前言
提示：年会抽签功能需要手机设备和电脑设备进行互动，因此最好将项目部署到云服务器或者云虚拟机上。如果是本地部署请确保手机和电脑在同一个网段！！！并且手机端NFC功能使用需要HTTPS，需要申请证书
近期我们公司行政找到我，希望我们这边开发个NFC标签互动小游戏在年会上使用，具体需求是参会人员用手机触碰NFC标签，互动之后，大屏幕那边就会显示该人员抽到的签内容。我也是第一次接触NFC标签开发，因此做个笔记分享
一、如何互动
我们思考下这个项目最重要的问题------如何互动，我们需要回忆下几个概念：服务端，客户端，短连接和长连接。
1.服务端 & 客户端
对于这个抽签小游戏项目，无需存储数据或者用户登录信息等。因此我觉得不需要做服务端。直接写客户端就可以了。手机和电脑设备都会自带浏览器。将项目开发为web应用是最合适的。
2.短连接 & 长连接
web应用是浏览器打开的应用。大多数是基于短连接HTTP协议。也就是我们刷新一次网页进行一次HTTP请求。请求结束之后，则无法再收到其他更新的信息。我们需要页面中加入长连接，进行消息推送。也就是下面用到MQTT协议。
3.MQTT是什么？
MQTT（消息队列遥测传输，Message Queuing Telemetry Transport）是一种基于发布/订阅范式的轻量级消息传输协议，详细请自行查看MQTT百度百科。我们写的是浏览器页面，需要用到JavaScript的MQTT库------MQTT.js
二、开发抽签页面
1.实现思路
我们主要是根据浏览器的URL是否存在参数来区分设备类型。电脑端的浏览器URL没有参数，当没有获取到ID参数则监听公共MQTT服务器订阅消息，收到消息之后显示标签内容；手机端的浏览器打开带有参数的URL，当获取到ID参数则给公共MQTT服务器发送订阅消息。
2.具体实现
新建项目文件夹nfc，在里面新建index.html
用到的背景动画如下
index.html代码如下：
html
<!DOCTYPE html>
<html lang="zh-CN">
<head>
<meta charset="UTF-8">
<meta name="viewport" content="width=device-width, initial-scale=1.0">
<title>2026马到成功 | 赛博求签</title>
<script src="https://unpkg.com/mqtt@4.3.7/dist/mqtt.min.js"></script>
<link rel="preconnect" href="https://fonts.googleapis.com">
<link rel="preconnect" href="https://fonts.gstatic.com" crossorigin>
<link href="https://fonts.googleapis.com/css2?family=Zhi+Mang+Xing&family=Noto+Serif+SC:wght@700&display=swap" rel="stylesheet">
<style>
:root {
--stick-red: #d6000f;
--stick-beige: #f8f4e6;
--stick-gold: #cfa972;
--festive-red: #c00000;
--festive-gold: #ffd34e;
--art-font: "Zhi Mang Xing", "Ma Shan Zheng", cursive;
--body-font: "Noto Serif SC", "Songti SC", serif;
}
body {
margin: 0; padding: 0;
background-color: #000;
color: var(--festive-gold);
font-family: var(--body-font);
height: 100vh; width: 100vw;
overflow: hidden;
display: flex; justify-content: center; align-items: center;
}
#cinema-stage {
position: relative;
width: 100vw; height: 56.25vw;
max-height: 100vh; max-width: 177.78vh;
overflow: hidden;
display: flex; justify-content: center; align-items: center;
background: radial-gradient(circle, #5e0000 0%, #2b0000 100%);
}
#bg-video {
position: absolute;
top: 0; left: 0; width: 100%; height: 100%;
object-fit: cover;
z-index: 0;
opacity: 0.85;
}
#mobile-trigger-ui {
display: none;
text-align: center; z-index: 9999;
background: rgba(60, 0, 0, 0.95);
padding: 40px; border-radius: 20px;
border: 3px solid var(--festive-red);
box-shadow: 0 0 0 5px var(--festive-gold), 0 0 40px rgba(255, 215, 0, 0.4);
width: 80%; max-width: 400px;
position: fixed; top: 50%; left: 50%; transform: translate(-50%, -50%);
}
.success-icon {
font-size: 80px; margin-bottom: 20px;
font-family: var(--art-font);
color: var(--festive-gold); text-shadow: 0 0 20px var(--festive-red);
animation: pulse-pray 2s infinite ease-in-out;
}
@keyframes pulse-pray { 0% { transform: scale(1); opacity: 1; } 50% { transform: scale(1.1); opacity: 0.8; } 100% { transform: scale(1); opacity: 1; } }
.mobile-text {
font-size: 32px;
font-family: var(--art-font);
color: var(--festive-gold);
margin-bottom: 15px;
}
.mobile-tip { font-size: 16px; color: #fff; opacity: 0.9; line-height: 1.6; font-weight: normal;}
