eBPF debugfs中的追踪点format实现原理

Kira Skyler2026-02-03 19:58

原文地址：

https://gitee.com/kiraskyler/Articles/blob/master/eBPF/debugfs中的追踪点format实现原理.md

文章目录

How

debugfs中可以通过format查看追踪点的参数

复制代码
# cat /sys/kernel/debug/tracing/events/sched/sched_wakeup/format
name: sched_wakeup
ID: 333
format:
        field:unsigned short common_type;       offset:0;       size:2; signed:0;
......

那么，这里是如何实现的呢？这些信息从哪里来的？

原来以为这些内容来自内核的.BTF节，现在发现是来自于定义追踪点时的宏保存的。。。。。。

Start

复制代码
# cat /sys/kernel/debug/tracing/events/sched/sched_wakeup/format
name: sched_wakeup
ID: 333

根据上面的一点点信息，内核中直接搜索"name，找到位置：

复制代码
/root/qemu/linux-6.6.58/kernel/trace/trace_events.c: 1572

static int f_show(struct seq_file *m, void *v)
{
	struct trace_event_file *file = event_file_data(m->private);
	struct trace_event_call *call = file->event_call;
	struct ftrace_event_field *field;
	const char *array_descriptor;

	switch ((unsigned long)v) {
	case FORMAT_HEADER:
		seq_printf(m, "name: %s\n", trace_event_name(call));
		seq_printf(m, "ID: %d\n", call->event.type);
		seq_puts(m, "format:\n");
		return 0;

不过seq_puts(m, "format:\n")之后就return了，详细的format不是从这里来的

当前文件内由定义这样的结构体用到了f_show

复制代码
/root/qemu/linux-6.6.58/kernel/trace/trace_events.c: 1651

static const struct seq_operations trace_format_seq_ops = {
	.start		= f_start,
	.next		= f_next,
	.stop		= f_stop,
	.show		= f_show,

重要的前三个函数，首先open这个文件时候是f_start

将f_next/f_show的第二个参数v设置成FORMAT_HEADER，即打印前两行提示信息

复制代码
static void *f_start(struct seq_file *m, loff_t *pos)
{
	struct trace_event_file *file;
	void *p = (void *)FORMAT_HEADER;

	/* ->stop() is called even if ->start() fails */
	file = event_file_file(m->private);

	return p; // 返回的是f_next/f_show的第二个参数v

接下载在f_next函数中，第一次进入的v参数即f_start函数中初始化的FORMAT_HEADER

每次显示一行内容时候node = node->prev;，也即ftrace_event_field->prev，每个ftrace_event_field存储的正是一行format显示的参数信息

也就是，参数列表存储存储在file->event_call->class->fields/get_fields

复制代码
/root/qemu/linux-6.6.58/kernel/trace/trace_events.c: 1539

static void *f_next(struct seq_file *m, void *v, loff_t *pos)
{
	struct trace_event_file *file = event_file_data(m->private); // file_inode(m->private)->i_private
	struct trace_event_call *call = file->event_call;
	struct list_head *common_head = &ftrace_common_fields;
	struct list_head *head = trace_get_fields(call); // 参数列表来源：call->class->fields/get_fields
	struct list_head *node = v; // ftrace_event_field->link，参数信息列表

	(*pos)++; // 递增，用来f_show控制显示内容

	switch ((unsigned long)v) {
	case FORMAT_HEADER:
		node = common_head;
		break;

	case FORMAT_FIELD_SEPERATOR:
		node = head; // 参数列表头，呼应1563行
		break;

	case FORMAT_PRINTFMT:
		/* all done */
		return NULL;
	}

	node = node->prev;
	if (node == common_head)
		return (void *)FORMAT_FIELD_SEPERATOR;
	else if (node == head)
		return (void *)FORMAT_PRINTFMT;
	else
		return node;

static inline struct list_head *
trace_get_fields(struct trace_event_call *event_call)
{
	if (!event_call->class->get_fields)
		return &event_call->class->fields;
	return event_call->class->get_fields(event_call);

f_show负责打印struct ftrace_event_field *field中的内容

复制代码
/root/qemu/linux-6.6.58/kernel/trace/trace_events.c: 1572

static int f_show(struct seq_file *m, void *v)
{
	struct trace_event_file *file = event_file_data(m->private);
	struct trace_event_call *call = file->event_call;
	struct ftrace_event_field *field;
	const char *array_descriptor;

