一、前言:当AI作曲伙伴常驻屏幕边缘
音乐创作是一项需要灵感与技艺并重的艺术活动。在移动设备上进行音乐创作时,开发者(音乐创作者)常常面临这样的困境:需要在编曲软件、音效库、教程文档之间频繁切换;灵感迸发时找不到合适的和弦进行;对混音效果不满意却不知道如何调整参数。
HarmonyOS 6(API 23)带来的悬浮导航(Floating Navigation)和 沉浸光感(Immersive Lighting)能力,让我们有机会打造一个常驻屏幕边缘的AI音乐创作伙伴------它像一位懂音乐的搭档,在你创作时静静悬浮在屏幕角落,当你遇到和声瓶颈时随时唤出建议;它通过光效感知你的创作情绪,在你陷入僵局时温柔启发,在你完成精彩段落时为你喝彩。
核心创新点:
- 🎵 智能和声推荐:悬浮窗实时分析当前旋律,推荐和弦进行与配器方案
- 💡 情绪光感反馈:通过设备边框光效颜色变化,反映音乐情绪与创作状态
- 🤖 多模态智能体:支持哼唱输入、手势节奏输入、歌词生成三种交互方式
- 🎹 协作创作模式:支持多人通过悬浮窗实时协作,光效同步显示创作节奏
二、应用场景设计
2.1 场景一:旋律和声化
当你在编曲界面输入一段旋律后,悬浮胶囊自动识别调性与情绪,轻点展开即可看到AI推荐的和弦进行方案,包括流行、爵士、电子等多种风格,并可直接试听。
2.2 场景二:情绪配色
你正在创作一首悲伤的慢歌,智能体通过分析你的旋律走向,自动将设备边框调整为深蓝色呼吸光效;当你切换到欢快的段落时,光效自动变为明黄色跳跃节奏,帮助你保持创作情绪的一致性。
2.3 场景三:协作光效
在多人协作创作模式下,每位协作者的设备边框显示不同颜色的光效,当某位成员正在输入音符时,其对应颜色的光效会闪烁,其他人可以直观感知到谁在创作、创作节奏如何。
三、技术架构
┌─────────────────────────────────────────────────────────────┐
│ HarmonyOS Music Creation Workshop Agent │
├─────────────┬─────────────┬─────────────┬───────────────────┤
│ 悬浮窗UI │ 沉浸光感 │ 智能体引擎 │ 音频分析模块 │
│ FloatUI │ Lighting │ AI Engine │ AudioAnalyzer │
├─────────────┴─────────────┴─────────────┴───────────────────┤
│ 音乐创作上下文层(Music Context) │
│ 旋律分析 │ 和声生成 │ 节奏识别 │ 情绪检测 │ 协作同步 │
├─────────────────────────────────────────────────────────────┤
│ HarmonyOS 6 (API 23) 系统服务层 │
│ 悬浮导航 │ 光感服务 │ 智能体框架 │ 音频服务 │ 分布式软总线 │
└─────────────────────────────────────────────────────────────┘
四、核心代码实现
4.1 音频上下文感知引擎(MusicContextEngine)
这是整个系统的"耳朵",通过音频服务获取当前创作内容,分析旋律、和声、节奏与情绪。
typescript
// engine/MusicContextEngine.ets
import { audio } from '@kit.AudioKit';
import { BusinessError } from '@kit.BasicServicesKit';
export interface MusicContext {
key: string; // 当前调性
tempo: number; // BPM
timeSignature: string; // 拍号
melodyNotes: NoteEvent[]; // 旋律音符序列
detectedMood: MusicMood; // 检测到的情绪
harmonicComplexity: number; // 和声复杂度 0-100
currentChord: string; // 当前和弦
nextSuggestions: ChordProgression[]; // 下一段推荐
}
export enum MusicMood {
JOYFUL = 'joyful', // 欢快
MELANCHOLY = 'melancholy', // 忧郁
ENERGETIC = 'energetic', // 激昂
PEACEFUL = 'peaceful', // 宁静
TENSE = 'tense', // 紧张
ROMANTIC = 'romantic' // 浪漫
}
export interface NoteEvent {
pitch: number; // MIDI音高
velocity: number; // 力度
startTime: number; // 开始时间(拍)
duration: number; // 时长(拍)
}
export interface ChordProgression {
name: string;
chords: string[];
style: string;
confidence: number;
previewNotes: number[][];
}
export class MusicContextEngine {
private audioCapturer: audio.AudioCapturer | null = null;
private analysisInterval: number = 0;
private contextCallbacks: Array<(context: MusicContext) => void> = [];
private noteBuffer: NoteEvent[] = [];
private lastAnalysisTime: number = 0;
/**
* 初始化音频上下文感知
* 亮点:通过音频捕获分析当前创作内容,无需修改宿主应用
*/
async init(): Promise<void> {
try {
// 配置音频捕获参数
const capturerInfo: audio.AudioCapturerInfo = {
source: audio.SourceType.MIC,
capturerFlags: 0
};
const audioStreamInfo: audio.AudioStreamInfo = {
samplingRate: audio.AudioSamplingRate.SAMPLE_RATE_44100,
channels: audio.AudioChannel.CHANNEL_2,
sampleFormat: audio.AudioSampleFormat.SAMPLE_FORMAT_S16LE,
encodingType: audio.AudioEncodingType.ENCODING_TYPE_RAW
};
this.audioCapturer = await audio.createAudioCapturer(capturerInfo, audioStreamInfo);
// 开始捕获音频数据
await this.audioCapturer.start();
// 设置定时分析(每2秒分析一次)
this.analysisInterval = setInterval(() => this.analyzeAudio(), 2000);
console.info('[MusicContext] 音频上下文感知引擎初始化完成');
} catch (err) {
console.error(`[MusicContext] 初始化失败: ${JSON.stringify(err)}`);
}
}
/**
* 分析音频数据,提取音乐上下文
* 策略:音高追踪 + 节奏检测 + 情绪识别
*/
private async analyzeAudio(): Promise<void> {
if (!this.audioCapturer) return;
try {
// 读取音频数据
const bufferSize = 4096;
const audioData = new ArrayBuffer(bufferSize);
const readSize = await this.audioCapturer.read(audioData, bufferSize);
if (readSize <= 0) return;
// 音高追踪(简化实现,实际需使用YIN或CREPE算法)
const pitches = this.extractPitches(audioData);
// 更新音符缓冲区
this.updateNoteBuffer(pitches);
// 分析和声与情绪
const context = this.buildMusicContext();
// 通知订阅者
this.contextCallbacks.forEach(cb => cb(context));
} catch (err) {
console.error(`[MusicContext] 分析失败: ${JSON.stringify(err)}`);
}
}
/**
* 从音频数据提取音高
* 简化实现:使用自相关法
*/
private extractPitches(audioData: ArrayBuffer): number[] {
const dataView = new DataView(audioData);
const samples: number[] = [];
// 将16位PCM转换为浮点数
for (let i = 0; i < audioData.byteLength; i += 2) {
const sample = dataView.getInt16(i, true) / 32768.0;
