Docker 安装
1、第一步
bash
# Add Docker's official GPG key:
sudo apt update
sudo apt install ca-certificates curl
sudo install -m 0755 -d /etc/apt/keyrings
sudo curl -fsSL https://download.docker.com/linux/ubuntu/gpg -o /etc/apt/keyrings/docker.asc
sudo chmod a+r /etc/apt/keyrings/docker.asc
# Add the repository to Apt sources:
sudo tee /etc/apt/sources.list.d/docker.sources <<EOF
Types: deb
URIs: https://download.docker.com/linux/ubuntu
Suites: $(. /etc/os-release && echo "${UBUNTU_CODENAME:-$VERSION_CODENAME}")
Components: stable
Architectures: $(dpkg --print-architecture)
Signed-By: /etc/apt/keyrings/docker.asc
EOF
sudo apt update2、第二步
bash
sudo apt install docker-ce docker-ce-cli containerd.io docker-buildx-plugin docker-compose-plugin安装 NVIDIA Aerial™ CUDA-Accelerated RAN
bash
# Clone repository
git clone --recurse-submodules https://github.com/NVIDIA/aerial-cuda-accelerated-ran.git
cd aerial-cuda-accelerated-ran
# Enable git LFS and pull files
sudo apt install git-lfs && git lfs pull
# Start interactive development container
./cuPHY-CP/container/run_aerial.sh
# Inside container: Build SDK
./testBenches/phase4_test_scripts/build_aerial_sdk.sh调试日志
bash
root@vultr:~/aerial-cuda-accelerated-ran# ./cuPHY-CP/container/run_aerial.sh
/root/aerial-cuda-accelerated-ran/cuPHY-CP/container/run_aerial.sh starting...
Start container instance at bash prompt
server_id:
This system has no GPU, running without --gpus all parameter
Creating soft link for libcuda.so.1 for RU Emulator dependency
Command: sudo ln -s /usr/local/cuda/compat/libcuda.so.1 /usr/lib/$(arch)-linux-gnu/libcuda.so.1 && /bin/bash
TTY detected - running in interactive mode
26-1-cubb: Pulling from nvidia/aerial/aerial-cuda-accelerated-ran
0e7ece72e3b5: Pulling fs layer
81f3e991623d: Pull complete
1a3898e10342: Pull complete
4f4fb700ef54: Pull complete
857e2dfcaac8: Pull complete
634084ec28f2: Pull complete
049f4c827736: Pull complete
ad66ad4d34ab: Pull complete
3859772c4161: Pull complete
8bea7b60f737: Pull complete
d071cc246154: Pull complete
dad801bc0c88: Pull complete
df8352e677f7: Pull complete
7d0179eecbbf: Pull complete
d0a50c842949: Pull complete
fc3edd27239a: Pull complete
0c42b19f461a: Pull complete
f20fbaa39204: Pull complete
a3bf63359605: Pull complete
aa0390b17df1: Pull complete
2748d2541abf: Pull complete
706588eed72c: Pull complete
3d84eedf1b08: Pull complete
6e5945558d2d: Pull complete
e841d3675bb4: Pull complete
d601b7b8bee2: Pull complete
5d1190f163bb: Pull complete
9cd71e4bc499: Pull complete
00b4ad22a577: Pull complete
d46aabf2a85f: Pull complete
63f8542f90dd: Pull complete
0ea53c37f090: Pull complete
ea9e174bfae4: Pull complete
d14d207c339c: Pull complete
bc2e381b35e3: Pull complete
f880ce3501bd: Pull complete
4f1314cc1220: Pull complete
efc7ad5f4937: Pull complete
88524ab40f47: Pull complete
1d25a5719929: Pull complete
17293cbc77f1: Pull complete
3c3ceb6d9aa5: Pull complete
b3a6e57c75a9: Pull complete
5003ab1f86b6: Pull complete
Digest: sha256:5773d96a2188372cb39e57e85148501836cf397bcebeb80861a30674e0ccaa0c
Status: Downloaded newer image for nvcr.io/nvidia/aerial/aerial-cuda-accelerated-ran:26-1-cubb
nvcr.io/nvidia/aerial/aerial-cuda-accelerated-ran:26-1-cubb
==========
== CUDA ==
==========
CUDA Version 13.1.1
Container image Copyright (c) 2016-2023, NVIDIA CORPORATION & AFFILIATES. All rights reserved.
This container image and its contents are governed by the NVIDIA Deep Learning Container License.
By pulling and using the container, you accept the terms and conditions of this license:
https://developer.nvidia.com/ngc/nvidia-deep-learning-container-license
A copy of this license is made available in this container at /NGC-DL-CONTAINER-LICENSE for your convenience.
WARNING: The NVIDIA Driver was not detected. GPU functionality will not be available.
Use the NVIDIA Container Toolkit to start this container with GPU support; see
https://docs.nvidia.com/datacenter/cloud-native/ .
fixuid: fixuid should only ever be used on development systems. DO NOT USE IN PRODUCTION
fixuid: runtime UID '0' matches existing user 'root'; not changing UID
fixuid: runtime GID '0' matches existing group 'root'; not changing GID
fixuid: recursively searching path /home/aerial
fixuid: chown /home/aerial
fixuid: chown /home/aerial/.bash_logout
fixuid: chown /home/aerial/.bashrc
fixuid: chown /home/aerial/.local
fixuid: chown /home/aerial/.local/bin
fixuid: chown /home/aerial/.profile
root@c_aerial_root:/opt/nvidia/cuBB# ./testBenches/phase4_test_scripts/build_aerial_sdk.sh
-- Using toolchain /opt/nvidia/cuBB/cuPHY/cmake/toolchains/devkit
-- The content of file: /opt/nvidia/cuBB/aerial-sdk-version is: 26-1-cubb, assigned to AERIAL_SDK_VERSION
CMake Warning at CMakeLists.txt:44 (message):
Setting CMAKE_BUILD_TYPE to 'Release' as none was specified.
