若依前后端分离版学习笔记（二十）——实现滑块验证码（vue3）

参考官方文档实现

一、后端实现

1.1 新增依赖

在ruoyi-framework\pom.xml中新增依赖

<!-- 滑块验证码  -->
<dependency>
    <groupId>com.github.anji-plus</groupId>
    <artifactId>captcha-spring-boot-starter</artifactId>
    <version>1.2.7</version>
</dependency>
<!-- 原有的验证码kaptcha依赖不需要可以删除  -->

1.2 新增yml配置

在application.yml中加入aj-captcha配置

# 滑块验证码
aj:
  captcha:
    # 缓存类型
    cache-type: redis
    # blockPuzzle 滑块 clickWord 文字点选  default默认两者都实例化
    type: blockPuzzle
    # 右下角显示字
    water-mark: ruoyi.vip
    # 校验滑动拼图允许误差偏移量(默认5像素)
    slip-offset: 5
    # aes加密坐标开启或者禁用(true|false)
    aes-status: true
    # 滑动干扰项(0/1/2)
    interference-options: 2

在ruoyi-admin\src\main\resources\META-INF\services下创建文件com.anji.captcha.service.CaptchaCacheService并写入内容

com.ruoyi.framework.web.service.CaptchaRedisService

这里注意文件路径一定要对好，否则扫不到CaptchaRedisService，当生成滑块验证码时会发生空指针报错

1.3 配置匿名访问

在SecurityConfig中设置httpSecurity配置匿名访问（可不通过身份验证直接访问）

.antMatchers("/login", "/captcha/get", "/captcha/check").permitAll()

1.4 修改相关类

1.移除不需要的类

ruoyi-admin\com\ruoyi\web\controller\common\CaptchaController.java
ruoyi-framework\com\ruoyi\framework\config\CaptchaConfig.java
ruoyi-framework\com\ruoyi\framework\config\KaptchaTextCreator.java

我这里直接注释掉

2.更改登录方法

修改ruoyi-admin\com\ruoyi\web\controller\system\SysLoginController.java

/**
     * 登录方法
     *
     * @param loginBody 登录信息
     * @return 结果
     */
    @PostMapping("/login")
    public AjaxResult login(@RequestBody LoginBody loginBody)
    {
        AjaxResult ajax = AjaxResult.success();
        // 生成令牌
//        String token = loginService.login(loginBody.getUsername(), loginBody.getPassword(), loginBody.getCode(),
//                loginBody.getUuid());
        String token = loginService.login(loginBody.getUsername(), loginBody.getPassword(), loginBody.getCode());
        ajax.put(Constants.TOKEN, token);
        return ajax;
    }


修改ruoyi-framework\com\ruoyi\framework\web\service\SysLoginService.java

package com.ruoyi.framework.web.service;

import javax.annotation.Resource;

import com.anji.captcha.model.common.ResponseModel;
import com.anji.captcha.model.vo.CaptchaVO;
import com.anji.captcha.service.CaptchaService;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.context.annotation.Lazy;
import org.springframework.security.authentication.AuthenticationManager;
import org.springframework.security.authentication.BadCredentialsException;
import org.springframework.security.authentication.UsernamePasswordAuthenticationToken;
import org.springframework.security.core.Authentication;
import org.springframework.stereotype.Component;
import com.ruoyi.common.constant.CacheConstants;
import com.ruoyi.common.constant.Constants;
import com.ruoyi.common.constant.UserConstants;
import com.ruoyi.common.core.domain.entity.SysUser;
import com.ruoyi.common.core.domain.model.LoginUser;
import com.ruoyi.common.core.redis.RedisCache;
import com.ruoyi.common.exception.ServiceException;
import com.ruoyi.common.exception.user.BlackListException;
import com.ruoyi.common.exception.user.CaptchaException;
import com.ruoyi.common.exception.user.CaptchaExpireException;
import com.ruoyi.common.exception.user.UserNotExistsException;
import com.ruoyi.common.exception.user.UserPasswordNotMatchException;
import com.ruoyi.common.utils.DateUtils;
import com.ruoyi.common.utils.MessageUtils;
import com.ruoyi.common.utils.StringUtils;
import com.ruoyi.common.utils.ip.IpUtils;
import com.ruoyi.framework.manager.AsyncManager;
import com.ruoyi.framework.manager.factory.AsyncFactory;
import com.ruoyi.framework.security.context.AuthenticationContextHolder;
import com.ruoyi.system.service.ISysConfigService;
import com.ruoyi.system.service.ISysUserService;

