名
ALLOWED_EXTENSIONS = {'csv', 'json', 'txt'}
@staticmethod
def init_app(app):
"""初始化应用配置"""
# 确保上传目录存在
if not os.path.exists(Config.UPLOAD_FOLDER):
os.makedirs(Config.UPLOAD_FOLDER).env
env
SECRET_KEY=your-secret-key-change-this
NEO4J_URI=bolt://localhost:7687
NEO4J_USER=neo4j
NEO4J_PASSWORD=your-password
DEBUG=True3. Neo4j连接工具
utils/neo4j_connector.py
python
from neo4j import GraphDatabase, BoltDriver
from typing import List, Dict, Any, Optional
import pandas as pd
import json
class Neo4jConnector:
"""Neo4j数据库连接管理器"""
def __init__(self, uri: str, user: str, password: str):
"""
初始化Neo4j连接
:param uri: Neo4j连接URI
:param user: 用户名
:param password: 密码
"""
self.uri = uri
self.user = user
self.password = password
self.driver = None
self._connect()
def _connect(self):
"""建立数据库连接"""
try:
self.driver = GraphDatabase.driver(
self.uri,
auth=(self.user, self.password),
max_connection_lifetime=30 * 60,
connection_timeout=15,
connection_acquisition_timeout=2 * 60
)
# 测试连接
with self.driver.session() as session:
session.run("RETURN 1")
print("Neo4j连接成功")
except Exception as e:
print(f"Neo4j连接失败: {e}")
self.driver = None
def close(self):
"""关闭数据库连接"""
if self.driver:
self.driver.close()
def is_connected(self) -> bool:
"""检查连接状态"""
try:
with self.driver.session() as session:
session.run("RETURN 1")
return True
except:
return False
def execute_query(self, query: str, params: dict = None) -> List[Dict]:
"""
执行Cypher查询
:param query: Cypher查询语句
:param params: 查询参数
:return: 查询结果列表
"""
if not self.is_connected():
self._connect()
try:
with self.driver.session() as session:
result = session.run(query, parameters=params or {})
records = []
for record in result:
# 将Record对象转换为字典
record_dict = {}
for key in record.keys():
value = record[key]
# 处理Neo4j的特殊类型
if hasattr(value, '__dict__'):
value = dict(value)
record_dict[key] = value
records.append(record_dict)
return records
except Exception as e:
print(f"查询执行失败: {e}")
return []
def get_database_info(self) -> Dict[str, Any]:
"""获取数据库信息"""
queries = {
"节点统计": """
CALL db.labels() YIELD label
CALL apoc.cypher.run('MATCH (n:`' + label + '`) RETURN count(*) as count', {})
YIELD value
RETURN label, value.count as count
ORDER BY label
""",
"关系统计": """
CALL db.relationshipTypes() YIELD relationshipType
CALL apoc.cypher.run('MATCH ()-[r:`' + relationshipType + '`]->() RETURN count(*) as count', {})
YIELD value
RETURN relationshipType, value.count as count
ORDER BY relationshipType
""",
"属性统计": """
MATCH (n)
UNWIND keys(n) as key
RETURN key, count(*) as count, collect(distinct apoc.convert.toString(n[key]))[0..5] as sample_values
ORDER BY count DESC
LIMIT 10
"""
}
info = {"状态": "已连接" if self.is_connected() else "未连接"}
if self.is_connected():
for name, query in queries.items():
try:
info[name] = self.execute_query(query)
except:
info[name] = []
return info
def import_csv(self, filepath: str, label: str = None) -> Dict[str, Any]:
"""
从CSV文件导入数据
:param filepath: CSV文件路径
:param label: 节点标签
:return: 导入结果
"""
try:
df = pd.read_csv(filepath)
if 'label' in df.columns and not label:
# 使用CSV中的label列
labels = df['label'].unique()
results = {}
for lbl in labels:
nodes_df = df[df['label'] == lbl]
properties = {}
for _, row in nodes_df.iterrows():
node_props = {}
for col in nodes_df.columns:
if col != 'label' and pd.notna(row[col]):
node_props[col] = row[col]
query = f"""
CREATE (n:{lbl} $props)
RETURN id(n) as id
"""
result = self.execute_query(query, {"props": node_props})
if result:
node_id = result[0]['id']
properties[str(node_id)] = node_props
results[lbl] = {
"count": len(nodes_df),
"properties": properties
}
return {
"success": True,
"message": f"成功导入 {len(df)} 个节点",
"results": results
}
else:
# 使用指定的label
nodes_created = 0
properties = {}
for _, row in df.iterrows():
props = {}
for col in df.columns:
if pd.notna(row[col]):
props[col] = row[col]
query = f"""
CREATE (n:{label} $props)
RETURN id(n) as id
"""
result = self.execute_query(query, {"props": props})
if result:
node_id = result[0]['id']
properties[str(node_id)] = props
nodes_created += 1
return {
"success": True,
"message": f"成功导入 {nodes_created} 个节点",
"results": {label: {"count": nodes_created, "properties": properties}}
}
except Exception as e:
return {
"success": False,
"message": f"导入失败: {str(e)}"
}
def export_to_json(self, filename: str = "knowledge_graph.json") -> Dict[str, Any]:
"""导出知识图谱为JSON格式"""
try:
# 获取所有节点
nodes_query = """
MATCH (n)
RETURN
id(n) as id,
labels(n) as labels,
properties(n) as properties
"""
# 获取所有关系
relationships_query = """
MATCH (a)-[r]->(b)
RETURN
id(a) as start_id,
type(r) as type,
properties(r) as properties,
id(b) as end_id,
labels(a) as start_labels,
labels(b) as end_labels
"""
nodes = self.execute_query(nodes_query)
relationships = self.execute_query(relationships_query)
# 构建图结构
graph_data = {
"nodes": nodes,
"relationships": relationships,
"metadata": {
"node_count": len(nodes),
"relationship_count": len(relationships),
"export_time": pd.Timestamp.now().isoformat()
}
}
# 保存到文件
with open(filename, 'w', encoding='utf-8') as f:
json.dump(graph_data, f, ensure_ascii=False, indent=2)
return {
"success": True,
"message": f"数据已导出到 {filename}",
"filepath": filename,
"stats": {
"nodes": len(nodes),
"relationships": len(relationships)
}
}
except Exception as e:
return {
"success": False,
"message": f"导出失败: {str(e)}"
}
def clear_database(self) -> Dict[str, Any]:
"""清空数据库"""
try:
query = "MATCH (n) DETACH DELETE n"
self.execute_query(query)
# 重建索引
self.execute_query("CREATE CONSTRAINT IF NOT EXISTS FOR (n:Person) REQUIRE n.id IS UNIQUE")
self.execute_query("CREATE CONSTRAINT IF NOT EXISTS FOR (n:Company) REQUIRE n.id IS UNIQUE")
self.execute_query("CREATE INDEX IF NOT EXISTS FOR (n:Person) ON (n.name)")
self.execute_query("CREATE INDEX IF NOT EXISTS FOR (n:Company) ON (n.name)")
return {
"success": True,
"message": "数据库已清空并重建索引"
}
except Exception as e:
return {
"success": False,
"message": f"清空失败: {str(e)}"
}4. Flask主应用
python
from flask import Flask, render_template, request, jsonify, redirect, url_for, flash, send_file
from flask_cors import CORS
import os
import json
