说明
基于Tarojs+NutUI做移动签名时,发现原生Signature组件无法兼容UI的设计要求,事件无法自定义处理,同时又要兼容微信小程序和H5的展示。于是重新使用Canvas来生成签名。
代码示例
独立一个签名组件,实现基本的签名、重置、图片生成,需要使用的地方通过组件引用的方式使用。
签名组件代码如下:
javascript
<template>
<view class="canvas-signature" @catchtouchmove.stop.prevent>
<canvas
:canvas-id="canvasId"
:id="canvasId"
:width="canvasWidth"
:height="canvasHeight"
class="signature-canvas"
:style="{ width: displayWidth + 'px', height: displayHeight + 'px' }"
@touchstart.stop="handleTouchStart"
@touchmove.stop="handleTouchMove"
@touchend.stop="handleTouchEnd"
disable-scroll
@catchtouchmove.stop.prevent
></canvas>
</view>
</template>
<script setup lang="ts">
import { ref, onMounted, nextTick, computed, watch } from 'vue';
import Taro from '@tarojs/taro';
interface Props {
width?: number;
height?: number;
lineWidth?: number;
lineColor?: string;
}
const props = withDefaults(defineProps<Props>(), {
width: 0, // 0表示自适应
height: 0, // 0表示自适应
lineWidth: 2,
lineColor: '#000000',
});
const emit = defineEmits<{
confirm: [data: string];
clear: [];
}>();
const canvasId = ref(`signatureCanvas_${Date.now()}`);
const canvasWidth = ref(props.width || 750); // canvas实际绘制宽度(默认与展示一致)
const canvasHeight = ref(props.height || 344); // canvas实际绘制高度(默认与展示一致)
const displayWidth = ref(props.width || 750); // canvas显示宽度
const displayHeight = ref(props.height || 344); // canvas显示高度
const ctx = ref<any>(null);
const isDrawing = ref(false);
const lastPoint = ref<{ x: number; y: number } | null>(null);
const paths = ref<Array<Array<{ x: number; y: number }>>>([]); // 用于撤销功能
let drawTimer: any = null; // 用于节流draw调用
const normalizedLineWidth = computed(() => Math.max(1, props.lineWidth));
const hasStartedDrawing = ref(false); // 标记是否已经开始签名
// 初始化canvas
const initCanvas = () => {
nextTick(() => {
// 获取 canvas 尺寸(用 canvas 自身而不是外层容器,避免 padding 导致导出缩放/错位)
const query = Taro.createSelectorQuery();
query
.select(`#${canvasId.value}`)
.boundingClientRect((rect: any) => {
if (rect && rect.width > 0 && rect.height > 0) {
// 设置显示尺寸(单位为 px,保证 DOM 展示尺寸明确)
displayWidth.value = props.width && props.width > 0 ? props.width : rect.width;
displayHeight.value = props.height && props.height > 0 ? props.height : rect.height;
// 内部绘制尺寸与显示尺寸一致,避免实际绘图被缩放
canvasWidth.value = Math.max(1, Math.round(displayWidth.value));
canvasHeight.value = Math.max(1, Math.round(displayHeight.value));
// 更新canvas位置缓存
canvasRect = {
left: rect.left,
top: rect.top,
width: displayWidth.value,
height: displayHeight.value,
};
}
// 初始化canvas上下文
try {
ctx.value = Taro.createCanvasContext(canvasId.value);
if (ctx.value) {
// 先设置白色背景(这是画布的底色,不会被clearRect清除)
ctx.value.setFillStyle('#ffffff');
ctx.value.fillRect(0, 0, canvasWidth.value, canvasHeight.value);
// 设置绘制样式
ctx.value.setStrokeStyle(props.lineColor);
ctx.value.setLineWidth(normalizedLineWidth.value);
ctx.value.setLineCap('round');
ctx.value.setLineJoin('round');
ctx.value.setLineDash([]);
// 绘制提示文字
drawHintText();
ctx.value.draw(true);
console.log('Canvas初始化成功', {
