企业微信外部联系人同步中的数据一致性与最终一致性保障

在 wlkankan.cn 客户管理系统中，需将企业微信外部联系人（客户）实时同步至本地数据库，用于画像分析、营销触达等场景。由于企业微信 API 存在调用频率限制、网络抖动及异步事件延迟，直接拉取或被动接收变更通知均可能导致数据不一致。本文结合增量拉取、幂等写入、版本控制与补偿机制，构建高可靠同步体系。

1. 外部联系人模型与版本标识

为支持变更追踪，本地表增加 seq 序列号与 sync_version：

java 复制代码

package wlkankan.cn.wecom.contact.model;

public class ExternalContact {
    private String externalUserId;     // 企微外部联系人ID
    private String name;
    private String position;
    private String corpName;
    private Long updateTime;           // 企微返回的更新时间戳
    private Long seq;                  // 本地自增序列，用于排序
    private Integer syncVersion;       // 同步版本号，每次变更+1
    // getters/setters
}

2. 增量拉取服务

基于 next_cursor 分页拉取最新变更：

java 复制代码

package wlkankan.cn.wecom.contact.sync;

import wlkankan.cn.wecom.client.WecomApiClient;
import wlkankan.cn.wecom.contact.repo.ExternalContactRepository;
import org.springframework.stereotype.Service;
import java.util.List;

@Service
public class IncrementalContactSyncService {

    private final WecomApiClient wecomClient;
    private final ExternalContactRepository contactRepo;
    private volatile String lastCursor = "";

    public void syncIncremental() {
        String cursor = this.lastCursor;
        try {
            do {
                WecomContactBatchResponse response = wecomClient.getExternalContactList(cursor);
                List<ExternalContact> contacts = convert(response.getContactList());
                contactRepo.batchUpsert(contacts); // 幂等写入
                cursor = response.getNextCursor();
            } while (cursor != null && !cursor.isEmpty());

            this.lastCursor = cursor;
        } catch (Exception e) {
            // 记录失败，触发告警
            throw new RuntimeException("Sync failed", e);
        }
    }

    private List<ExternalContact> convert(List<WecomContactDto> dtos) {
        return dtos.stream().map(dto -> {
            ExternalContact c = new ExternalContact();
            c.setExternalUserId(dto.getExternalUserId());
            c.setName(dto.getName());
            c.setPosition(dto.getPosition());
            c.setCorpName(dto.getCorpName());
            c.setUpdateTime(dto.getUpdateTime());
            return c;
        }).collect(Collectors.toList());
    }
}

3. 幂等写入与版本控制

使用 ON DUPLICATE KEY UPDATE 实现安全更新：

java 复制代码

// MyBatis Mapper
@Update({
    "<script>",
    "INSERT INTO external_contact (external_user_id, name, position, corp_name, update_time, sync_version) ",
    "VALUES ",
    "<foreach collection='list' item='c' separator=','>",
    "(#{c.externalUserId}, #{c.name}, #{c.position}, #{c.corpName}, #{c.updateTime}, 1)",
    "</foreach>",
    " ON DUPLICATE KEY UPDATE ",
    "name = VALUES(name), ",
    "position = VALUES(position), ",
    "corp_name = VALUES(corp_name), ",
    "update_time = VALUES(update_time), ",
    "sync_version = IF(update_time < VALUES(update_time), sync_version + 1, sync_version)",
    "</script>"
})
void batchUpsert(@Param("list") List<ExternalContact> contacts);

仅当新数据 update_time 更大时才更新，避免旧数据覆盖。

4. 事件驱动补充（回调通知）

监听企微 change_external_contact 事件：

java 复制代码

@PostMapping("/wecom/callback/contact")
public String handleContactChangeEvent(@RequestBody ContactChangeEvent event) {
    if ("add_external_contact".equals(event.getChangeType()) ||
        "edit_external_contact".equals(event.getChangeType())) {

        // 异步拉取详情，避免回调超时
        contactDetailFetcher.fetchAsync(event.getExternalUserId());
    }
    return "success";
}

拉取详情并写入：

java 复制代码

public void fetchAsync(String externalUserId) {
    executor.submit(() -> {
        try {
            WecomContactDetail detail = wecomClient.getContactDetail(externalUserId);
            ExternalContact contact = convert(detail);
            contactRepo.upsertWithVersionCheck(contact); // 同上逻辑
        } catch (Exception e) {
            // 加入重试队列
            retryQueue.offer(new RetryTask(externalUserId, System.currentTimeMillis() + 60_000));
        }
    });
}

5. 补偿任务与最终一致性

每日全量校验修复差异：

java 复制代码

@Scheduled(cron = "0 0 2 * * ?") // 每日凌晨2点
public void fullConsistencyCheck() {
    List<String> localIds = contactRepo.getAllExternalUserIds();
    Set<String> remoteIds = fetchAllRemoteIds();

    // 找出本地多出的（已删除）
    localIds.stream()
            .filter(id -> !remoteIds.contains(id))
            .forEach(contactRepo::markAsDeleted);

    // 找出远程有但本地缺失的
    remoteIds.stream()
            .filter(id -> !localIds.contains(id))
            .forEach(this::forceSyncById);
}

private Set<String> fetchAllRemoteIds() {
    Set<String> ids = new HashSet<>();
    String cursor = "";
    do {
        var resp = wecomClient.getExternalContactList(cursor);
        ids.addAll(resp.getContactList().stream()
                .map(WecomContactDto::getExternalUserId)
                .collect(Collectors.toSet()));
        cursor = resp.getNextCursor();
    } while (!cursor.isEmpty());
    return ids;
}

6. 重试与死信机制

对失败任务进行指数退避重试：

java 复制代码

public class RetryQueueProcessor {
    private final PriorityQueue<RetryTask> queue = new PriorityQueue<>(Comparator.comparing(RetryTask::getRetryTime));

    @Scheduled(fixedDelay = 5000)
    public void processRetryQueue() {
        long now = System.currentTimeMillis();
        while (!queue.isEmpty() && queue.peek().getRetryTime() <= now) {
            RetryTask task = queue.poll();
            try {
                contactDetailFetcher.fetchNow(task.getExternalUserId());
            } catch (Exception e) {
                if (task.getRetryCount() < 3) {
                    task.incrementRetry();
                    task.setRetryTime(now + (long) Math.pow(2, task.getRetryCount()) * 1000);
                    queue.offer(task);
                } else {
                    deadLetterQueue.send(task); // 告警人工介入
                }
            }
        }
    }
}

通过增量拉取、事件回调、幂等写入与定时补偿四重机制，wlkankan.cn 系统在面对企业微信 API 不可靠性时，仍能保证外部联系人数据的最终一致性，误差窗口控制在分钟级，满足 CRM 业务对客户数据准确性的严苛要求。