from datetime import datetime
from config import Config
from utils.neo4j_connector import Neo4jConnector
from utils.kg_builder import KnowledgeGraphBuilder
from utils.visualizer import KGVisualizer
# 初始化应用
app = Flask(__name__)
app.config.from_object(Config)
CORS(app)
# 初始化Neo4j连接
neo4j_conn = Neo4jConnector(
uri=app.config['NEO4J_URI'],
user=app.config['NEO4J_USER'],
password=app.config['NEO4J_PASSWORD']
)
# 初始化知识图谱构建器
kg_builder = KnowledgeGraphBuilder(neo4j_conn)
@app.route('/')
def index():
"""首页"""
db_info = neo4j_conn.get_database_info()
return render_template('index.html', db_info=db_info)
@app.route('/dashboard')
def dashboard():
"""仪表盘"""
# 获取统计信息
stats_query = """
MATCH (n)
WITH labels(n) as labels
UNWIND labels as label
RETURN label, count(*) as count
ORDER BY count DESC
"""
stats = neo4j_conn.execute_query(stats_query)
# 获取最近添加的节点
recent_query = """
MATCH (n)
WHERE n.created_at IS NOT NULL
RETURN n.name as name, labels(n)[0] as label, n.created_at as created_at
ORDER BY n.created_at DESC
LIMIT 10
"""
recent_nodes = neo4j_conn.execute_query(recent_query)
# 获取数据库信息
db_info = neo4j_conn.get_database_info()
return render_template('dashboard.html',
stats=stats,
recent_nodes=recent_nodes,
db_info=db_info)
@app.route('/query', methods=['GET', 'POST'])
def query():
"""查询页面"""
results = []
query_text = ""
if request.method == 'POST':
query_text = request.form.get('query', '')
if query_text:
results = neo4j_conn.execute_query(query_text)
# 获取预定义查询模板
query_templates = [
{
"name": "查找所有人物",
"query": "MATCH (p:Person) RETURN p.name as name, p.age as age, p.profession as profession LIMIT 50"
},
{
"name": "查找所有关系",
"query": "MATCH (a)-[r]->(b) RETURN a.name as from, type(r) as relation, b.name as to LIMIT 50"
},
{
"name": "查找朋友的朋友",
"query": "MATCH (p:Person {name: 'Alice'})-[:FRIEND*2]->(fof) RETURN DISTINCT fof.name as name"
},
{
"name": "查找所有公司及其员工",
"query": "MATCH (c:Company)<-[:WORKS_AT]-(p:Person) RETURN c.name as company, collect(p.name) as employees"
}
]
return render_template('query.html',
results=results,
query_text=query_text,
query_templates=query_templates)
@app.route('/visualize')
def visualize():
"""可视化页面"""
# 获取所有节点类型用于筛选
node_labels_query = "CALL db.labels() YIELD label RETURN label"
node_labels = [item['label'] for item in neo4j_conn.execute_query(node_labels_query)]
# 获取所有关系类型
rel_types_query = "CALL db.relationshipTypes() YIELD relationshipType RETURN relationshipType"
rel_types = [item['relationshipType'] for item in neo4j_conn.execute_query(rel_types_query)]
# 获取示例数据用于预览
sample_query = """
MATCH (n)
RETURN labels(n)[0] as label, properties(n) as properties
LIMIT 5
"""
sample_data = neo4j_conn.execute_query(sample_query)
return render_template('visualize.html',
node_labels=node_labels,
rel_types=rel_types,
sample_data=sample_data)
@app.route('/api/graph_data', methods=['GET'])
def get_graph_data():
"""获取图谱数据API"""
try:
# 获取查询参数
label_filter = request.args.get('label', '')
limit = int(request.args.get('limit', 100))
# 构建查询
if label_filter:
query = f"""
MATCH (n:{label_filter})-[r]-(m)
RETURN
id(n) as source_id,
labels(n)[0] as source_label,
properties(n) as source_props,
id(m) as target_id,
labels(m)[0] as target_label,
properties(m) as target_props,
type(r) as relationship_type,
properties(r) as relationship_props
LIMIT {limit}
"""
else:
query = f"""
MATCH (n)-[r]-(m)
RETURN
id(n) as source_id,
labels(n)[0] as source_label,
properties(n) as source_props,
id(m) as target_id,
labels(m)[0] as target_label,
properties(m) as target_props,
type(r) as relationship_type,
properties(r) as relationship_props
LIMIT {limit}
"""
results = neo4j_conn.execute_query(query)
# 构建节点和边数据
nodes = {}
edges = []
node_counter = 0
for record in results:
# 处理源节点
source_id = record['source_id']
if source_id not in nodes:
nodes[source_id] = {
"id": node_counter,
"neo4j_id": source_id,
"label": record['source_label'],
"properties": record['source_props'],
"name": record['source_props'].get('name', f"Node_{source_id}")
}
node_counter += 1
# 处理目标节点
target_id = record['target_id']
if target_id not in nodes:
nodes[target_id] = {
"id": node_counter,
"neo4j_id": target_id,
"label": record['target_label'],
"properties": record['target_props'],
"name": record['target_props'].get('name', f"Node_{target_id}")
}
node_counter += 1
# 添加边
edges.append({
"source": nodes[source_id]["id"],
"target": nodes[target_id]["id"],
"type": record['relationship_type'],
"properties": record['relationship_props']
})
return jsonify({
"success": True,
"nodes": list(nodes.values()),
"edges": edges,
"count": {
"nodes": len(nodes),
"edges": len(edges)
}
})
except Exception as e:
return jsonify({
"success": False,
"error": str(e)
}), 500
@app.route('/manage', methods=['GET', 'POST'])
def manage():
"""管理页面"""
message = None
message_type = None
if request.method == 'POST':
action = request.form.get('action')
if action == 'clear':
result = neo4j_conn.clear_database()
message = result['message']
message_type = 'success' if result['success'] else 'error'
elif action == 'export':
filename = f"kg_export_{datetime.now().strftime('%Y%m%d_%H%M%S')}.json"
result = neo4j_conn.export_to_json(filename)
message = result['message']
message_type = 'success' if result['success'] else 'error'
if result['success']:
return send_file(filename, as_attachment=True)
elif action == 'import_csv':
if 'csv_file' in request.files:
file = request.files['csv_file']
if file.filename != '':
filename = os.path.join(app.config['UPLOAD_FOLDER'], file.filename)
file.save(filename)
label = request.form.get('label', 'Node')
result = neo4j_conn.import_csv(filename, label)
message = result['message']
message_type = 'success' if result['success'] else 'error'
elif action == 'create_sample':
result = kg_builder.create_sample_data()
message = result['message']
message_type = 'success' if result['success'] else 'error'
return render_template('manage.html', message=message, message_type=message_type)
@app.route('/api/create_node', methods=['POST'])
def create_node():
"""创建节点API"""
try:
data = request.json
label = data.get('label')