width: canvasWidth.value,
height: canvasHeight.value,
displayWidth: displayWidth.value,
displayHeight: displayHeight.value,
});
}
} catch (error) {
console.error('Canvas初始化失败:', error);
}
})
.exec();
});
};
watch(
() => [props.width, props.height],
([width, height], [prevWidth, prevHeight]) => {
const shouldResize = (width && width > 0 && width !== prevWidth) || (height && height > 0 && height !== prevHeight);
if (!shouldResize) {
return;
}
if (width && width > 0) {
displayWidth.value = width;
canvasWidth.value = Math.max(1, Math.round(width));
}
if (height && height > 0) {
displayHeight.value = height;
canvasHeight.value = Math.max(1, Math.round(height));
}
nextTick(() => {
initCanvas();
});
},
);
// 缓存canvas的位置信息,避免频繁查询
let canvasRect: { left: number; top: number; width: number; height: number } | null = null;
// 绘制提示文字
const drawHintText = () => {
if (!ctx.value || hasStartedDrawing.value) return;
const text = '请在此处手写签名';
const fontSize = Math.min(canvasWidth.value / 15, 16); // 根据画布宽度自适应字体大小,最大20px
ctx.value.setFillStyle('#666666'); // 浅灰色提示文字
ctx.value.setFontSize(fontSize);
ctx.value.setTextAlign('center');
ctx.value.setTextBaseline('middle');
// 在画布中心绘制文字
const centerX = canvasWidth.value / 2;
const centerY = canvasHeight.value / 2;
ctx.value.fillText(text, centerX, centerY);
};
// 清除提示文字
const clearHintText = () => {
if (!ctx.value) return;
// 重新填充白色背景,清除提示文字
ctx.value.setFillStyle('#ffffff');
ctx.value.fillRect(0, 0, canvasWidth.value, canvasHeight.value);
// 重新设置绘制样式
ctx.value.setStrokeStyle(props.lineColor);
ctx.value.setLineWidth(normalizedLineWidth.value);
ctx.value.setLineCap('round');
ctx.value.setLineJoin('round');
};
// 说明:canvasRect 在 initCanvas 中已基于 canvas 节点一次性设置;如后续需要支持旋转/布局变化,可再加更新逻辑
// 获取触摸点坐标(同步版本,提高性能)
// 关键:weapp 真机下优先用 touches[0].x/y(通常已是 canvas 内坐标),并在缺失时使用 pageX/pageY - rect 兜底。
const getTouchPointSync = (e: any): { x: number; y: number } | null => {
const t = e.touches?.[0] || e.changedTouches?.[0];
// weapp:优先使用 x/y(很多机型/版本直接给 canvas 内坐标)
if (process.env.TARO_ENV === 'weapp') {
if (t && typeof t.x === 'number' && typeof t.y === 'number') {
// 若 x/y 看起来已经是 canvas 内坐标,则直接用
if (t.x >= 0 && t.y >= 0 && t.x <= canvasWidth.value && t.y <= canvasHeight.value) {
return {
x: Math.max(0, Math.min(canvasWidth.value, t.x)),
y: Math.max(0, Math.min(canvasHeight.value, t.y)),
};
}
return {
x: Math.max(0, Math.min(canvasWidth.value, t.x)),
y: Math.max(0, Math.min(canvasHeight.value, t.y)),
};
}
if (e.detail && typeof e.detail.x === 'number' && typeof e.detail.y === 'number') {
return {
x: Math.max(0, Math.min(canvasWidth.value, e.detail.x)),
y: Math.max(0, Math.min(canvasHeight.value, e.detail.y)),
};
}
// 兜底:用 pageX/pageY(或 clientX/clientY)减 rect(得到的是显示坐标 px)
if (canvasRect && canvasRect.width > 0 && canvasRect.height > 0 && t) {
const pageX = (t.pageX ?? t.clientX ?? 0) as number;
const pageY = (t.pageY ?? t.clientY ?? 0) as number;
const relativeX = pageX - canvasRect.left;
