FISCO BCOS 部署Solidity投票智能合约并基于Java SDK 调用智能合约详细指南

老蒋每日coding2026-01-27 15:22

目录

设计方案

一、环境准备

[1.1 安装FISCO BCOS节点](#1.1 安装FISCO BCOS节点)

[1.2 创建Java项目](#1.2 创建Java项目)

二、Solidity投票智能合约

[2.1 创建Voting.sol](#2.1 创建Voting.sol)

[2.2 编译合约](#2.2 编译合约)

[三、Java SDK配置与实现](#三、Java SDK配置与实现)

[3.1 配置文件](#3.1 配置文件)

[3.2 SDK配置类](#3.2 SDK配置类)

[3.3 合约服务类](#3.3 合约服务类)

[3.4 控制器类](#3.4 控制器类)

[3.5 主应用类](#3.5 主应用类)

四、部署与测试

[4.1 创建证书目录结构](#4.1 创建证书目录结构)

[4.2 编译和运行](#4.2 编译和运行)

[4.3 使用Postman测试API](#4.3 使用Postman测试API)

[1. 部署合约](#1. 部署合约)

[2. 授予投票权](#2. 授予投票权)

[3. 投票](#3. 投票)

[4. 查询获胜者](#4. 查询获胜者)

[5. 查询所有提案](#5. 查询所有提案)

五、高级功能扩展

[5.1 事件监听器](#5.1 事件监听器)

[5.2 数据库集成（可选）](#5.2 数据库集成（可选）)

六、注意事项

[6.1 安全性考虑](#6.1 安全性考虑)

[6.2 性能优化](#6.2 性能优化)

[6.3 错误处理](#6.3 错误处理)

设计方案

我们使用FISCO BCOS Java SDK来调用智能合约。以下是步骤：

  1. 1、环境准备：确保已经安装并启动了FISCO BCOS节点，并且已经生成了SDK所需的证书（ca.crt、sdk.crt、sdk.key）。

  2. 2、编写Solidity投票智能合约（同上）。

  3. 3、编译Solidity合约，获取abi和bin文件。

  4. 4、使用Java SDK进行合约部署和调用。

我们将使用一个简单的Java项目，基于Spring Boot框架，使用Java SDK与链交互。

下面为您提供完整的FISCO BCOS投票合约部署和Java SDK调用实现方案。

一、环境准备

1.1 安装FISCO BCOS节点

bash 复制代码
# 下载安装脚本
curl -LO https://github.com/FISCO-BCOS/FISCO-BCOS/releases/download/v3.4.0/build_chain.sh && chmod u+x build_chain.sh

# 构建单节点链
./build_chain.sh -l 127.0.0.1:4 -p 30300,20200,8545

# 启动节点
./nodes/127.0.0.1/start_all.sh

# 检查节点状态
./nodes/127.0.0.1/fisco-bcos -v

# 获取节点证书
cd nodes/127.0.0.1/
ls sdk/  # 查看ca.crt, sdk.crt, sdk.key等文件

1.2 创建Java项目

使用Maven创建项目：

XML 复制代码
<!-- pom.xml -->
<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0
         http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>

    <groupId>com.fisco.bcos</groupId>
    <artifactId>voting-demo</artifactId>
    <version>1.0.0</version>
    <packaging>jar</packaging>

    <properties>
        <maven.compiler.source>8</maven.compiler.source>
        <maven.compiler.target>8</maven.compiler.target>
        <java.version>1.8</java.version>
        <fisco-bcos-java-sdk.version>3.4.0</fisco-bcos-java-sdk.version>
        <spring-boot.version>2.7.0</spring-boot.version>
    </properties>

    <dependencies>
        <!-- FISCO BCOS Java SDK -->
        <dependency>
            <groupId>org.fisco-bcos.java-sdk</groupId>
            <artifactId>fisco-bcos-java-sdk</artifactId>
            <version>${fisco-bcos-java-sdk.version}</version>
        </dependency>

        <!-- Spring Boot Web -->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
            <version>${spring-boot.version}</version>
        </dependency>

        <!-- Lombok -->
        <dependency>
            <groupId>org.projectlombok</groupId>
            <artifactId>lombok</artifactId>
            <version>1.18.24</version>
            <scope>provided</scope>
        </dependency>

        <!-- JSON -->
        <dependency>
            <groupId>com.alibaba</groupId>
            <artifactId>fastjson</artifactId>
            <version>2.0.23</version>
        </dependency>
    </dependencies>

    <build>
        <plugins>
            <plugin>
                <groupId>org.springframework.boot</groupId>
                <artifactId>spring-boot-maven-plugin</artifactId>
                <version>${spring-boot.version}</version>
            </plugin>
        </plugins>
    </build>
</project>

二、Solidity投票智能合约

2.1 创建Voting.sol

javascript 复制代码
// SPDX-License-Identifier: MIT
pragma solidity ^0.8.0;

contract Voting {
    // 投票者信息
    struct Voter {
        uint weight;        // 投票权重
        bool voted;         // 是否已投票
        uint8 voteIndex;    // 投票提案索引
        address delegate;   // 委托投票地址
    }

    // 提案信息
    struct Proposal {
        bytes32 name;       // 提案名称（bytes32格式）
        uint voteCount;     // 得票数
    }

