前言概念

图像分割

分割任务就是在原始图像中逐像素的找到你需要的家伙!

语义分割

就是把每个像素都打上标签（这个像素点是人，树，背景等）

（语义分割只区分类别，不区分类别中具体单位）

实例分割

实例分割不光要区别类别，还要区分类别中每一个个体

损失函数：

逐像素的交叉熵：还经常需要考虑样本均衡问题，交叉熵损失函数公式如下：

Focal loss：样本也由难易之分，就跟玩游戏一样，难度越高的BOSS奖励越高

Gamma通常设置为2，例如预测正样本概率0.95，如果预测正样本概率0.4， （相当于样本的难易权值）

（再结合样本数量的权值就是Focal Loss）

IOU计算

多分类任务时：iou_dog = 801 / true_dog + predict_dog - 801

MIOU指标：

MIOU就是计算所有类别的平均值，一般当作分割任务评估指标

Unet

整体结构：概述就是编码解码过程；简单但是很实用，应用广；起初是做医学方向，现在也是

Unet++

整体网络结构：特征融合，拼接更全面；其实跟densenet思想一致；把能拼能凑的特征全用上

Deep Supervision ：多输出损失；由多个位置计算，再更新

容易剪枝：可以根据速度要求来快速完成剪枝；训练的时候同样会用到L4，效果还不错

U²net

代码 论文

听名字知道就是把Unet中每个stage再变成一个Unet，这样就嵌套了一个Unet变成U²net；

输出为解码器各个阶段输出再拼接，经过一次卷积输出

现有卷积块和我们提出的残差U形块RSU的说明：（a）普通卷积块PLN，（b）残差类块RES，（c）密集类块DSE，（d）启始类块INC和（e）我们的残差U型块RSU

残差块与我们的RSU的比较

就作者展示的效果而言，出奇的不错，有兴趣去代码界面看看，使用也很简单，下面展示一些

代码结构放最后；有兴趣看看

python 复制代码
#U²net结构；387行forward开始
import torch
import torch.nn as nn
from torchvision import models
import torch.nn.functional as F

class REBNCONV(nn.Module):
    def __init__(self,in_ch=3,out_ch=3,dirate=1):
        super(REBNCONV,self).__init__()

        self.conv_s1 = nn.Conv2d(in_ch,out_ch,3,padding=1*dirate,dilation=1*dirate)
        self.bn_s1 = nn.BatchNorm2d(out_ch)
        self.relu_s1 = nn.ReLU(inplace=True)

    def forward(self,x):

        hx = x
        xout = self.relu_s1(self.bn_s1(self.conv_s1(hx)))

        return xout

## upsample tensor 'src' to have the same spatial size with tensor 'tar'
def _upsample_like(src,tar):

    src = F.upsample(src,size=tar.shape[2:],mode='bilinear')

    return src


### RSU-7 ###
class RSU7(nn.Module):#UNet07DRES(nn.Module):

    def __init__(self, in_ch=3, mid_ch=12, out_ch=3):
        super(RSU7,self).__init__()

        self.rebnconvin = REBNCONV(in_ch,out_ch,dirate=1)

        self.rebnconv1 = REBNCONV(out_ch,mid_ch,dirate=1)
        self.pool1 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.rebnconv2 = REBNCONV(mid_ch,mid_ch,dirate=1)
        self.pool2 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.rebnconv3 = REBNCONV(mid_ch,mid_ch,dirate=1)
        self.pool3 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.rebnconv4 = REBNCONV(mid_ch,mid_ch,dirate=1)
        self.pool4 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.rebnconv5 = REBNCONV(mid_ch,mid_ch,dirate=1)
        self.pool5 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.rebnconv6 = REBNCONV(mid_ch,mid_ch,dirate=1)

        self.rebnconv7 = REBNCONV(mid_ch,mid_ch,dirate=2)

        self.rebnconv6d = REBNCONV(mid_ch*2,mid_ch,dirate=1)
        self.rebnconv5d = REBNCONV(mid_ch*2,mid_ch,dirate=1)
        self.rebnconv4d = REBNCONV(mid_ch*2,mid_ch,dirate=1)
        self.rebnconv3d = REBNCONV(mid_ch*2,mid_ch,dirate=1)
        self.rebnconv2d = REBNCONV(mid_ch*2,mid_ch,dirate=1)
        self.rebnconv1d = REBNCONV(mid_ch*2,out_ch,dirate=1)