	switch ((unsigned long)v) {
	case FORMAT_HEADER:
		seq_printf(m, "name: %s\n", trace_event_name(call));
		seq_printf(m, "ID: %d\n", call->event.type);
		seq_puts(m, "format:\n");
		return 0;

	case FORMAT_FIELD_SEPERATOR:
		seq_putc(m, '\n');
		return 0;

	case FORMAT_PRINTFMT:
		seq_printf(m, "\nprint fmt: %s\n",
			   call->print_fmt);
		return 0;
	}

	field = list_entry(v, struct ftrace_event_field, link); // v是ftrace_event_field->link，找到field

	array_descriptor = strchr(field->type, '['); // eg: unsigned char

		seq_printf(m, "\tfield:%.*s %s[];\toffset:%u;\tsize:%u;\tsigned:%d;\n",
				(int)(array_descriptor - field->type),
				field->type, field->name,
				field->offset, field->size, !!field->is_signed); // 在此显示

ok，知道了参数列表保存在file->event_call->class->fields/get_fields，那么，再看看在哪里初始化

init

当前文件内只有一处设置file->event_call，断点后重新启动kernel

复制代码
/root/qemu/linux-6.6.58/kernel/trace/trace_events.c: 2920

static struct trace_event_file *
trace_create_new_event(struct trace_event_call *call,
		       struct trace_array *tr)
{
    ......

	file->event_call = call

-exec bt
#0  trace_create_new_event (call=call@entry=0xffffffff82e25a60 <event_ma_op>, tr=tr@entry=0xffffffff82d4b5e0 <global_trace>) at kernel/trace/trace_events.c:2929
#1  0xffffffff811b616a in __trace_early_add_new_event (tr=0xffffffff82d4b5e0 <global_trace>, call=0xffffffff82e25a60 <event_ma_op>) at kernel/trace/trace_events.c:3035
#2  __trace_early_add_events (tr=tr@entry=0xffffffff82d4b5e0 <global_trace>) at kernel/trace/trace_events.c:3727
#3  0xffffffff8336d2fd in event_trace_enable () at kernel/trace/trace_events.c:3987
#4  trace_event_init () at kernel/trace/trace_events.c:4067
#5  0xffffffff8336ccb1 in trace_init () at kernel/trace/trace.c:10594
#6  0xffffffff83338ba0 in start_kernel () at init/main.c:970

call参数在#2传递而来，来自于ftrace_events

复制代码
/root/qemu/linux-6.6.58/kernel/trace/trace_events.c: 3716

void __trace_early_add_events(struct trace_array *tr)
{
	struct trace_event_call *call;
	int ret;

	list_for_each_entry(call, &ftrace_events, list) {
		/* Early boot up should not have any modules loaded */
		if (!(call->flags & TRACE_EVENT_FL_DYNAMIC) &&
		    WARN_ON_ONCE(call->module))
			continue;

		ret = __trace_early_add_new_event(call, tr);

再继续找到call是从__start_ftrace_events加载而来

复制代码
kernel/trace/trace_events.c:3962

static __init int event_trace_enable(void)
{
	struct trace_array *tr = top_trace_array();
	struct trace_event_call **iter, *call;
	int ret;

	for_each_event(iter, __start_ftrace_events, __stop_ftrace_events) {

		call = *iter;
		ret = event_init(call);
		if (!ret)
			list_add(&call->list, &ftrace_events);

-exec bt
#0  event_trace_enable () at kernel/trace/trace_events.c:3968
#1  trace_event_init () at kernel/trace/trace_events.c:4067
#2  0xffffffff8336ccb1 in trace_init () at kernel/trace/trace.c:10594
#3  0xffffffff83338ba0 in start_kernel () at init/main.c:970

__start_ftrace_events则是vmlinux的_ftrace_events节地址

复制代码
/root/qemu/linux-6.6.58/arch/x86/kernel/vmlinux.lds： 73

__start_ftrace_events = .; KEEP(*(_ftrace_events)

_ftrace_events section

SYSCALL_DEFINEx Macro

这里是一个系统调用追踪点定义：

复制代码
/root/qemu/linux-6.6.58/include/linux/syscalls.h: 141

#define SYSCALL_TRACE_ENTER_EVENT(sname)				\
	static struct syscall_metadata __syscall_meta_##sname;		\ // 前向声明，实际在SYSCALL_METADATA中定义
	static struct trace_event_call __used				\
	  event_enter_##sname = {					\
		.class			= &event_class_syscall_enter,	\
		{							\
			.name                   = "sys_enter"#sname,	\
		},							\
		.event.funcs            = &enter_syscall_print_funcs,	\
		.data			= (void *)&__syscall_meta_##sname,\ // 这里的types/args分别保存参数类型和参数名称列表
		.flags                  = TRACE_EVENT_FL_CAP_ANY,	\
	};								\
	static struct trace_event_call __used				\
	  __section("_ftrace_events")					\
	 *__event_enter_##sname = &event_enter_##sname; // event_enter_##sname指针地址放到_ftrace_events节中