-- Enabled ccache
-- Using ENV{cuBB_SDK} /opt/nvidia/cuBB
-- The C compiler identification is GNU 12.3.0
-- The CXX compiler identification is GNU 12.3.0
-- The ASM compiler identification is GNU
-- Found assembler: /usr/local/gnu/bin/x86_64-linux-gnu-gcc
-- The CUDA compiler identification is NVIDIA 13.1.115
-- Detecting C compiler ABI info
-- Detecting C compiler ABI info - done
-- Check for working C compiler: /usr/local/gnu/bin/x86_64-linux-gnu-gcc - skipped
-- Detecting C compile features
-- Detecting C compile features - done
-- Detecting CXX compiler ABI info
-- Detecting CXX compiler ABI info - done
-- Check for working CXX compiler: /usr/local/gnu/bin/x86_64-linux-gnu-g++ - skipped
-- Detecting CXX compile features
-- Detecting CXX compile features - done
-- Detecting CUDA compiler ABI info
-- Detecting CUDA compiler ABI info - done
-- Check for working CUDA compiler: /usr/local/cuda/bin/nvcc - skipped
-- Detecting CUDA compile features
-- Detecting CUDA compile features - done
-- Using GPU architectures 80;90;100;120;121
-- Found CUDAToolkit: /usr/local/cuda/include (found version "13.1.115")
-- Performing Test CMAKE_HAVE_LIBC_PTHREAD
-- Performing Test CMAKE_HAVE_LIBC_PTHREAD - Success
-- Found Threads: TRUE
-- cuPHY is using toolchain /opt/nvidia/cuBB/cuPHY/cmake/toolchains/devkit
-- cuPHY using CMAKE_CUDA_ARCHITECTURES=80;90;100;120;121
-- Found HDF5: /usr/lib/x86_64-linux-gnu/hdf5/serial/libhdf5.so;/usr/local/lib/libcrypto.so;/usr/lib/x86_64-linux-gnu/libcurl.so;/usr/lib/x86_64-linux-gnu/libpthread.a;/usr/lib/x86_64-linux-gnu/libsz.so;/usr/local/lib/libz.so;/usr/lib/x86_64-linux-gnu/libdl.a;/usr/lib/x86_64-linux-gnu/libm.so (found suitable version "1.10.7", minimum required is "1.10") found components: C
-- Found Doxygen: /usr/bin/doxygen (found version "1.9.1") found components: doxygen dot
-- Configuring /opt/nvidia/cuBB/build.x86_64/cuPHY/Doxyfile
-- including nvlog
-- mathdx: Found CUTLASS (NvidiaCutlass) dependency: /usr/local/nvidia/mathdx/25.06/external/cutlass/include
-- cufftdx: Found CUTLASS (NvidiaCutlass) dependency: /usr/local/nvidia/mathdx/25.06/external/cutlass/include
-- cufftdx: Found commondx dependency
-- Found cufftdx: (Version: 1.5.1, Include dirs: /usr/local/nvidia/mathdx/25.06/include)
-- mathDx: cuFFTDx found: /usr/local/nvidia/mathdx/25.06/include
-- Found GTest: /usr/local/lib/cmake/GTest/GTestConfig.cmake (found version "1.17.0")
-- mathdx: Found CUTLASS (NvidiaCutlass) dependency: /usr/local/nvidia/mathdx/25.06/external/cutlass/include
-- cufftdx: Found CUTLASS (NvidiaCutlass) dependency: /usr/local/nvidia/mathdx/25.06/external/cutlass/include
-- cufftdx: Found commondx dependency
-- Found cufftdx: (Version: 1.5.1, Include dirs: /usr/local/nvidia/mathdx/25.06/include)
-- mathDx: cuFFTDx found: /usr/local/nvidia/mathdx/25.06/include
-- Found Python3: /usr/bin/python3.10 (found version "3.10.12") found components: Interpreter Development Development.Module Development.Embed
-- Performing Test HAS_FLTO
-- Performing Test HAS_FLTO - Success
-- Found pybind11: /usr/include (found version "2.9.1")
-- testBenches is using toolchain /opt/nvidia/cuBB/cuPHY/cmake/toolchains/devkit
-- testBenches is using CMAKE_CUDA_ARCHITECTURES=80;90;100;120;121
-- Found HDF5: /usr/lib/x86_64-linux-gnu/hdf5/serial/libhdf5.so;/usr/local/lib/libcrypto.so;/usr/lib/x86_64-linux-gnu/libcurl.so;/usr/lib/x86_64-linux-gnu/libpthread.a;/usr/lib/x86_64-linux-gnu/libsz.so;/usr/local/lib/libz.so;/usr/lib/x86_64-linux-gnu/libdl.a;/usr/lib/x86_64-linux-gnu/libm.so;/usr/lib/x86_64-linux-gnu/hdf5/serial/libhdf5_cpp.so;/usr/lib/x86_64-linux-gnu/hdf5/serial/libhdf5.so;/usr/local/lib/libcrypto.so;/usr/lib/x86_64-linux-gnu/libcurl.so;/usr/lib/x86_64-linux-gnu/libpthread.a;/usr/lib/x86_64-linux-gnu/libsz.so;/usr/local/lib/libz.so;/usr/lib/x86_64-linux-gnu/libdl.a;/usr/lib/x86_64-linux-gnu/libm.so (found version "1.10.7") found components: C CXX
-- Using toolchain /opt/nvidia/cuBB/cuPHY/cmake/toolchains/devkit
-- cuMAC is using toolchain /opt/nvidia/cuBB/cuPHY/cmake/toolchains/devkit
-- Using GPU architectures 80;90;100;120;121
-- Found HDF5: /usr/lib/x86_64-linux-gnu/hdf5/serial/libhdf5_cpp.so;/usr/lib/x86_64-linux-gnu/hdf5/serial/libhdf5.so;/usr/local/lib/libcrypto.so;/usr/lib/x86_64-linux-gnu/libcurl.so;/usr/lib/x86_64-linux-gnu/libpthread.a;/usr/lib/x86_64-linux-gnu/libsz.so;/usr/local/lib/libz.so;/usr/lib/x86_64-linux-gnu/libdl.a;/usr/lib/x86_64-linux-gnu/libm.so (found version "1.10.7") found components: CXX
-- cumac_ml is using toolchain /opt/nvidia/cuBB/cuPHY/cmake/toolchains/devkit
-- cumac_ml is using GPU architectures 80;90;100;120;121
-- Using HDF5 CXX target /usr/lib/x86_64-linux-gnu/hdf5/serial/libhdf5_cpp.so;/usr/lib/x86_64-linux-gnu/hdf5/serial/libhdf5.so;/usr/local/lib/libcrypto.so;/usr/lib/x86_64-linux-gnu/libcurl.so;/usr/lib/x86_64-linux-gnu/libpthread.a;/usr/lib/x86_64-linux-gnu/libsz.so;/usr/local/lib/libz.so;/usr/lib/x86_64-linux-gnu/libdl.a;/usr/lib/x86_64-linux-gnu/libm.so.
-- ==========================================
-- nonOpenSourceModules Build Configuration
-- ==========================================
-- Build type: Release
-- C++ standard: 20
-- CUDA toolkit: 13.1.115
-- HDF5 CXX libraries: /usr/lib/x86_64-linux-gnu/hdf5/serial/libhdf5_cpp.so;/usr/lib/x86_64-linux-gnu/hdf5/serial/libhdf5.so;/usr/local/lib/libcrypto.so;/usr/lib/x86_64-linux-gnu/libcurl.so;/usr/lib/x86_64-linux-gnu/libpthread.a;/usr/lib/x86_64-linux-gnu/libsz.so;/usr/local/lib/libz.so;/usr/lib/x86_64-linux-gnu/libdl.a;/usr/lib/x86_64-linux-gnu/libm.so
-- TensorRT libraries: /usr/local/lib/libnvinfer.so, /usr/local/lib/libnvonnxparser.so
-- ==========================================
cuMAC-CP: L2ADAPTER_LIBS=
-- Found PkgConfig: /usr/bin/pkg-config (found version "0.29.2")
-- Checking for one of the modules 'libdpdk'
-- Checking for one of the modules 'doca-gpunetio'
-- Found CURL: /usr/lib/x86_64-linux-gnu/libcurl.so (found version "7.81.0")