samples.push(sample);
}
// 简化的音高检测(实际项目中应使用更精确的算法)
const pitches: number[] = [];
// ... 音高检测逻辑
return pitches;
}
private updateNoteBuffer(pitches: number[]): void {
const now = Date.now();
pitches.forEach(pitch => {
if (pitch > 0) {
this.noteBuffer.push({
pitch: Math.round(pitch),
velocity: 80,
startTime: now,
duration: 0.5
});
}
});
// 清理过期音符(保留最近10秒)
this.noteBuffer = this.noteBuffer.filter(n => now - n.startTime < 10000);
}
/**
* 构建音乐上下文
*/
private buildMusicContext(): MusicContext {
const notes = this.noteBuffer;
// 推断调性
const key = this.detectKey(notes);
// 推断BPM
const tempo = this.detectTempo(notes);
// 检测情绪
const mood = this.detectMood(notes, key);
// 计算和声复杂度
const complexity = this.calculateHarmonicComplexity(notes);
// 生成和弦建议
const suggestions = this.generateChordSuggestions(key, mood);
return {
key,
tempo,
timeSignature: '4/4',
melodyNotes: notes,
detectedMood: mood,
harmonicComplexity: complexity,
currentChord: this.detectCurrentChord(notes),
nextSuggestions: suggestions
};
}
/**
* 调性检测
* 基于音符分布统计
*/
private detectKey(notes: NoteEvent[]): string {
if (notes.length === 0) return 'C Major';
const pitchClasses = new Array(12).fill(0);
notes.forEach(n => {
pitchClasses[n.pitch % 12]++;
});
// 简化的调性检测:找最大概率
const keyProfiles = this.getKeyProfiles();
let bestKey = 'C Major';
let bestScore = -1;
keyProfiles.forEach((profile, key) => {
let score = 0;
profile.forEach((weight, pc) => {
score += pitchClasses[pc] * weight;
});
if (score > bestScore) {
bestScore = score;
bestKey = key;
}
});
return bestKey;
}
/**
* 情绪检测
* 基于音高走向、节奏密度、音程大小
*/
private detectMood(notes: NoteEvent[], key: string): MusicMood {
if (notes.length < 3) return MusicMood.PEACEFUL;
// 分析音高走向
let ascending = 0, descending = 0;
for (let i = 1; i < notes.length; i++) {
if (notes[i].pitch > notes[i-1].pitch) ascending++;
else if (notes[i].pitch < notes[i-1].pitch) descending++;
}
// 分析平均音高
const avgPitch = notes.reduce((sum, n) => sum + n.pitch, 0) / notes.length;
// 分析节奏密度
const density = notes.length / ((notes[notes.length-1].startTime - notes[0].startTime) / 1000);
// 综合判断
if (density > 4 && ascending > descending) return MusicMood.ENERGETIC;
if (density < 2 && descending > ascending) return MusicMood.MELANCHOLY;
if (avgPitch > 60 && ascending > descending) return MusicMood.JOYFUL;
if (density > 3 && Math.abs(ascending - descending) < 2) return MusicMood.TENSE;
return MusicMood.PEACEFUL;
}
/**
* 生成和弦进行建议
*/
private generateChordSuggestions(key: string, mood: MusicMood): ChordProgression[] {
const progressions: ChordProgression[] = [];
// 基于调性和情绪推荐经典进行
const suggestions = this.getProgressionDatabase(key, mood);
suggestions.forEach(prog => {
progressions.push({
name: prog.name,
chords: prog.chords,
style: prog.style,
confidence: prog.confidence,
previewNotes: this.chordsToNotes(prog.chords)
});
});
return progressions;
}
private getKeyProfiles(): Map<string, number[]> {
// 返回各调性的音级权重分布
const profiles = new Map<string, number[]>();
profiles.set('C Major', [1, 0, 0.8, 0, 0.9, 0.7, 0, 1, 0, 0.6, 0, 0.5]);
profiles.set('G Major', [0.5, 0, 0.6, 0, 0.8, 0.7, 0, 1, 0, 0.9, 0, 0.8]);
// ... 更多调性
return profiles;
}
private getProgressionDatabase(key: string, mood: MusicMood): any[] {
// 返回预定义的和弦进行数据库
const database: Record<string, any[]> = {
'C Major': [
{ name: '流行进行 I-V-vi-IV', chords: ['C', 'G', 'Am', 'F'], style: 'pop', confidence: 0.95 },
{ name: '爵士进行 ii-V-I', chords: ['Dm7', 'G7', 'Cmaj7'], style: 'jazz', confidence: 0.88 },
{ name: '抒情进行 I-vi-IV-V', chords: ['C', 'Am', 'F', 'G'], style: 'ballad', confidence: 0.92 }
]
};
return database[key] || [];
}
private chordsToNotes(chords: string[]): number[][] {
// 将和弦名转换为MIDI音符
const chordNotes: Record<string, number[]> = {
'C': [60, 64, 67], 'G': [67, 71, 74], 'Am': [69, 72, 76], 'F': [65, 69, 72],
'Dm7': [62, 65, 69, 72], 'G7': [67, 71, 74, 77], 'Cmaj7': [60, 64, 67, 71]
};
return chords.map(c => chordNotes[c] || [60, 64, 67]);
}
private detectCurrentChord(notes: NoteEvent[]): string {
if (notes.length === 0) return 'N.C.';
// 简化:返回最后一个音符对应的和弦
const lastPitch = notes[notes.length - 1].pitch;
const chordMap: Record<number, string> = { 60: 'C', 62: 'D', 64: 'E', 65: 'F', 67: 'G', 69: 'A', 71: 'B' };
return chordMap[lastPitch % 12] || 'C';
}
private calculateHarmonicComplexity(notes: NoteEvent[]): number {
// 基于音程多样性计算复杂度
const intervals = new Set<number>();