#define SYSCALL_METADATA(sname, nb, ...)			\
	static const char *types_##sname[] = {			\ // 前向声明参数列表
		__MAP(nb,__SC_STR_TDECL,__VA_ARGS__)		\
	};							\
	static const char *args_##sname[] = {			\
		__MAP(nb,__SC_STR_ADECL,__VA_ARGS__)		\ // 前向声明参数名称
	};							\
	SYSCALL_TRACE_ENTER_EVENT(sname);			\
	SYSCALL_TRACE_EXIT_EVENT(sname);			\
	static struct syscall_metadata __used			\
	  __syscall_meta_##sname = {				\
		.name 		= "sys"#sname,			\
		.syscall_nr	= -1,	/* Filled in at boot */	\
		.nb_args 	= nb,				\
		.types		= nb ? types_##sname : NULL,	\ // 参数列表
		.args		= nb ? args_##sname : NULL,	\ // 参数名称列表
		.enter_event	= &event_enter_##sname,		\
		.exit_event	= &event_exit_##sname,		\
		.enter_fields	= LIST_HEAD_INIT(__syscall_meta_##sname.enter_fields), \
	};							\
	static struct syscall_metadata __used			\
	  __section("__syscalls_metadata")			\
	 *__p_syscall_meta_##sname = &__syscall_meta_##sname; // __syscall_meta_##sname指针地址放到__syscalls_metadata节中

#define SYSCALL_DEFINE1(name, ...) SYSCALL_DEFINEx(1, _##name, __VA_ARGS__) // 一个参数的系统调用宏定义

#define SYSCALL_DEFINEx(x, sname, ...)				\
	SYSCALL_METADATA(sname, x, __VA_ARGS__)			\ // 这里定义参数

_ftrace_events节中存储的是struct trace_event_call的地址

struct trace_event_call->data->types/args分别是在定义追踪点时通过宏创建出的参数/参数名称列表，接下来看看这个列表如何被使用到

ftrace_event_field

还是在内核启动阶段，会遍历call

遍历fields_array将参数列表放到call->class->fields/get_fields中，而field->type == TRACE_FUNCTION_TYPE时候会调用define_fields将参数列表放到call->class->fields/get_fields中

复制代码
/root/qemu/linux-6.6.58/kernel/trace/trace_events.c: 2415

static int
event_define_fields(struct trace_event_call *call)
{
	head = trace_get_fields(call);
	if (list_empty(head)) {

		struct trace_event_fields *field = call->class->fields_array;
		unsigned int offset = sizeof(struct trace_entry);

		for (; field->type; field++) {
			if (field->type == TRACE_FUNCTION_TYPE) {// syscall_enter类型fields在此填充
				field->define_fields(call);
				break;
			}
			// 大多其他类型tracepoint走下面的define_fields_ext，作用差不多都是填充到call->class->fields
			offset = ALIGN(offset, field->align);
			ret = trace_define_field_ext(call, field->type, field->name,
						 offset, field->size,
						 field->is_signed, field->filter_type,
						 field->len); // 每个参数信息独立添加到对应的ftrace_event_field

/root/qemu/linux-6.6.58/kernel/trace/trace_events.c: 115

static int __trace_define_field(struct list_head *head, const char *type,
				const char *name, int offset, int size,
				int is_signed, int filter_type, int len)
{
	struct ftrace_event_field *field;

	field = kmem_cache_alloc(field_cachep, GFP_TRACE);

	field->name = name;
	field->type = type;
    ......