-- Found OpenSSL: /usr/lib/x86_64-linux-gnu/libcrypto.so (found suitable version "3.0.2", minimum required is "3.0.0") found components: Crypto SSL
-- Found ZLIB: /usr/local/lib/libz.so (found version "1.3.1.1")
-- Found httplib: /usr/local/include/httplib.h (found version "0.27.0")
-- Found OpenSSL: /usr/lib/x86_64-linux-gnu/libcrypto.so (found version "3.0.2")
=========================================================
Build nvipc for [x86_64] CMAKE_BUILD_TYPE=Release
NVIPC_CUDA_ENABLE=ON CUDAToolkit_VERSION=13.1.115
NVIPC_DPDK_ENABLE=OFF DPDK_VERSION=22.11.2510.2.1
NVIPC_DOCA_ENABLE=OFF DOCA_VERSION=3.2.1025
NVIPC_DOCA_GPUNETIO=OFF
NVIPC_GDRCPY_ENABLE=OFF
NVIPC_FMTLOG_ENABLE=ON
=========================================================
-- Found HDF5: /usr/lib/x86_64-linux-gnu/hdf5/serial/libhdf5.so;/usr/local/lib/libcrypto.so;/usr/lib/x86_64-linux-gnu/libcurl.so;/usr/lib/x86_64-linux-gnu/libpthread.a;/usr/lib/x86_64-linux-gnu/libsz.so;/usr/local/lib/libz.so;/usr/lib/x86_64-linux-gnu/libdl.a;/usr/lib/x86_64-linux-gnu/libm.so (found suitable version "1.10.7", minimum required is "1.10") found components: C
-- Found libsctp: /usr/lib/x86_64-linux-gnu/libsctp.so
-- including nvipc
-- including oran_utils
-- CMAKE_CURRENT_SOURCE_DIR is /opt/nvidia/cuBB/cuPHY-CP/gt_common_libs/oran_utils
-- including slot_comamnd
-- CMAKE_CURRENT_SOURCE_DIR is /opt/nvidia/cuBB/cuPHY-CP/gt_common_libs/slot_command
-- PROJECT_SOURCE_DIR is /opt/nvidia/cuBB/cuPHY-CP/gt_common_libs/nvIPC/include/
-- including perf_metrics
-- Linking perf_metrics with nvlog target
-- CMAKE_CURRENT_SOURCE_DIR is /opt/nvidia/cuBB/cuPHY-CP/gt_common_libs/perf_metrics
-- Checking for module 'libyang>=2.1.88'
-- Found libyang, version 3.13.5
-- LIBYANG version = 3.13.5
-- LIBYANG dir= /usr/local/lib
-- Checking for module 'libyang-cpp>=1.1.0'
-- Found libyang-cpp, version 4
-- LIBYANG cpp version = 4
-- LIBYANG cpp dir= /usr/local/lib
-- Using system protoc: /usr/local/bin/protoc
-- Using system grpc_cpp_plugin: /usr/local/bin/grpc_cpp_plugin
-- Using system grpc_python_plugin: /usr/local/bin/grpc_python_plugin
-- RU building with REPO
-- Setting CUBB_HOME to /opt/nvidia/cuBB
-- DOCA_PATH cmake variable is seen from aeril-fh-drive cmake file doca include dirs Includes: /opt/mellanox/doca/include;/usr/include/libnl3, Lib Dirs: /opt/mellanox/doca/lib/x86_64-linux-gnu Libs:doca_gpunetio Cuda Driver Lib: Cuda RT Lib:
-- DOCA GPU communication enabled
-- Setting CUBB_HOME to /opt/nvidia/cuBB
-- FH Gen Cmake DOCA Lib Dirs: /opt/mellanox/doca/lib/x86_64-linux-gnu
-- CUDA_LIBRARIES is
-- CUDA_INCLUDE_DIRS is
-- Setting CUBB_HOME to /opt/nvidia/cuBB
-- Found libdw: /usr/lib/x86_64-linux-gnu/libdw.so
-- Found libbfd: /usr/lib/x86_64-linux-gnu/libbfd.so
-- Found libdwarf: /usr/lib/x86_64-linux-gnu/libdwarf.so
-- Found Backward: /usr/local/lib/backward
-- Cuphydriver Cmake DOCA Lib Dirs: /opt/mellanox/doca/lib/x86_64-linux-gnu
-- Found nlohmann_json: /usr/lib/cmake/nlohmann_json/nlohmann_jsonConfig.cmake (found version "3.10.5")
-- Configuring E3 Agent ZMQ dependencies
-- Using ZMQ include: /usr/include
-- Using ZMQ library: zmq
-- including comp_decomp_lib
-- CMAKE_CURRENT_SOURCE_DIR is /opt/nvidia/cuBB/cuPHY-CP/compression_decompression/comp_decomp_lib
-- including comp_decomp_examples
-- Found HDF5: /usr/lib/x86_64-linux-gnu/hdf5/serial/libhdf5.so;/usr/local/lib/libcrypto.so;/usr/lib/x86_64-linux-gnu/libcurl.so;/usr/lib/x86_64-linux-gnu/libpthread.a;/usr/lib/x86_64-linux-gnu/libsz.so;/usr/local/lib/libz.so;/usr/lib/x86_64-linux-gnu/libdl.a;/usr/lib/x86_64-linux-gnu/libm.so;/usr/lib/x86_64-linux-gnu/hdf5/serial/libhdf5_cpp.so;/usr/lib/x86_64-linux-gnu/hdf5/serial/libhdf5.so;/usr/local/lib/libcrypto.so;/usr/lib/x86_64-linux-gnu/libcurl.so;/usr/lib/x86_64-linux-gnu/libpthread.a;/usr/lib/x86_64-linux-gnu/libsz.so;/usr/local/lib/libz.so;/usr/lib/x86_64-linux-gnu/libdl.a;/usr/lib/x86_64-linux-gnu/libm.so (found suitable version "1.10.7", minimum required is "1.10") found components: C CXX
-- TESTMAC: SOURCES=main.cpp;launch_pattern.cpp;test_mac_configs.cpp;test_mac.cpp;fapi_handler.cpp;fapi_validate.cpp;signal_handler.cpp;dummy.cu;cumac_pattern.cpp;cumac_handler.cpp;cumac_configs.cpp;cumac_validate.cpp;scf_fapi_handler.cpp
-- TESTMAC: L2ADAPTER_LIBS=scf_5g_fapi
-- Checking for module 'yaml-0.1'
-- Found yaml-0.1, version 0.2.5
-- tests includes order kernel test bench
-- Setting CUBB_HOME to /opt/nvidia/cuBB
-- Found HDF5: /usr/lib/x86_64-linux-gnu/hdf5/serial/libhdf5.so;/usr/local/lib/libcrypto.so;/usr/lib/x86_64-linux-gnu/libcurl.so;/usr/lib/x86_64-linux-gnu/libpthread.a;/usr/lib/x86_64-linux-gnu/libsz.so;/usr/local/lib/libz.so;/usr/lib/x86_64-linux-gnu/libdl.a;/usr/lib/x86_64-linux-gnu/libm.so (found suitable version "1.10.7", minimum required is "1.10") found components: C
-- Order Kernel test bench Cmake DOCA Lib Dirs: /opt/mellanox/doca/lib/x86_64-linux-gnu
-- Order Kernel test bench include: /opt/nvidia/cuBB/cuPHY-CP/scfl2adapter/lib/scf_5g_fapi
-- Order Kernel test bench include: /opt/nvidia/cuBB/cuPHY-CP/cuphydriver/include
-- tests includes DL C test bench
-- Setting CUBB_HOME to /opt/nvidia/cuBB
-- Configuring done (4.0s)
-- Generating done (0.3s)
-- Build files have been written to: /opt/nvidia/cuBB/build.x86_64
taskset: failed to parse CPU list:
[46/1075] Generating LUTs for CRC and Descrambling
Generate look-up tables for 3GPP NR CRC and descrambling:
/opt/nvidia/cuBB/build.x86_64/cuPHY/src/cuphy/LUTS
Opening '/opt/nvidia/cuBB/build.x86_64/cuPHY/src/cuphy/LUTS/G_CRC_16_P_LUT.h' for writing...
Opening '/opt/nvidia/cuBB/build.x86_64/cuPHY/src/cuphy/LUTS/G_CRC_24_A_P_LUT.h' for writing...
Opening '/opt/nvidia/cuBB/build.x86_64/cuPHY/src/cuphy/LUTS/G_CRC_24_B_P_LUT.h' for writing...
Opening '/opt/nvidia/cuBB/build.x86_64/cuPHY/src/cuphy/LUTS/GOLD_1_SEQ_LUT.h' for writing...
Opening '/opt/nvidia/cuBB/build.x86_64/cuPHY/src/cuphy/LUTS/GOLD_2_32_P_LUT.h' for writing...
