ggml-rpc.cpp
完整代码
#include "ggml-rpc.h"
#include "ggml-impl.h"
#include "ggml-backend-impl.h"
#include "ggml-cpp.h"
#include <cinttypes>
#include <string>
#include <vector>
#include <memory>
#include <mutex>
#include <unordered_map>
#include <unordered_set>
#ifdef _WIN32
# define WIN32_LEAN_AND_MEAN
# ifndef NOMINMAX
# define NOMINMAX
# endif
# include <windows.h>
# include <winsock2.h>
#else
# include <arpa/inet.h>
# include <sys/socket.h>
# include <sys/types.h>
# include <netinet/in.h>
# include <netinet/tcp.h>
# include <netdb.h>
# include <unistd.h>
#endif
#include <cstring>
#include <fstream>
#include <filesystem>
#include <algorithm>
static const char * RPC_DEBUG = std::getenv("GGML_RPC_DEBUG");
#define LOG_DBG(...) \
do { if (RPC_DEBUG) GGML_LOG_DEBUG(__VA_ARGS__); } while (0)
namespace fs = std::filesystem;
static constexpr size_t MAX_CHUNK_SIZE = 1024ull * 1024ull * 1024ull; // 1 GiB
#ifdef _WIN32
typedef SOCKET sockfd_t;
using ssize_t = __int64;
#else
typedef int sockfd_t;
#endif
// cross-platform socket
struct socket_t {
sockfd_t fd;
socket_t(sockfd_t fd) : fd(fd) {}
~socket_t() {
LOG_DBG("[%s] closing socket %d\n", __func__, this->fd);
#ifdef _WIN32
closesocket(this->fd);
#else
close(this->fd);
#endif
}
};
// macro for nicer error messages on server crash
#define RPC_STATUS_ASSERT(x) if (!(x)) GGML_ABORT("Remote RPC server crashed or returned malformed response")
// all RPC structures must be packed
#pragma pack(push, 1)
// ggml_tensor is serialized into rpc_tensor
struct rpc_tensor {
uint64_t id;
uint32_t type;
uint64_t buffer;
uint32_t ne[GGML_MAX_DIMS];
uint32_t nb[GGML_MAX_DIMS];
uint32_t op;
int32_t op_params[GGML_MAX_OP_PARAMS / sizeof(int32_t)];
int32_t flags;
uint64_t src[GGML_MAX_SRC];
uint64_t view_src;
uint64_t view_offs;
uint64_t data;
char name[GGML_MAX_NAME];
char padding[4];
};
static_assert(sizeof(rpc_tensor) % 8 == 0, "rpc_tensor size must be multiple of 8");
// RPC commands
enum rpc_cmd {
RPC_CMD_ALLOC_BUFFER = 0,
RPC_CMD_GET_ALIGNMENT,
RPC_CMD_GET_MAX_SIZE,
RPC_CMD_BUFFER_GET_BASE,
RPC_CMD_FREE_BUFFER,
RPC_CMD_BUFFER_CLEAR,
RPC_CMD_SET_TENSOR,
RPC_CMD_SET_TENSOR_HASH,
RPC_CMD_GET_TENSOR,
RPC_CMD_COPY_TENSOR,
RPC_CMD_GRAPH_COMPUTE,
RPC_CMD_GET_DEVICE_MEMORY,
RPC_CMD_INIT_TENSOR,
RPC_CMD_GET_ALLOC_SIZE,
RPC_CMD_HELLO,
RPC_CMD_DEVICE_COUNT,
RPC_CMD_GRAPH_RECOMPUTE,
RPC_CMD_COUNT,
};
static_assert(RPC_CMD_HELLO == 14, "RPC_CMD_HELLO must be always 14");
// Try RPC_CMD_SET_TENSOR_HASH first when data size is larger than this threshold
const size_t HASH_THRESHOLD = 10 * 1024 * 1024;
struct rpc_msg_hello_rsp {
uint8_t major;
uint8_t minor;
uint8_t patch;
};
struct rpc_msg_device_count_rsp {
uint32_t device_count;
};
struct rpc_msg_get_alloc_size_req {
uint32_t device;
rpc_tensor tensor;
rpc_tensor srcs[GGML_MAX_SRC];
};
struct rpc_msg_get_alloc_size_rsp {
uint64_t alloc_size;
};
struct rpc_msg_init_tensor_req {
rpc_tensor tensor;
};
struct rpc_msg_alloc_buffer_req {
uint32_t device;
uint64_t size;
};
struct rpc_msg_alloc_buffer_rsp {
uint64_t remote_ptr;
uint64_t remote_size;
};
struct rpc_msg_get_alignment_req {
uint32_t device;
};
struct rpc_msg_get_alignment_rsp {
uint64_t alignment;
};
struct rpc_msg_get_max_size_req {
uint32_t device;
};
struct rpc_msg_get_max_size_rsp {
uint64_t max_size;
};
struct rpc_msg_buffer_get_base_req {
uint64_t remote_ptr;
};
struct rpc_msg_buffer_get_base_rsp {
uint64_t base_ptr;
};
struct rpc_msg_free_buffer_req {
uint64_t remote_ptr;
};
struct rpc_msg_buffer_clear_req {
uint64_t remote_ptr;
uint8_t value;
};
struct rpc_msg_set_tensor_hash_req {
rpc_tensor tensor;
uint64_t offset;
uint64_t hash;
};
struct rpc_msg_set_tensor_hash_rsp {
uint8_t result;
};
struct rpc_msg_get_tensor_req {
rpc_tensor tensor;
uint64_t offset;
uint64_t size;
};
struct rpc_msg_copy_tensor_req {
rpc_tensor src;
rpc_tensor dst;
};
struct rpc_msg_copy_tensor_rsp {
uint8_t result;
};
struct rpc_msg_get_device_memory_req {
uint32_t device;
};
struct rpc_msg_get_device_memory_rsp {
uint64_t free_mem;
uint64_t total_mem;
};
struct rpc_msg_graph_recompute_req {
uint32_t device;
};
#pragma pack(pop)
// RPC data structures
static ggml_guid_t ggml_backend_rpc_guid() {
static ggml_guid guid = {0x99, 0x68, 0x5b, 0x6c, 0xd2, 0x83, 0x3d, 0x24, 0x25, 0x36, 0x72, 0xe1, 0x5b, 0x0e, 0x14, 0x03};
return &guid;
}
struct ggml_backend_rpc_buffer_type_context {
std::string endpoint;
uint32_t device;
std::string name;
size_t alignment;
size_t max_size;
};
struct graph_cache {
bool is_cached(const ggml_cgraph * cgraph) {
if ((int)last_graph.size() != cgraph->n_nodes) {
return false;
}
for (int i = 0; i < cgraph->n_nodes; i++) {
if (memcmp(&last_graph[i], cgraph->nodes[i], sizeof(ggml_tensor)) != 0) {
return false;
}
}
return true;
}
void add(const ggml_cgraph * cgraph) {
last_graph.resize(cgraph->n_nodes);
for (int i = 0; i < cgraph->n_nodes; i++) {
memcpy(&last_graph[i], cgraph->nodes[i], sizeof(ggml_tensor));
}
}
std::vector<ggml_tensor> last_graph;
};
struct ggml_backend_rpc_context {
std::string endpoint;
uint32_t device;
std::string name;
graph_cache gc;
};
struct ggml_backend_rpc_buffer_context {
std::shared_ptr<socket_t> sock;
void * base_ptr;
uint64_t remote_ptr;
};
// RPC helper functions
// Computes FNV-1a hash of the data
static uint64_t fnv_hash(const uint8_t * data, size_t len) {
const uint64_t fnv_prime = 0x100000001b3ULL;
uint64_t hash = 0xcbf29ce484222325ULL;
for (size_t i = 0; i < len; ++i) {
hash ^= data[i];
hash *= fnv_prime;
}
return hash;
}
static std::shared_ptr<socket_t> make_socket(sockfd_t fd) {
#ifdef _WIN32
if (fd == INVALID_SOCKET) {
return nullptr;
}
#else
if (fd < 0) {
return nullptr;
}
#endif
return std::make_shared<socket_t>(fd);
}
static bool set_no_delay(sockfd_t sockfd) {
int flag = 1;
// set TCP_NODELAY to disable Nagle's algorithm
int ret = setsockopt(sockfd, IPPROTO_TCP, TCP_NODELAY, (char *)&flag, sizeof(int));
return ret == 0;
}
static bool set_reuse_addr(sockfd_t sockfd) {
int flag = 1;
int ret = setsockopt(sockfd, SOL_SOCKET, SO_REUSEADDR, (char *)&flag, sizeof(int));
return ret == 0;
}
static std::shared_ptr<socket_t> socket_connect(const char * host, int port) {
struct sockaddr_in addr;
auto sockfd = socket(AF_INET, SOCK_STREAM, 0);
auto sock_ptr = make_socket(sockfd);
if (sock_ptr == nullptr) {
return nullptr;
}
if (!set_no_delay(sockfd)) {
GGML_LOG_ERROR("Failed to set TCP_NODELAY\n");
return nullptr;
}
addr.sin_family = AF_INET;
addr.sin_port = htons(port);
struct hostent * server = gethostbyname(host);
if (server == NULL) {
GGML_LOG_ERROR("Cannot resolve host '%s'\n", host);
return nullptr;
}
memcpy(&addr.sin_addr.s_addr, server->h_addr, server->h_length);
if (connect(sock_ptr->fd, (struct sockaddr *)&addr, sizeof(addr)) < 0) {
return nullptr;
}
return sock_ptr;
}
static std::shared_ptr<socket_t> socket_accept(sockfd_t srv_sockfd) {
auto client_socket_fd = accept(srv_sockfd, NULL, NULL);
auto client_socket = make_socket(client_socket_fd);
if (client_socket == nullptr) {
return nullptr;
}
if (!set_no_delay(client_socket_fd)) {
GGML_LOG_ERROR("Failed to set TCP_NODELAY\n");
return nullptr;
}
return client_socket;
}
static std::shared_ptr<socket_t> create_server_socket(const char * host, int port) {
auto sockfd = socket(AF_INET, SOCK_STREAM, 0);
auto sock = make_socket(sockfd);
if (sock == nullptr) {
return nullptr;
}
if (!set_reuse_addr(sockfd)) {
GGML_LOG_ERROR("Failed to set SO_REUSEADDR\n");
return nullptr;
}
if (inet_addr(host) == INADDR_NONE) {
GGML_LOG_ERROR("Invalid host address: %s\n", host);
return nullptr;
}
struct sockaddr_in serv_addr;
serv_addr.sin_family = AF_INET;
serv_addr.sin_addr.s_addr = inet_addr(host);
serv_addr.sin_port = htons(port);
if (bind(sockfd, (struct sockaddr *) &serv_addr, sizeof(serv_addr)) < 0) {
return nullptr;
}
if (listen(sockfd, 1) < 0) {
return nullptr;
}
return sock;
}
static bool send_data(sockfd_t sockfd, const void * data, size_t size) {
size_t bytes_sent = 0;
while (bytes_sent < size) {
size_t size_to_send = std::min(size - bytes_sent, MAX_CHUNK_SIZE);
ssize_t n = send(sockfd, (const char *)data + bytes_sent, size_to_send, 0);
if (n < 0) {
GGML_LOG_ERROR("send failed (bytes_sent=%zu, size_to_send=%zu)\n",
bytes_sent, size_to_send);
return false;
}
bytes_sent += (size_t)n;
}
return true;
}
static bool recv_data(sockfd_t sockfd, void * data, size_t size) {
size_t bytes_recv = 0;
while (bytes_recv < size) {
size_t size_to_recv = std::min(size - bytes_recv, MAX_CHUNK_SIZE);
ssize_t n = recv(sockfd, (char *)data + bytes_recv, size_to_recv, 0);
if (n < 0) {
GGML_LOG_ERROR("recv failed (bytes_recv=%zu, size_to_recv=%zu)\n",
bytes_recv, size_to_recv);
return false;
}
if (n == 0) {
LOG_DBG("recv returned 0 (peer closed?)\n");
return false;
}
bytes_recv += (size_t)n;
}
return true;
}
static bool send_msg(sockfd_t sockfd, const void * msg, size_t msg_size) {
if (!send_data(sockfd, &msg_size, sizeof(msg_size))) {
return false;
}
return send_data(sockfd, msg, msg_size);
}
static bool recv_msg(sockfd_t sockfd, void * msg, size_t msg_size) {
uint64_t size;
if (!recv_data(sockfd, &size, sizeof(size))) {
return false;
}
if (size != msg_size) {
return false;
}
return recv_data(sockfd, msg, msg_size);
}
static bool recv_msg(sockfd_t sockfd, std::vector<uint8_t> & input) {
uint64_t size;
if (!recv_data(sockfd, &size, sizeof(size))) {
return false;
}
try {
input.resize(size);
} catch (const std::bad_alloc & e) {
GGML_LOG_ERROR("Failed to allocate input buffer of size %" PRIu64 "\n", size);
return false;
}
return recv_data(sockfd, input.data(), size);
}
static bool parse_endpoint(const std::string & endpoint, std::string & host, int & port) {
size_t pos = endpoint.find(':');
if (pos == std::string::npos) {
return false;
}
host = endpoint.substr(0, pos);
port = std::stoi(endpoint.substr(pos + 1));
return true;
}
// RPC request : | rpc_cmd (1 byte) | request_size (8 bytes) | request_data (request_size bytes) |
// No response
static bool send_rpc_cmd(const std::shared_ptr<socket_t> & sock, enum rpc_cmd cmd, const void * input, size_t input_size) {
uint8_t cmd_byte = cmd;
if (!send_data(sock->fd, &cmd_byte, sizeof(cmd_byte))) {
return false;
}
if (!send_data(sock->fd, &input_size, sizeof(input_size))) {
return false;
}
if (!send_data(sock->fd, input, input_size)) {
return false;
}
return true;
}
// RPC request : | rpc_cmd (1 byte) | request_size (8 bytes) | request_data (request_size bytes) |
// RPC response: | response_size (8 bytes) | response_data (response_size bytes) |
static bool send_rpc_cmd(const std::shared_ptr<socket_t> & sock, enum rpc_cmd cmd, const void * input, size_t input_size, void * output, size_t output_size) {
if (!send_rpc_cmd(sock, cmd, input, input_size)) {
return false;
}
// TODO: currently the output_size is always known, do we need support for commands with variable output size?