properties = data.get('properties', {})
# 添加创建时间戳
properties['created_at'] = datetime.now().isoformat()
query = f"""
CREATE (n:{label} $props)
RETURN id(n) as id, labels(n) as labels, properties(n) as properties
"""
result = neo4j_conn.execute_query(query, {"props": properties})
if result:
return jsonify({
"success": True,
"message": "节点创建成功",
"node": result[0]
})
else:
return jsonify({
"success": False,
"message": "节点创建失败"
}), 400
except Exception as e:
return jsonify({
"success": False,
"message": str(e)
}), 500
@app.route('/api/create_relationship', methods=['POST'])
def create_relationship():
"""创建关系API"""
try:
data = request.json
source_id = data.get('source_id')
target_id = data.get('target_id')
rel_type = data.get('type')
properties = data.get('properties', {})
query = f"""
MATCH (a) WHERE id(a) = $source_id
MATCH (b) WHERE id(b) = $target_id
CREATE (a)-[r:{rel_type} $props]->(b)
RETURN id(r) as id, type(r) as type, properties(r) as properties
"""
params = {
"source_id": source_id,
"target_id": target_id,
"props": properties
}
result = neo4j_conn.execute_query(query, params)
if result:
return jsonify({
"success": True,
"message": "关系创建成功",
"relationship": result[0]
})
else:
return jsonify({
"success": False,
"message": "关系创建失败"
}), 400
except Exception as e:
return jsonify({
"success": False,
"message": str(e)
}), 500
@app.route('/api/search', methods=['GET'])
def search():
"""搜索API"""
try:
keyword = request.args.get('q', '')
search_type = request.args.get('type', 'both') # node, relation, both
results = []
if search_type in ['node', 'both']:
# 搜索节点
node_query = """
MATCH (n)
WHERE n.name CONTAINS $keyword OR n.id CONTAINS $keyword
RETURN
id(n) as id,
labels(n) as labels,
properties(n) as properties,
'node' as type
LIMIT 20
"""
nodes = neo4j_conn.execute_query(node_query, {"keyword": keyword})
results.extend(nodes)
if search_type in ['relation', 'both']:
# 搜索关系
rel_query = """
MATCH (a)-[r]-(b)
WHERE type(r) CONTAINS $keyword
RETURN
id(r) as id,
type(r) as type,
properties(r) as properties,
id(a) as source_id,
id(b) as target_id,
'relationship' as result_type
LIMIT 20
"""
relationships = neo4j_conn.execute_query(rel_query, {"keyword": keyword})
results.extend(relationships)
return jsonify({
"success": True,
"count": len(results),
"results": results
})
except Exception as e:
return jsonify({
"success": False,
"message": str(e)
}), 500
@app.route('/api/statistics')
def get_statistics():
"""获取统计数据API"""
try:
# 节点统计
node_stats = neo4j_conn.execute_query("""
CALL db.labels() YIELD label
CALL apoc.cypher.run('MATCH (n:`' + label + '`) RETURN count(*) as count', {})
YIELD value
RETURN label, value.count as count
ORDER BY count DESC
""")
# 关系统计
rel_stats = neo4j_conn.execute_query("""
CALL db.relationshipTypes() YIELD relationshipType
CALL apoc.cypher.run('MATCH ()-[r:`' + relationshipType + '`]->() RETURN count(*) as count', {})
YIELD value
RETURN relationshipType, value.count as count
ORDER BY count DESC
""")
# 属性统计
prop_stats = neo4j_conn.execute_query("""
MATCH (n)
UNWIND keys(n) as key
RETURN key, count(*) as count
ORDER BY count DESC
LIMIT 10
""")
return jsonify({
"success": True,
"statistics": {
"nodes_by_label": node_stats,
"relationships_by_type": rel_stats,
"top_properties": prop_stats
}
})
except Exception as e:
return jsonify({
"success": False,
"message": str(e)
}), 500
@app.route('/health')
def health_check():
"""健康检查"""
db_status = neo4j_conn.is_connected()
return jsonify({
"status": "healthy" if db_status else "unhealthy",
"database": "connected" if db_status else "disconnected",
"timestamp": datetime.now().isoformat()
})
@app.teardown_appcontext
def teardown_db(exception):
"""关闭数据库连接"""
neo4j_conn.close()
if __name__ == '__main__':
app.run(debug=True, port=5000, host='0.0.0.0')5. 知识图谱构建器
utils/kg_builder.py
python
class KnowledgeGraphBuilder:
"""知识图谱构建器"""
def __init__(self, neo4j_connector):
self.conn = neo4j_connector
def create_sample_data(self):
"""创建示例数据"""
try:
# 创建电影知识图谱示例
sample_data = [
# 创建电影
("CREATE (m:Movie {title: 'The Matrix', year: 1999, genre: 'Sci-Fi', rating: 8.7})", {}),
("CREATE (m:Movie {title: 'Inception', year: 2010, genre: 'Sci-Fi', rating: 8.8})", {}),
("CREATE (m:Movie {title: 'The Godfather', year: 1972, genre: 'Crime', rating: 9.2})", {}),
# 创建演员
("CREATE (p:Person {name: 'Keanu Reeves', born: 1964, nationality: 'Canadian'})", {}),
("CREATE (p:Person {name: 'Laurence Fishburne', born: 1961, nationality: 'American'})", {}),
("CREATE (p:Person {name: 'Leonardo DiCaprio', born: 1974, nationality: 'American'})", {}),
("CREATE (p:Person {name: 'Marlon Brando', born: 1924, nationality: 'American'})", {}),
# 创建导演
("CREATE (p:Person {name: 'The Wachowskis', profession: 'Directors'})", {}),
("CREATE (p:Person {name: 'Christopher Nolan', born: 1970, nationality: 'British'})", {}),
("CREATE (p:Person {name: 'Francis Ford Coppola', born: 1939, nationality: 'American'})", {}),
# 创建关系
("""
MATCH (a:Person {name: 'Keanu Reeves'})
MATCH (b:Movie {title: 'The Matrix'})
CREATE (a)-[r:ACTED_IN {role: 'Neo'}]->(b)
""", {}),
("""
MATCH (a:Person {name: 'Laurence Fishburne'})
MATCH (b:Movie {title: 'The Matrix'})
CREATE (a)-[r:ACTED_IN {role: 'Morpheus'}]->(b)
""", {}),
("""
MATCH (a:Person {name: 'Leonardo DiCaprio'})
MATCH (b:Movie {title: 'Inception'})
CREATE (a)-[r:ACTED_IN {role: 'Cobb'}]->(b)
""", {}),
("""
MATCH (a:Person {name: 'Marlon Brando'})
MATCH (b:Movie {title: 'The Godfather'})
CREATE (a)-[r:ACTED_IN {role: 'Vito Corleone'}]->(b)
""", {}),
("""
MATCH (a:Person {name: 'The Wachowskis'})
MATCH (b:Movie {title: 'The Matrix'})
CREATE (a)-[r:DIRECTED]->(b)
""", {}),
("""
MATCH (a:Person {name: 'Christopher Nolan'})
MATCH (b:Movie {title: 'Inception'})
CREATE (a)-[r:DIRECTED]->(b)
""", {}),
("""
MATCH (a:Person {name: 'Francis Ford Coppola'})
MATCH (b:Movie {title: 'The Godfather'})
CREATE (a)-[r:DIRECTED]->(b)
""", {})
]
for query, params in sample_data:
self.conn.execute_query(query, params)
return {
"success": True,
"message": "示例数据创建成功",
"data": {
"movies": 3,
"people": 7,
"relationships": 7
}
}
except Exception as e:
return {
"success": False,