const relativeY = pageY - canvasRect.top;
return {
x: Math.max(0, Math.min(canvasWidth.value, relativeX)),
y: Math.max(0, Math.min(canvasHeight.value, relativeY)),
};
}
return null;
}
// H5:用 client 坐标 + rect 转换
const clientX = (t?.clientX ?? t?.x ?? 0) as number;
const clientY = (t?.clientY ?? t?.y ?? 0) as number;
if (canvasRect && canvasRect.width > 0 && canvasRect.height > 0) {
const relativeX = clientX - canvasRect.left;
const relativeY = clientY - canvasRect.top;
return {
x: Math.max(0, Math.min(canvasWidth.value, relativeX)),
y: Math.max(0, Math.min(canvasHeight.value, relativeY)),
};
}
return null;
};
// 获取触摸点坐标(异步版本,仅在必要时使用)
const getTouchPoint = (e: any): Promise<{ x: number; y: number }> => {
const syncPoint = getTouchPointSync(e);
if (syncPoint) {
return Promise.resolve(syncPoint);
}
// 如果没有缓存,查询并返回
let x = 0;
let y = 0;
if (e.detail && typeof e.detail.x === 'number' && typeof e.detail.y === 'number') {
x = e.detail.x;
y = e.detail.y;
} else {
const touch = e.touches?.[0] || e.changedTouches?.[0];
if (touch) {
x = touch.clientX || touch.x || 0;
y = touch.clientY || touch.y || 0;
}
}
return new Promise<{ x: number; y: number }>(resolve => {
const query = Taro.createSelectorQuery();
query
.select(`#${canvasId.value}`)
.boundingClientRect((rect: any) => {
if (rect && rect.width > 0 && rect.height > 0) {
canvasRect = {
left: rect.left,
top: rect.top,
width: rect.width,
height: rect.height,
};
const relativeX = x - rect.left;
const relativeY = y - rect.top;
const scaleX = canvasWidth.value / rect.width;
const scaleY = canvasHeight.value / rect.height;
resolve({
x: Math.max(0, Math.min(canvasWidth.value, relativeX * scaleX)),
y: Math.max(0, Math.min(canvasHeight.value, relativeY * scaleY)),
});
} else {
resolve({ x, y });
}
})
.exec();
});
};
// 触摸开始
const handleTouchStart = (e: any) => {
e.preventDefault();
isDrawing.value = true;
// 如果是第一次开始签名,清除提示文字
if (!hasStartedDrawing.value && ctx.value) {
clearHintText();
hasStartedDrawing.value = true;
ctx.value.draw(true);
}
// 优先使用同步方法获取坐标
const point = getTouchPointSync(e);
if (point) {
// 起笔在画布外:直接不开始绘制
if (point.x < 0 || point.y < 0 || point.x > canvasWidth.value || point.y > canvasHeight.value) {
isDrawing.value = false;
lastPoint.value = null;
return;
}
lastPoint.value = point;
// 开始新的路径
paths.value.push([point]);
if (ctx.value) {
// 画一个"起始点",保证轻微移动/单击也能看到笔迹
drawLine(point, point);
}
} else {
// 如果缓存不存在,异步获取
getTouchPoint(e).then(p => {
if (isDrawing.value && ctx.value) {
// 如果是第一次开始签名,清除提示文字
if (!hasStartedDrawing.value) {
clearHintText();
hasStartedDrawing.value = true;
ctx.value.draw(true);
}
lastPoint.value = p;
paths.value.push([p]);
ctx.value.beginPath();
ctx.value.moveTo(p.x, p.y);
}
});
}
};
// 计算两点之间的距离
const getDistance = (p1: { x: number; y: number }, p2: { x: number; y: number }) => {
const dx = p2.x - p1.x;
const dy = p2.y - p1.y;
return Math.sqrt(dx * dx + dy * dy);
};
// 触摸移动(优化版本,使用同步获取坐标和节流绘制)
const handleTouchMove = (e: any) => {
