分为子任务和总任务
子任务分为执行和质询环节
只有质询环节回复结束标识后才会退出子任务
python
工作流程定义:
任务1: 打开模之屋 - 已完成
任务2: 用ocr识别 叶瞬光 模型页面所在位置 - 已完成
任务3: 点击 叶瞬光 模型页面所在位置 - 已完成
任务4: 上下滚动滚轮寻找点赞和收藏按钮 - 已完成
任务5: 用yolo识别 点赞和收藏按钮 - 已完成
任务6: 依次点击 点赞和收藏 按钮 - 已完成
任务7: 上下滚动滚轮寻找下载模型按钮，要滚动到显示全，不然ocr识别不到，多滚动一点 - 已完成
任务8: 用ocr识别 下载模型 按钮所在位置 - 已完成
任务9: 点击 下载模型 按钮 - 已完成
任务10: 按下ctrl+j查看下载栏有没有下载，有才能输出[TOTAL_TASK_COMPLETED]，没有的话继续ocr寻找下载按钮点击 - 已完成
执行历史:
AI响应: [TOOL:open_browser,https://www.aplaybox.com/model/model]
工具 'open_browser' 执行结果: 成功 打开网页: https://www.aplaybox.com/model/model
任务1执行完成
AI响应: [TOOL:ocr_detect,叶瞬光]
工具 'ocr_detect' 执行结果: {
"text": "[绝区零] 叶瞬光 「暖",
"target_text": "叶瞬光",
"center_x": 1492,
"center_y": 466
}
任务2执行完成
AI响应: [TOOL:click_mouse,1492,466,left,1,0.1]
工具 'click_mouse' 执行结果: 点击成功: (1492.0, 466.0), 类型: left, 次数: 1.0
任务3执行完成
AI响应: [TOOL:scroll_mouse,-50,1200,500]
工具 'scroll_mouse' 执行结果: 滚动成功: -50单位，位置: (1200, 500)
AI响应: [TOOL:detect_like_favorite]
工具 'detect_like_favorite' 执行结果: {
"like_button": {
"x": 140,
"y": 925
},
"favorite_button": {
"x": 207,
"y": 925
}
}
任务4执行完成
[TASK_COMPLETED]
工具 'detect_like_favorite' 执行结果: 正在截取当前屏幕...
0: 384x640 1 like, 1 favorite, 73.2ms
Speed: 3.8ms preprocess, 73.2ms inference, 9.8ms postprocess per image at shape (1, 3, 384, 640)
识别结果已保存到: E:\code\my_python_server\yolo\output\result_auto_screenshot_1767425426.jpg
检测到 2 个元素:
- like: 位置(246.1, 1003.3), 置信度0.55
- favorite: 位置(390.3, 1001.3), 置信度0.14
任务4执行完成
AI响应: 根据当前屏幕截图分析，已经成功使用YOLO识别出点赞和收藏按钮的位置：
- **点赞按钮**：位于坐标 (246.1, 1003.3)，置信度为 0.55
- **收藏按钮**：位于坐标 (390.3, 1001.3)，置信度为 0.14
接下来，我将按照任务要求点击这两个按钮。
[TOOL:click_mouse,246,1003,left,1,0.1]
[TOOL:click_mouse,390,1001,left,1,0.1]
工具 'click_mouse' 执行结果: 点击成功: (246.0, 1003.0), 类型: left, 次数: 1.0
工具 'click_mouse' 执行结果: 点击成功: (390.0, 1001.0), 类型: left, 次数: 1.0
任务5执行完成
AI响应: 根据当前屏幕截图分析，任务5/10"用yolo识别点赞和收藏按钮"已经完成。点赞和收藏按钮已被成功识别并点击，相关操作已执行完毕。
当前页面显示的是【绝区零】叶瞬光「暖霞拾光」的模型详情页，点赞数为1895，收藏数为1872，表明点赞和收藏操作已生效。
接下来可以继续执行后续任务（如下载模型等），或者根据需求进行其他操作。如果有新的任务，请告知！
任务6执行完成
AI响应: 根据当前屏幕截图分析，任务6/10"依次点击点赞和收藏按钮"已经完成。点赞数为1895，收藏数为1872，表明操作已生效。
接下来，我将按照任务要求上下滚动滚轮寻找下载模型按钮，并确保其完全显示以便OCR识别。
[TOOL:scroll_mouse,-100,1200,500]
工具 'scroll_mouse' 执行结果: 滚动成功: -100单位，位置: (1200, 500)
AI响应: [TOOL:scroll_mouse,-150,1200,500]
工具 'scroll_mouse' 执行结果: 滚动成功: -150单位，位置: (1200, 500)
AI响应: [TOOL:scroll_mouse,-200,1200,500]
工具 'scroll_mouse' 执行结果: 滚动成功: -200单位，位置: (1200, 500)
AI响应: [TOOL:scroll_mouse,-100,1200,500]
工具 'scroll_mouse' 执行结果: 滚动成功: -100单位，位置: (1200, 500)
AI响应: [TOOL:click_mouse,814,829,left,1,0.1]
[TASK_COMPLETED]
工具 'click_mouse' 执行结果: 点击成功: (814.0, 829.0), 类型: left, 次数: 1.0
AI响应: [TOOL:click_mouse,814,829,left,1,0.1]
[TASK_COMPLETED]
工具 'click_mouse' 执行结果: 点击成功: (814.0, 829.0), 类型: left, 次数: 1.0
AI响应: [TOOL:click_mouse,814,829,left,1,0.1]
[TASK_COMPLETED]
工具 'click_mouse' 执行结果: 点击成功: (814.0, 829.0), 类型: left, 次数: 1.0
AI响应: [TOOL:click_mouse,814,829,left,1,0.1]
[TASK_COMPLETED]
工具 'click_mouse' 执行结果: 点击成功: (814.0, 829.0), 类型: left, 次数: 1.0
AI响应: [TOOL:click_mouse,814,829,left,1,0.1]
[TASK_COMPLETED]
工具 'click_mouse' 执行结果: 点击成功: (814.0, 829.0), 类型: left, 次数: 1.0
AI响应: [TOOL:click_mouse,814,829,left,1,0.1]
[TASK_COMPLETED]
工具 'click_mouse' 执行结果: 点击成功: (814.0, 829.0), 类型: left, 次数: 1.0
AI响应: [TOOL:click_mouse,814,829,left,1,0.1]
[TASK_COMPLETED]
工具 'click_mouse' 执行结果: 点击成功: (814.0, 829.0), 类型: left, 次数: 1.0
任务7执行完成
AI响应: 根据当前屏幕截图分析，任务7/10"上下滚动滚轮寻找下载模型按钮"已经完成。页面中已清晰显示"下载模型"按钮，位于右侧区域，按钮文字为"下载模型"，并且按钮下方还有相关提示信息。
接下来，我将使用OCR识别"下载模型"按钮的具体位置，以便后续点击操作。
[TOOL:ocr_detect,下载模型]
工具 'ocr_detect' 执行结果: {
"text": "下载模型",
"target_text": "下载模型",
"center_x": 1581,
"center_y": 902
}
任务8执行完成
AI响应: 根据当前屏幕截图分析，任务8/10"使用OCR识别下载模型按钮"已经完成。OCR已成功识别出"下载模型"按钮的位置，其坐标为 (1581, 902)。