    // 状态变量
    address public chairperson;                 // 主持人地址
    mapping(address => Voter) public voters;    // 投票者映射
    Proposal[] public proposals;                // 提案列表

    // 事件定义
    event VoterRegistered(address indexed voter);
    event Voted(address indexed voter, uint indexed proposalIndex);
    event Delegated(address indexed from, address indexed to);
    event ProposalCreated(bytes32 indexed name);
    event VotingResult(uint winningProposalIndex, bytes32 winningProposalName);

    /**
     * @dev 构造函数，初始化提案
     * @param proposalNames 提案名称数组
     */
    constructor(bytes32[] memory proposalNames) {
        chairperson = msg.sender;

        // 主持人自动获得投票权
        voters[chairperson] = Voter({
            weight: 1,
            voted: false,
            voteIndex: 0,
            delegate: address(0)
        });

        // 创建提案
        for (uint i = 0; i < proposalNames.length; i++) {
            proposals.push(Proposal({
                name: proposalNames[i],
                voteCount: 0
            }));
            emit ProposalCreated(proposalNames[i]);
        }
    }

    /**
     * @dev 主持人授予投票权
     * @param voter 投票者地址
     */
    function giveRightToVote(address voter) public {
        require(msg.sender == chairperson, "Only chairperson can give voting rights");
        require(!voters[voter].voted, "The voter already voted");
        require(voters[voter].weight == 0, "Voter already has right");

        voters[voter].weight = 1;
        emit VoterRegistered(voter);
    }

    /**
     * @dev 批量授予投票权
     * @param votersArray 投票者地址数组
     */
    function giveRightToVoteBatch(address[] calldata votersArray) public {
        require(msg.sender == chairperson, "Only chairperson can give voting rights");

        for (uint i = 0; i < votersArray.length; i++) {
            address voter = votersArray[i];
            if (!voters[voter].voted && voters[voter].weight == 0) {
                voters[voter].weight = 1;
                emit VoterRegistered(voter);
            }
        }
    }

    /**
     * @dev 委托投票
     * @param to 被委托人地址
     */
    function delegate(address to) public {
        Voter storage sender = voters[msg.sender];
        require(!sender.voted, "You already voted");
        require(to != msg.sender, "Self-delegation is disallowed");
        require(voters[to].weight > 0, "Delegate has no voting right");

        // 查找最终委托地址
        while (voters[to].delegate != address(0)) {
            to = voters[to].delegate;
            require(to != msg.sender, "Found loop in delegation");
        }

        sender.voted = true;
        sender.delegate = to;

        Voter storage delegateTo = voters[to];
        if (delegateTo.voted) {
            // 被委托人已投票，增加对应提案的票数
            proposals[delegateTo.voteIndex].voteCount += sender.weight;
        } else {
            // 被委托人未投票，增加其权重
            delegateTo.weight += sender.weight;
        }

        emit Delegated(msg.sender, to);
    }

    /**
     * @dev 投票
     * @param proposalIndex 提案索引
     */
    function vote(uint8 proposalIndex) public {
        Voter storage sender = voters[msg.sender];
        require(sender.weight > 0, "Has no right to vote");
        require(!sender.voted, "Already voted");
        require(proposalIndex < proposals.length, "Invalid proposal index");

        sender.voted = true;
        sender.voteIndex = proposalIndex;

        // 计票
        proposals[proposalIndex].voteCount += sender.weight;

        emit Voted(msg.sender, proposalIndex);
    }

    /**
     * @dev 计算获胜提案
     * @return winningProposalIndex 获胜提案索引
     */
    function winningProposal() public view returns (uint winningProposalIndex) {
        uint winningVoteCount = 0;
        for (uint i = 0; i < proposals.length; i++) {
            if (proposals[i].voteCount > winningVoteCount) {
                winningVoteCount = proposals[i].voteCount;
                winningProposalIndex = i;
            }
        }
    }

    /**
     * @dev 获取获胜提案名称
     * @return winnerName 获胜提案名称
     */
    function winnerName() public view returns (bytes32 winnerName) {
        winnerName = proposals[winningProposal()].name;
    }

    /**
     * @dev 结束投票并公布结果
     */
    function endVoting() public returns (uint, bytes32) {
        require(msg.sender == chairperson, "Only chairperson can end voting");

        uint winningIndex = winningProposal();
        bytes32 winningName = proposals[winningIndex].name;

        emit VotingResult(winningIndex, winningName);
        return (winningIndex, winningName);
    }

    /**
     * @dev 获取提案数量
     * @return 提案数量
     */
    function getProposalsCount() public view returns (uint) {
        return proposals.length;
    }

    /**
     * @dev 获取提案详情
     * @param index 提案索引
     * @return name 提案名称
     * @return voteCount 得票数
     */
    function getProposal(uint index) public view returns (bytes32 name, uint voteCount) {
        require(index < proposals.length, "Invalid proposal index");
        Proposal memory proposal = proposals[index];
        return (proposal.name, proposal.voteCount);
    }

    /**
     * @dev 获取所有提案信息
     * @return names 提案名称数组
     * @return voteCounts 得票数数组
     */
    function getAllProposals() public view returns (bytes32[] memory names, uint[] memory voteCounts) {
        uint length = proposals.length;
        names = new bytes32[](length);
        voteCounts = new uint[](length);

        for (uint i = 0; i < length; i++) {
            names[i] = proposals[i].name;
            voteCounts[i] = proposals[i].voteCount;
        }
    }