    def forward(self,x):
        print(x.shape)
        hx = x
        hxin = self.rebnconvin(hx)
        print(hxin.shape)
        hx1 = self.rebnconv1(hxin)
        print(hx1.shape)
        hx = self.pool1(hx1)
        print(hx.shape)

        hx2 = self.rebnconv2(hx)
        print(hx2.shape)
        hx = self.pool2(hx2)
        print(hx.shape)

        hx3 = self.rebnconv3(hx)
        print(hx3.shape)
        hx = self.pool3(hx3)
        print(hx.shape)

        hx4 = self.rebnconv4(hx)
        print(hx4.shape)
        hx = self.pool4(hx4)
        print(hx.shape)

        hx5 = self.rebnconv5(hx)
        print(hx5.shape)
        hx = self.pool5(hx5)
        print(hx.shape)

        hx6 = self.rebnconv6(hx)
        print(hx6.shape)

        hx7 = self.rebnconv7(hx6)
        print(hx7.shape)

        hx6d =  self.rebnconv6d(torch.cat((hx7,hx6),1))
        print(hx6d.shape)
        hx6dup = _upsample_like(hx6d,hx5)
        print(hx6dup.shape)

        hx5d =  self.rebnconv5d(torch.cat((hx6dup,hx5),1))
        print(hx5d.shape)
        hx5dup = _upsample_like(hx5d,hx4)
        print(hx5dup.shape)

        hx4d = self.rebnconv4d(torch.cat((hx5dup,hx4),1))
        print(hx4d.shape)
        hx4dup = _upsample_like(hx4d,hx3)
        print(hx4dup.shape)

        hx3d = self.rebnconv3d(torch.cat((hx4dup,hx3),1))
        print(hx3d.shape)
        hx3dup = _upsample_like(hx3d,hx2)
        print(hx3dup.shape)

        hx2d = self.rebnconv2d(torch.cat((hx3dup,hx2),1))
        print(hx2d.shape)
        hx2dup = _upsample_like(hx2d,hx1)
        print(hx2dup.shape)

        hx1d = self.rebnconv1d(torch.cat((hx2dup,hx1),1))
        print(hx1d.shape)

        return hx1d + hxin

### RSU-6 ###
class RSU6(nn.Module):#UNet06DRES(nn.Module):

    def __init__(self, in_ch=3, mid_ch=12, out_ch=3):
        super(RSU6,self).__init__()

        self.rebnconvin = REBNCONV(in_ch,out_ch,dirate=1)

        self.rebnconv1 = REBNCONV(out_ch,mid_ch,dirate=1)
        self.pool1 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.rebnconv2 = REBNCONV(mid_ch,mid_ch,dirate=1)
        self.pool2 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.rebnconv3 = REBNCONV(mid_ch,mid_ch,dirate=1)
        self.pool3 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.rebnconv4 = REBNCONV(mid_ch,mid_ch,dirate=1)
        self.pool4 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.rebnconv5 = REBNCONV(mid_ch,mid_ch,dirate=1)

        self.rebnconv6 = REBNCONV(mid_ch,mid_ch,dirate=2)

        self.rebnconv5d = REBNCONV(mid_ch*2,mid_ch,dirate=1)
        self.rebnconv4d = REBNCONV(mid_ch*2,mid_ch,dirate=1)
        self.rebnconv3d = REBNCONV(mid_ch*2,mid_ch,dirate=1)
        self.rebnconv2d = REBNCONV(mid_ch*2,mid_ch,dirate=1)
        self.rebnconv1d = REBNCONV(mid_ch*2,out_ch,dirate=1)

    def forward(self,x):

        hx = x

        hxin = self.rebnconvin(hx)

        hx1 = self.rebnconv1(hxin)
        hx = self.pool1(hx1)

        hx2 = self.rebnconv2(hx)
        hx = self.pool2(hx2)

        hx3 = self.rebnconv3(hx)
        hx = self.pool3(hx3)

        hx4 = self.rebnconv4(hx)
        hx = self.pool4(hx4)

