引言

随着万物互联时代的到来,传统的操作系统已经无法满足多设备协同、跨平台互通的需求。华为鸿蒙HarmonyOS作为面向全场景的分布式操作系统,以其独特的分布式架构和全栈解决方案,正在重新定义智能设备的交互方式。本文将从系统架构、开发环境、应用开发、分布式特性、性能优化等多个维度,深入解析鸿蒙系统的核心技术和开发实践,帮助开发者全面掌握鸿蒙应用开发的精髓。

第一章:鸿蒙系统概述与发展历程

1.1 鸿蒙系统的诞生背景

1.1.1 技术发展趋势

鸿蒙系统的诞生源于对未来智能生态的深度思考。在5G、IoT、AI等技术快速发展的背景下,传统的单设备操作系统已经无法满足多设备协同的需求。

1.1.2 市场需求驱动

消费者对于设备间无缝连接、数据共享、协同工作的需求日益增长,这要求操作系统具备天然的分布式能力。

1.2 鸿蒙系统的核心理念

1.2.1 一次开发,多端部署

鸿蒙系统通过统一的开发框架,实现了真正的"一次开发,多端部署",大大降低了开发成本。

typescript 复制代码
// 统一的组件开发模式
@Entry
@Component
struct MainPage {
  @State message: string = 'Hello HarmonyOS'

  build() {
    Row() {
      Column() {
        Text(this.message)
          .fontSize(50)
          .fontWeight(FontWeight.Bold)
      }
      .width('100%')
    }
    .height('100%')
  }
}
1.2.2 分布式软总线

通过分布式软总线技术,实现设备间的无缝连接和资源共享。

1.3 发展历程与版本演进

1.3.1 关键时间节点
  • 2019年8月:鸿蒙OS 1.0发布
  • 2020年9月:鸿蒙OS 2.0发布
  • 2021年6月:HarmonyOS 2正式商用
  • 2022年7月:HarmonyOS 3.0发布
  • 2023年8月:HarmonyOS 4.0发布
1.3.2 技术能力演进

每个版本都在分布式能力、开发工具、性能优化等方面有显著提升。

第二章:鸿蒙系统架构深度解析

2.1 分布式架构设计

2.1.1 分布式软总线架构

鸿蒙系统的核心是分布式软总线,它为设备间通信提供了统一的抽象层。

typescript 复制代码
// 分布式设备发现示例
import deviceManager from '@ohos.distributedHardware.deviceManager';

class DeviceDiscovery {
  private dmInstance: deviceManager.DeviceManager;

  async initDeviceManager() {
    try {
      this.dmInstance = deviceManager.createDeviceManager('com.example.app');

      // 监听设备状态变化
      this.dmInstance.on('deviceStateChange', (data) => {
        console.info('Device state changed:', data);
        this.handleDeviceStateChange(data);
      });

      // 开始设备发现
      this.startDeviceDiscovery();
    } catch (error) {
      console.error('Init device manager failed:', error);
    }
  }

  private startDeviceDiscovery() {
    const discoverParam = {
      subscribeId: 1,
      mode: 0xAA, // 主动发现模式
      medium: 2,  // 自动选择媒介
      freq: 2,    // 高频发现
      isSameAccount: false,
      isWakeRemote: true,
      capability: 0
    };

    this.dmInstance.startDeviceDiscovery(discoverParam);
  }

  private handleDeviceStateChange(data: any) {
    switch (data.action) {
      case deviceManager.DeviceStateChangeAction.READY:
        console.info('Device ready:', data.device.deviceName);
        break;
      case deviceManager.DeviceStateChangeAction.OFFLINE:
        console.info('Device offline:', data.device.deviceName);
        break;
    }
  }
}
2.1.2 分布式数据管理

通过分布式数据管理服务,实现数据在多设备间的同步和共享。

typescript 复制代码
import distributedData from '@ohos.data.distributedData';

class DistributedDataManager {
  private kvStore: distributedData.KVStore;

  async initKVStore() {
    const kvManagerConfig = {
      context: getContext(this),
      bundleName: 'com.example.app'
    };

    const kvManager = distributedData.createKVManager(kvManagerConfig);

    const options = {
      createIfMissing: true,
      encrypt: false,
      backup: false,
      autoSync: true,
      kvStoreType: distributedData.KVStoreType.DEVICE_COLLABORATION,
      schema: '',
      securityLevel: distributedData.SecurityLevel.S2
    };

    try {
      this.kvStore = await kvManager.getKVStore('user_preferences', options);
      this.setupSyncListener();
    } catch (error) {
      console.error('Create KV store failed:', error);
    }
  }

  private setupSyncListener() {
    this.kvStore.on('syncComplete', (data) => {
      console.info('Sync completed:', data);
    });
  }

  async syncData(key: string, value: string) {
    try {
      await this.kvStore.put(key, value);

      // 同步到其他设备
      const deviceList = await this.getConnectedDevices();
      if (deviceList.length > 0) {
        await this.kvStore.sync(deviceList, distributedData.SyncMode.PUSH_ONLY);
      }
    } catch (error) {
      console.error('Sync data failed:', error);
    }
  }

  private async getConnectedDevices(): Promise<string[]> {
    // 获取已连接的设备列表
    return [];
  }
}

2.2 分层架构设计

2.2.1 内核层

鸿蒙采用微内核架构,提供了更好的安全性和可靠性。

2.2.2 系统服务层

包含分布式软总线、分布式数据管理、分布式任务调度等核心服务。

2.2.3 框架层

提供应用开发所需的各种框架和API。

2.2.4 应用层

运行各种系统应用和第三方应用。

2.3 ArkTS语言特性

2.3.1 TypeScript超集

ArkTS是基于TypeScript的应用开发语言,提供了更强的类型安全和开发效率。

typescript 复制代码
// 装饰器的使用
@Component
struct CustomButton {
  @Prop buttonText: string = 'Click Me'
  @Prop buttonColor: Color = Color.Blue
  @State isPressed: boolean = false

  build() {
    Button(this.buttonText)
      .backgroundColor(this.isPressed ? Color.Gray : this.buttonColor)
      .onClick(() => {
        this.isPressed = !this.isPressed
        this.handleClick()
      })
  }

  private handleClick() {
    console.info('Button clicked:', this.buttonText)
  }
}
2.3.2 声明式UI开发

采用声明式UI开发模式,让界面开发更加直观和高效。

typescript 复制代码
@Entry
@Component
struct TodoList {
  @State todos: Array<TodoItem> = []
  @State inputText: string = ''

  build() {
    Column() {
      // 输入框
      Row() {
        TextInput({ placeholder: '添加新任务' })
          .layoutWeight(1)
          .onChange((value: string) => {
            this.inputText = value
          })

        Button('添加')
          .onClick(() => {
            this.addTodo()
          })
      }
      .padding(16)

      // 任务列表
      List() {
        ForEach(this.todos, (item: TodoItem, index: number) => {
          ListItem() {
            TodoItemComponent({
              item: item,
              onToggle: () => this.toggleTodo(index),
              onDelete: () => this.deleteTodo(index)
            })
          }
        })
      }
      .layoutWeight(1)
    }
    .width('100%')
    .height('100%')
  }

  private addTodo() {
    if (this.inputText.trim()) {
      this.todos.push({
        id: Date.now(),
        text: this.inputText,
        completed: false
      })
      this.inputText = ''
    }
  }

  private toggleTodo(index: number) {
    this.todos[index].completed = !this.todos[index].completed
  }

  private deleteTodo(index: number) {
    this.todos.splice(index, 1)
  }
}

interface TodoItem {
  id: number
  text: string
  completed: boolean
}

第三章:鸿蒙开发环境搭建与配置

3.1 DevEco Studio安装配置

3.1.1 系统要求
  • Windows 10/11 (64位)
  • macOS 10.15或更高版本
  • Ubuntu 18.04或更高版本
  • 内存:8GB以上推荐
  • 存储:至少10GB可用空间
3.1.2 安装步骤
  1. 从华为开发者官网下载DevEco Studio
  2. 运行安装程序,选择安装路径
  3. 配置SDK路径和工具链
  4. 创建或导入项目

3.2 SDK配置与管理

3.2.1 SDK组件说明
json 复制代码
{
  "apiVersion": 9,
  "version": {
    "code": 1000000,
    "name": "1.0.0"
  },
  "deviceConfig": {
    "default": {
      "debug": true
    }
  },
  "module": {
    "package": "com.example.myapplication",
    "name": ".MyApplication",
    "mainAbility": ".MainAbility",
    "deviceType": [
      "phone",
      "tablet",
      "tv",
      "wearable"
    ],
    "distro": {
      "deliveryWithInstall": true,
      "moduleName": "entry",
      "moduleType": "entry",
      "installationFree": false
    },
    "abilities": [
      {
        "skills": [
          {
            "entities": [
              "entity.system.home"
            ],
            "actions": [
              "action.system.home"
            ]
          }
        ],
        "orientation": "unspecified",
        "visible": true,
        "name": ".MainAbility",
        "icon": "$media:icon",
        "description": "$string:description_mainability",
        "label": "$string:entry_MainAbility",
        "type": "page",
        "launchType": "standard"
      }
    ]
  }
}
3.2.2 依赖管理

使用ohpm进行依赖包管理:

json 复制代码
{
  "name": "my-harmony-app",
  "version": "1.0.0",
  "description": "A HarmonyOS application",
  "main": "index.ets",
  "author": "",
  "license": "",
  "dependencies": {
    "@ohos/hypium": "1.0.6"
  },
  "devDependencies": {
    "@ohos/hvigor-ohos-plugin": "1.4.6",
    "@ohos/hvigor": "1.4.6"
  }
}

3.3 项目创建与结构分析

3.3.1 项目结构
复制代码
MyApplication/
├── AppScope/
│   └── app.json5
├── entry/
│   ├── src/
│   │   ├── main/
│   │   │   ├── ets/
│   │   │   │   ├── entryability/
│   │   │   │   └── pages/
│   │   │   ├── resources/
│   │   │   └── module.json5
│   │   └── ohosTest/
│   ├── build-profile.json5
│   └── hvigorfile.ts
├── build-profile.json5
├── hvigorfile.ts
└── oh-package.json5
3.3.2 核心配置文件

app.json5配置:

json5 复制代码
{
  "app": {
    "bundleName": "com.example.myapplication",
    "vendor": "example",
    "versionCode": 1000000,
    "versionName": "1.0.0",
    "icon": "$media:app_icon",
    "label": "$string:app_name",
    "distributedNotificationEnabled": true,
    "targetAPIVersion": 9
  }
}

module.json5配置:

json5 复制代码
{
  "module": {
    "name": "entry",
    "type": "entry",
    "description": "$string:module_desc",
    "mainElement": "EntryAbility",
    "deviceTypes": [
      "phone",
      "tablet"
    ],
    "deliveryWithInstall": true,
    "installationFree": false,
    "pages": "$profile:main_pages",
    "abilities": [
      {
        "name": "EntryAbility",
        "srcEntry": "./ets/entryability/EntryAbility.ts",
        "description": "$string:EntryAbility_desc",
        "icon": "$media:icon",
        "label": "$string:EntryAbility_label",
        "startWindowIcon": "$media:icon",
        "startWindowBackground": "$color:start_window_background",
        "exported": true,
        "skills": [
          {
            "entities": [
              "entity.system.home"
            ],
            "actions": [
              "action.system.home"
            ]
          }
        ]
      }
    ]
  }
}