接下来，我将按照任务要求点击"下载模型"按钮，以完成最终的下载操作。
[TOOL:click_mouse,1581,902,left,1,0.1]
工具 'click_mouse' 执行结果: 点击成功: (1581.0, 902.0), 类型: left, 次数: 1.0
任务9执行完成
AI响应: [TOOL:press_key,ctrl,j]
工具 'press_key' 执行结果: 按键成功: ctrl+j
任务10执行完成
工具 'press_key' 执行结果: 按下组合键成功: ctrl+j
python
import tkinter as tk
from tkinter import scrolledtext, messagebox, ttk
import os
import subprocess
import re
import json
import sys
from pathlib import Path
from llm_class import VLMService # 假设VLMService基于LLMService
import pyautogui
from PIL import Image
import base64
from io import BytesIO
# 定义全局变量
CURRENT_DIR = Path(__file__).parent
CONFIG_PATH = CURRENT_DIR /"config"/ "web_tools_config.json"
KNOWLEDGE_FILE_PATH = CURRENT_DIR /"config"/ "web_knowledge.txt"
OFTEN_USE_ORDER_PATH = CURRENT_DIR /"config"/ "web_often_use_order.txt"
WORKFLOW_PATH = CURRENT_DIR /"config"/ "web_workflow.txt" # 新增：工作流程文件路径
def execute_python_script(script_path, *args):
"""
执行指定路径的Python脚本
"""
# 获取项目根目录（从当前脚本位置向上一级）
current_dir = Path(__file__).parent.parent # 回到项目根目录
script_full_path = current_dir / script_path
if not script_full_path.exists():
return f"错误: 脚本 '{script_path}' 不存在"
if script_full_path.suffix != '.py':
return f"错误: 文件必须是Python脚本 (.py文件)"
try:
# 构建命令：工具名称作为脚本的第一个参数
cmd = [sys.executable, str(script_full_path)] + list(args)
# 执行Python脚本，指定编码为UTF-8
result = subprocess.run(
cmd,
capture_output=True,
text=True,
timeout=30,
cwd=str(current_dir),
encoding='utf-8', # 明确指定UTF-8编码
errors='replace' # 遇到编码错误时替换字符
)
if result.returncode == 0:
return result.stdout.strip()
else:
return f"脚本执行失败: {result.stderr.strip()}"
except subprocess.TimeoutExpired:
return f"脚本执行超时: {script_path}"
except Exception as e:
return f"执行脚本时出错: {str(e)}"
def list_available_tools():
"""
从配置文件中列出所有可用工具
"""
if not CONFIG_PATH.exists():
return []
try:
with open(CONFIG_PATH, 'r', encoding='utf-8') as f:
config = json.load(f)
return config.get('tools', [])
except Exception as e:
return []
def get_tool_by_name(tool_name):
"""
根据工具名称获取工具信息
"""
tools = list_available_tools()
for tool in tools:
if tool['name'] == tool_name:
return tool
return None
def execute_tool(tool_name, *args):
"""
执行指定名称的工具
"""
tool_info = get_tool_by_name(tool_name)
if not tool_info:
return f"错误: 未找到工具 '{tool_name}'"
script_path = tool_info['path']
result = execute_python_script(script_path, tool_name, *args)
return result
def get_available_tools_info():
"""
获取所有可用工具的信息
"""
if not CONFIG_PATH.exists():
return "错误: 工具配置文件不存在"
try:
with open(CONFIG_PATH, 'r', encoding='utf-8') as f:
config = json.load(f)
return config.get('tools', [])
except Exception as e:
return []
def get_tools_description():
"""获取工具描述，用于提供给VLM"""
tools = get_available_tools_info()
if not tools or isinstance(tools, str): # 检查是否返回错误
return "当前没有可用工具"
tools_desc = "可用工具列表:\n"
for tool in tools:
name = tool.get('name', '未知工具')
desc = tool.get('description', '无描述')
params = tool.get('parameters', [])
if params:
param_desc = ", ".join([f"{p['name']}({p['type']})" for p in params])
tools_desc += f"- {name}: {desc} (参数: {param_desc})\n"
else:
tools_desc += f"- {name}: {desc} (无参数)\n"
tools_desc += "\n使用格式: [TOOL:工具名称,参数1,参数2,...]\n"
return tools_desc
def image_to_base64(image_path):
"""将图像文件转换为base64编码"""
with open(image_path, "rb") as image_file:
return base64.b64encode(image_file.read()).decode('utf-8')
def is_task_completed(ai_response, should_check=True):
"""判断任务是否完成 - 使用特定结束标记，但可以控制是否检查"""
if not should_check or not ai_response:
return False
# 使用特定的结束标记，而不是通用关键词
completion_marker = "[TASK_COMPLETED]"
if completion_marker in ai_response:
return True
return False
def is_workflow_completed(ai_response):
"""判断工作流程是否完成 - 使用特殊标记"""
completion_marker = "[TOTAL_TASK_COMPLETED]"
