不懂就问
python
import os
import subprocess
import time
import sys
import socket
import json
def activate_ue_window():
"""
激活ue窗口（精确匹配窗口标题），如果没有运行则启动ue
"""
try:
import pygetwindow as gw
except ImportError:
print("pygetwindow未安装，请运行: pip install pygetwindow")
return False
try:
# 获取所有窗口
all_windows = gw.getAllWindows()
ue_window = None
for window in all_windows:
window_title = window.title.strip()
print(f"检查窗口: {window_title}")
# 修改匹配逻辑以包含中文标题
if ('虚幻编辑器' in window_title or
'Unreal Editor' in window_title or
'UE4Editor' in window_title or
window_title == 'ue' or # 基础标题
(window_title.startswith('ue') and
not any(exclude in window_title.lower() for exclude in ['vscode', 'visual studio', 'code']))):
# 额外检查确保不是VSCode或其他编辑器
if ' - ' not in window_title or 'ue.exe' in window_title.lower() or '虚幻编辑器' in window_title:
ue_window = window
break
if ue_window:
print(f"激活窗口: {ue_window.title}")
try:
import win32gui
import win32con
hwnd = ue_window._hWnd
win32gui.ShowWindow(hwnd, win32con.SW_RESTORE)
win32gui.SetForegroundWindow(hwnd)
print(f"窗口已放到最前端: {ue_window.title}")
return True
except ImportError:
print("pywin32未安装，请运行: pip install pywin32")
if hasattr(ue_window, 'isMinimized') and ue_window.isMinimized:
ue_window.restore()
ue_window.activate()
print("ue窗口已激活（使用pygetwindow方法）")
return True
else:
print("未找到ue窗口，正在启动ue...")
# 启动ue
start_ue()
return False
except Exception as e:
print(f"激活ue窗口时出错: {e}")
return False
def send_python_code_request(code=None, host="localhost", port=8070):
"""
发送Python代码执行请求到UE服务器
"""
try:
# 创建socket连接
sock = socket.socket(socket.AF_INET, socket.SOCK_STREAM)
sock.connect((host, port))
# 准备数据
payload = {
"code": code or "unreal.SystemLibrary.print_string(None, 'Hello from remote execution!', True, True, unreal.LinearColor(0,1,0,1), 5.0)"
}
# 发送JSON数据
json_data = json.dumps(payload)
sock.send(json_data.encode('utf-8'))
# 接收响应
response = sock.recv(4096).decode('utf-8')
print(f"服务器响应: {response}")
sock.close()
return {"status": "success", "result": response}
except Exception as e:
print(f"发送请求时出错: {str(e)}")
return {"status": "error", "message": str(e)}
def send_fbx_import_request(host="localhost", port=8070):
"""
发送FBX导入请求到服务器 - 使用固定路径
"""
code = """
import unreal
import os
# 检查文件是否存在
fbx_path = "E:\\\\blender\\\\SK_W_MainChar_01.fbx"
destination_path = "/Game/Characters/MainChar/W/Meshes/"
if not os.path.exists(fbx_path):
result = "文件路径无效: " + fbx_path
else:
# 创建导入任务
import_task = unreal.AssetImportTask()
import_task.set_editor_property('filename', fbx_path)
import_task.set_editor_property('destination_path', destination_path)
import_task.set_editor_property('save', True)
import_task.set_editor_property('automated', True)
import_task.set_editor_property('replace_existing', True)
# 执行导入任务
asset_tools = unreal.AssetToolsHelpers.get_asset_tools()
asset_tools.import_asset_tasks([import_task])
# 获取文件名
filename = os.path.basename(fbx_path)
result = "成功导入文件: " + filename + " 到 " + destination_path
result
"""
return send_python_code_request(code, host, port)
def delete_materials_in_folder():
"""
删除指定文件夹中的材质文件
Returns:
dict: API响应结果
"""
code = """
import unreal
folder_path = "/Game/Characters/MainChar/W/Meshes"
print(f"正在扫描文件夹: {folder_path}")
asset_registry = unreal.AssetRegistryHelpers.get_asset_registry()
filter = unreal.ARFilter(recursive_paths=True)
filter.package_paths.append(folder_path)
filter.class_names.append("Material")
filter.class_names.append("MaterialInstanceConstant")
assets = asset_registry.get_assets(filter)
print(f"在 {folder_path} 中找到 {len(assets)} 个材质资产")
material_paths = []
for asset_data in assets:
print(f"找到材质资产: {asset_data.object_path}")
material_paths.append(str(asset_data.object_path))
deleted = []
for path in material_paths:
success = unreal.EditorAssetLibrary.delete_asset(path)
if success:
print(f"成功删除材质: {path}")
deleted.append(path)
else:
print(f"删除材质失败: {path} - 可能被引用或锁定")
print(f"共删除 {len(deleted)} 个材质资产。")
