部署Kubernetes

王da魔2026-08-23 14:47

一 构建部署Kubernetes所需要的主机

主机名 IP 配置 角色
www.onepiece.com 192.168.136.100 cpu1、mem 1G harbor本地仓库
K8s 192.168.136.10 cpu4、mem>4G master，k8s集群控制节点
K8s1 192.168.136.20 cpu2、mem 2G worker，k8s集群工作节点
K8s2 192.168.136.30 cpu2、mem 2G worker，k8s集群工作节点

!IMPORTANT

以下所有的操作在所有主机中都需要配置

关闭swap

bash 复制代码
# 禁用并立即停止 swap.target
[root@K8s ~]# systemctl disable --now swap.target

# 屏蔽 swap.target
[root@K8s ~]# systemctl mask swap.target

# 注释 /etc/fstab 中的 swap 配置
sed '/swap/s/^/#/g' -i /etc/fstab

安装docker

bash 复制代码
[root@K8s ~]# cd /etc/yum.repos.d/
[root@K8s yum.repos.d]# vim dokcer.repo
[docker]
name = docker
baseurl = https://mirrors.aliyun.com/docker-ce/linux/rhel/9.8/x86_64/stable/
gpgcheck = 0
[root@K8s yum.repos.d]# dnf install docker-ce -y
[root@K8s yum.repos.d]# vim /lib/systemd/system/docker.service
ExecStart=/usr/bin/dockerd -H fd:// --containerd=/run/containerd/containerd.sock --iptables=true
[root@K8s yum.repos.d]# echo br_netfilter > /etc/modules-load.d/docker_mod.conf
[root@K8s yum.repos.d]# modprobe -a br_netfilter
[root@K8s yum.repos.d]# cat  > /etc/sysctl.d/docker.conf <<EOF
net.bridge.bridge-nf-call-iptables = 1
net.bridge.bridge-nf-call-ip6tables = 1
net.ipv4.ip_forward = 1
EOF
[root@K8s yum.repos.d]# sysctl --system
[root@K8s yum.repos.d]# systemctl enable --now docker

配置证书可以使用harbor仓库

bash 复制代码
[root@K8s yum.repos.d]# mkdir  /etc/docker/certs.d/www.onepiece.com/ -p
[root@Harbor ~]# for i in 10 20 30; do scp /data/certs/onepiece.com.crt root@192.168.136.$i:/etc/docker/certs.d/www.onepiece.com/ca.crt; done
[root@K8s yum.repos.d]# systemctl restart docker

配置docker加速器

bash 复制代码
# 让Docker拉取镜像时使用指定的镜像仓库镜像源
[root@K8s ~]# cat >/etc/docker/daemon.json <<EOF
{
  "registry-mirrors":["https://www.onepiece.com"]
}
EOF
[root@K8s ~]# systemctl restart docker
[root@K8s ~]# docker info
Registry Mirrors:
  https://www.onepiece.com/

彼此建立解析

bash 复制代码
[root@K8s ~]# vim /etc/hosts
127.0.0.1   localhost localhost.localdomain localhost4 localhost4.localdomain4
::1         localhost localhost.localdomain localhost6 localhost6.localdomain6
192.168.136.10     K8s
192.168.136.20     K8s1
192.168.136.30     K8s2
192.168.136.100     www.onepiece.com

配置kubernetes安装源

bash 复制代码
[root@K8s ~]# dnf list kubelet
正在更新 Subscription Management 软件仓库。
无法读取客户身份

本系统尚未在权利服务器中注册。可使用 "rhc" 或 "subscription-manager" 进行注册。

上次元数据过期检查：0:11:27 前，执行于 2026年08月22日 星期六 11时26分34秒。
可安装的软件包
kubelet.aarch64                          1.35.8-150500.1.1                           kubernetes
kubelet.ppc64le                          1.35.8-150500.1.1                           kubernetes
kubelet.s390x                            1.35.8-150500.1.1                           kubernetes
kubelet.src                              1.35.8-150500.1.1                           kubernetes
kubelet.x86_64                           1.35.8-150500.1.1                           kubernetes
[root@K8s ~]#
[root@K8s ~]# vim /etc/yum.repos.d/kubernetes.repo
[kubernetes]
name = kubernetes
baseurl = https://mirrors.aliyun.com/kubernetes-new/core/stable/v1.35/rpm/
gpgcheck = 0
[root@K8s ~]# dnf list kubelet
正在更新 Subscription Management 软件仓库。
无法读取客户身份