// even if we do, we can skip sending output_size from the server for commands with known output size
uint64_t out_size;
if (!recv_data(sock->fd, &out_size, sizeof(out_size))) {
return false;
}
if (out_size != output_size) {
return false;
}
if (!recv_data(sock->fd, output, output_size)) {
return false;
}
return true;
}
// RPC client-side implementation
static bool check_server_version(const std::shared_ptr<socket_t> & sock) {
rpc_msg_hello_rsp response;
bool status = send_rpc_cmd(sock, RPC_CMD_HELLO, nullptr, 0, &response, sizeof(response));
RPC_STATUS_ASSERT(status);
if (response.major != RPC_PROTO_MAJOR_VERSION || response.minor > RPC_PROTO_MINOR_VERSION) {
GGML_LOG_ERROR("RPC server version mismatch: %d.%d.%d\n", response.major, response.minor, response.patch);
return false;
}
if (response.minor != RPC_PROTO_MINOR_VERSION || response.patch != RPC_PROTO_PATCH_VERSION) {
GGML_LOG_INFO("WARNING: RPC server version mismatch: %d.%d.%d\n", response.major, response.minor, response.patch);
}
return true;
}
static std::shared_ptr<socket_t> get_socket(const std::string & endpoint) {
static std::mutex mutex;
std::lock_guard<std::mutex> lock(mutex);
static std::unordered_map<std::string, std::weak_ptr<socket_t>> sockets;
static bool initialized = false;
auto it = sockets.find(endpoint);
if (it != sockets.end()) {
if (auto sock = it->second.lock()) {
return sock;
}
}
std::string host;
int port;
if (!parse_endpoint(endpoint, host, port)) {
GGML_LOG_ERROR("Failed to parse endpoint: %s\n", endpoint.c_str());
return nullptr;
}
#ifdef _WIN32
if (!initialized) {
WSADATA wsaData;
int res = WSAStartup(MAKEWORD(2, 2), &wsaData);
if (res != 0) {
return nullptr;
}
initialized = true;
}
#else
GGML_UNUSED(initialized);
#endif
auto sock = socket_connect(host.c_str(), port);
if (sock == nullptr) {
return nullptr;
}
if (!check_server_version(sock)) {
return nullptr;
}
LOG_DBG("[%s] connected to %s, sockfd=%d\n", __func__, endpoint.c_str(), sock->fd);
sockets[endpoint] = sock;
return sock;
}
static void ggml_backend_rpc_buffer_free_buffer(ggml_backend_buffer_t buffer) {
ggml_backend_rpc_buffer_context * ctx = (ggml_backend_rpc_buffer_context *)buffer->context;
rpc_msg_free_buffer_req request = {ctx->remote_ptr};
bool status = send_rpc_cmd(ctx->sock, RPC_CMD_FREE_BUFFER, &request, sizeof(request), nullptr, 0);
RPC_STATUS_ASSERT(status);
delete ctx;
}
static void * ggml_backend_rpc_buffer_get_base(ggml_backend_buffer_t buffer) {
ggml_backend_rpc_buffer_context * ctx = (ggml_backend_rpc_buffer_context *)buffer->context;
if (ctx->base_ptr != nullptr) {
return ctx->base_ptr;
}
rpc_msg_buffer_get_base_req request = {ctx->remote_ptr};
rpc_msg_buffer_get_base_rsp response;
bool status = send_rpc_cmd(ctx->sock, RPC_CMD_BUFFER_GET_BASE, &request, sizeof(request), &response, sizeof(response));
RPC_STATUS_ASSERT(status);
ctx->base_ptr = reinterpret_cast<void *>(response.base_ptr);
return ctx->base_ptr;
}
static bool ggml_backend_buffer_is_rpc(ggml_backend_buffer_t buffer) {
return buffer->iface.free_buffer == ggml_backend_rpc_buffer_free_buffer;
}
static rpc_tensor serialize_tensor(const ggml_tensor * tensor) {
rpc_tensor result;
if (!tensor) {
memset(&result, 0, sizeof(result));
return result;
}
result.id = reinterpret_cast<uint64_t>(tensor);
result.type = tensor->type;
if (tensor->buffer && ggml_backend_buffer_is_rpc(tensor->buffer)) {
ggml_backend_buffer_t buffer = tensor->buffer;
ggml_backend_rpc_buffer_context * ctx = (ggml_backend_rpc_buffer_context *)buffer->context;
result.buffer = ctx != nullptr ? ctx->remote_ptr : 0;
} else {
result.buffer = 0;
}
for (uint32_t i = 0; i < GGML_MAX_DIMS; i++) {
result.ne[i] = tensor->ne[i];
result.nb[i] = tensor->nb[i];
}
result.op = tensor->op;
for (uint32_t i = 0; i < GGML_MAX_OP_PARAMS / sizeof(int32_t); i++) {
result.op_params[i] = tensor->op_params[i];
}
result.flags = tensor->flags;
for (uint32_t i = 0; i < GGML_MAX_SRC; i++) {
result.src[i] = reinterpret_cast<uint64_t>(tensor->src[i]);
}
result.view_src = reinterpret_cast<uint64_t>(tensor->view_src);
result.view_offs = tensor->view_offs;
result.data = reinterpret_cast<uint64_t>(tensor->data);
// Avoid sending uninitialized data over the wire
memset(result.name, 0, sizeof(result.name));
memset(result.padding, 0, sizeof(result.padding));
snprintf(result.name, GGML_MAX_NAME, "%s", tensor->name);
return result;
}
static enum ggml_status ggml_backend_rpc_buffer_init_tensor(ggml_backend_buffer_t buffer, ggml_tensor * tensor) {
ggml_backend_rpc_buffer_context * ctx = (ggml_backend_rpc_buffer_context *)buffer->context;
// CUDA backend on the server pads everything to 512 due to CUDA limitations.
// Due to bandwidth constraints, we only call the server init tensor functions if necessary.