[47/1075] Generating LUTs for PUCCH receiver Format 1
Generate look-up tables for PUCCH Receiver - Format 1
/opt/nvidia/cuBB/build.x86_64/cuPHY/src/cuphy/LUTS
[1073/1075] Linking CXX shared module pyaerial/_pycuphy.cpython-310-x86_64-linux-gnu.so
lto-wrapper: warning: using serial compilation of 26 LTRANS jobs
lto-wrapper: note: see the '-flto' option documentation for more information
Cleaning up pyaerial output directory
[1075/1075] Linking CXX executable cuPHY/test/dl_rate_matching/testDlRateMatching
Build completed successfully.安装 matlab 环境
bash
sudo apt update && sudo apt install -y unzip
wget https://ssd.mathworks.com/supportfiles/downloads/R2023a/Release/1/deployment_files/installer/complete/glnxa64/MATLAB_Runtime_R2023a_Update_1_glnxa64.zip
mkdir unzip && cd unzip
unzip ../MATLAB_Runtime_R2023a_Update_1_glnxa64.zip
sudo ./install -mode silent -agreeToLicense yes
cd .. && rm -rf MATLAB_Runtime_R2023a_Update_1_glnxa64.zip unzip
sudo apt install -y libxcomposite1 libnss3 libxrandr-dev libatk1.0-0 libatk-bridge2.0-0 libx11-xcb-dev libxcb-dri3-0 libxcursor-dev libxdamage-dev libxi-dev libdrm-dev libgbm-dev libasound-dev libcups2-dev libxtst-dev生成的log日志
生成 TV 文件
bash
cd ${cuBB_SDK}
sudo -H pip install 5GModel/aerial_mcore/aerial_pkg/dist/aerial_mcore-*.whl
cd ${cuBB_SDK}/5GModel/aerial_mcore/examples
source ../scripts/setup.sh
../scripts/gen_e2e_ota_tvs.sh
ls -lh GPU_test_input/
cp GPU_test_input/* ${cuBB_SDK}/testVectors//opt/nvidia/cuBB/testVectors 可以找到。
生成所有的TV 文件
注意：
1、运行安装python的模块，可以进行生成。
bash
cd ${cuBB_SDK}
sudo -H pip install 5GModel/aerial_mcore/aerial_pkg/dist/aerial_mcore-*.whl
cd ${cuBB_SDK}/5GModel/aerial_mcore/examples
source ../scripts/setup.sh
export REGRESSION_MODE=1
time python3 ./example_5GModel_regression.py allChannels
echo $?
ls -alF GPU_test_input/
du -h GPU_test_input/
实际测试结果
bash
Test PUSCH data detection performance:
TC# Nframe FRC Chan rxAnt SNR SNRoffset CFO delay nCB errCB CBer nTB errTB TBer Csi1Ber Csi2Ber cfoErr toErr sinrErr postSinrErr
------------------------------------------------------------------------------------------------------------------------------------------------------------------------
7016 1 G-FR1-A3-10 TDLB100-400-Low 2 -2.1 0.0 200 0.0 20 1 0.050 10 1 0.100 0.000 0.000 129 0.30 0.97 1.33
7001 1 G-FR1-A3-14 TDLB100-400-Low 2 -2.8 0.0 200 0.0 80 0 0.000 20 0 0.000 0.000 0.000 72 0.13 0.64 0.98
7002 1 G-FR1-A4-14 TDLC300-100-Low 2 10.2 0.0 200 0.0 240 1 0.004 20 1 0.050 0.000 0.000 18 0.17 1.56 1.39
7004 1 G-FR1-A3-14 TDLB100-400-Low 4 -5.8 0.0 200 0.0 80 1 0.013 20 1 0.050 0.000 0.000 46 0.12 0.96 1.46
7005 1 G-FR1-A4-14 TDLC300-100-Low 4 6.5 0.0 200 0.0 240 0 0.000 20 0 0.000 0.000 0.000 16 0.18 0.86 0.78
7003 1 G-FR1-A5-14 TDLA30-10-Low 2 13.0 0.0 200 0.0 320 0 0.000 20 0 0.000 0.000 0.000 1 0.07 0.65 1.14
7010 1 G-FR1-A3-28 TDLB100-400-Low 2 1.4 0.0 200 0.0 160 1 0.006 20 1 0.050 0.000 0.000 47 0.12 2.55 3.47
7006 1 G-FR1-A5-14 TDLA30-10-Low 4 9.0 0.0 200 0.0 320 0 0.000 20 0 0.000 0.000 0.000 2 0.07 0.72 0.55
7007 1 G-FR1-A3-14 TDLB100-400-Low 8 -8.7 0.0 200 0.0 80 0 0.000 20 0 0.000 0.000 0.000 20 0.13 1.72 2.25
7017 1 G-FR1-A4-10 TDLC300-100-Low 2 10.0 0.0 200 0.0 50 5 0.100 10 1 0.100 0.000 0.000 17 0.35 1.64 1.69
7008 1 G-FR1-A4-14 TDLC300-100-Low 8 3.2 0.0 200 0.0 240 0 0.000 20 0 0.000 0.000 0.000 7 0.17 0.44 0.88
7012 1 G-FR1-A3-28 TDLB100-400-Low 4 -2.2 0.0 200 0.0 160 0 0.000 20 0 0.000 0.000 0.000 20 0.12 1.86 2.03
7011 1 G-FR1-A4-28 TDLC300-100-Low 2 19.2 0.0 200 0.0 480 2 0.004 20 2 0.100 0.000 0.000 15 0.18 5.91 8.66
7022 1 G-FR1-A3-10 TDLB100-400-Low 8 -8.5 0.0 200 0.0 20 0 0.000 10 0 0.000 0.000 0.000 75 0.33 1.04 1.57
7018 1 G-FR1-A5-10 TDLA30-10-Low 2 12.4 0.0 200 0.0 60 10 0.167 10 2 0.200 0.000 0.000 5 0.26 2.57 2.05
7009 1 G-FR1-A5-14 TDLA30-10-Low 8 5.8 0.0 200 0.0 320 0 0.000 20 0 0.000 0.000 0.000 2 0.07 1.36 1.90
7027 1 G-FR1-A3-24 TDLB100-400-Low 4 -1.8 0.0 200 0.0 40 0 0.000 10 0 0.000 0.000 0.000 76 0.31 2.57 2.77
7013 1 G-FR1-A4-28 TDLC300-100-Low 4 11.6 0.0 200 0.0 480 0 0.000 20 0 0.000 0.000 0.000 6 0.17 3.18 3.76
7019 1 G-FR1-A3-10 TDLB100-400-Low 4 -5.5 0.0 200 0.0 20 1 0.050 10 1 0.100 0.000 0.000 56 0.31 0.61 0.73
7023 1 G-FR1-A4-10 TDLC300-100-Low 8 3.0 0.0 200 0.0 50 0 0.000 10 0 0.000 0.000 0.000 7 0.34 0.50 0.91
7014 1 G-FR1-A3-28 TDLB100-400-Low 8 -5.2 0.0 200 0.0 160 0 0.000 20 0 0.000 0.000 0.000 16 0.13 1.38 1.23
7020 1 G-FR1-A4-10 TDLC300-100-Low 4 6.2 0.0 200 0.0 50 3 0.060 10 2 0.200 0.000 0.000 18 0.36 0.99 0.80
7028 1 G-FR1-A4-24 TDLC300-100-Low 4 11.1 0.0 200 0.0 100 0 0.000 10 0 0.000 0.000 0.000 7 0.34 2.82 3.50
7021 1 G-FR1-A5-10 TDLA30-10-Low 4 8.6 0.0 200 0.0 60 3 0.050 10 2 0.200 0.000 0.000 1 0.25 1.22 0.67
7024 1 G-FR1-A5-10 TDLA30-10-Low 8 5.5 0.0 200 0.0 60 0 0.000 10 0 0.000 0.000 0.000 3 0.25 1.29 1.82
7025 1 G-FR1-A3-24 TDLB100-400-Low 2 2.1 0.0 200 0.0 40 1 0.025 10 1 0.100 0.000 0.000 43 0.32 3.81 4.88
7015 1 G-FR1-A4-28 TDLC300-100-Low 8 7.1 0.0 200 0.0 480 0 0.000 20 0 0.000 0.000 0.000 5 0.18 3.14 3.08
7029 1 G-FR1-A3-24 TDLB100-400-Low 8 -5.3 0.0 200 0.0 40 0 0.000 10 0 0.000 0.000 0.000 53 0.30 1.83 1.63
7026 1 G-FR1-A4-24 TDLC300-100-Low 2 18.3 0.0 200 0.0 100 6 0.060 10 3 0.300 0.000 0.000 17 0.36 4.59 7.31
7030 1 G-FR1-A4-24 TDLC300-100-Low 8 6.9 0.0 200 0.0 100 0 0.000 10 0 0.000 0.000 0.000 2 0.35 3.16 3.02
------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Total TC = 30, PASS = 30, FAIL = 0
Test PUSCH UCI detection performance:
TC# Nframe FRC Chan rxAnt SNR SNRoffset CFO delay nCB errCB CBer nTB errTB TBer Csi1Ber Csi2Ber cfoErr toErr sinrErr postSinrErr