/**
 * 登录校验方法
 *
 * @author ruoyi
 */
@Component
public class SysLoginService
{
    @Autowired
    private TokenService tokenService;

    @Resource
    private AuthenticationManager authenticationManager;

    @Autowired
    private RedisCache redisCache;

    @Autowired
    private ISysUserService userService;

    @Autowired
    private ISysConfigService configService;

    @Autowired
    @Lazy
    private CaptchaService captchaService;

    /**
     * 登录验证
     *
     * @param username 用户名
     * @param password 密码
     * @param code 验证码
     * @return 结果
     */
    public String login(String username, String password, String code)
    {
        // 验证码校验
        validateCaptcha(username, code);
        // 登录前置校验
        loginPreCheck(username, password);
        // 用户验证
        Authentication authentication = null;
        try
        {
            UsernamePasswordAuthenticationToken authenticationToken = new UsernamePasswordAuthenticationToken(username, password);
            AuthenticationContextHolder.setContext(authenticationToken);
            // 该方法会去调用UserDetailsServiceImpl.loadUserByUsername
            authentication = authenticationManager.authenticate(authenticationToken);
        }
        catch (Exception e)
        {
            if (e instanceof BadCredentialsException)
            {
                AsyncManager.me().execute(AsyncFactory.recordLogininfor(username, Constants.LOGIN_FAIL, MessageUtils.message("user.password.not.match")));
                throw new UserPasswordNotMatchException();
            }
            else
            {
                AsyncManager.me().execute(AsyncFactory.recordLogininfor(username, Constants.LOGIN_FAIL, e.getMessage()));
                throw new ServiceException(e.getMessage());
            }
        }
        finally
        {
            AuthenticationContextHolder.clearContext();
        }
        AsyncManager.me().execute(AsyncFactory.recordLogininfor(username, Constants.LOGIN_SUCCESS, MessageUtils.message("user.login.success")));
        LoginUser loginUser = (LoginUser) authentication.getPrincipal();
        recordLoginInfo(loginUser.getUserId());
        // 生成token
        return tokenService.createToken(loginUser);
    }

    /**
     * 校验验证码
     *
     * @param username 用户名
     * @param code 验证码
     * @return 结果
     */
    public void validateCaptcha(String username, String code)
    {
        CaptchaVO captchaVO = new CaptchaVO();
        captchaVO.setCaptchaVerification(code);
        ResponseModel response = captchaService.verification(captchaVO);
        if (!response.isSuccess())
        {
            AsyncManager.me().execute(AsyncFactory.recordLogininfor(username, Constants.LOGIN_FAIL, MessageUtils.message("user.jcaptcha.error")));
            throw new CaptchaException();
        }
    }

    /**
     * 登录前置校验
     * @param username 用户名
     * @param password 用户密码
     */
    public void loginPreCheck(String username, String password)
    {
        // 用户名或密码为空 错误
        if (StringUtils.isEmpty(username) || StringUtils.isEmpty(password))
        {
            AsyncManager.me().execute(AsyncFactory.recordLogininfor(username, Constants.LOGIN_FAIL, MessageUtils.message("not.null")));
            throw new UserNotExistsException();
        }
        // 密码如果不在指定范围内 错误
        if (password.length() < UserConstants.PASSWORD_MIN_LENGTH
                || password.length() > UserConstants.PASSWORD_MAX_LENGTH)
        {
            AsyncManager.me().execute(AsyncFactory.recordLogininfor(username, Constants.LOGIN_FAIL, MessageUtils.message("user.password.not.match")));
            throw new UserPasswordNotMatchException();
        }
        // 用户名不在指定范围内 错误
        if (username.length() < UserConstants.USERNAME_MIN_LENGTH
                || username.length() > UserConstants.USERNAME_MAX_LENGTH)
        {
            AsyncManager.me().execute(AsyncFactory.recordLogininfor(username, Constants.LOGIN_FAIL, MessageUtils.message("user.password.not.match")));
            throw new UserPasswordNotMatchException();
        }
        // IP黑名单校验
        String blackStr = configService.selectConfigByKey("sys.login.blackIPList");
        if (IpUtils.isMatchedIp(blackStr, IpUtils.getIpAddr()))
        {
            AsyncManager.me().execute(AsyncFactory.recordLogininfor(username, Constants.LOGIN_FAIL, MessageUtils.message("login.blocked")));
            throw new BlackListException();
        }
    }

