幽冥大陆(一百07)—门禁局域网http获取名单—东方仙盟练气期

获取名单列表

Url 地址:http://deviceAddress:port/getAllDeviceIdWhiteList

请求方式:post

发送消息的内容

|--------|----------|--------|
| 数据类型 | 字段名称 | 说明 |
| String | password | 设备用户密码 |

接受消息应答数据内容

|--------|---------|------------------------|
| 数据类型 | 字段名称 | 说明 |
| String | message | 提示消息 |
| int | result | 0 成功; 1,参数设置错误;2,密码错误; |
| Object | data | 消息体 |

消息体的内容

|------------|-----------|--------------|
| 数据类型 | 字段名称 | 说明 |
| String\[\] | idNumList | 表示人员的唯一编号的数组 |

示例

复制代码
url:http://192.168.1.135:8091/getAllDeviceIdWhiteList`

`发送:`
`{"password":"123456"}`

`返回:`
`{`
`"data":"{\n\t\"idList\":\n\t[\n\t\t\"3886\",\n\t\t\"3887\",\n\t\t\"3888\"}",`
`    "message" : "Get All Device   White List Success",`
`    "result" : 0`
`}`

`

获取名单详情

Url 地址:http://deviceAddress:port/getDeviceWhiteListDetailByIdNum

请求方式:post

发送消息的内容

|--------|----------|--------|
| 数据类型 | 字段名称 | 说明 |
| String | password | 设备用户密码 |
| Object | data | 消息体 |

消息体的内容

|--------|-----------------|-----------|
| 数据类型 | 字段名称 | 说明 |
| String | employee_number | 表示人员的唯一编号 |

接受消息应答数据内容

|--------|---------|------------------------|
| 数据类型 | 字段名称 | 说明 |
| String | message | 提示消息 |
| int | result | 0 成功; 1,参数设置错误;2,密码错误; |
| Object | data | 消息体 |

消息体的内容

|--------|-----------------|---------------------------------------------------------------|
| 数据类型 | 字段名称 | 说明 |
| String | usertype | user类型;white(白名单),black(黑名单) |
| String | name | 姓名 |
| String | sex | 男,女 |
| String | nation | 民族 |
| String | idno | 身份证号 |
| String | peoplestartdate | 名单有效期开始 |
| String | peopleenddate | 名单有效期结束 |
| String | idissue | 身份证签发机关 |
| String | idaddress | 身份证地址 |
| String | icno | ic卡号 20180716 |
| int | TimeGroupId | 0:任意时间识别成功都可同行 1:周一到周日指定时间段内识别成功才能通行,时间段外提示"无权限进入,请在指定时间段内识别" |
| String | register_base64 | 名单的base64字符串 |

示例

复制代码
url:http://192.168.1.135:8091/getDeviceWhiteListDetailByIdNum`

`发送:`
`{"password":"123456","data":{"employee_number":"5463"}}`

`返回:`
`{`
    `"data"` `:`
    `{`
        `"TimeGroupId"` `:` `0,`
        `"icno"` `:`   `"0020202469",`
        `"idaddress"` `:` `"",`
        `"idissue"` `:` `"",`
        `"idno"` `:` `"",`
        `"name"` `:` `"2573",`
        `"nation"` `:` `"",`
        `"peopleenddate"` `:`   `"2030-12-18 15:18:20",`
        `"peoplestartdate"` `:`   `"2020-12-18 15:18:20",`
        `"register_base64"` `:`   `"/9j/4AAQSkZ....",`
        `"sex"` `:` `"男",`
        `"usertype"` `:`   `"white"`
    `},`
    `"message"` `:` `"Get Device   White Detail By ID Number Success",`
    `"result"` `:` `0`
`}`
`