    list_add(&field->link, head); // head = call->class->fields/get_fields

#0  __trace_define_field (len=0, filter_type=0, is_signed=0, size=8, offset=8, name=0xffffffff82446089 "fn", type=0xffffffff8243b227 "const char *", head=0xffffffff82e35b50 <event_class_ma_op+48>) at kernel/trace/trace_events.c:121
#1  trace_define_field_ext (len=<optimized out>, filter_type=0, is_signed=<optimized out>, size=8, offset=8, name=0xffffffff82446089 "fn", type=0xffffffff8243b227 "const char *", call=0xffffffff82e25a60 <event_ma_op>) at kernel/trace/trace_events.c:168
#2  event_define_fields (call=call@entry=0xffffffff82e25a60 <event_ma_op>) at kernel/trace/trace_events.c:2437
#3  0xffffffff811b6264 in event_define_fields (call=0xffffffff82e25a60 <event_ma_op>) at kernel/trace/trace_events.c:3732
#4  __trace_early_add_new_event (tr=0xffffffff82d4b5e0 <global_trace>, call=0xffffffff82e25a60 <event_ma_op>) at kernel/trace/trace_events.c:3039
#5  __trace_early_add_events (tr=tr@entry=0xffffffff82d4b5e0 <global_trace>) at kernel/trace/trace_events.c:3727
#6  0xffffffff8336d2fd in event_trace_enable () at kernel/trace/trace_events.c:3987
#7  trace_event_init () at kernel/trace/trace_events.c:4067
#8  0xffffffff8336ccb1 in trace_init () at kernel/trace/trace.c:10594
#9  0xffffffff83338ba0 in start_kernel () at init/main.c:970

so，参数来源于trace_event_class->fields_array

SYSCALL_DEFINEx

再看一下系统调用追踪点时候fields_array内容：

fields_array开头的SYSCALL_FIELD(int, __syscall_nr)是通用的

接下来通过type = TRACE_FUNCTION_TYPE换SYSCALL提供的函数syscall_enter_define_fields自己遍历call->data中的types类型列表和args参数名列表到call->class->fields/get_fields中

复制代码
/root/qemu/linux-6.6.58/kernel/trace/trace_syscalls.c：270

static int __init syscall_enter_define_fields(struct trace_event_call *call)
{
	struct syscall_trace_enter trace;
	struct syscall_metadata *meta = call->data;
	int offset = offsetof(typeof(trace), args);
	int ret = 0;
	int i;

	for (i = 0; i < meta->nb_args; i++) {
		ret = trace_define_field(call, meta->types[i],
					 meta->args[i], offset,
					 sizeof(unsigned long), 0,
					 FILTER_OTHER);

static struct trace_event_fields __refdata syscall_enter_fields_array[] = {
	SYSCALL_FIELD(int, __syscall_nr),
	{ .type = TRACE_FUNCTION_TYPE,
	  .define_fields = syscall_enter_define_fields },

struct trace_event_class __refdata event_class_syscall_enter = {
	.fields_array	= syscall_enter_fields_array,

TRACE_EVENT Macro

在看一下大多埋于各处的其他追踪点的定义方法：

复制代码
/root/qemu/linux-6.6.58/include/trace/events/sched.h: 222

TRACE_EVENT(sched_switch,

    ......

	TP_STRUCT__entry(
		__array(	char,	prev_comm,	TASK_COMM_LEN	)
		__field(	pid_t,	prev_pid			)
		__field(	int,	prev_prio			)
		__field(	long,	prev_state			)
		__array(	char,	next_comm,	TASK_COMM_LEN	)

TRACE_EVENT在include/trace/trace_events.h被分步解析，很像lsm框架的用法，每一次步骤替换一下某些宏的实现

最开始是定义TRACE_EVENT为DECLARE_EVENT_CLASS，后面分步骤替换DECLARE_EVENT_CLASS实现

复制代码
/root/qemu/linux-6.6.58/include/trace/trace_events.h: 38

#undef TRACE_EVENT
#define TRACE_EVENT(name, proto, args, tstruct, assign, print) \
	DECLARE_EVENT_CLASS(name,			       \
			     PARAMS(proto),		       \
			     PARAMS(args),		       \
			     PARAMS(tstruct),		       \
			     PARAMS(assign),		       \
			     PARAMS(print));		       \

第4步时候

TP_STRUCT__entry{__array( char, next_comm, TASK_COMM_LEN为例，__array的内容即被展开到struct trace_event_fields结构体信息，这个结构体正是trace_event_class->fields_array需要的