    /**
     * @dev 获取投票者信息
     * @param voterAddress 投票者地址
     * @return weight 投票权重
     * @return voted 是否已投票
     * @return voteIndex 投票提案索引
     * @return delegate 委托地址
     */
    function getVoter(address voterAddress) public view returns (
        uint weight,
        bool voted,
        uint8 voteIndex,
        address delegate
    ) {
        Voter memory voter = voters[voterAddress];
        return (voter.weight, voter.voted, voter.voteIndex, voter.delegate);
    }
}

2.2 编译合约

bash 复制代码
# 安装solc编译器
npm install -g solc

# 编译合约
solcjs --bin --abi Voting.sol -o build/

# 生成Java wrapper
# 使用FISCO BCOS提供的sol2java.sh工具
./sol2java.sh org.fisco.bcos.voting build/Voting.sol

三、Java SDK配置与实现

3.1 配置文件

XML 复制代码
# src/main/resources/application.yml
spring:
  application:
    name: fisco-voting-demo

fisco:
  bcos:
    # 链配置
    chain-id: 1
    group-id: 1

    # 节点连接配置
    nodes:
      - 127.0.0.1:20200

    # 证书配置
    cert-path: classpath:conf/ca.crt
    private-key: classpath:conf/sdk.key
    cert-file: classpath:conf/sdk.crt

    # 账户配置
    account:
      key-file: classpath:conf/sdk.key
      password: ""

    # 合约配置
    contract:
      voting:
        address: ""  # 部署后更新
        abi: classpath:contracts/Voting.abi
        bin: classpath:contracts/Voting.bin

3.2 SDK配置类

java 复制代码
// src/main/java/com/fisco/bcos/config/FiscoConfig.java
package com.fisco.bcos.config;

import lombok.Data;
import org.fisco.bcos.sdk.v3.BcosSDK;
import org.fisco.bcos.sdk.v3.client.Client;
import org.fisco.bcos.sdk.v3.config.ConfigOption;
import org.fisco.bcos.sdk.v3.config.exceptions.ConfigException;
import org.fisco.bcos.sdk.v3.crypto.keypair.CryptoKeyPair;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.core.io.ClassPathResource;

import java.io.IOException;
import java.util.Arrays;
import java.util.List;

@Configuration
@Data
public class FiscoConfig {

    @Value("${fisco.bcos.chain-id}")
    private int chainId;

    @Value("${fisco.bcos.group-id}")
    private int groupId;

    @Value("${fisco.bcos.nodes}")
    private String[] nodes;

    @Value("${fisco.bcos.cert-path}")
    private String certPath;

    @Value("${fisco.bcos.cert-file}")
    private String certFile;

    @Value("${fisco.bcos.private-key}")
    private String privateKey;

    @Bean
    public ConfigOption configOption() throws IOException, ConfigException {
        // 读取证书文件
        ClassPathResource caResource = new ClassPathResource(certPath);
        ClassPathResource sslCertResource = new ClassPathResource(certFile);
        ClassPathResource sslKeyResource = new ClassPathResource(privateKey);

        // 构建配置选项
        org.fisco.bcos.sdk.v3.config.model.ConfigProperty configProperty =
            new org.fisco.bcos.sdk.v3.config.model.ConfigProperty();

        configProperty.setCryptoMaterial(
            new org.fisco.bcos.sdk.v3.config.model.CryptoMaterialConfig(
                caResource.getFile().getAbsolutePath(),
                sslCertResource.getFile().getAbsolutePath(),
                sslKeyResource.getFile().getAbsolutePath(),
                null,
                null
            )
        );

        configProperty.setNetwork(
            new org.fisco.bcos.sdk.v3.config.model.NetworkConfig(
                Arrays.asList(nodes)
            )
        );

        configProperty.setAmop(null);
        configProperty.setAccount(null);
        configProperty.setThreadPool(null);

        return new ConfigOption(configProperty, "config.toml");
    }

    @Bean
    public BcosSDK bcosSDK(ConfigOption configOption) {
        return new BcosSDK(configOption);
    }

    @Bean
    public Client client(BcosSDK bcosSDK) {
        return bcosSDK.getClient(groupId);
    }

    @Bean
    public CryptoKeyPair cryptoKeyPair(Client client) throws IOException {
        // 从文件加载私钥
        ClassPathResource keyResource = new ClassPathResource(privateKey);
        String privateKeyHex = org.apache.commons.io.FileUtils.readFileToString(
            keyResource.getFile(), "UTF-8"
        ).trim();

        // 创建密钥对
        return client.getCryptoSuite().createKeyPair(privateKeyHex);
    }
}

