🎯 系列导读：在前面的章节中，我们探讨了Agent的感知、记忆和规划模块。本篇将深入Agent的"手脚"------行动模块，了解Agent如何通过工具调用和具身执行与真实世界交互。
📑 目录
- [1. 引言：从思考到行动](#1. 引言：从思考到行动)
- [2. 行动模块概述](#2. 行动模块概述)
- [2.1 什么是行动模块](#2.1 什么是行动模块)
- [2.2 行动模块的核心能力](#2.2 行动模块的核心能力)
- [2.3 行动模块架构设计](#2.3 行动模块架构设计)
- [3. 工具使用：Toolformer 与工具增强学习](#3. 工具使用：Toolformer 与工具增强学习)
- [3.1 Toolformer 论文解读](#3.1 Toolformer 论文解读)
- [3.2 工具调用的技术实现](#3.2 工具调用的技术实现)
- [3.3 工具选择与编排策略](#3.3 工具选择与编排策略)
- [4. API 调用：连接数字世界](#4. API 调用：连接数字世界)
- [4.1 RESTful API 集成](#4.1 RESTful API 集成)
- [4.2 Function Calling 机制](#4.2 Function Calling 机制)
- [4.3 API 编排与错误处理](#4.3 API 编排与错误处理)
- [5. 代码执行：动态能力扩展](#5. 代码执行：动态能力扩展)
- [5.1 代码生成与执行流程](#5.1 代码生成与执行流程)
- [5.2 多语言运行时支持](#5.2 多语言运行时支持)
- [5.3 代码执行的挑战与解决方案](#5.3 代码执行的挑战与解决方案)
- [6. 安全沙箱：行动的边界](#6. 安全沙箱：行动的边界)
- [6.1 沙箱技术原理](#6.1 沙箱技术原理)
- [6.2 容器化隔离方案](#6.2 容器化隔离方案)
- [6.3 权限控制与审计](#6.3 权限控制与审计)
- [7. 具身智能：从数字到物理](#7. 具身智能：从数字到物理)
- [7.1 具身智能基础概念](#7.1 具身智能基础概念)
- [7.2 SayCan：语言模型遇见机器人](#7.2 SayCan：语言模型遇见机器人)
- [7.3 多模态感知与行动](#7.3 多模态感知与行动)
- [8. 实战：构建完整的行动模块](#8. 实战：构建完整的行动模块)
- [8.1 系统架构设计](#8.1 系统架构设计)
- [8.2 核心代码实现](#8.2 核心代码实现)
- [8.3 测试与优化](#8.3 测试与优化)
- [9. 前沿进展与未来展望](#9. 前沿进展与未来展望)
- [10. 总结](#10. 总结)
- 参考文献
1. 引言：从思考到行动
在人工智能的发展历程中，我们见证了语言模型从简单的文本生成演进到复杂的推理和规划。然而，一个真正智能的Agent不仅需要"思考"，更需要"行动"------将其认知转化为对世界的实际影响。
💡 思考：为什么说行动能力是Agent从"智能助手"跃迁为"智能代理"的关键？
🤔 解答：传统的语言模型就像一位博学的顾问，能够提供建议但无法执行。而具备行动能力的Agent则像一位称职的助理，不仅能理解需求、制定计划，还能亲自完成任务。这种从"说"到"做"的转变，正是Agent革命的核心所在。
让我们先看一个直观的对比：
传统 LLM 交互：
用户：帮我查询北京今天的天气
LLM：您可以访问weather.com查询，或者使用手机天气应用...
具备行动能力的 Agent：
用户：帮我查询北京今天的天气
Agent：[调用天气API] 北京今天晴，气温 -2°C 到 8°C，
空气质量良好，适合户外活动。这个简单的例子揭示了行动模块的本质价值：将语言理解转化为实际操作，将抽象意图转化为具体结果。
本文将系统性地探讨Agent行动模块的设计与实现，从工具使用的理论基础（Toolformer）到具身智能的前沿实践（SayCan），从API调用的工程细节到安全沙箱的防护机制，为读者呈现一幅完整的技术图景。
2. 行动模块概述
2.1 什么是行动模块
行动模块（Action Module）是Agent系统中负责执行具体操作的核心组件。如果将Agent比作人类，那么感知模块是"眼睛和耳朵"，记忆模块是"大脑的存储区"，规划模块是"前额叶皮层"，而行动模块就是"手脚"------将意图转化为行为的执行器。
┌─────────────────────────────────────────────────────────────────┐
│ Agent 系统架构 │
├─────────────────────────────────────────────────────────────────┤
│ │
│ ┌──────────┐ ┌──────────┐ ┌──────────┐ │
│ │ 感知模块 │───▶│ 规划模块 │───▶│ 行动模块 │ │
│ │ (Input) │ │(Planning)│ │ (Action) │ │
│ └──────────┘ └────┬─────┘ └────┬─────┘ │
│ │ │ │
│ ┌────▼────┐ │ │
│ │记忆模块 │◀─────────┘ │
│ │(Memory) │ │
│ └─────────┘ │
│ │
│ ┌─────────────────────────────────────────────────────┐ │
│ │ 行动模块详解 │ │
│ ├─────────────────────────────────────────────────────┤ │
│ │ ┌─────────┐ ┌─────────┐ ┌─────────┐ ┌────────┐ │ │
│ │ │工具调用 │ │API请求 │ │代码执行 │ │具身控制│ │ │
│ │ │ Tools │ │ APIs │ │ Code │ │Embodied│ │ │
│ │ └────┬────┘ └────┬────┘ └────┬────┘ └───┬────┘ │ │
│ │ │ │ │ │ │ │
│ │ └────────────┴─────┬──────┴───────────┘ │ │
│ │ │ │ │
│ │ ┌──────▼──────┐ │ │
│ │ │ 安全沙箱 │ │ │
│ │ │ (Sandbox) │ │ │
│ │ └─────────────┘ │ │
│ └─────────────────────────────────────────────────────┘ │
│ │
└─────────────────────────────────────────────────────────────────┘2.2 行动模块的核心能力
行动模块需要具备以下核心能力：
| 能力维度 | 描述 | 典型应用场景 |
|---|---|---|
| 工具调用 | 使用预定义的工具完成特定任务 | 计算器、搜索引擎、日历管理 |
| API交互 | 与外部服务进行数据交换 | 天气查询、地图导航、支付处理 |
| 代码执行 | 动态生成并运行代码 | 数据分析、图表生成、自动化脚本 |
| 具身控制 | 操控物理设备或机器人 | 智能家居、工业机器人、自动驾驶 |
| 多模态输出 | 生成图像、音频、视频等内容 | 图像生成、语音合成、视频编辑 |
💡 思考：这些能力之间是否存在层次关系？
🤔 解答：确实存在。我们可以将这些能力按照抽象程度分为三个层次：
抽象层次金字塔
/\
/ \
/ 具身 \ Layer 3: 物理世界交互
/ 控制 \ 需要感知-决策-执行闭环
/──────────\
/ \
/ 代码执行 \ Layer 2: 动态能力扩展
/ (Sandbox) \ 需要运行时环境支持
/──────────────────\
/ \
/ 工具调用 & API \ Layer 1: 基础能力层
/ (Predefined) \ 需要接口定义和权限
/──────────────────────────\2.3 行动模块架构设计
一个生产级的行动模块需要考虑以下架构要素：
┌─────────────────────────────────────────────────────────────────────┐
│ 行动模块架构详图 │
├─────────────────────────────────────────────────────────────────────┤
│ │
│ ┌─────────────┐ │
│ │ 规划模块 │ │
│ │ (Planner) │ │
│ └──────┬──────┘ │
│ │ Action Request │
│ ▼ │
│ ┌──────────────────────────────────────────────────────────────┐ │
│ │ 行动解析器 (Action Parser) │ │
│ │ ┌──────────────────────────────────────────────────────────┐│ │
│ │ │ Input: "search_web(query='AI agents')" ││ │
│ │ │ Output: {action: 'search_web', params: {query: '...'}} ││ │
│ │ └──────────────────────────────────────────────────────────┘│ │
│ └──────────────────────────┬───────────────────────────────────┘ │
│ │ │
│ ┌───────────────────┼───────────────────┐ │
│ ▼ ▼ ▼ │
│ ┌─────────────┐ ┌─────────────┐ ┌─────────────┐ │
│ │ 工具路由器 │ │ API网关 │ │ 代码执行器 │ │
│ │ Tool Router │ │ API Gateway │ │Code Executor│ │
│ └──────┬──────┘ └──────┬──────┘ └──────┬──────┘ │
│ │ │ │ │
│ ▼ ▼ ▼ │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ 安全沙箱层 (Security Sandbox) │ │
│ │ ┌─────────┐ ┌─────────┐ ┌─────────┐ ┌─────────┐ │ │
│ │ │权限检查 │──│资源隔离 │──│执行监控 │──│审计日志 │ │ │
│ │ └─────────┘ └─────────┘ └─────────┘ └─────────┘ │ │
│ └──────────────────────────┬──────────────────────────────────┘ │
│ │ │
│ ┌───────────────────┼───────────────────┐ │
│ ▼ ▼ ▼ │
│ ┌─────────────┐ ┌─────────────┐ ┌─────────────┐ │
│ │ 本地工具集 │ │ 外部API │ │ 运行时环境 │ │
│ │Local Tools │ │External APIs│ │ Runtime │ │
│ └─────────────┘ └─────────────┘ └─────────────┘ │
│ │
│ ┌──────────────────────────────────────────────────────────────┐ │
│ │ 结果聚合器 (Result Aggregator) │ │
│ │ • 结果格式化 • 错误处理 • 重试机制 • 结果缓存 │ │
│ └──────────────────────────────────────────────────────────────┘ │
│ │
└─────────────────────────────────────────────────────────────────────┘下面是行动模块的核心接口定义：
python
from abc import ABC, abstractmethod
from typing import Any, Dict, List, Optional
from dataclasses import dataclass
from enum import Enum
class ActionType(Enum):
"""行动类型枚举"""
TOOL_CALL = "tool_call"
API_REQUEST = "api_request"
CODE_EXECUTION = "code_execution"
EMBODIED_ACTION = "embodied_action"
@dataclass
class ActionRequest:
"""行动请求数据结构"""
action_type: ActionType
action_name: str
parameters: Dict[str, Any]
context: Optional[Dict[str, Any]] = None
timeout: float = 30.0
retry_count: int = 3
@dataclass
class ActionResult:
"""行动结果数据结构"""
success: bool
data: Any
error: Optional[str] = None
execution_time: float = 0.0
metadata: Optional[Dict[str, Any]] = None
class ActionExecutor(ABC):
"""行动执行器抽象基类"""
@abstractmethod
async def execute(self, request: ActionRequest) -> ActionResult:
"""执行行动"""
pass
@abstractmethod
def validate(self, request: ActionRequest) -> bool:
"""验证行动请求"""
pass
@abstractmethod
def get_capabilities(self) -> List[str]:
"""获取支持的能力列表"""
pass
class ActionModule:
"""行动模块主类"""
def __init__(self):
self.executors: Dict[ActionType, ActionExecutor] = {}
self.sandbox = SecuritySandbox()
self.logger = ActionLogger()
def register_executor(self, action_type: ActionType,
executor: ActionExecutor):
"""注册行动执行器"""
self.executors[action_type] = executor
async def execute_action(self, request: ActionRequest) -> ActionResult:
"""执行行动的主入口"""
# 1. 安全检查
if not self.sandbox.check_permission(request):
return ActionResult(
success=False,
data=None,
error="Permission denied"
)
# 2. 获取执行器
executor = self.executors.get(request.action_type)
if not executor:
return ActionResult(
success=False,
data=None,
error=f"No executor for {request.action_type}"
)
# 3. 验证请求
if not executor.validate(request):
return ActionResult(
success=False,
data=None,
error="Invalid request"
)
# 4. 在沙箱中执行
result = await self.sandbox.run(
executor.execute,
request
)
# 5. 记录日志
self.logger.log(request, result)
return result3. 工具使用：Toolformer 与工具增强学习
3.1 Toolformer 论文解读
2023年，Meta AI发布的Toolformer论文开创了语言模型自主学习使用工具的新范式。这篇工作的核心贡献在于：让语言模型自己学会何时以及如何调用外部工具，而无需大量人工标注数据。
💡 思考：为什么Toolformer如此重要？传统的工具调用方式有什么局限？
🤔 解答：传统方法通常依赖于：
- 硬编码规则：if "天气" in query then call weather_api() --- 缺乏泛化能力
- 监督学习：需要大量人工标注的工具调用数据 --- 成本高昂
- 强化学习：需要精心设计的奖励函数 --- 调试困难
Toolformer的创新之处在于利用语言模型自身的能力来生成训练数据，实现了自我监督的工具学习。
Toolformer 核心思想：
┌─────────────────────────────────────────────────────────────────────┐
│ Toolformer 训练流程 │
├─────────────────────────────────────────────────────────────────────┤
│ │
│ Step 1: 采样 API 调用 │
│ ┌────────────────────────────────────────────────────────────────┐ │
│ │ 输入: "The Eiffel Tower is located in [MASK] and was built in" │ │
│ │ │ │
│ │ LM生成候选调用: │ │
│ │ • [QA("Where is Eiffel Tower")] → Paris │ │
│ │ • [Calculator(1889-0)] → 1889 │ │
│ │ • [Search("Eiffel Tower location")] → Paris, France │ │
│ └────────────────────────────────────────────────────────────────┘ │
│ │ │
│ ▼ │
│ Step 2: 执行 API 并获取结果 │
│ ┌────────────────────────────────────────────────────────────────┐ │
│ │ [QA("Where is Eiffel Tower")] → "Paris" │ │
│ │ [Calculator(1889-0)] → "1889" │ │
│ │ [Search("Eiffel Tower")] → "Paris, France, 1887-1889" │ │
│ └────────────────────────────────────────────────────────────────┘ │
│ │ │
│ ▼ │
│ Step 3: 过滤有用的 API 调用 │
│ ┌────────────────────────────────────────────────────────────────┐ │
│ │ 评估标准: L(with API result) < L(without API) - threshold │ │
│ │ │ │
│ │ 如果API调用降低了模型的困惑度(perplexity)，则保留该调用 │ │
│ │ │ │
│ │ 保留: [Search("Eiffel Tower")] ✓ │ │
│ │ 丢弃: [Calculator(1889-0)] ✗ (对预测下文帮助不大) │ │
│ └────────────────────────────────────────────────────────────────┘ │
│ │ │
│ ▼ │
│ Step 4: 微调模型 │
│ ┌────────────────────────────────────────────────────────────────┐ │
│ │ 原始文本: │ │
│ │ "The Eiffel Tower is located in Paris and was built..." │ │
│ │ │ │
│ │ 增强文本: │ │
│ │ "The Eiffel Tower is located in [Search("Eiffel Tower")] │ │
│ │ →Paris, France] Paris and was built..." │ │
│ │ │ │
│ │ 使用增强文本微调LM，使其学会在适当位置插入API调用 │ │
│ └────────────────────────────────────────────────────────────────┘ │
│ │
└─────────────────────────────────────────────────────────────────────┘Toolformer 的数学形式化：
设 x = ( x 1 , . . . , x n ) x = (x_1, ..., x_n) x=(x1,...,xn) 为输入序列， c = ( a i , r i ) c = (a_i, r_i) c=(ai,ri) 为位置 i i i 的API调用及其结果。定义：
L i + ( c ) = − ∑ j = i n log p ( x j ∣ x 1 : i − 1 , c , x i : j − 1 ) L_i^+(c) = -\sum_{j=i}^{n} \log p(x_j | x_{1:i-1}, c, x_{i:j-1}) Li+(c)=−j=i∑nlogp(xj∣x1:i−1,c,xi:j−1)
L i − = − ∑ j = i n log p ( x j ∣ x 1 : j − 1 ) L_i^- = -\sum_{j=i}^{n} \log p(x_j | x_{1:j-1}) Li−=−j=i∑nlogp(xj∣x1:j−1)
过滤条件：当 L i − − L i + ( c ) ≥ τ L_i^- - L_i^+(c) \geq \tau Li−−Li+(c)≥τ 时，保留该API调用。
python
import torch
from transformers import AutoModelForCausalLM, AutoTokenizer
from typing import List, Tuple, Callable
import re
class ToolformerTrainer:
"""Toolformer 训练器简化实现"""
def __init__(self, model_name: str, tools: dict):
self.tokenizer = AutoTokenizer.from_pretrained(model_name)
self.model = AutoModelForCausalLM.from_pretrained(model_name)
self.tools = tools # {tool_name: callable}
self.threshold = 0.5 # 过滤阈值
def sample_api_calls(self, text: str,
position: int) -> List[Tuple[str, str]]:
"""
在指定位置采样可能的API调用
返回: [(api_call_string, result), ...]
"""
candidates = []
# 构建提示，让模型生成可能的API调用
prompt = f"""Given the text: "{text[:position]}"
What API call would be helpful here?