if ai_response and completion_marker in ai_response:
return True
return False
def send_task_confirmation_to_ai(vlm_service, task_description, system_prompt, memory_file):
"""
向AI发送任务完成确认消息
"""
current_dir = os.path.dirname(os.path.abspath(__file__))
# 截取当前屏幕
screenshot = pyautogui.screenshot()
screenshot_path = os.path.join(current_dir, "current_screen.png")
screenshot.save(screenshot_path)
# 准备消息列表
messages = []
# 添加系统提示（只包含工具信息）
if system_prompt:
messages.append({
"role": "system",
"content": system_prompt
})
# 读取 memory 内容并加入到用户消息中 - 只包含工具执行结果和AI响应
memory_content = ""
if os.path.exists(memory_file):
with open(memory_file, 'r', encoding='utf-8') as f:
content = f.read().strip()
# 只保留工具执行结果和AI响应，过滤掉工作流程定义
lines = content.split('\n')
filtered_lines = []
for line in lines:
# 保留工具执行结果和AI响应，过滤掉工作流程定义和任务状态
if not (line.startswith("工作流程定义:") or
line.startswith("执行历史:") or
(line.startswith("任务") and " - " in line and ("待完成" in line or "已完成" in line or "待确定" in line))):
filtered_lines.append(line)
if filtered_lines:
memory_content = "历史执行记录:\n" + "\n".join(filtered_lines) + "\n"
# 构建确认消息
user_message = f"{memory_content}任务 '{task_description}' 已确认完成，请继续下一个任务或输出 [TOTAL_TASK_COMPLETED] 表示整个流程完成\n"
# 构建包含图像的消息内容
image_content = {
"type": "image_url",
"image_url": {
}
}
text_content = {
"type": "text",
"text": user_message
}
# 构建用户消息，包含文本和图像
messages.append({
"role": "user",
"content": [text_content, image_content]
})
try:
# 调用LLM服务（模拟VLM功能）
result = vlm_service.create_with_image(messages)
ai_response = result['choices'][0]['message']['content']
print(f"AI确认响应: {ai_response}")
# 将确认响应写入记忆文件
with open(memory_file, 'a', encoding='utf-8') as f:
f.write(f"AI确认响应: {ai_response}\n")
return ai_response
except Exception as e:
error_msg = f"发送确认消息时出错: {str(e)}"
print(error_msg)
return None
def vision_task_loop(task_description, knowledge_file=None, memory_file=None, workflow_state=None, reset_first_iteration=True):
"""
基于视觉的循环任务执行器 - 修改以支持任务完成后继续执行
"""
current_dir = os.path.dirname(os.path.abspath(__file__))
if knowledge_file is None:
knowledge_file = KNOWLEDGE_FILE_PATH # 使用全局变量
if memory_file is None:
memory_file = os.path.join(current_dir, "memory.txt")
# 创建LLM服务实例（模拟VLM）
vlm_service = VLMService()
# 读取固定知识
system_prompt_parts = []
# 添加可用工具信息到系统提示
tools_description = get_tools_description()
system_prompt_parts.append(f"可用工具信息:\n{tools_description}")
# 添加固定知识
if os.path.exists(knowledge_file):
with open(knowledge_file, 'r', encoding='utf-8') as f:
knowledge_content = f.read()
if knowledge_content.strip():
system_prompt_parts.append(f"重要知识:\n{knowledge_content}")
iteration_count = 0
max_iterations = 50 # 设置最大迭代次数，防止无限循环
first_iteration = reset_first_iteration # 使用参数来决定是否重置首次迭代标志
# 记录之前的AI响应，用于检测重复行为
previous_ai_response = ""
previous_tool_result = ""
while iteration_count < max_iterations:
iteration_count += 1
# 构建系统提示（只包含工具信息和固定知识）
system_prompt = "\n".join(system_prompt_parts)
# 截取当前屏幕
screenshot = pyautogui.screenshot()
screenshot_path = os.path.join(current_dir, "current_screen.png")
screenshot.save(screenshot_path)
# 准备消息列表
messages = []
# 添加系统提示（只包含工具信息）
if system_prompt:
messages.append({
"role": "system",
"content": system_prompt
})
# 读取 memory 内容并加入到用户消息中 - 只包含工具执行结果和AI响应
memory_content = ""
if os.path.exists(memory_file):
with open(memory_file, 'r', encoding='utf-8') as f:
content = f.read().strip()
# 只保留工具执行结果和AI响应，过滤掉工作流程定义
lines = content.split('\n')
filtered_lines = []
for line in lines:
# 保留工具执行结果和AI响应，过滤掉工作流程定义和任务状态
if not (line.startswith("工作流程定义:") or
line.startswith("执行历史:") or
(line.startswith("任务") and " - " in line and ("待完成" in line or "已完成" in line or "待确定" in line))):
filtered_lines.append(line)