"""
return send_python_code_request(code)
def move_and_rename_skeleton():
"""
将meshes文件夹中的Skeleton资产移动到指定目标文件夹并重命名
Returns:
dict: API响应结果
"""
code = '''
import unreal
# 配置路径和目标名称
delete_folder = "/Game/Characters/Skeleton"
mesh_folder = "/Game/Characters/MainChar/W/Meshes"
target_folder = delete_folder
target_name = "Base_skeleton"
target_asset_path = f"{target_folder}/{target_name}"
print(f"开始删除目录下所有Skeleton资产: {delete_folder}")
# 获取资产注册表
asset_registry = unreal.AssetRegistryHelpers.get_asset_registry()
# 删除delete_folder下所有Skeleton资产
delete_filter = unreal.ARFilter(recursive_paths=True)
delete_filter.package_paths.append(delete_folder)
delete_filter.class_names.append("Skeleton")
skeletons_to_delete = asset_registry.get_assets(delete_filter)
deleted_count = 0
for asset_data in skeletons_to_delete:
asset_path = str(asset_data.object_path)
success = unreal.EditorAssetLibrary.delete_asset(asset_path)
if success:
print(f"已删除: {asset_path}")
deleted_count += 1
else:
print(f"删除失败: {asset_path}（可能被引用或锁定）")
print(f"共删除 {deleted_count} 个Skeleton资产。")
# 扫描mesh_folder的Skeleton资产并移动重命名
print(f"开始扫描骨骼资产: {mesh_folder}")
mesh_filter = unreal.ARFilter(recursive_paths=True)
mesh_filter.package_paths.append(mesh_folder)
mesh_filter.class_names.append("Skeleton")
skeleton_assets = asset_registry.get_assets(mesh_filter)
print(f"在 {mesh_folder} 找到 {len(skeleton_assets)} 个Skeleton资产")
if len(skeleton_assets) == 0:
print("未找到任何Skeleton资产，脚本结束。")
else:
if unreal.EditorAssetLibrary.does_asset_exist(target_asset_path):
print(f"目标路径 {target_asset_path} 已存在Skeleton资产，请先处理或改名，脚本中止。")
else:
asset_data = skeleton_assets[0]
old_path = str(asset_data.object_path)
print(f"尝试重命名并移动骨骼资产:\\n{old_path} -> {target_asset_path}")
success = unreal.EditorAssetLibrary.rename_asset(old_path, target_asset_path)
if success:
print(f"成功重命名并移动Skeleton资产到：{target_asset_path}")
else:
print(f"重命名或移动失败，可能资产被引用或锁定。")
'''
return send_python_code_request(code)
def create_material_instances_from_textures():
"""
从纹理文件夹中的纹理创建材质实例，绑定到指定的主材质
Returns:
dict: API响应结果
"""
code = '''
import unreal
master_material_path = "/Game/Characters/_Shared/Materials/Master/M_CharaMaster_Cloth"
textures_folder = "/Game/Characters/MainChar/W/Textures"
materials_folder = "/Game/Characters/MainChar/W/Materials"
base_color_param_name = "BaseColor"
print(f"开始清空材质实例目录: {materials_folder}")
assets_to_delete = unreal.EditorAssetLibrary.list_assets(materials_folder, recursive=True, include_folder=False)
for asset_path in assets_to_delete:
unreal.EditorAssetLibrary.delete_asset(asset_path)
print(f"清空完成，共删除 {len(assets_to_delete)} 个资产。")
master_material = unreal.EditorAssetLibrary.load_asset(master_material_path)
if not master_material:
raise RuntimeError(f"无法加载主材质: {master_material_path}")
texture_paths = unreal.EditorAssetLibrary.list_assets(textures_folder, recursive=True, include_folder=False)
texture_assets = []
for path in texture_paths:
asset = unreal.EditorAssetLibrary.load_asset(path)
if asset and isinstance(asset, unreal.Texture):
texture_assets.append(asset)
print(f"找到 {len(texture_assets)} 个纹理用于创建材质实例。")
asset_tools = unreal.AssetToolsHelpers.get_asset_tools()
for texture in texture_assets:
instance_name = texture.get_name()
instance_path = f"{materials_folder}/{instance_name}"
if unreal.EditorAssetLibrary.does_asset_exist(instance_path):
unreal.log(f"已存在材质实例，跳过：{instance_path}")
continue
mi = asset_tools.create_asset(
asset_name=instance_name,
package_path=materials_folder,
asset_class=unreal.MaterialInstanceConstant,
factory=unreal.MaterialInstanceConstantFactoryNew()
)
if not mi:
unreal.log_error(f"创建失败：{instance_path}")
continue
mi.set_editor_property("parent", master_material)
# 设置纹理参数，需使用 FMaterialParameterInfo
parameter_info = unreal.MaterialParameterInfo()
parameter_info.name = base_color_param_name
# 用MaterialEditingLibrary接口设置参数更安全
unreal.MaterialEditingLibrary.set_material_instance_texture_parameter_value(mi, parameter_info.name, texture)