        hx5 = self.rebnconv5(hx)

        hx6 = self.rebnconv6(hx5)


        hx5d =  self.rebnconv5d(torch.cat((hx6,hx5),1))
        hx5dup = _upsample_like(hx5d,hx4)

        hx4d = self.rebnconv4d(torch.cat((hx5dup,hx4),1))
        hx4dup = _upsample_like(hx4d,hx3)

        hx3d = self.rebnconv3d(torch.cat((hx4dup,hx3),1))
        hx3dup = _upsample_like(hx3d,hx2)

        hx2d = self.rebnconv2d(torch.cat((hx3dup,hx2),1))
        hx2dup = _upsample_like(hx2d,hx1)

        hx1d = self.rebnconv1d(torch.cat((hx2dup,hx1),1))

        return hx1d + hxin

### RSU-5 ###
class RSU5(nn.Module):#UNet05DRES(nn.Module):

    def __init__(self, in_ch=3, mid_ch=12, out_ch=3):
        super(RSU5,self).__init__()

        self.rebnconvin = REBNCONV(in_ch,out_ch,dirate=1)

        self.rebnconv1 = REBNCONV(out_ch,mid_ch,dirate=1)
        self.pool1 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.rebnconv2 = REBNCONV(mid_ch,mid_ch,dirate=1)
        self.pool2 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.rebnconv3 = REBNCONV(mid_ch,mid_ch,dirate=1)
        self.pool3 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.rebnconv4 = REBNCONV(mid_ch,mid_ch,dirate=1)

        self.rebnconv5 = REBNCONV(mid_ch,mid_ch,dirate=2)

        self.rebnconv4d = REBNCONV(mid_ch*2,mid_ch,dirate=1)
        self.rebnconv3d = REBNCONV(mid_ch*2,mid_ch,dirate=1)
        self.rebnconv2d = REBNCONV(mid_ch*2,mid_ch,dirate=1)
        self.rebnconv1d = REBNCONV(mid_ch*2,out_ch,dirate=1)

    def forward(self,x):

        hx = x

        hxin = self.rebnconvin(hx)

        hx1 = self.rebnconv1(hxin)
        hx = self.pool1(hx1)

        hx2 = self.rebnconv2(hx)
        hx = self.pool2(hx2)

        hx3 = self.rebnconv3(hx)
        hx = self.pool3(hx3)

        hx4 = self.rebnconv4(hx)

        hx5 = self.rebnconv5(hx4)

        hx4d = self.rebnconv4d(torch.cat((hx5,hx4),1))
        hx4dup = _upsample_like(hx4d,hx3)

        hx3d = self.rebnconv3d(torch.cat((hx4dup,hx3),1))
        hx3dup = _upsample_like(hx3d,hx2)

        hx2d = self.rebnconv2d(torch.cat((hx3dup,hx2),1))
        hx2dup = _upsample_like(hx2d,hx1)

        hx1d = self.rebnconv1d(torch.cat((hx2dup,hx1),1))

        return hx1d + hxin

### RSU-4 ###
class RSU4(nn.Module):#UNet04DRES(nn.Module):

    def __init__(self, in_ch=3, mid_ch=12, out_ch=3):
        super(RSU4,self).__init__()

        self.rebnconvin = REBNCONV(in_ch,out_ch,dirate=1)

        self.rebnconv1 = REBNCONV(out_ch,mid_ch,dirate=1)
        self.pool1 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.rebnconv2 = REBNCONV(mid_ch,mid_ch,dirate=1)
        self.pool2 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.rebnconv3 = REBNCONV(mid_ch,mid_ch,dirate=1)

        self.rebnconv4 = REBNCONV(mid_ch,mid_ch,dirate=2)

        self.rebnconv3d = REBNCONV(mid_ch*2,mid_ch,dirate=1)
        self.rebnconv2d = REBNCONV(mid_ch*2,mid_ch,dirate=1)
        self.rebnconv1d = REBNCONV(mid_ch*2,out_ch,dirate=1)

    def forward(self,x):

        hx = x

        hxin = self.rebnconvin(hx)

        hx1 = self.rebnconv1(hxin)
        hx = self.pool1(hx1)