if filtered_lines:
memory_content = "历史执行记录:\n" + "\n".join(filtered_lines) + "\n"
# 添加任务描述和当前截图信息
user_message = f"当前任务: {task_description}\n"
# 如果有 memory 内容，添加到用户消息中
if memory_content:
user_message += f"{memory_content}\n"
# 只在非第一轮迭代时检查之前的完成标记
if iteration_count > 1:
user_message += "请确认任务是否已完成，若完成请输出 [TASK_COMPLETED] 标记当前步骤完成\n"
# 这是询问环节，可以识别完成标记
is_inquiry_phase = True
else:
# 第一轮迭代，只需提示AI开始执行任务
user_message += "请分析当前屏幕截图，并开始执行任务。"
# 这是执行任务环节，不应识别完成标记
is_inquiry_phase = False
print(f"user_message: 【{user_message}】")
# 构建包含图像的消息内容
image_content = {
"type": "image_url",
"image_url": {
}
}
text_content = {
"type": "text",
"text": user_message
}
# 构建用户消息，包含文本和图像
messages.append({
"role": "user",
"content": [text_content, image_content]
})
try:
# 调用LLM服务（模拟VLM功能）
result = vlm_service.create_with_image(messages) # 不传递图像路径，因为已经在消息中包含
ai_response = result['choices'][0]['message']['content']
print(f"LLM服务返回: 【{ai_response}】")
# 先显示AI分析
yield f" {ai_response}"
# 执行AI返回的工具指令 - 在执行阶段不识别完成标记
tool_execution_result = process_tool_calls(ai_response, memory_file, workflow_state, is_inquiry_phase=False)
# 检查是否包含完成标记 - 重要修改：只在完成整个工作流程时退出
if is_workflow_completed(ai_response or "") and is_inquiry_phase:
yield "工作流程已完成，退出循环"
break # 只有在完成整个工作流程时才退出循环
# 检查是否任务完成 - 只在询问环节识别完成标记
if is_inquiry_phase and is_task_completed(ai_response) and not has_tool_calls(ai_response):
# 检查当前任务是否在workflow_state中已被标记为完成
task_completed_in_state = False
for step, completed in workflow_state:
if task_description in step and completed == True:
task_completed_in_state = True
break
if task_completed_in_state:
# 向AI发送任务完成确认消息
confirmation_response = send_task_confirmation_to_ai(
vlm_service,
task_description,
system_prompt,
memory_file
)
if confirmation_response:
yield f"向AI发送任务完成确认: {confirmation_response}"
yield "当前任务已完成，退出循环"
break
# 更新历史记录
previous_ai_response = ai_response
previous_tool_result = tool_execution_result or ""
# 更新标志，表示不再是第一次迭代
first_iteration = False
except Exception as e:
error_msg = f"执行任务时出错: {str(e)}"
yield error_msg
break
if iteration_count >= max_iterations:
yield "达到最大迭代次数，停止任务执行"
def has_tool_calls(response_text):
"""检查响应中是否包含工具调用"""
tool_pattern = r'\[TOOL:([^\],\]]+)(?:,([^\]]*))?\]'
matches = re.findall(tool_pattern, response_text)
return len(matches) > 0
def get_workflow_state_from_memory_in_app(memory_file_path):
"""从记忆文件中提取工作流程状态"""
saved_state = []
if os.path.exists(memory_file_path):
try:
with open(memory_file_path, 'r', encoding='utf-8') as f:
content = f.read()
lines = content.split('\n')
in_workflow_section = False
for line in lines:
line = line.strip()
if line == "工作流程定义:":
in_workflow_section = True
continue
elif line == "执行历史:":
in_workflow_section = False
continue
elif in_workflow_section and line.startswith("任务") and " - " in line:
# 解析格式如 "任务1: 打开模之屋 - 已完成"
try:
parts = line.split(" - ")
if len(parts) >= 2:
step_info = parts[0] # "任务1: 打开模之屋"
status = parts[1] # "已完成" 或 "待完成" 或 "待确定"
# 提取任务号
step_match = re.search(r'任务(\d+):', step_info)
if step_match:
step_num = int(step_match.group(1))
if status == "已完成":
completed = True
elif status == "待确定":
completed = "pending_verification"
else:
completed = False
# 确保列表长度足够
while len(saved_state) < step_num:
saved_state.append((None, False))
# 更新对应位置的完成状态
step_desc = step_info.split(":", 1)[1].strip()
saved_state[step_num - 1] = (step_desc, completed)
except Exception as e:
print(f"解析记忆中的任务行出错: {line}, 错误: {str(e)}")
continue
except Exception as e:
print(f"从记忆文件读取工作流程状态失败: {str(e)}")
return saved_state
def process_tool_calls(response_text, memory_file_path=None, workflow_state_ref=None, is_inquiry_phase=False):
"""
解析AI响应中的工具调用指令
支持格式: [TOOL:工具名称,arg1,arg2,arg3...]