unreal.EditorAssetLibrary.save_asset(instance_path)
unreal.log(f"已创建材质实例: {instance_path}，BaseColor设置为纹理: {texture.get_path_name()}")
unreal.log(f"共创建 {len(texture_assets)} 个材质实例，路径: {materials_folder}")
'''
return send_python_code_request(code)
def move_textures_to_folder():
"""
将meshes文件夹中的纹理资产移动到textures文件夹中
Returns:
dict: API响应结果
"""
code = """
import unreal
# 路径配置（无结尾斜杠）
textures_folder = "/Game/Characters/MainChar/W/Textures"
meshes_folder = "/Game/Characters/MainChar/W/Meshes"
# 1. 删除 textures_folder 目录下所有资产
print(f"开始删除目录下所有资产: {textures_folder}")
assets_to_delete = unreal.EditorAssetLibrary.list_assets(textures_folder, recursive=True, include_folder=False)
deleted_count = 0
for asset_path in assets_to_delete:
success = unreal.EditorAssetLibrary.delete_asset(asset_path)
if success:
print(f"删除成功: {asset_path}")
deleted_count += 1
else:
print(f"删除失败: {asset_path}（可能被引用或锁定）")
print(f"共删除了 {deleted_count} 个资产。")
# 2. 查找 meshes_folder 中所有纹理资产
print(f"\\n开始查找文件夹中的纹理资产: {meshes_folder}")
asset_registry = unreal.AssetRegistryHelpers.get_asset_registry()
filter = unreal.ARFilter(recursive_paths=True)
filter.package_paths.append(meshes_folder)
filter.class_names.append("Texture2D")
filter.class_names.append("TextureCube")
filter.class_names.append("TextureRenderTarget2D")
filter.class_names.append("TextureRenderTargetCube")
filter.class_names.append("Texture")
texture_assets = asset_registry.get_assets(filter)
print(f"找到 {len(texture_assets)} 个纹理资产。")
# 3. 移动纹理资产到 textures_folder（重命名路径）
moved_count = 0
for asset_data in texture_assets:
old_path = str(asset_data.object_path)
asset_name = asset_data.asset_name
new_path = f"{textures_folder}/{asset_name}"
if unreal.EditorAssetLibrary.does_asset_exist(new_path):
print(f"目标路径已存在，跳过: {new_path}")
continue
success = unreal.EditorAssetLibrary.rename_asset(old_path, new_path)
if success:
print(f"已移动: {old_path} -> {new_path}")
moved_count += 1
else:
print(f"移动失败: {old_path} -> {new_path}（可能被引用或锁定）")
print(f"共移动 {moved_count} 个纹理资产到 {textures_folder}。")
"""
return send_python_code_request(code)
def execute_tool(tool_name, *args):
"""
根据工具名称执行对应的ue操作
Args:
tool_name (str): 工具名称
*args: 工具参数
Returns:
dict: API响应结果
"""
tool_functions = {
"activate_ue": activate_ue_window,
"send_python_code_request": send_python_code_request,
"send_fbx_import_request": send_fbx_import_request,
"delete_materials_in_folder": delete_materials_in_folder,
"move_textures_to_folder": move_textures_to_folder,
"move_and_rename_skeleton": move_and_rename_skeleton,
"create_material_instances_from_textures": create_material_instances_from_textures, # 新增这一行
}
if tool_name in tool_functions:
if tool_name == "activate_ue":
# 特殊处理：激活ue窗口不需要API调用
result = tool_functions[tool_name]()
return {"status": "success", "result": result} if result else {"status": "error", "message": "Failed to activate ue"}
elif tool_name in ["delete_objects_by_name"] and args:
# 处理带参数的删除功能
return tool_functions[tool_name](args[0])
else:
# 其他工具调用API
return tool_functions[tool_name]()
else:
print(f"错误: 未知的ue工具 '{tool_name}'")
return {"status": "error", "message": f"未知的ue工具 '{tool_name}'"}
def start_ue():
"""
启动ue（在后台进程启动，不阻塞当前线程）
"""
ue_path = r"D:\UE_4.26\Engine\Binaries\Win64\UE4Editor.exe"
if not os.path.exists(ue_path):
print(f"错误: 找不到ue可执行文件: {ue_path}")
return False
try:
# 使用CREATE_NEW_CONSOLE标志启动ue，使其在独立的进程中运行
subprocess.Popen([ue_path],
creationflags=subprocess.CREATE_NEW_CONSOLE | subprocess.DETACHED_PROCESS)
print(f"ue已在后台启动: {ue_path}")
time.sleep(2) # 短暂延迟确保进程已开始启动
return True
except Exception as e:
print(f"启动ue时出错: {e}")
return False
def main():
# delete_objects_by_name("ObjectName")
# return
tool_name = sys.argv[1]
# 检查是否有额外参数传递给工具
args = sys.argv[2:] # 获取工具名称之后的所有参数
# 执行对应的工具
response = execute_tool(tool_name, *args)
if response:
print(json.dumps(response))
if __name__ == "__main__":
main()
