大家好，我是小悟。

一、API Gateway概述

什么是API Gateway？

API Gateway（API网关）是一个服务器端组件，作为客户端与后端微服务之间的单一入口点。它负责请求路由、组合、协议转换以及跨领域功能处理。

主要功能：

  1. 请求路由：将客户端请求路由到对应的后端服务
  2. 负载均衡：在多个服务实例间分发请求
  3. 身份验证和授权：统一处理安全认证
  4. 限流和熔断：防止服务过载
  5. 监控和日志：集中收集请求指标
  6. 协议转换：处理不同协议间的转换
  7. 缓存：缓存响应以提升性能

二、Spring Cloud Gateway整合步骤

环境要求

  • JDK 11+
  • Spring Boot 2.7+
  • Maven 3.6+

步骤1：创建父工程

复制代码
<!-- pom.xml -->
<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0
         http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>

    <groupId>com.example</groupId>
    <artifactId>gateway-demo</artifactId>
    <version>1.0.0</version>
    <packaging>pom</packaging>

    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>2.7.14</version>
        <relativePath/>
    </parent>

    <properties>
        <java.version>11</java.version>
        <spring-cloud.version>2021.0.8</spring-cloud.version>
    </properties>

    <dependencyManagement>
        <dependencies>
            <dependency>
                <groupId>org.springframework.cloud</groupId>
                <artifactId>spring-cloud-dependencies</artifactId>
                <version>${spring-cloud.version}</version>
                <type>pom</type>
                <scope>import</scope>
            </dependency>
        </dependencies>
    </dependencyManagement>

    <modules>
        <module>api-gateway</module>
    </modules>
</project>

步骤2：创建Gateway服务

复制代码
<!-- api-gateway/pom.xml -->
<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0
         http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <parent>
        <artifactId>gateway-demo</artifactId>
        <groupId>com.example</groupId>
        <version>1.0.0</version>
    </parent>

    <modelVersion>4.0.0</modelVersion>
    <artifactId>api-gateway</artifactId>

    <dependencies>
        <!-- Spring Cloud Gateway -->
        <dependency>
            <groupId>org.springframework.cloud</groupId>
            <artifactId>spring-cloud-starter-gateway</artifactId>
        </dependency>

        <!-- 服务发现 -->
        <dependency>
            <groupId>org.springframework.cloud</groupId>
            <artifactId>spring-cloud-starter-netflix-eureka-client</artifactId>
        </dependency>

        <!-- 配置中心 -->
        <dependency>
            <groupId>org.springframework.cloud</groupId>
            <artifactId>spring-cloud-starter-config</artifactId>
        </dependency>

        <!-- 监控 -->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-actuator</artifactId>
        </dependency>

        <!-- 安全 -->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-security</artifactId>
        </dependency>

        <!-- JWT -->
        <dependency>
            <groupId>io.jsonwebtoken</groupId>
            <artifactId>jjwt</artifactId>
            <version>0.9.1</version>
        </dependency>
    </dependencies>
</project>

步骤3：主启动类

复制代码
// ApiGatewayApplication.java
package com.example.gateway;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.cloud.client.discovery.EnableDiscoveryClient;

@SpringBootApplication
@EnableDiscoveryClient
public class ApiGatewayApplication {
    public static void main(String[] args) {
        SpringApplication.run(ApiGatewayApplication.class, args);
    }
}

步骤4：基础配置

复制代码
# application.yml
server:
  port: 8080

spring:
  application:
    name: api-gateway
  cloud:
    gateway:
      discovery:
        locator:
          enabled: true  # 启用服务发现
          lower-case-service-id: true

      routes:
        # 用户服务路由
        - id: user-service
          uri: lb://USER-SERVICE
          predicates:
            - Path=/api/users/**
          filters:
            - StripPrefix=1
            - name: CircuitBreaker
              args:
                name: userService
                fallbackUri: forward:/fallback/user

        # 商品服务路由
        - id: product-service
          uri: lb://PRODUCT-SERVICE
          predicates:
            - Path=/api/products/**
          filters:
            - StripPrefix=1
            - AddRequestHeader=X-Request-From, gateway

