第45节：分布式渲染：Web Workers多线程渲染优化

概述

随着Web应用复杂度的增加，单线程渲染已成为性能瓶颈。分布式渲染通过Web Workers将计算任务分发到多个线程，充分利用多核CPU优势，显著提升渲染性能。

分布式渲染架构：
主线程任务调度器几何处理Worker 物理计算Worker 光照计算Worker 后期处理Worker 顶点处理几何变换 LOD计算碰撞检测物理模拟约束求解阴影计算光照烘焙全局光照效果合成色调映射抗锯齿结果收集器最终渲染

核心原理

Web Workers通信模式

通信模式	适用场景	优点	缺点
Transferable Objects	大数据传输	零拷贝，高性能	数据所有权转移
SharedArrayBuffer	多线程共享数据	真正共享内存	需要同步机制
MessageChannel	双向通信	灵活，支持多通道	序列化开销
BroadcastChannel	广播通信	一对多通信	所有Worker都能接收

任务分割策略

javascript 复制代码

// 任务分割配置
class TaskScheduler {
    static createRenderTasks(scene, camera, renderer, workerCount) {
        const tasks = [];
        const objects = scene.getVisibleObjects(camera);
        const objectsPerWorker = Math.ceil(objects.length / workerCount);

        for (let i = 0; i < workerCount; i++) {
            const start = i * objectsPerWorker;
            const end = Math.min(start + objectsPerWorker, objects.length);
            const workerObjects = objects.slice(start, end);

            tasks.push({
                workerId: i,
                objects: workerObjects,
                camera: camera.clone(),
                viewport: this.calculateViewport(i, workerCount),
                dependencies: this.calculateDependencies(i, workerCount)
            });
        }

        return tasks;
    }

    static calculateViewport(workerIndex, totalWorkers) {
        const width = 1.0 / totalWorkers;
        const x = workerIndex * width;
        return { x, y: 0, width, height: 1.0 };
    }
}

完整代码实现

分布式渲染系统

vue 复制代码

<template>
  <div class="distributed-rendering-container">
    <!-- 主渲染视图 -->
    <div class="render-view">
      <canvas ref="mainCanvas" class="main-canvas"></canvas>

      <!-- Worker状态监控 -->
      <div class="worker-monitor">
        <div class="monitor-panel">
          <h4>Worker状态监控</h4>
          <div class="worker-grid">
            <div v-for="worker in workerStatus"
                 :key="worker.id"
                 :class="['worker-status', worker.status]">
              <div class="worker-header">
                <span class="worker-name">{{ worker.name }}</span>
                <span class="worker-indicator">{{ worker.indicator }}</span>
              </div>
              <div class="worker-stats">
                <div class="stat">任务: {{ worker.tasksCompleted }}</div>
                <div class="stat">内存: {{ worker.memory }} MB</div>
                <div class="stat">负载: {{ worker.load }}%</div>
              </div>
            </div>
          </div>
        </div>

        <div class="performance-panel">
          <h4>性能统计</h4>
          <div class="performance-stats">
            <div class="perf-item">
              <span>主线程帧率:</span>
              <span>{{ mainFPS }} FPS</span>
            </div>
            <div class="perf-item">
              <span>Worker帧率:</span>
              <span>{{ workerFPS }} FPS</span>
            </div>
            <div class="perf-item">
              <span>通信开销:</span>
              <span>{{ communicationOverhead }}ms</span>
            </div>
            <div class="perf-item">
              <span>并行加速比:</span>
              <span>{{ speedupRatio }}x</span>
            </div>
          </div>
        </div>
      </div>
    </div>

    <!-- 控制面板 -->
    <div class="control-panel">
      <div class="panel-section">
        <h3>🔧 Worker配置</h3>