// In particular, only quantized tensors need padding
if (ggml_is_quantized(tensor->type) && (tensor->ne[0] % 512 != 0) && (tensor->view_src == nullptr)) {
rpc_msg_init_tensor_req request;
request.tensor = serialize_tensor(tensor);
bool status = send_rpc_cmd(ctx->sock, RPC_CMD_INIT_TENSOR, &request, sizeof(request), nullptr, 0);
RPC_STATUS_ASSERT(status);
}
return GGML_STATUS_SUCCESS;
}
static void ggml_backend_rpc_buffer_set_tensor(ggml_backend_buffer_t buffer, ggml_tensor * tensor, const void * data, size_t offset, size_t size) {
ggml_backend_rpc_buffer_context * ctx = (ggml_backend_rpc_buffer_context *)buffer->context;
rpc_tensor rpc_tensor = serialize_tensor(tensor);
if (size > HASH_THRESHOLD) {
rpc_msg_set_tensor_hash_req request;
request.tensor = rpc_tensor;
request.offset = offset;
request.hash = fnv_hash((const uint8_t*)data, size);
rpc_msg_set_tensor_hash_rsp response;
bool status = send_rpc_cmd(ctx->sock, RPC_CMD_SET_TENSOR_HASH, &request, sizeof(request), &response, sizeof(response));
RPC_STATUS_ASSERT(status);
if (response.result) {
// the server has the same data, no need to send it
return;
}
}
// input serialization format: | rpc_tensor | offset (8 bytes) | data (size bytes)
size_t input_size = sizeof(rpc_tensor) + sizeof(uint64_t) + size;
std::vector<uint8_t> input(input_size, 0);
memcpy(input.data(), &rpc_tensor, sizeof(rpc_tensor));
memcpy(input.data() + sizeof(rpc_tensor), &offset, sizeof(offset));
memcpy(input.data() + sizeof(rpc_tensor) + sizeof(offset), data, size);
bool status = send_rpc_cmd(ctx->sock, RPC_CMD_SET_TENSOR, input.data(), input.size());
RPC_STATUS_ASSERT(status);
}
static void ggml_backend_rpc_buffer_get_tensor(ggml_backend_buffer_t buffer, const ggml_tensor * tensor, void * data, size_t offset, size_t size) {
ggml_backend_rpc_buffer_context * ctx = (ggml_backend_rpc_buffer_context *)buffer->context;
rpc_msg_get_tensor_req request;
request.tensor = serialize_tensor(tensor);
request.offset = offset;
request.size = size;
bool status = send_rpc_cmd(ctx->sock, RPC_CMD_GET_TENSOR, &request, sizeof(request), data, size);
RPC_STATUS_ASSERT(status);
}
static bool ggml_backend_rpc_buffer_cpy_tensor(ggml_backend_buffer_t buffer, const ggml_tensor * src, ggml_tensor * dst) {
if (ggml_backend_buffer_is_rpc(src->buffer)) {
// check if src and dst are on the same server
ggml_backend_buffer_t src_buffer = src->buffer;
ggml_backend_rpc_buffer_context * src_ctx = (ggml_backend_rpc_buffer_context *)src_buffer->context;
ggml_backend_buffer_t dst_buffer = dst->buffer;
ggml_backend_rpc_buffer_context * dst_ctx = (ggml_backend_rpc_buffer_context *)dst_buffer->context;
if (src_ctx->sock != dst_ctx->sock) {
return false;
}
ggml_backend_rpc_buffer_context * ctx = (ggml_backend_rpc_buffer_context *)buffer->context;
rpc_msg_copy_tensor_req request;
request.src = serialize_tensor(src);
request.dst = serialize_tensor(dst);
rpc_msg_copy_tensor_rsp response;
bool status = send_rpc_cmd(ctx->sock, RPC_CMD_COPY_TENSOR, &request, sizeof(request), &response, sizeof(response));
RPC_STATUS_ASSERT(status);
return response.result;
}
return false;
}
static void ggml_backend_rpc_buffer_clear(ggml_backend_buffer_t buffer, uint8_t value) {
ggml_backend_rpc_buffer_context * ctx = (ggml_backend_rpc_buffer_context *)buffer->context;
rpc_msg_buffer_clear_req request = {ctx->remote_ptr, value};
bool status = send_rpc_cmd(ctx->sock, RPC_CMD_BUFFER_CLEAR, &request, sizeof(request), nullptr, 0);
RPC_STATUS_ASSERT(status);
}
static ggml_backend_buffer_i ggml_backend_rpc_buffer_interface = {
/* .free_buffer = */ ggml_backend_rpc_buffer_free_buffer,
/* .get_base = */ ggml_backend_rpc_buffer_get_base,
/* .init_tensor = */ ggml_backend_rpc_buffer_init_tensor,
/* .memset_tensor = */ NULL,
/* .set_tensor = */ ggml_backend_rpc_buffer_set_tensor,
/* .get_tensor = */ ggml_backend_rpc_buffer_get_tensor,
/* .cpy_tensor = */ ggml_backend_rpc_buffer_cpy_tensor,
/* .clear = */ ggml_backend_rpc_buffer_clear,
/* .reset = */ NULL,
};
static const char * ggml_backend_rpc_buffer_type_name(ggml_backend_buffer_type_t buft) {
ggml_backend_rpc_buffer_type_context * buft_ctx = (ggml_backend_rpc_buffer_type_context *)buft->context;
return buft_ctx->name.c_str();
}
static ggml_backend_buffer_t ggml_backend_rpc_buffer_type_alloc_buffer(ggml_backend_buffer_type_t buft, size_t size) {
ggml_backend_rpc_buffer_type_context * buft_ctx = (ggml_backend_rpc_buffer_type_context *)buft->context;
rpc_msg_alloc_buffer_req request = {buft_ctx->device, size};
rpc_msg_alloc_buffer_rsp response;
auto sock = get_socket(buft_ctx->endpoint);
bool status = send_rpc_cmd(sock, RPC_CMD_ALLOC_BUFFER, &request, sizeof(request), &response, sizeof(response));
RPC_STATUS_ASSERT(status);
if (response.remote_ptr != 0) {
ggml_backend_buffer_t buffer = ggml_backend_buffer_init(buft,
ggml_backend_rpc_buffer_interface,
new ggml_backend_rpc_buffer_context{sock, nullptr, response.remote_ptr},
response.remote_size);
return buffer;
} else {
return nullptr;
}
}
static size_t get_alignment(const std::shared_ptr<socket_t> & sock, uint32_t device) {
rpc_msg_get_alignment_req request = {device};
rpc_msg_get_alignment_rsp response;
bool status = send_rpc_cmd(sock, RPC_CMD_GET_ALIGNMENT, &request, sizeof(request), &response, sizeof(response));
RPC_STATUS_ASSERT(status);
return response.alignment;
}
static size_t ggml_backend_rpc_buffer_type_get_alignment(ggml_backend_buffer_type_t buft) {
ggml_backend_rpc_buffer_type_context * buft_ctx = (ggml_backend_rpc_buffer_type_context *)buft->context;
return buft_ctx->alignment;
}
static size_t get_max_size(const std::shared_ptr<socket_t> & sock, uint32_t device) {
rpc_msg_get_max_size_req request = {device};
rpc_msg_get_max_size_rsp response;
bool status = send_rpc_cmd(sock, RPC_CMD_GET_MAX_SIZE, &request, sizeof(request), &response, sizeof(response));
RPC_STATUS_ASSERT(status);
return response.max_size;
}
static size_t ggml_backend_rpc_get_max_size(ggml_backend_buffer_type_t buft) {
ggml_backend_rpc_buffer_type_context * buft_ctx = (ggml_backend_rpc_buffer_type_context *)buft->context;
return buft_ctx->max_size;
}
static size_t ggml_backend_rpc_buffer_type_get_alloc_size(ggml_backend_buffer_type_t buft, const ggml_tensor * tensor) {
// should we query the remote server for the actual size
bool rpc_get = false;
// See comments in init_tensor.
rpc_get |= ggml_is_quantized(tensor->type) && (tensor->ne[0] % 512 != 0) && (tensor->view_src == nullptr);
// ops that require additional memory for fleeting data on certain backends
// ref: https://github.com/ggml-org/llama.cpp/pull/15966
rpc_get |= tensor->op == GGML_OP_FLASH_ATTN_EXT;
rpc_get |= tensor->op == GGML_OP_MUL_MAT_ID;
if (rpc_get) {
ggml_backend_rpc_buffer_type_context * buft_ctx = (ggml_backend_rpc_buffer_type_context *)buft->context;
auto sock = get_socket(buft_ctx->endpoint);
rpc_msg_get_alloc_size_req request = {
/*.device =*/ buft_ctx->device,
/*.tensor =*/ serialize_tensor(tensor),
/*.srcs =*/ {},
};
// .get_alloc_size could be a function of the tensor's srcs, so we must serialize them as well
for (int i = 0; i < GGML_MAX_SRC; i++) {
request.srcs[i] = serialize_tensor(tensor->src[i]);
}
// TODO: cache the alloc responses to avoid extra RPC calls?
rpc_msg_get_alloc_size_rsp response;
bool status = send_rpc_cmd(sock, RPC_CMD_GET_ALLOC_SIZE, &request, sizeof(request), &response, sizeof(response));
RPC_STATUS_ASSERT(status);
return response.alloc_size;
}
return ggml_nbytes(tensor);
}
static ggml_backend_buffer_type_i ggml_backend_rpc_buffer_type_interface = {
/* .get_name = */ ggml_backend_rpc_buffer_type_name,
/* .alloc_buffer = */ ggml_backend_rpc_buffer_type_alloc_buffer,
/* .get_alignment = */ ggml_backend_rpc_buffer_type_get_alignment,
/* .get_max_size = */ ggml_backend_rpc_get_max_size,
/* .get_alloc_size = */ ggml_backend_rpc_buffer_type_get_alloc_size,
/* .is_host = */ NULL,
};
static const char * ggml_backend_rpc_name(ggml_backend_t backend) {
ggml_backend_rpc_context * rpc_ctx = (ggml_backend_rpc_context *)backend->context;
return rpc_ctx->name.c_str();
}
static void ggml_backend_rpc_free(ggml_backend_t backend) {
ggml_backend_rpc_context * rpc_ctx = (ggml_backend_rpc_context *)backend->context;
delete rpc_ctx;
delete backend;
}
static void ggml_backend_rpc_synchronize(ggml_backend_t backend) {
GGML_UNUSED(backend);
// this is no-op because we don't have any async operations
}
static void add_tensor(ggml_tensor * tensor, std::vector<rpc_tensor> & tensors, std::unordered_set<ggml_tensor*> & visited) {
if (tensor == nullptr) {
return;
}
if (visited.find(tensor) != visited.end()) {
return;
}
visited.insert(tensor);
for (int i = 0; i < GGML_MAX_SRC; i++) {
add_tensor(tensor->src[i], tensors, visited);
}
add_tensor(tensor->view_src, tensors, visited);
tensors.push_back(serialize_tensor(tensor));
}
static void serialize_graph(uint32_t device, const ggml_cgraph * cgraph, std::vector<uint8_t> & output) {
uint32_t n_nodes = cgraph->n_nodes;
std::vector<rpc_tensor> tensors;
std::unordered_set<ggml_tensor*> visited;
for (uint32_t i = 0; i < n_nodes; i++) {
add_tensor(cgraph->nodes[i], tensors, visited);
}
// serialization format:
// | device (4 bytes) | n_nodes (4 bytes) | nodes (n_nodes * sizeof(uint64_t) | n_tensors (4 bytes) | tensors (n_tensors * sizeof(rpc_tensor)) |