本系统尚未在权利服务器中注册。可使用 "rhc" 或 "subscription-manager" 进行注册。

上次元数据过期检查：0:11:27 前，执行于 2026年08月22日 星期六 11时26分34秒。
可安装的软件包
kubelet.aarch64                          1.35.8-150500.1.1                           kubernetes
kubelet.ppc64le                          1.35.8-150500.1.1                           kubernetes
kubelet.s390x                            1.35.8-150500.1.1                           kubernetes
kubelet.src                              1.35.8-150500.1.1                           kubernetes
kubelet.x86_64                           1.35.8-150500.1.1                           kubernetes

以上操作完成后重启主机检测swap分区

bash 复制代码
# 没有任何输出表示ok
swapon  -s

二 kubernetes的部署

1 安装cri-dockerd

bash 复制代码
# 所有主机中安装
# 可以用rpm包部署cri-dockerd，但是rpm包版本相对较老 推荐二进制方式部署
# 下载二进制包
[root@K8s ~]# wget https://github.com/Mirantis/cri-dockerd/releases/download/v0.4.4/cri-dockerd-0.4.4.amd64.tgz

# 解压二进制压缩包
[root@K8s ~]# tar zxf cri-dockerd-0.4.4.amd64.tgz

[root@K8s ~]# cd cri-dockerd/
[root@K8s cri-dockerd]# ls
cri-dockerd  cri-docker.service  cri-docker.socket

# 安装cri-docker命令到系统
[root@K8s cri-dockerd]# install -o root -g root -m 0755 cri-dockerd  /usr/local/bin/cri-dockerd
[root@K8s cri-dockerd]# ls -l /usr/local/bin/cri-dockerd
-rwxr-xr-x 1 root root 51638434  8月 22 11:45 /usr/local/bin/cri-dockerd

# 生成启动文件
[root@K8s cri-dockerd]# cp cri-docker.s* /lib/systemd/system
[root@K8s cri-dockerd]#  chmod  +x /lib/systemd/system/cri-docker.s*
[root@K8s cri-dockerd]# vim /lib/systemd/system/cri-docker.service
ExecStart=/usr/local/bin/cri-dockerd --container-runtime-endpoint fd://
[root@K8s cri-dockerd]# systemctl daemon-reload

# 启动服务
[root@K8s cri-dockerd]# systemctl enable --now cri-docker
The unit files have no installation config (WantedBy=, RequiredBy=, Also=,
Alias= settings in the [Install] section, and DefaultInstance= for template
units). This means they are not meant to be enabled or disabled using systemctl.

Possible reasons for having this kind of units are:
• A unit may be statically enabled by being symlinked from another unit's
  .wants/ or .requires/ directory.
• A unit's purpose may be to act as a helper for some other unit which has
  a requirement dependency on it.
• A unit may be started when needed via activation (socket, path, timer,
  D-Bus, udev, scripted systemctl call, ...).
• In case of template units, the unit is meant to be enabled with some
  instance name specified.
[root@K8s ~]# systemctl status cri-docker.service
● cri-docker.service - CRI Interface for Docker Application Container Engine
     Loaded: loaded (/usr/lib/systemd/system/cri-docker.service; static)
     Active: active (running) since Sat 2026-08-22 12:34:29 CST; 2min 33s ago
TriggeredBy: ● cri-docker.socket
       Docs: https://docs.mirantis.com
   Main PID: 12842 (cri-dockerd)
      Tasks: 11 (limit: 22916)
     Memory: 63.9M
        CPU: 53ms
     CGroup: /system.slice/cri-docker.service
             └─12842 /usr/local/bin/cri-dockerd --container-runtime-endpoint fd://

2 安装构建kubernetes 集群所需软件

Master(K8s主机)节点

bash 复制代码
[root@K8s ~]# dnf install kubelet kubeadm kubectl -y
[root@K8s ~]# systemctl enable --now kubelet.service
Created symlink /etc/systemd/system/multi-user.target.wants/kubelet.service → /usr/lib/systemd/system/kubelet.service.

node(K8s1&2)节点

bash 复制代码
[root@K8s1 cri-dockerd]# dnf install kubelet kubeadm  -y
[root@K8s2 ~]# systemctl enable --now kubelet.service
Created symlink /etc/systemd/system/multi-user.target.wants/kubelet.service → /usr/lib/systemd/system/kubelet.service.

master(K8s)节点中 kubectl 和kubeadm 补齐

bash 复制代码
[root@K8s ~]# echo "source <(kubectl completion bash)" >> ~/.bashrc
[root@K8s ~]# echo "source <(kubeadm completion bash)" >> ~/.bashrc
[root@K8s ~]# source  ~/.bashrc