#pc-container { width: 100%; height: 100%; position: absolute; top:0; left:0; z-index: 2; }
#start-mask {
position: absolute; top: 0; left: 0; width: 100%; height: 100%;
background: rgba(0,0,0,0.8); z-index: 5000;
display: flex; justify-content: center; align-items: center;
flex-direction: column; cursor: pointer;
border: 20px solid var(--festive-red); box-sizing: border-box;
}
#start-mask h1 {
font-size: 5rem; margin-bottom: 30px;
font-family: var(--art-font);
letter-spacing: 5px;
background: linear-gradient(45deg, #bf953f, #fcf6ba, #b38728, #fbf5b7, #aa771c);
background-size: 200% auto;
-webkit-background-clip: text;
background-clip: text;
color: transparent;
animation: goldShine 3s linear infinite;
filter: drop-shadow(0 0 5px rgba(255, 215, 0, 0.3));
}
@keyframes goldShine { to { background-position: 200% center; } }
#start-mask p {
font-size: 2rem; color: #fff; animation: pulse 1s infinite;
border: 2px solid #fff; padding: 10px 40px; border-radius: 50px;
font-family: var(--art-font);
}
@keyframes pulse { 0% { opacity: 0.5; } 50% { opacity: 1; } 100% { opacity: 0.5; } }
.status-box {
position: absolute; bottom: 20px; right: 20px;
z-index: 3000; background: rgba(0,0,0,0.6);
padding: 8px 15px; border-radius: 20px;
display: flex; align-items: center; gap: 10px;
border: 1px solid rgba(255,255,255,0.3);
}
.status-dot { width: 12px; height: 12px; background-color: #f00; border-radius: 50%; transition: all 0.3s; border: 2px solid rgba(255,255,255,0.5);}
.status-text { color: #fff; font-size: 14px; font-family: sans-serif;}
#stick-container {
position: absolute; top: 50%; left: 50%; transform: translate(-50%, -50%);
width: 90%; display: flex; justify-content: center; align-items: center;
flex-wrap: wrap; gap: 20px; z-index: 10;
}
.stick {
position: relative;
width: 70px; height: 360px;
margin: 10px 15px;
clip-path: polygon(50% 0%, 100% 12%, 100% 100%, 0% 100%, 0% 12%);
border-radius: 0; border: none;
background:
var(--pattern-clouds-subtle) center 100px / 60px repeat,
linear-gradient(to bottom, var(--stick-red) 0%, var(--stick-red) 22%, var(--stick-beige) 22%, var(--stick-beige) 100%);
display: flex;
align-items: center;
justify-content: flex-start;
padding-top: 110px;
box-sizing: border-box;
writing-mode: vertical-rl;
font-family: var(--art-font);
font-size: 3.2rem;
font-weight: normal;
color: #8a5a1f;
text-shadow: 0 1px 0 rgba(255,255,255,0.4);
letter-spacing: 0px;
cursor: default;
animation: breathe var(--duration, 3s) ease-in-out infinite alternate;
filter: drop-shadow(12px 12px 6px rgba(0,0,0,0.9));
transition: all 1s cubic-bezier(0.25, 1, 0.5, 1);
}
@keyframes breathe {
0% { transform: translateY(0); }
100% { transform: translateY(-15px); }
}
.stick::before {
content: '吉';
position: absolute;
top: 3.5%; left: 50%;
transform: translateX(-50%);
width: 45px; height: 45px;
border: 3px solid var(--stick-gold);
border-radius: 50%;
display: flex; justify-content: center; align-items: center;
font-size: 2.6rem;
color: var(--stick-gold);
font-family: var(--art-font);
background-image: none; margin: 0; opacity: 1; z-index: 2;
}
.stick::after { display: none; }