for (let i = 1; i < notes.length; i++) {
intervals.add(Math.abs(notes[i].pitch - notes[i-1].pitch));
}
return Math.min(intervals.size * 10, 100);
}
private detectTempo(notes: NoteEvent[]): number {
if (notes.length < 2) return 120;
const totalTime = notes[notes.length - 1].startTime - notes[0].startTime;
const avgInterval = totalTime / (notes.length - 1);
return Math.round(60000 / avgInterval);
}
onContextChange(callback: (context: MusicContext) => void): void {
this.contextCallbacks.push(callback);
}
getLastContext(): MusicContext | null {
// 返回最后一次分析的上下文
return null;
}
destroy(): void {
clearInterval(this.analysisInterval);
this.audioCapturer?.stop();
this.audioCapturer?.release();
}
}
4.2 沉浸光感音乐情绪反馈(MusicLightingController)
光效不仅是装饰,更是音乐情绪的"可视化延伸"。我们设计了与音乐情绪深度绑定的光效系统。
typescript
// lighting/MusicLightingController.ets
import { lighting } from '@kit.ArkUI';
import { MusicMood } from '../engine/MusicContextEngine';
export class MusicLightingController {
private currentMood: MusicMood = MusicMood.PEACEFUL;
private isCollaborating: boolean = false;
private collaboratorColors: Map<string, string> = new Map();
/**
* 初始化音乐光感
* 设计哲学:光效是音乐的"视觉化延伸"
*/
async init(): Promise<void> {
if (!lighting.isImmersiveLightSupported()) {
console.warn('[MusicLight] 设备不支持沉浸光感');
return;
}
// 初始状态:柔和白色,表示就绪
await this.setLightEffect({
type: 'solid',
position: 'all_edges',
color: '#FFFFFF',
brightness: 20,
duration: 0
});
console.info('[MusicLight] 音乐光感初始化完成');
}
/**
* 根据音乐情绪更新光效
*/
async updateByMood(mood: MusicMood, intensity: number = 0.5): Promise<void> {
this.currentMood = mood;
const moodEffects: Record<<MusicMood, lighting.LightEffect> = {
[MusicMood.JOYFUL]: {
type: 'flashing',
position: 'all_edges',
color: '#FFD600', // 明黄
brightness: 50 + intensity * 30,
duration: 0,
flashCount: -1, // 持续闪烁
frequency: 500 // 快节奏
},
[MusicMood.MELANCHOLY]: {
type: 'breathing',
position: 'bottom_edge',
color: '#304FFE', // 深蓝
brightness: 30 + intensity * 20,
duration: 0,
frequency: 4000 // 慢呼吸
},
[MusicMood.ENERGETIC]: {
type: 'flashing',
position: 'all_edges',
color: '#FF1744', // 鲜红
brightness: 60 + intensity * 30,
duration: 0,
flashCount: -1,
frequency: 200 // 极快闪
},
[MusicMood.PEACEFUL]: {
type: 'breathing',
position: 'all_edges',
color: '#00E676', // 翠绿
brightness: 30 + intensity * 20,
duration: 0,
frequency: 3000
},
[MusicMood.TENSE]: {
type: 'wave',
position: 'all_edges',
color: '#FF9100', // 琥珀
brightness: 50 + intensity * 20,
duration: 0,
direction: 'clockwise',
speed: 'fast'
},
[MusicMood.ROMANTIC]: {
type: 'breathing',
position: 'all_edges',
color: '#F50057', // 玫红
brightness: 35 + intensity * 25,
duration: 0,
frequency: 2500
}
};
await lighting.setImmersiveLight(moodEffects[mood]);
console.info(`[MusicLight] 情绪光效更新: ${mood}`);
}
/**
* 节拍同步光效
* 根据BPM闪烁,帮助创作者保持节奏感
*/
async syncToBeat(bpm: number, beat: number = 1): Promise<void> {
const interval = 60000 / bpm; // 每拍毫秒数
// 强拍:全边框闪光
if (beat === 1) {
await lighting.setImmersiveLight({
type: 'flashing',
position: 'all_edges',
color: '#FFFFFF',
brightness: 40,
duration: interval * 0.3,
flashCount: 1
});
} else {
// 弱拍:底部边缘微闪
await lighting.setImmersiveLight({
type: 'flashing',
position: 'bottom_edge',
color: '#FFFFFF',
brightness: 20,
duration: interval * 0.2,
flashCount: 1
});
}
}
/**
* 协作创作光效
* 每位协作者分配独特颜色,创作时闪烁
*/
async setCollaboratorColor(userId: string, color: string): Promise<void> {
this.collaboratorColors.set(userId, color);
this.isCollaborating = true;
}
async indicateCollaboratorActive(userId: string): Promise<void> {
const color = this.collaboratorColors.get(userId) || '#FFFFFF';
await lighting.setImmersiveLight({
type: 'flashing',
position: 'left_edge',
color: color,
brightness: 50,
duration: 1000,
flashCount: 2
});
}
/**
* 完成段落庆祝光效
*/
async celebrateCompletion(): Promise<void> {
// 彩虹渐变效果
const colors = ['#FF0000', '#FF7F00', '#FFFF00', '#00FF00', '#0000FF', '#4B0082', '#9400D3'];
for (const color of colors) {
await lighting.setImmersiveLight({
type: 'solid',
position: 'all_edges',
color: color,
brightness: 60,
duration: 200
});
await new Promise(resolve => setTimeout(resolve, 200));
}
// 恢复当前情绪光效
await this.updateByMood(this.currentMood);
}
/**
* 静音/暂停状态
*/
async setPaused(): Promise<void> {
await lighting.setImmersiveLight({
type: 'solid',
position: 'bottom_edge',
color: '#9E9E9E',
brightness: 15,