3.3 合约服务类

java 复制代码
// src/main/java/com/fisco/bcos/service/VotingService.java
package com.fisco.bcos.service;

import com.fisco.bcos.config.FiscoConfig;
import lombok.extern.slf4j.Slf4j;
import org.fisco.bcos.sdk.v3.client.Client;
import org.fisco.bcos.sdk.v3.codec.datatypes.generated.tuples.generated.Tuple4;
import org.fisco.bcos.sdk.v3.codec.datatypes.generated.tuples.generated.Tuple2;
import org.fisco.bcos.sdk.v3.contract.Contract;
import org.fisco.bcos.sdk.v3.crypto.keypair.CryptoKeyPair;
import org.fisco.bcos.sdk.v3.model.TransactionReceipt;
import org.fisco.bcos.sdk.v3.transaction.codec.decode.TransactionDecoderInterface;
import org.fisco.bcos.sdk.v3.transaction.codec.decode.TransactionDecoderService;
import org.fisco.bcos.sdk.v3.transaction.model.exception.ContractException;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.core.io.ClassPathResource;
import org.springframework.stereotype.Service;
import org.springframework.util.StreamUtils;

import javax.annotation.PostConstruct;
import java.io.IOException;
import java.math.BigInteger;
import java.nio.charset.StandardCharsets;
import java.util.*;

@Service
@Slf4j
public class VotingService {

    @Autowired
    private Client client;

    @Autowired
    private CryptoKeyPair cryptoKeyPair;

    @Autowired
    private FiscoConfig fiscoConfig;

    @Value("${fisco.bcos.contract.voting.abi}")
    private String abiPath;

    @Value("${fisco.bcos.contract.voting.bin}")
    private String binPath;

    @Value("${fisco.bcos.contract.voting.address}")
    private String contractAddress;

    private Voting votingContract;
    private String abiContent;
    private String binContent;
    private TransactionDecoderInterface txDecoder;

    @PostConstruct
    public void init() throws IOException {
        // 读取ABI和BIN文件
        ClassPathResource abiResource = new ClassPathResource(abiPath);
        ClassPathResource binResource = new ClassPathResource(binPath);

        abiContent = StreamUtils.copyToString(abiResource.getInputStream(), StandardCharsets.UTF_8);
        binContent = StreamUtils.copyToString(binResource.getInputStream(), StandardCharsets.UTF_8);

        txDecoder = new TransactionDecoderService(client.getCryptoSuite());

        // 如果合约地址已配置，则加载合约
        if (contractAddress != null && !contractAddress.isEmpty()) {
            loadContract(contractAddress);
        }
    }

    /**
     * 部署投票合约
     */
    public Map<String, Object> deployContract(List<String> proposalNames) throws ContractException, IOException {
        log.info("Deploying voting contract with proposals: {}", proposalNames);

        // 转换提案名称为bytes32
        List<byte[]> bytes32Proposals = new ArrayList<>();
        for (String name : proposalNames) {
            byte[] bytes32 = new byte[32];
            byte[] nameBytes = name.getBytes(StandardCharsets.UTF_8);
            System.arraycopy(nameBytes, 0, bytes32, 0, Math.min(nameBytes.length, 32));
            bytes32Proposals.add(bytes32);
        }

        // 部署合约
        votingContract = Voting.deploy(
            client,
            cryptoKeyPair,
            abiContent,
            binContent,
            bytes32Proposals
        );

        contractAddress = votingContract.getContractAddress();
        log.info("Contract deployed at address: {}", contractAddress);

        // 解析部署交易回执
        TransactionReceipt receipt = votingContract.getTransactionReceipt();

        Map<String, Object> result = new HashMap<>();
        result.put("contractAddress", contractAddress);
        result.put("transactionHash", receipt.getTransactionHash());
        result.put("status", receipt.getStatus());
        result.put("blockNumber", receipt.getBlockNumber());
        result.put("gasUsed", receipt.getGasUsed());
        result.put("proposals", proposalNames);

        return result;
    }

    /**
     * 加载已部署的合约
     */
    public void loadContract(String contractAddress) {
        log.info("Loading contract from address: {}", contractAddress);

        votingContract = Voting.load(
            contractAddress,
            abiContent,
            client,
            cryptoKeyPair
        );

        this.contractAddress = contractAddress;
        log.info("Contract loaded successfully");
    }

    /**
     * 授予投票权
     */
    public Map<String, Object> giveRightToVote(String voterAddress) throws ContractException {
        log.info("Giving voting right to: {}", voterAddress);

        TransactionReceipt receipt = votingContract.giveRightToVote(voterAddress);
        Map<String, Object> result = parseReceipt(receipt);

        log.info("Voting right granted to {}", voterAddress);
        return result;
    }

    /**
     * 批量授予投票权
     */
    public Map<String, Object> giveRightToVoteBatch(List<String> voterAddresses) throws ContractException {
        log.info("Batch giving voting rights to: {}", voterAddresses);

        TransactionReceipt receipt = votingContract.giveRightToVoteBatch(voterAddresses);
        Map<String, Object> result = parseReceipt(receipt);

        log.info("Batch voting rights granted successfully");
        return result;
    }

    /**
     * 投票
     */
    public Map<String, Object> vote(int proposalIndex) throws ContractException {
        log.info("Voting for proposal index: {}", proposalIndex);

        TransactionReceipt receipt = votingContract.vote(BigInteger.valueOf(proposalIndex));
        Map<String, Object> result = parseReceipt(receipt);

        // 解析投票事件
        List<Map<String, Object>> events = decodeEvents(receipt, "Voted");
        result.put("events", events);

        log.info("Vote cast for proposal {}", proposalIndex);
        return result;
    }