        # 订单服务路由
        - id: order-service
          uri: lb://ORDER-SERVICE
          predicates:
            - Path=/api/orders/**
          filters:
            - StripPrefix=1
            - name: RequestRateLimiter
              args:
                redis-rate-limiter.replenishRate: 10  # 每秒10个请求
                redis-rate-limiter.burstCapacity: 20   # 最大突发容量20
                key-resolver: "#{@userKeyResolver}"

        # 直接路由示例
        - id: baidu-route
          uri: https://www.baidu.com
          predicates:
            - Path=/baidu/**

      # 全局过滤器配置
      default-filters:
        - AddResponseHeader=X-Response-Time, ${spring.application.name}

    # 负载均衡配置
    loadbalancer:
      retry:
        enabled: true

# 熔断器配置
resilience4j:
  circuitbreaker:
    instances:
      userService:
        slidingWindowSize: 10
        failureRateThreshold: 50
        waitDurationInOpenState: 10000

# 监控端点
management:
  endpoints:
    web:
      exposure:
        include: health,info,gateway
  endpoint:
    gateway:
      enabled: true

步骤5：自定义过滤器

复制代码
// JwtAuthenticationFilter.java
package com.example.gateway.filter;

import io.jsonwebtoken.Claims;
import io.jsonwebtoken.Jwts;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.cloud.gateway.filter.GatewayFilter;
import org.springframework.cloud.gateway.filter.factory.AbstractGatewayFilterFactory;
import org.springframework.http.HttpHeaders;
import org.springframework.http.HttpStatus;
import org.springframework.stereotype.Component;
import reactor.core.publisher.Mono;

@Component
public class JwtAuthenticationFilter extends AbstractGatewayFilterFactory<JwtAuthenticationFilter.Config> {

    @Value("${jwt.secret}")
    private String jwtSecret;

    public JwtAuthenticationFilter() {
        super(Config.class);
    }

    @Override
    public GatewayFilter apply(Config config) {
        return (exchange, chain) -> {
            String path = exchange.getRequest().getURI().getPath();

            // 跳过认证的路径
            if (config.getWhiteList().stream().anyMatch(path::startsWith)) {
                return chain.filter(exchange);
            }

            // 获取token
            String token = exchange.getRequest()
                    .getHeaders()
                    .getFirst(HttpHeaders.AUTHORIZATION);

            if (token == null || !token.startsWith("Bearer ")) {
                exchange.getResponse().setStatusCode(HttpStatus.UNAUTHORIZED);
                return exchange.getResponse().setComplete();
            }

            try {
                // 验证JWT
                Claims claims = Jwts.parser()
                        .setSigningKey(jwtSecret)
                        .parseClaimsJws(token.substring(7))
                        .getBody();

                // 添加用户信息到header
                exchange.getRequest().mutate()
                        .header("X-User-Id", claims.getSubject())
                        .header("X-User-Roles", claims.get("roles", String.class))
                        .build();

            } catch (Exception e) {
                exchange.getResponse().setStatusCode(HttpStatus.UNAUTHORIZED);
                return exchange.getResponse().setComplete();
            }

            return chain.filter(exchange);
        };
    }

    public static class Config {
        private java.util.List<String> whiteList = new java.util.ArrayList<>();

        public java.util.List<String> getWhiteList() {
            return whiteList;
        }

        public void setWhiteList(java.util.List<String> whiteList) {
            this.whiteList = whiteList;
        }
    }
}

步骤6：全局过滤器

复制代码
// GlobalLoggingFilter.java
package com.example.gateway.filter;

import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.cloud.gateway.filter.GatewayFilterChain;
import org.springframework.cloud.gateway.filter.GlobalFilter;
import org.springframework.core.Ordered;
import org.springframework.stereotype.Component;
import org.springframework.web.server.ServerWebExchange;
import reactor.core.publisher.Mono;