duration: 0
});
}
async reset(): Promise<void> {
await lighting.resetImmersiveLight();
}
}
4.3 音乐智能体引擎(MusicAgentEngine)
这是系统的"音乐大脑",负责理解和声、生成建议、创作伴奏。
typescript
// agent/MusicAgentEngine.ets
import { ai } from '@kit.AiKit';
import { MusicContext, MusicMood, ChordProgression } from '../engine/MusicContextEngine';
export interface MusicSuggestion {
type: 'chord' | 'melody' | 'rhythm' | 'lyrics' | 'arrangement';
content: string;
preview?: number[]; // MIDI音符预览
confidence: number;
explanation: string;
}
export class MusicAgentEngine {
private agent: ai.AgentSession | null = null;
private styleDatabase: Map<string, any> = new Map();
/**
* 初始化音乐智能体
* 加载音乐理论和声知识库
*/
async init(): Promise<void> {
// 加载本地音乐风格数据库
await this.loadStyleDatabase();
const model = await ai.createModel({
modelId: 'harmonyos-music-v1',
type: ai.ModelType.LOCAL,
capabilities: ['music_theory', 'harmony_analysis', 'composition']
});
this.agent = await ai.createAgentSession({
model: model,
systemPrompt: `你是一位专业的音乐理论家和作曲助手,精通HarmonyOS音频开发。
请基于用户提供的音乐上下文,提供:
1. 符合音乐理论的和声建议
2. 适合当前情绪的配器方案
3. 鸿蒙AudioKit最佳实践
4. 创作技巧和灵感启发
回答请包含具体的和弦名称、MIDI音符编号和实现代码。`
});
console.info('[MusicAgent] 音乐智能体初始化完成');
}
/**
* 生成和声建议
*/
async suggestHarmony(context: MusicContext): Promise<<MusicSuggestion[]> {
if (!this.agent) throw new Error('智能体未初始化');
const suggestions: MusicSuggestion[] = [];
// 基于规则快速生成(低延迟)
const ruleBased = this.generateRuleBasedSuggestions(context);
suggestions.push(...ruleBased);
// AI深度生成(高质量)
const aiBased = await this.generateAISuggestions(context);
suggestions.push(...aiBased);
return suggestions.sort((a, b) => b.confidence - a.confidence);
}
/**
* 基于音乐理论的规则生成
*/
private generateRuleBasedSuggestions(context: MusicContext): MusicSuggestion[] {
const suggestions: MusicSuggestion[] = [];
const key = context.key;
const mood = context.detectedMood;
// 调内和弦功能分析
const diatonicChords = this.getDiatonicChords(key);
// 根据情绪推荐进行
if (mood === MusicMood.JOYFUL) {
suggestions.push({
type: 'chord',
content: `${key} I-V-vi-IV 流行进行`,
preview: this.chordsToMidi(['C4', 'G3', 'A3', 'F3']),
confidence: 0.9,
explanation: '大调正格进行,明亮稳定,适合欢快情绪'
});
} else if (mood === MusicMood.MELANCHOLY) {
suggestions.push({
type: 'chord',
content: `${key} vi-IV-I-V 抒情进行`,
preview: this.chordsToMidi(['A3', 'F3', 'C4', 'G3']),
confidence: 0.85,
explanation: '以小调色彩为主,带有淡淡的忧伤感'
});
}
return suggestions;
}
/**
* AI深度生成建议
*/
private async generateAISuggestions(context: MusicContext): Promise<<MusicSuggestion[]> {
const prompt = `基于以下音乐上下文生成和声建议:
调性:${context.key}
情绪:${context.detectedMood}
当前和弦:${context.currentChord}
旋律片段:${context.melodyNotes.map(n => n.pitch).join(', ')}
请生成3个和声进行建议,包含:
1. 和弦名称与功能
2. 与当前旋律的匹配度分析
3. 情绪一致性评估
4. 鸿蒙AudioKit实现代码片段`;
const result = await this.agent!.invoke({
input: { question: prompt },
options: { maxTokens: 1024, temperature: 0.4 }
});
// 解析AI返回的建议
return this.parseAISuggestions(result);
}
/**
* 生成歌词
*/
async generateLyrics(theme: string, mood: MusicMood, structure: string = 'verse-chorus'): Promise<string> {
if (!this.agent) return '';
const prompt = `请为${mood}情绪的歌曲创作歌词,主题:${theme}。
结构:${structure}(主歌-副歌)
要求:
1. 符合${mood}的情绪色彩
2. 每句字数适合中文歌曲演唱
3. 包含具体的意象和画面感
4. 副歌部分要有记忆点`;
const result = await this.agent.invoke({
input: { question: prompt },
options: { maxTokens: 512, temperature: 0.7 }
});
return result.data?.lyrics || '';
}
/**
* 生成配器方案
*/
async suggestArrangement(context: MusicContext): Promise<<MusicSuggestion> {
const arrangements: Record<<MusicMood, string> = {
[MusicMood.JOYFUL]: '钢琴+吉他+轻打击乐,中高频为主',
[MusicMood.MELANCHOLY]: '钢琴+弦乐+长笛,中低频铺底',
[MusicMood.ENERGETIC]: '电吉他+鼓组+合成器,全频段饱满',
[MusicMood.PEACEFUL]: '钢琴+竖琴+环境音,高频泛音丰富',
[MusicMood.TENSE]: '弦乐颤音+低音鼓+合成器音效',
[MusicMood.ROMANTIC]: '钢琴+小提琴+萨克斯,中频温暖'
};
return {
type: 'arrangement',
content: arrangements[context.detectedMood],
confidence: 0.88,
explanation: `基于${context.detectedMood}情绪的典型配器方案`
};
}
/**
* 节奏建议
*/
async suggestRhythm(style: string, bpm: number): Promise<<MusicSuggestion> {
const rhythms: Record<string, string> = {
'pop': '4/4拍,底鼓+军鼓+踩镲,每小节重拍在1、3',
'jazz': '摇摆节奏,ride镲+军鼓反拍,底鼓 walking bass',
'electronic': '4/4拍,kick每拍一下,hi-hat十六分音符',
'ballad': '6/8拍,钢琴分解和弦+弦乐长音'
};
return {
type: 'rhythm',
content: rhythms[style] || rhythms['pop'],
confidence: 0.9,
explanation: `${style}风格的典型节奏型,BPM ${bpm}`
};
}
private getDiatonicChords(key: string): string[] {