"message": f"创建示例数据失败: {str(e)}"
}
def build_company_kg(self):
"""构建公司知识图谱"""
try:
# 创建公司节点
companies = [
{"name": "Apple", "industry": "Technology", "founded": 1976},
{"name": "Google", "industry": "Technology", "founded": 1998},
{"name": "Microsoft", "industry": "Technology", "founded": 1975}
]
# 创建人物节点
people = [
{"name": "Steve Jobs", "role": "Co-founder", "company": "Apple"},
{"name": "Tim Cook", "role": "CEO", "company": "Apple"},
{"name": "Larry Page", "role": "Co-founder", "company": "Google"},
{"name": "Sundar Pichai", "role": "CEO", "company": "Google"},
{"name": "Bill Gates", "role": "Co-founder", "company": "Microsoft"},
{"name": "Satya Nadella", "role": "CEO", "company": "Microsoft"}
]
# 创建产品节点
products = [
{"name": "iPhone", "type": "Smartphone", "company": "Apple"},
{"name": "MacBook", "type": "Laptop", "company": "Apple"},
{"name": "Google Search", "type": "Search Engine", "company": "Google"},
{"name": "Android", "type": "Operating System", "company": "Google"},
{"name": "Windows", "type": "Operating System", "company": "Microsoft"},
{"name": "Office", "type": "Productivity Suite", "company": "Microsoft"}
]
# 批量创建节点
for company in companies:
self.conn.execute_query(
"CREATE (c:Company $props)",
{"props": company}
)
for person in people:
self.conn.execute_query(
"CREATE (p:Person $props)",
{"props": person}
)
for product in products:
self.conn.execute_query(
"CREATE (p:Product $props)",
{"props": product}
)
# 创建关系
relationships = [
# 人物-公司关系
("MATCH (p:Person {name: 'Steve Jobs'}) MATCH (c:Company {name: 'Apple'}) CREATE (p)-[:FOUNDED]->(c)", {}),
("MATCH (p:Person {name: 'Tim Cook'}) MATCH (c:Company {name: 'Apple'}) CREATE (p)-[:WORKS_AS {position: 'CEO'}]->(c)", {}),
("MATCH (p:Person {name: 'Larry Page'}) MATCH (c:Company {name: 'Google'}) CREATE (p)-[:FOUNDED]->(c)", {}),
("MATCH (p:Person {name: 'Sundar Pichai'}) MATCH (c:Company {name: 'Google'}) CREATE (p)-[:WORKS_AS {position: 'CEO'}]->(c)", {}),
("MATCH (p:Person {name: 'Bill Gates'}) MATCH (c:Company {name: 'Microsoft'}) CREATE (p)-[:FOUNDED]->(c)", {}),
("MATCH (p:Person {name: 'Satya Nadella'}) MATCH (c:Company {name: 'Microsoft'}) CREATE (p)-[:WORKS_AS {position: 'CEO'}]->(c)", {}),
# 产品-公司关系
("MATCH (p:Product {name: 'iPhone'}) MATCH (c:Company {name: 'Apple'}) CREATE (p)-[:PRODUCED_BY]->(c)", {}),
("MATCH (p:Product {name: 'MacBook'}) MATCH (c:Company {name: 'Apple'}) CREATE (p)-[:PRODUCED_BY]->(c)", {}),
("MATCH (p:Product {name: 'Google Search'}) MATCH (c:Company {name: 'Google'}) CREATE (p)-[:PRODUCED_BY]->(c)", {}),
("MATCH (p:Product {name: 'Android'}) MATCH (c:Company {name: 'Google'}) CREATE (p)-[:PRODUCED_BY]->(c)", {}),
("MATCH (p:Product {name: 'Windows'}) MATCH (c:Company {name: 'Microsoft'}) CREATE (p)-[:PRODUCED_BY]->(c)", {}),
("MATCH (p:Product {name: 'Office'}) MATCH (c:Company {name: 'Microsoft'}) CREATE (p)-[:PRODUCED_BY]->(c)", {}),
# 竞争关系
("MATCH (c1:Company {name: 'Apple'}) MATCH (c2:Company {name: 'Google'}) CREATE (c1)-[:COMPETES_WITH]->(c2)", {}),
("MATCH (c1:Company {name: 'Apple'}) MATCH (c2:Company {name: 'Microsoft'}) CREATE (c1)-[:COMPETES_WITH]->(c2)", {}),
("MATCH (c1:Company {name: 'Google'}) MATCH (c2:Company {name: 'Microsoft'}) CREATE (c1)-[:COMPETES_WITH]->(c2)", {})
]
for query, params in relationships:
self.conn.execute_query(query, params)
return {
"success": True,
"message": "公司知识图谱创建成功",
"data": {
"companies": len(companies),
"people": len(people),
"products": len(products),
"relationships": len(relationships)
}
}
except Exception as e:
return {
"success": False,
"message": f"构建公司知识图谱失败: {str(e)}"
}6. HTML模板
templates/base.html
html
<!DOCTYPE html>
<html lang="zh-CN">
<head>
<meta charset="UTF-8">
<meta name="viewport" content="width=device-width, initial-scale=1.0">
<title>{% block title %}知识图谱管理系统{% endblock %}</title>
<!-- Bootstrap CSS -->
<link href="https://cdn.jsdelivr.net/npm/bootstrap@5.1.3/dist/css/bootstrap.min.css" rel="stylesheet">
<!-- Font Awesome -->
<link rel="stylesheet" href="https://cdnjs.cloudflare.com/ajax/libs/font-awesome/6.0.0/css/all.min.css">
<!-- 自定义样式 -->
<style>
:root {
--primary-color: #3498db;
--secondary-color: #2c3e50;
--accent-color: #e74c3c;
--light-bg: #f8f9fa;
--dark-bg: #343a40;
}
body {
font-family: 'Segoe UI', Tahoma, Geneva, Verdana, sans-serif;
background-color: var(--light-bg);
}
.navbar-brand {
font-weight: bold;
color: var(--primary-color) !important;
}
.sidebar {
min-height: calc(100vh - 56px);
background-color: var(--secondary-color);
color: white;
}
.sidebar a {
color: rgba(255, 255, 255, 0.8);
text-decoration: none;
padding: 10px 15px;
display: block;
border-radius: 5px;
margin: 5px 0;
transition: all 0.3s;
}
.sidebar a:hover {
background-color: rgba(255, 255, 255, 0.1);
color: white;
}
.sidebar a.active {
background-color: var(--primary-color);
color: white;
}
.sidebar i {
margin-right: 10px;
width: 20px;
text-align: center;
}
.card {
border: none;
box-shadow: 0 2px 10px rgba(0,0,0,0.1);
margin-bottom: 20px;
transition: transform 0.3s;
}
.card:hover {
transform: translateY(-2px);
}
.card-header {
background-color: var(--primary-color);
color: white;
font-weight: bold;
}
.stat-card {
text-align: center;
padding: 20px;
background: linear-gradient(135deg, var(--primary-color), #2980b9);
color: white;
border-radius: 10px;
}
.stat-card i {
font-size: 3rem;
margin-bottom: 10px;
}
.stat-card .number {
font-size: 2.5rem;
font-weight: bold;
}
.stat-card .label {
font-size: 1rem;
opacity: 0.9;
}
.btn-primary {
background-color: var(--primary-color);
border-color: var(--primary-color);
}
.btn-primary:hover {
background-color: #2980b9;
border-color: #2980b9;
}
.table-hover tbody tr:hover {
background-color: rgba(52, 152, 219, 0.1);
}
.alert {
border: none;
border-radius: 5px;
}
.alert-success {
background-color: #d4edda;
color: #155724;
}
.alert-error {
background-color: #f8d7da;
color: #721c24;
}
.cypher-editor {
font-family: 'Courier New', monospace;
min-height: 200px;
}
#graph-container {
width: 100%;
height: 600px;
border: 1px solid #ddd;
border-radius: 5px;
background-color: white;
}