        <div class="worker-config">
          <div class="config-group">
            <label>Worker数量</label>
            <select v-model="workerCount" @change="reinitializeWorkers">
              <option value="2">2 Workers</option>
              <option value="4">4 Workers</option>
              <option value="8">8 Workers</option>
              <option value="auto">自动检测</option>
            </select>
          </div>

          <div class="config-group">
            <label>任务分配策略</label>
            <select v-model="taskStrategy">
              <option value="spatial">空间分割</option>
              <option value="object">物体分割</option>
              <option value="hybrid">混合分割</option>
            </select>
          </div>

          <div class="config-group">
            <label>通信模式</label>
            <select v-model="communicationMode">
              <option value="transferable">Transferable Objects</option>
              <option value="shared">SharedArrayBuffer</option>
              <option value="message">MessageChannel</option>
            </select>
          </div>
        </div>
      </div>

      <div class="panel-section">
        <h3>⚡ 渲染优化</h3>

        <div class="optimization-controls">
          <div class="control-group">
            <label>
              <input type="checkbox" v-model="enableGeometryWorker">
              几何处理Worker
            </label>
          </div>

          <div class="control-group">
            <label>
              <input type="checkbox" v-model="enableLightingWorker">
              光照计算Worker
            </label>
          </div>

          <div class="control-group">
            <label>
              <input type="checkbox" v-model="enablePhysicsWorker">
              物理计算Worker
            </label>
          </div>

          <div class="control-group">
            <label>
              <input type="checkbox" v-model="enablePostProcessingWorker">
              后期处理Worker
            </label>
          </div>

          <div class="control-group">
            <label>任务粒度</label>
            <input type="range" v-model="taskGranularity" min="1" max="10">
            <span>{{ taskGranularity }}</span>
          </div>
        </div>
      </div>

      <div class="panel-section">
        <h3>📊 负载均衡</h3>

        <div class="load-balancing">
          <div class="balance-controls">
            <div class="control-group">
              <label>动态负载均衡</label>
              <input type="checkbox" v-model="dynamicLoadBalancing">
            </div>

            <div class="control-group">
              <label>均衡频率</label>
              <input type="range" v-model="balanceFrequency" min="1" max="60">
              <span>{{ balanceFrequency }}帧</span>
            </div>

            <div class="control-group">
              <label>负载阈值</label>
              <input type="range" v-model="loadThreshold" min="50" max="95">
              <span>{{ loadThreshold }}%</span>
            </div>
          </div>

          <div class="load-distribution">
            <h5>负载分布</h5>
            <div class="distribution-bars">
              <div v-for="worker in workerStatus"
                   :key="worker.id"
                   class="distribution-bar">
                <div class="bar-label">{{ worker.name }}</div>
                <div class="bar-container">
                  <div class="bar-fill" :style="{ width: worker.load + '%' }"></div>
                </div>
                <div class="bar-value">{{ worker.load }}%</div>
              </div>
            </div>
          </div>
        </div>
      </div>

      <div class="panel-section">
        <h3>🎮 场景控制</h3>

        <div class="scene-controls">
          <div class="control-group">
            <label>场景复杂度</label>
            <select v-model="sceneComplexity" @change="updateScene">
              <option value="low">低 (1K物体)</option>
              <option value="medium">中 (10K物体)</option>
              <option value="high">高 (100K物体)</option>
            </select>
          </div>

          <div class="control-group">
            <label>渲染模式</label>
            <select v-model="renderMode" @change="toggleRenderMode">
              <option value="single">单线程</option>
              <option value="multi">多线程</option>
              <option value="hybrid">混合模式</option>
            </select>
          </div>

          <div class="control-buttons">
            <button @click="startWorkers" class="control-button" :disabled="workersRunning">
              ▶️ 启动Workers
            </button>
            <button @click="stopWorkers" class="control-button" :disabled="!workersRunning">
              ⏹️ 停止Workers
            </button>
            <button @click="resetScene" class="control-button">
              🔄 重置场景
            </button>
          </div>
        </div>
      </div>
    </div>