        hx2 = self.rebnconv2(hx)
        hx = self.pool2(hx2)

        hx3 = self.rebnconv3(hx)

        hx4 = self.rebnconv4(hx3)

        hx3d = self.rebnconv3d(torch.cat((hx4,hx3),1))
        hx3dup = _upsample_like(hx3d,hx2)

        hx2d = self.rebnconv2d(torch.cat((hx3dup,hx2),1))
        hx2dup = _upsample_like(hx2d,hx1)

        hx1d = self.rebnconv1d(torch.cat((hx2dup,hx1),1))

        return hx1d + hxin

### RSU-4F ###
class RSU4F(nn.Module):#UNet04FRES(nn.Module):

    def __init__(self, in_ch=3, mid_ch=12, out_ch=3):
        super(RSU4F,self).__init__()

        self.rebnconvin = REBNCONV(in_ch,out_ch,dirate=1)

        self.rebnconv1 = REBNCONV(out_ch,mid_ch,dirate=1)
        self.rebnconv2 = REBNCONV(mid_ch,mid_ch,dirate=2)
        self.rebnconv3 = REBNCONV(mid_ch,mid_ch,dirate=4)

        self.rebnconv4 = REBNCONV(mid_ch,mid_ch,dirate=8)

        self.rebnconv3d = REBNCONV(mid_ch*2,mid_ch,dirate=4)
        self.rebnconv2d = REBNCONV(mid_ch*2,mid_ch,dirate=2)
        self.rebnconv1d = REBNCONV(mid_ch*2,out_ch,dirate=1)

    def forward(self,x):

        hx = x

        hxin = self.rebnconvin(hx)
        print(hxin.shape)
        hx1 = self.rebnconv1(hxin)
        print(hx1.shape)
        hx2 = self.rebnconv2(hx1)
        print(hx2.shape)
        hx3 = self.rebnconv3(hx2)
        print(hx3.shape)

        hx4 = self.rebnconv4(hx3)
        print(hx4.shape)
        hx3d = self.rebnconv3d(torch.cat((hx4,hx3),1))
        print(hx3d.shape)
        hx2d = self.rebnconv2d(torch.cat((hx3d,hx2),1))
        print(hx2d.shape)
        hx1d = self.rebnconv1d(torch.cat((hx2d,hx1),1))
        print(hx1d.shape)

        return hx1d + hxin


##### U^2-Net ####
class U2NET(nn.Module):

    def __init__(self,in_ch=3,out_ch=1):
        super(U2NET,self).__init__()

        self.stage1 = RSU7(in_ch,32,64)
        self.pool12 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.stage2 = RSU6(64,32,128)
        self.pool23 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.stage3 = RSU5(128,64,256)
        self.pool34 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.stage4 = RSU4(256,128,512)
        self.pool45 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.stage5 = RSU4F(512,256,512)
        self.pool56 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.stage6 = RSU4F(512,256,512)

        # decoder
        self.stage5d = RSU4F(1024,256,512)
        self.stage4d = RSU4(1024,128,256)
        self.stage3d = RSU5(512,64,128)
        self.stage2d = RSU6(256,32,64)
        self.stage1d = RSU7(128,16,64)

        self.side1 = nn.Conv2d(64,out_ch,3,padding=1)
        self.side2 = nn.Conv2d(64,out_ch,3,padding=1)
        self.side3 = nn.Conv2d(128,out_ch,3,padding=1)
        self.side4 = nn.Conv2d(256,out_ch,3,padding=1)
        self.side5 = nn.Conv2d(512,out_ch,3,padding=1)
        self.side6 = nn.Conv2d(512,out_ch,3,padding=1)

        self.outconv = nn.Conv2d(6,out_ch,1)

    def forward(self,x):
        print(x.shape)
        hx = x

        #stage 1
        hx1 = self.stage1(hx)
        print(hx1.shape)
        hx = self.pool12(hx1)
        print(hx.shape)
        #stage 2
        hx2 = self.stage2(hx)
        print(hx2.shape)
        hx = self.pool23(hx2)
        print(hx.shape)

        #stage 3
        hx3 = self.stage3(hx)
        print(hx3.shape)
        hx = self.pool34(hx3)
        print(hx.shape)