第四章:鸿蒙应用开发基础

4.1 UIAbility生命周期管理

4.1.1 生命周期概述

UIAbility是鸿蒙应用的基本单元,具有完整的生命周期管理机制。

typescript 复制代码
import UIAbility from '@ohos.app.ability.UIAbility';
import hilog from '@ohos.hilog';
import window from '@ohos.window';

export default class EntryAbility extends UIAbility {
  onCreate(want, launchParam) {
    hilog.info(0x0000, 'testTag', '%{public}s', 'Ability onCreate');

    // 应用数据初始化
    this.initializeAppData();

    // 全局配置
    this.setupGlobalConfiguration();
  }

  onDestroy() {
    hilog.info(0x0000, 'testTag', '%{public}s', 'Ability onDestroy');

    // 清理资源
    this.cleanup();
  }

  onWindowStageCreate(windowStage: window.WindowStage) {
    hilog.info(0x0000, 'testTag', '%{public}s', 'Ability onWindowStageCreate');

    // 设置系统事件监听
    this.setupSystemEventListeners(windowStage);

    // 主窗口设置
    windowStage.loadContent('pages/Index', (err, data) => {
      if (err.code) {
        hilog.error(0x0000, 'testTag', 'Failed to load the content. Cause: %{public}s', JSON.stringify(err) ?? '');
        return;
      }
      hilog.info(0x0000, 'testTag', 'Succeeded in loading the content. Data: %{public}s', JSON.stringify(data) ?? '');
    });

    // 设置状态栏和导航栏
    this.setupStatusAndNavigationBar(windowStage);
  }

  onWindowStageDestroy() {
    hilog.info(0x0000, 'testTag', '%{public}s', 'Ability onWindowStageDestroy');
  }

  onForeground() {
    hilog.info(0x0000, 'testTag', '%{public}s', 'Ability onForeground');

    // 应用进入前台时的处理
    this.handleAppForeground();
  }

  onBackground() {
    hilog.info(0x0000, 'testTag', '%{public}s', 'Ability onBackground');

    // 应用进入后台时的处理
    this.handleAppBackground();
  }

  private initializeAppData() {
    // 初始化应用数据
    console.info('Initializing app data...');
  }

  private setupGlobalConfiguration() {
    // 全局配置设置
    console.info('Setting up global configuration...');
  }

  private setupSystemEventListeners(windowStage: window.WindowStage) {
    // 系统事件监听设置
    console.info('Setting up system event listeners...');
  }

  private setupStatusAndNavigationBar(windowStage: window.WindowStage) {
    windowStage.getMainWindow().then((mainWindow) => {
      // 设置状态栏
      mainWindow.setWindowSystemBarEnable(['status', 'navigation']);

      // 设置状态栏样式
      mainWindow.setWindowSystemBarProperties({
        statusBarColor: '#FF0000FF',
        navigationBarColor: '#FF0000FF',
        statusBarContentColor: '#FFFFFF',
        navigationBarContentColor: '#FFFFFF'
      });
    });
  }

  private handleAppForeground() {
    // 应用状态管理
    console.info('App entered foreground');

    // 恢复定时任务
    this.resumePeriodicTasks();
  }

  private handleAppBackground() {
    // 应用状态管理
    console.info('App entered background');

    // 暂停定时任务
    this.pausePeriodicTasks();
  }

  private resumePeriodicTasks() {
    // 恢复周期性任务
  }

  private pausePeriodicTasks() {
    // 暂停周期性任务
  }

  private cleanup() {
    // 资源清理
    console.info('Cleaning up resources...');
  }
}
4.1.2 ServiceExtensionAbility服务组件
typescript 复制代码
import ServiceExtensionAbility from '@ohos.app.ability.ServiceExtensionAbility';
import Want from '@ohos.app.ability.Want';
import rpc from '@ohos.rpc';

class ServiceStub extends rpc.RemoteObject {
  constructor(des: string) {
    super(des);
  }

  onRemoteMessageRequest(code: number, data: rpc.MessageSequence, reply: rpc.MessageSequence, option: rpc.MessageOption) {
    console.info('ServiceStub onRemoteMessageRequest called');

    switch (code) {
      case 1: // 获取数据
        let result = this.getData();
        reply.writeString(result);
        break;
      case 2: // 设置数据
        let inputData = data.readString();
        this.setData(inputData);
        reply.writeInt(0); // 成功
        break;
      default:
        console.error('Unknown request code:', code);
        break;
    }

    return true;
  }

  private getData(): string {
    return 'Service data';
  }

  private setData(data: string) {
    console.info('Setting data:', data);
  }
}

export default class BackgroundService extends ServiceExtensionAbility {
  private serviceStub: ServiceStub;

  onCreate(want: Want) {
    console.info('BackgroundService onCreate');
    this.serviceStub = new ServiceStub('BackgroundService');
  }

  onRequest(want: Want, startId: number) {
    console.info('BackgroundService onRequest');

    // 处理服务请求
    this.handleServiceRequest(want, startId);
  }

  onConnect(want: Want) {
    console.info('BackgroundService onConnect');
    return this.serviceStub;
  }

  onDisconnect(want: Want) {
    console.info('BackgroundService onDisconnect');
  }

  onDestroy() {
    console.info('BackgroundService onDestroy');
  }

  private handleServiceRequest(want: Want, startId: number) {
    // 根据want参数处理不同的服务请求
    const action = want.action;

    switch (action) {
      case 'com.example.START_BACKGROUND_TASK':
        this.startBackgroundTask();
        break;
      case 'com.example.STOP_BACKGROUND_TASK':
        this.stopBackgroundTask();
        break;
      default:
        console.warn('Unknown service action:', action);
        break;
    }
  }

  private startBackgroundTask() {
    console.info('Starting background task...');
    // 启动后台任务逻辑
  }

  private stopBackgroundTask() {
    console.info('Stopping background task...');
    // 停止后台任务逻辑
  }
}

4.2 自定义组件开发

4.2.1 基础组件封装
typescript 复制代码
// 自定义卡片组件
@Component
export struct CustomCard {
  @Prop title: string = ''
  @Prop content: string = ''
  @Prop imageUrl: string = ''
  @Prop @Watch('onActionChanged') actionText: string = ''
  @State isExpanded: boolean = false
  private onActionClick?: () => void

  build() {
    Column() {
      // 卡片头部
      Row() {
        Text(this.title)
          .fontSize(18)
          .fontWeight(FontWeight.Bold)
          .layoutWeight(1)

        Button(this.isExpanded ? '收起' : '展开')
          .type(ButtonType.Normal)
          .fontSize(12)
          .onClick(() => {
            this.toggleExpanded()
          })
      }
      .width('100%')
      .padding({ left: 16, right: 16, top: 12, bottom: 8 })

      // 图片区域
      if (this.imageUrl) {
        Image(this.imageUrl)
          .width('100%')
          .height(200)
          .objectFit(ImageFit.Cover)
          .borderRadius({ topLeft: 0, topRight: 0, bottomLeft: 8, bottomRight: 8 })
      }

      // 内容区域
      Column() {
        Text(this.content)
          .fontSize(14)
          .lineHeight(20)
          .maxLines(this.isExpanded ? -1 : 3)
          .textOverflow({ overflow: TextOverflow.Ellipsis })
          .width('100%')

        // 操作按钮
        if (this.actionText && this.onActionClick) {
          Button(this.actionText)
            .width('100%')
            .margin({ top: 12 })
            .onClick(() => {
              this.onActionClick?.()
            })
        }
      }
      .padding(16)
      .alignItems(HorizontalAlign.Start)
    }
    .backgroundColor(Color.White)
    .borderRadius(12)
    .shadow({ radius: 8, color: '#1F000000', offsetX: 0, offsetY: 2 })
    .margin({ left: 16, right: 16, top: 8, bottom: 8 })
  }

  private toggleExpanded() {
    animateTo({
      duration: 300,
      curve: Curve.EaseInOut
    }, () => {
      this.isExpanded = !this.isExpanded
    })
  }

  onActionChanged() {
    console.info('Action text changed:', this.actionText)
  }

  // 组件方法
  public expand() {
    this.isExpanded = true
  }

  public collapse() {
    this.isExpanded = false
  }
}

// 使用自定义组件
@Entry
@Component
struct CardDemo {
  @State cards: CardData[] = [
    {
      title: '鸿蒙开发指南',
      content: '鸿蒙系统是华为推出的面向全场景的分布式操作系统,具有强大的跨设备协同能力...',
      imageUrl: 'https://example.com/harmony-logo.png',
      actionText: '了解更多'
    },
    {
      title: 'ArkTS语言特性',
      content: 'ArkTS是基于TypeScript的声明式开发语言,为鸿蒙应用开发提供了强大的类型安全保障...',
      imageUrl: '',
      actionText: '查看详情'
    }
  ]

  build() {
    Scroll() {
      Column() {
        ForEach(this.cards, (card: CardData, index: number) => {
          CustomCard({
            title: card.title,
            content: card.content,
            imageUrl: card.imageUrl,
            actionText: card.actionText,
            onActionClick: () => {
              this.handleCardAction(index)
            }
          })
        })
      }
    }
    .width('100%')
    .height('100%')
    .backgroundColor('#F5F5F5')
  }

  private handleCardAction(index: number) {
    console.info('Card action clicked:', index)
    // 处理卡片操作
  }
}

interface CardData {
  title: string
  content: string
  imageUrl: string
  actionText: string
}

4.3 状态管理

4.3.1 本地状态管理
typescript 复制代码
// 状态管理类
class AppStateManager {
  private static instance: AppStateManager
  private listeners: Map<string, Function[]> = new Map()
  private state: Map<string, any> = new Map()

  static getInstance(): AppStateManager {
    if (!AppStateManager.instance) {
      AppStateManager.instance = new AppStateManager()
    }
    return AppStateManager.instance
  }

  // 设置状态
  setState<T>(key: string, value: T) {
    const oldValue = this.state.get(key)
    this.state.set(key, value)

    // 通知监听者
    const keyListeners = this.listeners.get(key) || []
    keyListeners.forEach(listener => {
      listener(value, oldValue)
    })
  }

  // 获取状态
  getState<T>(key: string): T | undefined {
    return this.state.get(key)
  }