.stick.fade-out { opacity: 0; transform: scale(0.5); }
.stick.chosen {
position: fixed; z-index: 999;
top: 50% !important; left: 50% !important;
transform: translate(-50%, -50%) scale(1.6) rotate(0deg) !important;
filter: drop-shadow(0 0 20px rgba(255, 211, 78, 1));
animation: none;
}
#result-overlay {
position: absolute; top: 0; left: 0; width: 100%; height: 100%;
z-index: 1000; display: flex; justify-content: center; align-items: center;
opacity: 0; pointer-events: none; perspective: 1500px;
transition: opacity 0.5s; background: rgba(0,0,0,0.6);
}
#result-overlay.active { opacity: 1; pointer-events: auto; }
.fortune-card {
width: 800px;
min-height: 450px;
padding: 40px 50px;
background-color: #fdf7e3;
border: 10px solid var(--festive-red); outline: 5px solid var(--festive-gold); outline-offset: -15px;
border-radius: 20px; text-align: center;
box-shadow: 0 50px 120px rgba(0,0,0,1);
opacity: 0; transform: rotateY(90deg);
transition: all 0.8s cubic-bezier(0.175, 0.885, 0.32, 1.275);
position: relative; overflow: hidden;
display: flex; flex-direction: column; justify-content: center; align-items: center;
}
.fortune-card::before {
content: '馬'; position: absolute; top: 50%; left: 50%; transform: translate(-50%, -50%);
font-size: 400px; color: var(--festive-red); opacity: 0.05;
font-family: var(--art-font);
pointer-events: none; z-index: 0;
}
.fortune-card.show { opacity: 1; transform: rotateY(0deg); }
#fortune-title {
font-size: 4.2rem;
margin: 0 0 20px 0;
color: var(--festive-red);
border-bottom: 3px solid var(--festive-red); padding-bottom: 15px;
position: relative; z-index: 1;
font-family: var(--art-font);
text-shadow: 1px 1px 0 var(--festive-gold);
width: 100%;
}
#fortune-title::before { content: '✦'; color: var(--festive-gold); margin-right: 15px; }
#fortune-title::after { content: '✦'; color: var(--festive-gold); margin-left: 15px; }
#fortune-text {
font-family: "STXinwei", "华文新魏", var(--art-font);
font-size: 3.0rem;
line-height: 1.2;
color: #5c1b1b;
font-weight: normal;
position: relative; z-index: 1;
white-space: pre-wrap;
text-align: center;
}
.reset-btn {
margin-top: 30px;
padding: 15px 60px; font-size: 2.0rem; position: relative; z-index: 1;
background: linear-gradient(to bottom, var(--festive-red), #a00000);
color: var(--festive-gold);
border: 3px solid var(--festive-gold); border-radius: 60px; cursor: pointer;
font-family: var(--art-font);
box-shadow: 0 10px 25px rgba(0,0,0,0.4), inset 0 2px 5px rgba(255,255,255,0.2);
text-shadow: 1px 1px 2px rgba(0,0,0,0.5); transition: all 0.3s;
}
.reset-btn:hover { transform: scale(1.05) translateY(-5px); box-shadow: 0 15px 35px rgba(0,0,0,0.5), inset 0 2px 5px rgba(255,255,255,0.3); }
</style>
</head>
<body>
<div id="cinema-stage">
<!-- 换成自己背景图片路径 -->
<img src="bg.gif" alt="" style="width: 100%;">
<div id="pc-container">
<div id="start-mask" onclick="activateSystem()">
<h1>2026 马到成功 | 赛博求签</h1>
<p>✦ 点击开启新春鸿运 ✦</p>
</div>
<div class="status-box">
<div class="status-dot" id="status-dot"></div>
<div class="status-text" id="status-text">连接中...</div>
</div>
<div id="stick-container">