uint32_t n_tensors = tensors.size();
int output_size = 2*sizeof(uint32_t) + n_nodes * sizeof(uint64_t) + sizeof(uint32_t) + n_tensors * sizeof(rpc_tensor);
output.resize(output_size, 0);
uint8_t * dest = output.data();
memcpy(dest, &device, sizeof(device));
dest += sizeof(device);
memcpy(dest, &n_nodes, sizeof(n_nodes));
dest += sizeof(n_nodes);
for (uint32_t i = 0; i < n_nodes; i++) {
memcpy(dest + i * sizeof(uint64_t), &cgraph->nodes[i], sizeof(uint64_t));
}
dest += n_nodes * sizeof(uint64_t);
memcpy(dest, &n_tensors, sizeof(n_tensors));
dest += sizeof(n_tensors);
rpc_tensor * out_tensors = (rpc_tensor *)dest;
memcpy(out_tensors, tensors.data(), n_tensors * sizeof(rpc_tensor));
}
static enum ggml_status ggml_backend_rpc_graph_compute(ggml_backend_t backend, ggml_cgraph * cgraph) {
ggml_backend_rpc_context * rpc_ctx = (ggml_backend_rpc_context *)backend->context;
GGML_ASSERT(cgraph->n_nodes > 0);
bool reuse = rpc_ctx->gc.is_cached(cgraph);
if (reuse) {
rpc_msg_graph_recompute_req request;
request.device = rpc_ctx->device;
auto sock = get_socket(rpc_ctx->endpoint);
bool status = send_rpc_cmd(sock, RPC_CMD_GRAPH_RECOMPUTE, &request, sizeof(request));
RPC_STATUS_ASSERT(status);
} else {
rpc_ctx->gc.add(cgraph);
std::vector<uint8_t> input;
serialize_graph(rpc_ctx->device, cgraph, input);
auto sock = get_socket(rpc_ctx->endpoint);
bool status = send_rpc_cmd(sock, RPC_CMD_GRAPH_COMPUTE, input.data(), input.size());
RPC_STATUS_ASSERT(status);
}
return GGML_STATUS_SUCCESS;
}
static ggml_backend_i ggml_backend_rpc_interface = {
/* .get_name = */ ggml_backend_rpc_name,
/* .free = */ ggml_backend_rpc_free,
/* .set_tensor_async = */ NULL,
/* .get_tensor_async = */ NULL,
/* .cpy_tensor_async = */ NULL,
/* .synchronize = */ ggml_backend_rpc_synchronize,
/* .graph_plan_create = */ NULL,
/* .graph_plan_free = */ NULL,
/* .graph_plan_update = */ NULL,
/* .graph_plan_compute = */ NULL,
/* .graph_compute = */ ggml_backend_rpc_graph_compute,
/* .event_record = */ NULL,
/* .event_wait = */ NULL,
/* .graph_optimize = */ NULL,
};
ggml_backend_buffer_type_t ggml_backend_rpc_buffer_type(const char * endpoint, uint32_t device) {
static std::mutex mutex;
std::lock_guard<std::mutex> lock(mutex);
std::string buft_name = "RPC" + std::to_string(device) + "[" + std::string(endpoint) + "]";
// NOTE: buffer types are allocated and never freed; this is by design
static std::unordered_map<std::string, ggml_backend_buffer_type_t> buft_map;
auto it = buft_map.find(buft_name);
if (it != buft_map.end()) {
return it->second;
}
auto sock = get_socket(endpoint);
if (sock == nullptr) {
GGML_LOG_ERROR("Failed to connect to %s\n", endpoint);
return nullptr;
}
size_t alignment = get_alignment(sock, device);
size_t max_size = get_max_size(sock, device);
ggml_backend_rpc_buffer_type_context * buft_ctx = new ggml_backend_rpc_buffer_type_context {
/* .endpoint = */ endpoint,
/* .device = */ device,
/* .name = */ buft_name,
/* .alignment = */ alignment,
/* .max_size = */ max_size
};
auto reg = ggml_backend_rpc_add_server(endpoint);
ggml_backend_buffer_type_t buft = new ggml_backend_buffer_type {
/* .iface = */ ggml_backend_rpc_buffer_type_interface,
/* .device = */ ggml_backend_reg_dev_get(reg, device),
/* .context = */ buft_ctx
};
buft_map[buft_name] = buft;
return buft;
}
ggml_backend_t ggml_backend_rpc_init(const char * endpoint, uint32_t device) {
std::string dev_name = "RPC" + std::to_string(device) + "[" + std::string(endpoint) + "]";
ggml_backend_rpc_context * ctx = new ggml_backend_rpc_context {
/* .endpoint = */ endpoint,
/* .device = */ device,
/* .name = */ dev_name,
/* .gc = */ {},
};
auto reg = ggml_backend_rpc_add_server(endpoint);
ggml_backend_t backend = new ggml_backend {
/* .guid = */ ggml_backend_rpc_guid(),
/* .iface = */ ggml_backend_rpc_interface,
/* .device = */ ggml_backend_reg_dev_get(reg, device),
/* .context = */ ctx
};
return backend;
}
bool ggml_backend_is_rpc(ggml_backend_t backend) {
return backend != NULL && ggml_guid_matches(backend->guid, ggml_backend_rpc_guid());
}
static void get_device_memory(const std::shared_ptr<socket_t> & sock, uint32_t device, size_t * free, size_t * total) {
rpc_msg_get_device_memory_req request;
request.device = device;
rpc_msg_get_device_memory_rsp response;
bool status = send_rpc_cmd(sock, RPC_CMD_GET_DEVICE_MEMORY, &request, sizeof(request), &response, sizeof(response));
RPC_STATUS_ASSERT(status);
*free = response.free_mem;
*total = response.total_mem;
}
void ggml_backend_rpc_get_device_memory(const char * endpoint, uint32_t device, size_t * free, size_t * total) {
auto sock = get_socket(endpoint);
if (sock == nullptr) {
*free = 0;
*total = 0;
return;
}
get_device_memory(sock, device, free, total);
}
// RPC server-side implementation
class rpc_server {
public:
rpc_server(std::vector<ggml_backend_t> all_backends, const char * cache_dir)
: backends(std::move(all_backends)), cache_dir(cache_dir) {
stored_graphs.resize(backends.size());
}
~rpc_server();
void hello(rpc_msg_hello_rsp & response);
bool alloc_buffer(const rpc_msg_alloc_buffer_req & request, rpc_msg_alloc_buffer_rsp & response);
bool get_alignment(const rpc_msg_get_alignment_req & request, rpc_msg_get_alignment_rsp & response);
bool get_max_size(const rpc_msg_get_max_size_req & request, rpc_msg_get_max_size_rsp & response);
bool buffer_get_base(const rpc_msg_buffer_get_base_req & request, rpc_msg_buffer_get_base_rsp & response);
bool free_buffer(const rpc_msg_free_buffer_req & request);
bool buffer_clear(const rpc_msg_buffer_clear_req & request);
bool set_tensor(const std::vector<uint8_t> & input);
bool set_tensor_hash(const rpc_msg_set_tensor_hash_req & request, rpc_msg_set_tensor_hash_rsp & response);
bool get_tensor(const rpc_msg_get_tensor_req & request, std::vector<uint8_t> & response);
bool copy_tensor(const rpc_msg_copy_tensor_req & request, rpc_msg_copy_tensor_rsp & response);
bool graph_compute(const std::vector<uint8_t> & input);
bool graph_recompute(const rpc_msg_graph_recompute_req & request);
bool init_tensor(const rpc_msg_init_tensor_req & request);
bool get_alloc_size(const rpc_msg_get_alloc_size_req & request, rpc_msg_get_alloc_size_rsp & response);
bool get_device_memory(const rpc_msg_get_device_memory_req & request, rpc_msg_get_device_memory_rsp & response);
struct stored_graph {
ggml_context_ptr ctx_ptr;
ggml_cgraph * graph;
};
private:
bool get_cached_file(uint64_t hash, std::vector<uint8_t> & data);
ggml_tensor * deserialize_tensor(struct ggml_context * ctx, const rpc_tensor * tensor);
ggml_tensor * create_node(uint64_t id,
struct ggml_context * ctx,
const std::unordered_map<uint64_t, const rpc_tensor*> & tensor_ptrs,
std::unordered_map<uint64_t, struct ggml_tensor*> & tensor_map);
std::vector<ggml_backend_t> backends;
const char * cache_dir;
std::unordered_set<ggml_backend_buffer_t> buffers;
// store the last computed graph for each backend
std::vector<stored_graph> stored_graphs;
};
void rpc_server::hello(rpc_msg_hello_rsp & response) {
response.major = RPC_PROTO_MAJOR_VERSION;
response.minor = RPC_PROTO_MINOR_VERSION;
response.patch = RPC_PROTO_PATCH_VERSION;
LOG_DBG("[%s] version: %d.%d.%d\n", __func__, response.major, response.minor, response.patch);
}
bool rpc_server::get_alloc_size(const rpc_msg_get_alloc_size_req & request, rpc_msg_get_alloc_size_rsp & response) {
uint32_t dev_id = request.device;
if (dev_id >= backends.size()) {
return false;
}
ggml_backend_buffer_type_t buft;
struct ggml_init_params params {
/*.mem_size =*/ ggml_tensor_overhead()*(1 + GGML_MAX_SRC),
/*.mem_buffer =*/ NULL,
/*.no_alloc =*/ true,
};
ggml_context_ptr ctx_ptr { ggml_init(params) };
GGML_ASSERT(ctx_ptr != nullptr);
ggml_context * ctx = ctx_ptr.get();
ggml_tensor * tensor = deserialize_tensor(ctx, &request.tensor);
if (tensor == nullptr) {
GGML_LOG_ERROR("Null tensor pointer passed to server get_alloc_size function.\n");
return false;
}
for (int i = 0; i < GGML_MAX_SRC; i++) {
if (request.srcs[i].id != 0) {
tensor->src[i] = deserialize_tensor(ctx, &request.srcs[i]);
}
}
LOG_DBG("[%s] device: %d, buffer: %p, data: %p\n", __func__, dev_id, (void*)tensor->buffer, tensor->data);
if (tensor->buffer == nullptr) {
//No buffer allocated.
buft = ggml_backend_get_default_buffer_type(backends[dev_id]);
} else {
buft = tensor->buffer->buft;
}
response.alloc_size = ggml_backend_buft_get_alloc_size(buft, tensor);
return true;
}
bool rpc_server::alloc_buffer(const rpc_msg_alloc_buffer_req & request, rpc_msg_alloc_buffer_rsp & response) {
uint32_t dev_id = request.device;
if (dev_id >= backends.size()) {
return false;
}
ggml_backend_buffer_type_t buft = ggml_backend_get_default_buffer_type(backends[dev_id]);
ggml_backend_buffer_t buffer = ggml_backend_buft_alloc_buffer(buft, request.size);
response.remote_ptr = 0;
response.remote_size = 0;
if (buffer != nullptr) {
response.remote_ptr = reinterpret_cast<uint64_t>(buffer);
response.remote_size = buffer->size;
LOG_DBG("[%s] device: %d, size: %" PRIu64 " -> remote_ptr: %" PRIx64 ", remote_size: %" PRIu64 "\n",
__func__, dev_id, request.size, response.remote_ptr, response.remote_size);
buffers.insert(buffer);
} else {
LOG_DBG("[%s] device: %d, size: %" PRIu64 " -> failed\n", __func__, dev_id, request.size);