  // 订阅状态变化
  subscribe(key: string, listener: Function): () => void {
    if (!this.listeners.has(key)) {
      this.listeners.set(key, [])
    }

    const keyListeners = this.listeners.get(key)!
    keyListeners.push(listener)

    // 返回取消订阅函数
    return () => {
      const index = keyListeners.indexOf(listener)
      if (index > -1) {
        keyListeners.splice(index, 1)
      }
    }
  }

  // 批量更新状态
  batchUpdate(updates: Map<string, any>) {
    const affectedKeys = new Set<string>()

    // 更新所有状态
    updates.forEach((value, key) => {
      this.state.set(key, value)
      affectedKeys.add(key)
    })

    // 批量通知
    affectedKeys.forEach(key => {
      const keyListeners = this.listeners.get(key) || []
      const newValue = this.state.get(key)
      keyListeners.forEach(listener => {
        listener(newValue, undefined)
      })
    })
  }
}

// 使用状态管理的组件
@Component
struct UserProfile {
  @State private userName: string = ''
  @State private userAvatar: string = ''
  @State private userLevel: number = 1
  private stateManager = AppStateManager.getInstance()
  private unsubscribers: (() => void)[] = []

  aboutToAppear() {
    // 订阅用户状态变化
    this.unsubscribers.push(
      this.stateManager.subscribe('userName', (newName: string) => {
        this.userName = newName
      })
    )

    this.unsubscribers.push(
      this.stateManager.subscribe('userAvatar', (newAvatar: string) => {
        this.userAvatar = newAvatar
      })
    )

    this.unsubscribers.push(
      this.stateManager.subscribe('userLevel', (newLevel: number) => {
        this.userLevel = newLevel
      })
    )

    // 初始化用户数据
    this.loadUserData()
  }

  aboutToDisappear() {
    // 取消所有订阅
    this.unsubscribers.forEach(unsubscribe => unsubscribe())
    this.unsubscribers = []
  }

  build() {
    Column() {
      // 用户头像
      Image(this.userAvatar || $r('app.media.default_avatar'))
        .width(80)
        .height(80)
        .borderRadius(40)
        .margin({ bottom: 16 })

      // 用户名
      Text(this.userName || '未登录')
        .fontSize(20)
        .fontWeight(FontWeight.Bold)
        .margin({ bottom: 8 })

      // 用户等级
      Row() {
        Text('等级:')
          .fontSize(14)
          .fontColor('#666666')

        Text(this.userLevel.toString())
          .fontSize(14)
          .fontColor('#FF6B35')
          .fontWeight(FontWeight.Bold)
      }
      .margin({ bottom: 20 })

      // 操作按钮
      Button('更新资料')
        .width('80%')
        .onClick(() => {
          this.updateUserProfile()
        })
    }
    .width('100%')
    .padding(20)
    .alignItems(HorizontalAlign.Center)
  }

  private async loadUserData() {
    try {
      // 模拟从服务器加载用户数据
      const userData = await this.fetchUserData()

      // 批量更新状态
      const updates = new Map()
      updates.set('userName', userData.name)
      updates.set('userAvatar', userData.avatar)
      updates.set('userLevel', userData.level)

      this.stateManager.batchUpdate(updates)
    } catch (error) {
      console.error('Load user data failed:', error)
    }
  }

  private async fetchUserData(): Promise<UserData> {
    // 模拟网络请求
    return new Promise((resolve) => {
      setTimeout(() => {
        resolve({
          name: '鸿蒙开发者',
          avatar: 'https://example.com/avatar.jpg',
          level: 5
        })
      }, 1000)
    })
  }

  private updateUserProfile() {
    // 更新用户资料逻辑
    console.info('Updating user profile...')
  }
}

interface UserData {
  name: string
  avatar: string
  level: number
}

4.4 页面路由与导航

4.4.1 基础路由配置
typescript 复制代码
// router/index.ts
import router from '@ohos.router'

export class RouterManager {
  private static instance: RouterManager
  private routeStack: string[] = []

  static getInstance(): RouterManager {
    if (!RouterManager.instance) {
      RouterManager.instance = new RouterManager()
    }
    return RouterManager.instance
  }

  // 页面跳转
  async pushPage(url: string, params?: object): Promise<void> {
    try {
      await router.pushUrl({
        url: url,
        params: params
      })

      this.routeStack.push(url)
      console.info('Navigate to:', url)
    } catch (error) {
      console.error('Navigation failed:', error)
      throw error
    }
  }

  // 替换当前页面
  async replacePage(url: string, params?: object): Promise<void> {
    try {
      await router.replaceUrl({
        url: url,
        params: params
      })

      if (this.routeStack.length > 0) {
        this.routeStack[this.routeStack.length - 1] = url
      } else {
        this.routeStack.push(url)
      }

      console.info('Replace with:', url)
    } catch (error) {
      console.error('Replace failed:', error)
      throw error
    }
  }

  // 返回上一页
  async goBack(): Promise<void> {
    try {
      await router.back()

      if (this.routeStack.length > 0) {
        this.routeStack.pop()
      }

      console.info('Go back')
    } catch (error) {
      console.error('Go back failed:', error)
      throw error
    }
  }

  // 清空路由栈并跳转
  async clearAndPush(url: string, params?: object): Promise<void> {
    try {
      await router.clear()
      await this.pushPage(url, params)

      this.routeStack = [url]
      console.info('Clear and navigate to:', url)
    } catch (error) {
      console.error('Clear and push failed:', error)
      throw error
    }
  }

  // 获取当前路由栈
  getRouteStack(): string[] {
    return [...this.routeStack]
  }

  // 获取路由参数
  getParams<T>(): T | undefined {
    try {
      const params = router.getParams()
      return params as T
    } catch (error) {
      console.error('Get params failed:', error)
      return undefined
    }
  }
}

// 页面基类
export abstract class BasePage {
  protected routerManager = RouterManager.getInstance()
  protected pageParams: any

  aboutToAppear() {
    // 获取页面参数
    this.pageParams = this.routerManager.getParams()
    this.onPageLoad()
  }

  // 子类需要实现的方法
  protected abstract onPageLoad(): void

  // 通用导航方法
  protected navigateTo(url: string, params?: object) {
    this.routerManager.pushPage(url, params)
  }

  protected navigateBack() {
    this.routerManager.goBack()
  }

  protected navigateReplace(url: string, params?: object) {
    this.routerManager.replacePage(url, params)
  }
}
4.4.2 页面间数据传递
typescript 复制代码
// 列表页面
@Entry
@Component
struct ProductList extends BasePage {
  @State products: Product[] = []
  @State loading: boolean = false

  protected onPageLoad() {
    this.loadProducts()
  }

  build() {
    Column() {
      // 标题栏
      Row() {
        Text('商品列表')
          .fontSize(20)
          .fontWeight(FontWeight.Bold)
          .layoutWeight(1)

        Button('搜索')
          .onClick(() => {
            this.navigateTo('pages/ProductSearch')
          })
      }
      .width('100%')
      .padding(16)
      .backgroundColor('#FFFFFF')

      // 商品列表
      if (this.loading) {
        LoadingIndicator()
      } else {
        List() {
          ForEach(this.products, (product: Product) => {
            ListItem() {
              ProductItem({
                product: product,
                onItemClick: (item: Product) => {
                  this.navigateToDetail(item)
                }
              })
            }
          })
        }
        .layoutWeight(1)
      }
    }
    .width('100%')
    .height('100%')
    .backgroundColor('#F5F5F5')
  }

  private async loadProducts() {
    this.loading = true

    try {
      // 模拟加载商品数据
      this.products = await this.fetchProducts()
    } catch (error) {
      console.error('Load products failed:', error)
    } finally {
      this.loading = false
    }
  }

  private navigateToDetail(product: Product) {
    this.navigateTo('pages/ProductDetail', {
      productId: product.id,
      productName: product.name,
      fromPage: 'ProductList'
    })
  }

  private async fetchProducts(): Promise<Product[]> {
    return new Promise((resolve) => {
      setTimeout(() => {
        resolve([
          { id: 1, name: '华为Mate 50', price: 4999, image: 'mate50.jpg' },
          { id: 2, name: '华为P60', price: 5999, image: 'p60.jpg' }
        ])
      }, 1000)
    })
  }
}

// 详情页面
@Entry
@Component
struct ProductDetail extends BasePage {
  @State product: Product | null = null
  @State loading: boolean = false
  private productId: number = 0
  private fromPage: string = ''

  protected onPageLoad() {
    // 获取传递的参数
    if (this.pageParams) {
      this.productId = this.pageParams.productId
      this.fromPage = this.pageParams.fromPage
    }

    this.loadProductDetail()
  }

  build() {
    Column() {
      // 导航栏
      Row() {
        Button('返回')
          .onClick(() => {
            this.handleBackPress()
          })

        Text('商品详情')
          .fontSize(18)
          .fontWeight(FontWeight.Bold)
          .layoutWeight(1)
          .textAlign(TextAlign.Center)

        Button('分享')
          .onClick(() => {
            this.shareProduct()
          })
      }
      .width('100%')
      .padding(16)
      .backgroundColor('#FFFFFF')

      // 商品详情内容
      if (this.loading) {
        LoadingIndicator()
      } else if (this.product) {
        Scroll() {
          Column() {
            // 商品图片
            Image(this.product.image)
              .width('100%')
              .height(300)
              .objectFit(ImageFit.Cover)

            // 商品信息
            Column() {
              Text(this.product.name)
                .fontSize(20)
                .fontWeight(FontWeight.Bold)
                .margin({ bottom: 8 })

              Text(`¥${this.product.price}`)
                .fontSize(24)
                .fontColor('#FF6B35')
                .fontWeight(FontWeight.Bold)
                .margin({ bottom: 16 })

              // 操作按钮
              Row() {
                Button('加入购物车')
                  .layoutWeight(1)
                  .margin({ right: 8 })
                  .onClick(() => {
                    this.addToCart()
                  })

                Button('立即购买')
                  .layoutWeight(1)
                  .margin({ left: 8 })
                  .backgroundColor('#FF6B35')
                  .onClick(() => {
                    this.buyNow()
                  })
              }
              .width('100%')
            }
            .padding(16)
            .alignItems(HorizontalAlign.Start)
          }
        }
        .layoutWeight(1)
      }
    }
    .width('100%')
    .height('100%')
    .backgroundColor('#F5F5F5')
  }

  private async loadProductDetail() {
    this.loading = true

    try {
      this.product = await this.fetchProductDetail(this.productId)
    } catch (error) {
      console.error('Load product detail failed:', error)
    } finally {
      this.loading = false
    }
  }

  private handleBackPress() {
    // 可以根据来源页面做不同处理
    if (this.fromPage === 'ProductList') {
      this.navigateBack()
    } else {
      this.navigateTo('pages/ProductList')
    }
  }

  private shareProduct() {
    console.info('Share product:', this.product?.name)
  }

  private addToCart() {
    console.info('Add to cart:', this.product?.name)
    // 添加到购物车逻辑
  }

  private buyNow() {
    if (this.product) {
      this.navigateTo('pages/OrderConfirm', {
        product: this.product,
        quantity: 1
      })
    }
  }

  private async fetchProductDetail(id: number): Promise<Product> {
    return new Promise((resolve) => {
      setTimeout(() => {
        resolve({
          id: id,
          name: '华为Mate 50',
          price: 4999,
          image: 'https://example.com/mate50.jpg'
        })
      }, 800)
    })
  }
}