const diatonicMap: Record<string, string[]> = {
'C Major': ['C', 'Dm', 'Em', 'F', 'G', 'Am', 'Bdim'],
'G Major': ['G', 'Am', 'Bm', 'C', 'D', 'Em', 'F#dim']
};
return diatonicMap[key] || diatonicMap['C Major'];
}
private chordsToMidi(chords: string[]): number[] {
// 简化和弦到MIDI转换
const noteMap: Record<string, number> = {
'C3': 48, 'D3': 50, 'E3': 52, 'F3': 53, 'G3': 55, 'A3': 57, 'B3': 59,
'C4': 60, 'D4': 62, 'E4': 64, 'F4': 65, 'G4': 67, 'A4': 69, 'B4': 71
};
return chords.map(c => noteMap[c] || 60);
}
private parseAISuggestions(result: ai.ModelOutput): MusicSuggestion[] {
// 解析AI返回的JSON格式建议
const data = result.data || {};
return (data.suggestions || []).map((s: any) => ({
type: s.type || 'chord',
content: s.content,
preview: s.preview,
confidence: s.confidence || 0.5,
explanation: s.explanation
}));
}
private async loadStyleDatabase(): Promise<void> {
// 加载本地音乐风格数据库
const styles = await import('../resources/music_styles.json');
styles.default.forEach((style: any) => {
this.styleDatabase.set(style.name, style);
});
}
destroy(): void {
this.agent?.destroy();
}
}
4.4 悬浮窗音乐控制面板(MusicFloatWindow)
typescript
// float/MusicFloatWindow.ets
import { window } from '@kit.ArkUI';
import { emitter } from '@kit.BasicServicesKit';
import { MusicContext, ChordProgression } from '../engine/MusicContextEngine';
import { MusicSuggestion } from '../agent/MusicAgentEngine';
export class MusicFloatWindow {
private floatWin: window.Window | null = null;
private currentLevel: 'capsule' | 'panel' | 'full' = 'capsule';
async create(): Promise<void> {
const option: window.WindowOption = {
name: 'MusicWorkshop',
windowType: window.WindowType.TYPE_FLOAT,
ctx: getContext(this)
};
this.floatWin = await window.createWindow(getContext(this), option);
// 胶囊形态:显示当前调性与情绪
await this.floatWin.resize({ width: 100, height: 100 });
await this.floatWin.moveWindowTo({ x: 950, y: 150 });
await this.floatWin.setWindowTouchable(true);
await this.floatWin.setUIContent('pages/MusicCapsulePage');
await this.floatWin.showWindow();
}
async expandToPanel(context: MusicContext, suggestions: MusicSuggestion[]): Promise<void> {
if (!this.floatWin) return;
this.currentLevel = 'panel';
await this.floatWin.resize({ width: 420, height: 680 });
await this.floatWin.moveWindowTo({ x: 580, y: 80 });
await this.floatWin.setUIContent('pages/MusicPanelPage');
emitter.emit('showMusicPanel', { data: { context, suggestions } });
}
async expandToFull(suggestions: MusicSuggestion[]): Promise<void> {
if (!this.floatWin) return;
this.currentLevel = 'full';
await this.floatWin.resize({ width: 600, height: 900 });
await this.floatWin.moveWindowTo({ x: 360, y: 40 });
await this.floatWin.setUIContent('pages/MusicFullPage');
emitter.emit('showMusicFull', { data: { suggestions } });
}
async collapseToCapsule(): Promise<void> {
if (!this.floatWin) return;
this.currentLevel = 'capsule';
await this.floatWin.resize({ width: 100, height: 100 });
await this.floatWin.moveWindowTo({ x: 950, y: 150 });
await this.floatWin.setUIContent('pages/MusicCapsulePage');
}
destroy(): void {
this.floatWin?.destroyWindow();
}
}
4.5 音乐胶囊页面(MusicCapsulePage)
typescript
// pages/MusicCapsulePage.ets
import { emitter } from '@kit.BasicServicesKit';
import { MusicMood } from '../engine/MusicContextEngine';
@Entry
@Component
struct MusicCapsulePage {
@State currentKey: string = 'C';
@State currentMood: MusicMood = MusicMood.PEACEFUL;
@State bpm: number = 120;
@State isPlaying: boolean = false;
private moodEmojis: Record<<MusicMood, string> = {
[MusicMood.JOYFUL]: '😊',
[MusicMood.MELANCHOLY]: '😢',
[MusicMood.ENERGETIC]: '🔥',
[MusicMood.PEACEFUL]: '😌',
[MusicMood.TENSE]: '😰',
[MusicMood.ROMANTIC]: '💕'
};
aboutToAppear() {
emitter.on('updateMusicContext', (event) => {
const ctx = event.data;
this.currentKey = ctx?.key?.split(' ')[0] || 'C';
this.currentMood = ctx?.detectedMood || MusicMood.PEACEFUL;
this.bpm = ctx?.tempo || 120;
});
}
build() {
Stack() {
// 外圈光晕(播放中)
if (this.isPlaying) {
Circle()
.width(110)
.height(110)
.fill(this.getMoodColor())
.opacity(0.3)
.animation({
duration: 1000,
iterations: -1,
curve: Curve.EaseInOut,
playMode: PlayMode.Alternate
})
}
// 主胶囊
Column() {
// 调性显示
Text(`${this.currentKey}`)
.fontSize(28)
.fontWeight(FontWeight.Bold)
.fontColor('#333')
// 情绪表情
Text(this.moodEmojis[this.currentMood])
.fontSize(24)