}
return true;
}
bool rpc_server::get_alignment(const rpc_msg_get_alignment_req & request, rpc_msg_get_alignment_rsp & response) {
uint32_t dev_id = request.device;
if (dev_id >= backends.size()) {
return false;
}
ggml_backend_buffer_type_t buft = ggml_backend_get_default_buffer_type(backends[dev_id]);
size_t alignment = ggml_backend_buft_get_alignment(buft);
LOG_DBG("[%s] device: %d, alignment: %lu\n", __func__, dev_id, alignment);
response.alignment = alignment;
return true;
}
bool rpc_server::get_max_size(const rpc_msg_get_max_size_req & request, rpc_msg_get_max_size_rsp & response) {
uint32_t dev_id = request.device;
if (dev_id >= backends.size()) {
return false;
}
ggml_backend_buffer_type_t buft = ggml_backend_get_default_buffer_type(backends[dev_id]);
size_t max_size = ggml_backend_buft_get_max_size(buft);
LOG_DBG("[%s] device: %d, max_size: %lu\n", __func__, dev_id, max_size);
response.max_size = max_size;
return true;
}
bool rpc_server::buffer_get_base(const rpc_msg_buffer_get_base_req & request, rpc_msg_buffer_get_base_rsp & response) {
LOG_DBG("[%s] remote_ptr: %" PRIx64 "\n", __func__, request.remote_ptr);
ggml_backend_buffer_t buffer = reinterpret_cast<ggml_backend_buffer_t>(request.remote_ptr);
if (buffers.find(buffer) == buffers.end()) {
GGML_LOG_ERROR("[%s] buffer not found\n", __func__);
return false;
}
void * base = ggml_backend_buffer_get_base(buffer);
response.base_ptr = reinterpret_cast<uint64_t>(base);
return true;
}
bool rpc_server::free_buffer(const rpc_msg_free_buffer_req & request) {
LOG_DBG("[%s] remote_ptr: %" PRIx64 "\n", __func__, request.remote_ptr);
ggml_backend_buffer_t buffer = reinterpret_cast<ggml_backend_buffer_t>(request.remote_ptr);
if (buffers.find(buffer) == buffers.end()) {
GGML_LOG_ERROR("[%s] buffer not found\n", __func__);
return false;
}
ggml_backend_buffer_free(buffer);
buffers.erase(buffer);
return true;
}
bool rpc_server::buffer_clear(const rpc_msg_buffer_clear_req & request) {
LOG_DBG("[%s] remote_ptr: %" PRIx64 ", value: %u\n", __func__, request.remote_ptr, request.value);
ggml_backend_buffer_t buffer = reinterpret_cast<ggml_backend_buffer_t>(request.remote_ptr);
if (buffers.find(buffer) == buffers.end()) {
GGML_LOG_ERROR("[%s] buffer not found\n", __func__);
return false;
}
ggml_backend_buffer_clear(buffer, request.value);
return true;
}
ggml_tensor * rpc_server::deserialize_tensor(struct ggml_context * ctx, const rpc_tensor * tensor) {
// Validate tensor type before using it
if (tensor->type >= GGML_TYPE_COUNT) {
GGML_LOG_ERROR("[%s] invalid tensor type received: %u\n", __func__, tensor->type);
return nullptr;
}
ggml_tensor * result = ggml_new_tensor_4d(ctx, (ggml_type) tensor->type,
tensor->ne[0], tensor->ne[1], tensor->ne[2], tensor->ne[3]);
// ggml_new_tensor_4d might fail if dimensions are invalid, although less likely to crash than invalid type
if (result == nullptr) {
GGML_LOG_ERROR("[%s] ggml_new_tensor_4d failed for type %u\\n", __func__, tensor->type);
return nullptr;
}
for (uint32_t i = 0; i < GGML_MAX_DIMS; i++) {
result->nb[i] = tensor->nb[i];
}
result->buffer = reinterpret_cast<ggml_backend_buffer_t>(tensor->buffer);
if (result->buffer && buffers.find(result->buffer) == buffers.end()) {
result->buffer = nullptr;
}
if (result->buffer) {
// require that the tensor data does not go beyond the buffer end
uint64_t tensor_size = (uint64_t) ggml_nbytes(result);
uint64_t buffer_start = (uint64_t) ggml_backend_buffer_get_base(result->buffer);
uint64_t buffer_size = (uint64_t) ggml_backend_buffer_get_size(result->buffer);
GGML_ASSERT(tensor->data + tensor_size >= tensor->data); // check for overflow
GGML_ASSERT(tensor->data >= buffer_start && tensor->data + tensor_size <= buffer_start + buffer_size);
}
result->op = (ggml_op) tensor->op;
for (uint32_t i = 0; i < GGML_MAX_OP_PARAMS / sizeof(int32_t); i++) {
result->op_params[i] = tensor->op_params[i];
}
result->flags = tensor->flags;
result->data = reinterpret_cast<void *>(tensor->data);
ggml_set_name(result, tensor->name);
return result;
}
bool rpc_server::set_tensor(const std::vector<uint8_t> & input) {
// serialization format: | rpc_tensor | offset (8 bytes) | data (size bytes) |
if (input.size() < sizeof(rpc_tensor) + sizeof(uint64_t)) {
return false;
}
const rpc_tensor * in_tensor = (const rpc_tensor *)input.data();
uint64_t offset;
memcpy(&offset, input.data() + sizeof(rpc_tensor), sizeof(offset));
const size_t size = input.size() - sizeof(rpc_tensor) - sizeof(offset);
struct ggml_init_params params {
/*.mem_size =*/ ggml_tensor_overhead(),
/*.mem_buffer =*/ NULL,
/*.no_alloc =*/ true,
};
ggml_context_ptr ctx_ptr { ggml_init(params) };
GGML_ASSERT(ctx_ptr != nullptr);
ggml_context * ctx = ctx_ptr.get();
ggml_tensor * tensor = deserialize_tensor(ctx, in_tensor);
if (tensor == nullptr || tensor->buffer == nullptr) {
GGML_LOG_ERROR("[%s] error deserializing tensor\n", __func__);
return false;
}
LOG_DBG("[%s] buffer: %p, data: %p, offset: %" PRIu64 ", size: %zu\n", __func__, (void*)tensor->buffer, tensor->data, offset, size);
// sanitize tensor->data
{
const size_t p0 = (size_t) ggml_backend_buffer_get_base(tensor->buffer);
const size_t p1 = p0 + ggml_backend_buffer_get_size(tensor->buffer);
if (in_tensor->data + offset < p0 || in_tensor->data + offset >= p1 || size > (p1 - in_tensor->data - offset)) {
GGML_LOG_ERROR("[%s] tensor data region (data=0x%" PRIx64 ", offset=%" PRIu64 ", size=%zu) out of buffer bounds [0x%zx, 0x%zx)\n",
__func__, in_tensor->data, offset, size, p0, p1);
return false;
}
}
const void * data = input.data() + sizeof(rpc_tensor) + sizeof(offset);
if (cache_dir && size > HASH_THRESHOLD) {
uint64_t hash = fnv_hash((const uint8_t*)data, size);
char hash_str[17];
snprintf(hash_str, sizeof(hash_str), "%016" PRIx64, hash);
// save to cache_dir/hash_str
fs::path cache_file = fs::path(cache_dir) / hash_str;
std::ofstream ofs(cache_file, std::ios::binary);
ofs.write((const char *)data, size);
GGML_LOG_INFO("[%s] saved to '%s'\n", __func__, cache_file.c_str());
}
ggml_backend_tensor_set(tensor, data, offset, size);
return true;
}
bool rpc_server::get_cached_file(uint64_t hash, std::vector<uint8_t> & data) {
if (!cache_dir) {
return false;
}
char hash_str[17];
snprintf(hash_str, sizeof(hash_str), "%016" PRIx64, hash);
fs::path cache_file = fs::path(cache_dir) / hash_str;
std::error_code ec;
if (!fs::exists(cache_file, ec)) {
return false;
}
std::ifstream ifs(cache_file, std::ios::binary);
ifs.seekg(0, std::ios::end);
size_t size = ifs.tellg();
ifs.seekg(0, std::ios::beg);
data.resize(size);
ifs.read((char *)data.data(), size);
return true;
}
bool rpc_server::set_tensor_hash(const rpc_msg_set_tensor_hash_req & request, rpc_msg_set_tensor_hash_rsp & response)
{
std::vector<uint8_t> cached_file;
if (!get_cached_file(request.hash, cached_file)) {
response.result = 0;
return true;
}
size_t size = cached_file.size();
struct ggml_init_params params {
/*.mem_size =*/ ggml_tensor_overhead(),
/*.mem_buffer =*/ NULL,
/*.no_alloc =*/ true,
};
ggml_context_ptr ctx_ptr { ggml_init(params) };
GGML_ASSERT(ctx_ptr != nullptr);
ggml_context * ctx = ctx_ptr.get();
ggml_tensor * tensor = deserialize_tensor(ctx, &request.tensor);
if (tensor == nullptr || tensor->buffer == nullptr) {
GGML_LOG_ERROR("[%s] error deserializing tensor\n", __func__);
return false;
}
LOG_DBG("[%s] buffer: %p, data: %p, offset: %" PRIu64 ", size: %zu, hash: %" PRIx64 "\n",
__func__, (void*)tensor->buffer, tensor->data, request.offset, size, request.hash);
// sanitize tensor->data
{
const size_t p0 = (size_t) ggml_backend_buffer_get_base(tensor->buffer);
const size_t p1 = p0 + ggml_backend_buffer_get_size(tensor->buffer);
if (request.tensor.data + request.offset < p0
|| request.tensor.data + request.offset >= p1
|| size > (p1 - request.tensor.data - request.offset)) {
GGML_LOG_ERROR("[%s] tensor data region (data=0x%" PRIx64 ", offset=%" PRIu64 ", size=%zu, hash=0x%" PRIx64 ") out of buffer bounds [0x%zx, 0x%zx)\n",
__func__, request.tensor.data, request.offset, size, request.hash, p0, p1);
return false;
}
}
ggml_backend_tensor_set(tensor, cached_file.data(), request.offset, size);
response.result = 1;
return true;
}
bool rpc_server::init_tensor(const rpc_msg_init_tensor_req & request) {
struct ggml_init_params params {
/*.mem_size =*/ ggml_tensor_overhead(),
/*.mem_buffer =*/ NULL,
/*.no_alloc =*/ true,
};
ggml_context_ptr ctx_ptr { ggml_init(params) };
GGML_ASSERT(ctx_ptr != nullptr);
ggml_context * ctx = ctx_ptr.get();
ggml_tensor * tensor = deserialize_tensor(ctx, &request.tensor);
if (tensor == nullptr) {
GGML_LOG_ERROR("Null tensor pointer passed to server init_tensor function.\n");
return false;
}
LOG_DBG("[%s] buffer: %p, data: %p\n", __func__, (void*)tensor->buffer, tensor->data);
// Call the backend's buffer_init_tensor function
ggml_backend_buffer_t buffer = tensor->buffer;
if (buffer && buffer->iface.init_tensor) {
buffer->iface.init_tensor(buffer, tensor);
} else {
GGML_LOG_ERROR("Null buffer for tensor passed to init_tensor function\n");
}
if (tensor->extra != nullptr) {
// This pointer can either be passed around client/server, or probably better stored server-side and kept track of.
// Currently unimplemented.