    /**
     * 委托投票
     */
    public Map<String, Object> delegate(String toAddress) throws ContractException {
        log.info("Delegating vote to: {}", toAddress);

        TransactionReceipt receipt = votingContract.delegate(toAddress);
        Map<String, Object> result = parseReceipt(receipt);

        // 解析委托事件
        List<Map<String, Object>> events = decodeEvents(receipt, "Delegated");
        result.put("events", events);

        log.info("Vote delegated to {}", toAddress);
        return result;
    }

    /**
     * 获取获胜提案
     */
    public Map<String, Object> getWinner() throws ContractException {
        log.info("Getting winning proposal");

        BigInteger winningIndex = votingContract.winningProposal();
        byte[] winningNameBytes = votingContract.winnerName();

        // 转换bytes32为字符串
        String winningName = new String(winningNameBytes, StandardCharsets.UTF_8).trim();

        Map<String, Object> result = new HashMap<>();
        result.put("winningIndex", winningIndex);
        result.put("winningName", winningName);

        log.info("Winning proposal: {} (index: {})", winningName, winningIndex);
        return result;
    }

    /**
     * 结束投票并公布结果
     */
    public Map<String, Object> endVoting() throws ContractException {
        log.info("Ending voting and announcing results");

        TransactionReceipt receipt = votingContract.endVoting();
        Map<String, Object> result = parseReceipt(receipt);

        // 解析投票结果事件
        List<Map<String, Object>> events = decodeEvents(receipt, "VotingResult");
        result.put("votingResult", events);

        log.info("Voting ended successfully");
        return result;
    }

    /**
     * 获取所有提案信息
     */
    public List<Map<String, Object>> getAllProposals() throws ContractException {
        log.info("Getting all proposals");

        BigInteger count = votingContract.getProposalsCount();
        List<Map<String, Object>> proposals = new ArrayList<>();

        for (int i = 0; i < count.intValue(); i++) {
            Tuple2<byte[], BigInteger> proposal = votingContract.getProposal(BigInteger.valueOf(i));

            Map<String, Object> proposalInfo = new HashMap<>();
            proposalInfo.put("index", i);
            proposalInfo.put("name", new String(proposal.getValue1(), StandardCharsets.UTF_8).trim());
            proposalInfo.put("voteCount", proposal.getValue2());

            proposals.add(proposalInfo);
        }

        log.info("Found {} proposals", proposals.size());
        return proposals;
    }

    /**
     * 获取提案数量
     */
    public int getProposalCount() throws ContractException {
        BigInteger count = votingContract.getProposalsCount();
        return count.intValue();
    }

    /**
     * 获取投票者信息
     */
    public Map<String, Object> getVoterInfo(String voterAddress) throws ContractException {
        log.info("Getting voter info for: {}", voterAddress);

        Tuple4<BigInteger, Boolean, BigInteger, String> voter = votingContract.getVoter(voterAddress);

        Map<String, Object> voterInfo = new HashMap<>();
        voterInfo.put("address", voterAddress);
        voterInfo.put("weight", voter.getValue1());
        voterInfo.put("voted", voter.getValue2());
        voterInfo.put("voteIndex", voter.getValue3());
        voterInfo.put("delegate", voter.getValue4());

        log.info("Voter info retrieved");
        return voterInfo;
    }

    /**
     * 获取合约地址
     */
    public String getContractAddress() {
        return contractAddress;
    }

    /**
     * 解析交易回执
     */
    private Map<String, Object> parseReceipt(TransactionReceipt receipt) {
        Map<String, Object> result = new HashMap<>();
        result.put("transactionHash", receipt.getTransactionHash());
        result.put("status", receipt.getStatus());
        result.put("blockNumber", receipt.getBlockNumber());
        result.put("gasUsed", receipt.getGasUsed());
        result.put("from", receipt.getFrom());
        result.put("to", receipt.getTo());
        result.put("output", receipt.getOutput());

        return result;
    }

    /**
     * 解码事件日志
     */
    private List<Map<String, Object>> decodeEvents(TransactionReceipt receipt, String eventName) {
        List<Map<String, Object>> events = new ArrayList<>();

        try {
            org.fisco.bcos.sdk.v3.codec.EventValues eventValues =
                txDecoder.decodeEvents(receipt.getLogEntries(), abiContent, eventName);

            if (eventValues != null && eventValues.getNonIndexedValues() != null) {
                for (int i = 0; i < eventValues.getNonIndexedValues().size(); i++) {
                    Map<String, Object> event = new HashMap<>();
                    event.put("name", eventName);
                    event.put("value", eventValues.getNonIndexedValues().get(i).getValue());
                    events.add(event);
                }
            }
        } catch (Exception e) {
            log.error("Failed to decode events: {}", e.getMessage());
        }

        return events;
    }
}

// 合约Java Wrapper类（通过sol2java.sh生成）
// 此处为简化版，实际应使用工具生成
class Voting extends Contract {
    public Voting(String contractAddress, String abi, Client client, CryptoKeyPair credential) {
        super(abi, contractAddress, client, credential);
    }

    public static Voting deploy(Client client, CryptoKeyPair credential, String abi, String binary, List<byte[]> proposalNames) {
        return deploy(Voting.class, client, credential, abi, binary, "", proposalNames);
    }