    <!-- 通信监控 -->
    <div v-if="showCommunicationMonitor" class="communication-monitor">
      <div class="monitor-header">
        <h4>线程通信监控</h4>
        <button @click="showCommunicationMonitor = false" class="close-button">×</button>
      </div>
      <div class="communication-logs">
        <div v-for="log in communicationLogs"
             :key="log.id"
             :class="['log-entry', log.type]">
          <span class="log-time">{{ log.timestamp }}</span>
          <span class="log-direction">{{ log.direction }}</span>
          <span class="log-message">{{ log.message }}</span>
          <span class="log-size">{{ log.size }} KB</span>
        </div>
      </div>
    </div>
  </div>
</template>

<script>
import { onMounted, onUnmounted, ref, reactive, computed } from 'vue';
import * as THREE from 'three';
import { OrbitControls } from 'three/addons/controls/OrbitControls.js';

// Worker管理器
class WorkerManager {
  constructor() {
    this.workers = new Map();
    this.taskQueue = new Map();
    this.results = new Map();
    this.workerScripts = new Map();

    this.setupWorkerScripts();
  }

  setupWorkerScripts() {
    // 注册不同类型的Worker
    this.workerScripts.set('geometry', this.createGeometryWorkerScript());
    this.workerScripts.set('lighting', this.createLightingWorkerScript());
    this.workerScripts.set('physics', this.createPhysicsWorkerScript());
    this.workerScripts.set('postprocess', this.createPostProcessWorkerScript());
  }

  // 初始化Workers
  async initializeWorkers(count, types = ['geometry', 'lighting', 'physics', 'postprocess']) {
    this.terminateAllWorkers();

    const cpuCores = navigator.hardwareConcurrency || 4;
    const actualCount = count === 'auto' ? Math.min(cpuCores, types.length) : parseInt(count);

    for (let i = 0; i < actualCount; i++) {
      const workerType = types[i % types.length];
      const worker = await this.createWorker(workerType, i);
      this.workers.set(worker.id, worker);
    }

    return Array.from(this.workers.values());
  }

  // 创建Worker
  createWorker(type, id) {
    return new Promise((resolve) => {
      const blob = new Blob([this.workerScripts.get(type)], { type: 'application/javascript' });
      const workerUrl = URL.createObjectURL(blob);
      const worker = new Worker(workerUrl);

      worker.id = `worker_${type}_${id}`;
      worker.type = type;
      worker.status = 'idle';
      worker.tasksCompleted = 0;

      // 设置消息处理器
      worker.onmessage = (event) => {
        this.handleWorkerMessage(worker, event);
      };

      worker.onerror = (error) => {
        console.error(`Worker ${worker.id} 错误:`, error);
        worker.status = 'error';
      };

      resolve(worker);
    });
  }

  // 处理Worker消息
  handleWorkerMessage(worker, event) {
    const { type, taskId, result, error, performance } = event.data;

    switch (type) {
      case 'ready':
        worker.status = 'ready';
        break;

      case 'task_complete':
        worker.status = 'idle';
        worker.tasksCompleted++;
        this.results.set(taskId, result);
        this.taskQueue.delete(taskId);

        // 触发任务完成回调
        if (this.onTaskComplete) {
          this.onTaskComplete(taskId, result, performance);
        }
        break;

      case 'error':
        worker.status = 'error';
        console.error(`Worker ${worker.id} 任务错误:`, error);
        break;
    }
  }

  // 分配任务
  assignTask(workerId, task) {
    const worker = this.workers.get(workerId);
    if (!worker || worker.status !== 'idle') return false;

    worker.status = 'working';
    const taskId = this.generateTaskId();

    this.taskQueue.set(taskId, {
      workerId,
      task,
      startTime: performance.now()
    });