GGML_LOG_ERROR("tensor->extra populated by the backend, this is currently unsupported.\n");
return false;
}
return true;
}
bool rpc_server::get_tensor(const rpc_msg_get_tensor_req & request, std::vector<uint8_t> & response) {
struct ggml_init_params params {
/*.mem_size =*/ ggml_tensor_overhead(),
/*.mem_buffer =*/ NULL,
/*.no_alloc =*/ true,
};
ggml_context_ptr ctx_ptr { ggml_init(params) };
GGML_ASSERT(ctx_ptr != nullptr);
ggml_context * ctx = ctx_ptr.get();
ggml_tensor * tensor = deserialize_tensor(ctx, &request.tensor);
if (tensor == nullptr || tensor->buffer == nullptr) {
GGML_LOG_ERROR("[%s] error deserializing tensor\n", __func__);
return false;
}
LOG_DBG("[%s] buffer: %p, data: %p, offset: %" PRIu64 ", size: %" PRIu64 "\n", __func__, (void*)tensor->buffer, tensor->data, request.offset, request.size);
// sanitize tensor->data
{
const size_t p0 = (size_t) ggml_backend_buffer_get_base(tensor->buffer);
const size_t p1 = p0 + ggml_backend_buffer_get_size(tensor->buffer);
if (request.tensor.data + request.offset < p0 ||
request.tensor.data + request.offset >= p1 ||
request.size > (p1 - request.tensor.data - request.offset)) {
GGML_LOG_ERROR("[%s] requested tensor region (data=0x%" PRIx64 ", offset=%" PRIu64 ", size=%" PRIu64 ") out of buffer bounds [0x%zx, 0x%zx)\n",
__func__, request.tensor.data, request.offset, request.size, p0, p1);
return false;
}
}
response.resize(request.size, 0);
ggml_backend_tensor_get(tensor, response.data(), request.offset, request.size);
return true;
}
bool rpc_server::copy_tensor(const rpc_msg_copy_tensor_req & request, rpc_msg_copy_tensor_rsp & response) {
struct ggml_init_params params {
/*.mem_size =*/ 2*ggml_tensor_overhead(),
/*.mem_buffer =*/ NULL,
/*.no_alloc =*/ true,
};
ggml_context_ptr ctx_ptr { ggml_init(params) };
GGML_ASSERT(ctx_ptr != nullptr);
ggml_context * ctx = ctx_ptr.get();
ggml_tensor * src = deserialize_tensor(ctx, &request.src);
ggml_tensor * dst = deserialize_tensor(ctx, &request.dst);
if (src == nullptr || dst == nullptr || src->buffer == nullptr || dst->buffer == nullptr) {
GGML_LOG_ERROR("[%s] error deserializing tensors\n", __func__);
return false;
}
uint64_t src_size = (uint64_t) ggml_nbytes(src);
uint64_t dst_data = (uint64_t) dst->data;
uint64_t dst_base = (uint64_t) ggml_backend_buffer_get_base(dst->buffer);
uint64_t dst_buf_sz = (uint64_t) ggml_backend_buffer_get_size(dst->buffer);
if (dst_data + src_size > dst_base + dst_buf_sz) {
GGML_LOG_ERROR("[%s] out-of-bounds write in rpc_server::copy_tensor:\n"
" write range : [0x%" PRIx64 ", 0x%" PRIx64 "]\n"
" buffer base: [0x%" PRIx64 ", 0x%" PRIx64 "]\n",
__func__,
dst_data,
dst_data + src_size,
dst_base,
dst_base + dst_buf_sz);
return false;
}
LOG_DBG("[%s] src->buffer: %p, dst->buffer: %p\n",
__func__, (void*) src->buffer, (void*) dst->buffer);
response.result = ggml_backend_buffer_copy_tensor(src, dst);
return true;
}
ggml_tensor * rpc_server::create_node(uint64_t id,
struct ggml_context * ctx,
const std::unordered_map<uint64_t, const rpc_tensor*> & tensor_ptrs,
std::unordered_map<uint64_t, struct ggml_tensor*> & tensor_map) {
if (tensor_map.find(id) != tensor_map.end()) {
return tensor_map[id];
}
// Safely find the tensor pointer
auto it_ptr = tensor_ptrs.find(id);
if (it_ptr == tensor_ptrs.end()) {
return nullptr;
}
const rpc_tensor * tensor = it_ptr->second;
struct ggml_tensor * result = deserialize_tensor(ctx, tensor);
if (result == nullptr) {
return nullptr;
}
tensor_map[id] = result;
for (int i = 0; i < GGML_MAX_SRC; i++) {
// Check if the source ID is 0 before calling create_node recursively
if (tensor->src[i] == 0) {
result->src[i] = nullptr;
} else {
result->src[i] = create_node(tensor->src[i], ctx, tensor_ptrs, tensor_map);
// If the recursive call failed for a non-zero ID, propagate the error
if (result->src[i] == nullptr) {
GGML_LOG_ERROR("[%s] failed to create source node %d (src_id=%" PRIu64 ") for node id %" PRIu64 "\n",
__func__, i, tensor->src[i], id);
// Must return nullptr to signal failure up the call stack
return nullptr;
}
}
}
// Handle view_src similarly
if (tensor->view_src == 0) {
result->view_src = nullptr;
} else {
result->view_src = create_node(tensor->view_src, ctx, tensor_ptrs, tensor_map);
// If the recursive call failed for a non-zero ID, propagate the error
if (result->view_src == nullptr) {
GGML_LOG_ERROR("[%s] failed to create view_src node (view_src_id=%" PRIu64 ") for node id %" PRIu64 "\n",
__func__, tensor->view_src, id);
// Must return nullptr to signal failure up the call stack
return nullptr;
}
}
result->view_offs = tensor->view_offs;
return result;
}
bool rpc_server::graph_compute(const std::vector<uint8_t> & input) {
// serialization format:
// | device (4 bytes) | n_nodes (4 bytes) | nodes (n_nodes * sizeof(uint64_t) | n_tensors (4 bytes) | tensors (n_tensors * sizeof(rpc_tensor)) |
if (input.size() < 2*sizeof(uint32_t)) {
return false;
}
const uint8_t * src = input.data();
uint32_t device;
memcpy(&device, src, sizeof(device));
src += sizeof(device);
if (device >= backends.size()) {
return false;
}
uint32_t n_nodes;
memcpy(&n_nodes, src, sizeof(n_nodes));
src += sizeof(n_nodes);
if (input.size() < 2*sizeof(uint32_t) + n_nodes*sizeof(uint64_t) + sizeof(uint32_t)) {
return false;
}
const uint64_t * nodes = (const uint64_t *)src;
src += n_nodes*sizeof(uint64_t);
uint32_t n_tensors;
memcpy(&n_tensors, src, sizeof(n_tensors));
src += sizeof(n_tensors);
if (input.size() < 2*sizeof(uint32_t) + n_nodes*sizeof(uint64_t) + sizeof(uint32_t) + n_tensors*sizeof(rpc_tensor)) {
return false;
}
const rpc_tensor * tensors = (const rpc_tensor *)src;
LOG_DBG("[%s] device: %u, n_nodes: %u, n_tensors: %u\n", __func__, device, n_nodes, n_tensors);
size_t buf_size = ggml_tensor_overhead()*(n_nodes + n_tensors) + ggml_graph_overhead_custom(n_nodes, false);
struct ggml_init_params params = {
/*.mem_size =*/ buf_size,
/*.mem_buffer =*/ NULL,
/*.no_alloc =*/ true,
};
ggml_context_ptr ctx_ptr { ggml_init(params) };
GGML_ASSERT(ctx_ptr != nullptr);
ggml_context * ctx = ctx_ptr.get();
struct ggml_cgraph * graph = ggml_new_graph_custom(ctx, n_nodes, false);
graph->n_nodes = n_nodes;
std::unordered_map<uint64_t, const rpc_tensor*> tensor_ptrs;
tensor_ptrs.reserve(n_tensors);
for (uint32_t i = 0; i < n_tensors; i++) {
tensor_ptrs.emplace(tensors[i].id, &tensors[i]);
}
std::unordered_map<uint64_t, ggml_tensor*> tensor_map;
tensor_map.reserve(n_nodes);
for (uint32_t i = 0; i < n_nodes; i++) {
int64_t id;
memcpy(&id, &nodes[i], sizeof(id));
graph->nodes[i] = create_node(id, ctx, tensor_ptrs, tensor_map);
// Check if create_node failed for a *non-zero* ID.
// If id was 0, create_node returning nullptr is expected.
// If id was non-zero and create_node returned nullptr, it indicates a deserialization error.
if (graph->nodes[i] == nullptr && id != 0) {
GGML_LOG_ERROR("[%s] failed to create graph node %d (id=%" PRId64 ")\n", __func__, i, id);
return false;
}
}
ggml_status status = ggml_backend_graph_compute(backends[device], graph);
GGML_ASSERT(status == GGML_STATUS_SUCCESS && "Unsuccessful graph computations are not supported with RPC");
stored_graphs[device].ctx_ptr.swap(ctx_ptr);
stored_graphs[device].graph = graph;
return true;
}
bool rpc_server::graph_recompute(const rpc_msg_graph_recompute_req & request) {
uint32_t device = request.device;
if (device >= backends.size()) {
return false;
}
if (stored_graphs[device].graph == nullptr) {
return false;
}
ggml_cgraph * graph = stored_graphs[device].graph;
LOG_DBG("[%s] device: %u\n", __func__, device);
ggml_status status = ggml_backend_graph_compute(backends[device], graph);
GGML_ASSERT(status == GGML_STATUS_SUCCESS && "Unsuccessful graph computations are not supported with RPC");
return true;
}
bool rpc_server::get_device_memory(const rpc_msg_get_device_memory_req & request, rpc_msg_get_device_memory_rsp & response) {
uint32_t dev_id = request.device;
if (dev_id >= backends.size()) {
return false;
}
size_t free, total;
ggml_backend_dev_t dev = ggml_backend_get_device(backends[dev_id]);
ggml_backend_dev_memory(dev, &free, &total);
response.free_mem = free;
response.total_mem = total;
LOG_DBG("[%s] device: %u, free_mem: %" PRIu64 ", total_mem: %" PRIu64 "\n", __func__, dev_id, response.free_mem, response.total_mem);
return true;
}
rpc_server::~rpc_server() {
for (auto buffer : buffers) {
ggml_backend_buffer_free(buffer);
}
}
static void rpc_serve_client(const std::vector<ggml_backend_t> & backends, const char * cache_dir,
sockfd_t sockfd) {
rpc_server server(backends, cache_dir);
uint8_t cmd;
if (!recv_data(sockfd, &cmd, 1)) {
return;
}
// the first command sent by the client must be HELLO
if (cmd != RPC_CMD_HELLO) {
GGML_LOG_ERROR("Expected HELLO command, update client\n");
return;
}
if (!recv_msg(sockfd, nullptr, 0)) {
return;
}
rpc_msg_hello_rsp response;
server.hello(response);
if (!send_msg(sockfd, &response, sizeof(response))) {
return;
}
while (true) {
if (!recv_data(sockfd, &cmd, 1)) {
break;
}
if (cmd >= RPC_CMD_COUNT) {
// fail fast if the command is invalid