// 商品项组件
@Component
struct ProductItem {
  @Prop product: Product
  private onItemClick?: (product: Product) => void

  build() {
    Row() {
      Image(this.product.image)
        .width(80)
        .height(80)
        .borderRadius(8)
        .margin({ right: 12 })

      Column() {
        Text(this.product.name)
          .fontSize(16)
          .fontWeight(FontWeight.Medium)
          .maxLines(2)
          .textOverflow({ overflow: TextOverflow.Ellipsis })
          .margin({ bottom: 8 })

        Text(`¥${this.product.price}`)
          .fontSize(18)
          .fontColor('#FF6B35')
          .fontWeight(FontWeight.Bold)
      }
      .layoutWeight(1)
      .alignItems(HorizontalAlign.Start)
    }
    .width('100%')
    .padding(16)
    .backgroundColor('#FFFFFF')
    .borderRadius(8)
    .margin({ left: 16, right: 16, top: 8, bottom: 8 })
    .onClick(() => {
      this.onItemClick?.(this.product)
    })
  }
}

// 加载指示器组件
@Component
struct LoadingIndicator {
  build() {
    Column() {
      LoadingProgress()
        .width(50)
        .height(50)
        .margin({ bottom: 16 })

      Text('加载中...')
        .fontSize(14)
        .fontColor('#999999')
    }
    .width('100%')
    .height('100%')
    .justifyContent(FlexAlign.Center)
    .alignItems(HorizontalAlign.Center)
  }
}

interface Product {
  id: number
  name: string
  price: number
  image: string
}

第五章:鸿蒙分布式特性开发

5.1 跨设备应用迁移

5.1.1 应用迁移基础
typescript 复制代码
import distributedMissionManager from '@ohos.distributedMissionManager';
import deviceManager from '@ohos.distributedHardware.deviceManager';

class ApplicationMigrationManager {
  private dmInstance: deviceManager.DeviceManager;
  private currentMissionId: number = -1;

  async initMigrationCapability() {
    try {
      // 初始化设备管理器
      this.dmInstance = deviceManager.createDeviceManager('com.example.migration');

      // 监听设备状态变化
      this.dmInstance.on('deviceStateChange', (data) => {
        this.handleDeviceStateChange(data);
      });

      // 获取当前任务ID
      this.currentMissionId = await this.getCurrentMissionId();

      console.info('Migration capability initialized');
    } catch (error) {
      console.error('Init migration capability failed:', error);
    }
  }

  // 开始应用迁移
  async startMigration(targetDeviceId: string, wantParam?: any) {
    try {
      const missionParam = {
        deviceId: targetDeviceId,
        missionId: this.currentMissionId,
        wantParam: wantParam || {}
      };

      // 执行迁移
      await distributedMissionManager.startSyncRemoteMissions(targetDeviceId, missionParam);

      console.info('Migration started to device:', targetDeviceId);

      // 保存迁移状态
      await this.saveMigrationState(targetDeviceId);

    } catch (error) {
      console.error('Start migration failed:', error);
      throw error;
    }
  }

  // 处理迁移回调
  async handleMigrationCallback(targetDeviceId: string, result: number) {
    if (result === 0) {
      console.info('Migration successful to:', targetDeviceId);

      // 迁移成功后的处理
      await this.onMigrationSuccess(targetDeviceId);
    } else {
      console.error('Migration failed with result:', result);

      // 迁移失败后的处理
      await this.onMigrationFailed(targetDeviceId, result);
    }
  }

  // 获取可迁移的设备列表
  async getAvailableDevices(): Promise<deviceManager.DeviceInfo[]> {
    try {
      const deviceList = this.dmInstance.getTrustedDeviceListSync();

      // 过滤支持迁移的设备
      return deviceList.filter(device => {
        return this.isDeviceSupportMigration(device);
      });
    } catch (error) {
      console.error('Get available devices failed:', error);
      return [];
    }
  }

  private async getCurrentMissionId(): Promise<number> {
    // 获取当前应用的任务ID
    return 1; // 示例值
  }

  private handleDeviceStateChange(data: any) {
    console.info('Device state changed:', data);

    if (data.action === deviceManager.DeviceStateChangeAction.READY) {
      console.info('Device ready for migration:', data.device.deviceName);
    }
  }

  private isDeviceSupportMigration(device: deviceManager.DeviceInfo): boolean {
    // 检查设备是否支持迁移
    return device.deviceType !== deviceManager.DeviceType.UNKNOWN;
  }

  private async saveMigrationState(targetDeviceId: string) {
    // 保存迁移状态到本地存储
    console.info('Saving migration state for device:', targetDeviceId);
  }

  private async onMigrationSuccess(targetDeviceId: string) {
    // 迁移成功后的清理工作
    console.info('Migration success cleanup for device:', targetDeviceId);
  }

  private async onMigrationFailed(targetDeviceId: string, errorCode: number) {
    // 迁移失败后的恢复工作
    console.error('Migration failed cleanup for device:', targetDeviceId, 'Error:', errorCode);
  }
}
5.1.2 迁移状态保存与恢复
typescript 复制代码
// 应用状态管理器
class MigrationStateManager {
  private static readonly STATE_KEY = 'migration_state';
  private kvStore: distributedData.KVStore;

  async initStateManager() {
    const kvManagerConfig = {
      context: getContext(this),
      bundleName: 'com.example.migration'
    };

    const kvManager = distributedData.createKVManager(kvManagerConfig);

    const options = {
      createIfMissing: true,
      encrypt: false,
      backup: true,
      autoSync: true,
      kvStoreType: distributedData.KVStoreType.DEVICE_COLLABORATION,
      securityLevel: distributedData.SecurityLevel.S2
    };

    this.kvStore = await kvManager.getKVStore('migration_state', options);
  }

  // 保存应用状态
  async saveApplicationState(state: ApplicationState) {
    try {
      const stateJson = JSON.stringify(state);
      await this.kvStore.put(MigrationStateManager.STATE_KEY, stateJson);

      console.info('Application state saved');
    } catch (error) {
      console.error('Save application state failed:', error);
    }
  }

  // 恢复应用状态
  async restoreApplicationState(): Promise<ApplicationState | null> {
    try {
      const stateJson = await this.kvStore.get(MigrationStateManager.STATE_KEY) as string;

      if (stateJson) {
        const state = JSON.parse(stateJson) as ApplicationState;
        console.info('Application state restored');
        return state;
      }

      return null;
    } catch (error) {
      console.error('Restore application state failed:', error);
      return null;
    }
  }

  // 清除状态
  async clearApplicationState() {
    try {
      await this.kvStore.delete(MigrationStateManager.STATE_KEY);
      console.info('Application state cleared');
    } catch (error) {
      console.error('Clear application state failed:', error);
    }
  }
}

// 支持迁移的页面基类
abstract class MigratablePage {
  protected migrationManager = new ApplicationMigrationManager();
  protected stateManager = new MigrationStateManager();

  async aboutToAppear() {
    await this.migrationManager.initMigrationCapability();
    await this.stateManager.initStateManager();

    // 检查是否需要恢复状态
    await this.checkAndRestoreState();
  }

  // 准备迁移
  async prepareMigration(): Promise<ApplicationState> {
    const state: ApplicationState = {
      pageUrl: this.getCurrentPageUrl(),
      pageData: await this.getPageData(),
      userInputs: this.getUserInputs(),
      scrollPosition: this.getScrollPosition(),
      timestamp: Date.now()
    };

    // 保存状态
    await this.stateManager.saveApplicationState(state);

    return state;
  }

  // 执行迁移
  async performMigration(targetDeviceId: string) {
    try {
      // 准备迁移状态
      const state = await this.prepareMigration();

      // 开始迁移
      await this.migrationManager.startMigration(targetDeviceId, {
        migrationState: state
      });

    } catch (error) {
      console.error('Perform migration failed:', error);
      throw error;
    }
  }

  // 检查并恢复状态
  private async checkAndRestoreState() {
    const state = await this.stateManager.restoreApplicationState();

    if (state) {
      console.info('Restoring application state:', state);
      await this.restorePageState(state);
    }
  }

  // 抽象方法,子类需要实现
  protected abstract getCurrentPageUrl(): string;
  protected abstract getPageData(): Promise<any>;
  protected abstract getUserInputs(): any;
  protected abstract getScrollPosition(): number;
  protected abstract restorePageState(state: ApplicationState): Promise<void>;
}

interface ApplicationState {
  pageUrl: string;
  pageData: any;
  userInputs: any;
  scrollPosition: number;
  timestamp: number;
}

5.2 协同组件开发

5.2.1 分布式组件通信
typescript 复制代码
// 分布式组件基类
abstract class DistributedComponent {
  protected deviceId: string = '';
  protected componentId: string = '';
  protected eventBus: DistributedEventBus;

  constructor(componentId: string) {
    this.componentId = componentId;
    this.eventBus = DistributedEventBus.getInstance();
  }

  async initDistributedCapability() {
    // 注册组件
    await this.eventBus.registerComponent(this.componentId, this);

    // 监听远程事件
    this.eventBus.on(`${this.componentId}_remote_event`, (data) => {
      this.handleRemoteEvent(data);
    });
  }

  // 发送事件到远程设备
  async sendEventToRemote(targetDeviceId: string, eventType: string, data: any) {
    await this.eventBus.sendToRemote(targetDeviceId, {
      componentId: this.componentId,
      eventType: eventType,
      data: data
    });
  }

  // 广播事件到所有设备
  async broadcastEvent(eventType: string, data: any) {
    await this.eventBus.broadcast({
      componentId: this.componentId,
      eventType: eventType,
      data: data
    });
  }

  // 处理远程事件
  protected abstract handleRemoteEvent(data: any): void;
}

// 分布式事件总线
class DistributedEventBus {
  private static instance: DistributedEventBus;
  private components: Map<string, DistributedComponent> = new Map();
  private eventListeners: Map<string, Function[]> = new Map();
  private distributedObject: distributedObject.DistributedObject;

  static getInstance(): DistributedEventBus {
    if (!DistributedEventBus.instance) {
      DistributedEventBus.instance = new DistributedEventBus();
    }
    return DistributedEventBus.instance;
  }

  async init() {
    // 创建分布式对象
    this.distributedObject = distributedObject.createDistributedObject({
      events: new Map()
    });