.margin({ top: 4 })
// BPM
Text(`${this.bpm} BPM`)
.fontSize(10)
.fontColor('#999')
.margin({ top: 4 })
}
.width(100)
.height(100)
.justifyContent(FlexAlign.Center)
.backgroundColor('rgba(255, 255, 255, 0.95)')
.borderRadius(50)
.shadow({ radius: 15, color: 'rgba(0,0,0,0.15)' })
.gesture(
GestureGroup(GestureMode.Sequence,
TapGesture({ count: 1 })
.onAction(() => emitter.emit('expandToPanel')),
TapGesture({ count: 2 })
.onAction(() => emitter.emit('expandToFull')),
LongPressGesture({ duration: 800 })
.onAction(() => emitter.emit('togglePlayback'))
)
)
}
.width('100%')
.height('100%')
.align(Alignment.Center)
}
private getMoodColor(): string {
const colors: Record<<MusicMood, string> = {
[MusicMood.JOYFUL]: '#FFD600',
[MusicMood.MELANCHOLY]: '#304FFE',
[MusicMood.ENERGETIC]: '#FF1744',
[MusicMood.PEACEFUL]: '#00E676',
[MusicMood.TENSE]: '#FF9100',
[MusicMood.ROMANTIC]: '#F50057'
};
return colors[this.currentMood];
}
}
4.6 音乐面板页面(MusicPanelPage)
typescript
// pages/MusicPanelPage.ets
import { emitter } from '@kit.BasicServicesKit';
import { MusicContext, ChordProgression } from '../engine/MusicContextEngine';
import { MusicSuggestion } from '../agent/MusicAgentEngine';
@Entry
@Component
struct MusicPanelPage {
@State context: MusicContext | null = null;
@State suggestions: MusicSuggestion[] = [];
@State selectedSuggestion: number = -1;
@State isPlayingPreview: boolean = false;
aboutToAppear() {
emitter.on('showMusicPanel', (event) => {
this.context = event.data?.context;
this.suggestions = event.data?.suggestions || [];
});
}
build() {
Column() {
// 顶部标题栏
Row() {
Text('🎵 AI音乐助手')
.fontSize(18)
.fontWeight(FontWeight.Bold)
.layoutWeight(1)
Button('收起')
.fontSize(12)
.backgroundColor('#f0f0f0')
.fontColor('#333')
.onClick(() => emitter.emit('collapseToCapsule'))
}
.width('100%')
.padding(16)
// 当前音乐上下文
Column() {
Row() {
Column() {
Text('🎹')
.fontSize(24)
Text(`${this.context?.key || 'C Major'}`)
.fontSize(14)
.fontWeight(FontWeight.Medium)
}
.layoutWeight(1)
Column() {
Text('😊')
.fontSize(24)
Text(`${this.context?.detectedMood || 'peaceful'}`)
.fontSize(14)
}
.layoutWeight(1)
Column() {
Text('⏱️')
.fontSize(24)
Text(`${this.context?.tempo || 120} BPM`)
.fontSize(14)
}
.layoutWeight(1)
}
.width('100%')
.padding(12)
.backgroundColor('#f8f9fa')
.borderRadius(12)
}
.padding(16)
// 和弦建议列表
Text('🎼 和声建议')
.fontSize(16)
.fontWeight(FontWeight.Medium)
.width('100%')
.padding({ left: 16, top: 16, bottom: 8 })
List() {
ForEach(this.suggestions, (suggestion: MusicSuggestion, index: number) => {
ListItem() {
Column() {
Row() {
Text(suggestion.type === 'chord' ? '🎹' :
suggestion.type === 'melody' ? '🎵' :
suggestion.type === 'rhythm' ? '🥁' : '🎸')
.fontSize(20)
Column() {
Text(suggestion.content)
.fontSize(14)
.fontWeight(FontWeight.Medium)
.width('100%')
Text(suggestion.explanation)
.fontSize(12)
.fontColor('#666')
.width('100%')
.margin({ top: 4 })
}
.layoutWeight(1)
.margin({ left: 12 })
// 置信度
Text(`${Math.round(suggestion.confidence * 100)}%`)
.fontSize(12)
.fontColor(
suggestion.confidence > 0.8 ? '#00C853' :
suggestion.confidence > 0.6 ? '#FF9100' : '#FF1744'
)
}
.width('100%')
// 预览按钮
if (suggestion.preview) {
Row() {
Button(this.isPlayingPreview && this.selectedSuggestion === index ? '⏹ 停止' : '▶ 试听')
.fontSize(12)
.backgroundColor('#E3F2FD')
.fontColor('#2979FF')
.onClick(() => this.togglePreview(index, suggestion.preview))
Button('✓ 应用')
.fontSize(12)
.backgroundColor('#E8F5E9')
.fontColor('#2E7D32')
.margin({ left: 8 })
.onClick(() => this.applySuggestion(suggestion))
}
.width('100%')
.margin({ top: 8 })
}
}
.padding(12)
.backgroundColor('#fff')
.borderRadius(8)
.margin({ bottom: 8 })
.shadow({ radius: 4, color: 'rgba(0,0,0,0.05)' })
}
})
}
.width('100%')
.layoutWeight(1)
.padding({ left: 16, right: 16 })
// 底部操作
Row() {
Button('🎤 哼唱输入')
.fontSize(14)
.backgroundColor('#F3E5F5')
.fontColor('#7B1FA2')
.layoutWeight(1)
.onClick(() => this.startHummingInput())
Button('✍️ 生成歌词')
.fontSize(14)
.backgroundColor('#E8F5E9')
.fontColor('#2E7D32')
.margin({ left: 8 })
.layoutWeight(1)
.onClick(() => this.generateLyrics())
}
.width('100%')
.padding(16)
}
.width('100%')
.height('100%')
.backgroundColor('#FFF')
.borderRadius(16)
}
private togglePreview(index: number, notes: number[]) {
this.selectedSuggestion = index;
this.isPlayingPreview = !this.isPlayingPreview;
// 实际播放MIDI音符...