.node-tooltip {
position: absolute;
background: white;
border: 1px solid #ddd;
border-radius: 3px;
padding: 10px;
box-shadow: 0 2px 10px rgba(0,0,0,0.1);
display: none;
z-index: 1000;
max-width: 300px;
}
@media (max-width: 768px) {
.sidebar {
min-height: auto;
margin-bottom: 20px;
}
}
</style>
{% block extra_css %}{% endblock %}
</head>
<body>
<!-- 导航栏 -->
<nav class="navbar navbar-expand-lg navbar-dark bg-dark">
<div class="container-fluid">
<a class="navbar-brand" href="{{ url_for('index') }}">
<i class="fas fa-project-diagram"></i> 知识图谱管理系统
</a>
<button class="navbar-toggler" type="button" data-bs-toggle="collapse" data-bs-target="#navbarNav">
<span class="navbar-toggler-icon"></span>
</button>
<div class="collapse navbar-collapse" id="navbarNav">
<ul class="navbar-nav ms-auto">
<li class="nav-item">
<a class="nav-link" href="{{ url_for('health') }}">
<i class="fas fa-heartbeat"></i> 健康检查
</a>
</li>
<li class="nav-item">
<span class="nav-link">
<i class="fas fa-database"></i>
{% if neo4j_conn.is_connected() %}
<span class="text-success">数据库已连接</span>
{% else %}
<span class="text-danger">数据库未连接</span>
{% endif %}
</span>
</li>
</ul>
</div>
</div>
</nav>
<div class="container-fluid">
<div class="row">
<!-- 侧边栏 -->
<div class="col-md-3 col-lg-2 sidebar d-md-block">
<div class="position-sticky pt-3">
<ul class="nav flex-column">
<li>
<a href="{{ url_for('dashboard') }}"
class="{% if request.endpoint == 'dashboard' %}active{% endif %}">
<i class="fas fa-tachometer-alt"></i> 仪表盘
</a>
</li>
<li>
<a href="{{ url_for('query') }}"
class="{% if request.endpoint == 'query' %}active{% endif %}">
<i class="fas fa-search"></i> 查询
</a>
</li>
<li>
<a href="{{ url_for('visualize') }}"
class="{% if request.endpoint == 'visualize' %}active{% endif %}">
<i class="fas fa-eye"></i> 可视化
</a>
</li>
<li>
<a href="{{ url_for('manage') }}"
class="{% if request.endpoint == 'manage' %}active{% endif %}">
<i class="fas fa-cog"></i> 管理
</a>
</li>
</ul>
<hr class="bg-light">
<h6 class="sidebar-heading px-3 mt-4 mb-1 text-muted">
<span>数据库信息</span>
</h6>
<ul class="nav flex-column">
<li>
<a href="#" class="text-info">
<i class="fas fa-server"></i> {{ neo4j_conn.uri }}
</a>
</li>
<li>
<a href="#" class="text-info">
<i class="fas fa-user"></i> {{ neo4j_conn.user }}
</a>
</li>
</ul>
</div>
</div>
<!-- 主内容区域 -->
<div class="col-md-9 col-lg-10 ms-sm-auto px-md-4">
{% with messages = get_flashed_messages(with_categories=true) %}
{% if messages %}
{% for category, message in messages %}
<div class="alert alert-{{ category }} mt-3">
{{ message }}
</div>
{% endfor %}
{% endif %}
{% endwith %}
{% block content %}{% endblock %}
</div>
</div>
</div>
<!-- Bootstrap JS -->
<script src="https://cdn.jsdelivr.net/npm/bootstrap@5.1.3/dist/js/bootstrap.bundle.min.js"></script>
<!-- 全局JS -->
<script>
// 显示加载指示器
function showLoading() {
const loadingEl = document.createElement('div');
loadingEl.id = 'loading';
loadingEl.innerHTML = `
<div style="position: fixed; top: 0; left: 0; width: 100%; height: 100%;
background: rgba(0,0,0,0.5); z-index: 9999; display: flex;
align-items: center; justify-content: center;">
<div class="spinner-border text-light" role="status">
<span class="visually-hidden">加载中...</span>
</div>
</div>
`;
document.body.appendChild(loadingEl);
}
// 隐藏加载指示器
function hideLoading() {
const loadingEl = document.getElementById('loading');
if (loadingEl) {
loadingEl.remove();
}
}
// 显示消息
function showMessage(message, type = 'info') {
const alertDiv = document.createElement('div');
alertDiv.className = `alert alert-${type} alert-dismissible fade show`;
alertDiv.innerHTML = `
${message}
<button type="button" class="btn-close" data-bs-dismiss="alert"></button>
`;
const container = document.querySelector('.container-fluid .col-md-9');
container.insertBefore(alertDiv, container.firstChild);
setTimeout(() => {
alertDiv.remove();
}, 5000);
}
// 处理表单提交
function handleFormSubmit(formId, successCallback) {
const form = document.getElementById(formId);
if (form) {
form.addEventListener('submit', function(e) {
e.preventDefault();
showLoading();
const formData = new FormData(this);
const action = this.getAttribute('action');
const method = this.getAttribute('method') || 'POST';
fetch(action, {
method: method,
body: formData
})
.then(response => response.json())
.then(data => {
hideLoading();
if (data.success) {
showMessage(data.message, 'success');
if (successCallback) successCallback(data);
} else {
showMessage(data.message, 'danger');
}
})
.catch(error => {
hideLoading();
showMessage('请求失败: ' + error.message, 'danger');
});
});
}
}
// 页面加载完成
document.addEventListener('DOMContentLoaded', function() {
// 为所有带有 data-confirm 属性的链接添加确认对话框
document.querySelectorAll('a[data-confirm]').forEach(link => {
link.addEventListener('click', function(e) {
if (!confirm(this.getAttribute('data-confirm'))) {
e.preventDefault();
}
});
});
// 为所有表格行添加点击效果
document.querySelectorAll('table tbody tr').forEach(row => {
row.addEventListener('click', function() {
this.classList.toggle('table-active');
});
});
});
</script>
{% block extra_js %}{% endblock %}
</body>
</html>templates/dashboard.html
html
{% extends "base.html" %}
{% block title %}仪表盘 - 知识图谱管理系统{% endblock %}
{% block content %}
<div class="d-flex justify-content-between flex-wrap flex-md-nowrap align-items-center pt-3 pb-2 mb-3 border-bottom">
<h1 class="h2">
<i class="fas fa-tachometer-alt"></i> 仪表盘
</h1>
<div class="btn-toolbar mb-2 mb-md-0">
<div class="btn-group me-2">
<button type="button" class="btn btn-sm btn-outline-secondary" οnclick="refreshDashboard()">
<i class="fas fa-sync-alt"></i> 刷新
</button>
</div>
</div>
</div>
<!-- 统计卡片 -->
<div class="row mb-4">
<div class="col-md-3">
<div class="stat-card">
<i class="fas fa-cube"></i>
<div class="number" id="node-count">0</div>
<div class="label">节点总数</div>
</div>
</div>
<div class="col-md-3">
<div class="stat-card">
<i class="fas fa-link"></i>
<div class="number" id="rel-count">0</div>
<div class="label">关系总数</div>
</div>
</div>
<div class="col-md-3">
<div class="stat-card">
<i class="fas fa-tag"></i>