        #stage 4
        hx4 = self.stage4(hx)
        print(hx4.shape)
        hx = self.pool45(hx4)
        print(hx.shape)

        #stage 5
        hx5 = self.stage5(hx)
        print(hx5.shape)
        hx = self.pool56(hx5)
        print(hx.shape)

        #stage 6
        hx6 = self.stage6(hx)
        print(hx6.shape)
        hx6up = _upsample_like(hx6,hx5)
        print(hx6up.shape)

        #-------------------- decoder --------------------
        hx5d = self.stage5d(torch.cat((hx6up,hx5),1))
        print(hx5d.shape)
        hx5dup = _upsample_like(hx5d,hx4)
        print(hx5dup.shape)
        hx4d = self.stage4d(torch.cat((hx5dup,hx4),1))
        print(hx4d.shape)
        hx4dup = _upsample_like(hx4d,hx3)
        print(hx4dup.shape)

        hx3d = self.stage3d(torch.cat((hx4dup,hx3),1))
        print(hx3d.shape)
        hx3dup = _upsample_like(hx3d,hx2)
        print(hx3dup.shape)

        hx2d = self.stage2d(torch.cat((hx3dup,hx2),1))
        print(hx2d.shape)
        hx2dup = _upsample_like(hx2d,hx1)
        print(hx2dup.shape)

        hx1d = self.stage1d(torch.cat((hx2dup,hx1),1))
        print(hx1d.shape)


        #side output
        d1 = self.side1(hx1d)
        print(d1.shape)

        d2 = self.side2(hx2d)
        print(d2.shape)
        d2 = _upsample_like(d2,d1)
        print(d2.shape)

        d3 = self.side3(hx3d)
        print(d3.shape)
        d3 = _upsample_like(d3,d1)
        print(d3.shape)

        d4 = self.side4(hx4d)
        print(d4.shape)
        d4 = _upsample_like(d4,d1)
        print(d4.shape)

        d5 = self.side5(hx5d)
        print(d5.shape)
        d5 = _upsample_like(d5,d1)
        print(d5.shape)

        d6 = self.side6(hx6)
        print(d6.shape)
        d6 = _upsample_like(d6,d1)
        print(d6.shape)

        d0 = self.outconv(torch.cat((d1,d2,d3,d4,d5,d6),1))
        print(d0.shape)

        return F.sigmoid(d0), F.sigmoid(d1), F.sigmoid(d2), F.sigmoid(d3), F.sigmoid(d4), F.sigmoid(d5), F.sigmoid(d6)

### U^2-Net small ###
class U2NETP(nn.Module):

    def __init__(self,in_ch=3,out_ch=1):
        super(U2NETP,self).__init__()

        self.stage1 = RSU7(in_ch,16,64)
        self.pool12 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.stage2 = RSU6(64,16,64)
        self.pool23 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.stage3 = RSU5(64,16,64)
        self.pool34 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.stage4 = RSU4(64,16,64)
        self.pool45 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.stage5 = RSU4F(64,16,64)
        self.pool56 = nn.MaxPool2d(2,stride=2,ceil_mode=True)

        self.stage6 = RSU4F(64,16,64)

        # decoder
        self.stage5d = RSU4F(128,16,64)
        self.stage4d = RSU4(128,16,64)
        self.stage3d = RSU5(128,16,64)
        self.stage2d = RSU6(128,16,64)
        self.stage1d = RSU7(128,16,64)

        self.side1 = nn.Conv2d(64,out_ch,3,padding=1)
        self.side2 = nn.Conv2d(64,out_ch,3,padding=1)
        self.side3 = nn.Conv2d(64,out_ch,3,padding=1)
        self.side4 = nn.Conv2d(64,out_ch,3,padding=1)
        self.side5 = nn.Conv2d(64,out_ch,3,padding=1)
        self.side6 = nn.Conv2d(64,out_ch,3,padding=1)

        self.outconv = nn.Conv2d(6,out_ch,1)

    def forward(self,x):

        hx = x

        #stage 1
        hx1 = self.stage1(hx)
        hx = self.pool12(hx1)

        #stage 2
        hx2 = self.stage2(hx)
        hx = self.pool23(hx2)