    // 使用Transferable Objects优化大数据传输
    const transferables = this.prepareTransferableObjects(task);

    worker.postMessage({
      type: 'execute_task',
      taskId,
      task
    }, transferables);

    return taskId;
  }

  // 准备可传输对象
  prepareTransferableObjects(task) {
    const transferables = [];

    if (task.geometryData && task.geometryData.vertices) {
      transferables.push(task.geometryData.vertices.buffer);
    }

    if (task.textureData) {
      transferables.push(task.textureData.buffer);
    }

    return transferables;
  }

  // 智能任务调度
  scheduleTask(task) {
    // 找到最适合的Worker
    const suitableWorkers = this.findSuitableWorkers(task.type);
    if (suitableWorkers.length === 0) return null;

    // 选择负载最低的Worker
    const bestWorker = suitableWorkers.reduce((prev, current) =>
      prev.load < current.load ? prev : current
    );

    return this.assignTask(bestWorker.id, task);
  }

  // 查找合适的Worker
  findSuitableWorkers(taskType) {
    return Array.from(this.workers.values()).filter(worker =>
      worker.status === 'idle' &&
      (worker.type === taskType || worker.type === 'general')
    );
  }

  generateTaskId() {
    return `task_${Date.now()}_${Math.random().toString(36).substr(2, 9)}`;
  }

  // 终止所有Worker
  terminateAllWorkers() {
    for (const worker of this.workers.values()) {
      worker.terminate();
    }
    this.workers.clear();
    this.taskQueue.clear();
    this.results.clear();
  }

  // 创建Worker脚本
  createGeometryWorkerScript() {
    return `
      importScripts('https://cdnjs.cloudflare.com/ajax/libs/three.js/r128/three.min.js');

      let scene, camera;
      const geometries = new Map();

      self.onmessage = function(event) {
        const { type, taskId, task } = event.data;

        switch (type) {
          case 'execute_task':
            handleGeometryTask(taskId, task);
            break;
        }
      };

      function handleGeometryTask(taskId, task) {
        const startTime = performance.now();

        try {
          // 处理几何数据
          const result = processGeometryData(task.geometryData, task.operations);
          const processingTime = performance.now() - startTime;

          self.postMessage({
            type: 'task_complete',
            taskId,
            result,
            performance: {
              processingTime,
              memory: getMemoryUsage()
            }
          });
        } catch (error) {
          self.postMessage({
            type: 'error',
            taskId,
            error: error.message
          });
        }
      }

      function processGeometryData(geometryData, operations) {
        // 创建BufferGeometry
        const geometry = new THREE.BufferGeometry();

        if (geometryData.vertices) {
          const vertices = new Float32Array(geometryData.vertices);
          geometry.setAttribute('position', new THREE.BufferAttribute(vertices, 3));
        }

        if (geometryData.normals) {
          const normals = new Float32Array(geometryData.normals);
          geometry.setAttribute('normal', new THREE.BufferAttribute(normals, 3));
        }

        // 应用几何操作
        if (operations.transform) {
          applyTransform(geometry, operations.transform);
        }

        if (operations.lod) {
          applyLOD(geometry, operations.lod);
        }

        // 计算边界体积
        geometry.computeBoundingSphere();
        geometry.computeBoundingBox();

        return {
          geometry: serializeGeometry(geometry),
          bounds: {
            boundingSphere: geometry.boundingSphere,
            boundingBox: geometry.boundingBox
          }
        };
      }

      function serializeGeometry(geometry) {
        // 简化几何体序列化
        const attributes = {};
        for (const [name, attribute] of Object.entries(geometry.attributes)) {
          attributes[name] = {
            array: attribute.array,
            itemSize: attribute.itemSize,
            normalized: attribute.normalized
          };
        }

        return {
          attributes,
          index: geometry.index ? geometry.index.array : null
        };
      }

      function getMemoryUsage() {
        return performance.memory ? (performance.memory.usedJSHeapSize / 1048576).toFixed(1) : 0;
      }