3 下载kubernetes集群所需镜像

查看镜像

bash 复制代码
[root@K8s ~]# kubeadm config images list
I0822 12:44:47.114606   13403 version.go:260] remote version is much newer: v1.36.4; falling back to: stable-1.35
registry.k8s.io/kube-apiserver:v1.35.8
registry.k8s.io/kube-controller-manager:v1.35.8
registry.k8s.io/kube-scheduler:v1.35.8
registry.k8s.io/kube-proxy:v1.35.8
registry.k8s.io/coredns/coredns:v1.13.1
registry.k8s.io/pause:3.10.1
registry.k8s.io/etcd:3.6.6-0

下载镜像

bash 复制代码
[root@K8s ~]# kubeadm config images pull \
--image-repository registry.aliyuncs.com/google_containers \
--kubernetes-version v1.35.7 \
--cri-socket=unix:///var/run/cri-dockerd.sock
[config/images] Pulled registry.aliyuncs.com/google_containers/kube-apiserver:v1.35.7
[config/images] Pulled registry.aliyuncs.com/google_containers/kube-controller-manager:v1.35.7
[config/images] Pulled registry.aliyuncs.com/google_containers/kube-scheduler:v1.35.7
[config/images] Pulled registry.aliyuncs.com/google_containers/kube-proxy:v1.35.7
[config/images] Pulled registry.aliyuncs.com/google_containers/coredns:v1.13.1
[config/images] Pulled registry.aliyuncs.com/google_containers/pause:3.10.1
[config/images] Pulled registry.aliyuncs.com/google_containers/etcd:3.6.6-0

上传镜像到本地harbor仓库

bash 复制代码
[root@K8s ~]# docker login www.onepiece.com -uadmin
Password:
Login Succeeded
[root@K8s ~]# docker images --format "{{.Repository}}:{{.Tag}}" | awk -F "/" '/google/{system("docker tag "$0" www.onepiece.com/k8s/"$3)}'
[root@K8s ~]# docker images --format "{{.Repository}}:{{.Tag}}" | awk -F "/" '/onepiece/{system("docker push "$0)}'

4 在master中初始化kubernetes集群

在master中完成集群初始化

bash 复制代码
[root@K8s ~]# kubeadm init --pod-network-cidr=10.244.0.0/16 --image-repository www.onepiece.com/k8s --kubernetes-version v1.35.7 --cri-socket=unix:///var/run/cri-dockerd.sock

# 每个人不一样，其他主机加入本集群的凭证
kubeadm join 192.168.136.10:6443 --token zfcu29.dnb6aj9b8iboqncz \
        --discovery-token-ca-cert-hash sha256:cbeda5aa208463a315bb564bf264cbaff2d466ae615cf84696a31e654af6af22

# 如果忘记
[root@K8s ~]# kubeadm token create --print-join-command
kubeadm join 192.168.136.10:6443 --token 4zm4uy.pg76rmyg9dm87f5j --discovery-token-ca-cert-hash sha256:cbeda5aa208463a315bb564bf264cbaff2d466ae615cf84696a31e654af6af22

# 如果初始化出问题
# 直接重置
[root@K8s ~]# kubeadm reset  --cri-socket=unix:///var/run/cri-dockerd.sock

添加kubernets环境变量到本机

bash 复制代码
[root@K8s ~]# echo "export KUBECONFIG=/etc/kubernetes/admin.conf" > ~/.bash_profile
[root@K8s ~]# source  ~/.bash_profile
[root@K8s ~]# kubectl get nodes
NAME   STATUS     ROLES           AGE     VERSION
k8s    NotReady   control-plane   2m57s   v1.35.8

添加node节点到本集群

bash 复制代码
[root@K8s1 ~]# kubeadm join 192.168.136.10:6443 --token lw0ynt.ej1kryw9519vf31u --discovery-token-ca-cert-hash sha256:cbeda5aa208463a315bb564bf264cbaff2d466ae615cf84696a31e654af6af22  --cri-socket=unix:///var/run/cri-dockerd.sock
[root@K8s ~]# kubectl get nodes
NAME   STATUS     ROLES           AGE    VERSION
k8s    NotReady   control-plane   7m6s   v1.35.8
k8s1   NotReady   <none>          65s    v1.35.8
k8s2   NotReady   <none>          3s     v1.35.8