        #stage 3
        hx3 = self.stage3(hx)
        hx = self.pool34(hx3)

        #stage 4
        hx4 = self.stage4(hx)
        hx = self.pool45(hx4)

        #stage 5
        hx5 = self.stage5(hx)
        hx = self.pool56(hx5)

        #stage 6
        hx6 = self.stage6(hx)
        hx6up = _upsample_like(hx6,hx5)

        #decoder
        hx5d = self.stage5d(torch.cat((hx6up,hx5),1))
        hx5dup = _upsample_like(hx5d,hx4)

        hx4d = self.stage4d(torch.cat((hx5dup,hx4),1))
        hx4dup = _upsample_like(hx4d,hx3)

        hx3d = self.stage3d(torch.cat((hx4dup,hx3),1))
        hx3dup = _upsample_like(hx3d,hx2)

        hx2d = self.stage2d(torch.cat((hx3dup,hx2),1))
        hx2dup = _upsample_like(hx2d,hx1)

        hx1d = self.stage1d(torch.cat((hx2dup,hx1),1))


        #side output
        d1 = self.side1(hx1d)

        d2 = self.side2(hx2d)
        d2 = _upsample_like(d2,d1)

        d3 = self.side3(hx3d)
        d3 = _upsample_like(d3,d1)

        d4 = self.side4(hx4d)
        d4 = _upsample_like(d4,d1)

        d5 = self.side5(hx5d)
        d5 = _upsample_like(d5,d1)

        d6 = self.side6(hx6)
        d6 = _upsample_like(d6,d1)

        d0 = self.outconv(torch.cat((d1,d2,d3,d4,d5,d6),1))

        return F.sigmoid(d0), F.sigmoid(d1), F.sigmoid(d2), F.sigmoid(d3), F.sigmoid(d4), F.sigmoid(d5), F.sigmoid(d6)
相关推荐
深度学习实战训练营34 分钟前
基于CNN-RNN的影像报告生成
人工智能·深度学习
昨日之日20063 小时前
Moonshine - 新型开源ASR（语音识别）模型，体积小，速度快，比OpenAI Whisper快五倍 本地一键整合包下载
人工智能·whisper·语音识别
浮生如梦_3 小时前
Halcon基于laws纹理特征的SVM分类
图像处理·人工智能·算法·支持向量机·计算机视觉·分类·视觉检测
深度学习lover3 小时前
＜项目代码＞YOLOv8 苹果腐烂识别＜目标检测＞
人工智能·python·yolo·目标检测·计算机视觉·苹果腐烂识别
热爱跑步的恒川4 小时前
【论文复现】基于图卷积网络的轻量化推荐模型
网络·人工智能·开源·aigc·ai编程
阡之尘埃6 小时前
Python数据分析案例61——信贷风控评分卡模型(A卡)（scorecardpy 全面解析）
人工智能·python·机器学习·数据分析·智能风控·信贷风控
孙同学要努力8 小时前
全连接神经网络案例——手写数字识别
人工智能·深度学习·神经网络
Eric.Lee20218 小时前
yolo v5 开源项目
人工智能·yolo·目标检测·计算机视觉
其实吧39 小时前
基于Matlab的图像融合研究设计
人工智能·计算机视觉·matlab
丕羽9 小时前
【Pytorch】基本语法
人工智能·pytorch·python
热门推荐
01【HarmonyOS】HUAWEI DevEco Studio 下载地址汇总02(欧拉)openEuler系统添加网卡文件配置流程、(欧拉)openEuler系统手动配置ipv6地址流程、(欧拉)openEuler系统网络管理说明03组基轨迹建模 GBTM的介绍与实现（Stata 或 R）04【AIGC】重塑未来的科技巨轮05全面解析：构建基于深度学习的安全帽检测系统（UI界面+YOLO代码+数据集）06【经验分享】Ubuntu22.04安装微信(linux官方版)07基于YOLOv10深度学习的CT扫描图像肾结石智能检测系统【python源码+Pyqt5界面+数据集+训练代码】深度学习实战、目标检测08Ubuntu 20.04使用Livox mid 360 测试 FAST_LIO09RAG 实践- Ollama+RagFlow 部署本地知识库10红米手机使用google play