@Component
public class GlobalLoggingFilter implements GlobalFilter, Ordered {

    private static final Logger logger = LoggerFactory.getLogger(GlobalLoggingFilter.class);

    @Override
    public Mono<Void> filter(ServerWebExchange exchange, GatewayFilterChain chain) {
        long startTime = System.currentTimeMillis();

        return chain.filter(exchange).then(Mono.fromRunnable(() -> {
            long duration = System.currentTimeMillis() - startTime;
            logger.info("Request: {} {} - Status: {} - Time: {}ms",
                    exchange.getRequest().getMethod(),
                    exchange.getRequest().getURI().getPath(),
                    exchange.getResponse().getStatusCode(),
                    duration);
        }));
    }

    @Override
    public int getOrder() {
        return Ordered.HIGHEST_PRECEDENCE;
    }
}

步骤7：限流配置

复制代码
// RateLimiterConfig.java
package com.example.gateway.config;

import org.springframework.cloud.gateway.filter.ratelimit.KeyResolver;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import reactor.core.publisher.Mono;

@Configuration
public class RateLimiterConfig {

    @Bean
    public KeyResolver userKeyResolver() {
        return exchange -> {
            // 根据用户限流
            String userId = exchange.getRequest()
                    .getHeaders()
                    .getFirst("X-User-Id");

            if (userId != null) {
                return Mono.just(userId);
            }

            // 根据IP限流
            String ip = exchange.getRequest()
                    .getRemoteAddress()
                    .getAddress()
                    .getHostAddress();

            return Mono.just(ip);
        };
    }

    @Bean
    public KeyResolver apiKeyResolver() {
        return exchange -> Mono.just(
                exchange.getRequest().getURI().getPath()
        );
    }
}

步骤8：熔断降级处理

复制代码
// FallbackController.java
package com.example.gateway.controller;

import org.springframework.http.HttpStatus;
import org.springframework.http.ResponseEntity;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.RestController;
import reactor.core.publisher.Mono;

import java.util.HashMap;
import java.util.Map;

@RestController
public class FallbackController {

    @GetMapping("/fallback/user")
    public Mono<ResponseEntity<Map<String, Object>>> userServiceFallback() {
        return Mono.just(ResponseEntity
                .status(HttpStatus.SERVICE_UNAVAILABLE)
                .body(createFallbackResponse("User service is temporarily unavailable")));
    }

    @GetMapping("/fallback/product")
    public Mono<ResponseEntity<Map<String, Object>>> productServiceFallback() {
        return Mono.just(ResponseEntity
                .status(HttpStatus.SERVICE_UNAVAILABLE)
                .body(createFallbackResponse("Product service is temporarily unavailable")));
    }

    private Map<String, Object> createFallbackResponse(String message) {
        Map<String, Object> response = new HashMap<>();
        response.put("success", false);
        response.put("message", message);
        response.put("timestamp", System.currentTimeMillis());
        response.put("code", 503);
        return response;
    }
}

步骤9：安全配置

复制代码
// SecurityConfig.java
package com.example.gateway.config;

import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.security.config.annotation.web.reactive.EnableWebFluxSecurity;
import org.springframework.security.config.web.server.ServerHttpSecurity;
import org.springframework.security.web.server.SecurityWebFilterChain;

@Configuration
@EnableWebFluxSecurity
public class SecurityConfig {

    @Bean
    public SecurityWebFilterChain securityWebFilterChain(ServerHttpSecurity http) {
        return http
                .csrf().disable()
                .authorizeExchange()
                .pathMatchers("/actuator/**", "/fallback/**").permitAll()
                .pathMatchers("/api/auth/**").permitAll()
                .pathMatchers("/api/public/**").permitAll()
                .anyExchange().authenticated()
                .and()
                .httpBasic().disable()
                .formLogin().disable()
                .build();
    }
}

步骤10：健康检查配置

复制代码
// HealthCheckConfig.java
package com.example.gateway.config;

import org.springframework.boot.actuate.health.Health;
import org.springframework.boot.actuate.health.ReactiveHealthIndicator;
import org.springframework.stereotype.Component;
import reactor.core.publisher.Mono;