    // 监听分布式对象变化
    this.distributedObject.on('change', (sessionId, fields) => {
      this.handleDistributedObjectChange(sessionId, fields);
    });
  }

  async registerComponent(componentId: string, component: DistributedComponent) {
    this.components.set(componentId, component);
    console.info('Component registered:', componentId);
  }

  on(eventType: string, listener: Function) {
    if (!this.eventListeners.has(eventType)) {
      this.eventListeners.set(eventType, []);
    }
    this.eventListeners.get(eventType)!.push(listener);
  }

  async sendToRemote(targetDeviceId: string, eventData: any) {
    try {
      // 通过分布式对象发送事件
      const eventKey = `${Date.now()}_${Math.random()}`;
      this.distributedObject.events.set(eventKey, {
        targetDeviceId: targetDeviceId,
        ...eventData
      });

      console.info('Event sent to remote device:', targetDeviceId);
    } catch (error) {
      console.error('Send to remote failed:', error);
    }
  }

  async broadcast(eventData: any) {
    try {
      const eventKey = `broadcast_${Date.now()}_${Math.random()}`;
      this.distributedObject.events.set(eventKey, {
        broadcast: true,
        ...eventData
      });

      console.info('Event broadcasted');
    } catch (error) {
      console.error('Broadcast failed:', error);
    }
  }

  private handleDistributedObjectChange(sessionId: string, fields: string[]) {
    fields.forEach(field => {
      if (field === 'events') {
        const events = this.distributedObject.events;
        events.forEach((eventData, eventKey) => {
          this.processRemoteEvent(eventData);
        });
      }
    });
  }

  private processRemoteEvent(eventData: any) {
    const { componentId, eventType } = eventData;
    const eventName = `${componentId}_remote_event`;

    const listeners = this.eventListeners.get(eventName) || [];
    listeners.forEach(listener => {
      listener(eventData);
    });
  }
}
5.2.2 实际应用示例
typescript 复制代码
// 分布式音乐播放器组件
class DistributedMusicPlayer extends DistributedComponent {
  @State private currentSong: Song | null = null;
  @State private isPlaying: boolean = false;
  @State private progress: number = 0;
  @State private volume: number = 50;

  constructor() {
    super('music_player');
  }

  async aboutToAppear() {
    await this.initDistributedCapability();
  }

  build() {
    Column() {
      // 歌曲信息
      if (this.currentSong) {
        Column() {
          Image(this.currentSong.cover)
            .width(200)
            .height(200)
            .borderRadius(12)
            .margin({ bottom: 16 })

          Text(this.currentSong.title)
            .fontSize(20)
            .fontWeight(FontWeight.Bold)
            .margin({ bottom: 8 })

          Text(this.currentSong.artist)
            .fontSize(16)
            .fontColor('#666666')
            .margin({ bottom: 16 })
        }
        .alignItems(HorizontalAlign.Center)
      }

      // 进度条
      Row() {
        Text(this.formatTime(this.progress))
          .fontSize(12)
          .fontColor('#999999')

        Slider({
          value: this.progress,
          min: 0,
          max: this.currentSong?.duration || 100,
          step: 1
        })
          .layoutWeight(1)
          .margin({ left: 12, right: 12 })
          .onChange((value: number) => {
            this.seekTo(value);
          })

        Text(this.formatTime(this.currentSong?.duration || 0))
          .fontSize(12)
          .fontColor('#999999')
      }
      .width('100%')
      .margin({ bottom: 20 })

      // 控制按钮
      Row() {
        Button('上一首')
          .onClick(() => {
            this.previousSong();
          })

        Button(this.isPlaying ? '暂停' : '播放')
          .margin({ left: 16, right: 16 })
          .onClick(() => {
            this.togglePlayPause();
          })

        Button('下一首')
          .onClick(() => {
            this.nextSong();
          })
      }
      .margin({ bottom: 20 })

      // 音量控制
      Row() {
        Text('音量')
          .fontSize(14)
          .margin({ right: 12 })

        Slider({
          value: this.volume,
          min: 0,
          max: 100,
          step: 1
        })
          .layoutWeight(1)
          .onChange((value: number) => {
            this.setVolume(value);
          })
      }
      .width('100%')
      .margin({ bottom: 20 })

      // 设备控制
      Button('同步到其他设备')
        .width('80%')
        .onClick(() => {
          this.syncToOtherDevices();
        })
    }
    .width('100%')
    .padding(20)
    .alignItems(HorizontalAlign.Center)
  }

  private togglePlayPause() {
    this.isPlaying = !this.isPlaying;

    // 同步播放状态到其他设备
    this.broadcastEvent('playStateChanged', {
      isPlaying: this.isPlaying,
      currentSong: this.currentSong,
      progress: this.progress
    });
  }

  private seekTo(position: number) {
    this.progress = position;

    // 同步进度到其他设备
    this.broadcastEvent('progressChanged', {
      progress: this.progress
    });
  }

  private setVolume(volume: number) {
    this.volume = volume;

    // 同步音量到其他设备
    this.broadcastEvent('volumeChanged', {
      volume: this.volume
    });
  }

  private previousSong() {
    // 切换到上一首歌曲的逻辑
    this.broadcastEvent('songChanged', {
      action: 'previous'
    });
  }

  private nextSong() {
    // 切换到下一首歌曲的逻辑
    this.broadcastEvent('songChanged', {
      action: 'next'
    });
  }

  private async syncToOtherDevices() {
    const currentState = {
      currentSong: this.currentSong,
      isPlaying: this.isPlaying,
      progress: this.progress,
      volume: this.volume
    };

    await this.broadcastEvent('fullStateSync', currentState);
  }

  protected handleRemoteEvent(data: any) {
    const { eventType, data: eventData } = data;

    switch (eventType) {
      case 'playStateChanged':
        this.isPlaying = eventData.isPlaying;
        this.currentSong = eventData.currentSong;
        this.progress = eventData.progress;
        break;

      case 'progressChanged':
        this.progress = eventData.progress;
        break;

      case 'volumeChanged':
        this.volume = eventData.volume;
        break;

      case 'songChanged':
        this.handleSongChange(eventData.action);
        break;

      case 'fullStateSync':
        this.currentSong = eventData.currentSong;
        this.isPlaying = eventData.isPlaying;
        this.progress = eventData.progress;
        this.volume = eventData.volume;
        break;
    }
  }

  private handleSongChange(action: string) {
    // 处理歌曲切换
    console.info('Handle song change:', action);
  }

  private formatTime(seconds: number): string {
    const mins = Math.floor(seconds / 60);
    const secs = Math.floor(seconds % 60);
    return `${mins.toString().padStart(2, '0')}:${secs.toString().padStart(2, '0')}`;
  }
}

interface Song {
  id: string;
  title: string;
  artist: string;
  cover: string;
  duration: number;
  url: string;
}

5.3 分布式文件系统

5.3.1 跨设备文件访问
typescript 复制代码
import distributedFile from '@ohos.file.distributedFile';
import fs from '@ohos.file.fs';

class DistributedFileManager {
  private static instance: DistributedFileManager;

  static getInstance(): DistributedFileManager {
    if (!DistributedFileManager.instance) {
      DistributedFileManager.instance = new DistributedFileManager();
    }
    return DistributedFileManager.instance;
  }

  // 获取分布式文件路径
  async getDistributedFilePath(deviceId: string, bundleName: string, fileName: string): Promise<string> {
    try {
      const distributedPath = await distributedFile.getDistributedFilePath(deviceId, bundleName, fileName);
      console.info('Distributed file path:', distributedPath);
      return distributedPath;
    } catch (error) {
      console.error('Get distributed file path failed:', error);
      throw error;
    }
  }

  // 读取远程设备文件
  async readRemoteFile(deviceId: string, bundleName: string, fileName: string): Promise<string> {
    try {
      const filePath = await this.getDistributedFilePath(deviceId, bundleName, fileName);

      const file = fs.openSync(filePath, fs.OpenMode.READ_ONLY);
      const buffer = new ArrayBuffer(1024 * 1024); // 1MB buffer
      const readResult = fs.readSync(file.fd, buffer);

      fs.closeSync(file);

      const content = String.fromCharCode.apply(null, new Uint8Array(buffer, 0, readResult));
      return content;
    } catch (error) {
      console.error('Read remote file failed:', error);
      throw error;
    }
  }

  // 写入文件到远程设备
  async writeRemoteFile(deviceId: string, bundleName: string, fileName: string, content: string): Promise<void> {
    try {
      const filePath = await this.getDistributedFilePath(deviceId, bundleName, fileName);

      const file = fs.openSync(filePath, fs.OpenMode.CREATE | fs.OpenMode.WRITE_ONLY);
      const buffer = new ArrayBuffer(content.length);
      const uint8Array = new Uint8Array(buffer);

      for (let i = 0; i < content.length; i++) {
        uint8Array[i] = content.charCodeAt(i);
      }

      fs.writeSync(file.fd, buffer);
      fs.closeSync(file);

      console.info('Write remote file success:', fileName);
    } catch (error) {
      console.error('Write remote file failed:', error);
      throw error;
    }
  }

  // 同步文件到多个设备
  async syncFileToDevices(fileName: string, content: string, targetDevices: string[]): Promise<void> {
    const bundleName = 'com.example.app';
    const syncPromises = targetDevices.map(deviceId =>
      this.writeRemoteFile(deviceId, bundleName, fileName, content)
    );

    try {
      await Promise.all(syncPromises);
      console.info('File synced to all devices:', fileName);
    } catch (error) {
      console.error('Sync file to devices failed:', error);
      throw error;
    }
  }

  // 获取文件列表
  async getRemoteFileList(deviceId: string, bundleName: string, dirPath: string): Promise<FileInfo[]> {
    try {
      const distributedDirPath = await distributedFile.getDistributedFilePath(deviceId, bundleName, dirPath);
      const files = fs.listFileSync(distributedDirPath);

      const fileInfoList: FileInfo[] = [];

      for (const fileName of files) {
        const filePath = `${distributedDirPath}/${fileName}`;
        const stat = fs.statSync(filePath);

        fileInfoList.push({
          name: fileName,
          path: filePath,
          size: stat.size,
          isDirectory: stat.isDirectory(),
          modifiedTime: stat.mtime
        });
      }

      return fileInfoList;
    } catch (error) {
      console.error('Get remote file list failed:', error);
      return [];
    }
  }

  // 删除远程文件
  async deleteRemoteFile(deviceId: string, bundleName: string, fileName: string): Promise<void> {
    try {
      const filePath = await this.getDistributedFilePath(deviceId, bundleName, fileName);
      fs.unlinkSync(filePath);

      console.info('Remote file deleted:', fileName);
    } catch (error) {
      console.error('Delete remote file failed:', error);
      throw error;
    }
  }
}