Available APIs: {list(self.tools.keys())}
Generate API call:"""
inputs = self.tokenizer(prompt, return_tensors="pt")
# 生成多个候选
outputs = self.model.generate(
**inputs,
num_return_sequences=5,
max_new_tokens=50,
do_sample=True,
temperature=0.7
)
for output in outputs:
api_call = self.tokenizer.decode(output, skip_special_tokens=True)
# 解析并执行API调用
result = self._execute_api_call(api_call)
if result:
candidates.append((api_call, result))
return candidates
def _execute_api_call(self, api_call: str) -> str:
"""解析并执行API调用"""
# 简化的解析逻辑
match = re.match(r'(\w+)\((.*)\)', api_call)
if match:
tool_name, args = match.groups()
if tool_name in self.tools:
try:
return str(self.tools[tool_name](args))
except Exception as e:
return None
return None
def compute_loss_with_api(self, text: str, position: int,
api_call: str, result: str) -> float:
"""计算带API调用的损失"""
# 插入API调用和结果
augmented_text = (
text[:position] +
f" [{api_call}→{result}] " +
text[position:]
)
inputs = self.tokenizer(augmented_text, return_tensors="pt")
with torch.no_grad():
outputs = self.model(**inputs, labels=inputs["input_ids"])
return outputs.loss.item()
def compute_loss_without_api(self, text: str) -> float:
"""计算不带API调用的损失"""
inputs = self.tokenizer(text, return_tensors="pt")
with torch.no_grad():
outputs = self.model(**inputs, labels=inputs["input_ids"])
return outputs.loss.item()
def filter_useful_apis(self, text: str,
candidates: List[Tuple[int, str, str]]) -> List:
"""
过滤有用的API调用
candidates: [(position, api_call, result), ...]
"""
useful_apis = []
base_loss = self.compute_loss_without_api(text)
for position, api_call, result in candidates:
loss_with_api = self.compute_loss_with_api(
text, position, api_call, result
)
# 如果带API的损失显著降低，保留该调用
if base_loss - loss_with_api >= self.threshold:
useful_apis.append({
'position': position,
'api_call': api_call,
'result': result,
'loss_reduction': base_loss - loss_with_api
})
return useful_apis
def create_training_example(self, text: str,
useful_apis: List[dict]) -> str:
"""创建训练样本"""
# 按位置排序，从后往前插入以保持位置正确
sorted_apis = sorted(useful_apis,
key=lambda x: x['position'],
reverse=True)
augmented = text
for api in sorted_apis:
pos = api['position']
insertion = f" [{api['api_call']}→{api['result']}] "
augmented = augmented[:pos] + insertion + augmented[pos:]
return augmented
# 使用示例
def calculator(expr: str) -> float:
"""简单计算器工具"""
try:
return eval(expr) # 生产环境需要安全的表达式求值
except:
return None
def search(query: str) -> str:
"""模拟搜索工具"""
# 实际应调用搜索API
mock_results = {
"Eiffel Tower": "Paris, France, completed in 1889",
"population of Tokyo": "13.96 million (2021)",
}
return mock_results.get(query, "No results found")
# 初始化训练器
tools = {
"Calculator": calculator,
"Search": search
}
trainer = ToolformerTrainer("gpt2", tools)3.2 工具调用的技术实现
在实际的Agent系统中，工具调用需要一套完整的技术栈来支撑：
┌─────────────────────────────────────────────────────────────────────┐
│ 工具调用技术栈 │
├─────────────────────────────────────────────────────────────────────┤
│ │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ 工具注册中心 (Tool Registry) │ │
│ │ ┌─────────────────────────────────────────────────────────┐│ │
│ │ │ { ││ │
│ │ │ "calculator": { ││ │
│ │ │ "description": "执行数学计算", ││ │
│ │ │ "parameters": { ││ │
│ │ │ "expression": {"type": "string", "required": true} ││ │
│ │ │ }, ││ │
│ │ │ "returns": "number", ││ │
│ │ │ "examples": ["calculator('2+2')", ...] ││ │
│ │ │ }, ││ │
│ │ │ "web_search": {...}, ││ │
│ │ │ "send_email": {...} ││ │
│ │ │ } ││ │
│ │ └─────────────────────────────────────────────────────────┘│ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │ │
│ ▼ │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ 工具选择器 (Tool Selector) │ │
│ │ │ │
│ │ 输入: 用户意图 + 工具描述 │ │
│ │ 输出: 最匹配的工具及参数 │ │
│ │ │ │
│ │ 策略: │ │
│ │ • 语义匹配: 基于embedding的相似度计算 │ │
│ │ • Few-shot: 基于示例的上下文学习 │ │
│ │ • Fine-tuned: 微调的工具选择模型 │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │ │
│ ▼ │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ 参数提取器 (Parameter Extractor) │ │
│ │ │ │
│ │ 从自然语言中提取工具所需的参数 │ │
│ │ │ │
│ │ 示例: │ │
│ │ "帮我搜索最近的AI新闻" → │ │
│ │ {tool: "web_search", params: {query: "最近的AI新闻"}} │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │ │
│ ▼ │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ 工具执行器 (Tool Executor) │ │
│ │ │ │
│ │ ┌──────────┐ ┌──────────┐ ┌──────────┐ │ │
│ │ │参数验证 │───▶│权限检查 │───▶│安全执行 │ │ │
│ │ └──────────┘ └──────────┘ └──────────┘ │ │
│ │ │ │ │
│ │ ┌────────┴────────┐ │ │
│ │ ▼ ▼ │ │
│ │ ┌──────────┐ ┌──────────┐ │ │
│ │ │ 成功结果 │ │ 错误处理 │ │ │
│ │ └──────────┘ └──────────┘ │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │
└─────────────────────────────────────────────────────────────────────┘以下是一个完整的工具系统实现：
python
from dataclasses import dataclass, field
from typing import Any, Callable, Dict, List, Optional, Union
import json
import asyncio
from pydantic import BaseModel, validator
import numpy as np
# ============== 工具定义 ==============
@dataclass
class ToolParameter:
"""工具参数定义"""
name: str
type: str # string, number, boolean, array, object
description: str
required: bool = True
default: Any = None
enum: Optional[List[Any]] = None
@dataclass
class Tool:
"""工具定义"""
name: str
description: str
parameters: List[ToolParameter]
function: Callable
returns: str = "any"
examples: List[str] = field(default_factory=list)
category: str = "general"
requires_confirmation: bool = False
def to_schema(self) -> dict:
"""转换为JSON Schema格式（兼容OpenAI Function Calling）"""
properties = {}
required = []
for param in self.parameters:
properties[param.name] = {
"type": param.type,
"description": param.description
}
if param.enum:
properties[param.name]["enum"] = param.enum
if param.required:
required.append(param.name)
return {
"name": self.name,
"description": self.description,
"parameters": {
"type": "object",
"properties": properties,
"required": required
}
}
# ============== 工具注册中心 ==============
class ToolRegistry:
"""工具注册中心"""
def __init__(self):
self._tools: Dict[str, Tool] = {}
self._categories: Dict[str, List[str]] = {}
def register(self, tool: Tool):
"""注册工具"""
self._tools[tool.name] = tool
if tool.category not in self._categories:
self._categories[tool.category] = []
self._categories[tool.category].append(tool.name)
def get(self, name: str) -> Optional[Tool]:
"""获取工具"""
return self._tools.get(name)
def list_all(self) -> List[Tool]:
"""列出所有工具"""
return list(self._tools.values())
def list_by_category(self, category: str) -> List[Tool]:
"""按类别列出工具"""
tool_names = self._categories.get(category, [])
return [self._tools[name] for name in tool_names]
def get_schemas(self) -> List[dict]:
"""获取所有工具的Schema"""
return [tool.to_schema() for tool in self._tools.values()]
def search(self, query: str, top_k: int = 5) -> List[Tool]:
"""
搜索相关工具
实际应用中可使用embedding进行语义搜索
"""
# 简化实现：基于关键词匹配
scores = []
query_lower = query.lower()
for tool in self._tools.values():
score = 0
# 名称匹配
if query_lower in tool.name.lower():
score += 10
# 描述匹配
for word in query_lower.split():
if word in tool.description.lower():
score += 1
scores.append((tool, score))
# 按分数排序
scores.sort(key=lambda x: x[1], reverse=True)
return [tool for tool, score in scores[:top_k] if score > 0]
# ============== 工具执行器 ==============
class ToolExecutionError(Exception):
"""工具执行错误"""
pass
class ToolExecutor:
"""工具执行器"""
def __init__(self, registry: ToolRegistry):
self.registry = registry
self.execution_history: List[dict] = []
def validate_parameters(self, tool: Tool,
params: Dict[str, Any]) -> bool:
"""验证参数"""
for param_def in tool.parameters:
if param_def.required and param_def.name not in params:
raise ToolExecutionError(
f"Missing required parameter: {param_def.name}"
)
if param_def.name in params:
value = params[param_def.name]
# 类型检查（简化版）
type_map = {
'string': str,
'number': (int, float),
'boolean': bool,
'array': list,
'object': dict
}
expected_type = type_map.get(param_def.type)
if expected_type and not isinstance(value, expected_type):
raise ToolExecutionError(
f"Parameter {param_def.name} should be {param_def.type}"
)
# 枚举检查
if param_def.enum and value not in param_def.enum:
raise ToolExecutionError(
f"Parameter {param_def.name} must be one of {param_def.enum}"
)
return True
async def execute(self, tool_name: str,
params: Dict[str, Any]) -> Any:
"""执行工具"""
tool = self.registry.get(tool_name)
if not tool:
raise ToolExecutionError(f"Tool not found: {tool_name}")
# 参数验证
self.validate_parameters(tool, params)
# 填充默认值
for param_def in tool.parameters:
if param_def.name not in params and param_def.default is not None:
params[param_def.name] = param_def.default
# 执行
try:
if asyncio.iscoroutinefunction(tool.function):
result = await tool.function(**params)
else:
result = tool.function(**params)
# 记录历史
self.execution_history.append({
'tool': tool_name,
'params': params,
'result': result,
'success': True
})
return result
except Exception as e:
self.execution_history.append({
'tool': tool_name,
'params': params,
'error': str(e),
'success': False
})
raise ToolExecutionError(f"Execution failed: {str(e)}")
# ============== 示例工具定义 ==============
def create_calculator_tool() -> Tool:
"""创建计算器工具"""
def calculate(expression: str) -> float:
# 安全的数学表达式求值
import ast
import operator
operators = {
ast.Add: operator.add,
ast.Sub: operator.sub,
ast.Mult: operator.mul,
ast.Div: operator.truediv,
ast.Pow: operator.pow,
ast.USub: operator.neg,
}
def eval_expr(node):
if isinstance(node, ast.Num):
return node.n
elif isinstance(node, ast.BinOp):
return operators[type(node.op)](
eval_expr(node.left),
eval_expr(node.right)
)
elif isinstance(node, ast.UnaryOp):
return operators[type(node.op)](eval_expr(node.operand))
else:
raise TypeError(f"Unsupported type: {type(node)}")
tree = ast.parse(expression, mode='eval')
return eval_expr(tree.body)
return Tool(
name="calculator",
description="执行数学计算，支持加减乘除和幂运算",
parameters=[
ToolParameter(
name="expression",
type="string",
description="数学表达式，如 '2 + 3 * 4'"
)
],
function=calculate,
returns="number",
examples=["calculator('2 + 2')", "calculator('3.14 * 10 ** 2')"],
category="math"
)
def create_web_search_tool() -> Tool:
"""创建网页搜索工具"""
async def web_search(query: str, num_results: int = 5) -> List[dict]:
# 模拟搜索结果
# 实际应调用搜索API（如Google、Bing等）
return [
{
"title": f"Search result {i} for: {query}",
"url": f"https://example.com/result{i}",
"snippet": f"This is a snippet about {query}..."
}
for i in range(num_results)
]
return Tool(
name="web_search",
description="搜索互联网获取相关信息",
parameters=[
ToolParameter(
name="query",
type="string",
description="搜索关键词"
),
ToolParameter(
name="num_results",
type="number",
description="返回结果数量",
required=False,
default=5
)
],
function=web_search,
returns="array",
examples=["web_search('Python教程')", "web_search('今日新闻', 10)"],
category="information"
)
# ============== 使用示例 ==============
async def main():
# 创建注册中心
registry = ToolRegistry()
# 注册工具
registry.register(create_calculator_tool())
registry.register(create_web_search_tool())
# 创建执行器
executor = ToolExecutor(registry)
# 执行计算
result = await executor.execute("calculator", {"expression": "2 + 3 * 4"})
print(f"Calculator result: {result}") # 14.0
# 执行搜索
results = await executor.execute("web_search", {"query": "AI agents"})
print(f"Search results: {len(results)} items")
# asyncio.run(main())3.3 工具选择与编排策略
当Agent面对复杂任务时，往往需要组合多个工具来完成。这就涉及到工具选择和编排的问题。
💡 思考：如何让Agent学会在正确的时机选择正确的工具？
🤔 解答：这涉及三个层面的设计：
-
工具选择：基于任务意图匹配最相关的工具
-
参数填充：从上下文中提取工具所需的参数
-
执行编排：处理工具之间的依赖关系和执行顺序
┌─────────────────────────────────────────────────────────────────────┐
│ 工具编排策略 │
├─────────────────────────────────────────────────────────────────────┤
│ │
│ 策略1: 顺序执行 (Sequential) │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ Task: "搜索今日天气，然后根据天气推荐穿搭" │ │
│ │ │ │
│ │ [Tool 1: weather_search] ──▶ [Tool 2: outfit_recommend] │ │
│ │ "北京 晴 15°C" ──▶ "推荐薄外套..." │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │
│ 策略2: 并行执行 (Parallel) │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ Task: "同时查询北京、上海、广州的天气" │ │
│ │ │ │
│ │ ┌── [weather_search(北京)] ──┐ │ │
│ │ │ │ │ │
│ │ ─────┼── [weather_search(上海)] ──┼─────▶ [合并结果] │ │
│ │ │ │ │ │
│ │ └── [weather_search(广州)] ──┘ │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │
│ 策略3: 条件分支 (Conditional) │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ Task: "如果明天下雨就提醒我带伞" │ │
│ │ │ │
│ │ [weather_forecast] ──┬── if 雨 ──▶ [set_reminder] │ │
│ │ │ │ │
│ │ └── else ──▶ [no_action] │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │
│ 策略4: 循环执行 (Loop) │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ Task: "监控股票价格，跌破100元时提醒" │ │
│ │ │ │
│ │ ┌──────────────────────────────────────┐ │ │
│ │ │ while price > 100: │ │ │
│ │ │ [get_stock_price] ──▶ check │ │ │
│ │ │ wait(interval) │ │ │
│ │ │ [send_alert] │ │ │
│ │ └──────────────────────────────────────┘ │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │
└─────────────────────────────────────────────────────────────────────┘
以下是工具编排器的实现：
python
from typing import Any, Dict, List, Optional, Union
from dataclasses import dataclass
from enum import Enum
import asyncio
class OrchestrationStrategy(Enum):
"""编排策略"""
SEQUENTIAL = "sequential"
PARALLEL = "parallel"
CONDITIONAL = "conditional"
LOOP = "loop"
@dataclass
class ToolCall:
"""工具调用定义"""
tool_name: str
parameters: Dict[str, Any]
output_key: str = "result" # 存储结果的键名
depends_on: Optional[List[str]] = None # 依赖的输出键
@dataclass
class OrchestrationPlan:
"""编排计划"""
strategy: OrchestrationStrategy
calls: List[ToolCall]
condition: Optional[str] = None # 用于条件分支
max_iterations: int = 100 # 用于循环
class ToolOrchestrator:
"""工具编排器"""
def __init__(self, executor: ToolExecutor):
self.executor = executor
self.context: Dict[str, Any] = {}
def _resolve_parameters(self, params: Dict[str, Any]) -> Dict[str, Any]:
"""解析参数中的引用"""
resolved = {}
for key, value in params.items():
if isinstance(value, str) and value.startswith("$"):
# 引用上下文中的值
ref_key = value[1:]
if ref_key in self.context:
resolved[key] = self.context[ref_key]
else:
raise ValueError(f"Reference not found: {ref_key}")
else:
resolved[key] = value
return resolved
async def execute_sequential(self, calls: List[ToolCall]) -> Dict[str, Any]:
"""顺序执行"""
results = {}
for call in calls:
# 检查依赖
if call.depends_on:
for dep in call.depends_on:
if dep not in self.context:
raise ValueError(f"Dependency not satisfied: {dep}")
# 解析参数
params = self._resolve_parameters(call.parameters)
# 执行
result = await self.executor.execute(call.tool_name, params)
# 存储结果
self.context[call.output_key] = result
results[call.output_key] = result
return results
async def execute_parallel(self, calls: List[ToolCall]) -> Dict[str, Any]:
"""并行执行"""
tasks = []
for call in calls:
params = self._resolve_parameters(call.parameters)
task = self.executor.execute(call.tool_name, params)
tasks.append((call.output_key, task))
results = {}
gathered = await asyncio.gather(*[t[1] for t in tasks],
return_exceptions=True)
for (key, _), result in zip(tasks, gathered):
if isinstance(result, Exception):
results[key] = {"error": str(result)}