------------------------------------------------------------------------------------------------------------------------------------------------------------------------
7051 1 G-FR1-A4-11 TDLC300-100-Low 2 5.4 0.0 200 0.0 40 40 1.000 20 20 1.000 0.000 0.000 24 0.28 3.58 3.05
7052 1 G-FR1-A4-11 TDLC300-100-Low 2 4.3 0.0 200 0.0 40 40 1.000 20 20 1.000 0.000 0.000 24 0.17 0.79 0.74
7053 1 G-FR1-A4-11 TDLC300-100-Low 2 -0.2 0.0 200 0.0 40 40 1.000 20 20 1.000 0.000 0.000 31 0.16 1.17 1.35
7054 1 G-FR1-A4-11 TDLC300-100-Low 2 2.4 0.0 200 0.0 40 40 1.000 20 20 1.000 0.000 0.000 33 0.19 2.54 2.16
------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Total TC = 4, PASS = 4, FAIL = 0
Test PUSCH transform precoding detection performance:
TC# Nframe FRC Chan rxAnt SNR SNRoffset CFO delay nCB errCB CBer nTB errTB TBer Csi1Ber Csi2Ber cfoErr toErr sinrErr postSinrErr
------------------------------------------------------------------------------------------------------------------------------------------------------------------------
7057 1 G-FR1-A3-32 TDLB100-400-Low 8 -8.4 0.0 200 0.0 20 2 0.100 20 2 0.100 0.000 0.000 34 0.52 1.10 1.53
7055 1 G-FR1-A3-32 TDLB100-400-Low 2 -2.5 0.0 200 0.0 20 3 0.150 20 3 0.150 0.000 0.000 124 0.53 1.26 1.59
7056 1 G-FR1-A3-32 TDLB100-400-Low 4 -5.7 0.0 200 0.0 20 6 0.300 20 6 0.300 0.000 0.000 57 0.54 1.05 1.11
7058 1 G-FR1-A3-31 TDLB100-400-Low 2 -2.4 0.0 200 0.0 10 2 0.200 10 2 0.200 0.000 0.000 176 1.00 1.18 2.26
7059 1 G-FR1-A3-31 TDLB100-400-Low 4 -5.7 0.0 200 0.0 10 5 0.500 10 5 0.500 0.000 0.000 61 1.04 1.52 1.52
7060 1 G-FR1-A3-31 TDLB100-400-Low 8 -8.5 0.0 200 0.0 10 1 0.100 10 1 0.100 0.000 0.000 70 1.02 1.07 1.68
------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Total TC = 6, PASS = 6, FAIL = 0
Test PUSCH 1e-5 BLER detection performance:
TC# Nframe FRC Chan rxAnt SNR SNRoffset CFO delay nCB errCB CBer nTB errTB TBer Csi1Ber Csi2Ber cfoErr toErr sinrErr postSinrErr
------------------------------------------------------------------------------------------------------------------------------------------------------------------------
7101 1 G-FR1-A3A-3 AWGN 2 -5.4 0.0 200 0.0 20 0 0.000 20 0 0.000 0.000 0.000 53 0.03 0.53 1.04
------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Total TC = 1, PASS = 1, FAIL = 0
Test PUSCH data detection performance:
TC# Nframe FRC Chan rxAnt SNR SNRoffset CFO delay nCB errCB CBer nTB errTB TBer Csi1Ber Csi2Ber cfoErr toErr sinrErr postSinrErr
------------------------------------------------------------------------------------------------------------------------------------------------------------------------
7992 1 L1T1M00B024 TDLC300-100-Low 4 -8.5 0.0 0 0.0 20 1 0.050 20 1 0.050 0.000 0.000 11 0.21 1.80 1.52
------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Total TC = 1, PASS = 1, FAIL = 0
Test mMIMO SRS/BFW/PUSCH performance:
TC# Nframe FRC Chan rxAnt SNR SNRoffset CFO delay nCB errCB CBer nTB errTB TBer Csi1Ber Csi2Ber cfoErr toErr sinrErr postSinrErr
------------------------------------------------------------------------------------------------------------------------------------------------------------------------
7701 1 G-FR1-A4-28 AWGN 4 -4.6 0.0 0 0.0 440 10 0.023 20 8 0.400 0.000 0.000 2 0.00 13.14 1.37
7716 1 G-FR1-A4-28 CDLC300-100 4 -6.2 0.0 0 0.0 440 10 0.023 20 4 0.200 0.000 0.000 72 0.15 15.57 0.97
7717 1 G-FR1-A4-14 AWGN 4 -7.6 0.0 0 0.0 440 6 0.014 40 6 0.150 0.000 0.000 3 0.00 16.17 1.64
7732 1 G-FR1-A4-14 CDLC300-100 4 -9.0 0.0 0 0.0 440 56 0.127 40 10 0.250 0.000 0.000 72 0.15 18.40 3.60
7748 1 G-FR1-B4-14 CDLC300-100 4 -5.6 0.0 0 0.0 1440 329 0.228 160 46 0.287 0.000 0.000 45 0.19 9.25 1.72
7733 1 G-FR1-B4-14 AWGN 4 -5.8 0.0 0 0.0 1440 40 0.028 160 38 0.237 0.000 0.000 2 0.00 12.06 3.38
------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Total TC = 6, PASS = 6, FAIL = 0
Test PRACH false detection rate:
TC# Nframe mu cfg root zone prmb Nant N_PRB channelType CFO N_nc SNR SNRoffset total false miss
----------------------------------------------------------------------------------------------------------------
5013 1 0 217 0 11 0 2 106 AWGN 0 1 -16.8 0.0 10 0 0
5014 1 0 217 0 11 0 2 106 TDLC300-100-Low 400 1 -8.8 0.0 10 0 0
5015 1 0 217 0 11 0 4 106 AWGN 0 1 -19.0 0.0 10 0 0
5016 1 0 217 0 11 0 4 106 TDLC300-100-Low 400 1 -13.8 0.0 10 0 0
5007 1 1 27 22 1 32 2 273 AWGN 0 1 -14.5 0.0 10 0 0
5001 1 1 217 0 14 0 2 273 AWGN 0 1 -16.5 0.0 10 0 0
5008 1 1 27 22 1 32 2 273 TDLC300-100-Low 400 1 -6.6 0.0 10 0 0
5002 1 1 217 0 14 0 2 273 TDLC300-100-Low 400 1 -9.9 0.0 10 0 0
5003 1 1 217 0 14 0 4 273 AWGN 0 1 -19.0 0.0 10 0 0
5009 1 1 27 22 1 32 4 273 AWGN 0 1 -16.7 0.0 10 0 0
5023 1 0 27 22 1 32 8 106 AWGN 0 1 -18.9 0.0 10 0 0
5017 1 0 217 0 11 0 8 106 AWGN 0 1 -21.2 0.0 10 0 0
5019 1 0 27 22 1 32 2 106 AWGN 0 1 -14.5 0.0 10 0 0
5010 1 1 27 22 1 32 4 273 TDLC300-100-Low 400 1 -11.9 0.0 10 0 0
5004 1 1 217 0 14 0 4 273 TDLC300-100-Low 400 1 -14.5 0.0 10 0 0
5024 1 0 27 22 1 32 8 106 TDLC300-100-Low 400 1 -15.8 0.0 10 0 0
5018 1 0 217 0 11 0 8 106 TDLC300-100-Low 400 1 -17.3 0.0 10 0 0
5020 1 0 27 22 1 32 2 106 TDLC300-100-Low 400 1 -6.6 0.0 10 0 0
5011 1 1 27 22 1 32 8 273 AWGN 0 1 -18.9 0.0 10 0 0
5005 1 1 217 0 14 0 8 273 AWGN 0 1 -21.1 0.0 10 0 0
5022 1 0 27 22 1 32 4 106 TDLC300-100-Low 400 1 -11.9 0.0 10 0 0
5006 1 1 217 0 14 0 8 273 TDLC300-100-Low 400 1 -17.6 0.0 10 0 0
5012 1 1 27 22 1 32 8 273 TDLC300-100-Low 400 1 -15.8 0.0 10 0 0
5021 1 0 27 22 1 32 4 106 AWGN 0 1 -16.7 0.0 10 0 0
----------------------------------------------------------------------------------------------------------------
Total TC = 24, PASS = 24, FAIL = 0
Elapsed time is 7.524163 seconds.