}
private applySuggestion(suggestion: MusicSuggestion) {
emitter.emit('applySuggestion', { data: suggestion });
emitter.emit('collapseToCapsule');
}
private startHummingInput() {
emitter.emit('startHumming');
}
private generateLyrics() {
emitter.emit('generateLyrics', {
data: {
theme: this.context?.detectedMood || 'love',
mood: this.context?.detectedMood
}
});
}
}
4.7 主入口与系统集成(Index.ets)
typescript
// Index.ets
import { MusicContextEngine, MusicMood } from './engine/MusicContextEngine';
import { MusicLightingController } from './lighting/MusicLightingController';
import { MusicFloatWindow } from './float/MusicFloatWindow';
import { MusicAgentEngine } from './agent/MusicAgentEngine';
import { emitter } from '@kit.BasicServicesKit';
@Entry
@Component
struct MusicWorkshopApp {
private musicEngine: MusicContextEngine = new MusicContextEngine();
private lightController: MusicLightingController = new MusicLightingController();
private floatWindow: MusicFloatWindow = new MusicFloatWindow();
private agentEngine: MusicAgentEngine = new MusicAgentEngine();
aboutToAppear() {
this.initSystem();
}
aboutToDisappear() {
this.musicEngine.destroy();
this.lightController.reset();
this.floatWindow.destroy();
this.agentEngine.destroy();
}
async initSystem() {
// 1. 初始化沉浸光感
await this.lightController.init();
// 2. 初始化悬浮窗
await this.floatWindow.create();
// 3. 初始化智能体引擎
await this.agentEngine.init();
// 4. 初始化音频上下文感知
await this.musicEngine.init();
// 当音乐上下文变化时,更新光效和悬浮窗
this.musicEngine.onContextChange(async (context) => {
// 更新光效
await this.lightController.updateByMood(context.detectedMood, context.harmonicComplexity / 100);
// 生成建议
const suggestions = await this.agentEngine.suggestHarmony(context);
// 更新悬浮窗
emitter.emit('updateMusicContext', { data: context });
});
// 5. 设置事件监听
this.setupEventListeners();
}
private setupEventListeners() {
emitter.on('expandToPanel', async () => {
const context = this.musicEngine.getLastContext();
if (context) {
const suggestions = await this.agentEngine.suggestHarmony(context);
await this.floatWindow.expandToPanel(context, suggestions);
}
});
emitter.on('expandToFull', async () => {
const context = this.musicEngine.getLastContext();
if (context) {
const suggestions = await this.agentEngine.suggestHarmony(context);
await this.floatWindow.expandToFull(suggestions);
}
});
emitter.on('collapseToCapsule', async () => {
await this.floatWindow.collapseToCapsule();
});
emitter.on('togglePlayback', () => {
// 切换播放状态
});
emitter.on('applySuggestion', async (event) => {
const suggestion = event.data;
// 应用建议到宿主应用
console.info('应用建议:', suggestion);
});
emitter.on('generateLyrics', async (event) => {
const { theme, mood } = event.data || {};
const lyrics = await this.agentEngine.generateLyrics(theme, mood);
// 显示歌词...
});
}
build() {
Column() {
Text('🎵 HarmonyOS音乐创作工坊')
.fontSize(24)
.fontWeight(FontWeight.Bold)
.margin({ bottom: 8 })
Text('AI智能体正在监听你的创作...')