      // 通知主线程Worker已就绪
      self.postMessage({ type: 'ready' });
    `;
  }

  createLightingWorkerScript() {
    return `
      // 光照计算Worker实现
      self.onmessage = function(event) {
        const { type, taskId, task } = event.data;

        if (type === 'execute_task') {
          handleLightingTask(taskId, task);
        }
      };

      function handleLightingTask(taskId, task) {
        // 光照计算逻辑
        const result = calculateLighting(task.sceneData, task.lights, task.materials);

        self.postMessage({
          type: 'task_complete',
          taskId,
          result
        });
      }

      function calculateLighting(sceneData, lights, materials) {
        // 简化光照计算
        return {
          lightingData: new Float32Array(sceneData.vertexCount * 3),
          shadows: new Uint8Array(sceneData.vertexCount)
        };
      }
    `;
  }

  createPhysicsWorkerScript() {
    return `
      // 物理计算Worker实现
      importScripts('https://cdn.jsdelivr.net/npm/ammo.js@1.0.0/builds/ammo.wasm.js');

      let physicsWorld;

      self.onmessage = async function(event) {
        const { type, taskId, task } = event.data;

        if (type === 'execute_task') {
          await handlePhysicsTask(taskId, task);
        }
      };

      async function handlePhysicsTask(taskId, task) {
        if (!physicsWorld) {
          await initPhysics();
        }

        // 物理模拟逻辑
        const result = simulatePhysics(task.bodies, task.constraints, task.deltaTime);

        self.postMessage({
          type: 'task_complete',
          taskId,
          result
        });
      }

      async function initPhysics() {
        // 初始化物理引擎
        // 简化实现
      }
    `;
  }

  createPostProcessWorkerScript() {
    return `
      // 后期处理Worker实现
      self.onmessage = function(event) {
        const { type, taskId, task } = event.data;

        if (type === 'execute_task') {
          handlePostProcessTask(taskId, task);
        }
      };

      function handlePostProcessTask(taskId, task) {
        const result = applyPostProcessing(
          task.imageData,
          task.effects,
          task.parameters
        );

        self.postMessage({
          type: 'task_complete',
          taskId,
          result
        }, [result.buffer]); // 传输结果缓冲区
      }

      function applyPostProcessing(imageData, effects, parameters) {
        // 后期处理效果应用
        const processedData = new Uint8ClampedArray(imageData.data);

        effects.forEach(effect => {
          switch (effect) {
            case 'bloom':
              applyBloom(processedData, parameters);
              break;
            case 'ssao':
              applySSAO(processedData, parameters);
              break;
            case 'colorGrading':
              applyColorGrading(processedData, parameters);
              break;
          }
        });

        return processedData;
      }
    `;
  }
}

// 分布式渲染器
class DistributedRenderer {
  constructor(mainRenderer, workerManager) {
    this.mainRenderer = mainRenderer;
    this.workerManager = workerManager;
    this.renderTasks = new Map();
    this.partialResults = new Map();

    this.setupWorkerCallbacks();
  }

  setupWorkerCallbacks() {
    this.workerManager.onTaskComplete = (taskId, result, performance) => {
      this.handleTaskResult(taskId, result, performance);
    };
  }

  // 分布式渲染
  async renderDistributed(scene, camera) {
    const startTime = performance.now();

    // 分割渲染任务
    const tasks = this.splitRenderTasks(scene, camera);
    const taskPromises = [];

    // 分配任务给Workers
    for (const task of tasks) {
      const taskId = this.workerManager.scheduleTask(task);
      if (taskId) {
        taskPromises.push(this.waitForTask(taskId));
      }
    }

    // 等待所有任务完成
    await Promise.all(taskPromises);

    // 合成最终结果
    const finalResult = this.composeResults();
    const renderTime = performance.now() - startTime;

    return { finalResult, renderTime, taskCount: tasks.length };
  }

  // 分割渲染任务
  splitRenderTasks(scene, camera) {
    const tasks = [];
    const visibleObjects = this.getVisibleObjects(scene, camera);
    const workerCount = this.workerManager.workers.size;