else:
results[key] = result
self.context[key] = result
return results
async def execute_conditional(self, plan: OrchestrationPlan) -> Dict[str, Any]:
"""条件执行"""
# 评估条件
condition_result = eval(plan.condition, {"context": self.context})
if condition_result:
# 执行为真分支（假设第一个调用是true分支）
return await self.execute_sequential([plan.calls[0]])
elif len(plan.calls) > 1:
# 执行为假分支
return await self.execute_sequential([plan.calls[1]])
return {}
async def execute_loop(self, plan: OrchestrationPlan) -> Dict[str, Any]:
"""循环执行"""
results = []
iteration = 0
while iteration < plan.max_iterations:
# 执行一次迭代
iter_results = await self.execute_sequential(plan.calls)
results.append(iter_results)
# 检查退出条件
if plan.condition:
should_continue = eval(plan.condition, {"context": self.context})
if not should_continue:
break
iteration += 1
return {"iterations": results, "count": iteration}
async def execute(self, plan: OrchestrationPlan) -> Dict[str, Any]:
"""执行编排计划"""
self.context = {} # 重置上下文
if plan.strategy == OrchestrationStrategy.SEQUENTIAL:
return await self.execute_sequential(plan.calls)
elif plan.strategy == OrchestrationStrategy.PARALLEL:
return await self.execute_parallel(plan.calls)
elif plan.strategy == OrchestrationStrategy.CONDITIONAL:
return await self.execute_conditional(plan)
elif plan.strategy == OrchestrationStrategy.LOOP:
return await self.execute_loop(plan)
else:
raise ValueError(f"Unknown strategy: {plan.strategy}")
# ============== 编排计划生成器 ==============
class PlanGenerator:
"""
根据自然语言任务生成编排计划
实际应用中可使用LLM来生成
"""
def __init__(self, registry: ToolRegistry):
self.registry = registry
def generate(self, task: str) -> OrchestrationPlan:
"""
生成编排计划
这里是简化实现，实际应使用LLM
"""
# 示例：硬编码一些常见模式
if "同时" in task or "并行" in task:
# 并行模式
return self._generate_parallel_plan(task)
elif "如果" in task or "当" in task:
# 条件模式
return self._generate_conditional_plan(task)
elif "监控" in task or "持续" in task:
# 循环模式
return self._generate_loop_plan(task)
else:
# 默认顺序模式
return self._generate_sequential_plan(task)
def _generate_sequential_plan(self, task: str) -> OrchestrationPlan:
"""生成顺序计划（示例）"""
# 实际应使用LLM分析任务并匹配工具
return OrchestrationPlan(
strategy=OrchestrationStrategy.SEQUENTIAL,
calls=[
ToolCall(
tool_name="web_search",
parameters={"query": task},
output_key="search_result"
)
]
)
def _generate_parallel_plan(self, task: str) -> OrchestrationPlan:
"""生成并行计划（示例）"""
return OrchestrationPlan(
strategy=OrchestrationStrategy.PARALLEL,
calls=[
ToolCall(
tool_name="web_search",
parameters={"query": "part1"},
output_key="result1"
),
ToolCall(
tool_name="web_search",
parameters={"query": "part2"},
output_key="result2"
)
]
)
def _generate_conditional_plan(self, task: str) -> OrchestrationPlan:
"""生成条件计划（示例）"""
return OrchestrationPlan(
strategy=OrchestrationStrategy.CONDITIONAL,
condition="context.get('check_result', False)",
calls=[
ToolCall(
tool_name="web_search",
parameters={"query": "true branch"},
output_key="true_result"
),
ToolCall(
tool_name="web_search",
parameters={"query": "false branch"},
output_key="false_result"
)
]
)
def _generate_loop_plan(self, task: str) -> OrchestrationPlan:
"""生成循环计划（示例）"""
return OrchestrationPlan(
strategy=OrchestrationStrategy.LOOP,
condition="context.get('should_continue', True)",
max_iterations=10,
calls=[
ToolCall(
tool_name="web_search",
parameters={"query": "monitor"},
output_key="monitor_result"
)
]
)4. API 调用：连接数字世界
4.1 RESTful API 集成
API（Application Programming Interface）是Agent连接外部服务的桥梁。通过API，Agent可以获取实时数据、调用远程服务、与其他系统交互。
┌─────────────────────────────────────────────────────────────────────┐
│ Agent API 集成架构 │
├─────────────────────────────────────────────────────────────────────┤
│ │
│ ┌─────────────┐ │
│ │ Agent │ │
│ │ Core │ │
│ └──────┬──────┘ │
│ │ │
│ ▼ │
│ ┌──────────────────────────────────────────────────────────────┐ │
│ │ API Gateway │ │
│ │ ┌─────────────┐ ┌─────────────┐ ┌─────────────┐ │ │
│ │ │ 认证管理 │ │ 限流控制 │ │ 请求路由 │ │ │
│ │ │ Auth Mgmt │ │ Rate Limit │ │ Routing │ │ │
│ │ └─────────────┘ └─────────────┘ └─────────────┘ │ │
│ └──────────────────────────┬───────────────────────────────────┘ │
│ │ │
│ ┌───────────────────┼───────────────────┐ │
│ │ │ │ │
│ ▼ ▼ ▼ │
│ ┌─────────────┐ ┌─────────────┐ ┌─────────────┐ │
│ │ Weather API │ │ Maps API │ │ Payment API │ │
│ │ │ │ │ │ │ │
│ │ • 天气查询 │ │ • 地点搜索 │ │ • 支付处理 │ │
│ │ • 预报数据 │ │ • 路线规划 │ │ • 订单查询 │ │
│ │ • 历史数据 │ │ • 地理编码 │ │ • 退款处理 │ │
│ └─────────────┘ └─────────────┘ └─────────────┘ │
│ │ │ │ │
│ └───────────────────┼───────────────────┘ │
│ │ │
│ ▼ │
│ ┌──────────────────────────────────────────────────────────────┐ │
│ │ Response Handler │ │
│ │ ┌─────────────┐ ┌─────────────┐ ┌─────────────┐ │ │
│ │ │ 数据解析 │ │ 错误处理 │ │ 结果缓存 │ │ │
│ │ │ Parsing │ │ Error Hdl │ │ Caching │ │ │
│ │ └─────────────┘ └─────────────┘ └─────────────┘ │ │
│ └──────────────────────────────────────────────────────────────┘ │
│ │
└─────────────────────────────────────────────────────────────────────┘以下是一个通用的API客户端实现：
python
import aiohttp
import asyncio
from typing import Any, Dict, Optional, Union
from dataclasses import dataclass
from enum import Enum
import json
import time
import hashlib
class HTTPMethod(Enum):
GET = "GET"
POST = "POST"
PUT = "PUT"
DELETE = "DELETE"
PATCH = "PATCH"
@dataclass
class APIConfig:
"""API配置"""
base_url: str
api_key: Optional[str] = None
timeout: float = 30.0
max_retries: int = 3
rate_limit: Optional[int] = None # 每分钟请求数
@dataclass
class APIResponse:
"""API响应"""
status_code: int
data: Any
headers: Dict[str, str]
elapsed_time: float
class RateLimiter:
"""速率限制器"""
def __init__(self, requests_per_minute: int):
self.requests_per_minute = requests_per_minute
self.requests: List[float] = []
async def acquire(self):
"""获取请求许可"""
now = time.time()
# 清理一分钟前的记录
self.requests = [t for t in self.requests if now - t < 60]
if len(self.requests) >= self.requests_per_minute:
# 需要等待
wait_time = 60 - (now - self.requests[0])
await asyncio.sleep(wait_time)
self.requests.append(time.time())
class APIClient:
"""通用API客户端"""
def __init__(self, config: APIConfig):
self.config = config
self.session: Optional[aiohttp.ClientSession] = None
self.rate_limiter = (
RateLimiter(config.rate_limit)
if config.rate_limit else None
)
self.cache: Dict[str, tuple] = {} # {cache_key: (response, timestamp)}
self.cache_ttl = 300 # 缓存过期时间（秒）
async def _ensure_session(self):
"""确保session存在"""
if self.session is None or self.session.closed:
self.session = aiohttp.ClientSession()
def _build_headers(self, custom_headers: Optional[Dict] = None) -> Dict:
"""构建请求头"""
headers = {
"Content-Type": "application/json",
"User-Agent": "AgentAPIClient/1.0"
}
if self.config.api_key:
headers["Authorization"] = f"Bearer {self.config.api_key}"
if custom_headers:
headers.update(custom_headers)
return headers
def _get_cache_key(self, method: HTTPMethod, url: str,
params: Optional[Dict] = None) -> str:
"""生成缓存键"""
key_data = f"{method.value}:{url}:{json.dumps(params or {}, sort_keys=True)}"
return hashlib.md5(key_data.encode()).hexdigest()
def _get_from_cache(self, cache_key: str) -> Optional[APIResponse]:
"""从缓存获取"""
if cache_key in self.cache:
response, timestamp = self.cache[cache_key]
if time.time() - timestamp < self.cache_ttl:
return response
else:
del self.cache[cache_key]
return None
def _set_cache(self, cache_key: str, response: APIResponse):
"""设置缓存"""
self.cache[cache_key] = (response, time.time())
async def request(
self,
method: HTTPMethod,
endpoint: str,
params: Optional[Dict] = None,
data: Optional[Dict] = None,
headers: Optional[Dict] = None,
use_cache: bool = True
) -> APIResponse:
"""发送API请求"""
await self._ensure_session()
url = f"{self.config.base_url.rstrip('/')}/{endpoint.lstrip('/')}"
# 检查缓存（仅GET请求）
if method == HTTPMethod.GET and use_cache:
cache_key = self._get_cache_key(method, url, params)
cached = self._get_from_cache(cache_key)
if cached:
return cached
# 速率限制
if self.rate_limiter:
await self.rate_limiter.acquire()
# 构建请求
request_headers = self._build_headers(headers)
# 重试逻辑
last_error = None
for attempt in range(self.config.max_retries):
try:
start_time = time.time()
async with self.session.request(
method.value,
url,
params=params,
json=data,
headers=request_headers,
timeout=aiohttp.ClientTimeout(total=self.config.timeout)
) as response:
elapsed = time.time() - start_time
response_data = await response.json()
api_response = APIResponse(
status_code=response.status,
data=response_data,
headers=dict(response.headers),
elapsed_time=elapsed
)
# 缓存成功响应
if method == HTTPMethod.GET and use_cache and response.status == 200:
self._set_cache(cache_key, api_response)
return api_response
except asyncio.TimeoutError:
last_error = "Request timeout"
except aiohttp.ClientError as e:
last_error = str(e)
# 指数退避
if attempt < self.config.max_retries - 1:
await asyncio.sleep(2 ** attempt)
raise Exception(f"API request failed after {self.config.max_retries} attempts: {last_error}")
async def get(self, endpoint: str, params: Optional[Dict] = None,
**kwargs) -> APIResponse:
"""GET请求"""
return await self.request(HTTPMethod.GET, endpoint, params=params, **kwargs)
async def post(self, endpoint: str, data: Optional[Dict] = None,
**kwargs) -> APIResponse:
"""POST请求"""
return await self.request(HTTPMethod.POST, endpoint, data=data, **kwargs)
async def close(self):
"""关闭客户端"""
if self.session:
await self.session.close()
# ============== 具体API封装示例 ==============
class WeatherAPIClient(APIClient):
"""天气API客户端"""
def __init__(self, api_key: str):
super().__init__(APIConfig(
base_url="https://api.openweathermap.org/data/2.5",
api_key=api_key,
rate_limit=60 # 每分钟60次
))
async def get_current_weather(self, city: str) -> Dict:
"""获取当前天气"""
response = await self.get("weather", params={
"q": city,
"appid": self.config.api_key,
"units": "metric",
"lang": "zh_cn"
})
if response.status_code == 200:
data = response.data
return {
"city": data["name"],
"temperature": data["main"]["temp"],
"feels_like": data["main"]["feels_like"],
"humidity": data["main"]["humidity"],
"description": data["weather"][0]["description"],
"wind_speed": data["wind"]["speed"]
}
else:
raise Exception(f"Weather API error: {response.data}")
async def get_forecast(self, city: str, days: int = 5) -> List[Dict]:
"""获取天气预报"""
response = await self.get("forecast", params={
"q": city,
"appid": self.config.api_key,
"units": "metric",
"lang": "zh_cn",
"cnt": days * 8 # 每天8个时间点
})
if response.status_code == 200:
forecasts = []
for item in response.data["list"]:
forecasts.append({
"datetime": item["dt_txt"],
"temperature": item["main"]["temp"],
"description": item["weather"][0]["description"]
})
return forecasts
else:
raise Exception(f"Forecast API error: {response.data}")
# 使用示例
async def weather_example():
client = WeatherAPIClient(api_key="your_api_key")
try:
weather = await client.get_current_weather("Beijing")
print(f"北京天气: {weather['temperature']}°C, {weather['description']}")
forecast = await client.get_forecast("Beijing", days=3)
for f in forecast[:5]:
print(f" {f['datetime']}: {f['temperature']}°C")
finally:
await client.close()4.2 Function Calling 机制
OpenAI在2023年推出的Function Calling机制极大地简化了LLM与工具的集成。这种机制让模型能够生成结构化的函数调用，而不是自由格式的文本。
💡 思考：Function Calling相比传统的prompt engineering有什么优势？
🤔 解答：
- 结构化输出：返回JSON格式，便于解析和验证
- 类型安全：参数类型由schema定义，减少错误
- 可靠性高：模型经过专门训练，调用准确率更高
- 简化开发：无需复杂的prompt设计和输出解析
python
import openai
from typing import Any, Dict, List, Optional
import json
class FunctionCallingAgent:
"""基于Function Calling的Agent"""
def __init__(self, api_key: str, model: str = "gpt-4"):
self.client = openai.OpenAI(api_key=api_key)
self.model = model
self.functions = []
self.function_handlers = {}
def register_function(self, name: str, description: str,
parameters: Dict, handler: callable):
"""注册函数"""
self.functions.append({
"name": name,
"description": description,
"parameters": parameters
})
self.function_handlers[name] = handler
def _execute_function(self, function_name: str,
arguments: Dict) -> Any:
"""执行函数"""
if function_name not in self.function_handlers:
raise ValueError(f"Unknown function: {function_name}")
handler = self.function_handlers[function_name]
return handler(**arguments)
def chat(self, user_message: str,
conversation_history: Optional[List[Dict]] = None) -> str:
"""对话接口"""
messages = conversation_history or []
messages.append({"role": "user", "content": user_message})
# 第一次调用：获取模型响应
response = self.client.chat.completions.create(
model=self.model,
messages=messages,
functions=self.functions,
function_call="auto"
)
assistant_message = response.choices[0].message
# 检查是否有函数调用
while assistant_message.function_call:
function_name = assistant_message.function_call.name
arguments = json.loads(assistant_message.function_call.arguments)
print(f"[Calling function: {function_name}({arguments})]")
# 执行函数
try:
result = self._execute_function(function_name, arguments)
function_response = json.dumps(result, ensure_ascii=False)
except Exception as e:
function_response = json.dumps({"error": str(e)})
# 添加到对话历史
messages.append({
"role": "assistant",
"content": None,
"function_call": {
"name": function_name,
"arguments": json.dumps(arguments)
}
})
messages.append({
"role": "function",
"name": function_name,
"content": function_response
})
# 再次调用模型处理函数结果
response = self.client.chat.completions.create(
model=self.model,
messages=messages,
functions=self.functions,
function_call="auto"
)
assistant_message = response.choices[0].message
return assistant_message.content
# ============== 使用示例 ==============
def get_weather(city: str, unit: str = "celsius") -> Dict:
"""获取天气（模拟）"""
return {
"city": city,
"temperature": 22 if unit == "celsius" else 72,
"unit": unit,
"condition": "晴朗"
}
def calculate(expression: str) -> Dict:
"""计算表达式"""
try:
result = eval(expression) # 生产环境需要安全处理
return {"expression": expression, "result": result}
except Exception as e:
return {"error": str(e)}
def search_web(query: str, num_results: int = 3) -> Dict:
"""搜索网页（模拟）"""
return {
"query": query,
"results": [
{"title": f"Result {i}", "url": f"https://example.com/{i}"}
for i in range(num_results)
]
}
# 创建Agent
agent = FunctionCallingAgent(api_key="your_key")
# 注册函数
agent.register_function(
name="get_weather",
description="获取指定城市的当前天气",
parameters={
"type": "object",
"properties": {
"city": {
"type": "string",
"description": "城市名称，如北京、上海"
},
"unit": {
"type": "string",
"enum": ["celsius", "fahrenheit"],
"description": "温度单位"
}
},
"required": ["city"]
},
handler=get_weather
)
agent.register_function(
name="calculate",
description="执行数学计算",
parameters={
"type": "object",
"properties": {
"expression": {
"type": "string",
"description": "数学表达式，如 2+3*4"
}
},
"required": ["expression"]
},
handler=calculate
)
agent.register_function(
name="search_web",
description="搜索互联网获取信息",
parameters={
"type": "object",
"properties": {
"query": {
"type": "string",
"description": "搜索关键词"
},
"num_results": {
"type": "integer",
"description": "返回结果数量，默认3"
}
},
"required": ["query"]
},
handler=search_web
)