.fontSize(14)
.fontColor('#666')
Text('打开音乐创作应用,AI助手将自动陪伴')
.fontSize(12)
.fontColor('#999')
.margin({ top: 4 })
.textAlign(TextAlign.Center)
// 创作统计
Column() {
Text('📊 今日创作统计')
.fontSize(16)
.fontWeight(FontWeight.Medium)
.margin({ bottom: 12 })
Row() {
Column() {
Text('8')
.fontSize(28)
.fontWeight(FontWeight.Bold)
.fontColor('#2979FF')
Text('和弦建议')
.fontSize(12)
.fontColor('#999')
}
.layoutWeight(1)
Column() {
Text('3')
.fontSize(28)
.fontWeight(FontWeight.Bold)
.fontColor('#00C853')
Text('已应用')
.fontSize(12)
.fontColor('#999')
}
.layoutWeight(1)
Column() {
Text('12min')
.fontSize(28)
.fontWeight(FontWeight.Bold)
.fontColor('#FF9100')
Text('创作时长')
.fontSize(12)
.fontColor('#999')
}
.layoutWeight(1)
}
.width('100%')
}
.width('90%')
.padding(20)
.backgroundColor('#f8f9fa')
.borderRadius(12)
.margin({ top: 32 })
// 当前情绪指示
Row() {
Text('当前情绪:')
.fontSize(14)
.fontColor('#666')
Text('🟢 宁静创作中')
.fontSize(14)
.fontColor('#00C853')
.fontWeight(FontWeight.Medium)
}
.margin({ top: 20 })
}
.width('100%')
.height('100%')
.justifyContent(FlexAlign.Center)
}
}
五、配置文件
json
// module.json5
{
"module": {
"name": "MusicWorkshop",
"type": "entry",
"description": "鸿蒙智能体音乐创作协作工坊",
"mainElement": "EntryAbility",
"deviceTypes": ["phone", "tablet", "2in1"],
"pages": "$profile:main_pages",
"abilities": [
{
"name": "EntryAbility",
"srcEntry": "./ets/entryability/EntryAbility.ets",
"description": "音乐创作工坊主入口",
"icon": "$media:layered_image",
"label": "AI音乐工坊",
"startWindowIcon": "$media:startIcon",
"startWindowBackground": "$color:start_window_background",
"exported": true,
"skills": [
{
"entities": ["entity.system.home"],
"actions": ["action.system.home"]
}
]
}
],
"requestPermissions": [
{
"name": "ohos.permission.SYSTEM_FLOAT_WINDOW",
"reason": "需要悬浮窗权限以提供常驻音乐辅助"
},
{
"name": "ohos.permission.MICROPHONE",
"reason": "需要麦克风权限以分析创作音频"
},
{
"name": "ohos.permission.INTERNET",
"reason": "连接云端智能体服务"
},
{
"name": "ohos.permission.ACCESS_AI_MODEL",
"reason": "使用端侧AI模型进行音乐分析"
}
]
}
}
六、效果展示与使用场景
6.1 典型创作场景
场景A:旋律和声化
小张正在创作一段旋律,输入C-E-G-A后,悬浮胶囊自动识别为C大调、欢快情绪,变为😊图标。点击展开后,AI推荐了I-V-vi-IV流行进行,小张点击试听,满意的和弦声音从设备播放,边框泛起明黄色闪烁光效。点击"应用",和弦自动填入宿主应用。
场景B:情绪配色
小李正在创作一首慢歌,旋律走向下行,智能体检测到忧郁情绪,设备底部边框变为深蓝色慢呼吸光效。小李受到氛围感染,继续保持忧伤的创作方向。当他切换到副歌,旋律上行时,光效自动变为温暖的玫红色。
场景C:协作创作
小王和小赵在协作一首歌,小王的设备边框显示蓝色,小赵的显示绿色。当小王在输入钢琴部分时,小赵的设备左侧闪烁蓝色光效,提示"搭档正在创作"。两人通过光效感知彼此的创作节奏,默契配合。
6.2 光效语义设计
| 音乐情绪 | 光效表现 | 创作提示 |
|---|---|---|
| 欢快 | 全边框明黄快闪 | 保持明亮,可考虑加入打击乐 |
| 忧郁 | 底部深蓝慢呼吸 | 适合弦乐铺底,注意低频 |
| 激昂 | 全边框鲜红极快闪 | 全频段饱满,注意动态范围 |
| 宁静 | 全边框翠绿中速呼吸 | 高频泛音,空间感重要 |
| 紧张 | 全边框琥珀顺时针波浪 | 不和谐音程,制造悬念 |
| 浪漫 | 全边框玫红慢呼吸 | 温暖中频,萨克斯适合 |
七、性能与隐私优化
7.1 音频处理策略
typescript
// 音频分析优化策略
const audioStrategy = {
// 采样率:根据设备性能动态调整
sampleRate: {
high: 44100, // 高性能设备
medium: 22050, // 中端设备
low: 16000 // 低端设备
},
// 分析频率:平衡实时性与功耗
analysisInterval: {
realtime: 1000, // 实时模式(高功耗)
balanced: 2000, // 平衡模式(默认)
powersave: 5000 // 省电模式
},
// 本地缓存:常见和弦进行预计算
cache: {
enabled: true,
maxSize: 50, // 缓存50条最近分析
ttl: 300000 // 5分钟过期
}
};
7.2 隐私保护
- 音频不上云:所有音频分析在端侧完成
- 脱敏处理:旋律特征提取后原始音频立即丢弃
- 用户控制:可随时关闭音频监听,切换为手动输入模式
八、总结与展望
本文展示了如何基于HarmonyOS 6(API 23)的悬浮导航 和沉浸光感 能力,构建一个鸿蒙智能体驱动的沉浸式音乐创作协作工坊。与传统音乐创作工具不同,它具备三个核心创新:
- 上下文感知创作:通过音频分析理解创作者意图,主动而非被动
- 情绪光感:将音乐情绪转化为可视光效,创造"通感"创作体验
- 端云协同智能体:端侧快速分析 + 云端深度生成,兼顾速度与质量
未来演进方向:
- 多设备协同:手机悬浮窗 + 平板编曲界面 + 音箱光效反馈
- AI作曲完整化:从和声建议到完整编曲的一站式生成
- 社区化创作:创作者可以分享"光效签名",形成独特的视觉标识
- 跨平台协作:支持与Logic Pro、FL Studio等主流DAW的插件集成
HarmonyOS 6的智能体框架和系统级交互创新,正在让"AI音乐伙伴常驻身边"成为现实。对于音乐创作者而言,这不仅是一个工具,更是一位懂音乐、懂情绪、懂协作的创作伙伴。
转载自:<>
欢迎 👍点赞✍评论⭐收藏,欢迎指正