e.preventDefault();
if (!isDrawing.value || !lastPoint.value || !ctx.value) return;
// 使用同步方法获取坐标,避免异步延迟
const point = getTouchPointSync(e);
if (!point) {
// 如果缓存不存在,异步获取(这种情况应该很少)
getTouchPoint(e).then(p => {
if (isDrawing.value && lastPoint.value && ctx.value) {
drawLine(lastPoint.value, p);
lastPoint.value = p;
if (paths.value.length > 0) {
paths.value[paths.value.length - 1].push(p);
}
}
});
return;
}
// 手指滑出画布:停止本次会话(防止继续绘制/保存异常)
if (point.x < 0 || point.y < 0 || point.x > canvasWidth.value || point.y > canvasHeight.value) {
handleTouchEnd(e);
return;
}
// 绘制线条
if (lastPoint.value) {
drawLine(lastPoint.value, point);
}
// 更新当前路径
if (paths.value.length > 0) {
paths.value[paths.value.length - 1].push(point);
}
lastPoint.value = point;
};
// 绘制线条(优化版本,减少draw调用频率)
const drawLine = (from: { x: number; y: number }, to: { x: number; y: number }) => {
if (!ctx.value) return;
// 小程序 createCanvasContext:每次 draw() 后当前 path 会被清空
// 所以必须每次都 beginPath + moveTo,再 lineTo + stroke
ctx.value.beginPath();
ctx.value.moveTo(from.x, from.y);
const distance = getDistance(from, to);
// 轻微移动也要出线:只要 distance > 0 就 lineTo;插值阈值降低,提高跟手
if (distance > 1) {
const steps = Math.min(Math.ceil(distance / 2), 12); // 每2像素一个点,最多12步
for (let i = 1; i <= steps; i++) {
const ratio = i / steps;
const interpolatedX = from.x + (to.x - from.x) * ratio;
const interpolatedY = from.y + (to.y - from.y) * ratio;
ctx.value.lineTo(interpolatedX, interpolatedY);
}
} else {
ctx.value.lineTo(to.x, to.y);
}
ctx.value.stroke();
// 使用节流,减少 draw 调用频率(每 16ms 最多一次),但不"反复重置计时器"(否则手指一直动会延迟到最后才 draw)
if (drawTimer) return;
drawTimer = setTimeout(() => {
drawTimer = null;
if (ctx.value) ctx.value.draw(true);
}, 16);
};
// 触摸结束
const handleTouchEnd = (e: any) => {
e.preventDefault();
// 清除节流定时器
if (drawTimer) {
clearTimeout(drawTimer);
drawTimer = null;
}
// 确保最后一点也被绘制
if (isDrawing.value && ctx.value && lastPoint.value) {
ctx.value.draw(true);
}
isDrawing.value = false;
lastPoint.value = null;
};
// 清空画布(只清空绘制内容,保留白色背景)
const clear = () => {
if (ctx.value) {
// 重新填充白色背景(clearRect会清空所有内容,包括背景色)
ctx.value.setFillStyle('#ffffff');
ctx.value.fillRect(0, 0, canvasWidth.value, canvasHeight.value);
// 重新设置绘制样式
ctx.value.setStrokeStyle(props.lineColor);
ctx.value.setLineWidth(normalizedLineWidth.value);
ctx.value.setLineCap('round');
ctx.value.setLineJoin('round');
// 重置绘制状态,重新绘制提示文字
hasStartedDrawing.value = false;
drawHintText();
ctx.value.draw(true);
}
paths.value = [];
emit('clear');
};
// 撤销上一步
const undo = () => {
if (paths.value.length === 0) {
Taro.showToast({
title: '没有可撤销的操作',
icon: 'none',
});
return;
}
// 移除最后一条路径
paths.value.pop();
// 清空画布并重绘所有路径(保留白色背景)
if (ctx.value) {
// 先填充白色背景
ctx.value.setFillStyle('#ffffff');
ctx.value.fillRect(0, 0, canvasWidth.value, canvasHeight.value);
// 再清空绘制内容
ctx.value.clearRect(0, 0, canvasWidth.value, canvasHeight.value);
// 重新设置绘制样式
ctx.value.setStrokeStyle(props.lineColor);
ctx.value.setLineWidth(normalizedLineWidth.value);