    public static Voting load(String contractAddress, String abi, Client client, CryptoKeyPair credential) {
        return new Voting(contractAddress, abi, client, credential);
    }

    public TransactionReceipt giveRightToVote(String voter) {
        return executeTransaction("giveRightToVote", voter);
    }

    public TransactionReceipt giveRightToVoteBatch(List<String> voters) {
        return executeTransaction("giveRightToVoteBatch", voters);
    }

    public TransactionReceipt vote(BigInteger proposalIndex) {
        return executeTransaction("vote", proposalIndex);
    }

    public TransactionReceipt delegate(String to) {
        return executeTransaction("delegate", to);
    }

    public BigInteger winningProposal() throws ContractException {
        return call("winningProposal");
    }

    public byte[] winnerName() throws ContractException {
        return call("winnerName");
    }

    public TransactionReceipt endVoting() {
        return executeTransaction("endVoting");
    }

    public BigInteger getProposalsCount() throws ContractException {
        return call("getProposalsCount");
    }

    public Tuple2<byte[], BigInteger> getProposal(BigInteger index) throws ContractException {
        return call("getProposal", index);
    }

    public Tuple4<BigInteger, Boolean, BigInteger, String> getVoter(String voterAddress) throws ContractException {
        return call("getVoter", voterAddress);
    }
}

3.4 控制器类

java 复制代码
// src/main/java/com/fisco/bcos/controller/VotingController.java
package com.fisco.bcos.controller;

import com.fisco.bcos.service.VotingService;
import lombok.extern.slf4j.Slf4j;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.web.bind.annotation.*;

import java.util.Arrays;
import java.util.HashMap;
import java.util.List;
import java.util.Map;

@RestController
@RequestMapping("/api/voting")
@Slf4j
public class VotingController {

    @Autowired
    private VotingService votingService;

    /**
     * 部署投票合约
     */
    @PostMapping("/deploy")
    public Map<String, Object> deployContract(@RequestBody Map<String, Object> request) {
        try {
            @SuppressWarnings("unchecked")
            List<String> proposals = (List<String>) request.get("proposals");

            if (proposals == null || proposals.isEmpty()) {
                proposals = Arrays.asList("Proposal A", "Proposal B", "Proposal C");
            }

            Map<String, Object> result = votingService.deployContract(proposals);
            result.put("success", true);
            result.put("message", "Contract deployed successfully");

            return result;
        } catch (Exception e) {
            log.error("Failed to deploy contract: {}", e.getMessage(), e);
            return createErrorResponse("Deploy failed: " + e.getMessage());
        }
    }

    /**
     * 加载合约
     */
    @PostMapping("/load")
    public Map<String, Object> loadContract(@RequestBody Map<String, Object> request) {
        try {
            String contractAddress = (String) request.get("contractAddress");
            votingService.loadContract(contractAddress);

            Map<String, Object> result = new HashMap<>();
            result.put("success", true);
            result.put("message", "Contract loaded successfully");
            result.put("contractAddress", contractAddress);

            return result;
        } catch (Exception e) {
            log.error("Failed to load contract: {}", e.getMessage(), e);
            return createErrorResponse("Load failed: " + e.getMessage());
        }
    }

    /**
     * 授予投票权
     */
    @PostMapping("/grant")
    public Map<String, Object> grantVotingRight(@RequestBody Map<String, Object> request) {
        try {
            String voterAddress = (String) request.get("voterAddress");

            Map<String, Object> result = votingService.giveRightToVote(voterAddress);
            result.put("success", true);
            result.put("message", "Voting right granted");

            return result;
        } catch (Exception e) {
            log.error("Failed to grant voting right: {}", e.getMessage(), e);
            return createErrorResponse("Grant failed: " + e.getMessage());
        }
    }

    /**
     * 批量授予投票权
     */
    @PostMapping("/grant/batch")
    public Map<String, Object> grantVotingRightBatch(@RequestBody Map<String, Object> request) {
        try {
            @SuppressWarnings("unchecked")
            List<String> voterAddresses = (List<String>) request.get("voterAddresses");

            Map<String, Object> result = votingService.giveRightToVoteBatch(voterAddresses);
            result.put("success", true);
            result.put("message", "Batch voting rights granted");

            return result;
        } catch (Exception e) {
            log.error("Failed to grant batch voting rights: {}", e.getMessage(), e);
            return createErrorResponse("Batch grant failed: " + e.getMessage());
        }
    }

    /**
     * 投票
     */
    @PostMapping("/vote")
    public Map<String, Object> vote(@RequestBody Map<String, Object> request) {
        try {
            Integer proposalIndex = (Integer) request.get("proposalIndex");

            Map<String, Object> result = votingService.vote(proposalIndex);
            result.put("success", true);
            result.put("message", "Vote cast successfully");

            return result;
        } catch (Exception e) {
            log.error("Failed to vote: {}", e.getMessage(), e);
            return createErrorResponse("Vote failed: " + e.getMessage());
        }
    }

    /**
     * 委托投票
     */
    @PostMapping("/delegate")
    public Map<String, Object> delegate(@RequestBody Map<String, Object> request) {
        try {
            String toAddress = (String) request.get("toAddress");