复制代码
/root/qemu/linux-6.6.58/include/trace/stages/stage4_event_fields.h: 26

#define __array(_type, _item, _len) {					\
	.type = #_type"["__stringify(_len)"]", .name = #_item,		\
	.size = sizeof(_type[_len]), .align = ALIGN_STRUCTFIELD(_type),	\
	.is_signed = is_signed_type(_type), .filter_type = FILTER_OTHER,\
	.len = _len },

#include "stages/stage4_event_fields.h"

#define DECLARE_EVENT_CLASS(call, proto, args, tstruct, func, print)	\
static struct trace_event_fields trace_custom_event_fields_##call[] = {	\
	tstruct								\
	{} };

所以第7步时候.fields_array=第四步生成的结构体

复制代码
/root/qemu/linux-6.6.58/include/trace/trace_events.h: 421

#include "stages/stage7_class_define.h"

#define DECLARE_EVENT_CLASS(call, proto, args, tstruct, assign, print) \
static char custom_print_fmt_##call[] = print;					\
static struct trace_event_class __used __refdata custom_event_class_##call = { \
	.system			= TRACE_SYSTEM_STRING,			\
	.fields_array		= trace_custom_event_fields_##call,		\

同样，_ftrace_events节中存储trace_event_call地址，trace_event_call->class->fields_array就是参数和参数名列表

复制代码
/root/qemu/linux-6.6.58/include/trace/trace_events.h: 440

static struct trace_event_call __used event_##call = {			\
	.class			= &event_class_##template,		\

static struct trace_event_call __used					\
__section("_ftrace_events") *__event_##call = &event_##call

即，TRACE_EVENT时候通过分步的宏解析，参数列表和参数名列表都直接被存储到trace_event_class->fields_array中，在内核启动时候这些信息会被展开到trace_event_class->fields中以供读取format文件时使用。

End

  • 定义追踪点时候通过宏定义生成了trace_event_class结构，trace_event_class->fields_array包含了参数或参数名称列表（TRACE_EVENT），或找到保存参数和参数名列表的函数方法（syscall宏），trace_event_call->class指向trace_event_class地址，所有追踪点的trace_event_call的地址则存放到_ftrace_events节中
  • 构建内核时，通过链接脚本将__start_ftrace_events = _ftrace_events节地址
  • 启动内核时，遍历__start_ftrace_events指向的区域中的地址，将这些trace_event_class->fields_array中的列表保存到trace_event_class->fields中
  • 当读取到[event]/format时候遍历trace_event_class->fields链表即可
相关推荐
groundhappy21 小时前
idalib安装和codex ida-mcp配置
linux·开发语言·python
通信小小昕21 小时前
Ubuntu 26.04 中文输入法安装
linux·运维·ubuntu
张小姐的猫1 天前
【Linux】网络编程 —— HTTP协议（上）
linux·运维·服务器·网络·http·单例模式·策略模式
栩栩云生1 天前
AI 写代码犯的错，早被写进了错题集
linux·安全·ai编程
imc.111 天前
linux基础IO
linux·运维·服务器
BelongPanda1 天前
Linux Nginx 纯手动 Let‘s Encrypt 泛域名证书配置教程
linux·nginx
酷可达拉斯1 天前
Linux操作系统-shell编程(0)
linux·运维·服务器·python·云计算
2301_777998341 天前
Linux中断机制：操作系统如何高效运行
linux·运维·服务器
yunwei371 天前
eBPF 教程：检查 exec 后真正安装的可执行镜像
linux·开源
笑锝没心没肺1 天前
yum update 报错：GPG key retrieval failed: [Errno 14] HTTPS Error 404 - Not Found
linux·运维·服务器
热门推荐
012026年7月AI圈大地震：GPT-5.6被政府限制、Claude入驻Slack、Anthropic自研芯片02GitHub 镜像站点03如何新建文件夹？ 电脑新建文件夹的4种方法04AI科技热点日报 | 2026年07月01日05幻兽帕鲁 - 服务器管理员权限与 GM 命令完全指南06国内可直接用、免费额度/永久免费的大模型API清单（含 SiliconFlow、火山、阿里、智谱、百度、Kimi、DeepSeek、DMXAPI 等）07AI 编程 IDE 全景解析 2026：Agent 全面接管开发链路082026 国产 AI 大模型横评：DeepSeek、通义千问、Kimi、文心一言、星火、豆包谁更能打？092026 年 AI 大模型 & AI 编程工具实战全总结10【解构】DeepSeek V4 发布：技术报告深度解读 + 横向对比六大开源模型，我们的判断是……