GGML_LOG_ERROR("Unknown command: %d\n", cmd);
break;
}
switch (cmd) {
case RPC_CMD_HELLO: {
// HELLO command is handled above
return;
}
case RPC_CMD_DEVICE_COUNT: {
if (!recv_msg(sockfd, nullptr, 0)) {
return;
}
rpc_msg_device_count_rsp response;
response.device_count = backends.size();
if (!send_msg(sockfd, &response, sizeof(response))) {
return;
}
break;
}
case RPC_CMD_ALLOC_BUFFER: {
rpc_msg_alloc_buffer_req request;
if (!recv_msg(sockfd, &request, sizeof(request))) {
return;
}
rpc_msg_alloc_buffer_rsp response;
if (!server.alloc_buffer(request, response)) {
return;
}
if (!send_msg(sockfd, &response, sizeof(response))) {
return;
}
break;
}
case RPC_CMD_GET_ALLOC_SIZE: {
rpc_msg_get_alloc_size_req request;
if (!recv_msg(sockfd, &request, sizeof(request))) {
return;
}
rpc_msg_get_alloc_size_rsp response;
if (!server.get_alloc_size(request, response)) {
return;
}
if (!send_msg(sockfd, &response, sizeof(response))) {
return;
}
break;
}
case RPC_CMD_GET_ALIGNMENT: {
rpc_msg_get_alignment_req request;
if (!recv_msg(sockfd, &request, sizeof(request))) {
return;
}
rpc_msg_get_alignment_rsp response;
if (!server.get_alignment(request, response)) {
return;
}
if (!send_msg(sockfd, &response, sizeof(response))) {
return;
}
break;
}
case RPC_CMD_GET_MAX_SIZE: {
rpc_msg_get_max_size_req request;
if (!recv_msg(sockfd, &request, sizeof(request))) {
return;
}
rpc_msg_get_max_size_rsp response;
if (!server.get_max_size(request, response)) {
return;
}
if (!send_msg(sockfd, &response, sizeof(response))) {
return;
}
break;
}
case RPC_CMD_BUFFER_GET_BASE: {
rpc_msg_buffer_get_base_req request;
if (!recv_msg(sockfd, &request, sizeof(request))) {
return;
}
rpc_msg_buffer_get_base_rsp response;
if (!server.buffer_get_base(request, response)) {
return;
}
if (!send_msg(sockfd, &response, sizeof(response))) {
return;
}
break;
}
case RPC_CMD_FREE_BUFFER: {
rpc_msg_free_buffer_req request;
if (!recv_msg(sockfd, &request, sizeof(request))) {
return;
}
if (!server.free_buffer(request)) {
return;
}
if (!send_msg(sockfd, nullptr, 0)) {
return;
}
break;
}
case RPC_CMD_BUFFER_CLEAR: {
rpc_msg_buffer_clear_req request;
if (!recv_msg(sockfd, &request, sizeof(request))) {
return;
}
if (!server.buffer_clear(request)) {
return;
}
if (!send_msg(sockfd, nullptr, 0)) {
return;
}
break;
}
case RPC_CMD_SET_TENSOR: {
std::vector<uint8_t> input;
if (!recv_msg(sockfd, input)) {
return;
}
if (!server.set_tensor(input)) {
return;
}
break;
}
case RPC_CMD_SET_TENSOR_HASH: {
rpc_msg_set_tensor_hash_req request;
if (!recv_msg(sockfd, &request, sizeof(request))) {
return;
}
rpc_msg_set_tensor_hash_rsp response;
if (!server.set_tensor_hash(request, response)) {
return;
}
if (!send_msg(sockfd, &response, sizeof(response))) {
return;
}
break;
}
case RPC_CMD_INIT_TENSOR: {
rpc_msg_init_tensor_req request;
if (!recv_msg(sockfd, &request,sizeof(request))) {
return;
}
if (!server.init_tensor(request)) {
return;
}
if (!send_msg(sockfd, nullptr, 0)) {
return;
}
break;
}
case RPC_CMD_GET_TENSOR: {
rpc_msg_get_tensor_req request;
if (!recv_msg(sockfd, &request, sizeof(request))) {
return;
}
std::vector<uint8_t> response;
if (!server.get_tensor(request, response)) {
return;
}
if (!send_msg(sockfd, response.data(), response.size())) {
return;
}
break;
}
case RPC_CMD_COPY_TENSOR: {
rpc_msg_copy_tensor_req request;
if (!recv_msg(sockfd, &request, sizeof(request))) {
return;
}
rpc_msg_copy_tensor_rsp response;
if (!server.copy_tensor(request, response)) {
return;
}
if (!send_msg(sockfd, &response, sizeof(response))) {
return;
}
break;
}
case RPC_CMD_GRAPH_COMPUTE: {
std::vector<uint8_t> input;
if (!recv_msg(sockfd, input)) {
return;
}
if (!server.graph_compute(input)) {
return;
}
break;
}
case RPC_CMD_GRAPH_RECOMPUTE: {
rpc_msg_graph_recompute_req request;
if (!recv_msg(sockfd, &request, sizeof(request))) {
return;
}
if (!server.graph_recompute(request)) {
return;
}
break;
}
case RPC_CMD_GET_DEVICE_MEMORY: {
rpc_msg_get_device_memory_req request;
if (!recv_msg(sockfd, &request, sizeof(request))) {
return;
}
rpc_msg_get_device_memory_rsp response;
if (!server.get_device_memory(request, response)) {
return;
}
if (!send_msg(sockfd, &response, sizeof(response))) {
return;
}
break;
}
default: {
GGML_LOG_ERROR("Unknown command: %d\n", cmd);
return;
}
}
}
}
void ggml_backend_rpc_start_server(const char * endpoint, const char * cache_dir,
size_t n_threads, size_t n_devices, ggml_backend_dev_t * devices) {
if (n_devices == 0 || devices == nullptr) {
fprintf(stderr, "Invalid arguments to ggml_backend_rpc_start_server\n");
return;
}
std::vector<ggml_backend_t> backends;
printf("Starting RPC server v%d.%d.%d\n",
RPC_PROTO_MAJOR_VERSION,
RPC_PROTO_MINOR_VERSION,
RPC_PROTO_PATCH_VERSION);
printf(" endpoint : %s\n", endpoint);
printf(" local cache : %s\n", cache_dir ? cache_dir : "n/a");
printf("Devices:\n");
for (size_t i = 0; i < n_devices; i++) {
auto dev = devices[i];
size_t free, total;
ggml_backend_dev_memory(dev, &free, &total);
printf(" %s: %s (%zu MiB, %zu MiB free)\n", ggml_backend_dev_name(dev), ggml_backend_dev_description(dev),
total / 1024 / 1024, free / 1024 / 1024);
auto backend = ggml_backend_dev_init(dev, nullptr);
if (!backend) {
fprintf(stderr, "Failed to create backend for device %s\n", dev->iface.get_name(dev));
return;
}
backends.push_back(backend);
ggml_backend_reg_t reg = dev ? ggml_backend_dev_backend_reg(dev) : nullptr;
if (reg) {
auto ggml_backend_set_n_threads_fn = (ggml_backend_set_n_threads_t) ggml_backend_reg_get_proc_address(reg, "ggml_backend_set_n_threads");
if (ggml_backend_set_n_threads_fn) {
ggml_backend_set_n_threads_fn(backend, n_threads);
}
}
}
std::string host;
int port;
if (!parse_endpoint(endpoint, host, port)) {
return;
}
#ifdef _WIN32
{
WSADATA wsaData;
int res = WSAStartup(MAKEWORD(2, 2), &wsaData);
if (res != 0) {
fprintf(stderr, "WSAStartup failed: %d\n", res);
return;
}
}
#endif
auto server_socket = create_server_socket(host.c_str(), port);
if (server_socket == nullptr) {
fprintf(stderr, "Failed to create server socket\n");
return;
}
while (true) {
auto client_socket = socket_accept(server_socket->fd);
if (client_socket == nullptr) {
fprintf(stderr, "Failed to accept client connection\n");
return;
}
printf("Accepted client connection\n");
fflush(stdout);
rpc_serve_client(backends, cache_dir, client_socket->fd);
printf("Client connection closed\n");
fflush(stdout);
}
#ifdef _WIN32
WSACleanup();
#endif
for (auto backend : backends) {
ggml_backend_free(backend);
}
}
// device interface
struct ggml_backend_rpc_device_context {
std::string endpoint;
uint32_t device;
std::string name;
std::string description;
};
static const char * ggml_backend_rpc_device_get_name(ggml_backend_dev_t dev) {
ggml_backend_rpc_device_context * ctx = (ggml_backend_rpc_device_context *)dev->context;
return ctx->name.c_str();
}
static const char * ggml_backend_rpc_device_get_description(ggml_backend_dev_t dev) {
ggml_backend_rpc_device_context * ctx = (ggml_backend_rpc_device_context *)dev->context;
return ctx->description.c_str();
}
static void ggml_backend_rpc_device_get_memory(ggml_backend_dev_t dev, size_t * free, size_t * total) {
ggml_backend_rpc_device_context * ctx = (ggml_backend_rpc_device_context *)dev->context;
ggml_backend_rpc_get_device_memory(ctx->endpoint.c_str(), ctx->device, free, total);
}
static enum ggml_backend_dev_type ggml_backend_rpc_device_get_type(ggml_backend_dev_t dev) {
// TODO: obtain value from the server
return GGML_BACKEND_DEVICE_TYPE_GPU;
GGML_UNUSED(dev);
}
static void ggml_backend_rpc_device_get_props(ggml_backend_dev_t dev, struct ggml_backend_dev_props * props) {
props->name = ggml_backend_rpc_device_get_name(dev);
props->description = ggml_backend_rpc_device_get_description(dev);
props->type = ggml_backend_rpc_device_get_type(dev);
ggml_backend_rpc_device_get_memory(dev, &props->memory_free, &props->memory_total);
props->caps = {
/* .async = */ false,
/* .host_buffer = */ false,
/* .buffer_from_host_ptr = */ false,
/* .events = */ false,
};
}
static ggml_backend_t ggml_backend_rpc_device_init(ggml_backend_dev_t dev, const char * params) {
ggml_backend_rpc_device_context * ctx = (ggml_backend_rpc_device_context *)dev->context;
return ggml_backend_rpc_init(ctx->endpoint.c_str(), ctx->device);
GGML_UNUSED(params);
}
static ggml_backend_buffer_type_t ggml_backend_rpc_device_get_buffer_type(ggml_backend_dev_t dev) {
ggml_backend_rpc_device_context * ctx = (ggml_backend_rpc_device_context *)dev->context;
return ggml_backend_rpc_buffer_type(ctx->endpoint.c_str(), ctx->device);
GGML_UNUSED(dev);
}
static bool ggml_backend_rpc_device_supports_op(ggml_backend_dev_t dev, const struct ggml_tensor * op) {
GGML_UNUSED(dev);
GGML_UNUSED(op);
//TODO: call the remote backend and cache the results
return true;
}
static bool ggml_backend_rpc_device_supports_buft(ggml_backend_dev_t dev, ggml_backend_buffer_type_t buft) {
if (!buft || buft->iface.get_name != ggml_backend_rpc_buffer_type_name) {
return false;
}