            Map<String, Object> result = votingService.delegate(toAddress);
            result.put("success", true);
            result.put("message", "Vote delegated successfully");

            return result;
        } catch (Exception e) {
            log.error("Failed to delegate: {}", e.getMessage(), e);
            return createErrorResponse("Delegate failed: " + e.getMessage());
        }
    }

    /**
     * 获取获胜提案
     */
    @GetMapping("/winner")
    public Map<String, Object> getWinner() {
        try {
            Map<String, Object> result = votingService.getWinner();
            result.put("success", true);
            result.put("message", "Winner retrieved successfully");

            return result;
        } catch (Exception e) {
            log.error("Failed to get winner: {}", e.getMessage(), e);
            return createErrorResponse("Get winner failed: " + e.getMessage());
        }
    }

    /**
     * 结束投票
     */
    @PostMapping("/end")
    public Map<String, Object> endVoting() {
        try {
            Map<String, Object> result = votingService.endVoting();
            result.put("success", true);
            result.put("message", "Voting ended successfully");

            return result;
        } catch (Exception e) {
            log.error("Failed to end voting: {}", e.getMessage(), e);
            return createErrorResponse("End voting failed: " + e.getMessage());
        }
    }

    /**
     * 获取所有提案
     */
    @GetMapping("/proposals")
    public Map<String, Object> getAllProposals() {
        try {
            List<Map<String, Object>> proposals = votingService.getAllProposals();

            Map<String, Object> result = new HashMap<>();
            result.put("success", true);
            result.put("message", "Proposals retrieved successfully");
            result.put("proposals", proposals);
            result.put("count", proposals.size());

            return result;
        } catch (Exception e) {
            log.error("Failed to get proposals: {}", e.getMessage(), e);
            return createErrorResponse("Get proposals failed: " + e.getMessage());
        }
    }

    /**
     * 获取投票者信息
     */
    @GetMapping("/voter/{address}")
    public Map<String, Object> getVoterInfo(@PathVariable String address) {
        try {
            Map<String, Object> voterInfo = votingService.getVoterInfo(address);

            Map<String, Object> result = new HashMap<>();
            result.put("success", true);
            result.put("message", "Voter info retrieved successfully");
            result.put("voter", voterInfo);

            return result;
        } catch (Exception e) {
            log.error("Failed to get voter info: {}", e.getMessage(), e);
            return createErrorResponse("Get voter info failed: " + e.getMessage());
        }
    }

    /**
     * 获取合约地址
     */
    @GetMapping("/address")
    public Map<String, Object> getContractAddress() {
        Map<String, Object> result = new HashMap<>();
        result.put("success", true);
        result.put("contractAddress", votingService.getContractAddress());

        return result;
    }

    /**
     * 健康检查
     */
    @GetMapping("/health")
    public Map<String, Object> healthCheck() {
        Map<String, Object> result = new HashMap<>();
        result.put("status", "UP");
        result.put("service", "FISCO BCOS Voting Service");
        result.put("timestamp", System.currentTimeMillis());

        return result;
    }

    private Map<String, Object> createErrorResponse(String message) {
        Map<String, Object> error = new HashMap<>();
        error.put("success", false);
        error.put("message", message);

        return error;
    }
}

3.5 主应用类

java 复制代码
// src/main/java/com/fisco/bcos/VotingApplication.java
package com.fisco.bcos;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.boot.context.properties.EnableConfigurationProperties;

@SpringBootApplication
@EnableConfigurationProperties
public class VotingApplication {
    public static void main(String[] args) {
        SpringApplication.run(VotingApplication.class, args);
    }
}

四、部署与测试

4.1 创建证书目录结构

XML 复制代码
src/main/resources/
├── conf/
│   ├── ca.crt
│   ├── sdk.crt
│   └── sdk.key
├── contracts/
│   ├── Voting.abi
│   └── Voting.bin
└── application.yml

4.2 编译和运行

bash 复制代码
# 编译项目
mvn clean package

# 运行应用
java -jar target/voting-demo-1.0.0.jar

# 或使用Maven运行
mvn spring-boot:run

4.3 使用Postman测试API

1. 部署合约
bash 复制代码
POST http://localhost:8080/api/voting/deploy
Content-Type: application/json

{
    "proposals": ["区块链升级", "社区治理", "技术改进"]
}
2. 授予投票权
bash 复制代码
POST http://localhost:8080/api/voting/grant
Content-Type: application/json

{
    "voterAddress": "0xYourVoterAddress"
}
3. 投票
bash 复制代码
POST http://localhost:8080/api/voting/vote
Content-Type: application/json

{
    "proposalIndex": 0
}
4. 查询获胜者
bash 复制代码
GET http://localhost:8080/api/voting/winner
5. 查询所有提案
bash 复制代码
GET http://localhost:8080/api/voting/proposals

五、高级功能扩展

5.1 事件监听器

java 复制代码
// src/main/java/com/fisco/bcos/listener/VotingEventListener.java
package com.fisco.bcos.listener;

import lombok.extern.slf4j.Slf4j;
import org.fisco.bcos.sdk.v3.BcosSDK;
import org.fisco.bcos.sdk.v3.client.Client;
import org.fisco.bcos.sdk.v3.codec.EventValues;
import org.fisco.bcos.sdk.v3.eventsub.EventCallback;
import org.fisco.bcos.sdk.v3.eventsub.EventSubParams;
import org.fisco.bcos.sdk.v3.model.EventLog;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Component;

import javax.annotation.PostConstruct;
import java.math.BigInteger;
import java.util.List;