    // 基于空间分割任务
    if (this.taskStrategy === 'spatial') {
      const spatialTasks = this.createSpatialTasks(scene, camera, workerCount);
      tasks.push(...spatialTasks);
    }
    // 基于物体分割任务
    else if (this.taskStrategy === 'object') {
      const objectTasks = this.createObjectTasks(visibleObjects, workerCount);
      tasks.push(...objectTasks);
    }

    return tasks;
  }

  // 创建空间分割任务
  createSpatialTasks(scene, camera, workerCount) {
    const tasks = [];
    const frustum = new THREE.Frustum();
    const projectionMatrix = new THREE.Matrix4().multiplyMatrices(
      camera.projectionMatrix, camera.matrixWorldInverse
    );
    frustum.setFromProjectionMatrix(projectionMatrix);

    // 将视锥体分割为多个子区域
    for (let i = 0; i < workerCount; i++) {
      const subFrustum = this.createSubFrustum(frustum, i, workerCount);
      const taskObjects = this.getObjectsInFrustum(scene, subFrustum);

      tasks.push({
        type: 'render',
        workerType: 'geometry',
        objects: taskObjects,
        camera: this.cloneCamera(camera),
        viewport: this.calculateViewport(i, workerCount),
        frustum: subFrustum
      });
    }

    return tasks;
  }

  // 处理任务结果
  handleTaskResult(taskId, result, performance) {
    this.partialResults.set(taskId, result);

    // 记录性能数据
    this.performanceStats.push({
      taskId,
      workerId: this.workerManager.taskQueue.get(taskId)?.workerId,
      ...performance
    });
  }

  // 等待任务完成
  waitForTask(taskId) {
    return new Promise((resolve) => {
      const checkResult = () => {
        if (this.partialResults.has(taskId)) {
          resolve(this.partialResults.get(taskId));
        } else {
          setTimeout(checkResult, 1);
        }
      };
      checkResult();
    });
  }

  // 合成结果
  composeResults() {
    const finalCanvas = document.createElement('canvas');
    const context = finalCanvas.getContext('2d');

    finalCanvas.width = this.mainRenderer.domElement.width;
    finalCanvas.height = this.mainRenderer.domElement.height;

    // 合并所有部分渲染结果
    for (const [taskId, result] of this.partialResults) {
      if (result.imageData) {
        this.mergeImageData(context, result.imageData, result.viewport);
      }
    }

    this.partialResults.clear();
    return finalCanvas;
  }

  mergeImageData(context, imageData, viewport) {
    const tempCanvas = document.createElement('canvas');
    const tempContext = tempCanvas.getContext('2d');

    tempCanvas.width = imageData.width;
    tempCanvas.height = imageData.height;

    tempContext.putImageData(imageData, 0, 0);

    context.drawImage(
      tempCanvas,
      viewport.x * context.canvas.width,
      viewport.y * context.canvas.height,
      viewport.width * context.canvas.width,
      viewport.height * context.canvas.height
    );
  }
}

export default {
  name: 'DistributedRendering',
  setup() {
    // 响应式状态
    const mainCanvas = ref(null);

    const workerCount = ref('4');
    const taskStrategy = ref('spatial');
    const communicationMode = ref('transferable');
    const enableGeometryWorker = ref(true);
    const enableLightingWorker = ref(true);
    const enablePhysicsWorker = ref(false);
    const enablePostProcessingWorker = ref(false);
    const taskGranularity = ref(5);
    const dynamicLoadBalancing = ref(true);
    const balanceFrequency = ref(30);
    const loadThreshold = ref(80);
    const sceneComplexity = ref('medium');
    const renderMode = ref('multi');
    const showCommunicationMonitor = ref(false);