    /**
     * 记录登录信息
     *
     * @param userId 用户ID
     */
    public void recordLoginInfo(Long userId)
    {
        SysUser sysUser = new SysUser();
        sysUser.setUserId(userId);
        sysUser.setLoginIp(IpUtils.getIpAddr());
        sysUser.setLoginDate(DateUtils.getNowDate());
        userService.updateUserProfile(sysUser);
    }
}

3.新增验证码缓存redis服务类

ruoyi-framework\com\ruoyi\framework\web\service\CaptchaRedisService.java

package com.ruoyi.framework.web.service;

import java.util.concurrent.TimeUnit;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.data.redis.core.StringRedisTemplate;
import com.anji.captcha.service.CaptchaCacheService;

/**
 * 自定义redis验证码缓存实现类
 *
 * @author ruoyi
 */
public class CaptchaRedisService implements CaptchaCacheService
{
    @Autowired
    private StringRedisTemplate stringRedisTemplate;

    @Override
    public void set(String key, String value, long expiresInSeconds)
    {
        stringRedisTemplate.opsForValue().set(key, value, expiresInSeconds, TimeUnit.SECONDS);
    }

    @Override
    public boolean exists(String key)
    {
        return stringRedisTemplate.hasKey(key);
    }

    @Override
    public void delete(String key)
    {
        stringRedisTemplate.delete(key);
    }

    @Override
    public String get(String key)
    {
        return stringRedisTemplate.opsForValue().get(key);
    }

    @Override
    public Long increment(String key, long val)
    {
        return stringRedisTemplate.opsForValue().increment(key, val);
    }

    @Override
    public String type()
    {
        return "redis";
    }
}

1.5 代码启动

二、前端实现

2.1 新增依赖

在package.json中新增crypto-js依赖（启动前需要重新安装依赖）

{
  "name": "ruoyi",
  "version": "3.9.0",
  "description": "若依管理系统",
  "author": "若依",
  "license": "MIT",
  "type": "module",
  "scripts": {
    "dev": "vite",
    "build:prod": "vite build",
    "build:stage": "vite build --mode staging",
    "preview": "vite preview"
  },
  "repository": {
    "type": "git",
    "url": "https://gitee.com/y_project/RuoYi-Vue.git"
  },
  "dependencies": {
    "@element-plus/icons-vue": "2.3.1",
    "@vueup/vue-quill": "1.2.0",
    "@vueuse/core": "13.3.0",
    "axios": "1.9.0",
    "clipboard": "2.0.11",
    "echarts": "5.6.0",
    "element-plus": "2.10.7",
    "file-saver": "2.0.5",
    "fuse.js": "6.6.2",
    "js-beautify": "1.14.11",
    "js-cookie": "3.0.5",
    "jsencrypt": "3.3.2",
    "nprogress": "0.2.0",
    "pinia": "3.0.2",
    "splitpanes": "4.0.4",
    "vue": "3.5.16",
    "vue-cropper": "1.1.1",
    "vue-router": "4.5.1",
    "vuedraggable": "4.1.0",
    "crypto-js": "4.1.1"
  },
  "devDependencies": {
    "@vitejs/plugin-vue": "5.2.4",
    "sass-embedded": "1.89.1",
    "unplugin-auto-import": "0.18.6",
    "unplugin-vue-setup-extend-plus": "1.0.1",
    "vite": "6.3.5",
    "vite-plugin-compression": "0.5.1",
    "vite-plugin-svg-icons": "2.0.1"
  },
  "overrides": {
    "quill": "2.0.2"
  }
}