// 分布式文件浏览器组件
@Component
struct DistributedFileBrowser {
  @State private fileList: FileInfo[] = [];
  @State private currentPath: string = '';
  @State private selectedDeviceId: string = '';
  @State private loading: boolean = false;
  private fileManager: DistributedFileManager = DistributedFileManager.getInstance();

  build() {
    Column() {
      // 设备选择
      Row() {
        Text('设备:')
          .fontSize(16)
          .margin({ right: 8 })

        Button(this.selectedDeviceId || '选择设备')
          .layoutWeight(1)
          .onClick(() => {
            this.showDeviceSelector();
          })
      }
      .width('100%')
      .padding(16)

      // 当前路径
      if (this.currentPath) {
        Text(`路径:${this.currentPath}`)
          .fontSize(14)
          .fontColor('#666666')
          .width('100%')
          .padding({ left: 16, right: 16, bottom: 8 })
      }

      // 文件列表
      if (this.loading) {
        LoadingIndicator()
      } else {
        List() {
          ForEach(this.fileList, (file: FileInfo) => {
            ListItem() {
              FileItem({
                fileInfo: file,
                onItemClick: (item: FileInfo) => {
                  this.handleFileClick(item);
                },
                onDeleteClick: (item: FileInfo) => {
                  this.deleteFile(item);
                }
              })
            }
          })
        }
        .layoutWeight(1)
      }

      // 操作按钮
      Row() {
        Button('刷新')
          .layoutWeight(1)
          .margin({ right: 8 })
          .onClick(() => {
            this.refreshFileList();
          })

        Button('上传文件')
          .layoutWeight(1)
          .margin({ left: 8 })
          .onClick(() => {
            this.uploadFile();
          })
      }
      .width('100%')
      .padding(16)
    }
    .width('100%')
    .height('100%')
  }

  private async loadFileList() {
    if (!this.selectedDeviceId) {
      return;
    }

    this.loading = true;

    try {
      this.fileList = await this.fileManager.getRemoteFileList(
        this.selectedDeviceId,
        'com.example.app',
        this.currentPath || '/'
      );
    } catch (error) {
      console.error('Load file list failed:', error);
    } finally {
      this.loading = false;
    }
  }

  private showDeviceSelector() {
    // 显示设备选择器
    console.info('Show device selector');
  }

  private handleFileClick(file: FileInfo) {
    if (file.isDirectory) {
      this.currentPath = file.path;
      this.loadFileList();
    } else {
      this.openFile(file);
    }
  }

  private async openFile(file: FileInfo) {
    try {
      const content = await this.fileManager.readRemoteFile(
        this.selectedDeviceId,
        'com.example.app',
        file.name
      );

      console.info('File content:', content);
      // 处理文件内容
    } catch (error) {
      console.error('Open file failed:', error);
    }
  }

  private async deleteFile(file: FileInfo) {
    try {
      await this.fileManager.deleteRemoteFile(
        this.selectedDeviceId,
        'com.example.app',
        file.name
      );

      // 刷新文件列表
      await this.loadFileList();
    } catch (error) {
      console.error('Delete file failed:', error);
    }
  }

  private refreshFileList() {
    this.loadFileList();
  }

  private uploadFile() {
    // 上传文件逻辑
    console.info('Upload file');
  }
}

@Component
struct FileItem {
  @Prop fileInfo: FileInfo;
  private onItemClick?: (file: FileInfo) => void;
  private onDeleteClick?: (file: FileInfo) => void;

  build() {
    Row() {
      // 文件图标
      Image(this.fileInfo.isDirectory ? $r('app.media.folder_icon') : $r('app.media.file_icon'))
        .width(32)
        .height(32)
        .margin({ right: 12 })

      // 文件信息
      Column() {
        Text(this.fileInfo.name)
          .fontSize(16)
          .fontWeight(FontWeight.Medium)
          .alignSelf(ItemAlign.Start)
          .margin({ bottom: 4 })

        Row() {
          Text(this.formatFileSize(this.fileInfo.size))
            .fontSize(12)
            .fontColor('#999999')
            .margin({ right: 16 })

          Text(this.formatDate(this.fileInfo.modifiedTime))
            .fontSize(12)
            .fontColor('#999999')
        }
        .alignSelf(ItemAlign.Start)
      }
      .layoutWeight(1)
      .alignItems(HorizontalAlign.Start)

      // 删除按钮
      Button('删除')
        .fontSize(12)
        .backgroundColor('#FF4444')
        .onClick(() => {
          this.onDeleteClick?.(this.fileInfo);
        })
    }
    .width('100%')
    .padding(16)
    .backgroundColor('#FFFFFF')
    .borderRadius(8)
    .margin({ left: 16, right: 16, top: 4, bottom: 4 })
    .onClick(() => {
      this.onItemClick?.(this.fileInfo);
    })
  }

  private formatFileSize(size: number): string {
    if (size < 1024) {
      return `${size} B`;
    } else if (size < 1024 * 1024) {
      return `${(size / 1024).toFixed(1)} KB`;
    } else {
      return `${(size / (1024 * 1024)).toFixed(1)} MB`;
    }
  }

  private formatDate(timestamp: number): string {
    const date = new Date(timestamp);
    return `${date.getFullYear()}-${(date.getMonth() + 1).toString().padStart(2, '0')}-${date.getDate().toString().padStart(2, '0')}`;
  }
}

interface FileInfo {
  name: string;
  path: string;
  size: number;
  isDirectory: boolean;
  modifiedTime: number;
}

第六章:性能优化与最佳实践

6.1 应用性能优化

6.1.1 启动性能优化
typescript 复制代码
// 应用启动优化管理器
class AppStartupOptimizer {
  private static instance: AppStartupOptimizer;
  private preloadTasks: Map<string, () => Promise<void>> = new Map();
  private criticalResources: string[] = [];

  static getInstance(): AppStartupOptimizer {
    if (!AppStartupOptimizer.instance) {
      AppStartupOptimizer.instance = new AppStartupOptimizer();
    }
    return AppStartupOptimizer.instance;
  }

  // 注册预加载任务
  registerPreloadTask(taskName: string, task: () => Promise<void>) {
    this.preloadTasks.set(taskName, task);
  }

  // 注册关键资源
  registerCriticalResource(resourcePath: string) {
    this.criticalResources.push(resourcePath);
  }

  // 执行启动优化
  async optimizeStartup() {
    const startTime = Date.now();

    try {
      // 并行预加载关键资源
      await this.preloadCriticalResources();

      // 执行预加载任务
      await this.executePreloadTasks();

      // 初始化缓存
      await this.initializeCache();

      const endTime = Date.now();
      console.info(`Startup optimization completed in ${endTime - startTime}ms`);
    } catch (error) {
      console.error('Startup optimization failed:', error);
    }
  }

  private async preloadCriticalResources() {
    const preloadPromises = this.criticalResources.map(async (resourcePath) => {
      try {
        // 预加载图片资源
        if (resourcePath.endsWith('.png') || resourcePath.endsWith('.jpg')) {
          await this.preloadImage(resourcePath);
        }
        // 预加载字体资源
        else if (resourcePath.endsWith('.ttf') || resourcePath.endsWith('.otf')) {
          await this.preloadFont(resourcePath);
        }
        // 预加载数据
        else if (resourcePath.endsWith('.json')) {
          await this.preloadData(resourcePath);
        }
      } catch (error) {
        console.error(`Failed to preload resource: ${resourcePath}`, error);
      }
    });

    await Promise.all(preloadPromises);
  }

  private async executePreloadTasks() {
    const taskPromises = Array.from(this.preloadTasks.entries()).map(async ([taskName, task]) => {
      try {
        await task();
        console.info(`Preload task completed: ${taskName}`);
      } catch (error) {
        console.error(`Preload task failed: ${taskName}`, error);
      }
    });

    await Promise.all(taskPromises);
  }

  private async preloadImage(imagePath: string) {
    // 图片预加载逻辑
    console.info('Preloading image:', imagePath);
  }

  private async preloadFont(fontPath: string) {
    // 字体预加载逻辑
    console.info('Preloading font:', fontPath);
  }

  private async preloadData(dataPath: string) {
    // 数据预加载逻辑
    console.info('Preloading data:', dataPath);
  }

  private async initializeCache() {
    // 初始化应用缓存
    console.info('Initializing cache');
  }
}

// 在应用入口使用启动优化
export default class EntryAbility extends UIAbility {
  private startupOptimizer: AppStartupOptimizer = AppStartupOptimizer.getInstance();

  onCreate(want: Want, launchParam: AbilityConstant.LaunchParam) {
    console.info('[EntryAbility] onCreate');

    // 注册关键资源
    this.startupOptimizer.registerCriticalResource('app.media.logo');
    this.startupOptimizer.registerCriticalResource('app.media.background');
    this.startupOptimizer.registerCriticalResource('resources/base/profile/main_pages.json');

    // 注册预加载任务
    this.startupOptimizer.registerPreloadTask('initUserData', async () => {
      await this.initializeUserData();
    });

    this.startupOptimizer.registerPreloadTask('initNetworkConfig', async () => {
      await this.initializeNetworkConfig();
    });
  }

  onWindowStageCreate(windowStage: window.WindowStage) {
    console.info('[EntryAbility] onWindowStageCreate');

    // 执行启动优化
    this.startupOptimizer.optimizeStartup().then(() => {
      // 加载主页面
      windowStage.loadContent('pages/Index', (err, data) => {
        if (err.code) {
          console.error('Failed to load the content:', JSON.stringify(err));
          return;
        }
        console.info('Succeeded in loading the content:', JSON.stringify(data));
      });
    });
  }

  private async initializeUserData() {
    // 初始化用户数据
    console.info('Initializing user data');
  }

  private async initializeNetworkConfig() {
    // 初始化网络配置
    console.info('Initializing network config');
  }
}
6.1.2 内存管理优化
typescript 复制代码
// 内存管理器
class MemoryManager {
  private static instance: MemoryManager;
  private imageCache: Map<string, ImageBitmap> = new Map();
  private dataCache: Map<string, any> = new Map();
  private maxCacheSize: number = 50 * 1024 * 1024; // 50MB
  private currentCacheSize: number = 0;

  static getInstance(): MemoryManager {
    if (!MemoryManager.instance) {
      MemoryManager.instance = new MemoryManager();
    }
    return MemoryManager.instance;
  }

  // 缓存图片
  cacheImage(key: string, image: ImageBitmap, size: number) {
    if (this.currentCacheSize + size > this.maxCacheSize) {
      this.evictLRUCache(size);
    }

    this.imageCache.set(key, image);
    this.currentCacheSize += size;

    console.info(`Image cached: ${key}, size: ${size}, total: ${this.currentCacheSize}`);
  }

  // 获取缓存图片
  getCachedImage(key: string): ImageBitmap | null {
    return this.imageCache.get(key) || null;
  }