ctx.value.setLineCap('round');
ctx.value.setLineJoin('round');
// 重绘所有路径
paths.value.forEach(path => {
if (path.length > 0) {
ctx.value.beginPath();
ctx.value.moveTo(path[0].x, path[0].y);
path.forEach(point => {
ctx.value.lineTo(point.x, point.y);
});
ctx.value.stroke();
}
});
// 如果撤销后没有路径了,重新显示提示文字
if (paths.value.length === 0) {
hasStartedDrawing.value = false;
drawHintText();
}
ctx.value.draw(true);
}
};
// 保存为图片(返回base64或临时文件路径)
const saveAsImage = async (format: 'base64' | 'tempFilePath' = 'base64'): Promise<string> => {
return new Promise((resolve, reject) => {
if (!ctx.value) {
reject(new Error('Canvas未初始化'));
return;
}
// 检查是否有绘制内容
if (paths.value.length === 0) {
// Taro.showToast({
// title: '请先绘制签名',
// icon: 'error',
// });
reject(new Error('没有绘制内容'));
return;
}
// 导出时保持导出尺寸与显示尺寸一致,避免放大/缩小
const exportDestWidth = canvasWidth.value;
const exportDestHeight = canvasHeight.value;
if (format === 'base64') {
// 使用 canvasToTempFilePath 然后读取为 base64
Taro.canvasToTempFilePath({
canvasId: canvasId.value,
x: 0,
y: 0,
width: canvasWidth.value,
height: canvasHeight.value,
destWidth: exportDestWidth,
destHeight: exportDestHeight,
fileType: 'png',
success: res => {
// 在小程序中,需要读取临时文件并转换为base64
if (process.env.TARO_ENV === 'weapp') {
try {
const fs = Taro.getFileSystemManager();
fs.readFile({
filePath: res.tempFilePath,
encoding: 'base64',
success: (fileRes: any) => {
resolve(base64);
},
fail: reject,
});
} catch (error) {
reject(error);
}
} else {
// H5环境,tempFilePath 通常已经是 base64
if (res.tempFilePath && res.tempFilePath.startsWith('data:')) {
resolve(res.tempFilePath);
} else {
// 兜底方案:如果不是 base64,尝试通过 selectorQuery 获取节点(注意:H5下可能需要特定处理)
const query = Taro.createSelectorQuery();
query
.select(`#${canvasId.value}`)
.node((nodeRes: any) => {
const canvas = nodeRes?.node;
if (canvas && canvas.toDataURL) {
const base64 = canvas.toDataURL('image/png');
resolve(base64);
} else {
// 再次兜底:尝试直接通过原生 DOM 获取(仅 H5)
const nativeCanvas = document.getElementById(canvasId.value) as HTMLCanvasElement;
if (nativeCanvas && nativeCanvas.toDataURL) {
resolve(nativeCanvas.toDataURL('image/png'));
} else {
reject(new Error('无法获取canvas节点'));
}
}
})
.exec();
}
}
},
fail: reject,
});
} else {
// 返回临时文件路径
Taro.canvasToTempFilePath({
canvasId: canvasId.value,
x: 0,
y: 0,
width: canvasWidth.value,
height: canvasHeight.value,
destWidth: exportDestWidth,
destHeight: exportDestHeight,
fileType: 'png',
success: res => {
resolve(res.tempFilePath);
},
fail: reject,
});
}
});
};
// 确认并返回图片数据
const confirm = async () => {
try {
const imageData = await saveAsImage('base64');
emit('confirm', imageData);
return imageData;
} catch (error) {
console.error('保存签名失败:', error);
// Taro.showToast({
// title: '保存失败',
// icon: 'error',
// });
throw error;
}
};
// 暴露方法给父组件
defineExpose({
clear,
undo,
saveAsImage,
confirm,
});
onMounted(() => {
initCanvas();
});
</script>
<style lang="scss" scoped>
.canvas-signature {
width: 100%;