2.2 导入组件，图片

将Verifition组件放入src\components下，异常图片放到src\assets\images下

2.3 修改代码

1. src\api\login.js
   去除login方法的uuid参数

// 登录方法
export function login(username, password, code) {
  const data = {
    username,
    password,
    code
  }
  return request({
    url: '/login',
    headers: {
      isToken: false,
      repeatSubmit: false
    },
    method: 'post',
    data: data
  })
}

2.src\store\modules\user.js

去除uuid

// 登录
login(userInfo) {
  const username = userInfo.username.trim()
  const password = userInfo.password
  const code = userInfo.code
  return new Promise((resolve, reject) => {
    login(username, password, code).then(res => {
      setToken(res.token)
      this.token = res.token
      resolve()
    }).catch(error => {
      reject(error)
    })
  })
}

3.src\views\login.vue

代码中带有必要注释

<template>
  <div class="login">
    <el-form ref="loginRef" :model="loginForm" :rules="loginRules" class="login-form">
      <h3 class="title">{{ title }}</h3>
      <el-form-item prop="username">
        <el-input
          v-model="loginForm.username"
          type="text"
          size="large"
          auto-complete="off"
          placeholder="账号"
        >
          <template #prefix><svg-icon icon-class="user" class="el-input__icon input-icon" /></template>
        </el-input>
      </el-form-item>
      <el-form-item prop="password">
        <el-input
          v-model="loginForm.password"
          type="password"
          size="large"
          auto-complete="off"
          placeholder="密码"
          @keyup.enter="handleLogin"
        >
          <template #prefix><svg-icon icon-class="password" class="el-input__icon input-icon" /></template>
        </el-input>
      </el-form-item>
<!--      <el-form-item prop="code" v-if="captchaEnabled">-->
<!--        <el-input-->
<!--          v-model="loginForm.code"-->
<!--          size="large"-->
<!--          auto-complete="off"-->
<!--          placeholder="验证码"-->
<!--          style="width: 63%"-->
<!--          @keyup.enter="handleLogin"-->
<!--        >-->
<!--          <template #prefix><svg-icon icon-class="validCode" class="el-input__icon input-icon" /></template>-->
<!--        </el-input>-->
<!--        <div class="login-code">-->
<!--          <img :src="codeUrl" @click="getCode" class="login-code-img"/>-->
<!--        </div>-->
<!--      </el-form-item>-->

      <!--修改为滑块验证码，切换点击文字验证的话将captchaType的值修改为clickWord-->
      <Verify
          @success="capctchaCheckSuccess"
          :mode="'pop'"
          :captchaType="'blockPuzzle'"
          :imgSize="{ width: '330px', height: '155px' }"
          ref="verify"
      ></Verify>
      <el-checkbox v-model="loginForm.rememberMe" style="margin:0px 0px 25px 0px;">记住密码</el-checkbox>
      <el-form-item style="width:100%;">
        <el-button
          :loading="loading"
          size="large"
          type="primary"
          style="width:100%;"
          @click.prevent="handleLogin"
        >
          <span v-if="!loading">登 录</span>
          <span v-else>登 录 中...</span>
        </el-button>
        <div style="float: right;" v-if="register">
          <router-link class="link-type" :to="'/register'">立即注册</router-link>
        </div>
      </el-form-item>
    </el-form>
    <!--  底部  -->
    <div class="el-login-footer">
      <span>Copyright © 2018-2025 ruoyi.vip All Rights Reserved.</span>
    </div>
  </div>
</template>