<div class="number" id="label-count">0</div>
<div class="label">标签类型</div>
</div>
</div>
<div class="col-md-3">
<div class="stat-card">
<i class="fas fa-code-branch"></i>
<div class="number" id="rel-type-count">0</div>
<div class="label">关系类型</div>
</div>
</div>
</div>
<div class="row">
<!-- 节点统计 -->
<div class="col-md-6">
<div class="card">
<div class="card-header">
<i class="fas fa-chart-pie"></i> 节点统计（按标签）
</div>
<div class="card-body">
<table class="table table-hover">
<thead>
<tr>
<th>标签</th>
<th>数量</th>
<th>百分比</th>
</tr>
</thead>
<tbody id="node-stats">
{% for stat in stats %}
<tr>
<td>{{ stat.label }}</td>
<td>{{ stat.count }}</td>
<td>
<div class="progress">
<div class="progress-bar"
role="progressbar"
style="width: {{ stat.count * 100 / (stats|sum(attribute='count') or 1) }}%">
</div>
</div>
</td>
</tr>
{% endfor %}
</tbody>
</table>
</div>
</div>
</div>
<!-- 最近添加的节点 -->
<div class="col-md-6">
<div class="card">
<div class="card-header">
<i class="fas fa-history"></i> 最近添加的节点
</div>
<div class="card-body">
<div class="list-group">
{% for node in recent_nodes %}
<a href="#" class="list-group-item list-group-item-action">
<div class="d-flex w-100 justify-content-between">
<h6 class="mb-1">
<span class="badge bg-primary">{{ node.label }}</span>
{{ node.name }}
</h6>
<small>{{ node.created_at }}</small>
</div>
</a>
{% endfor %}
</div>
</div>
</div>
</div>
</div>
<!-- 数据库信息 -->
<div class="card mt-4">
<div class="card-header">
<i class="fas fa-info-circle"></i> 数据库信息
</div>
<div class="card-body">
<div class="accordion" id="dbInfoAccordion">
{% for section, data in db_info.items() %}
<div class="accordion-item">
<h2 class="accordion-header" id="heading{{ loop.index }}">
<button class="accordion-button collapsed" type="button"
data-bs-toggle="collapse" data-bs-target="#collapse{{ loop.index }}">
{{ section }} ({{ data|length }})
</button>
</h2>
<div id="collapse{{ loop.index }}" class="accordion-collapse collapse"
data-bs-parent="#dbInfoAccordion">
<div class="accordion-body">
{% if data is string %}
<p>{{ data }}</p>
{% elif data is mapping %}
<pre>{{ data|tojson(indent=2) }}</pre>
{% else %}
<table class="table table-sm">
{% for item in data %}
<tr>
{% for key, value in item.items() %}
<td><strong>{{ key }}:</strong></td>
<td>{{ value }}</td>
{% endfor %}
</tr>
{% endfor %}
</table>
{% endif %}
</div>
</div>
</div>
{% endfor %}
</div>
</div>
</div>
{% endblock %}
{% block extra_js %}
<script>
// 刷新统计数据
function refreshDashboard() {
showLoading();
fetch('/api/statistics')
.then(response => response.json())
.then(data => {
if (data.success) {
updateStatistics(data.statistics);
}
hideLoading();
})
.catch(error => {
console.error('Error:', error);
hideLoading();
});
}
// 更新统计数据显示
function updateStatistics(stats) {
// 更新节点统计表
const nodeStatsBody = document.getElementById('node-stats');
if (nodeStatsBody && stats.nodes_by_label) {
let totalNodes = 0;
stats.nodes_by_label.forEach(item => {
totalNodes += item.count;
});
nodeStatsBody.innerHTML = stats.nodes_by_label.map(item => `
<tr>
<td>${item.label}</td>
<td>${item.count}</td>
<td>
<div class="progress">
<div class="progress-bar"
role="progressbar"
style="width: ${totalNodes ? (item.count * 100 / totalNodes) : 0}%">
</div>
</div>
</td>
</tr>
`).join('');
// 更新统计卡片
document.getElementById('node-count').textContent = totalNodes;
document.getElementById('label-count').textContent = stats.nodes_by_label.length;
}
// 更新关系统计
if (stats.relationships_by_type) {
let totalRels = 0;
stats.relationships_by_type.forEach(item => {
totalRels += item.count;
});
document.getElementById('rel-count').textContent = totalRels;
document.getElementById('rel-type-count').textContent = stats.relationships_by_type.length;
}
}
// 页面加载时获取统计数据
document.addEventListener('DOMContentLoaded', function() {
refreshDashboard();
// 每30秒自动刷新
setInterval(refreshDashboard, 30000);
});
</script>
{% endblock %}templates/query.html
html
{% extends "base.html" %}
{% block title %}查询 - 知识图谱管理系统{% endblock %}
{% block content %}
<div class="d-flex justify-content-between flex-wrap flex-md-nowrap align-items-center pt-3 pb-2 mb-3 border-bottom">
<h1 class="h2">
<i class="fas fa-search"></i> Cypher 查询
</h1>
<div class="btn-toolbar mb-2 mb-md-0">
<div class="btn-group me-2">
<button type="button" class="btn btn-sm btn-outline-primary" οnclick="clearQuery()">
<i class="fas fa-eraser"></i> 清空
</button>
<button type="button" class="btn btn-sm btn-primary" οnclick="executeQuery()">
<i class="fas fa-play"></i> 执行
</button>
</div>
</div>
</div>
<div class="row">
<!-- 查询编辑器 -->
<div class="col-md-8">
<div class="card">
<div class="card-header">
<i class="fas fa-code"></i> 查询编辑器
</div>
<div class="card-body">
<form id="queryForm" method="POST">
<div class="mb-3">
<textarea class="form-control cypher-editor" id="query" name="query"
rows="8" placeholder="输入Cypher查询语句...">{{ query_text }}</textarea>
</div>
<div class="mb-3">
<label class="form-label">查询参数 (JSON格式):</label>
<textarea class="form-control" id="params" name="params"
rows="3" placeholder='{"name": "Alice"}'></textarea>
</div>
<button type="submit" class="btn btn-primary">
<i class="fas fa-play"></i> 执行查询
</button>
<button type="button" class="btn btn-outline-secondary ms-2" οnclick="explainQuery()">
<i class="fas fa-info-circle"></i> 解释执行计划
</button>
</form>
</div>
</div>
</div>
<!-- 查询模板 -->
<div class="col-md-4">
<div class="card">
<div class="card-header">
<i class="fas fa-clipboard-list"></i> 查询模板
</div>
<div class="card-body">
<div class="list-group">
{% for template in query_templates %}
<a href="#" class="list-group-item list-group-item-action"
οnclick="loadTemplate('{{ template.query }}')">
<div class="d-flex w-100 justify-content-between">
<h6 class="mb-1">{{ template.name }}</h6>
</div>
<small class="text-muted">{{ template.query|truncate(50) }}</small>
</a>
{% endfor %}
</div>
<div class="mt-3">
<h6>常用操作:</h6>
<div class="btn-group-vertical w-100">
<button class="btn btn-outline-info text-start"
οnclick="loadTemplate('MATCH (n) RETURN n LIMIT 10')">
<i class="fas fa-cube"></i> 查看所有节点
</button>