5 安装网络插件

bash 复制代码
[root@K8s ~]# tar zxf kube-flannel-v0.28.9.tar.gz
[root@K8s ~]# cd flannel/
[root@K8s flannel]# docker load  -i kube-flannel-v0.28.9.tar
Loaded image: ghcr.io/flannel-io/flannel-cni-plugin:v1.9.1-flannel3
Loaded image: ghcr.io/flannel-io/flannel:v0.28.9
[root@K8s flannel]# docker tag ghcr.io/flannel-io/flannel-cni-plugin:v1.9.1-flannel3 www.onepiece.com/flannel-io/flannel-cni-plugin:v1.9.1-flannel3
[root@K8s flannel]# docker push www.onepiece.com/flannel-io/flannel-cni-plugin:v1.9.1-flannel3
[root@K8s flannel]# docker tag ghcr.io/flannel-io/flannel:v0.28.9 www.onepiece.com/flannel-io/flannel:v0.28.9
[root@K8s flannel]# docker push www.onepiece.com/flannel-io/flannel:v0.28.9
The push refers to repository [www.onepiece.com/flannel-io/flannel]
f923fe4d6cdf: Pushed
55afa1ecc21d: Mounted from flannel-io/flannel-cni-plugin
552426a46922: Pushed
464e53b89363: Pushed
779e1d234370: Pushed
74f5049831bd: Pushed
7e7d4790580f: Pushed
dde022ac8ed4: Pushed
fef9ba352c99: Pushed
4f4fb700ef54: Pushed
v0.28.9: digest: sha256:d666a036197fe6c8928f82b670d89f38f5830d25e70bfcc35641da06f03cfcad size: 2197

i Info → Not all multiplatform-content is present and only the available single-platform image was pushed
          sha256:708a2c9c1cfbfe529d1dbb249cb7113af117f3ed26b5e3e4c8ee015e10555204 -> sha256:d666a036197fe6c8928f82b670d89f38f5830d25e70bfcc35641da06f03cfcad
[root@K8s flannel]#  vim kube-flannel.yml
		image: flann[root@K8s flannel]# kubectl apply -f kube-flannel.yml
namespace/kube-flannel created
serviceaccount/flannel created
clusterrole.rbac.authorization.k8s.io/flannel created
clusterrolebinding.rbac.authorization.k8s.io/flannel created
configmap/kube-flannel-cfg created
daemonset.apps/kube-flannel-ds created
el-io/flannel:v0.28.1
        image: flannel-io/flannel-cni-plugin:v1.9.0-flannel1
        image: flannel-io/flannel:v0.28.1
[root@K8s flannel]# kubectl apply -f kube-flannel.yml
namespace/kube-flannel created
serviceaccount/flannel created
clusterrole.rbac.authorization.k8s.io/flannel created
clusterrolebinding.rbac.authorization.k8s.io/flannel created
configmap/kube-flannel-cfg created
daemonset.apps/kube-flannel-ds created

# 测试
[root@K8s flannel]# kubectl get nodes
NAME   STATUS   ROLES           AGE   VERSION
k8s    Ready    control-plane   50m   v1.35.8
k8s1   Ready    <none>          44m   v1.35.8
k8s2   Ready    <none>          43m   v1.35.8
相关推荐
RobinDevNotes1 小时前
K8s+Megatron-LM+vLLM打通超大模型训练全链路
人工智能·kubernetes
池以遇2 小时前
云原生高级——kubernetes的部署
云原生·容器·kubernetes
UseLessQQ2 小时前
云计算k8s集群部署
java·kubernetes·云计算
智码看视界3 小时前
Day57-K8s核心概念速通：Pod、Deployment、Service与Ingress
云原生·容器·kubernetes·k8s·ingress·java后端·deployment
lxw20230271164 小时前
k8s安装部署（利用ansible）
linux·kubernetes·ansible
Stewie121384 小时前
K8s集群部署
云原生·容器·kubernetes
.柒宇.4 小时前
使用 cri-docker 搭建 Kubernetes 集群完整教程（v1.36.3）
docker·容器·kubernetes·k8s集群安装
starzy19905 小时前
K8s 集群容器管理工具选型与实战指南
云原生·容器
养海绵宝宝的小蜗5 小时前
K8S总结
云原生·容器·kubernetes
热门推荐
01国内可直接用、免费额度/永久免费的大模型API清单（含 SiliconFlow、火山、阿里、智谱、百度、Kimi、DeepSeek、DMXAPI 等）02GitHub 镜像站点03微信历史版本含下载地址（ Windows PC | 安卓 | MAC ）及设置微信不更新042026 国产 AI 大模型横评：DeepSeek、通义千问、Kimi、文心一言、星火、豆包谁更能打？05历年考研数学一、数学二、数学三真题试卷及答案PDF06Agnes AI 免费 API 接入指南：文本、生图、生视频，一套接口全免费07AI 编程 IDE 全景解析 2026：Agent 全面接管开发链路082026年7月AI圈大地震：GPT-5.6被政府限制、Claude入驻Slack、Anthropic自研芯片09VSCode+CodeX扩展，无法启动10如何新建文件夹？ 电脑新建文件夹的4种方法