# 对话
# response = agent.chat("北京今天天气怎么样？另外帮我算一下 123 * 456")
# print(response)4.3 API 编排与错误处理
在实际应用中，API调用常常会遇到各种问题：网络超时、服务不可用、数据格式错误等。一个健壮的Agent需要具备完善的错误处理机制。
┌─────────────────────────────────────────────────────────────────────┐
│ API 错误处理策略 │
├─────────────────────────────────────────────────────────────────────┤
│ │
│ 错误类型 处理策略 回退方案 │
│ ──────────────────────────────────────────────────────────────────│
│ │
│ ┌─────────────┐ ┌─────────────┐ ┌─────────────┐ │
│ │ 网络超时 │ ───▶ │ 指数退避 │ ───▶ │ 备用API │ │
│ │ Timeout │ │ 重试3次 │ │ 或缓存数据 │ │
│ └─────────────┘ └─────────────┘ └─────────────┘ │
│ │
│ ┌─────────────┐ ┌─────────────┐ ┌─────────────┐ │
│ │ 认证失败 │ ───▶ │ 刷新Token │ ───▶ │ 通知用户 │ │
│ │ 401/403 │ │ 重新认证 │ │ 重新授权 │ │
│ └─────────────┘ └─────────────┘ └─────────────┘ │
│ │
│ ┌─────────────┐ ┌─────────────┐ ┌─────────────┐ │
│ │ 限流触发 │ ───▶ │ 等待重试 │ ───▶ │ 降级处理 │ │
│ │ 429 │ │ 按Header │ │ 减少请求 │ │
│ └─────────────┘ └─────────────┘ └─────────────┘ │
│ │
│ ┌─────────────┐ ┌─────────────┐ ┌─────────────┐ │
│ │ 服务不可用 │ ───▶ │ 切换备用 │ ───▶ │ 返回默认值 │ │
│ │ 500/503 │ │ 服务端点 │ │ 或告知用户 │ │
│ └─────────────┘ └─────────────┘ └─────────────┘ │
│ │
│ ┌─────────────┐ ┌─────────────┐ ┌─────────────┐ │
│ │ 数据格式 │ ───▶ │ 解析修复 │ ───▶ │ 记录日志 │ │
│ │ 错误 │ │ 模糊匹配 │ │ 返回错误 │ │
│ └─────────────┘ └─────────────┘ └─────────────┘ │
│ │
└─────────────────────────────────────────────────────────────────────┘
python
from enum import Enum
from typing import Any, Callable, Optional, TypeVar, Generic
from dataclasses import dataclass
import asyncio
import logging
T = TypeVar('T')
class ErrorType(Enum):
"""错误类型"""
TIMEOUT = "timeout"
AUTH_FAILED = "auth_failed"
RATE_LIMITED = "rate_limited"
SERVER_ERROR = "server_error"
PARSE_ERROR = "parse_error"
UNKNOWN = "unknown"
@dataclass
class APIError(Exception):
"""API错误"""
error_type: ErrorType
message: str
status_code: Optional[int] = None
retry_after: Optional[int] = None
class Result(Generic[T]):
"""结果包装器"""
def __init__(self, value: Optional[T] = None,
error: Optional[APIError] = None):
self._value = value
self._error = error
@property
def is_success(self) -> bool:
return self._error is None
@property
def value(self) -> T:
if self._error:
raise self._error
return self._value
@property
def error(self) -> Optional[APIError]:
return self._error
@staticmethod
def success(value: T) -> 'Result[T]':
return Result(value=value)
@staticmethod
def failure(error: APIError) -> 'Result[T]':
return Result(error=error)
class RetryPolicy:
"""重试策略"""
def __init__(
self,
max_retries: int = 3,
base_delay: float = 1.0,
max_delay: float = 60.0,
exponential_base: float = 2.0,
retryable_errors: Optional[set] = None
):
self.max_retries = max_retries
self.base_delay = base_delay
self.max_delay = max_delay
self.exponential_base = exponential_base
self.retryable_errors = retryable_errors or {
ErrorType.TIMEOUT,
ErrorType.RATE_LIMITED,
ErrorType.SERVER_ERROR
}
def should_retry(self, error: APIError, attempt: int) -> bool:
"""判断是否应该重试"""
if attempt >= self.max_retries:
return False
return error.error_type in self.retryable_errors
def get_delay(self, attempt: int,
error: Optional[APIError] = None) -> float:
"""计算重试延迟"""
# 如果服务器指定了重试时间，使用它
if error and error.retry_after:
return min(error.retry_after, self.max_delay)
# 否则使用指数退避
delay = self.base_delay * (self.exponential_base ** attempt)
return min(delay, self.max_delay)
class CircuitBreaker:
"""熔断器"""
def __init__(
self,
failure_threshold: int = 5,
recovery_timeout: float = 30.0,
half_open_requests: int = 1
):
self.failure_threshold = failure_threshold
self.recovery_timeout = recovery_timeout
self.half_open_requests = half_open_requests
self.failures = 0
self.last_failure_time: Optional[float] = None
self.state = "closed" # closed, open, half-open
self.half_open_successes = 0
def record_success(self):
"""记录成功"""
if self.state == "half-open":
self.half_open_successes += 1
if self.half_open_successes >= self.half_open_requests:
self.state = "closed"
self.failures = 0
else:
self.failures = 0
def record_failure(self):
"""记录失败"""
self.failures += 1
self.last_failure_time = asyncio.get_event_loop().time()
if self.failures >= self.failure_threshold:
self.state = "open"
def can_execute(self) -> bool:
"""检查是否可以执行"""
if self.state == "closed":
return True
if self.state == "open":
# 检查是否可以进入half-open
current_time = asyncio.get_event_loop().time()
if current_time - self.last_failure_time >= self.recovery_timeout:
self.state = "half-open"
self.half_open_successes = 0
return True
return False
# half-open状态
return True
class ResilientAPIClient:
"""具备容错能力的API客户端"""
def __init__(
self,
client: APIClient,
retry_policy: Optional[RetryPolicy] = None,
circuit_breaker: Optional[CircuitBreaker] = None,
fallback: Optional[Callable] = None
):
self.client = client
self.retry_policy = retry_policy or RetryPolicy()
self.circuit_breaker = circuit_breaker or CircuitBreaker()
self.fallback = fallback
self.logger = logging.getLogger(__name__)
def _classify_error(self, status_code: Optional[int],
exception: Optional[Exception]) -> APIError:
"""分类错误"""
if exception:
if isinstance(exception, asyncio.TimeoutError):
return APIError(ErrorType.TIMEOUT, str(exception))
return APIError(ErrorType.UNKNOWN, str(exception))
if status_code:
if status_code == 401 or status_code == 403:
return APIError(ErrorType.AUTH_FAILED, "Authentication failed",
status_code)
elif status_code == 429:
return APIError(ErrorType.RATE_LIMITED, "Rate limited",
status_code)
elif status_code >= 500:
return APIError(ErrorType.SERVER_ERROR, "Server error",
status_code)
return APIError(ErrorType.UNKNOWN, "Unknown error", status_code)
async def execute(
self,
operation: Callable,
*args,
**kwargs
) -> Result[Any]:
"""执行操作，带重试和熔断"""
# 检查熔断器
if not self.circuit_breaker.can_execute():
self.logger.warning("Circuit breaker is open, using fallback")
if self.fallback:
return Result.success(self.fallback(*args, **kwargs))
return Result.failure(
APIError(ErrorType.SERVER_ERROR, "Circuit breaker open")
)
last_error = None
for attempt in range(self.retry_policy.max_retries + 1):
try:
result = await operation(*args, **kwargs)
# 检查响应状态
if hasattr(result, 'status_code') and result.status_code >= 400:
error = self._classify_error(result.status_code, None)
if self.retry_policy.should_retry(error, attempt):
delay = self.retry_policy.get_delay(attempt, error)
self.logger.info(
f"Retrying after {delay}s (attempt {attempt + 1})"
)
await asyncio.sleep(delay)
continue
self.circuit_breaker.record_failure()
return Result.failure(error)
self.circuit_breaker.record_success()
return Result.success(result)
except Exception as e:
error = self._classify_error(None, e)
last_error = error
if self.retry_policy.should_retry(error, attempt):
delay = self.retry_policy.get_delay(attempt, error)
self.logger.info(
f"Retrying after {delay}s due to {e} (attempt {attempt + 1})"
)
await asyncio.sleep(delay)
continue
break
# 所有重试都失败
self.circuit_breaker.record_failure()
# 尝试fallback
if self.fallback:
try:
fallback_result = self.fallback(*args, **kwargs)
return Result.success(fallback_result)
except Exception as e:
self.logger.error(f"Fallback also failed: {e}")
return Result.failure(last_error or APIError(ErrorType.UNKNOWN, "All retries failed"))
# ============== 使用示例 ==============
async def demo_resilient_api():
"""演示容错API使用"""
# 创建基础客户端
base_client = APIClient(APIConfig(
base_url="https://api.example.com",
api_key="your_key"
))
# 定义fallback函数
def weather_fallback(city: str) -> Dict:
return {
"city": city,
"temperature": "N/A",
"source": "fallback"
}
# 创建容错客户端
resilient_client = ResilientAPIClient(
client=base_client,
retry_policy=RetryPolicy(max_retries=3),
circuit_breaker=CircuitBreaker(failure_threshold=5),
fallback=weather_fallback
)
# 执行请求
result = await resilient_client.execute(
base_client.get,
"weather",
params={"city": "Beijing"}
)
if result.is_success:
print(f"Success: {result.value}")
else:
print(f"Failed: {result.error}")5. 代码执行：动态能力扩展
5.1 代码生成与执行流程
代码执行是Agent最强大的能力之一。通过动态生成和执行代码，Agent可以完成几乎任何计算任务，极大地扩展了其能力边界。
💡 思考：代码执行相比预定义工具有什么优势和风险？
🤔 解答：
优势：
- 无限灵活性：可以处理任意复杂的计算逻辑
- 动态适应：无需预先定义所有可能的操作
- 组合能力：可以组合多个库和工具
- 可解释性：代码本身就是执行逻辑的说明
风险：
-
安全风险：恶意代码可能造成系统损害
-
资源消耗：不当代码可能消耗过多资源
-
不确定性：生成的代码可能有bug
-
依赖管理：可能需要特定的库和环境
┌─────────────────────────────────────────────────────────────────────┐
│ 代码执行流程 │
├─────────────────────────────────────────────────────────────────────┤
│ │
│ ┌─────────────┐ │
│ │ 用户需求 │ "分析这份CSV数据，生成销售趋势图" │
│ └──────┬──────┘ │
│ │ │
│ ▼ │
│ ┌──────────────────────────────────────────────────────────────┐ │
│ │ 代码生成 (LLM) │ │
│ │ ┌──────────────────────────────────────────────────────────┐│ │
│ │ │ import pandas as pd ││ │
│ │ │ import matplotlib.pyplot as plt ││ │
│ │ │ ││ │
│ │ │ df = pd.read_csv('sales.csv') ││ │
│ │ │ df['date'] = pd.to_datetime(df['date']) ││ │
│ │ │ monthly = df.groupby(df['date'].dt.month)['amount'].sum()││ │
│ │ │ plt.plot(monthly.index, monthly.values) ││ │
│ │ │ plt.savefig('trend.png') ││ │
│ │ └──────────────────────────────────────────────────────────┘│ │
│ └──────────────────────────┬───────────────────────────────────┘ │
│ │ │
│ ▼ │
│ ┌──────────────────────────────────────────────────────────────┐ │
│ │ 安全检查 │ │
│ │ ┌─────────┐ ┌─────────┐ ┌─────────┐ ┌─────────┐ │ │
│ │ │语法检查 │──│危险API │──│资源限制 │──│沙箱配置 │ │ │
│ │ │Syntax │ │Blacklist│ │Resources│ │Sandbox │ │ │
│ │ └─────────┘ └─────────┘ └─────────┘ └─────────┘ │ │
│ └──────────────────────────┬───────────────────────────────────┘ │
│ │ │
│ ▼ │
│ ┌──────────────────────────────────────────────────────────────┐ │
│ │ 沙箱执行 │ │
│ │ ┌──────────────────────────────────────────────────────────┐│ │
│ │ │ Docker Container / VM / Process Isolation ││ │
│ │ │ ┌────────────────────────────────────────────────────┐ ││ │
│ │ │ │ Python Runtime │ ││ │
│ │ │ │ • CPU限制: 1核 │ ││ │
│ │ │ │ • 内存限制: 512MB │ ││ │
│ │ │ │ • 执行超时: 30秒 │ ││ │
│ │ │ │ • 网络隔离: 仅允许白名单 │ ││ │
│ │ │ └────────────────────────────────────────────────────┘ ││ │
│ │ └──────────────────────────────────────────────────────────┘│ │
│ └──────────────────────────┬───────────────────────────────────┘ │
│ │ │
│ ▼ │
│ ┌──────────────────────────────────────────────────────────────┐ │
│ │ 结果处理 │ │
│ │ • 捕获stdout/stderr │ │
│ │ • 收集生成的文件 │ │
│ │ • 格式化返回结果 │ │
│ │ • 清理临时资源 │ │
│ └──────────────────────────────────────────────────────────────┘ │
│ │
└─────────────────────────────────────────────────────────────────────┘
5.2 多语言运行时支持
不同的任务可能需要不同的编程语言。一个完善的代码执行模块应该支持多种语言运行时。
python
from abc import ABC, abstractmethod
from dataclasses import dataclass
from typing import Any, Dict, List, Optional
import subprocess
import tempfile
import os
import asyncio
import ast
@dataclass
class ExecutionResult:
"""执行结果"""
success: bool
output: str
error: Optional[str] = None
return_value: Any = None
execution_time: float = 0.0
files_created: List[str] = None
class LanguageRuntime(ABC):
"""语言运行时抽象基类"""
@abstractmethod
def get_language(self) -> str:
"""获取语言名称"""
pass
@abstractmethod
async def execute(self, code: str,
context: Optional[Dict] = None) -> ExecutionResult:
"""执行代码"""
pass
@abstractmethod
def validate(self, code: str) -> tuple:
"""验证代码"""
pass
class PythonRuntime(LanguageRuntime):
"""Python运行时"""
def __init__(self, timeout: float = 30.0):
self.timeout = timeout
self.forbidden_imports = {
'os.system', 'subprocess', 'eval', 'exec',
'compile', '__import__', 'open', # 除非在沙箱中
}
self.allowed_imports = {
'math', 'statistics', 'datetime', 'json',
'collections', 'itertools', 'functools',
'numpy', 'pandas', 'matplotlib'
}
def get_language(self) -> str:
return "python"
def validate(self, code: str) -> tuple:
"""
验证Python代码
返回: (is_valid, error_message)
"""
try:
tree = ast.parse(code)
# 检查危险操作
for node in ast.walk(tree):
if isinstance(node, ast.Import):
for alias in node.names:
if alias.name not in self.allowed_imports:
return False, f"Import not allowed: {alias.name}"
elif isinstance(node, ast.ImportFrom):
if node.module not in self.allowed_imports:
return False, f"Import not allowed: {node.module}"
elif isinstance(node, ast.Call):
if isinstance(node.func, ast.Name):
if node.func.id in {'eval', 'exec', 'compile'}:
return False, f"Function not allowed: {node.func.id}"
return True, None
except SyntaxError as e:
return False, f"Syntax error: {e}"
async def execute(self, code: str,
context: Optional[Dict] = None) -> ExecutionResult:
"""执行Python代码"""
# 先验证
is_valid, error = self.validate(code)
if not is_valid:
return ExecutionResult(
success=False,
output="",
error=error
)
# 创建临时文件
with tempfile.NamedTemporaryFile(
mode='w', suffix='.py', delete=False
) as f:
# 注入上下文
if context:
for key, value in context.items():
f.write(f"{key} = {repr(value)}\n")
f.write(code)
temp_file = f.name
try:
import time
start_time = time.time()
# 执行代码
process = await asyncio.create_subprocess_exec(
'python', temp_file,
stdout=asyncio.subprocess.PIPE,
stderr=asyncio.subprocess.PIPE
)
try:
stdout, stderr = await asyncio.wait_for(
process.communicate(),
timeout=self.timeout
)
execution_time = time.time() - start_time
return ExecutionResult(
success=process.returncode == 0,
output=stdout.decode(),
error=stderr.decode() if stderr else None,
execution_time=execution_time
)
except asyncio.TimeoutError:
process.kill()
return ExecutionResult(
success=False,
output="",
error=f"Execution timeout ({self.timeout}s)"
)
finally:
os.unlink(temp_file)
class JavaScriptRuntime(LanguageRuntime):
"""JavaScript运行时 (Node.js)"""
def __init__(self, timeout: float = 30.0):
self.timeout = timeout
def get_language(self) -> str:
return "javascript"
def validate(self, code: str) -> tuple:
"""简单的JavaScript验证"""
dangerous_patterns = [
'require("child_process")',
'require("fs")',
'eval(',
'Function(',
]
for pattern in dangerous_patterns:
if pattern in code:
return False, f"Dangerous pattern detected: {pattern}"
return True, None
async def execute(self, code: str,
context: Optional[Dict] = None) -> ExecutionResult:
"""执行JavaScript代码"""
is_valid, error = self.validate(code)
if not is_valid:
return ExecutionResult(success=False, output="", error=error)
# 包装代码
wrapped_code = ""
if context:
for key, value in context.items():
wrapped_code += f"const {key} = {json.dumps(value)};\n"
wrapped_code += code
with tempfile.NamedTemporaryFile(
mode='w', suffix='.js', delete=False
) as f:
f.write(wrapped_code)
temp_file = f.name
try:
import time
start_time = time.time()
process = await asyncio.create_subprocess_exec(
'node', temp_file,
stdout=asyncio.subprocess.PIPE,
stderr=asyncio.subprocess.PIPE
)
try:
stdout, stderr = await asyncio.wait_for(
process.communicate(),
timeout=self.timeout
)
return ExecutionResult(
success=process.returncode == 0,
output=stdout.decode(),
error=stderr.decode() if stderr else None,
execution_time=time.time() - start_time
)
except asyncio.TimeoutError:
process.kill()
return ExecutionResult(
success=False,
output="",
error=f"Execution timeout ({self.timeout}s)"
)
finally:
os.unlink(temp_file)
class CodeExecutor:
"""代码执行器"""
def __init__(self):