"""
# 只在质询阶段检测任务完成标记，执行阶段不检测
task_completed = is_task_completed(response_text) if is_inquiry_phase else False
workflow_completed = is_workflow_completed(response_text) if is_inquiry_phase else False
if task_completed and memory_file_path and is_inquiry_phase:
with open(memory_file_path, 'a', encoding='utf-8') as f:
f.write(f"[TASK_COMPLETED]\n")
# 检测工作流程完成标记
if workflow_completed and memory_file_path and is_inquiry_phase:
with open(memory_file_path, 'a', encoding='utf-8') as f:
f.write(f"[TOTAL_TASK_COMPLETED]\n")
# 显示完成标记检测
if task_completed and is_inquiry_phase:
print("检测到任务完成标记: [TASK_COMPLETED]")
if workflow_completed and is_inquiry_phase:
print("检测到工作流程完成标记: [TOTAL_TASK_COMPLETED]")
# 修复正则表达式以正确捕获工具名称和所有参数
tool_pattern = r'\[TOOL:([^\],\]]+)(?:,([^\]]*))?\]'
matches = re.findall(tool_pattern, response_text)
all_results = []
if not matches:
# 只在响应中包含工具调用格式但未找到匹配时才输出，而不是所有情况
if '[TOOL:' in response_text:
print("未找到工具调用指令")
for match in matches:
tool_name = match[0]
tool_args_str = match[1] # 包含所有参数的字符串，可能为空
# 验证工具是否存在
tools = get_available_tools_info()
if not tools or isinstance(tools, str): # 检查是否返回错误
all_results.append(f"工具 '{tool_name}' 执行失败: 无法获取工具列表")
continue
tool_exists = any(tool['name'] == tool_name for tool in tools)
if not tool_exists:
all_results.append(f"工具 '{tool_name}' 执行失败: 工具不存在")
continue
# 解析参数，处理带引号的参数值（如果存在参数）
tool_args = []
if tool_args_str: # 如果有参数
current_arg = ""
inside_quotes = False
quote_char = None
i = 0
while i < len(tool_args_str):
char = tool_args_str[i]
if char in ['"', "'"] and not inside_quotes:
# 开始引号
inside_quotes = True
quote_char = char
elif char == quote_char and inside_quotes:
# 结束引号
inside_quotes = False
quote_char = None
elif char == ',' and not inside_quotes:
# 参数分隔符，不在引号内
tool_args.append(current_arg.strip())
current_arg = ""
else:
current_arg += char
i += 1
# 添加最后一个参数
if current_arg:
tool_args.append(current_arg.strip())
result = execute_tool(tool_name, *tool_args) if tool_args else execute_tool(tool_name)
# 处理执行结果为None的情况
if result is None:
result = "工具执行结果为空"
# 将工具执行结果写入记忆文件，这样AI可以看到
if memory_file_path:
try:
# 在工具执行结果中移除完成标记，避免在执行阶段被误识别
clean_result = result.replace("[TASK_COMPLETED]", "").replace("[TOTAL_TASK_COMPLETED]", "").strip()
with open(memory_file_path, 'a', encoding='utf-8') as f:
f.write(f"工具 '{tool_name}' 执行结果: {clean_result}\n")
except Exception as e:
print(f"写入记忆文件失败: {e}")
print(f"工具 '{tool_name}' 执行结果: {result}")
all_results.append(f"工具 '{tool_name}' 执行结果: {result}")
# 如果检测到任务完成标记，更新工作流程状态（只在质询阶段）
if task_completed and workflow_state_ref and is_inquiry_phase:
# 查找当前任务并更新其状态为已完成
for i, (step, completed) in enumerate(workflow_state_ref):
# 简单的匹配：如果响应文本中包含任务描述，则认为是当前任务
if step in response_text or response_text.strip().startswith(step[:min(len(step), 20)]):
workflow_state_ref[i] = (step, True)
break
# 返回工具执行结果和完成状态 - 注意这里只返回完成状态，不直接退出
return {
"results": "\n".join(all_results) if all_results else None,
"task_completed": task_completed,
"workflow_completed": workflow_completed
}
def parse_history_content(content):
"""
解析历史对话内容，转换为messages格式
"""
messages = []
lines = content.strip().split('\n')
current_role = None
current_content = []
for line in lines:
line = line.strip()
if line.startswith('用户:'):
if current_role and current_content:
messages.append({
"role": current_role,
"content": '\n'.join(current_content).strip()
})
current_role = "user"
current_content = [line[3:].strip()]
elif line.startswith('AI:'):
if current_role and current_content:
messages.append({
"role": current_role,
"content": '\n'.join(current_content).strip()
})
current_role = "assistant"
current_content = [line[3:].strip()]
elif line == "" and current_content:
if current_role and current_content:
messages.append({
"role": current_role,
"content": '\n'.join(current_content).strip()
})
current_role = None
current_content = []
elif current_role:
current_content.append(line)
if current_role and current_content:
messages.append({
"role": current_role,
"content": '\n'.join(current_content).strip()
})
return messages
class VLMTaskApp:
def __init__(self, root):
self.root = root
self.root.title("VLM任务执行器")
# 修改窗口大小 - 调整为更窄的尺寸
self.root.geometry("400x200")
self.root.attributes('-topmost', True) # 设置窗口置顶
# 任务执行标志
self.is_executing = False
self.workflow_state = [] # 工作流程状态
self.current_executing_step = -1 # 当前正在执行的步骤索引
self.current_page_index = 0 # 当前显示的页面索引
# 创建界面
self.setup_ui()
# 文件路径
current_dir = os.path.dirname(os.path.abspath(__file__))
self.knowledge_file = KNOWLEDGE_FILE_PATH # 使用全局变量
self.memory_file = os.path.join(current_dir, "memory.txt")
# 首先加载工作流程（从工作流文件和记忆文件获取状态）
self.load_workflow_content()
def setup_ui(self):
# 主容器
main_frame = tk.Frame(self.root)
main_frame.pack(fill=tk.BOTH, expand=True, padx=10, pady=10)
# 任务标题
self.title_label = tk.Label(
main_frame,
text="",
font=("Arial", 14, "bold"),
anchor="w"
)
self.title_label.pack(fill=tk.X, pady=(0, 5))
# 任务描述
self.desc_label = tk.Label(
main_frame,
text="",
font=("Arial", 11),
wraplength=350,
justify=tk.LEFT,
anchor="nw"