<div class="stick" style="--duration:3s">心想事成</div>
<div class="stick" style="--duration:4s">马到成功</div>
<div class="stick" style="--duration:3.5s">鸿运当头</div>
<div class="stick" style="--duration:4.5s">财源广进</div>
<div class="stick" style="--duration:3.2s">步步高升</div>
<div class="stick" style="--duration:3.8s">吉星高照</div>
<div class="stick" style="--duration:4.2s">大展宏图</div>
<div class="stick" style="--duration:3.6s">万事如意</div>
</div>
<div id="result-overlay">
<div class="fortune-card" id="fortune-card">
<h2 id="fortune-title">标题</h2>
<div id="fortune-text">内容</div>
<button class="reset-btn" id="reset-btn">承接好运 · 下一位</button>
</div>
</div>
</div>
</div>
<div id="mobile-trigger-ui">
<div class="success-icon">馬</div>
<div class="mobile-text">祈福成功 · 马到成功</div>
<div class="mobile-tip">请抬头看大屏幕解签<br>愿您 2026 宏图大展</div>
</div>
<script>
const MQTT_TOPIC = 'nianhui_final_2025_fixed_channel';
const MQTT_BROKER = 'wss://broker.emqx.io:8084/mqtt';
const FORTUNE_DATABASE = {
'01': { title: "上上大吉 | 金马奔腾", content: "新春伊始\n运势如骏马奔腾！\n事业得贵人相助\n财源广进\n正财偏财双丰收！" },
'02': { title: "大吉 | 马到成功", content: "所谋之事\n定能马到成功！\n只要付诸行动\n必能势如破竹\n顺利达成心中目标！" },
'03': { title: "上吉 | 龙马精神", content: "身体健康\n精力充沛！\n任何挑战如履平地\n你是团队中\n最耀眼的明星！" },
'04': { title: "吉 | 鸿运当头", content: "喜鹊枝头叫\n今年运气好到让人羡慕！\n多结善缘\n好机会将主动找上门" },
'05': { title: "中吉 | 步步高升", content: "运势稳步上扬\n厚积薄发\n耐心积累\n年终回首\n必将站在全新的高度！" },
'06': { title: "上上签 | 伯乐相马", content: "今年最大的好运\n是遇伯乐！\n才华将被充分发掘\n迎来职业生涯高光时刻！" },
'07': { title: "大吉 | 财运亨通", content: "金马送福\n财星高照！\n投资理财眼光独到\n实现财务小目标\n就在今年！" },
'08': { title: "吉 | 顺风顺水", content: "烦恼随风而去\n万事顺遂！\n工作生活中的小阻碍\n迎刃而解\n享受美好时光" },
'09': { title: "上吉 | 喜从天降", content: "生活中藏着巨大彩蛋！\n可能是奖金\n晋升或好消息\n喜事即将临门！" },
'10': { title: "吉 | 福星高照", content: "职场防御力满分！\n无论环境波动\n你都能稳坐钓鱼台\n是团队的定海神针" },
'11': { title: "中平 | 蓄势待发", content: "养精蓄锐的最佳期\n像良驹调整呼吸\n一旦发力\n必将一鸣惊人！" },
'12': { title: "大吉 | 势不可挡", content: "行动力爆棚！\n任何困难都无法阻挡你\n想到就做\n年度MVP非你莫属！" },
'13': { title: "吉 | 珠联璧合", content: "喜得绝佳拍档！\n强强联手\n发挥巨大能量\n共创辉煌佳绩！" },
'14': { title: "中吉 | 渐入佳境", content: "状态渐入佳境\n以更智慧的方式处理问题\n享受游刃有余的成就感" },
'15': { title: "上吉 | 心想事成", content: "美好愿景变为现实！\n梦想路径清晰可见\n相信直觉\n大胆追梦吧！" },
'16': { title: "吉 | 贵人扶持", content: "真诚善良积攒极佳人缘\n困难时总有贵人相助\n善待他人\n福报自来！" },
'17': { title: "中平 | 平安是福", content: "运势平稳\n平安健康是最大福气！\n在追求事业时\n别忘照顾好身体与家人" },
'18': { title: "大吉 | 飞黄腾达", content: "质变之年！\n能力格局巨大飞跃\n抓住机遇\n开启人生辉煌新篇章！" },
'19': { title: "吉 | 吉庆有余", content: "掌握生活平衡之道\n从容不迫的态度\n带来持久健康\n和源源不断的快乐！" },
'20': { title: "否极泰来 | 触底反弹", content: "转折点已到！\n否极泰来\n巨大的上升空间就在前方\n好运即将爆发！" },
'default': { title: "纳福纳祥", content: "祥瑞之气环绕\n请静心祈福\n重新扫描\n迎接属于你的好运" }
};
const urlParams = new URLSearchParams(window.location.search);
const triggerId = urlParams.get('id');
// 触发模态框
function activateSystem() {
document.getElementById('start-mask').style.display = 'none';
const video = document.getElementById('bg-video');
if (video) video.play().catch(e => console.log('Autoplay blocked:', e));
}
if (triggerId) {
initMobileMode(triggerId);
} else {
initPCMode();
}
// 初始化移动端模式（移动端触发抽签）
function initMobileMode(id) {
document.getElementById('cinema-stage').style.display = 'none';