self.runtimes: Dict[str, LanguageRuntime] = {}
def register_runtime(self, runtime: LanguageRuntime):
"""注册运行时"""
self.runtimes[runtime.get_language()] = runtime
async def execute(self, language: str, code: str,
context: Optional[Dict] = None) -> ExecutionResult:
"""执行代码"""
runtime = self.runtimes.get(language)
if not runtime:
return ExecutionResult(
success=False,
output="",
error=f"Unsupported language: {language}"
)
return await runtime.execute(code, context)
# ============== 使用示例 ==============
async def code_execution_demo():
"""代码执行演示"""
executor = CodeExecutor()
executor.register_runtime(PythonRuntime(timeout=10.0))
executor.register_runtime(JavaScriptRuntime(timeout=10.0))
# Python示例
python_code = """
import math
def calculate_circle_area(radius):
return math.pi * radius ** 2
areas = [calculate_circle_area(r) for r in range(1, 6)]
for i, area in enumerate(areas, 1):
print(f"Radius {i}: Area = {area:.2f}")
"""
result = await executor.execute("python", python_code)
print("Python Result:")
print(result.output)
# JavaScript示例
js_code = """
const numbers = [1, 2, 3, 4, 5];
const doubled = numbers.map(n => n * 2);
console.log("Original:", numbers);
console.log("Doubled:", doubled);
"""
result = await executor.execute("javascript", js_code)
print("\nJavaScript Result:")
print(result.output)
# asyncio.run(code_execution_demo())5.3 代码执行的挑战与解决方案
┌─────────────────────────────────────────────────────────────────────┐
│ 代码执行挑战与解决方案 │
├─────────────────────────────────────────────────────────────────────┤
│ │
│ 挑战1: 安全性 │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ 问题: 恶意代码可能删除文件、窃取数据、消耗资源 │ │
│ │ │ │
│ │ 解决方案: │ │
│ │ • 沙箱隔离 (Docker/VM/进程隔离) │ │
│ │ • API白名单 (只允许安全的函数) │ │
│ │ • 资源限制 (CPU/内存/磁盘/网络) │ │
│ │ • 代码审查 (AST分析检测危险模式) │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │
│ 挑战2: 依赖管理 │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ 问题: 代码可能需要特定版本的库 │ │
│ │ │ │
│ │ 解决方案: │ │
│ │ • 预装常用库的基础镜像 │ │
│ │ • 虚拟环境按需创建 │ │
│ │ • 包管理器集成 (pip/npm/cargo) │ │
│ │ • 依赖缓存加速 │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │
│ 挑战3: 状态管理 │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ 问题: 多次执行之间如何保持状态？ │ │
│ │ │ │
│ │ 解决方案: │ │
│ │ • 会话级持久化 (保持解释器实例) │ │
│ │ • 文件系统挂载 (持久化数据文件) │ │
│ │ • 变量序列化 (pickle/JSON) │ │
│ │ • 数据库连接 (SQLite/Redis) │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │
│ 挑战4: 错误处理 │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ 问题: 生成的代码可能有语法或逻辑错误 │ │
│ │ │ │
│ │ 解决方案: │ │
│ │ • 语法预检查 │ │
│ │ • 详细错误信息返回给LLM │ │
│ │ • 自动修复重试 │ │
│ │ • 单元测试验证 │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │
└─────────────────────────────────────────────────────────────────────┘6. 安全沙箱：行动的边界
6.1 沙箱技术原理
安全沙箱是Agent行动模块的关键安全组件。它通过隔离技术限制代码的执行环境，防止恶意或错误代码对主系统造成损害。
💡 思考：为什么Agent需要沙箱？直接执行代码有什么风险？
🤔 解答：直接执行LLM生成的代码存在多重风险：
- 系统安全：可能执行删除文件、修改系统配置等危险操作
- 数据安全：可能读取敏感数据并外泄
- 资源滥用：可能进入死循环或消耗大量内存
- 网络风险：可能发起恶意网络请求
沙箱通过建立安全边界，让代码"只能在笼子里活动"。
┌─────────────────────────────────────────────────────────────────────┐
│ 沙箱技术层次 │
├─────────────────────────────────────────────────────────────────────┤
│ │
│ Level 4: 虚拟机隔离 (最强隔离) │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ ┌─────────────────────────────────────────────────────┐ │ │
│ │ │ Guest OS (Linux/Windows) │ │ │
│ │ │ ┌─────────────────────────────────────────────┐ │ │ │
│ │ │ │ Application │ │ │ │
│ │ │ │ 完全隔离的操作系统环境 │ │ │ │
│ │ │ │ 优点: 最强安全性 │ │ │ │
│ │ │ │ 缺点: 启动慢，资源开销大 │ │ │ │
│ │ │ └─────────────────────────────────────────────┘ │ │ │
│ │ └─────────────────────────────────────────────────────┘ │ │
│ │ Hypervisor (KVM/Xen/VMware) │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │
│ Level 3: 容器隔离 (平衡方案) │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ ┌──────────┐ ┌──────────┐ ┌──────────┐ │ │
│ │ │Container │ │Container │ │Container │ │ │
│ │ │ A │ │ B │ │ C │ │ │
│ │ └──────────┘ └──────────┘ └──────────┘ │ │
│ │ Docker Engine / containerd │ │
│ │ 优点: 快速启动，较好隔离 │ │
│ │ 缺点: 共享内核，隔离不如VM │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │
│ Level 2: 进程隔离 │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ ┌──────────────────────────────────────────────────┐ │ │
│ │ │ Sandboxed Process │ │ │
│ │ │ • seccomp (系统调用过滤) │ │ │
│ │ │ • namespaces (命名空间隔离) │ │ │
│ │ │ • cgroups (资源限制) │ │ │
│ │ │ 优点: 轻量级，快速 │ │ │
│ │ │ 缺点: 需要精细配置 │ │ │
│ │ └──────────────────────────────────────────────────┘ │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │
│ Level 1: 语言级沙箱 │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ ┌──────────────────────────────────────────────────┐ │ │
│ │ │ Restricted Execution Environment │ │ │
│ │ │ • RestrictedPython │ │ │
│ │ │ • PyPy Sandbox │ │ │
│ │ │ • 自定义 __builtins__ │ │ │
│ │ │ 优点: 最轻量 │ │ │
│ │ │ 缺点: 可能被绕过 │ │ │
│ │ └──────────────────────────────────────────────────┘ │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │
└─────────────────────────────────────────────────────────────────────┘6.2 容器化隔离方案
Docker是目前最流行的容器化方案，非常适合作为代码执行的沙箱。
python
import docker
import asyncio
from typing import Any, Dict, List, Optional
from dataclasses import dataclass
import tempfile
import os
import tarfile
import io
@dataclass
class SandboxConfig:
"""沙箱配置"""
image: str = "python:3.10-slim"
cpu_limit: float = 1.0 # CPU核数
memory_limit: str = "512m" # 内存限制
timeout: int = 30 # 执行超时（秒）
network_disabled: bool = True # 禁用网络
read_only: bool = True # 只读文件系统
working_dir: str = "/sandbox"
user: str = "nobody" # 非特权用户
@dataclass
class SandboxResult:
"""沙箱执行结果"""
exit_code: int
stdout: str
stderr: str
files: Dict[str, bytes] # 输出文件
execution_time: float
memory_used: Optional[int] = None
cpu_time: Optional[float] = None
class DockerSandbox:
"""Docker沙箱"""
def __init__(self, config: Optional[SandboxConfig] = None):
self.config = config or SandboxConfig()
self.client = docker.from_env()
self._ensure_image()
def _ensure_image(self):
"""确保镜像存在"""
try:
self.client.images.get(self.config.image)
except docker.errors.ImageNotFound:
print(f"Pulling image: {self.config.image}")
self.client.images.pull(self.config.image)
def _create_tar(self, files: Dict[str, str]) -> bytes:
"""创建tar归档"""
tar_stream = io.BytesIO()
with tarfile.open(fileobj=tar_stream, mode='w') as tar:
for name, content in files.items():
data = content.encode('utf-8')
info = tarfile.TarInfo(name=name)
info.size = len(data)
tar.addfile(info, io.BytesIO(data))
tar_stream.seek(0)
return tar_stream.read()
def _extract_files(self, container, paths: List[str]) -> Dict[str, bytes]:
"""从容器提取文件"""
files = {}
for path in paths:
try:
bits, stat = container.get_archive(path)
tar_stream = io.BytesIO()
for chunk in bits:
tar_stream.write(chunk)
tar_stream.seek(0)
with tarfile.open(fileobj=tar_stream) as tar:
for member in tar.getmembers():
if member.isfile():
f = tar.extractfile(member)
files[member.name] = f.read()
except docker.errors.NotFound:
continue
return files
async def execute(
self,
code: str,
language: str = "python",
input_files: Optional[Dict[str, str]] = None,
output_paths: Optional[List[str]] = None
) -> SandboxResult:
"""在沙箱中执行代码"""
import time
start_time = time.time()
# 准备文件
files_to_copy = input_files or {}
if language == "python":
files_to_copy["main.py"] = code
command = ["python", "main.py"]
elif language == "javascript":
files_to_copy["main.js"] = code
command = ["node", "main.js"]
else:
raise ValueError(f"Unsupported language: {language}")
# 创建容器
container = self.client.containers.create(
image=self.config.image,
command=command,
working_dir=self.config.working_dir,
user=self.config.user,
cpu_period=100000,
cpu_quota=int(100000 * self.config.cpu_limit),
mem_limit=self.config.memory_limit,
network_disabled=self.config.network_disabled,
read_only=self.config.read_only,
tmpfs={self.config.working_dir: "size=100M,mode=1777"},
detach=True
)
try:
# 复制文件到容器
tar_data = self._create_tar(files_to_copy)
container.put_archive(self.config.working_dir, tar_data)
# 启动容器
container.start()
# 等待执行完成
try:
result = container.wait(timeout=self.config.timeout)
exit_code = result['StatusCode']
except Exception:
container.kill()
return SandboxResult(
exit_code=-1,
stdout="",
stderr=f"Execution timeout ({self.config.timeout}s)",
files={},
execution_time=time.time() - start_time
)
# 获取输出
stdout = container.logs(stdout=True, stderr=False).decode('utf-8')
stderr = container.logs(stdout=False, stderr=True).decode('utf-8')
# 获取输出文件
output_files = {}
if output_paths:
output_files = self._extract_files(container, output_paths)
# 获取资源使用情况
stats = container.stats(stream=False)
return SandboxResult(
exit_code=exit_code,
stdout=stdout,
stderr=stderr,
files=output_files,
execution_time=time.time() - start_time,
memory_used=stats.get('memory_stats', {}).get('usage')
)
finally:
# 清理容器
container.remove(force=True)
class SecureSandbox:
"""安全沙箱封装层"""
def __init__(self, sandbox: DockerSandbox):
self.sandbox = sandbox
self.code_analyzers = []
def add_analyzer(self, analyzer: callable):
"""添加代码分析器"""
self.code_analyzers.append(analyzer)
def _analyze_code(self, code: str, language: str) -> tuple:
"""分析代码安全性"""
for analyzer in self.code_analyzers:
is_safe, reason = analyzer(code, language)
if not is_safe:
return False, reason
return True, None
async def execute_safely(
self,
code: str,
language: str = "python",
**kwargs
) -> SandboxResult:
"""安全执行代码"""
# 安全检查
is_safe, reason = self._analyze_code(code, language)
if not is_safe:
return SandboxResult(
exit_code=-1,
stdout="",
stderr=f"Security check failed: {reason}",
files={},
execution_time=0.0
)
# 在沙箱中执行
return await self.sandbox.execute(code, language, **kwargs)
# ============== 代码分析器 ==============
def python_security_analyzer(code: str, language: str) -> tuple:
"""Python安全分析器"""
if language != "python":
return True, None
dangerous_patterns = [
("import os", "OS module is not allowed"),
("import subprocess", "Subprocess module is not allowed"),
("__import__", "Dynamic import is not allowed"),
("eval(", "eval() is not allowed"),
("exec(", "exec() is not allowed"),
("open(", "File operations require explicit permission"),
]
for pattern, reason in dangerous_patterns:
if pattern in code:
return False, reason
return True, None
# ============== 使用示例 ==============
async def sandbox_demo():
"""沙箱演示"""
config = SandboxConfig(
image="python:3.10-slim",
cpu_limit=0.5,
memory_limit="256m",
timeout=10,
network_disabled=True
)
docker_sandbox = DockerSandbox(config)
secure_sandbox = SecureSandbox(docker_sandbox)
secure_sandbox.add_analyzer(python_security_analyzer)
# 安全的代码
safe_code = """
import math
def fibonacci(n):
if n <= 1:
return n
return fibonacci(n-1) + fibonacci(n-2)
for i in range(10):
print(f"fib({i}) = {fibonacci(i)}")
"""
result = await secure_sandbox.execute_safely(safe_code, "python")
print("Safe code result:")
print(f"Exit code: {result.exit_code}")
print(f"Output: {result.stdout}")
# 危险的代码
dangerous_code = """
import os
os.system("rm -rf /")
"""
result = await secure_sandbox.execute_safely(dangerous_code, "python")
print("\nDangerous code result:")
print(f"Exit code: {result.exit_code}")
print(f"Error: {result.stderr}")
# asyncio.run(sandbox_demo())6.3 权限控制与审计
┌─────────────────────────────────────────────────────────────────────┐
│ 权限控制与审计系统 │
├─────────────────────────────────────────────────────────────────────┤
│ │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ 权限模型 (RBAC) │ │
│ │ │ │
│ │ ┌─────────┐ ┌─────────┐ ┌─────────┐ │ │
│ │ │ User │───▶│ Role │───▶│Permission│ │ │
│ │ │ Agent-1 │ │ Basic │ │ read_web │ │ │
│ │ └─────────┘ │ Premium │ │ exec_code│ │ │
│ │ │ Admin │ │ send_email│ │ │
│ │ └─────────┘ └─────────┘ │ │
│ │ │ │
│ │ 权限矩阵: │ │
│ │ ┌──────────┬─────────┬─────────┬─────────┐ │ │
│ │ │ Action │ Basic │ Premium │ Admin │ │ │
│ │ ├──────────┼─────────┼─────────┼─────────┤ │ │
│ │ │ web_read │ ✓ │ ✓ │ ✓ │ │ │
│ │ │ web_write│ ✗ │ ✓ │ ✓ │ │ │
│ │ │ code_exec│ ✗ │ ✓ │ ✓ │ │ │
│ │ │ file_read│ ✗ │ ✓ │ ✓ │ │ │
│ │ │ file_write│ ✗ │ ✗ │ ✓ │ │ │
│ │ │ sys_admin│ ✗ │ ✗ │ ✓ │ │ │
│ │ └──────────┴─────────┴─────────┴─────────┘ │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ 审计日志系统 │ │
│ │ │ │
│ │ 记录内容: │ │
│ │ • 操作时间戳 │ │
│ │ • 操作者身份 │ │
│ │ • 操作类型 │ │
│ │ • 操作参数 │ │
│ │ • 操作结果 │ │
│ │ • 资源消耗 │ │
│ │ │ │
│ │ 日志格式示例: │ │
│ │ { │ │
│ │ "timestamp": "2024-01-15T10:30:00Z", │ │
│ │ "agent_id": "agent-001", │ │
│ │ "action": "code_execution", │ │
│ │ "params": {"language": "python", "code_hash": "abc123"}, │ │
│ │ "result": "success", │ │
│ │ "duration_ms": 1520, │ │
│ │ "memory_mb": 45 │ │
│ │ } │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │
└─────────────────────────────────────────────────────────────────────┘以下是权限控制和审计系统的实现：
python
from dataclasses import dataclass, field
from typing import Any, Dict, List, Optional, Set
from enum import Enum
from datetime import datetime
import json
import hashlib
import logging
class Permission(Enum):
"""权限枚举"""
WEB_READ = "web_read"
WEB_WRITE = "web_write"
CODE_EXECUTE = "code_execute"
FILE_READ = "file_read"
FILE_WRITE = "file_write"
API_CALL = "api_call"
EMAIL_SEND = "email_send"
SYSTEM_ADMIN = "system_admin"
@dataclass
class Role:
"""角色定义"""
name: str
permissions: Set[Permission]
description: str = ""
@dataclass
class Agent:
"""Agent身份"""
agent_id: str
name: str
roles: List[str]
metadata: Dict[str, Any] = field(default_factory=dict)
class PermissionManager:
"""权限管理器"""
def __init__(self):
self.roles: Dict[str, Role] = {}
self.agents: Dict[str, Agent] = {}
self._init_default_roles()
def _init_default_roles(self):
"""初始化默认角色"""
self.roles["basic"] = Role(
name="basic",
permissions={Permission.WEB_READ},
description="Basic read-only access"
)
self.roles["standard"] = Role(
name="standard",
permissions={
Permission.WEB_READ,
Permission.API_CALL,
Permission.FILE_READ
},
description="Standard user access"
)
self.roles["premium"] = Role(
name="premium",
permissions={
Permission.WEB_READ,
Permission.WEB_WRITE,
Permission.API_CALL,
Permission.CODE_EXECUTE,
Permission.FILE_READ,
Permission.FILE_WRITE
},
description="Premium user access"
)
self.roles["admin"] = Role(
name="admin",
permissions=set(Permission), # 所有权限
description="Full administrative access"
)
def register_agent(self, agent: Agent):
"""注册Agent"""
self.agents[agent.agent_id] = agent
def get_permissions(self, agent_id: str) -> Set[Permission]:
"""获取Agent的所有权限"""
agent = self.agents.get(agent_id)
if not agent:
return set()
permissions = set()
for role_name in agent.roles:
role = self.roles.get(role_name)
if role:
permissions.update(role.permissions)
return permissions
def check_permission(self, agent_id: str,
permission: Permission) -> bool:
"""检查权限"""
permissions = self.get_permissions(agent_id)
return permission in permissions
def require_permission(self, agent_id: str,
permission: Permission):
"""要求权限（不满足则抛出异常）"""
if not self.check_permission(agent_id, permission):
raise PermissionError(
f"Agent {agent_id} lacks permission: {permission.value}"
)
@dataclass
class AuditEntry:
"""审计条目"""
timestamp: datetime
agent_id: str
action: str
parameters: Dict[str, Any]