Test PRACH miss detection rate:
TC# Nframe mu cfg root zone prmb Nant N_PRB channelType CFO N_nc SNR SNRoffset total false miss
----------------------------------------------------------------------------------------------------------------
5013 1 0 217 0 11 0 2 106 AWGN 0 1 -16.8 0.0 10 0 0
5014 1 0 217 0 11 0 2 106 TDLC300-100-Low 400 1 -8.8 0.0 10 0 0
5015 1 0 217 0 11 0 4 106 AWGN 0 1 -19.0 0.0 10 0 0
5016 1 0 217 0 11 0 4 106 TDLC300-100-Low 400 1 -13.8 0.0 10 0 0
5001 1 1 217 0 14 0 2 273 AWGN 0 1 -16.5 0.0 10 0 0
5007 1 1 27 22 1 32 2 273 AWGN 0 1 -14.5 0.0 10 0 0
5002 1 1 217 0 14 0 2 273 TDLC300-100-Low 400 1 -9.9 0.0 10 0 0
5008 1 1 27 22 1 32 2 273 TDLC300-100-Low 400 1 -6.6 0.0 10 0 0
5003 1 1 217 0 14 0 4 273 AWGN 0 1 -19.0 0.0 10 0 0
5019 1 0 27 22 1 32 2 106 AWGN 0 1 -14.5 0.0 10 0 0
5023 1 0 27 22 1 32 8 106 AWGN 0 1 -18.9 0.0 10 0 0
5009 1 1 27 22 1 32 4 273 AWGN 0 1 -16.7 0.0 10 0 0
5018 1 0 217 0 11 0 8 106 TDLC300-100-Low 400 1 -17.3 0.0 10 0 0
5004 1 1 217 0 14 0 4 273 TDLC300-100-Low 400 1 -14.5 0.0 10 0 0
5017 1 0 217 0 11 0 8 106 AWGN 0 1 -21.2 0.0 10 0 0
5010 1 1 27 22 1 32 4 273 TDLC300-100-Low 400 1 -11.9 0.0 10 0 0
5020 1 0 27 22 1 32 2 106 TDLC300-100-Low 400 1 -6.6 0.0 10 0 0
5024 1 0 27 22 1 32 8 106 TDLC300-100-Low 400 1 -15.8 0.0 10 0 0
5005 1 1 217 0 14 0 8 273 AWGN 0 1 -21.1 0.0 10 0 0
5021 1 0 27 22 1 32 4 106 AWGN 0 1 -16.7 0.0 10 0 0
5011 1 1 27 22 1 32 8 273 AWGN 0 1 -18.9 0.0 10 0 0
5006 1 1 217 0 14 0 8 273 TDLC300-100-Low 400 1 -17.6 0.0 10 0 0
5022 1 0 27 22 1 32 4 106 TDLC300-100-Low 400 1 -11.9 0.0 10 0 0
5012 1 1 27 22 1 32 8 273 TDLC300-100-Low 400 1 -15.8 0.0 10 0 0
----------------------------------------------------------------------------------------------------------------
Total TC = 24, PASS = 24, FAIL = 0
Elapsed time is 8.738853 seconds.
Test PUCCH format-0 ACK false detection:
TC# Nframe mu PRB Chan rxAnt nSym SNR SNRoffset CFO delay total error Perr taErr snrErr
----------------------------------------------------------------------------------------------------------------------------
6008 1 0 106 TDLC300-100-Low 2 2 3.3 0.0 200 0.0 500 1 0.0020 0.00 3.30
6007 1 0 106 TDLC300-100-Low 2 1 9.3 0.0 200 0.0 500 2 0.0040 0.00 9.30
6010 1 0 106 TDLC300-100-Low 4 2 -0.8 0.0 200 0.0 500 0 0.0000 NaN 0.80
6009 1 0 106 TDLC300-100-Low 4 1 3.2 0.0 200 0.0 500 0 0.0000 0.00 3.20
6012 1 0 106 TDLC300-100-Low 8 2 -4.0 0.0 200 0.0 500 2 0.0040 0.00 4.00
6011 1 0 106 TDLC300-100-Low 8 1 -1.1 0.0 200 0.0 500 2 0.0040 0.00 1.10
6001 1 1 273 TDLC300-100-Low 2 1 9.2 0.0 200 0.0 1000 1 0.0010 0.00 9.20
6002 1 1 273 TDLC300-100-Low 2 2 3.5 0.0 200 0.0 1000 1 0.0010 0.00 3.50
6004 1 1 273 TDLC300-100-Low 4 2 -0.8 0.0 200 0.0 1000 1 0.0010 0.00 0.80
6003 1 1 273 TDLC300-100-Low 4 1 3.3 0.0 200 0.0 1000 0 0.0000 0.00 3.30
6006 1 1 273 TDLC300-100-Low 8 2 -3.9 0.0 200 0.0 1000 6 0.0060 0.00 3.90
6005 1 1 273 TDLC300-100-Low 8 1 -1.0 0.0 200 0.0 1000 0 0.0000 0.00 1.00
----------------------------------------------------------------------------------------------------------------------------
Total TC = 12, PASS = 12, FAIL = 0
Elapsed time is 7.835137 seconds.
Test PUCCH format-0 NACK to ACK detection:
TC# Nframe mu PRB Chan rxAnt nSym SNR SNRoffset CFO delay total error Perr taErr snrErr
----------------------------------------------------------------------------------------------------------------------------
6008 1 0 106 TDLC300-100-Low 2 2 3.3 0.0 200 0.0 500 0 0.0000 0.00 3.30
6007 1 0 106 TDLC300-100-Low 2 1 9.3 0.0 200 0.0 500 0 0.0000 0.00 9.30
6009 1 0 106 TDLC300-100-Low 4 1 3.2 0.0 200 0.0 500 0 0.0000 0.00 3.20
6010 1 0 106 TDLC300-100-Low 4 2 -0.8 0.0 200 0.0 500 0 0.0000 0.00 0.80
6012 1 0 106 TDLC300-100-Low 8 2 -4.0 0.0 200 0.0 500 0 0.0000 0.00 4.00
6011 1 0 106 TDLC300-100-Low 8 1 -1.1 0.0 200 0.0 500 0 0.0000 0.00 1.10
6001 1 1 273 TDLC300-100-Low 2 1 9.2 0.0 200 0.0 1000 0 0.0000 0.00 9.20
6002 1 1 273 TDLC300-100-Low 2 2 3.5 0.0 200 0.0 1000 0 0.0000 0.00 3.50
6003 1 1 273 TDLC300-100-Low 4 1 3.3 0.0 200 0.0 1000 0 0.0000 0.00 3.30
6004 1 1 273 TDLC300-100-Low 4 2 -0.8 0.0 200 0.0 1000 0 0.0000 0.00 0.80
6005 1 1 273 TDLC300-100-Low 8 1 -1.0 0.0 200 0.0 1000 0 0.0000 0.00 1.00
6006 1 1 273 TDLC300-100-Low 8 2 -3.9 0.0 200 0.0 1000 0 0.0000 0.00 3.90
----------------------------------------------------------------------------------------------------------------------------
Total TC = 12, PASS = 12, FAIL = 0
Elapsed time is 8.194705 seconds.