    // Worker状态
    const workerStatus = ref([]);
    const workersRunning = ref(false);

    // 性能统计
    const mainFPS = ref(0);
    const workerFPS = ref(0);
    const communicationOverhead = ref(0);
    const speedupRatio = ref(1);

    // 通信日志
    const communicationLogs = ref([]);

    // Three.js 和 Worker 对象
    let renderer, scene, camera, controls;
    let workerManager, distributedRenderer;
    let animationFrameId;
    let frameCount = 0;
    let lastFpsUpdate = 0;

    // 初始化
    const init = async () => {
      await initRenderer();
      initScene();
      await initWorkers();
      startAnimationLoop();
    };

    // 初始化渲染器
    const initRenderer = () => {
      renderer = new THREE.WebGLRenderer({
        canvas: mainCanvas.value,
        antialias: true,
        powerPreference: "high-performance"
      });

      renderer.setSize(window.innerWidth, window.innerHeight);
      renderer.setPixelRatio(Math.min(window.devicePixelRatio, 2));
    };

    // 初始化场景
    const initScene = () => {
      scene = new THREE.Scene();
      scene.background = new THREE.Color(0x1a1a2e);

      camera = new THREE.PerspectiveCamera(60, window.innerWidth / window.innerHeight, 0.1, 1000);
      camera.position.set(0, 10, 20);

      controls = new OrbitControls(camera, renderer.domElement);
      controls.enableDamping = true;

      // 照明
      const ambientLight = new THREE.AmbientLight(0x404040, 0.6);
      scene.add(ambientLight);

      const directionalLight = new THREE.DirectionalLight(0xffffff, 0.8);
      directionalLight.position.set(50, 50, 25);
      scene.add(directionalLight);

      // 创建测试场景
      createTestScene();
    };

    // 初始化Workers
    const initWorkers = async () => {
      workerManager = new WorkerManager();

      const workerTypes = [];
      if (enableGeometryWorker.value) workerTypes.push('geometry');
      if (enableLightingWorker.value) workerTypes.push('lighting');
      if (enablePhysicsWorker.value) workerTypes.push('physics');
      if (enablePostProcessingWorker.value) workerTypes.push('postprocess');

      const workers = await workerManager.initializeWorkers(workerCount.value, workerTypes);

      // 初始化Worker状态监控
      updateWorkerStatus(workers);

      distributedRenderer = new DistributedRenderer(renderer, workerManager);
    };

    // 重新初始化Workers
    const reinitializeWorkers = async () => {
      await initWorkers();
    };

    // 创建测试场景
    const createTestScene = () => {
      // 创建地面
      const groundGeometry = new THREE.PlaneGeometry(50, 50);
      const groundMaterial = new THREE.MeshStandardMaterial({ color: 0x3a3a3a });
      const ground = new THREE.Mesh(groundGeometry, groundMaterial);
      ground.rotation.x = -Math.PI / 2;
      ground.receiveShadow = true;
      scene.add(ground);

      // 根据复杂度创建物体
      const objectCount = getObjectCount(sceneComplexity.value);
      for (let i = 0; i < objectCount; i++) {
        const object = createRandomObject();
        scene.add(object);
      }
    };

    // 获取物体数量
    const getObjectCount = (complexity) => {
      const counts = {
        low: 1000,
        medium: 10000,
        high: 100000
      };
      return counts[complexity] || 1000;
    };

    // 创建随机物体
    const createRandomObject = () => {
      const geometries = [
        () => new THREE.BoxGeometry(1, 1, 1),
        () => new THREE.SphereGeometry(0.5, 8, 6),
        () => new THREE.ConeGeometry(0.5, 1, 8)
      ];

      const geometry = geometries[Math.floor(Math.random() * geometries.length)]();
      const material = new THREE.MeshStandardMaterial({
        color: new THREE.Color().setHSL(Math.random(), 0.7, 0.5)
      });

      const mesh = new THREE.Mesh(geometry, material);

      mesh.position.set(
        (Math.random() - 0.5) * 40,
        Math.random() * 10 + 1,
        (Math.random() - 0.5) * 40
      );

      mesh.rotation.set(
        Math.random() * Math.PI,
        Math.random() * Math.PI,
        Math.random() * Math.PI
      );

      mesh.castShadow = true;

      return mesh;
    };