  // 缓存数据
  cacheData(key: string, data: any) {
    const size = this.calculateDataSize(data);

    if (this.currentCacheSize + size > this.maxCacheSize) {
      this.evictLRUCache(size);
    }

    this.dataCache.set(key, {
      data: data,
      timestamp: Date.now(),
      size: size
    });

    this.currentCacheSize += size;
  }

  // 获取缓存数据
  getCachedData(key: string): any {
    const cached = this.dataCache.get(key);
    if (cached) {
      // 更新访问时间
      cached.timestamp = Date.now();
      return cached.data;
    }
    return null;
  }

  // LRU缓存淘汰
  private evictLRUCache(requiredSize: number) {
    const allEntries = Array.from(this.dataCache.entries())
      .sort((a, b) => a[1].timestamp - b[1].timestamp);

    let freedSize = 0;

    for (const [key, value] of allEntries) {
      this.dataCache.delete(key);
      freedSize += value.size;
      this.currentCacheSize -= value.size;

      if (freedSize >= requiredSize) {
        break;
      }
    }

    console.info(`Evicted ${freedSize} bytes from cache`);
  }

  // 计算数据大小
  private calculateDataSize(data: any): number {
    return JSON.stringify(data).length * 2; // 粗略估算
  }

  // 清理缓存
  clearCache() {
    this.imageCache.clear();
    this.dataCache.clear();
    this.currentCacheSize = 0;
    console.info('Cache cleared');
  }

  // 获取内存使用情况
  getMemoryUsage(): MemoryUsage {
    return {
      totalCacheSize: this.currentCacheSize,
      maxCacheSize: this.maxCacheSize,
      imageCount: this.imageCache.size,
      dataCount: this.dataCache.size,
      usagePercentage: (this.currentCacheSize / this.maxCacheSize) * 100
    };
  }
}

// 内存监控组件
@Component
struct MemoryMonitor {
  @State private memoryUsage: MemoryUsage = {
    totalCacheSize: 0,
    maxCacheSize: 0,
    imageCount: 0,
    dataCount: 0,
    usagePercentage: 0
  };

  private memoryManager: MemoryManager = MemoryManager.getInstance();
  private timer: number = -1;

  aboutToAppear() {
    this.updateMemoryUsage();
    this.timer = setInterval(() => {
      this.updateMemoryUsage();
    }, 5000); // 每5秒更新一次
  }

  aboutToDisappear() {
    if (this.timer !== -1) {
      clearInterval(this.timer);
    }
  }

  build() {
    Column() {
      Text('内存使用监控')
        .fontSize(18)
        .fontWeight(FontWeight.Bold)
        .margin({ bottom: 16 })

      // 内存使用进度条
      Row() {
        Text('缓存使用率:')
          .fontSize(14)
          .margin({ right: 8 })

        Progress({
          value: this.memoryUsage.usagePercentage,
          total: 100,
          type: ProgressType.Linear
        })
          .layoutWeight(1)
          .margin({ right: 8 })

        Text(`${this.memoryUsage.usagePercentage.toFixed(1)}%`)
          .fontSize(12)
          .fontColor('#666666')
      }
      .width('100%')
      .margin({ bottom: 12 })

      // 详细信息
      Column() {
        this.createInfoRow('总缓存大小', this.formatBytes(this.memoryUsage.totalCacheSize))
        this.createInfoRow('最大缓存大小', this.formatBytes(this.memoryUsage.maxCacheSize))
        this.createInfoRow('图片缓存数量', this.memoryUsage.imageCount.toString())
        this.createInfoRow('数据缓存数量', this.memoryUsage.dataCount.toString())
      }
      .alignItems(HorizontalAlign.Start)
      .margin({ bottom: 16 })

      // 操作按钮
      Button('清理缓存')
        .width('100%')
        .onClick(() => {
          this.memoryManager.clearCache();
          this.updateMemoryUsage();
        })
    }
    .width('100%')
    .padding(16)
    .backgroundColor('#F5F5F5')
    .borderRadius(8)
  }

  @Builder
  createInfoRow(label: string, value: string) {
    Row() {
      Text(label)
        .fontSize(14)
        .fontColor('#333333')
        .layoutWeight(1)

      Text(value)
        .fontSize(14)
        .fontColor('#666666')
    }
    .width('100%')
    .margin({ bottom: 8 })
  }

  private updateMemoryUsage() {
    this.memoryUsage = this.memoryManager.getMemoryUsage();
  }

  private formatBytes(bytes: number): string {
    if (bytes < 1024) {
      return `${bytes} B`;
    } else if (bytes < 1024 * 1024) {
      return `${(bytes / 1024).toFixed(1)} KB`;
    } else {
      return `${(bytes / (1024 * 1024)).toFixed(1)} MB`;
    }
  }
}

interface MemoryUsage {
  totalCacheSize: number;
  maxCacheSize: number;
  imageCount: number;
  dataCount: number;
  usagePercentage: number;
}

6.2 UI渲染优化

6.2.1 列表性能优化
typescript 复制代码
// 虚拟列表组件
@Component
struct VirtualList {
  @Prop items: any[];
  @Prop itemHeight: number = 60;
  @Prop containerHeight: number = 400;
  @State private visibleItems: any[] = [];
  @State private scrollOffset: number = 0;
  private visibleCount: number = 0;
  private startIndex: number = 0;
  private endIndex: number = 0;

  aboutToAppear() {
    this.visibleCount = Math.ceil(this.containerHeight / this.itemHeight) + 2;
    this.updateVisibleItems();
  }

  build() {
    Column() {
      Scroll() {
        Column() {
          // 顶部占位
          if (this.startIndex > 0) {
            Blank()
              .height(this.startIndex * this.itemHeight)
          }

          // 可见项目
          ForEach(this.visibleItems, (item: any, index: number) => {
            ListItem() {
              this.itemBuilder(item, this.startIndex + index)
            }
            .height(this.itemHeight)
          })

          // 底部占位
          if (this.endIndex < this.items.length - 1) {
            Blank()
              .height((this.items.length - this.endIndex - 1) * this.itemHeight)
          }
        }
      }
      .height(this.containerHeight)
      .onScroll((xOffset: number, yOffset: number) => {
        this.scrollOffset = yOffset;
        this.updateVisibleItems();
      })
    }
  }

  @Builder
  itemBuilder(item: any, index: number) {
    Row() {
      Text(`Item ${index}: ${item.title || item.name || item}`)
        .fontSize(16)
        .layoutWeight(1)
        .padding(16)
    }
    .width('100%')
    .backgroundColor('#FFFFFF')
    .borderRadius(4)
    .margin({ bottom: 1 })
  }

  private updateVisibleItems() {
    this.startIndex = Math.floor(this.scrollOffset / this.itemHeight);
    this.endIndex = Math.min(this.startIndex + this.visibleCount, this.items.length - 1);

    this.visibleItems = this.items.slice(this.startIndex, this.endIndex + 1);
  }
}

// 优化的图片加载组件
@Component
struct OptimizedImage {
  @Prop src: string;
  @Prop width: number = 100;
  @Prop height: number = 100;
  @Prop placeholder?: string;
  @State private loaded: boolean = false;
  @State private error: boolean = false;
  private memoryManager: MemoryManager = MemoryManager.getInstance();

  build() {
    Stack() {
      if (this.error) {
        // 错误占位符
        Column() {
          Image($r('app.media.error_icon'))
            .width(32)
            .height(32)
            .margin({ bottom: 8 })

          Text('加载失败')
            .fontSize(12)
            .fontColor('#999999')
        }
        .justifyContent(FlexAlign.Center)
        .alignItems(HorizontalAlign.Center)
        .width(this.width)
        .height(this.height)
        .backgroundColor('#F0F0F0')
      } else if (!this.loaded) {
        // 加载占位符
        Column() {
          if (this.placeholder) {
            Image(this.placeholder)
              .width(this.width)
              .height(this.height)
              .objectFit(ImageFit.Cover)
          } else {
            Column() {
              Image($r('app.media.loading_icon'))
                .width(24)
                .height(24)
                .margin({ bottom: 8 })

              Text('加载中...')
                .fontSize(12)
                .fontColor('#999999')
            }
            .justifyContent(FlexAlign.Center)
            .alignItems(HorizontalAlign.Center)
            .width(this.width)
            .height(this.height)
            .backgroundColor('#F0F0F0')
          }
        }
      } else {
        // 实际图片
        Image(this.src)
          .width(this.width)
          .height(this.height)
          .objectFit(ImageFit.Cover)
          .onComplete(() => {
            this.loaded = true;
            this.error = false;
          })
          .onError(() => {
            this.loaded = false;
            this.error = true;
          })
      }
    }
  }

  aboutToAppear() {
    this.preloadImage();
  }

  private async preloadImage() {
    try {
      // 检查缓存
      const cached = this.memoryManager.getCachedImage(this.src);
      if (cached) {
        this.loaded = true;
        return;
      }

      // 预加载图片
      const image = new Image();
      image.onload = () => {
        this.loaded = true;
        this.error = false;

        // 缓存图片
        const size = this.width * this.height * 4; // 估算大小
        this.memoryManager.cacheImage(this.src, image as any, size);
      };

      image.onerror = () => {
        this.loaded = false;
        this.error = true;
      };

      image.src = this.src;
    } catch (error) {
      console.error('Preload image failed:', error);
      this.error = true;
    }
  }
}

6.3 网络优化

6.3.1 请求优化和缓存策略
typescript 复制代码
// 网络请求优化管理器
class NetworkOptimizer {
  private static instance: NetworkOptimizer;
  private requestCache: Map<string, CachedResponse> = new Map();
  private pendingRequests: Map<string, Promise<any>> = new Map();
  private retryConfig: RetryConfig = {
    maxRetries: 3,
    retryDelay: 1000,
    backoffMultiplier: 2
  };

  static getInstance(): NetworkOptimizer {
    if (!NetworkOptimizer.instance) {
      NetworkOptimizer.instance = new NetworkOptimizer();
    }
    return NetworkOptimizer.instance;
  }

  // 优化的HTTP请求
  async request(options: RequestOptions): Promise<any> {
    const cacheKey = this.generateCacheKey(options);

    // 检查缓存
    if (options.cache && this.isCacheValid(cacheKey)) {
      console.info('Returning cached response for:', options.url);
      return this.requestCache.get(cacheKey)!.data;
    }

    // 检查是否有相同的请求正在进行
    if (this.pendingRequests.has(cacheKey)) {
      console.info('Reusing pending request for:', options.url);
      return this.pendingRequests.get(cacheKey)!;
    }

    // 创建新请求
    const requestPromise = this.executeRequest(options);
    this.pendingRequests.set(cacheKey, requestPromise);

    try {
      const response = await requestPromise;