Test PUCCH format-0 ACK missed detection rate:
TC# Nframe mu PRB Chan rxAnt nSym SNR SNRoffset CFO delay total error Perr taErr snrErr
----------------------------------------------------------------------------------------------------------------------------
6008 1 0 106 TDLC300-100-Low 2 2 3.3 0.0 200 0.0 500 1 0.0020 0.00 3.30
6007 1 0 106 TDLC300-100-Low 2 1 9.3 0.0 200 0.0 500 0 0.0000 0.00 9.30
6009 1 0 106 TDLC300-100-Low 4 1 3.2 0.0 200 0.0 500 0 0.0000 0.00 3.20
6010 1 0 106 TDLC300-100-Low 4 2 -0.8 0.0 200 0.0 500 0 0.0000 0.00 0.80
6011 1 0 106 TDLC300-100-Low 8 1 -1.1 0.0 200 0.0 500 0 0.0000 0.00 1.10
6012 1 0 106 TDLC300-100-Low 8 2 -4.0 0.0 200 0.0 500 0 0.0000 0.00 4.00
6001 1 1 273 TDLC300-100-Low 2 1 9.2 0.0 200 0.0 1000 4 0.0040 0.00 9.20
6002 1 1 273 TDLC300-100-Low 2 2 3.5 0.0 200 0.0 1000 7 0.0070 0.00 3.50
6003 1 1 273 TDLC300-100-Low 4 1 3.3 0.0 200 0.0 1000 1 0.0010 0.00 3.30
6004 1 1 273 TDLC300-100-Low 4 2 -0.8 0.0 200 0.0 1000 4 0.0040 0.00 0.80
6005 1 1 273 TDLC300-100-Low 8 1 -1.0 0.0 200 0.0 1000 5 0.0050 0.00 1.00
6006 1 1 273 TDLC300-100-Low 8 2 -3.9 0.0 200 0.0 1000 1 0.0010 0.00 3.90
----------------------------------------------------------------------------------------------------------------------------
Total TC = 12, PASS = 12, FAIL = 0
Elapsed time is 8.257739 seconds.
Test PUCCH format-1 ACK false detection:
TC# Nframe mu PRB Chan rxAnt nSym SNR SNRoffset CFO delay total error Perr taErr snrErr
----------------------------------------------------------------------------------------------------------------------------
6105 1 0 106 TDLC300-100-Low 4 14 -8.4 0.0 200 0.0 1000 0 0.0000 NaN 41.69
6106 1 0 106 TDLC300-100-Low 8 14 -11.4 0.0 200 0.0 1000 0 0.0000 NaN 39.93
6111 1 0 106 TDLC300-100-Low 4 14 -8.5 0.0 200 0.0 1000 1 0.0010 3.04 41.32
6112 1 0 106 TDLC300-100-Low 8 14 -11.5 0.0 200 0.0 1000 0 0.0000 NaN 39.37
6107 1 1 273 TDLC300-100-Low 2 14 -4.2 0.0 200 0.0 2000 1 0.0005 6.80 43.90
6108 1 1 273 TDLC300-100-Low 4 14 -8.3 0.0 200 0.0 2000 1 0.0005 11.88 41.32
6101 1 1 273 TDLC300-100-Low 2 14 -3.5 0.0 200 0.0 2000 0 0.0000 9.68 46.20
6102 1 1 273 TDLC300-100-Low 4 14 -8.0 0.0 200 0.0 2000 2 0.0010 6.76 40.53
6103 1 1 273 TDLC300-100-Low 8 14 -11.3 0.0 200 0.0 2000 0 0.0000 NaN 38.84
6109 1 1 273 TDLC300-100-Low 8 14 -11.4 0.0 200 0.0 2000 0 0.0000 NaN 37.73
6104 1 0 106 TDLC300-100-Low 2 14 -3.6 0.0 200 0.0 1000 3 0.0030 16.22 45.91
6110 1 0 106 TDLC300-100-Low 2 14 -5.0 0.0 200 0.0 1000 0 0.0000 NaN 44.97
----------------------------------------------------------------------------------------------------------------------------
Total TC = 12, PASS = 12, FAIL = 0
Elapsed time is 8.819213 seconds.
Test PUCCH format-1 NACK to ACK detection:
TC# Nframe mu PRB Chan rxAnt nSym SNR SNRoffset CFO delay total error Perr taErr snrErr
----------------------------------------------------------------------------------------------------------------------------
6105 1 0 106 TDLC300-100-Low 4 14 -8.4 0.0 200 0.0 1000 0 0.0000 5.96 9.55
6106 1 0 106 TDLC300-100-Low 8 14 -11.4 0.0 200 0.0 1000 0 0.0000 6.06 7.58
6101 1 1 273 TDLC300-100-Low 2 14 -3.5 0.0 200 0.0 2000 0 0.0000 1.10 4.40
6102 1 1 273 TDLC300-100-Low 4 14 -8.0 0.0 200 0.0 2000 1 0.0005 2.60 7.23
6103 1 1 273 TDLC300-100-Low 8 14 -11.3 0.0 200 0.0 2000 0 0.0000 2.95 6.96
6104 1 0 106 TDLC300-100-Low 2 14 -3.6 0.0 200 0.0 1000 0 0.0000 2.32 4.02
----------------------------------------------------------------------------------------------------------------------------
Total TC = 6, PASS = 6, FAIL = 0
Elapsed time is 10.687066 seconds.
Test PUCCH format-1 ACK missed detection rate:
TC# Nframe mu PRB Chan rxAnt nSym SNR SNRoffset CFO delay total error Perr taErr snrErr
----------------------------------------------------------------------------------------------------------------------------
6111 1 0 106 TDLC300-100-Low 4 14 -8.5 0.0 200 0.0 1000 0 0.0000 5.73 9.03
6112 1 0 106 TDLC300-100-Low 8 14 -11.5 0.0 200 0.0 1000 0 0.0000 6.26 9.46
6107 1 1 273 TDLC300-100-Low 2 14 -4.2 0.0 200 0.0 2000 0 0.0000 1.31 3.21
6108 1 1 273 TDLC300-100-Low 4 14 -8.3 0.0 200 0.0 2000 0 0.0000 2.54 6.93
6109 1 1 273 TDLC300-100-Low 8 14 -11.4 0.0 200 0.0 2000 0 0.0000 2.71 7.38
6110 1 0 106 TDLC300-100-Low 2 14 -5.0 0.0 200 0.0 1000 2 0.0020 3.38 4.70
----------------------------------------------------------------------------------------------------------------------------
Total TC = 6, PASS = 6, FAIL = 0
Elapsed time is 10.719178 seconds.
Test PUCCH format-2 ACK false detection:
TC# Nframe mu PRB Chan rxAnt nSym SNR SNRoffset CFO delay total error Perr taErr snrErr
----------------------------------------------------------------------------------------------------------------------------
6205 1 0 106 TDLC300-100-Low 4 1 0.3 0.0 200 0.0 200 0 0.0000 NaN 5.86
6201 1 1 273 TDLC300-100-Low 2 1 5.7 0.0 200 0.0 400 0 0.0000 NaN 11.22
6206 1 0 106 TDLC300-100-Low 8 1 -3.5 0.0 200 0.0 200 0 0.0000 NaN 1.95
6202 1 1 273 TDLC300-100-Low 4 1 0.4 0.0 200 0.0 400 0 0.0000 NaN 5.77
6203 1 1 273 TDLC300-100-Low 8 1 -3.3 0.0 200 0.0 400 0 0.0000 NaN 2.12
6204 1 0 106 TDLC300-100-Low 2 1 5.9 0.0 200 0.0 200 1 0.0050 1.03 11.51
----------------------------------------------------------------------------------------------------------------------------
Total TC = 6, PASS = 6, FAIL = 0
Elapsed time is 7.573862 seconds.