result: str # success, failure, denied
error: Optional[str] = None
duration_ms: Optional[float] = None
resource_usage: Optional[Dict[str, Any]] = None
class AuditLogger:
"""审计日志记录器"""
def __init__(self, log_file: Optional[str] = None):
self.entries: List[AuditEntry] = []
self.log_file = log_file
self.logger = logging.getLogger("audit")
if log_file:
handler = logging.FileHandler(log_file)
handler.setFormatter(logging.Formatter(
'%(asctime)s - %(message)s'
))
self.logger.addHandler(handler)
self.logger.setLevel(logging.INFO)
def log(self, entry: AuditEntry):
"""记录审计日志"""
self.entries.append(entry)
log_data = {
"timestamp": entry.timestamp.isoformat(),
"agent_id": entry.agent_id,
"action": entry.action,
"params": self._sanitize_params(entry.parameters),
"result": entry.result,
"error": entry.error,
"duration_ms": entry.duration_ms,
"resources": entry.resource_usage
}
self.logger.info(json.dumps(log_data))
def _sanitize_params(self, params: Dict[str, Any]) -> Dict[str, Any]:
"""清理敏感参数"""
sanitized = {}
sensitive_keys = {'password', 'api_key', 'secret', 'token'}
for key, value in params.items():
if key.lower() in sensitive_keys:
sanitized[key] = "***REDACTED***"
elif key == 'code':
# 对代码计算哈希
sanitized['code_hash'] = hashlib.sha256(
str(value).encode()
).hexdigest()[:16]
sanitized['code_length'] = len(str(value))
else:
sanitized[key] = value
return sanitized
def query(self,
agent_id: Optional[str] = None,
action: Optional[str] = None,
start_time: Optional[datetime] = None,
end_time: Optional[datetime] = None,
result: Optional[str] = None) -> List[AuditEntry]:
"""查询审计日志"""
filtered = self.entries
if agent_id:
filtered = [e for e in filtered if e.agent_id == agent_id]
if action:
filtered = [e for e in filtered if e.action == action]
if start_time:
filtered = [e for e in filtered if e.timestamp >= start_time]
if end_time:
filtered = [e for e in filtered if e.timestamp <= end_time]
if result:
filtered = [e for e in filtered if e.result == result]
return filtered
def get_statistics(self, agent_id: Optional[str] = None) -> Dict:
"""获取统计信息"""
entries = self.entries
if agent_id:
entries = [e for e in entries if e.agent_id == agent_id]
stats = {
"total_actions": len(entries),
"success_count": len([e for e in entries if e.result == "success"]),
"failure_count": len([e for e in entries if e.result == "failure"]),
"denied_count": len([e for e in entries if e.result == "denied"]),
"actions_by_type": {},
"avg_duration_ms": 0
}
durations = [e.duration_ms for e in entries if e.duration_ms]
if durations:
stats["avg_duration_ms"] = sum(durations) / len(durations)
for entry in entries:
action = entry.action
if action not in stats["actions_by_type"]:
stats["actions_by_type"][action] = 0
stats["actions_by_type"][action] += 1
return stats
class SecureActionExecutor:
"""安全行动执行器（集成权限控制和审计）"""
def __init__(self,
permission_manager: PermissionManager,
audit_logger: AuditLogger):
self.permission_manager = permission_manager
self.audit_logger = audit_logger
self.action_handlers: Dict[str, callable] = {}
self.action_permissions: Dict[str, Permission] = {}
def register_action(self, action_name: str,
handler: callable,
required_permission: Permission):
"""注册行动"""
self.action_handlers[action_name] = handler
self.action_permissions[action_name] = required_permission
async def execute(self, agent_id: str, action_name: str,
parameters: Dict[str, Any]) -> Any:
"""执行行动"""
import time
start_time = time.time()
# 检查权限
required_permission = self.action_permissions.get(action_name)
if not required_permission:
self._log_audit(agent_id, action_name, parameters,
"failure", "Unknown action")
raise ValueError(f"Unknown action: {action_name}")
if not self.permission_manager.check_permission(
agent_id, required_permission
):
self._log_audit(agent_id, action_name, parameters,
"denied", "Permission denied")
raise PermissionError(
f"Permission denied for action: {action_name}"
)
# 执行行动
handler = self.action_handlers[action_name]
try:
result = await handler(**parameters)
duration = (time.time() - start_time) * 1000
self._log_audit(agent_id, action_name, parameters,
"success", duration_ms=duration)
return result
except Exception as e:
duration = (time.time() - start_time) * 1000
self._log_audit(agent_id, action_name, parameters,
"failure", str(e), duration_ms=duration)
raise
def _log_audit(self, agent_id: str, action: str,
params: Dict, result: str,
error: Optional[str] = None,
duration_ms: Optional[float] = None):
"""记录审计"""
entry = AuditEntry(
timestamp=datetime.now(),
agent_id=agent_id,
action=action,
parameters=params,
result=result,
error=error,
duration_ms=duration_ms
)
self.audit_logger.log(entry)7. 具身智能：从数字到物理
7.1 具身智能基础概念
具身智能（Embodied Intelligence）是AI研究的前沿方向，它强调智能体需要有"身体"来与物理世界交互。与纯数字环境中的Agent不同，具身智能Agent需要处理物理约束、连续动作空间和真实世界的不确定性。
💡 思考：为什么说具身智能是AI的下一个里程碑？
🤔 解答：
-
完整的智能闭环：只有与物理世界交互，AI才能真正理解因果关系
-
实用价值：机器人、自动驾驶等应用需要具身智能
-
学习效率：通过身体与环境的交互学习，可能比纯数据训练更高效
-
通用智能：具身交互可能是实现AGI的关键路径
┌─────────────────────────────────────────────────────────────────────┐
│ 具身智能系统架构 │
├─────────────────────────────────────────────────────────────────────┤
│ │
│ ┌─────────────────┐ │
│ │ 语言模型 │ │
│ │ (LLM Brain) │ │
│ └────────┬────────┘ │
│ │ │
│ ┌─────────────────────┼─────────────────────┐ │
│ │ │ │ │
│ ▼ ▼ ▼ │
│ ┌─────────────┐ ┌─────────────┐ ┌─────────────┐ │
│ │ 语言理解 │ │ 任务规划 │ │ 世界模型 │ │
│ │ "拿起红色 │ │ 1.定位物体 │ │ 空间理解 │ │
│ │ 的杯子" │ │ 2.移动手臂 │ │ 物理常识 │ │
│ └──────┬──────┘ │ 3.抓取 │ └──────┬──────┘ │
│ │ │ 4.移动 │ │ │
│ │ └──────┬──────┘ │ │
│ └─────────────────────┼─────────────────────┘ │
│ │ │
│ ▼ │
│ ┌──────────────────────────┐ │
│ │ 行动价值评估 │ │
│ │ (Affordance Model) │ │
│ │ • 可行性检查 │ │
│ │ • 成功概率估计 │ │
│ │ • 安全性评估 │ │
│ └────────────┬─────────────┘ │
│ │ │
│ ▼ │
│ ┌───────────────────────────────────────────────────────────┐ │
│ │ 机器人控制层 │ │
│ │ ┌──────────────┐ ┌──────────────┐ ┌──────────────┐ │ │
│ │ │ 视觉感知 │ │ 运动规划 │ │ 力反馈控制 │ │ │
│ │ │ RGB-D相机 │ │ 逆运动学 │ │ 柔顺控制 │ │ │
│ │ └──────────────┘ └──────────────┘ └──────────────┘ │ │
│ └───────────────────────────────────────────────────────────┘ │
│ │ │
│ ▼ │
│ ┌───────────────────────────────────────────────────────────┐ │
│ │ 物理世界 │ │
│ │ 🤖 ───── 🔴 ───── 📦 ───── 🏠 │ │
│ │ 机器人 目标物体 容器 环境 │ │
│ └───────────────────────────────────────────────────────────┘ │
│ │
└─────────────────────────────────────────────────────────────────────┘
7.2 SayCan：语言模型遇见机器人
SayCan是Google在2022年发布的开创性工作，首次成功将大语言模型与机器人控制结合起来。其核心思想是：用语言模型提供"说什么"（Say），用价值函数评估"能做什么"（Can）。
┌─────────────────────────────────────────────────────────────────────┐
│ SayCan 核心原理 │
├─────────────────────────────────────────────────────────────────────┤
│ │
│ 用户指令: "I spilled my drink, can you help?" │
│ │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ Step 1: LLM生成技能候选 │ │
│ │ │ │
│ │ LLM Output (语言评分): │ │
│ │ • "find a sponge" → P(say) = 0.35 │ │
│ │ • "pick up the sponge" → P(say) = 0.25 │ │
│ │ • "find a cup" → P(say) = 0.05 │ │
│ │ • "go to the table" → P(say) = 0.15 │ │
│ │ • ... │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │ │
│ ▼ │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ Step 2: 价值函数评估可行性 │ │
│ │ │ │
│ │ Affordance Model (能力评分): │ │
│ │ 当前场景: 机器人在厨房，面前有海绵和杯子 │ │
│ │ │ │
│ │ • "find a sponge" → P(can) = 0.90 (海绵在视野中) │ │
│ │ • "pick up the sponge" → P(can) = 0.85 (可达且可抓取) │ │
│ │ • "find a cup" → P(can) = 0.70 (杯子也在视野中) │ │
│ │ • "go to the table" → P(can) = 0.95 (路径畅通) │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │ │
│ ▼ │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ Step 3: 联合评分选择行动 │ │
│ │ │ │
│ │ Score = P(say) × P(can) │ │
│ │ │ │
│ │ • "find a sponge" → 0.35 × 0.90 = 0.315 ✓ 最高 │ │
│ │ • "pick up the sponge" → 0.25 × 0.85 = 0.213 │ │
│ │ • "go to the table" → 0.15 × 0.95 = 0.143 │ │
│ │ • "find a cup" → 0.05 × 0.70 = 0.035 │ │
│ │ │ │
│ │ 选择: "find a sponge" → 执行该技能 │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │ │
│ ▼ │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ Step 4: 执行并迭代 │ │
│ │ │ │
│ │ 执行 "find a sponge" → 成功 │ │
│ │ 更新上下文: "I found a sponge." │ │
│ │ 继续规划下一步... │ │
│ │ │ │
│ │ 完整执行序列: │ │
│ │ 1. find a sponge ✓ │ │
│ │ 2. pick up the sponge ✓ │ │
│ │ 3. go to the spill ✓ │ │
│ │ 4. clean the spill ✓ │ │
│ │ 5. done ✓ │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │
└─────────────────────────────────────────────────────────────────────┘以下是SayCan思想的代码实现：
python
from dataclasses import dataclass
from typing import Any, Callable, Dict, List, Optional, Tuple
import numpy as np
@dataclass
class Skill:
"""机器人技能"""
name: str
description: str
execute: Callable # 执行函数
affordance_model: Callable # 可行性评估函数
preconditions: List[str] = None # 前置条件
effects: List[str] = None # 执行效果
@dataclass
class WorldState:
"""世界状态"""
robot_position: Tuple[float, float, float]
objects: Dict[str, Dict[str, Any]] # {object_name: {position, graspable, ...}}
robot_holding: Optional[str] = None
completed_tasks: List[str] = None
class LanguageModel:
"""语言模型（模拟）"""
def __init__(self, model_name: str = "gpt-4"):
self.model_name = model_name
def score_skills(self,
instruction: str,
context: str,
skills: List[str]) -> Dict[str, float]:
"""
为技能评分：该技能对完成指令有多大帮助？
返回: {skill_name: probability}
实际实现应调用LLM API
"""
# 模拟：构建prompt让LLM评估每个技能
prompt = f"""
User instruction: {instruction}
Current context: {context}
Available skills: {skills}
For each skill, estimate the probability that it should be
the next step to help complete the instruction.
"""
# 模拟返回（实际应解析LLM输出）
# 这里假设一些合理的分布
scores = {}
for skill in skills:
if "spill" in instruction.lower():
if "sponge" in skill.lower():
scores[skill] = 0.35
elif "clean" in skill.lower():
scores[skill] = 0.25
else:
scores[skill] = 0.1
else:
scores[skill] = 1.0 / len(skills)
# 归一化
total = sum(scores.values())
return {k: v/total for k, v in scores.items()}
class AffordanceModel:
"""可行性模型：评估机器人当前能否执行某技能"""
def __init__(self):
self.skill_models: Dict[str, Callable] = {}
def register_skill(self, skill_name: str,
model: Callable[[WorldState], float]):
"""注册技能的可行性模型"""
self.skill_models[skill_name] = model
def evaluate(self, skill_name: str,
world_state: WorldState) -> float:
"""评估技能的可行性（0-1）"""
if skill_name not in self.skill_models:
return 0.0
model = self.skill_models[skill_name]
return model(world_state)
class SayCanAgent:
"""SayCan Agent实现"""
def __init__(self,
language_model: LanguageModel,
affordance_model: AffordanceModel):
self.lm = language_model
self.affordance = affordance_model
self.skills: Dict[str, Skill] = {}
self.execution_history: List[str] = []
def register_skill(self, skill: Skill):
"""注册技能"""
self.skills[skill.name] = skill
self.affordance.register_skill(
skill.name,
skill.affordance_model
)
def select_action(self,
instruction: str,
world_state: WorldState) -> Optional[str]:
"""
选择下一个要执行的动作
使用SayCan公式: score = P(say) × P(can)
"""
skill_names = list(self.skills.keys())
# 构建上下文
context = self._build_context()
# Step 1: 语言模型评分 P(say)
say_scores = self.lm.score_skills(
instruction, context, skill_names
)
# Step 2: 可行性评分 P(can)
can_scores = {}
for skill_name in skill_names:
can_scores[skill_name] = self.affordance.evaluate(
skill_name, world_state
)
# Step 3: 联合评分
combined_scores = {}
for skill_name in skill_names:
combined_scores[skill_name] = (
say_scores.get(skill_name, 0) *
can_scores.get(skill_name, 0)
)
# 选择最高分的技能
if not combined_scores:
return None
best_skill = max(combined_scores, key=combined_scores.get)
best_score = combined_scores[best_skill]
# 如果最高分太低，可能任务已完成或无法继续
if best_score < 0.01:
return None
return best_skill
def _build_context(self) -> str:
"""构建执行上下文"""
if not self.execution_history:
return "No actions taken yet."
context = "Actions taken so far:\n"
for i, action in enumerate(self.execution_history, 1):
context += f"{i}. {action}\n"
return context
async def execute_plan(self,
instruction: str,
world_state: WorldState,
max_steps: int = 10) -> List[str]:
"""
执行完整计划
迭代选择和执行动作，直到任务完成或达到最大步数
"""
self.execution_history = []
for step in range(max_steps):
# 选择动作
action = self.select_action(instruction, world_state)
if action is None:
print(f"Step {step + 1}: No valid action, task complete")
break
print(f"Step {step + 1}: Executing '{action}'")
# 执行动作
skill = self.skills[action]
success = await skill.execute(world_state)
if success:
self.execution_history.append(f"{action} - success")
# 更新世界状态（这里简化处理）
else:
self.execution_history.append(f"{action} - failed")
print(f" Action failed, retrying...")
return self.execution_history
# ============== 示例技能定义 ==============
def create_find_object_skill(object_name: str) -> Skill:
"""创建寻找物体的技能"""
async def execute(world_state: WorldState) -> bool:
"""执行寻找物体"""
if object_name in world_state.objects:
print(f" Found {object_name} at position "
f"{world_state.objects[object_name]['position']}")
return True
return False
def affordance(world_state: WorldState) -> float:
"""评估可行性"""
if object_name in world_state.objects:
obj = world_state.objects[object_name]
# 根据距离和可见性计算可行性
distance = np.linalg.norm(
np.array(obj['position']) -
np.array(world_state.robot_position)
)
visibility = obj.get('visible', 1.0)
return visibility * max(0, 1 - distance / 10)
return 0.0
return Skill(
name=f"find {object_name}",
description=f"Locate the {object_name} in the environment",
execute=execute,
affordance_model=affordance,
effects=[f"located_{object_name}"]
)
def create_pick_object_skill(object_name: str) -> Skill:
"""创建拾取物体的技能"""
async def execute(world_state: WorldState) -> bool:
"""执行拾取"""
if object_name in world_state.objects:
obj = world_state.objects[object_name]
if obj.get('graspable', False):
world_state.robot_holding = object_name
print(f" Picked up {object_name}")
return True
return False
def affordance(world_state: WorldState) -> float:
"""评估可行性"""
if object_name not in world_state.objects:
return 0.0
obj = world_state.objects[object_name]
if not obj.get('graspable', False):
return 0.1 # 不可抓取
if world_state.robot_holding is not None:
return 0.0 # 手中已有物体
# 根据距离计算
distance = np.linalg.norm(
np.array(obj['position']) -
np.array(world_state.robot_position)
)
return max(0, 1 - distance / 5)
return Skill(
name=f"pick up {object_name}",
description=f"Grasp and pick up the {object_name}",
execute=execute,
affordance_model=affordance,
preconditions=[f"located_{object_name}"],
effects=[f"holding_{object_name}"]
)
# ============== 使用示例 ==============
async def saycan_demo():
"""SayCan演示"""
# 初始化
lm = LanguageModel()
affordance = AffordanceModel()
agent = SayCanAgent(lm, affordance)
# 注册技能
agent.register_skill(create_find_object_skill("sponge"))
agent.register_skill(create_find_object_skill("cup"))
agent.register_skill(create_pick_object_skill("sponge"))
agent.register_skill(create_pick_object_skill("cup"))
# 初始化世界状态
world_state = WorldState(
robot_position=(0, 0, 0),
objects={
"sponge": {
"position": (1, 0, 0),
"graspable": True,
"visible": 1.0
},
"cup": {
"position": (2, 1, 0),
"graspable": True,
"visible": 0.8
}
}
)
# 执行任务
instruction = "I spilled my drink, can you help?"