      // 缓存响应
      if (options.cache) {
        this.cacheResponse(cacheKey, response, options.cacheTimeout || 300000); // 默认5分钟
      }

      return response;
    } finally {
      this.pendingRequests.delete(cacheKey);
    }
  }

  private async executeRequest(options: RequestOptions): Promise<any> {
    let lastError: Error | null = null;

    for (let attempt = 0; attempt <= this.retryConfig.maxRetries; attempt++) {
      try {
        const response = await this.performHttpRequest(options);

        if (response.responseCode === 200) {
          return JSON.parse(response.result.toString());
        } else {
          throw new Error(`HTTP ${response.responseCode}: ${response.result}`);
        }
      } catch (error) {
        lastError = error as Error;

        if (attempt < this.retryConfig.maxRetries) {
          const delay = this.retryConfig.retryDelay * Math.pow(this.retryConfig.backoffMultiplier, attempt);
          console.warn(`Request failed, retrying in ${delay}ms. Attempt ${attempt + 1}/${this.retryConfig.maxRetries}`);
          await this.delay(delay);
        }
      }
    }

    throw lastError;
  }

  private async performHttpRequest(options: RequestOptions): Promise<any> {
    return new Promise((resolve, reject) => {
      const httpRequest = http.createHttp();

      httpRequest.request(options.url, {
        method: options.method || http.RequestMethod.GET,
        header: options.headers || {},
        extraData: options.data
      }, (err, data) => {
        if (err) {
          reject(err);
        } else {
          resolve(data);
        }
        httpRequest.destroy();
      });
    });
  }

  private generateCacheKey(options: RequestOptions): string {
    const keyData = {
      url: options.url,
      method: options.method || 'GET',
      data: options.data
    };
    return JSON.stringify(keyData);
  }

  private isCacheValid(cacheKey: string): boolean {
    const cached = this.requestCache.get(cacheKey);
    if (!cached) {
      return false;
    }

    return Date.now() < cached.expireTime;
  }

  private cacheResponse(cacheKey: string, data: any, timeout: number) {
    this.requestCache.set(cacheKey, {
      data: data,
      expireTime: Date.now() + timeout
    });
  }

  private delay(ms: number): Promise<void> {
    return new Promise(resolve => setTimeout(resolve, ms));
  }

  // 批量请求优化
  async batchRequest(requests: RequestOptions[]): Promise<any[]> {
    const batchSize = 5; // 并发限制
    const results: any[] = [];

    for (let i = 0; i < requests.length; i += batchSize) {
      const batch = requests.slice(i, i + batchSize);
      const batchPromises = batch.map(request => this.request(request));

      try {
        const batchResults = await Promise.all(batchPromises);
        results.push(...batchResults);
      } catch (error) {
        console.error('Batch request failed:', error);
        throw error;
      }
    }

    return results;
  }

  // 清理过期缓存
  cleanExpiredCache() {
    const now = Date.now();
    const expiredKeys: string[] = [];

    this.requestCache.forEach((cached, key) => {
      if (now >= cached.expireTime) {
        expiredKeys.push(key);
      }
    });

    expiredKeys.forEach(key => {
      this.requestCache.delete(key);
    });

    console.info(`Cleaned ${expiredKeys.length} expired cache entries`);
  }
}

interface RequestOptions {
  url: string;
  method?: string;
  headers?: Record<string, string>;
  data?: any;
  cache?: boolean;
  cacheTimeout?: number;
}

interface CachedResponse {
  data: any;
  expireTime: number;
}

interface RetryConfig {
  maxRetries: number;
  retryDelay: number;
  backoffMultiplier: number;
}

第七章:总结与展望

7.1 知识点总结

通过本文的深入学习,我们全面掌握了鸿蒙HarmonyOS开发的核心技术和实践方法:

7.1.1 核心技术要点
  1. 系统架构理解

    • 分布式软总线架构的设计理念
    • 分层架构中各层的职责和交互
    • ArkTS语言的特性和优势
    • 声明式UI开发范式
  2. 开发环境掌握

    • DevEco Studio的安装和配置
    • SDK管理和版本控制
    • 项目创建和结构分析
    • 调试和测试工具使用
  3. 应用开发基础

    • UIAbility生命周期管理
    • ServiceExtensionAbility服务开发
    • 自定义组件设计
    • 状态管理和数据绑定
    • 页面路由和导航
  4. 分布式特性开发

    • 跨设备应用迁移
    • 协同组件通信
    • 分布式文件系统访问
    • 设备发现和连接管理
  5. 性能优化实践

    • 应用启动性能优化
    • 内存管理和缓存策略
    • UI渲染性能提升
    • 网络请求优化
7.1.2 开发最佳实践
  1. 代码组织

    • 模块化设计原则
    • 组件复用策略
    • 状态管理模式
    • 错误处理机制
  2. 性能考虑

    • 懒加载和预加载平衡
    • 内存使用监控
    • 网络请求合并
    • 缓存策略设计
  3. 用户体验

    • 响应式设计
    • 加载状态提示
    • 错误友好提示
    • 无障碍访问支持

7.2 技术扩展与深入学习

7.2.1 进阶技术方向
  1. 分布式数据管理

    • 分布式数据库设计
    • 数据同步策略
    • 冲突解决机制
    • 数据安全和隐私保护
  2. AI能力集成

    • 机器学习模型集成
    • 语音识别和合成
    • 图像处理和识别
    • 自然语言处理
  3. IoT设备连接

    • 智能家居设备控制
    • 传感器数据采集
    • 设备状态监控
    • 自动化场景配置
  4. 企业级应用开发

    • 大型应用架构设计
    • 微服务集成
    • 安全认证和授权
    • 数据分析和报表
7.2.2 学习资源推荐
  1. 官方文档和资源

  2. 社区和论坛

    • HarmonyOS开发者社区
    • 华为开发者联盟
    • GitHub开源项目
    • Stack Overflow相关标签
  3. 实践项目建议

    • 个人任务管理应用
    • 智能家居控制中心
    • 多设备协同笔记应用
    • 分布式音视频播放器

7.3 技术发展趋势与思考

7.3.1 行业发展趋势
  1. 万物互联时代

    • 设备连接数量爆发式增长
    • 跨设备协同需求增强
    • 边缘计算能力提升
    • 5G网络普及加速
  2. AI原生应用

    • 智能化功能成为标配
    • 个性化体验需求增长
    • 自然交互方式普及
    • 预测性服务兴起
  3. 隐私和安全

    • 数据保护法规完善
    • 用户隐私意识提高
    • 零信任安全架构
    • 端侧计算重要性增强
7.3.2 技术挑战与机遇
  1. 技术挑战

    • 设备碎片化问题
    • 网络延迟和稳定性
    • 电池续航优化
    • 开发复杂度增加
  2. 发展机遇

    • 新兴应用场景涌现
    • 开发工具不断完善
    • 生态系统日趋成熟
    • 市场需求持续增长

7.4 实践建议与行动计划

7.4.1 学习路径建议
  1. 基础阶段(1-2个月)

    • 熟悉ArkTS语法和特性
    • 掌握基本组件使用
    • 完成简单应用开发
    • 理解应用生命周期
  2. 进阶阶段(2-3个月)

    • 深入分布式特性开发
    • 掌握性能优化技巧
    • 学习复杂状态管理
    • 实践企业级应用开发
  3. 专家阶段(3-6个月)

    • 参与开源项目贡献
    • 设计复杂应用架构
    • 分享技术经验
    • 探索前沿技术应用
7.4.2 实践项目推荐
  1. 入门项目

    typescript 复制代码
    // 待办事项管理应用
    // 功能:任务创建、编辑、删除、状态管理
    // 技术点:基础组件、状态管理、本地存储
  2. 进阶项目

    typescript 复制代码
    // 多设备协同笔记应用
    // 功能:实时同步、离线编辑、富文本支持
    // 技术点:分布式数据、冲突解决、UI优化
  3. 高级项目

    typescript 复制代码
    // 智能家居控制中心
    // 功能:设备发现、远程控制、场景自动化
    // 技术点:IoT集成、AI能力、安全认证

7.5 互动与交流

7.5.1 讨论话题
  1. 技术选型讨论

    • 在什么场景下选择HarmonyOS开发?
    • 如何平衡功能丰富性和性能表现?
    • 分布式特性的最佳应用场景是什么?
  2. 开发经验分享

    • 你在HarmonyOS开发中遇到的最大挑战是什么?
    • 有哪些提高开发效率的技巧和工具?
    • 如何设计用户友好的分布式应用体验?
  3. 未来发展预测

    • HarmonyOS生态系统的发展前景如何?
    • 哪些新兴技术会与HarmonyOS深度融合?
    • 开发者应该重点关注哪些技术方向?
7.5.2 学习交流建议
  1. 加入技术社区

    • 参与官方开发者社区讨论
    • 关注技术博客和公众号
    • 参加线上线下技术分享会
    • 加入相关技术交流群
  2. 实践分享

    • 记录学习笔记和心得
    • 分享项目开发经验
    • 贡献开源代码和文档
    • 帮助其他开发者解决问题
  3. 持续学习

    • 关注官方技术更新
    • 学习相关前沿技术
    • 参与技术认证考试
    • 建立个人技术品牌

结语

鸿蒙HarmonyOS作为面向万物互联时代的操作系统,为开发者提供了前所未有的技术机遇。通过本文的学习,相信你已经掌握了HarmonyOS开发的核心技术和实践方法。

技术的学习是一个持续的过程,希望你能够:

  • 🔖 收藏本文,作为学习和开发的参考资料
  • 👍 点赞支持,让更多开发者看到这些有价值的内容
  • 💬 积极讨论,在评论区分享你的学习心得和实践经验
  • 🚀 持续实践,将所学知识应用到实际项目中

让我们一起在HarmonyOS的技术道路上不断前行,共同构建更加智能、互联的数字世界!


本文涵盖了HarmonyOS开发的核心技术点,包含大量实用代码示例。如果你觉得有帮助,请不要忘记点赞收藏,也欢迎在评论区分享你的学习心得和项目经验!

相关推荐
胖咕噜的稞达鸭3 小时前
AVL树手撕,超详细图文详解
c语言·开发语言·数据结构·c++·算法·visual studio
007php0073 小时前
百度面试题解析:synchronized、volatile、JMM内存模型、JVM运行时区域及堆和方法区(三)
java·开发语言·jvm·缓存·面试·golang·php
okjohn4 小时前
浅谈需求分析与管理
java·架构·系统架构·软件工程·产品经理·需求分析·规格说明书
芒果量化4 小时前
Optuna - 自动调参利器&python实例
开发语言·python·算法·机器学习
.NET修仙日记4 小时前
.NET WinForms + WPF 综合学习路线:从传统到现代的.NET桌面开发
学习·c#·.net·wpf·.net core·winforms
foundbug9994 小时前
基于CSMA-CA协议的V2X通信MATLAB仿真
开发语言·网络·matlab
cellurw4 小时前
Day67 Linux I²C 总线与设备驱动架构、开发流程与调试
linux·c语言·架构
kkkkk0211064 小时前
架构风格专题
架构
WangMing_X4 小时前
C#上位机软件:2.5 体验CLR实现多语言混合编程
java·开发语言·c#