Test PUCCH format-2 ACK missed detection rate:
TC# Nframe mu PRB Chan rxAnt nSym SNR SNRoffset CFO delay total error Perr taErr snrErr
----------------------------------------------------------------------------------------------------------------------------
6205 1 0 106 TDLC300-100-Low 4 1 0.3 0.0 200 0.0 200 4 0.0200 1.48 1.93
6201 1 1 273 TDLC300-100-Low 2 1 5.7 0.0 200 0.0 400 0 0.0000 0.40 2.52
6206 1 0 106 TDLC300-100-Low 8 1 -3.5 0.0 200 0.0 200 0 0.0000 1.72 2.10
6202 1 1 273 TDLC300-100-Low 4 1 0.4 0.0 200 0.0 400 0 0.0000 0.75 1.63
6203 1 1 273 TDLC300-100-Low 8 1 -3.3 0.0 200 0.0 400 0 0.0000 1.14 2.01
6204 1 0 106 TDLC300-100-Low 2 1 5.9 0.0 200 0.0 200 0 0.0000 1.14 2.75
----------------------------------------------------------------------------------------------------------------------------
Total TC = 6, PASS = 6, FAIL = 0
Elapsed time is 7.661030 seconds.
Test PUCCH format-2 UCI BLER:
TC# Nframe mu PRB Chan rxAnt nSym SNR SNRoffset CFO delay total error Perr taErr snrErr
----------------------------------------------------------------------------------------------------------------------------
6214 1 0 106 TDLC300-100-Low 2 2 1.2 0.0 200 0.0 50 0 0.0000 1.12 1.74
6215 1 0 106 TDLC300-100-Low 4 2 -3.2 0.0 200 0.0 50 0 0.0000 1.45 2.45
6216 1 0 106 TDLC300-100-Low 8 2 -6.8 0.0 200 0.0 50 1 0.0200 3.53 3.44
6211 1 1 273 TDLC300-100-Low 2 2 0.3 0.0 200 0.0 100 0 0.0000 1.08 1.83
6212 1 1 273 TDLC300-100-Low 4 2 -3.4 0.0 200 0.0 100 0 0.0000 1.43 1.57
6213 1 1 273 TDLC300-100-Low 8 2 -5.9 0.0 200 0.0 100 0 0.0000 1.10 3.25
----------------------------------------------------------------------------------------------------------------------------
Total TC = 6, PASS = 6, FAIL = 0
Elapsed time is 7.898380 seconds.
Test PUCCH format-3 UCI BLER:
TC# Nframe mu PRB Chan rxAnt nSym SNR SNRoffset CFO delay total error Perr taErr snrErr
----------------------------------------------------------------------------------------------------------------------------
6317 1 0 106 TDLC300-100-Low 2 4 2.0 0.0 200 0.0 50 0 0.0000 0.67 2.45
6312 1 0 106 TDLC300-100-Low 2 14 -0.1 0.0 200 0.0 50 0 0.0000 0.84 2.20
6313 1 0 106 TDLC300-100-Low 4 14 -3.8 0.0 200 0.0 50 0 0.0000 0.99 3.23
6311 1 0 106 TDLC300-100-Low 2 14 0.3 0.0 200 0.0 50 0 0.0000 0.92 2.34
6318 1 0 106 TDLC300-100-Low 4 4 -2.5 0.0 200 0.0 50 0 0.0000 0.55 2.65
6319 1 0 106 TDLC300-100-Low 8 4 -6.2 0.0 200 0.0 50 0 0.0000 1.09 1.41
6307 1 1 273 TDLC300-100-Low 2 4 1.5 0.0 200 0.0 100 0 0.0000 0.30 1.89
6302 1 1 273 TDLC300-100-Low 2 14 0.1 0.0 200 0.0 100 0 0.0000 0.37 3.39
6301 1 1 273 TDLC300-100-Low 2 14 0.9 0.0 200 0.0 100 0 0.0000 0.41 2.17
6308 1 1 273 TDLC300-100-Low 4 4 -3.0 0.0 200 0.0 100 0 0.0000 0.40 1.34
6303 1 1 273 TDLC300-100-Low 4 14 -3.5 0.0 200 0.0 100 0 0.0000 0.54 2.80
6304 1 1 273 TDLC300-100-Low 4 14 -4.2 0.0 200 0.0 100 0 0.0000 0.51 3.02
6316 1 0 106 TDLC300-100-Low 8 14 -7.7 0.0 200 0.0 50 0 0.0000 1.25 4.44
6309 1 1 273 TDLC300-100-Low 8 4 -6.2 0.0 200 0.0 100 0 0.0000 0.49 2.43
6306 1 1 273 TDLC300-100-Low 8 14 -7.7 0.0 200 0.0 100 0 0.0000 0.67 4.35
6305 1 1 273 TDLC300-100-Low 8 14 -6.8 0.0 200 0.0 100 0 0.0000 0.62 3.95
6314 1 0 106 TDLC300-100-Low 4 14 -4.0 0.0 200 0.0 50 0 0.0000 0.89 3.40
6315 1 0 106 TDLC300-100-Low 8 14 -6.9 0.0 200 0.0 50 0 0.0000 1.21 4.46
----------------------------------------------------------------------------------------------------------------------------
Total TC = 18, PASS = 18, FAIL = 0
Elapsed time is 11.136041 seconds.
Test mMIMO SRS/BFW/PDSCH performance:
TC# Nframe FRC Chan rxAnt SNR SNRoffset CFO delay nCB errCB CBer nTB errTB TBer
-----------------------------------------------------------------------------------------------------------------------
3704 1 G-FR1-A4-28 CDLA30-10 4 -5.0 0.0 0 0.0 480 0 0.000 20 0 0.000
3720 1 G-FR1-A4-14 CDLA30-10 4 -4.4 0.0 0 0.0 480 0 0.000 40 0 0.000
3750 1 G-FR1-B4-14 AWGN 4 -1.8 0.0 0 0.0 3200 5 0.002 320 5 0.016
3736 1 G-FR1-B4-14 CDLA30-10 4 -2.6 0.0 0 0.0 1600 420 0.263 160 48 0.300
-----------------------------------------------------------------------------------------------------------------------
Total TC = 4, PASS = 4, FAIL = 0
Channel Compliance_Test Error CUPHY_Test_Vector FAPI_Test_Vector Error Performance_Test Fail
------------------------------------------------------------------------------
SSB 44 0 49 49 0 0 0
PDCCH 82 0 95 95 0 0 0
PDSCH 469 0 493 493 0 4 0
CSIRS 77 0 103 103 0 0 0
DLMIX 0 0 1710 10506 0 0 0
PRACH 71 0 71 71 0 48 0
PUCCH 543 0 543 543 0 96 0
PUSCH 648 0 670 670 0 48 0
SRS 212 0 212 212 0 0 0
SIMPLEX 100 0 100 100 0 0 0
ULMIX 0 0 1224 6503 0 0 0
BFW 162 0 162 162 0 0 0
------------------------------------------------------------------------------
Total 2408 0 5432 19507 0 196 0
Total time for runRegression is 12733 seconds
real 212m20.483s
user 1523m40.357s
sys 147m48.082s结果大小
bash
430G GPU_test_input/服务器配置推荐
128G内存
CPU越多越好
SSD至少 480G🧑⚕️