history = await agent.execute_plan(instruction, world_state)
print("\nExecution history:")
for action in history:
print(f" - {action}")
# asyncio.run(saycan_demo())7.3 多模态感知与行动
具身智能Agent需要处理多种感知模态，并将它们融合为统一的世界理解。
┌─────────────────────────────────────────────────────────────────────┐
│ 多模态感知与行动融合 │
├─────────────────────────────────────────────────────────────────────┤
│ │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ 感知模态 │ │
│ │ │ │
│ │ ┌─────────┐ ┌─────────┐ ┌─────────┐ ┌─────────┐ │ │
│ │ │ 视觉 │ │ 深度 │ │ 触觉 │ │ 语音 │ │ │
│ │ │ RGB │ │ Depth │ │ Force │ │ Audio │ │ │
│ │ │ Camera │ │ Sensor │ │ Sensor │ │ Input │ │ │
│ │ └────┬────┘ └────┬────┘ └────┬────┘ └────┬────┘ │ │
│ │ │ │ │ │ │ │
│ │ ▼ ▼ ▼ ▼ │ │
│ │ ┌─────────┐ ┌─────────┐ ┌─────────┐ ┌─────────┐ │ │
│ │ │物体检测 │ │3D重建 │ │接触感知 │ │语音识别 │ │ │
│ │ │分割 │ │点云处理 │ │力估计 │ │意图理解 │ │ │
│ │ └────┬────┘ └────┬────┘ └────┬────┘ └────┬────┘ │ │
│ │ │ │ │ │ │ │
│ │ └────────────┴──────┬─────┴────────────┘ │ │
│ │ │ │ │
│ │ ▼ │ │
│ │ ┌─────────────────────────────────┐ │ │
│ │ │ 多模态融合 (VLM) │ │ │
│ │ │ Vision-Language Model │ │ │
│ │ │ • 场景理解 │ │ │
│ │ │ • 物体关系推理 │ │ │
│ │ │ • 空间语义映射 │ │ │
│ │ └───────────────┬─────────────────┘ │ │
│ └────────────────────────────┼─────────────────────────────────┘ │
│ │ │
│ ▼ │
│ ┌─────────────────────────────────────────────────────────────┐ │
│ │ 行动规划与执行 │ │
│ │ │ │
│ │ 场景理解 ─────▶ 任务分解 ─────▶ 技能选择 ─────▶ 执行 │ │
│ │ │ │ │ │ │ │
│ │ ▼ ▼ ▼ ▼ │ │
│ │ "厨房台面上 "1.找到杯子 "pick up 电机控制 │ │
│ │ 有一个红杯" 2.拿起来 red cup" 轨迹规划 │ │
│ │ 3.放到水槽" │ │
│ └─────────────────────────────────────────────────────────────┘ │
│ │
└─────────────────────────────────────────────────────────────────────┘
python
from dataclasses import dataclass
from typing import Any, Dict, List, Optional, Tuple
import numpy as np
@dataclass
class VisualObservation:
"""视觉观察"""
rgb_image: np.ndarray # HxWx3
depth_image: Optional[np.ndarray] = None # HxW
segmentation_mask: Optional[np.ndarray] = None # HxW
detected_objects: Optional[List[Dict]] = None
@dataclass
class ProprioceptiveState:
"""本体感知状态"""
joint_positions: np.ndarray
joint_velocities: np.ndarray
end_effector_position: np.ndarray
end_effector_orientation: np.ndarray
gripper_state: float # 0-1, 0=closed, 1=open
@dataclass
class TactileReading:
"""触觉读数"""
contact_force: np.ndarray # 3D force vector
contact_location: Optional[np.ndarray] = None
is_contact: bool = False
@dataclass
class MultimodalObservation:
"""多模态观察"""
visual: VisualObservation
proprioceptive: ProprioceptiveState
tactile: Optional[TactileReading] = None
audio: Optional[np.ndarray] = None
language_instruction: Optional[str] = None
class MultimodalEncoder:
"""多模态编码器"""
def __init__(self, config: Dict[str, Any]):
self.config = config
# 这里应初始化各模态的编码器
# 如: ViT for vision, BERT for language等
def encode_visual(self, visual: VisualObservation) -> np.ndarray:
"""编码视觉信息"""
# 使用预训练视觉模型（如CLIP、ViT）
# 返回视觉特征向量
pass
def encode_proprioceptive(self,
proprio: ProprioceptiveState) -> np.ndarray:
"""编码本体感知"""
# 简单拼接和归一化
return np.concatenate([
proprio.joint_positions,
proprio.joint_velocities,
proprio.end_effector_position,
proprio.end_effector_orientation,
[proprio.gripper_state]
])
def encode_language(self, instruction: str) -> np.ndarray:
"""编码语言指令"""
# 使用语言模型编码
pass
def fuse(self,
visual_emb: np.ndarray,
proprio_emb: np.ndarray,
language_emb: Optional[np.ndarray] = None) -> np.ndarray:
"""融合多模态特征"""
# 可以使用简单拼接、交叉注意力等方法
embeddings = [visual_emb, proprio_emb]
if language_emb is not None:
embeddings.append(language_emb)
return np.concatenate(embeddings)
class EmbodiedActionSpace:
"""具身行动空间"""
def __init__(self,
position_dim: int = 3,
rotation_dim: int = 3,
gripper_dim: int = 1):
self.position_dim = position_dim
self.rotation_dim = rotation_dim
self.gripper_dim = gripper_dim
self.total_dim = position_dim + rotation_dim + gripper_dim
def clip_action(self, action: np.ndarray) -> np.ndarray:
"""裁剪动作到有效范围"""
clipped = action.copy()
# 位置增量限制
clipped[:self.position_dim] = np.clip(
clipped[:self.position_dim], -0.1, 0.1
)
# 旋转增量限制
clipped[self.position_dim:self.position_dim+self.rotation_dim] = np.clip(
clipped[self.position_dim:self.position_dim+self.rotation_dim],
-0.5, 0.5
)
# 夹爪状态
clipped[-1] = np.clip(clipped[-1], 0, 1)
return clipped
def action_to_command(self,
action: np.ndarray,
current_state: ProprioceptiveState) -> Dict:
"""将动作转换为机器人命令"""
position_delta = action[:self.position_dim]
rotation_delta = action[self.position_dim:self.position_dim+self.rotation_dim]
gripper_cmd = action[-1]
return {
"target_position": current_state.end_effector_position + position_delta,
"target_orientation": current_state.end_effector_orientation + rotation_delta,
"gripper_command": gripper_cmd
}
class EmbodiedAgent:
"""具身智能Agent"""
def __init__(self,
encoder: MultimodalEncoder,
action_space: EmbodiedActionSpace,
policy_model: Any): # 策略模型
self.encoder = encoder
self.action_space = action_space
self.policy = policy_model
self.observation_history: List[MultimodalObservation] = []
def observe(self, observation: MultimodalObservation):
"""接收观察"""
self.observation_history.append(observation)
if len(self.observation_history) > 10: # 保留最近10帧
self.observation_history.pop(0)
def act(self) -> np.ndarray:
"""基于当前观察生成动作"""
if not self.observation_history:
return np.zeros(self.action_space.total_dim)
current_obs = self.observation_history[-1]
# 编码多模态输入
visual_emb = self.encoder.encode_visual(current_obs.visual)
proprio_emb = self.encoder.encode_proprioceptive(
current_obs.proprioceptive
)
language_emb = None
if current_obs.language_instruction:
language_emb = self.encoder.encode_language(
current_obs.language_instruction
)
# 融合特征
fused_features = self.encoder.fuse(
visual_emb, proprio_emb, language_emb
)
# 策略网络生成动作
action = self.policy.forward(fused_features)
# 裁剪动作
action = self.action_space.clip_action(action)
return action
def reset(self):
"""重置Agent状态"""
self.observation_history = []8. 实战：构建完整的行动模块
8.1 系统架构设计
现在让我们将前面讨论的所有组件整合起来，构建一个完整的Agent行动模块。
┌─────────────────────────────────────────────────────────────────────┐
│ 完整行动模块架构 │
├─────────────────────────────────────────────────────────────────────┤
│ │
│ ┌───────────────────────────────────────────────────────────────┐ │
│ │ Agent Controller │ │
│ │ • 接收规划模块的行动请求 │ │
│ │ • 协调各子模块执行 │ │
│ │ • 返回执行结果给规划模块 │ │
│ └─────────────────────────────┬─────────────────────────────────┘ │
│ │ │
│ ┌──────────────────────┼──────────────────────┐ │
│ │ │ │ │
│ ▼ ▼ ▼ │
│ ┌─────────────┐ ┌─────────────┐ ┌─────────────┐ │
│ │ Tool │ │ API │ │ Code │ │
│ │ Executor │ │ Client │ │ Executor │ │
│ │ │ │ │ │ │ │
│ │ • 计算器 │ │ • HTTP请求 │ │ • Python │ │
│ │ • 搜索 │ │ • 认证管理 │ │ • JavaScript│ │
│ │ • 日历 │ │ • 重试逻辑 │ │ • SQL │ │
│ └──────┬──────┘ └──────┬──────┘ └──────┬──────┘ │
│ │ │ │ │
│ └──────────────────────┼──────────────────────┘ │
│ │ │
│ ▼ │
│ ┌───────────────────────────────────────────────────────────────┐ │
│ │ Security Layer │ │
│ │ ┌─────────────┐ ┌─────────────┐ ┌─────────────┐ │ │
│ │ │ Permission │ │ Sandbox │ │ Audit │ │ │
│ │ │ Manager │ │ Runtime │ │ Logger │ │ │
│ │ └─────────────┘ └─────────────┘ └─────────────┘ │ │
│ └───────────────────────────────────────────────────────────────┘ │
│ │
└─────────────────────────────────────────────────────────────────────┘8.2 核心代码实现
python
import asyncio
from dataclasses import dataclass, field
from typing import Any, Callable, Dict, List, Optional, Union
from enum import Enum
from datetime import datetime
import json
import logging
# ============== 行动类型定义 ==============
class ActionCategory(Enum):
"""行动类别"""
TOOL = "tool"
API = "api"
CODE = "code"
EMBODIED = "embodied"
@dataclass
class ActionDefinition:
"""行动定义"""
name: str
category: ActionCategory
description: str
parameters_schema: Dict[str, Any]
handler: Callable
permission_required: Optional[str] = None
timeout: float = 30.0
requires_confirmation: bool = False
@dataclass
class ActionRequest:
"""行动请求"""
action_name: str
parameters: Dict[str, Any]
agent_id: str
request_id: str = field(default_factory=lambda: str(uuid.uuid4()))
priority: int = 0
context: Optional[Dict[str, Any]] = None
@dataclass
class ActionResponse:
"""行动响应"""
request_id: str
success: bool
result: Any = None
error: Optional[str] = None
execution_time: float = 0.0
metadata: Dict[str, Any] = field(default_factory=dict)
# ============== 行动模块主类 ==============
class ActionModule:
"""Agent行动模块"""
def __init__(self, config: Optional[Dict] = None):
self.config = config or {}
self.actions: Dict[str, ActionDefinition] = {}
self.permission_manager = PermissionManager()
self.audit_logger = AuditLogger()
self.executors: Dict[ActionCategory, Any] = {}
self.middleware: List[Callable] = []
self.logger = logging.getLogger(__name__)
self._init_executors()
def _init_executors(self):
"""初始化执行器"""
# 工具执行器
self.executors[ActionCategory.TOOL] = ToolExecutor(
ToolRegistry()
)
# API执行器
self.executors[ActionCategory.API] = ResilientAPIClient(
APIClient(APIConfig(
base_url=self.config.get('api_base_url', ''),
timeout=self.config.get('api_timeout', 30.0)
))
)
# 代码执行器（沙箱）
if self.config.get('enable_code_execution', False):
sandbox_config = SandboxConfig(
**self.config.get('sandbox', {})
)
self.executors[ActionCategory.CODE] = SecureSandbox(
DockerSandbox(sandbox_config)
)
def register_action(self, action_def: ActionDefinition):
"""注册行动"""
self.actions[action_def.name] = action_def
self.logger.info(f"Registered action: {action_def.name}")
def add_middleware(self, middleware: Callable):
"""添加中间件"""
self.middleware.append(middleware)
async def execute(self, request: ActionRequest) -> ActionResponse:
"""执行行动"""
import time
import uuid
start_time = time.time()
# 获取行动定义
action_def = self.actions.get(request.action_name)
if not action_def:
return ActionResponse(
request_id=request.request_id,
success=False,
error=f"Unknown action: {request.action_name}"
)
# 权限检查
if action_def.permission_required:
if not self.permission_manager.check_permission(
request.agent_id,
Permission(action_def.permission_required)
):
self._log_audit(request, "denied", "Permission denied")
return ActionResponse(
request_id=request.request_id,
success=False,
error="Permission denied"
)
# 执行中间件
for middleware in self.middleware:
try:
request = await middleware(request)
except Exception as e:
return ActionResponse(
request_id=request.request_id,
success=False,
error=f"Middleware error: {str(e)}"
)
# 确认检查（如果需要）
if action_def.requires_confirmation:
# 这里应该有确认逻辑
pass
# 执行行动
try:
result = await asyncio.wait_for(
self._execute_action(action_def, request),
timeout=action_def.timeout
)
execution_time = time.time() - start_time
self._log_audit(request, "success",
duration_ms=execution_time * 1000)
return ActionResponse(
request_id=request.request_id,
success=True,
result=result,
execution_time=execution_time
)
except asyncio.TimeoutError:
self._log_audit(request, "failure", "Timeout")
return ActionResponse(
request_id=request.request_id,
success=False,
error=f"Action timeout ({action_def.timeout}s)"
)
except Exception as e:
self._log_audit(request, "failure", str(e))
return ActionResponse(
request_id=request.request_id,
success=False,
error=str(e)
)
async def _execute_action(self,
action_def: ActionDefinition,
request: ActionRequest) -> Any:
"""执行具体行动"""
executor = self.executors.get(action_def.category)
if action_def.category == ActionCategory.TOOL:
return await executor.execute(
action_def.name,
request.parameters
)
elif action_def.category == ActionCategory.API:
return await executor.execute(
action_def.handler,
**request.parameters
)
elif action_def.category == ActionCategory.CODE:
code = request.parameters.get('code', '')
language = request.parameters.get('language', 'python')
return await executor.execute_safely(code, language)
else:
# 通用处理
if asyncio.iscoroutinefunction(action_def.handler):
return await action_def.handler(**request.parameters)
else:
return action_def.handler(**request.parameters)
def _log_audit(self, request: ActionRequest, result: str,
error: Optional[str] = None,
duration_ms: Optional[float] = None):
"""记录审计日志"""
entry = AuditEntry(
timestamp=datetime.now(),
agent_id=request.agent_id,
action=request.action_name,
parameters=request.parameters,
result=result,
error=error,
duration_ms=duration_ms
)
self.audit_logger.log(entry)
def get_available_actions(self,
agent_id: str) -> List[Dict[str, Any]]:
"""获取Agent可用的行动列表"""
available = []
agent_permissions = self.permission_manager.get_permissions(agent_id)
for name, action_def in self.actions.items():
if action_def.permission_required:
required_perm = Permission(action_def.permission_required)
if required_perm not in agent_permissions:
continue
available.append({
"name": name,
"category": action_def.category.value,
"description": action_def.description,
"parameters": action_def.parameters_schema
})
return available
def to_function_schemas(self,
agent_id: str) -> List[Dict[str, Any]]:
"""转换为Function Calling格式"""
actions = self.get_available_actions(agent_id)
schemas = []
for action in actions:
schemas.append({
"name": action["name"],
"description": action["description"],
"parameters": {
"type": "object",
"properties": action["parameters"],
"required": [
k for k, v in action["parameters"].items()
if v.get("required", False)
]
}
})
return schemas
# ============== 便捷的装饰器 ==============
def action(name: str,
category: ActionCategory = ActionCategory.TOOL,
description: str = "",
permission: Optional[str] = None,
timeout: float = 30.0,
requires_confirmation: bool = False):
"""行动注册装饰器"""
def decorator(func):
# 从函数签名推断参数schema
import inspect
sig = inspect.signature(func)
params_schema = {}
for param_name, param in sig.parameters.items():
if param_name in ('self', 'cls'):
continue
param_info = {"type": "string"} # 默认类型
if param.annotation != inspect.Parameter.empty:
if param.annotation == int:
param_info["type"] = "integer"
elif param.annotation == float:
param_info["type"] = "number"
elif param.annotation == bool:
param_info["type"] = "boolean"
elif param.annotation == list:
param_info["type"] = "array"
if param.default == inspect.Parameter.empty:
param_info["required"] = True
else:
param_info["default"] = param.default
params_schema[param_name] = param_info
func._action_definition = ActionDefinition(
name=name,
category=category,
description=description or func.__doc__ or "",
parameters_schema=params_schema,
handler=func,
permission_required=permission,
timeout=timeout,
requires_confirmation=requires_confirmation
)
return func
return decorator
# ============== 完整使用示例 ==============
class MyAgentActions:
"""自定义Agent行动集合"""
def __init__(self):
self.action_module = ActionModule({
'enable_code_execution': True,
'sandbox': {
'cpu_limit': 0.5,
'memory_limit': '256m',
'timeout': 10
}
})
self._register_actions()
def _register_actions(self):
"""注册所有行动"""
# 搜索行动
@action(
name="web_search",
category=ActionCategory.API,
description="Search the web for information",
permission="web_read"
)
async def web_search(query: str, num_results: int = 5):
# 实际应调用搜索API
return {"query": query, "results": []}
self.action_module.register_action(web_search._action_definition)
# 计算器行动
@action(
name="calculator",
category=ActionCategory.TOOL,
description="Perform mathematical calculations"
)
def calculator(expression: str):
import ast
import operator
ops = {
ast.Add: operator.add,
ast.Sub: operator.sub,
ast.Mult: operator.mul,
ast.Div: operator.truediv,
}
def eval_node(node):
if isinstance(node, ast.Num):
return node.n
elif isinstance(node, ast.BinOp):
return ops[type(node.op)](
eval_node(node.left),
eval_node(node.right)
)
raise ValueError("Invalid expression")
tree = ast.parse(expression, mode='eval')
return eval_node(tree.body)
self.action_module.register_action(calculator._action_definition)
# 代码执行行动
@action(
name="execute_code",
category=ActionCategory.CODE,
description="Execute Python code in sandbox",
permission="code_execute",
timeout=30.0,
requires_confirmation=True
)
async def execute_code(code: str, language: str = "python"):
pass # 由沙箱执行器处理
self.action_module.register_action(execute_code._action_definition)
async def run_demo(self):
"""演示运行"""
import uuid
# 注册Agent
self.action_module.permission_manager.register_agent(
Agent(
agent_id="demo-agent",
name="Demo Agent",
roles=["premium"]
)
)
# 执行计算
request = ActionRequest(
action_name="calculator",
parameters={"expression": "2 + 3 * 4"},
agent_id="demo-agent"
)
response = await self.action_module.execute(request)
print(f"Calculator result: {response.result}")
# 获取可用行动
available = self.action_module.get_available_actions("demo-agent")
print(f"Available actions: {[a['name'] for a in available]}")
# 运行
# agent_actions = MyAgentActions()
# asyncio.run(agent_actions.run_demo())8.3 测试与优化
python
import pytest
import asyncio
from unittest.mock import Mock, patch, AsyncMock
class TestActionModule:
"""行动模块测试"""
@pytest.fixture
def action_module(self):
"""创建测试用的行动模块"""
return ActionModule({
'enable_code_execution': False
})
@pytest.fixture
def sample_action(self):
"""创建示例行动"""
async def handler(x: int, y: int) -> int:
return x + y
return ActionDefinition(
name="add",
category=ActionCategory.TOOL,
description="Add two numbers",
parameters_schema={
"x": {"type": "integer", "required": True},
"y": {"type": "integer", "required": True}
},
handler=handler
)
@pytest.mark.asyncio
async def test_register_and_execute(self, action_module, sample_action):
"""测试注册和执行行动"""
action_module.register_action(sample_action)
# 注册Agent
action_module.permission_manager.register_agent(
Agent("test-agent", "Test", ["basic"])
)
request = ActionRequest(
action_name="add",
parameters={"x": 1, "y": 2},
agent_id="test-agent"
)
response = await action_module.execute(request)
assert response.success
assert response.result == 3
@pytest.mark.asyncio
async def test_permission_denied(self, action_module):
"""测试权限拒绝"""
action = ActionDefinition(
name="admin_action",
category=ActionCategory.TOOL,
description="Admin only action",
parameters_schema={},
handler=lambda: None,
permission_required="system_admin"
)
action_module.register_action(action)
action_module.permission_manager.register_agent(
Agent("basic-agent", "Basic", ["basic"])
)
request = ActionRequest(
action_name="admin_action",
parameters={},
agent_id="basic-agent"
)
response = await action_module.execute(request)
assert not response.success
assert "Permission denied" in response.error
@pytest.mark.asyncio
async def test_timeout(self, action_module):
"""测试超时处理"""
async def slow_handler():
await asyncio.sleep(10)
return "done"
action = ActionDefinition(
name="slow_action",
category=ActionCategory.TOOL,
description="Slow action",
parameters_schema={},
handler=slow_handler,
timeout=0.1
)
action_module.register_action(action)
action_module.permission_manager.register_agent(
Agent("test-agent", "Test", ["basic"])
)
request = ActionRequest(
action_name="slow_action",
parameters={},
agent_id="test-agent"
)
response = await action_module.execute(request)
assert not response.success
assert "timeout" in response.error.lower()
@pytest.mark.asyncio
async def test_audit_logging(self, action_module, sample_action):
"""测试审计日志"""
action_module.register_action(sample_action)
action_module.permission_manager.register_agent(
Agent("test-agent", "Test", ["basic"])
)
request = ActionRequest(
action_name="add",
parameters={"x": 1, "y": 2},
agent_id="test-agent"
)
await action_module.execute(request)
# 检查审计日志
logs = action_module.audit_logger.query(agent_id="test-agent")
assert len(logs) == 1
assert logs[0].action == "add"
assert logs[0].result == "success"
class TestSandbox:
"""沙箱测试"""
@pytest.fixture
def secure_sandbox(self):
"""创建安全沙箱"""
config = SandboxConfig(
timeout=5,
memory_limit="128m"
)
docker_sandbox = DockerSandbox(config)
sandbox = SecureSandbox(docker_sandbox)
sandbox.add_analyzer(python_security_analyzer)
return sandbox
@pytest.mark.asyncio
async def test_safe_code_execution(self, secure_sandbox):
"""测试安全代码执行"""
code = """
print("Hello, World!")
result = 1 + 1
print(f"Result: {result}")
"""
result = await secure_sandbox.execute_safely(code, "python")
assert result.exit_code == 0
assert "Hello, World!" in result.stdout
@pytest.mark.asyncio
async def test_dangerous_code_blocked(self, secure_sandbox):
"""测试危险代码阻止"""
dangerous_code = """
import os
os.system("rm -rf /")
"""
result = await secure_sandbox.execute_safely(dangerous_code, "python")
assert result.exit_code == -1
assert "not allowed" in result.stderr.lower()
# 性能测试
class TestPerformance:
"""性能测试"""
@pytest.mark.asyncio
async def test_concurrent_execution(self):
"""测试并发执行性能"""
action_module = ActionModule()
async def quick_action():
await asyncio.sleep(0.01)
return "done"
action = ActionDefinition(
name="quick",
category=ActionCategory.TOOL,
description="Quick action",
parameters_schema={},
handler=quick_action
)
action_module.register_action(action)
action_module.permission_manager.register_agent(
Agent("test", "Test", ["basic"])
)
# 并发执行100个请求
import time
start = time.time()
tasks = []
for i in range(100):
request = ActionRequest(
action_name="quick",
parameters={},
agent_id="test"
)
tasks.append(action_module.execute(request))
results = await asyncio.gather(*tasks)
elapsed = time.time() - start
success_count = sum(1 for r in results if r.success)
print(f"Completed {success_count}/100 in {elapsed:.2f}s")
assert success_count == 100
assert elapsed < 5.0 # 应在5秒内完成9. 前沿进展与未来展望
🔬 前沿研究方向
┌─────────────────────────────────────────────────────────────────────┐
│ Agent行动模块前沿研究 │
├─────────────────────────────────────────────────────────────────────┤
│ │
│ 1. 工具学习 (Tool Learning) │
│ ┌───────────────────────────────────────────────────────────────┐ │
│ │ • Toolformer: 自监督工具使用学习 │ │
│ │ • ToolBench: 大规模工具调用基准测试 │ │
│ │ • TALM: 工具增强语言模型 │ │
│ │ • API-Bank: API调用能力评估 │ │
│ └───────────────────────────────────────────────────────────────┘ │
│ │
│ 2. 具身智能 (Embodied AI) │
│ ┌───────────────────────────────────────────────────────────────┐ │
│ │ • PaLM-E: 具身多模态语言模型 │ │
│ │ • RT-2: Vision-Language-Action模型 │ │
│ │ • SayCan: 语言模型指导机器人 │ │
│ │ • Open X-Embodiment: 跨机器人迁移学习 │ │
│ └───────────────────────────────────────────────────────────────┘ │
│ │
│ 3. 代码生成与执行 │
│ ┌───────────────────────────────────────────────────────────────┐ │
│ │ • CodeAct: 代码作为行动的Agent框架 │ │
│ │ • OpenInterpreter: 自然语言编程接口 │ │
│ │ • TaskWeaver: 代码优先的Agent框架 │ │
│ │ • AutoGen: 多Agent代码协作 │ │
│ └───────────────────────────────────────────────────────────────┘ │
│ │
│ 4. 安全与可控性 │
│ ┌───────────────────────────────────────────────────────────────┐ │
│ │ • Constitutional AI: 价值对齐 │ │
│ │ • Tool Use Safety: 工具使用安全性 │ │
│ │ • Sandboxing Techniques: 沙箱技术创新 │ │
│ │ • Interpretable Actions: 可解释的行动决策 │ │
│ └───────────────────────────────────────────────────────────────┘ │
│ │
└─────────────────────────────────────────────────────────────────────┘🔮 未来展望
💡 思考：Agent行动能力的发展会走向何方？
🤔 解答：
短期（1-2年）：
- Function Calling能力持续增强，支持更复杂的工具组合
- 代码执行沙箱更加成熟，安全性和性能平衡更好
- 多Agent协作完成复杂任务成为常态
中期（3-5年）：
- 具身智能取得突破，LLM驱动的机器人进入家庭
- 通用工具使用能力：Agent能自主学习新工具
- 行动规划与执行的深度融合，端到端优化
长期（5-10年）：
- 真正的通用Agent：能处理开放世界的任意任务
- 自主行动决策：在复杂环境中做出安全、有效的决策
- 人机协作新范式：Agent成为人类的延伸
10. 总结
本文系统性地探讨了Agent行动模块的设计与实现，主要内容包括：
📝 核心要点回顾
-
行动模块概述
- 行动模块是Agent与世界交互的"手脚"
- 核心能力包括：工具调用、API交互、代码执行、具身控制
- 架构设计需要考虑安全性、可扩展性、可观测性
-
工具使用与Toolformer
- Toolformer开创了自监督工具学习的新范式
- 工具选择与编排是复杂任务执行的关键
- 策略包括：顺序、并行、条件、循环
-
API调用
- RESTful API是连接外部服务的主要方式
- Function Calling简化了LLM与工具的集成
- 错误处理、重试、熔断是生产级必备
-
代码执行
- 代码执行提供无限灵活性
- 多语言运行时支持不同场景
- 安全是首要考虑
-
安全沙箱
- 沙箱是执行不可信代码的必要保障
- 容器化（Docker）是主流方案
- 权限控制与审计保障合规
-
具身智能
- SayCan证明了LLM与机器人结合的可行性
- 多模态感知是具身智能的基础
- 行动价值评估（Affordance）是关键
🎯 设计原则
- 安全第一：所有行动都应在安全边界内执行
- 最小权限：只授予必要的权限
- 可审计：所有行动都应被记录
- 可恢复：错误应能被检测和恢复
- 可扩展：新行动应易于添加
🚀 实践建议
- 从简单开始：先实现基础工具调用，再扩展复杂能力
- 重视测试：行动模块需要全面的单元测试和集成测试
- 监控先行：在生产环境部署前，确保有完善的监控
- 安全审查：定期审查权限配置和审计日志
- 持续迭代：根据使用情况不断优化行动库
通过本文的学习，相信读者已经对Agent行动模块有了全面的理解。行动能力是Agent从"智能助手"进化为"智能代理"的关键一步，也是AI走向实用化的重要里程碑。
💬 互动讨论：你在构建Agent行动模块时遇到过哪些挑战？欢迎在评论区分享你的经验！
⭐ 如果这篇文章对你有帮助，别忘了点赞、收藏、关注三连！
参考文献
1\] Schick, T., Dwivedi-Yu, J., Dessì, R., Raileanu, R., Lomeli, M., Zettlemoyer, L., ... \& Scialom, T. (2023). Toolformer: Language Models Can Teach Themselves to Use Tools. arXiv preprint arXiv:2302.04761. \[2\] Ahn, M., Brohan, A., Brown, N., Chebotar, Y., Cortes, O., David, B., ... \& Zeng, A. (2022). Do As I Can, Not As I Say: Grounding Language in Robotic Affordances. arXiv preprint arXiv:2204.01691. \[3\] Driess, D., Xia, F., Sajjadi, M. S., Lynch, C., Chowdhery, A., Ichter, B., ... \& Florence, P. (2023). PaLM-E: An Embodied Multimodal Language Model. arXiv preprint arXiv:2303.03378. \[4\] Brohan, A., Brown, N., Carbajal, J., Chebotar, Y., Chen, X., Choromanski, K., ... \& Zitkovich, B. (2023). RT-2: Vision-Language-Action Models Transfer Web Knowledge to Robotic Control. arXiv preprint arXiv:2307.15818. \[5\] Qin, Y., Liang, S., Ye, Y., Zhu, K., Yan, L., Lu, Y., ... \& Sun, M. (2023). ToolLLM: Facilitating Large Language Models to Master 16000+ Real-world APIs. arXiv preprint arXiv:2307.16789. \[6\] Wang, L., Ma, C., Feng, X., Zhang, Z., Yang, H., Zhang, J., ... \& Wang, J. (2023). A Survey on Large Language Model based Autonomous Agents. arXiv preprint arXiv:2308.11432. \[7\] Patil, S. G., Zhang, T., Wang, X., \& Gonzalez, J. E. (2023). Gorilla: Large Language Model Connected with Massive APIs. arXiv preprint arXiv:2305.15334. \[8\] Wang, G., Xie, Y., Jiang, Y., Mandlekar, A., Xiao, C., Zhu, Y., ... \& Anandkumar, A. (2023). Voyager: An Open-Ended Embodied Agent with Large Language Models. arXiv preprint arXiv:2305.16291. \[9\] Wu, Q., Bansal, G., Zhang, J., Wu, Y., Zhang, S., Zhu, E., ... \& Wang, C. (2023). AutoGen: Enabling Next-Gen LLM Applications via Multi-Agent Conversation. arXiv preprint arXiv:2308.08155. \[10\] Open X-Embodiment Collaboration. (2023). Open X-Embodiment: Robotic Learning Datasets and RT-X Models. arXiv preprint arXiv:2310.08864. \[11\] Liu, Z., Yao, W., Zhang, J., Xue, L., Heinecke, S., Murber, R., ... \& Savarese, S. (2023). BOLAA: Benchmarking and Orchestrating LLM-augmented Autonomous Agents. arXiv preprint arXiv:2308.05960. \[12\] Tang, Q., Deng, Z., Lin, H., Han, X., Liang, Q., \& Sun, L. (2023). ToolAlpaca: Generalized Tool Learning for Language Models with 3000 Simulated Cases. arXiv preprint arXiv:2306.05301. \[13\] Shen, Y., Song, K., Tan, X., Li, D., Lu, W., \& Zhuang, Y. (2023). HuggingGPT: Solving AI Tasks with ChatGPT and its Friends in Hugging Face. arXiv preprint arXiv:2303.17580. \[14\] Li, M., Song, F., Yu, B., Yu, H., Li, Z., Huang, F., \& Li, Y. (2023). API-Bank: A Benchmark for Tool-Augmented LLMs. arXiv preprint arXiv:2304.08244. \[15\] Hao, S., Gu, Y., Ma, H., Hong, J., Wang, Z., Wang, D., \& Hu, Z. (2023). Reasoning with Language Model is Planning with World Model. arXiv preprint arXiv:2305.14992. \[16\] Nakano, R., Hilton, J., Balaji, S., Wu, J., Ouyang, L., Kim, C., ... \& Schulman, J. (2021). WebGPT: Browser-assisted Question-answering with Human Feedback. arXiv preprint arXiv:2112.09332. \[17\] Yang, Z., Li, L., Wang, J., Lin, K., Azarnasab, E., Ahmed, F., ... \& Wang, L. (2023). MM-REACT: Prompting ChatGPT for Multimodal Reasoning and Action. arXiv preprint arXiv:2303.11381. \[18\] Xie, T., Zhou, F., Cheng, Z., Shi, P., Weng, L., Liu, Y., ... \& Lou, J. (2023). OpenAgents: An Open Platform for Language Agents in the Wild. arXiv preprint arXiv:2310.10634. \[19\] Reed, S., Zolna, K., Parisotto, E., Colmenarejo, S. G., Novikov, A., Barth-Maron, G., ... \& de Freitas, N. (2022). A Generalist Agent. arXiv preprint arXiv:2205.06175. \[20\] Xi, Z., Chen, W., Guo, X., He, W., Ding, Y., Hong, B., ... \& Gui, T. (2023). The Rise and Potential of Large Language Model Based Agents: A Survey. arXiv preprint arXiv:2309.07864.