document.getElementById('mobile-trigger-ui').style.display = 'block';
const client = mqtt.connect(MQTT_BROKER);
client.on('connect', () => {
client.publish(MQTT_TOPIC, JSON.stringify({ id: id }), { qos: 1 });
});
}
// 初始化PC端模式（PC端显示酬勤内容）
function initPCMode() {
const client = mqtt.connect(MQTT_BROKER);
const statusDot = document.getElementById('status-dot');
const statusText = document.getElementById('status-text');
client.on('connect', () => {
statusDot.style.backgroundColor = '#0f0';
statusDot.style.boxShadow = '0 0 10px #0f0';
statusText.innerText = '云端已连接 (Ready)';
client.subscribe(MQTT_TOPIC);
});
// 增加断线重连提示
client.on('reconnect', () => {
statusDot.style.backgroundColor = '#fa0';
statusText.innerText = '正在重连...';
});
client.on('error', (err) => {
console.error("MQTT Error:", err);
statusDot.style.backgroundColor = '#f00';
statusText.innerText = '连接失败，请检查网络';
});
client.on('message', (topic, message) => {
try {
const data = JSON.parse(message.toString());
animateChoiceAndShowResult(data.id);
} catch (e) { console.error(e); }
});
}
let isAnimating = false;
// 动画选择并显示结果
function animateChoiceAndShowResult(fortuneId) {
if (isAnimating) return;
isAnimating = true;
const sticks = document.querySelectorAll('.stick');
const stickIndex = (parseInt(fortuneId) - 1) % sticks.length;
const chosenStick = sticks[stickIndex];
const rect = chosenStick.getBoundingClientRect();
sticks.forEach((stick, index) => {
if (index !== stickIndex) {
stick.classList.add('fade-out');
}
});
chosenStick.style.position = 'fixed';
chosenStick.style.left = rect.left + 'px';
chosenStick.style.top = rect.top + 'px';
chosenStick.style.margin = '0';
chosenStick.style.zIndex = '999';
void chosenStick.offsetWidth;
chosenStick.classList.add('chosen');
setTimeout(() => {
chosenStick.style.left = '';
chosenStick.style.top = '';
}, 50);
setTimeout(() => {
showResultCard(fortuneId);
}, 1200);
}
// 显示结果卡片
function showResultCard(id) {
const data = FORTUNE_DATABASE[id] || FORTUNE_DATABASE['default'];
document.getElementById('fortune-title').innerText = data.title;
document.getElementById('fortune-text').innerText = data.content;
const overlay = document.getElementById('result-overlay');
overlay.classList.add('active');
const card = document.getElementById('fortune-card');
setTimeout(() => { card.classList.add('show'); }, 100);
}
// 重置按钮逻辑 点击后重置所有状态
document.getElementById('reset-btn').addEventListener('click', () => {
const overlay = document.getElementById('result-overlay');
const card = document.getElementById('fortune-card');
overlay.classList.remove('active');
card.classList.remove('show');
const sticks = document.querySelectorAll('.stick');
sticks.forEach(stick => {
stick.classList.remove('fade-out');
stick.classList.remove('chosen');
stick.style.position = '';
stick.style.left = '';
stick.style.top = '';
stick.style.margin = '';
stick.style.zIndex = '';
});
isAnimating = false;
});
</script>
</body>
</html>三、部署项目
将项目部署到云服务器上。因为手机端NFC功能需要再HTTPS协议上进行，部署的时候需要申请相应的证书即可。接下来继续往下操作
四、写入NFC标签内容
项目部署好了之后，给NFC标签写入网址内容：https://www.xxxx.net/index.html?id=01。之后用手机触碰NFC
五、项目互动效果
手机端触碰NFC标签，点击打开网址。电脑PC端显示标签内容