<button class="btn btn-outline-info text-start"
οnclick="loadTemplate('MATCH ()-[r]->() RETURN r LIMIT 10')">
<i class="fas fa-link"></i> 查看所有关系
</button>
<button class="btn btn-outline-info text-start"
οnclick="loadTemplate('CALL db.labels()')">
<i class="fas fa-tag"></i> 查看所有标签
</button>
<button class="btn btn-outline-info text-start"
οnclick="loadTemplate('CALL db.relationshipTypes()')">
<i class="fas fa-code-branch"></i> 查看所有关系类型
</button>
</div>
</div>
</div>
</div>
</div>
</div>
<!-- 查询结果 -->
{% if results %}
<div class="card mt-4">
<div class="card-header d-flex justify-content-between align-items-center">
<div>
<i class="fas fa-table"></i> 查询结果
<span class="badge bg-primary ms-2">{{ results|length }} 条记录</span>
</div>
<div>
<button class="btn btn-sm btn-outline-success" οnclick="exportResults()">
<i class="fas fa-download"></i> 导出为JSON
</button>
</div>
</div>
<div class="card-body">
<div class="table-responsive">
{% if results %}
{% set headers = results[0].keys() %}
<table class="table table-striped table-hover">
<thead>
<tr>
{% for header in headers %}
<th>{{ header }}</th>
{% endfor %}
</tr>
</thead>
<tbody>
{% for row in results %}
<tr>
{% for header in headers %}
<td>
{% if row[header] is mapping or row[header] is iterable and row[header] is not string %}
<button class="btn btn-sm btn-outline-info"
οnclick="showDetail('{{ row[header]|tojson|escape }}')">
查看详情
</button>
{% else %}
{{ row[header] }}
{% endif %}
</td>
{% endfor %}
</tr>
{% endfor %}
</tbody>
</table>
{% else %}
<div class="alert alert-info">
没有查询到数据
</div>
{% endif %}
</div>
</div>
</div>
{% endif %}
<!-- 执行计划结果模态框 -->
<div class="modal fade" id="explainModal" tabindex="-1">
<div class="modal-dialog modal-xl">
<div class="modal-content">
<div class="modal-header">
<h5 class="modal-title">执行计划</h5>
<button type="button" class="btn-close" data-bs-dismiss="modal"></button>
</div>
<div class="modal-body">
<pre id="explainResult" class="bg-light p-3"></pre>
</div>
</div>
</div>
</div>
<!-- 详情模态框 -->
<div class="modal fade" id="detailModal" tabindex="-1">
<div class="modal-dialog modal-lg">
<div class="modal-content">
<div class="modal-header">
<h5 class="modal-title">详情</h5>
<button type="button" class="btn-close" data-bs-dismiss="modal"></button>
</div>
<div class="modal-body">
<pre id="detailContent" class="bg-light p-3"></pre>
</div>
</div>
</div>
</div>
{% endblock %}
{% block extra_js %}
<script>
// 加载查询模板
function loadTemplate(query) {
document.getElementById('query').value = query;
}
// 清空查询
function clearQuery() {
document.getElementById('query').value = '';
document.getElementById('params').value = '';
}
// 执行查询
function executeQuery() {
document.getElementById('queryForm').submit();
}
// 解释执行计划
function explainQuery() {
const query = document.getElementById('query').value;
if (!query.trim()) {
alert('请输入查询语句');
return;
}
showLoading();
const explainQuery = 'EXPLAIN ' + query;
const params = document.getElementById('params').value;
let paramObj = {};
try {
if (params.trim()) {
paramObj = JSON.parse(params);
}
} catch (e) {
alert('参数格式错误: ' + e.message);
hideLoading();
return;
}
fetch('/query', {
method: 'POST',
headers: {
'Content-Type': 'application/json',
},
body: JSON.stringify({
query: explainQuery,
params: paramObj,
explain: true
})
})
.then(response => response.json())
.then(data => {
hideLoading();
if (data.success) {
const explainResult = document.getElementById('explainResult');
explainResult.textContent = JSON.stringify(data.result, null, 2);
const modal = new bootstrap.Modal(document.getElementById('explainModal'));
modal.show();
} else {
alert('错误: ' + data.message);
}
})
.catch(error => {
hideLoading();
alert('请求失败: ' + error.message);
});
}
// 显示详情
function showDetail(content) {
const detailContent = document.getElementById('detailContent');
try {
const parsed = JSON.parse(content);
detailContent.textContent = JSON.stringify(parsed, null, 2);
} catch (e) {
detailContent.textContent = content;
}
const modal = new bootstrap.Modal(document.getElementById('detailModal'));
modal.show();
}
// 导出结果为JSON
function exportResults() {
const results = {{ results|tojson|safe }};
const dataStr = JSON.stringify(results, null, 2);
const dataUri = 'data:application/json;charset=utf-8,'+ encodeURIComponent(dataStr);
const exportFileDefaultName = `query_results_${new Date().toISOString().slice(0,10)}.json`;
const linkElement = document.createElement('a');
linkElement.setAttribute('href', dataUri);
linkElement.setAttribute('download', exportFileDefaultName);
linkElement.click();
}
// 添加语法高亮（简化版）
document.addEventListener('DOMContentLoaded', function() {
const textarea = document.getElementById('query');
if (textarea) {
textarea.addEventListener('keydown', function(e) {
if (e.key === 'Tab') {
e.preventDefault();
const start = this.selectionStart;
const end = this.selectionEnd;
// 插入制表符
this.value = this.value.substring(0, start) + ' ' + this.value.substring(end);
// 移动光标位置
this.selectionStart = this.selectionEnd = start + 2;
}
});
}
// 自动调整textarea高度
function autoResize(textarea) {
textarea.style.height = 'auto';
textarea.style.height = (textarea.scrollHeight) + 'px';
}
if (textarea) {
textarea.addEventListener('input', function() {
autoResize(this);
});
autoResize(textarea); // 初始调整
}
});
</script>
{% endblock %}7. 可视化模块
utils/visualizer.py
python
import networkx as nx
import matplotlib.pyplot as plt
import plotly.graph_objects as go
from pyvis.network import Network
import json
import os
class KGVisualizer:
"""知识图谱可视化器"""
def __init__(self, neo4j_connector):
self.conn = neo4j_connector
def create_networkx_graph(self, limit=100):
"""创建NetworkX图"""
G = nx.Graph()
query = f"""
MATCH (n)-[r]->(m)
RETURN
id(n) as source_id,
labels(n)[0] as source_label,
n.name as source_name,
type(r) as relation_type,
id(m) as target_id,
labels(m)[0] as target_label,
m.name as target_name
LIMIT {limit}
"""
results = self.conn.execute_query(query)
for record in results:
source_id = record['source_id']
target_id = record['target_id']
# 添加节点
if source_id not in G:
G.add_node(
source_id,
label=record['source_label'],