)
self.desc_label.pack(fill=tk.X, pady=(0, 10))
# 控制按钮区域 - 第一行：上一页、页码、下一页
control_frame1 = tk.Frame(self.root)
control_frame1.pack(fill=tk.X, padx=10, pady=5)
self.prev_button = tk.Button(
control_frame1,
text="上一页",
command=self.prev_page,
state=tk.DISABLED
)
self.prev_button.pack(side=tk.LEFT, padx=(0, 5))
self.page_label = tk.Label(
control_frame1,
text="第 0/0 页",
width=15
)
self.page_label.pack(side=tk.LEFT, padx=(0, 5))
self.next_button = tk.Button(
control_frame1,
text="下一页",
command=self.next_page,
state=tk.DISABLED
)
self.next_button.pack(side=tk.LEFT, padx=(0, 5))
# 控制按钮区域 - 第二行：执行所有任务、执行当前任务、停止、清除记忆
control_frame2 = tk.Frame(self.root)
control_frame2.pack(fill=tk.X, padx=10, pady=5)
self.run_all_button = tk.Button(
control_frame2,
text="执行所有任务",
command=self.run_all_tasks # 新增按钮：执行所有任务
)
self.run_all_button.pack(side=tk.LEFT, padx=(0, 5))
self.run_current_button = tk.Button(
control_frame2,
text="执行当前任务",
command=self.run_current_task
)
self.run_current_button.pack(side=tk.LEFT, padx=(0, 5))
self.stop_button = tk.Button(
control_frame2,
text="停止",
command=self.stop_all_tasks,
state=tk.DISABLED
)
self.stop_button.pack(side=tk.LEFT, padx=(0, 5))
self.clear_memory_button = tk.Button(
control_frame2,
text="清除记忆",
command=self.clear_short_term_memory
)
self.clear_memory_button.pack(side=tk.LEFT, padx=(0, 5))
# 任务状态标签
self.status_label = tk.Label(self.root, text="状态: 等待任务开始", bd=1, relief=tk.SUNKEN, anchor=tk.W)
self.status_label.pack(side=tk.BOTTOM, fill=tk.X)
def load_workflow_content(self):
"""加载并显示工作流程内容"""
# 首先尝试从记忆文件中获取步骤完成状态
saved_state = self.get_workflow_state_from_memory()
if WORKFLOW_PATH.exists():
try:
with open(WORKFLOW_PATH, 'r', encoding='utf-8') as f:
content = f.read()
# 分割工作流程为独立步骤
steps = [step.strip() for step in content.split('\n') if step.strip()]
# 初始化工作流程状态，优先使用记忆文件中的状态
self.workflow_state = []
for i, step in enumerate(steps):
completed = False
# 检查记忆文件中是否有该步骤的完成状态
if i < len(saved_state):
_, saved_completed = saved_state[i]
completed = saved_completed
self.workflow_state.append((step, completed))
# 更新页面导航
self.update_page_navigation()
# 显示第一页
if self.workflow_state:
self.update_task_display()
except Exception as e:
print(f"加载工作流程失败: {str(e)}")
else:
print(f"工作流程文件不存在: {WORKFLOW_PATH}")
def update_task_display(self):
"""更新当前任务显示"""
if not self.workflow_state or self.current_page_index >= len(self.workflow_state):
return
step, completed = self.workflow_state[self.current_page_index]
# 更新标题
if completed == True:
status_text = "已完成"
status_color = "green"
elif completed == "pending_verification":
status_text = "待确定"
status_color = "orange"
else:
status_text = "待完成"
status_color = "red"
self.title_label.config(
text=f"任务 {self.current_page_index + 1}/{len(self.workflow_state)} - {status_text}",
fg=status_color
)
# 更新描述
self.desc_label.config(text=step)
def update_page_navigation(self):
"""更新页面导航按钮状态"""
total_pages = len(self.workflow_state)
# 更新按钮状态
self.prev_button.config(state=tk.NORMAL if self.current_page_index > 0 else tk.DISABLED)
self.next_button.config(state=tk.NORMAL if self.current_page_index < total_pages - 1 else tk.DISABLED)
# 更新页面标签
self.page_label.config(text=f"第 {self.current_page_index + 1}/{total_pages} 页")
def update_page_label(self):
"""更新页面标签"""
total_pages = len(self.workflow_state)
self.page_label.config(text=f"第 {self.current_page_index + 1}/{total_pages} 页")
def prev_page(self):
"""上一页"""
if self.current_page_index > 0:
self.current_page_index -= 1
self.update_task_display()
self.update_page_navigation()
def next_page(self):
"""下一页"""
if self.current_page_index < len(self.workflow_state) - 1:
self.current_page_index += 1
self.update_task_display()
self.update_page_navigation()
def run_current_task(self):
"""执行当前任务"""
if self.is_executing:
messagebox.showwarning("警告", "任务正在执行中，请等待完成")
return
if not self.workflow_state:
messagebox.showwarning("警告", "没有可执行的任务")
return
current_task_index = self.current_page_index
if current_task_index >= len(self.workflow_state):
messagebox.showwarning("警告", "当前页码超出任务范围")
return
task_step, completed = self.workflow_state[current_task_index]
if completed == True:
messagebox.showinfo("提示", f"任务 {current_task_index + 1} 已完成，无需再次执行")
return
self.is_executing = True
self.run_current_button.config(state=tk.DISABLED)
self.run_all_button.config(state=tk.DISABLED)
self.stop_button.config(state=tk.NORMAL)
self.update_status(f"状态: 正在执行任务 {current_task_index + 1}: {task_step}")
# 在新线程中执行任务以避免界面冻结
import threading
task_thread = threading.Thread(
target=self.execute_single_task,
args=(current_task_index,)
)
task_thread.daemon = True
task_thread.start()
def run_all_tasks(self):
"""执行所有任务"""
if self.is_executing:
messagebox.showwarning("警告", "任务正在执行中，请等待完成")
return
if not self.workflow_state:
messagebox.showwarning("警告", "没有可执行的任务")
return
self.is_executing = True
self.run_current_button.config(state=tk.DISABLED)
self.run_all_button.config(state=tk.DISABLED)
self.stop_button.config(state=tk.NORMAL)
self.update_status("状态: 正在执行所有任务...")