height: 100%;
padding: 2px;
background: #fff;
border-radius: 0.6rem;
box-shadow: 0rem 0rem 0.25rem 0rem rgba(207, 207, 207, 0.5);
display: flex;
align-items: center;
justify-content: center;
overflow: hidden;
position: relative;
touch-action: none; // 阻止触摸默认行为
.signature-canvas {
width: 100%;
height: 100%;
touch-action: none; // 阻止触摸默认行为
border-radius: 0.6rem;
position: relative;
}
}
</style>
主页面示例:
javascript
<template>
<view class="signature_page bg" @catchtouchmove.stop.prevent>
<page-nav title="我的签名"></page-nav>
<view class="signature_content" @catchtouchmove.stop.prevent>
<view class="signature_canvas" id="signature_canvas_container" @catchtouchmove.stop.prevent>
<CanvasSignature
:width="canvasWidth"
:height="canvasHeight"
ref="signatureRef"
class="signImg"
></CanvasSignature>
</view>
<view class="signature_btns">
<nut-button type="primary" @click="handleClear" class="signature_btn" plain>重置</nut-button>
<nut-button type="info" @click="handleConfirm" class="signature_btn signature_save">确认</nut-button>
</view>
<image v-show="imageUrl" :src="imageUrl" class="signImg" />
</view>
</view>
</template>
<script setup lang="ts">
import { onMounted, ref } from 'vue';
import Taro from '@tarojs/taro';
import CanvasSignature from './CanvasSignature.vue';
const canvasHeight = ref(300);
const canvasWidth = ref(0);
// 获取签名组件实例
const signatureRef = ref<InstanceType<typeof CanvasSignature> | null>(null);
const imageUrl = ref('');
onMounted(() => {});
//手动触发重置按钮点击事件
const handleClear = () => {
if (signatureRef.value) {
signatureRef.value.clear();
}
};
//手动触发确认按钮点击事件
const handleConfirm = async () => {
if (!signatureRef.value) {
return;
}
try {
const base64Data = await signatureRef.value.confirm();
if (!base64Data) {
Taro.showToast({
title: '没有签名内容',
icon: 'error',
});
return;
}
imageUrl.value = base64Data;
console.log('签名数据:', base64Data);
} catch (error) {
console.error('确认签名失败:', error);
Taro.showToast({
title: '请先录入签名',
icon: 'error',
});
return;
}
};
</script>
<style lang="scss">
.signature_page {
height: 100vh;
height: 100%;
display: flex;
flex-direction: column;
overflow: hidden; // 防止页面滚动
position: fixed;
width: 100%;
top: 0;
left: 0;
touch-action: none; // 阻止触摸默认行为
.signature_content {
flex: 1;
margin: 24px 32px;
display: flex;
flex-direction: column;
min-height: 0; // 防止flex子元素溢出
overflow: hidden; // 防止内容区域滚动
touch-action: none; // 阻止触摸默认行为
.signature_canvas {
flex-shrink: 0;
height: 620px; // 减小高度
position: relative;
overflow: hidden; // 防止canvas区域滚动
touch-action: none; // 阻止触摸默认行为
.signImg {
padding: 2px;
width: 100%;
height: 100%;
background: #fff;
border-radius: 0.6rem;
box-shadow: 0rem 0rem 0.25rem 0rem rgba(207, 207, 207, 0.5);
}
}
}
.signature_btns {
flex-shrink: 0;
padding: 24px 32px 40px;
display: flex;
align-items: center;
justify-content: center;
gap: 24px;
.signature_btn {
width: 210px;
height: 88px;
font-size: 28px;
}
.signature_save {
view view {
color: #fff;
}
}
}
}
</style>
页面效果