<script setup>
import { getCodeImg } from "@/api/login"
import Cookies from "js-cookie"
import { encrypt, decrypt } from "@/utils/jsencrypt"
import useUserStore from '@/store/modules/user'
// 引用组件Verify
import Verify from "@/components/Verifition/Verify";

const title = import.meta.env.VITE_APP_TITLE
const userStore = useUserStore()
const route = useRoute()
const router = useRouter()
const { proxy } = getCurrentInstance()

const loginForm = ref({
  username: "admin",
  password: "admin123",
  rememberMe: false,
  code: ""
  // 去除uuid
  // uuid: ""
})

const loginRules = {
  username: [{ required: true, trigger: "blur", message: "请输入您的账号" }],
  password: [{ required: true, trigger: "blur", message: "请输入您的密码" }]
  // 去除code
  // code: [{ required: true, trigger: "change", message: "请输入验证码" }]
}

// 去除验证码验证
// const codeUrl = ref("")
const loading = ref(false)
// 验证码开关
const captchaEnabled = ref(true)
// 注册开关
const register = ref(false)
const redirect = ref(undefined)

watch(route, (newRoute) => {
    redirect.value = newRoute.query && newRoute.query.redirect
}, { immediate: true })

function handleLogin() {
  proxy.$refs.loginRef.validate(valid => {
    if (valid) {
      // 展示滑块验证码
      proxy.$refs.verify.show();
      loading.value = true
      // 勾选了需要记住密码设置在 cookie 中设置记住用户名和密码
      if (loginForm.value.rememberMe) {
        Cookies.set("username", loginForm.value.username, { expires: 30 })
        Cookies.set("password", encrypt(loginForm.value.password), { expires: 30 })
        Cookies.set("rememberMe", loginForm.value.rememberMe, { expires: 30 })
      } else {
        // 否则移除
        Cookies.remove("username")
        Cookies.remove("password")
        Cookies.remove("rememberMe")
      }
      // 调用action的登录方法
      userStore.login(loginForm.value).then(() => {
        const query = route.query
        const otherQueryParams = Object.keys(query).reduce((acc, cur) => {
          if (cur !== "redirect") {
            acc[cur] = query[cur]
          }
          return acc
        }, {})
        router.push({ path: redirect.value || "/", query: otherQueryParams })
      }).catch(() => {
        loading.value = false
        // 重新获取验证码
        // if (captchaEnabled.value) {
        //   getCode()
        // }
      })
    }
  })
}

// 去除验证码验证
// function getCode() {
//   getCodeImg().then(res => {
//     captchaEnabled.value = res.captchaEnabled === undefined ? true : res.captchaEnabled
//     if (captchaEnabled.value) {
//       loginForm.value.uuid = res.uuid
//     }
//   })
// }

function getCookie() {
  const username = Cookies.get("username")
  const password = Cookies.get("password")
  const rememberMe = Cookies.get("rememberMe")
  loginForm.value = {
    username: username === undefined ? loginForm.value.username : username,
    password: password === undefined ? loginForm.value.password : decrypt(password),
    rememberMe: rememberMe === undefined ? false : Boolean(rememberMe)
  }
}

// 去除验证码验证
// getCode()
getCookie()
</script>

<style lang='scss' scoped>
.login {
  display: flex;
  justify-content: center;
  align-items: center;
  height: 100%;
  background-image: url("../assets/images/login-background.jpg");
  background-size: cover;
}
.title {
  margin: 0px auto 30px auto;
  text-align: center;
  color: #707070;
}

.login-form {
  border-radius: 6px;
  background: #ffffff;
  width: 400px;
  padding: 25px 25px 5px 25px;
  z-index: 1;
  .el-input {
    height: 40px;
    input {
      height: 40px;
    }
  }
  .input-icon {
    height: 39px;
    width: 14px;
    margin-left: 0px;
  }
}
.login-tip {
  font-size: 13px;
  text-align: center;
  color: #bfbfbf;
}
.login-code {
  width: 33%;
  height: 40px;
  float: right;
  img {
    cursor: pointer;
    vertical-align: middle;
  }
}
.el-login-footer {
  height: 40px;
  line-height: 40px;
  position: fixed;
  bottom: 0;
  width: 100%;
  text-align: center;
  color: #fff;
  font-family: Arial;
  font-size: 12px;
  letter-spacing: 1px;
}
.login-code-img {
  height: 40px;
  padding-left: 12px;
}
</style>

三、效果展示

滑块验证

点击文字验证