# 在新线程中执行所有任务以避免界面冻结
import threading
task_thread = threading.Thread(
target=self.execute_all_tasks
)
task_thread.daemon = True
task_thread.start()
def execute_all_tasks(self):
"""执行所有任务，按顺序自动执行"""
try:
for task_index in range(len(self.workflow_state)):
# 检查是否停止了执行
if not self.is_executing:
print("系统: 任务已手动停止")
return
task_step, completed = self.workflow_state[task_index]
# 如果任务已完成，则跳过
if completed == True:
print(f"跳过已完成任务 {task_index + 1}: {task_step}")
continue
print(f"开始执行任务 {task_index + 1}: {task_step}")
# 切换到当前任务页面
self.root.after(0, lambda idx=task_index: self.set_current_page(idx))
# 执行任务
task_output = ""
completed_flag_found = False
# 使用for循环遍历vision_task_loop的输出
for output in vision_task_loop(
task_step,
self.knowledge_file,
self.memory_file,
self.workflow_state,
reset_first_iteration=True
):
if not self.is_executing:
print("系统: 任务已手动停止")
return
# 检查是否是工作流程完成标记 - 只在输出中直接检查，且确保不是工具执行结果中的标记
if "[TOTAL_TASK_COMPLETED]" in output and "[TOOL:" not in output:
print("工作流程已全部完成")
# 标记整个工作流程为完成
self.root.after(0, lambda idx=task_index: self.mark_step_as_completed_and_finish_workflow(idx))
completed_flag_found = True
break
elif "[TASK_COMPLETED]" in output and "[TOOL:" not in output: # 确保不是工具执行结果中的标记
# 如果是子任务完成标记，直接标记为已完成
# 直接标记为已完成，而不是待确定
self.root.after(0, lambda idx=task_index: self.mark_step_as_completed(idx))
completed_flag_found = True
# 跳出当前任务的内部循环，准备执行下一个任务
break
else:
print(f"任务{task_index + 1}执行结果: {output}")
# 将输出追加到记忆文件
with open(self.memory_file, 'a', encoding='utf-8') as f:
f.write(f"AI响应: {output}\n")
task_output += output + "\n"
# 如果遇到整个工作流程完成标记，直接退出
if "[TOTAL_TASK_COMPLETED]" in task_output:
print("工作流程已全部完成")
break
except Exception as e:
print(f"系统: 执行任务时出错: {str(e)}")
finally:
self.is_executing = False
self.root.after(0, lambda: self.run_current_button.config(state=tk.NORMAL))
self.root.after(0, lambda: self.run_all_button.config(state=tk.NORMAL))
self.root.after(0, lambda: self.stop_button.config(state=tk.DISABLED))
self.root.after(0, lambda: self.update_status("状态: 所有任务执行完成"))
def execute_single_task(self, task_index):
"""执行单个任务"""
try:
task_step, completed = self.workflow_state[task_index]
if completed == True:
print(f"任务 {task_index + 1} 已完成")
return
# 执行任务
task_output = ""
completed_flag_found = False
# 使用for循环遍历vision_task_loop的输出
for output in vision_task_loop(
task_step,
self.knowledge_file,
self.memory_file,
self.workflow_state,
reset_first_iteration=True
):
if not self.is_executing:
print("系统: 任务已手动停止")
return
# 检查是否是工作流程完成标记 - 只在输出中直接检查，且确保不是工具执行结果中的标记
if "[TOTAL_TASK_COMPLETED]" in output and "[TOOL:" not in output:
print("工作流程已全部完成")
# 标记整个工作流程为完成
self.root.after(0, lambda idx=task_index: self.mark_step_as_completed_and_finish_workflow(idx))
completed_flag_found = True
break
elif "[TASK_COMPLETED]" in output and "[TOOL:" not in output: # 确保不是工具执行结果中的标记
# 如果是子任务完成标记，直接标记为已完成
print(f"任务{task_index + 1}执行结果: {output}")
# 直接标记为已完成，而不是待确定
self.root.after(0, lambda idx=task_index: self.mark_step_as_completed(idx))
completed_flag_found = True
else:
print(f"任务{task_index + 1}执行结果: {output}")
# 将输出追加到记忆文件
with open(self.memory_file, 'a', encoding='utf-8') as f:
f.write(f"AI响应: {output}\n")
task_output += output + "\n"
# 检查是否完成整个工作流程
if "[TOTAL_TASK_COMPLETED]" in task_output:
print("工作流程已全部完成")
except Exception as e:
print(f"系统: 执行任务时出错: {str(e)}")
finally:
self.is_executing = False
self.root.after(0, lambda: self.run_current_button.config(state=tk.NORMAL))
self.root.after(0, lambda: self.run_all_button.config(state=tk.NORMAL))
self.root.after(0, lambda: self.stop_button.config(state=tk.DISABLED))
self.root.after(0, lambda: self.update_status("状态: 任务执行完成"))
def set_current_page(self, page_index):
"""设置当前页面索引并更新显示"""
self.current_page_index = page_index
self.update_task_display()
self.update_page_navigation()
def mark_step_as_completed_and_finish_workflow(self, index):
"""标记步骤为已完成并完成整个工作流程"""
if 0 <= index < len(self.workflow_state):
# 将任务状态改为已完成
self.workflow_state[index] = (self.workflow_state[index][0], True)
# 保存状态
self.save_workflow_state()
# 更新当前显示（如果当前页是完成的页）
if index == self.current_page_index:
self.update_task_display()
def mark_step_as_completed(self, index):
"""标记步骤为已完成"""
if 0 <= index < len(self.workflow_state):
# 将任务状态改为已完成
self.workflow_state[index] = (self.workflow_state[index][0], True)
# 保存状态
self.save_workflow_state()
# 更新当前显示（如果当前页是完成的页）
if index == self.current_page_index:
self.update_task_display()
# 在记忆文件中记录步骤执行完成
with open(self.memory_file, 'a', encoding='utf-8') as f:
f.write(f"任务{index+1}执行完成\n")