@Component
@Slf4j
public class VotingEventListener {

    @Autowired
    private Client client;

    @Autowired
    private BcosSDK bcosSDK;

    private String contractAddress = "your_contract_address";

    @PostConstruct
    public void init() {
        subscribeToVotingEvents();
    }

    private void subscribeToVotingEvents() {
        try {
            // 订阅Voted事件
            EventSubParams votedEventParams = new EventSubParams();
            votedEventParams.setFromBlock(BigInteger.ZERO);
            votedEventParams.setToBlock(BigInteger.valueOf(-1)); // 最新块
            votedEventParams.setAddresses(Arrays.asList(contractAddress));
            votedEventParams.setTopics(Arrays.asList(
                client.getCryptoSuite().hash("Voted(address,uint256)")
            ));

            bcosSDK.getEventSubscribe().subscribeEvent(votedEventParams, new EventCallback() {
                @Override
                public void onReceiveLog(EventLog eventLog) {
                    log.info("Voted event received: {}", eventLog);
                    // 处理投票事件
                    processVotedEvent(eventLog);
                }
            });

            log.info("Subscribed to voting events");

        } catch (Exception e) {
            log.error("Failed to subscribe to events: {}", e.getMessage(), e);
        }
    }

    private void processVotedEvent(EventLog eventLog) {
        try {
            String voter = "0x" + eventLog.getTopics().get(1).substring(26);
            BigInteger proposalIndex = new BigInteger(eventLog.getTopics().get(2).substring(2), 16);

            log.info("Voter {} voted for proposal {}", voter, proposalIndex);

            // 可以在这里触发业务逻辑，如发送通知、更新数据库等

        } catch (Exception e) {
            log.error("Failed to process voted event: {}", e.getMessage());
        }
    }
}

5.2 数据库集成（可选）

java 复制代码
// 存储投票记录到数据库
@Service
public class VotingRecordService {

    @Autowired
    private JdbcTemplate jdbcTemplate;

    public void saveVotingRecord(String voter, int proposalIndex, String txHash) {
        String sql = "INSERT INTO voting_records (voter_address, proposal_index, transaction_hash, vote_time) " +
                    "VALUES (?, ?, ?, NOW())";

        jdbcTemplate.update(sql, voter, proposalIndex, txHash);
    }

    public List<Map<String, Object>> getVotingHistory(String voter) {
        String sql = "SELECT * FROM voting_records WHERE voter_address = ? ORDER BY vote_time DESC";
        return jdbcTemplate.queryForList(sql, voter);
    }
}

六、注意事项

6.1 安全性考虑

  1. 私钥管理：不要将私钥硬编码在代码中，使用环境变量或密钥管理服务

  2. 输入验证：所有API输入都应进行严格验证

  3. 权限控制：实现基于角色的访问控制

  4. 事务管理：确保操作的原子性和一致性

6.2 性能优化

  1. 连接池：配置合适的连接池大小

  2. 缓存：对频繁查询的数据使用缓存

  3. 批量操作：使用批量方法减少交易数量

  4. 异步处理：对耗时操作使用异步处理

6.3 错误处理

  1. 合约异常：正确处理ContractException

  2. 网络异常：实现重试机制

  3. 资源清理：确保正确释放资源

  4. 日志记录：记录详细的错误信息以便排查

这个完整的Java SDK实现方案提供了从环境搭建、合约部署到API调用的全流程。您可以根据实际需求进行调整和扩展。

相关推荐
木井巳2 小时前
【递归算法】计算布尔二叉树的值
java·算法·leetcode·深度优先
7λ2 小时前
java关于时间类
java·开发语言
java1234_小锋2 小时前
Spring里AutoWired与Resource区别？
java·后端·spring
风象南2 小时前
Spring Boot 定时任务多实例互斥执行
java·spring boot·后端
崎岖Qiu2 小时前
【深度剖析】：结合 Spring Bean 的生命周期理解 @PostConstruct 的原理
java·笔记·后端·spring·javaee
毕设源码-郭学长2 小时前
【开题答辩全过程】以 基于Springboot旅游景点管理系统的设计与实现为例，包含答辩的问题和答案
java·spring boot·后端
是三好2 小时前
JUC并发编程
java·开发语言
芬加达2 小时前
leetcode221 最大正方形
java·数据结构·算法
猿小羽2 小时前
深度实战：Spring AI 与 MCP（Model Context Protocol）构建下一代 AI Agent
java·大模型·llm·ai agent·spring ai·开发者工具·mcp
热门推荐
01GitHub 镜像站点02OpenCode 入门教程：介绍 · 安装 · 配置第三方 API (如 Claude)03Claude Code Skills 实用使用手册04struts2 XML外部实体注入漏洞复现（CVE-2025-68493）05Open Code教程（四）| 高级配置与集成06UV安装并设置国内源07Linux下V2Ray安装配置指南08AI 规范驱动开发“三剑客”深度对比：Spec-Kit、Kiro 与 OpenSpec 实战指南09在VSCode配置Java开发环境的保姆级教程（适配各类AI编程IDE）10Labelme从安装到标注：零基础完整指南