@Component
public class HealthCheckConfig implements ReactiveHealthIndicator {

    @Override
    public Mono<Health> health() {
        return checkDownstreamServiceHealth()
                .onErrorResume(ex -> Mono.just(
                        Health.down().withException(ex).build())
                );
    }

    private Mono<Health> checkDownstreamServiceHealth() {
        // 检查下游服务健康状态
        return Mono.just(Health.up().build());
    }
}

步骤11：动态路由配置（基于数据库）

复制代码
// DynamicRouteService.java
package com.example.gateway.service;

import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.cloud.gateway.event.RefreshRoutesEvent;
import org.springframework.cloud.gateway.route.RouteDefinition;
import org.springframework.cloud.gateway.route.RouteDefinitionWriter;
import org.springframework.context.ApplicationEventPublisher;
import org.springframework.stereotype.Service;
import reactor.core.publisher.Mono;

import javax.annotation.PostConstruct;
import java.util.List;

@Service
public class DynamicRouteService {

    @Autowired
    private RouteDefinitionWriter routeDefinitionWriter;

    @Autowired
    private ApplicationEventPublisher publisher;

    @PostConstruct
    public void initRoutes() {
        // 从数据库加载路由配置
        loadRoutesFromDatabase();
    }

    private void loadRoutesFromDatabase() {
        // 实现从数据库加载路由的逻辑
    }

    public void addRoute(RouteDefinition definition) {
        routeDefinitionWriter.save(Mono.just(definition)).subscribe();
        refreshRoutes();
    }

    public void updateRoute(RouteDefinition definition) {
        deleteRoute(definition.getId());
        addRoute(definition);
    }

    public void deleteRoute(String routeId) {
        routeDefinitionWriter.delete(Mono.just(routeId)).subscribe();
        refreshRoutes();
    }

    private void refreshRoutes() {
        publisher.publishEvent(new RefreshRoutesEvent(this));
    }
}

三、测试验证

创建测试配置

复制代码
# application-test.yml
spring:
  cloud:
    gateway:
      routes:
        - id: test-route
          uri: http://httpbin.org:80
          predicates:
            - Path=/get/**
          filters:
            - AddRequestHeader=Hello, World

logging:
  level:
    org.springframework.cloud.gateway: DEBUG
    com.example.gateway: DEBUG

编写测试用例

复制代码
// GatewayTest.java
package com.example.gateway;

import org.junit.jupiter.api.Test;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.boot.test.context.SpringBootTest;
import org.springframework.cloud.contract.wiremock.AutoConfigureWireMock;
import org.springframework.test.web.reactive.server.WebTestClient;

import static com.github.tomakehurst.wiremock.client.WireMock.*;

@SpringBootTest(webEnvironment = SpringBootTest.WebEnvironment.RANDOM_PORT)
@AutoConfigureWireMock(port = 8081)
class GatewayTest {

    @Autowired
    private WebTestClient webClient;

    @Test
    void testRoute() {
        stubFor(get(urlEqualTo("/test"))
                .willReturn(aResponse()
                        .withBody("test")
                        .withHeader("Content-Type", "text/plain")));

        webClient.get()
                .uri("/test")
                .exchange()
                .expectStatus().isOk()
                .expectBody(String.class).isEqualTo("test");
    }
}

四、部署配置

Docker部署配置

复制代码
# Dockerfile
FROM openjdk:11-jre-slim
VOLUME /tmp
COPY target/api-gateway-*.jar app.jar
ENTRYPOINT ["java", "-Djava.security.egd=file:/dev/./urandom", "-jar", "/app.jar"]
EXPOSE 8080