name=record['source_name'],
size=10,
color=self._get_color(record['source_label'])
)
if target_id not in G:
G.add_node(
target_id,
label=record['target_label'],
name=record['target_name'],
size=10,
color=self._get_color(record['target_label'])
)
# 添加边
G.add_edge(
source_id,
target_id,
type=record['relation_type'],
weight=1
)
return G
def _get_color(self, label):
"""根据标签获取颜色"""
color_map = {
"Person": "#FF6B6B",
"Company": "#4ECDC4",
"Movie": "#45B7D1",
"Product": "#96CEB4",
"Disease": "#FFEAA7",
"Symptom": "#DDA0DD",
"Drug": "#98D8C8",
"Location": "#F7DC6F"
}
return color_map.get(label, "#AAAAAA")
def create_pyvis_network(self, output_file="graph.html", limit=200):
"""创建Pyvis交互式网络图"""
net = Network(
height="750px",
width="100%",
bgcolor="#222222",
font_color="white",
directed=True
)
query = f"""
MATCH (n)-[r]->(m)
RETURN
id(n) as source_id,
labels(n)[0] as source_label,
n.name as source_name,
type(r) as relation_type,
properties(r) as rel_props,
id(m) as target_id,
labels(m)[0] as target_label,
m.name as target_name
LIMIT {limit}
"""
results = self.conn.execute_query(query)
added_nodes = set()
for record in results:
source_id = record['source_id']
target_id = record['target_id']
# 添加源节点
if source_id not in added_nodes:
net.add_node(
source_id,
label=record['source_name'] or f"{record['source_label']}_{source_id}",
title=f"""
标签: {record['source_label']}<br>
ID: {source_id}<br>
{self._format_properties(record.get('source_props', {}))}
""",
color=self._get_color(record['source_label']),
size=15
)
added_nodes.add(source_id)
# 添加目标节点
if target_id not in added_nodes:
net.add_node(
target_id,
label=record['target_name'] or f"{record['target_label']}_{target_id}",
title=f"""
标签: {record['target_label']}<br>
ID: {target_id}<br>
{self._format_properties(record.get('target_props', {}))}
""",
color=self._get_color(record['target_label']),
size=15
)
added_nodes.add(target_id)
# 添加边
rel_title = f"类型: {record['relation_type']}<br>"
if record.get('rel_props'):
rel_title += self._format_properties(record['rel_props'])
net.add_edge(
source_id,
target_id,
title=rel_title,
label=record['relation_type'],
color="#888888",
width=2
)
# 设置物理布局
net.set_options("""
var options = {
"physics": {
"barnesHut": {
"gravitationalConstant": -80000,
"centralGravity": 0.3,
"springLength": 95,
"springConstant": 0.04,
"damping": 0.09,
"avoidOverlap": 0
},
"minVelocity": 0.75,
"solver": "barnesHut"
}
}
""")
# 保存为HTML文件
net.save_graph(output_file)
return output_file
def _format_properties(self, props):
"""格式化属性显示"""
if not props:
return ""
lines = []
for key, value in props.items():
if isinstance(value, str):
value = value[:50] + "..." if len(value) > 50 else value
lines.append(f"{key}: {value}")
return "<br>".join(lines)
def create_plotly_visualization(self, limit=100):
"""创建Plotly可视化"""
G = self.create_networkx_graph(limit)
if not G.nodes():
return None
# 获取节点位置（使用spring布局）
pos = nx.spring_layout(G, k=1, iterations=50)
# 创建边迹
edge_x = []
edge_y = []
edge_text = []
for edge in G.edges(data=True):
x0, y0 = pos[edge[0]]
x1, y1 = pos[edge[1]]
edge_x.append(x0)
edge_x.append(x1)
edge_x.append(None)
edge_y.append(y0)
edge_y.append(y1)
edge_y.append(None)
edge_text.append(edge[2].get('type', ''))
edge_trace = go.Scatter(
x=edge_x, y=edge_y,
line=dict(width=0.5, color='#888'),
hoverinfo='none',
mode='lines'
)
# 创建节点迹
node_x = []
node_y = []
node_text = []
node_color = []
node_size = []
for node in G.nodes(data=True):
x, y = pos[node[0]]
node_x.append(x)
node_y.append(y)
node_data = node[1]
label = node_data.get('label', 'Node')
name = node_data.get('name', f'Node_{node[0]}')
node_text.append(f"{label}: {name}")
node_color.append(node_data.get('color', '#AAAAAA'))
node_size.append(node_data.get('size', 10))
node_trace = go.Scatter(
x=node_x, y=node_y,
mode='markers',
hoverinfo='text',
marker=dict(
size=node_size,
color=node_color,
line_width=2
),
text=node_text
)
# 创建图
fig = go.Figure(data=[edge_trace, node_trace],
layout=go.Layout(
title='知识图谱可视化',
titlefont_size=16,
showlegend=False,
hovermode='closest',
margin=dict(b=20, l=5, r=5, t=40),
xaxis=dict(showgrid=False, zeroline=False, showticklabels=False),
yaxis=dict(showgrid=False, zeroline=False, showticklabels=False)
))
return fig.to_html(full_html=False)
def export_graph_json(self, filename="graph_data.json"):
"""导出图为JSON格式"""
query = """
MATCH (n)-[r]->(m)
RETURN
id(n) as source_id,
labels(n) as source_labels,
properties(n) as source_properties,
type(r) as relationship_type,
properties(r) as relationship_properties,
id(m) as target_id,
labels(m) as target_labels,
properties(m) as target_properties
LIMIT 500
"""
results = self.conn.execute_query(query)
# 构建图数据
nodes = {}
edges = []
for record in results:
# 处理源节点
source_id = record['source_id']
if source_id not in nodes:
nodes[source_id] = {
"id": source_id,
"labels": record['source_labels'],
"properties": record['source_properties']
}
# 处理目标节点
target_id = record['target_id']
if target_id not in nodes:
nodes[target_id] = {
"id": target_id,
"labels": record['target_labels'],
"properties": record['target_properties']
}
# 添加边
edges.append({
"source": source_id,
"target": target_id,
"type": record['relationship_type'],
"properties": record['relationship_properties']
})
graph_data = {
"nodes": list(nodes.values()),
"edges": edges,
"metadata": {
"node_count": len(nodes),
"edge_count": len(edges)
}
}
# 保存到文件
with open(filename, 'w', encoding='utf-8') as f:
json.dump(graph_data, f, ensure_ascii=False, indent=2)
return filename8. 运行应用
requirements.txt
text
flask==2.3.2
neo4j==5.14.0
py2neo==2021.2.3
pandas==2.0.3
python-dotenv==1.0.0
flask-cors==4.0.0
networkx==3.1
matplotlib==3.7.2
plotly==5.15.0
pyvis==0.3.2运行步骤：
- 安装依赖：
bash
pip install -r requirements.txt-
配置Neo4j：
-
安装并启动Neo4j Desktop
-
修改默认密码
-
更新
.env文件中的配置
-
-
启动应用：
bash
python app.py-
访问应用：
-
打开浏览器访问
http://localhost:5000 -
查看仪表盘、执行查询、可视化图谱
-
9. 功能特点
-
完整的CRUD操作：支持节点和关系的创建、读取、更新、删除
-
强大的查询功能：支持Cypher查询、查询模板、执行计划
-
交互式可视化：使用Pyvis和Plotly实现图谱可视化
-
数据导入导出：支持CSV/JSON格式的数据导入导出
-
用户友好的界面：Bootstrap响应式设计，支持移动设备
-
实时统计：实时显示数据库统计信息
-
健康检查：监控数据库连接状态
-
示例数据：内置电影和公司知识图谱示例