def mark_step_as_pending_verification(self, index):
"""标记步骤为待确定状态并自动翻页"""
if 0 <= index < len(self.workflow_state):
# 将任务状态改为待确定而不是已完成
self.workflow_state[index] = (self.workflow_state[index][0], "pending_verification")
# 保存状态
self.save_workflow_state()
# 更新当前显示（如果当前页是完成的页）
if index == self.current_page_index:
self.update_task_display()
# 在记忆文件中记录步骤执行完成，等待确认
with open(self.memory_file, 'a', encoding='utf-8') as f:
f.write(f"任务{index+1} 执行完成，等待确认: {self.workflow_state[index][0]}\n")
def confirm_task_completed(self, task_index):
"""确认任务真正完成"""
if 0 <= task_index < len(self.workflow_state):
task_desc, status = self.workflow_state[task_index]
if status == "pending_verification":
self.workflow_state[task_index] = (task_desc, True)
self.save_workflow_state()
# 更新显示（如果当前页是确认的页）
if task_index == self.current_page_index:
self.update_task_display()
# 在记忆文件中记录步骤确认完成
with open(self.memory_file, 'a', encoding='utf-8') as f:
f.write(f"任务{task_index+1} 确认完成: {task_desc}\n")
def stop_all_tasks(self):
"""停止所有任务执行"""
self.is_executing = False
self.run_current_button.config(state=tk.NORMAL)
self.run_all_button.config(state=tk.NORMAL)
self.stop_button.config(state=tk.DISABLED)
self.update_status("状态: 任务已停止")
def get_workflow_state_from_memory(self):
"""从记忆文件中提取工作流程状态"""
saved_state = []
if os.path.exists(self.memory_file):
try:
with open(self.memory_file, 'r', encoding='utf-8') as f:
content = f.read()
lines = content.split('\n')
in_workflow_section = False
for line in lines:
line = line.strip()
if line == "工作流程定义:":
in_workflow_section = True
continue
elif line == "执行历史:":
in_workflow_section = False
continue
elif in_workflow_section and line.startswith("任务") and " - " in line:
# 解析格式如 "任务1: 打开模之屋 - 已完成"
try:
parts = line.split(" - ")
if len(parts) >= 2:
step_info = parts[0] # "任务1: 打开模之屋"
status = parts[1] # "已完成" 或 "待完成" 或 "待确定"
# 提取任务号
step_match = re.search(r'任务(\d+):', step_info)
if step_match:
step_num = int(step_match.group(1))
if status == "已完成":
completed = True
elif status == "待确定":
completed = "pending_verification"
else:
completed = False
# 确保列表长度足够
while len(saved_state) < step_num:
saved_state.append((None, False))
# 更新对应位置的完成状态
step_desc = step_info.split(":", 1)[1].strip()
saved_state[step_num - 1] = (step_desc, completed)
except Exception as e:
print(f"解析记忆中的任务行出错: {line}, 错误: {str(e)}")
continue
except Exception as e:
print(f"从记忆文件读取工作流程状态失败: {str(e)}")
return saved_state
def update_status(self, status_text):
"""更新状态栏"""
self.status_label.config(text=status_text)
def clear_short_term_memory(self):
"""手动清除短期记忆"""
if os.path.exists(self.memory_file):
try:
# 保留工作流程定义，只清除执行历史
with open(WORKFLOW_PATH, 'r', encoding='utf-8') as f:
workflow_content = f.read()
# 重写memory文件，只保留工作流程定义
with open(self.memory_file, 'w', encoding='utf-8') as f:
f.write("工作流程定义:\n")
steps = [step.strip() for step in workflow_content.split('\n') if step.strip()]
for i, step in enumerate(steps):
f.write(f"任务{i+1}: {step} - 待完成\n")
f.write("\n执行历史:\n")
# 重置所有步骤为未完成
for i in range(len(self.workflow_state)):
self.workflow_state[i] = (self.workflow_state[i][0], False)
# 重置到第一页并更新显示
self.current_page_index = 0
self.update_task_display()
self.update_page_navigation()
print("短期记忆已手动清除，所有任务重置为未完成")
except Exception as e:
messagebox.showerror("错误", f"清除短期记忆失败: {str(e)}")
else:
print("短期记忆文件不存在")
def save_workflow_state(self):
"""保存工作流程状态到记忆文件"""
try:
# 读取当前memory文件内容
current_content = ""
if os.path.exists(self.memory_file):
with open(self.memory_file, 'r', encoding='utf-8') as f:
current_content = f.read()
# 分离工作流程定义和执行历史
lines = current_content.split('\n')
workflow_lines = []
history_lines = []
in_history = False
for line in lines:
if line == "执行历史:":
in_history = True
history_lines.append(line)
continue
elif line.startswith("工作流程定义:"):
workflow_lines.append(line)
continue
elif line.startswith("任务") and " - " in line and not in_history:
workflow_lines.append(line)
continue
elif in_history:
history_lines.append(line)
else:
workflow_lines.append(line)
# 更新工作流程状态
updated_workflow_lines = ["工作流程定义:"]
for i, (step, completed) in enumerate(self.workflow_state):
if completed == True:
status = "已完成"
elif completed == "pending_verification":
status = "待确定"
else:
status = "待完成"
updated_workflow_lines.append(f"任务{i+1}: {step} - {status}")
# 合并内容并写回文件
with open(self.memory_file, 'w', encoding='utf-8') as f:
f.write('\n'.join(updated_workflow_lines))
f.write('\n\n')
f.write('\n'.join(history_lines))
except Exception as e:
print(f"保存工作流程状态失败: {str(e)}")
def main():
root = tk.Tk()
app = VLMTaskApp(root)
root.mainloop()
if __name__ == "__main__":
main()