Kubernetes配置

复制代码
# deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: api-gateway
spec:
  replicas: 3
  selector:
    matchLabels:
      app: api-gateway
  template:
    metadata:
      labels:
        app: api-gateway
    spec:
      containers:
      - name: api-gateway
        image: api-gateway:latest
        ports:
        - containerPort: 8080
        env:
        - name: SPRING_PROFILES_ACTIVE
          value: "prod"
        resources:
          requests:
            memory: "512Mi"
            cpu: "250m"
          limits:
            memory: "1Gi"
            cpu: "500m"
        livenessProbe:
          httpGet:
            path: /actuator/health
            port: 8080
          initialDelaySeconds: 60
          periodSeconds: 30
        readinessProbe:
          httpGet:
            path: /actuator/health
            port: 8080
          initialDelaySeconds: 30
          periodSeconds: 15

五、总结

优势特点：

  1. 性能优秀：基于WebFlux响应式编程，非阻塞IO，高并发能力强
  2. 功能全面：内置路由、过滤、熔断、限流等核心功能
  3. 易于扩展：支持自定义过滤器和全局过滤器
  4. 云原生友好：完美整合Spring Cloud生态
  5. 配置灵活：支持YAML配置、Java配置和动态配置

最佳实践：

  1. 路由设计：合理规划API路径，遵循RESTful规范
  2. 安全防护：统一认证授权，实施请求验证
  3. 性能监控：集成监控系统，实时收集指标
  4. 容错处理：配置熔断降级，确保系统可用性
  5. 版本管理：支持API版本控制，平滑升级

注意事项：

  1. 网关应保持轻量级，避免复杂业务逻辑
  2. 合理配置超时时间和重试机制
  3. 实施灰度发布和蓝绿部署
  4. 定期更新和维护路由规则
  5. 监控网关性能，及时扩容

通过Spring Cloud Gateway，我们可以构建一个高性能、可扩展、安全的API网关，有效管理和保护微服务架构中的API接口，提升系统的整体稳定性和可维护性。

谢谢你看我的文章，既然看到这里了，如果觉得不错，随手点个赞、转发、在看三连吧，感谢感谢。那我们，下次再见。

您的一键三连，是我更新的最大动力，谢谢

山水有相逢，来日皆可期，谢谢阅读，我们再会

我手中的金箍棒，上能通天，下能探海

相关推荐
shejizuopin2 小时前
基于JavaSSM+MySQL的实验室考勤管理系统设计与实现
java·mysql·vue·毕业设计·论文·springboot·实验室考勤管理系统设计与实现
J***51682 小时前
SpringSecurity的配置
java
面汤放盐2 小时前
软件架构指南 Software Architecture Guide
java·微服务·devops
tkevinjd2 小时前
JUC5（线程池）
java·线程池·多线程·juc
Tao____2 小时前
如何对接Modbus-tcp协议（使用Thinlinks物联网平台）
java·物联网·网络协议·tcp/ip·modbus
鱼跃鹰飞2 小时前
经典面试题：K8S的自动缩扩容和崩溃恢复
java·容器·kubernetes
Coder_Boy_2 小时前
Spring Boot 事务回滚异常 UnexpectedRollbackException 详解(常见问题集合)
java·spring boot·后端
青云交2 小时前
Java 大视界 -- 基于 Java+Redis Cluster 构建分布式缓存系统：实战与一致性保障（444）
java·redis·缓存·缓存穿透·分布式缓存·一致性保障·java+redis clus
不知疲倦的仄仄2 小时前
第五天:深度解密 Netty ByteBuf：高性能 IO 的基石
java·开源·github
xiaobaishuoAI2 小时前
后端工程化实战指南：从规范到自动化，打造高效协作体系
java·大数据·运维·人工智能·maven·devops·geo
热门推荐
01GitHub 镜像站点02Labelme从安装到标注：零基础完整指南03安娜的档案(Anna’s Archive) 镜像网站/国内最新可访问入口（持续更新）04Linux下V2Ray安装配置指南05Claude Code 2.1.2 升级报错？别折腾了，一行命令搞定06jdk21下载、安装（Windows、Linux、macOS）07【踩坑笔记】50系显卡适配的 PyTorch 安装08KGG转MP3工具|非KGM文件|解密音频09UV安装并设置国内源102025-04-03 Latex学习1——本地配置Latex + VScode环境