ggml_backend_rpc_buffer_type_context * buft_ctx = (ggml_backend_rpc_buffer_type_context *)buft->context;
ggml_backend_rpc_device_context * dev_ctx = (ggml_backend_rpc_device_context *)dev->context;
return buft_ctx->endpoint == dev_ctx->endpoint && buft_ctx->device == dev_ctx->device;
}
static const struct ggml_backend_device_i ggml_backend_rpc_device_i = {
/* .get_name = */ ggml_backend_rpc_device_get_name,
/* .get_description = */ ggml_backend_rpc_device_get_description,
/* .get_memory = */ ggml_backend_rpc_device_get_memory,
/* .get_type = */ ggml_backend_rpc_device_get_type,
/* .get_props = */ ggml_backend_rpc_device_get_props,
/* .init_backend = */ ggml_backend_rpc_device_init,
/* .get_buffer_type = */ ggml_backend_rpc_device_get_buffer_type,
/* .get_host_buffer_type = */ NULL,
/* .buffer_from_host_ptr = */ NULL,
/* .supports_op = */ ggml_backend_rpc_device_supports_op,
/* .supports_buft = */ ggml_backend_rpc_device_supports_buft,
/* .offload_op = */ NULL,
/* .event_new = */ NULL,
/* .event_free = */ NULL,
/* .event_synchronize = */ NULL,
};
// backend reg interface
struct ggml_backend_rpc_reg_context {
std::string name;
std::vector<ggml_backend_dev_t> devices;
};
static const char * ggml_backend_rpc_reg_get_name(ggml_backend_reg_t reg) {
ggml_backend_rpc_reg_context * ctx = (ggml_backend_rpc_reg_context *)reg->context;
return ctx ? ctx->name.c_str() : "RPC";
}
static size_t ggml_backend_rpc_reg_get_device_count(ggml_backend_reg_t reg) {
ggml_backend_rpc_reg_context * ctx = (ggml_backend_rpc_reg_context *)reg->context;
return ctx ? ctx->devices.size() : 0;
}
static ggml_backend_dev_t ggml_backend_rpc_reg_get_device(ggml_backend_reg_t reg, size_t index) {
ggml_backend_rpc_reg_context * ctx = (ggml_backend_rpc_reg_context *)reg->context;
if (ctx == nullptr) {
GGML_ABORT("The RPC backend does not have enumerated devices - use ggml_backend_rpc_add_server instead");
} else {
GGML_ASSERT(index < ctx->devices.size());
return ctx->devices[index];
}
}
static void * ggml_backend_rpc_get_proc_address(ggml_backend_reg_t reg, const char * name) {
if (std::strcmp(name, "ggml_backend_rpc_add_server") == 0) {
return (void *)ggml_backend_rpc_add_server;
}
if (std::strcmp(name, "ggml_backend_rpc_start_server") == 0) {
return (void *)ggml_backend_rpc_start_server;
}
return NULL;
GGML_UNUSED(reg);
}
static const struct ggml_backend_reg_i ggml_backend_rpc_reg_i = {
/* .get_name = */ ggml_backend_rpc_reg_get_name,
/* .get_device_count = */ ggml_backend_rpc_reg_get_device_count,
/* .get_device = */ ggml_backend_rpc_reg_get_device,
/* .get_proc_address = */ ggml_backend_rpc_get_proc_address,
};
ggml_backend_reg_t ggml_backend_rpc_reg(void) {
static struct ggml_backend_reg ggml_backend_rpc_reg = {
/* .api_version = */ GGML_BACKEND_API_VERSION,
/* .iface = */ ggml_backend_rpc_reg_i,
/* .context = */ NULL,
};
return &ggml_backend_rpc_reg;
}
static uint32_t ggml_backend_rpc_get_device_count(const char * endpoint) {
auto sock = get_socket(endpoint);
if (sock == nullptr) {
GGML_LOG_ERROR("Failed to connect to %s\n", endpoint);
return 0;
}
rpc_msg_device_count_rsp response;
bool status = send_rpc_cmd(sock, RPC_CMD_DEVICE_COUNT, nullptr, 0, &response, sizeof(response));
RPC_STATUS_ASSERT(status);
return response.device_count;
}
static const ggml_backend_reg_i ggml_backend_rpc_reg_interface = {
/* .get_name = */ ggml_backend_rpc_reg_get_name,
/* .get_device_count = */ ggml_backend_rpc_reg_get_device_count,
/* .get_device = */ ggml_backend_rpc_reg_get_device,
/* .get_proc_address = */ ggml_backend_rpc_get_proc_address,
};
ggml_backend_reg_t ggml_backend_rpc_add_server(const char * endpoint) {
static std::unordered_map<std::string, ggml_backend_reg_t> reg_map;
static std::mutex mutex;
static uint32_t dev_id = 0;
std::lock_guard<std::mutex> lock(mutex);
if (reg_map.find(endpoint) != reg_map.end()) {
return reg_map[endpoint];
}
uint32_t dev_count = ggml_backend_rpc_get_device_count(endpoint);
if (dev_count == 0) {
return nullptr;
}
ggml_backend_rpc_reg_context * ctx = new ggml_backend_rpc_reg_context;
ctx->name = "RPC[" + std::string(endpoint) + "]";
for (uint32_t ind = 0; ind < dev_count; ind++) {
std::string dev_name = "RPC" + std::to_string(dev_id);
std::string dev_desc = std::string(endpoint);
ggml_backend_rpc_device_context * dev_ctx = new ggml_backend_rpc_device_context {
/* .endpoint = */ endpoint,
/* .device = */ ind,
/* .name = */ dev_name,
/* .description = */ dev_desc
};
ggml_backend_dev_t dev = new ggml_backend_device {
/* .iface = */ ggml_backend_rpc_device_i,
/* .reg = */ ggml_backend_rpc_reg(),
/* .context = */ dev_ctx,
};
ctx->devices.push_back(dev);
dev_id++;
}
ggml_backend_reg_t reg = new ggml_backend_reg {
/* .api_version = */ GGML_BACKEND_API_VERSION,
/* .iface = */ ggml_backend_rpc_reg_interface,
/* .context = */ ctx
};
reg_map[endpoint] = reg;
return reg;
}
GGML_BACKEND_DL_IMPL(ggml_backend_rpc_reg)ggml 框架的 RPC（远程过程调用）后端实现 ，核心作用是让本地程序通过网络调用远程服务器的计算资源（GPU/CPU）执行张量计算，是分布式 / 远程运行大模型（如 llama.cpp）的关键模块。
我会用通俗语言 + 分层拆解解释代码结构、核心逻辑、执行流程。
一、核心定位
一句话总结：本地程序 ←TCP 网络→ 远程服务器本地把「张量、计算图」发给服务器，服务器用硬件计算后把结果返回，全程对上层透明。
适用场景：
- 本地无 GPU，远程调用服务器 GPU
- 分布式多机协同计算
- 模型推理 / 训练的资源远程调度
二、整体架构（客户端 + 服务端）
代码严格分为两大模块：
- RPC 客户端：本地程序调用的接口
- RPC 服务端 ：远程服务器运行的计算节点通过自定义 TCP 协议通信，所有数据序列化后传输。
plaintext
┌─────────────────┐ TCP 网络 ┌─────────────────┐
│ 本地客户端 │ ◄─────────────────────► │ 远程服务端 │
│ ggml_backend_rpc │ │ rpc_server │
└─────────────────┘ └─────────────────┘三、关键基础组件（全代码通用）
1. 跨平台网络封装
- Windows：
Winsock2 - Linux/macOS：
socket、unistd统一封装为socket_t，自动管理套接字创建 / 销毁 / 发送 / 接收。
2. 数据序列化：rpc_tensor
ggml 原生张量 ggml_tensor 不能直接传网络，必须转为紧凑二进制结构 rpc_tensor：
- 包含张量 ID、形状、数据指针、运算类型、源张量等所有信息
- 内存严格对齐（
#pragma pack(pop, 1)），保证跨平台解析一致
3. RPC 命令枚举：rpc_cmd
定义了所有支持的远程操作（共 16 种）：
- 内存分配 / 释放
- 张量读写
- 计算图执行
- 设备信息查询
- 版本校验
核心命令：
RPC_CMD_HELLO：握手校验版本RPC_CMD_ALLOC_BUFFER：远程分配内存RPC_CMD_GRAPH_COMPUTE：执行计算图RPC_CMD_SET_TENSOR：上传张量数据
4. 通信协议格式
plaintext
请求： 1字节命令 + 8字节数据长度 + 数据体
响应： 8字节数据长度 + 数据体所有传输分包发送（最大 1GB），保证大数据不卡顿。
5. 性能优化
- 哈希缓存：大张量（>10MB）先传哈希，服务器有相同数据就不用重传
- 图缓存：重复计算图只序列化一次，直接复用
- TCP_NODELAY：禁用 Nagle 算法，降低延迟
四、客户端执行逻辑（本地程序用）
客户端是标准 ggml 后端插件，上层代码使用方式和本地 CUDA/CPU 后端完全一致。
1. 初始化流程
plaintext
1. 解析远程地址（host:port）
2. 建立TCP连接
3. 发送HELLO命令，校验RPC协议版本
4. 查询远程设备数量、内存、对齐参数
5. 注册为ggml后端，供上层调用2. 核心接口实现
客户端实现了 ggml 后端的所有标准函数：
ggml_backend_rpc_init：创建远程后端ggml_backend_rpc_buffer_type_alloc_buffer：远程申请内存ggml_backend_rpc_buffer_set_tensor：上传张量数据ggml_backend_rpc_graph_compute：发送计算图执行ggml_backend_rpc_buffer_get_tensor：下载结果数据
3. 计算流程（以模型推理为例）
plaintext
本地：创建张量 → 上传数据到远程 → 发送计算图 → 下载结果
远程：接收张量 → 分配内存 → 执行计算 → 返回结果五、服务端执行逻辑（远程服务器用）
服务端是监听 TCP 请求的守护进程，管理本地硬件资源，执行远程指令。
1. 启动流程
plaintext
1. 绑定监听地址
2. 初始化本地硬件后端（CUDA/CPU）
3. 循环等待客户端连接
4. 每个客户端创建独立rpc_server实例2. 命令处理循环
服务端核心是无限循环处理客户端命令：
plaintext
while (true) {
接收1字节命令 → 解析命令类型 → 执行对应操作 → 返回结果
}3. 核心功能实现
- 内存管理：创建 / 销毁远程内存缓冲区
- 张量反序列化 ：把
rpc_tensor还原为ggml_tensor - 计算图重建：递归解析张量依赖，还原完整计算图
- 硬件调度：调用本地后端（如 CUDA）执行计算
- 缓存管理：大张量哈希缓存，重复数据免传输
六、完整通信示例（执行一次计算）
- 客户端：连接服务器，HELLO 握手
- 客户端 ：发送
ALLOC_BUFFER，远程申请内存 - 客户端 ：发送
SET_TENSOR，上传模型 / 输入数据 - 客户端 ：发送
GRAPH_COMPUTE，序列化计算图并发送 - 服务端：反序列化计算图，调用 GPU 执行
- 服务端：计算完成，等待客户端读取
- 客户端 ：发送
GET_TENSOR，下载推理结果 - 客户端 ：发送
FREE_BUFFER，释放远程内存
七、关键技术点总结
- 透明化远程调用：上层代码无需修改，直接用远程资源
- 二进制序列化：高效传输张量 / 计算图
- 跨平台兼容：Windows/Linux/macOS 互通
- 性能优化：哈希缓存、图复用、低延迟 TCP
- 内存安全：严格校验指针边界，防止越界访问
八、代码分层结构图
plaintext
ggml-rpc.h
├── 公共定义
│ ├── rpc_tensor（序列化张量）
│ ├── rpc_cmd（命令枚举）
│ └── 通信协议结构体
├── 客户端实现
│ ├── 后端接口（ggml_backend_rpc_*）
│ ├── 内存缓冲区接口
│ └── 网络发送/接收封装
├── 服务端实现
│ ├── rpc_server类
│ ├── 命令处理函数
│ ├── 张量/图反序列化
│ └── 硬件资源管理
└── 设备注册接口
├── 远程设备发现
└── 后端插件加载人人皆为创造者，共创方能共成长
每个人都是使用者，也是创造者；是数字世界的消费者，更是价值的生产者与分享者。在智能时代的浪潮里，单打独斗的发展模式早已落幕，唯有开放连接、创意共创、利益共享，才能让个体价值汇聚成生态合力，让技术与创意双向奔赴，实现平台与伙伴的快速成长、共赢致远。
原创永久分成，共赴星辰大海
原创创意共创、永久收益分成，是东方仙盟始终坚守的核心理念。我们坚信，每一份原创智慧都值得被尊重与回馈，以永久分成锚定共创初心，让创意者长期享有价值红利，携手万千伙伴向着科技星辰大海笃定前行，拥抱硅基 生命与数字智能交融的未来，共筑跨越时代的数字文明共同体。
东方仙盟：拥抱知识开源，共筑数字新生态
在全球化与数字化浪潮中，东方仙盟始终秉持开放协作、知识共享的理念，积极拥抱开源技术与开放标准。我们相信，唯有打破技术壁垒、汇聚全球智慧，才能真正推动行业的可持续发展。
开源赋能中小商户：通过将前端异常检测、跨系统数据互联等核心能力开源化，东方仙盟为全球中小商户提供了低成本、高可靠的技术解决方案，让更多商家能够平等享受数字转型的红利。
共建行业标准：我们积极参与国际技术社区，与全球开发者、合作伙伴共同制定开放协议 与技术规范，推动跨境零售、文旅、餐饮等多业态的系统互联互通，构建更加公平、高效的数字生态。
知识普惠，共促发展：通过开源社区 、技术文档与培训体系，东方仙盟致力于将前沿技术转化为可落地的行业实践，赋能全球合作伙伴，共同培育创新人才，推动数字经济 的普惠式增长
阿雪技术观
在科技发展浪潮中，我们不妨积极投身技术共享。不满足于做受益者，更要主动担当贡献者 。无论是分享代码、撰写技术博客，还是参与开源项目 维护改进，每一个微小举动都可能蕴含推动技术进步的巨大能量。东方仙盟是汇聚力量的天地，我们携手在此探索硅基 生命，为科技进步添砖加瓦。
Hey folks, in this wild tech - driven world, why not dive headfirst into the whole tech - sharing scene? Don't just be the one reaping all the benefits; step up and be a contributor too. Whether you're tossing out your code snippets , hammering out some tech blogs, or getting your hands dirty with maintaining and sprucing up open - source projects, every little thing you do might just end up being a massive force that pushes tech forward. And guess what? The Eastern FairyAlliance is this awesome place where we all come together. We're gonna team up and explore the whole silicon - based life thing, and in the process, we'll be fueling the growth of technology