    // 更新Worker状态
    const updateWorkerStatus = (workers) => {
      workerStatus.value = workers.map(worker => ({
        id: worker.id,
        name: worker.id,
        status: worker.status,
        indicator: getStatusIndicator(worker.status),
        tasksCompleted: worker.tasksCompleted,
        memory: (Math.random() * 50 + 10).toFixed(1), // 模拟内存使用
        load: Math.floor(Math.random() * 100) // 模拟负载
      }));
    };

    // 获取状态指示器
    const getStatusIndicator = (status) => {
      const indicators = {
        ready: '🟢',
        working: '🟡',
        idle: '⚪',
        error: '🔴'
      };
      return indicators[status] || '⚪';
    };

    // 启动Workers
    const startWorkers = () => {
      workersRunning.value = true;
      // 实际实现中会开始分配任务
    };

    // 停止Workers
    const stopWorkers = () => {
      workersRunning.value = false;
      workerManager.terminateAllWorkers();
    };

    // 重置场景
    const resetScene = () => {
      // 清理场景并重新创建
      while (scene.children.length > 0) {
        const child = scene.children[0];
        if (child.isMesh) {
          child.geometry.dispose();
          child.material.dispose();
        }
        scene.remove(child);
      }

      createTestScene();
    };

    // 切换渲染模式
    const toggleRenderMode = () => {
      // 实现渲染模式切换逻辑
    };

    // 更新场景
    const updateScene = () => {
      resetScene();
    };

    // 动画循环
    const startAnimationLoop = () => {
      const animate = () => {
        animationFrameId = requestAnimationFrame(animate);

        // 更新控制
        controls.update();

        // 性能统计
        updatePerformanceStats();

        // 渲染
        if (renderMode.value === 'multi' && workersRunning.value) {
          // 分布式渲染
          renderDistributed();
        } else {
          // 单线程渲染
          renderer.render(scene, camera);
        }
      };
      animate();
    };

    // 分布式渲染
    const renderDistributed = async () => {
      const result = await distributedRenderer.renderDistributed(scene, camera);

      // 使用Worker渲染结果
      if (result.finalResult) {
        const context = renderer.getContext();
        context.drawImage(result.finalResult, 0, 0);
      }
    };

    // 更新性能统计
    const updatePerformanceStats = () => {
      frameCount++;
      const now = performance.now();

      if (now - lastFpsUpdate >= 1000) {
        mainFPS.value = Math.round((frameCount * 1000) / (now - lastFpsUpdate));
        frameCount = 0;
        lastFpsUpdate = now;
      }

      // 模拟Worker性能数据
      workerFPS.value = Math.round(mainFPS.value * 0.8 + Math.random() * 10);
      communicationOverhead.value = (Math.random() * 2).toFixed(1);
      speedupRatio.value = (workerFPS.value / mainFPS.value).toFixed(1);
    };

    onMounted(() => {
      init();
      window.addEventListener('resize', handleResize);
    });

    onUnmounted(() => {
      if (animationFrameId) {
        cancelAnimationFrame(animationFrameId);
      }
      if (workerManager) {
        workerManager.terminateAllWorkers();
      }
      if (renderer) {
        renderer.dispose();
      }
      window.removeEventListener('resize', handleResize);
    });

    const handleResize = () => {
      if (!camera || !renderer) return;

      camera.aspect = window.innerWidth / window.innerHeight;
      camera.updateProjectionMatrix();
      renderer.setSize(window.innerWidth, window.innerHeight);
