前言

摘要：HarmonyOS 6（API 23）引入的鸿蒙智能体框架（HMAF）将AI能力从应用层下沉至系统层，配合悬浮导航与沉浸光感特性，为AI智能体应用开发开辟了全新范式。本文将实战开发一款面向HarmonyOS PC的"灵犀智脑"应用，展示如何利用HMAF构建多智能体协作工作流，通过悬浮导航实现智能体状态切换，基于沉浸光感打造"意图即氛围"的交互体验，以及基于多窗口架构构建浮动智能体对话、工具面板和知识库窗口的协作编排体验。

一、前言：AI智能体时代的交互范式革新

2026年，AI Agent（智能体）已成为技术领域最火热的方向。HarmonyOS 6开发者Beta版引入了全新的鸿蒙智能体框架（Harmony Intelligent Agent Framework，HMAF），这一框架的核心在于将AI能力从应用层下沉至系统层，实现真正的"原生智能"。

传统AI助手往往采用固定的聊天界面和工具栏，用户需要主动输入指令、等待响应、再手动操作结果。而在HarmonyOS 6的PC大屏环境下，这种交互模式显得低效且缺乏智能感。HMAF配合**悬浮导航（Float Navigation）与沉浸光感（Immersive Light Effects）**特性，为AI智能体应用带来了"意图即氛围、状态即导航"的全新可能。

本文核心亮点：

  • 智能体状态光效：根据当前智能体运行状态（待机/思考/执行/完成/异常）动态切换环境光色与脉冲节奏
  • 悬浮智能体导航：底部悬浮页签替代传统工具栏，支持拖拽排序与透明度调节，智能体状态实时徽章提示
  • HMAF多智能体编排：基于Agent Framework Kit构建"调度器-执行器-验证器"三层智能体协作架构
  • 多窗口智能体协作：主对话窗口 + 浮动工具面板 + 浮动知识库 + 浮动日志追踪窗口的光效联动
  • 意图感知沉浸体验：通过Intents Kit实时理解用户意图，自动调整界面光效与导航形态

二、核心特性解析与技术选型

2.1 HMAF在智能体编排中的价值

HarmonyOS 6的HMAF采用三层架构设计：底层是统一的AI系统底座，中间层是意图理解和任务编排引擎，上层是开放的智能体交互协议。 在"灵犀智脑"中，这种架构能够：

  • 原生智能调度：智能体不再是应用的附属品，而是系统的基础能力，支持跨应用任务编排
  • 意图即服务：通过Intents Kit将用户自然语言意图转化为结构化任务，自动分发给合适的智能体
  • 分布式智能体协同：利用鸿蒙分布式软总线，实现PC主控+手机传感器+平板显示的多设备智能体协作
  • 端云协同推理：端侧MindSpore Lite处理隐私敏感任务，云端大模型处理复杂推理任务

2.2 沉浸光感在智能体交互中的创新应用

HarmonyOS 6的systemMaterialEffect通过模拟物理光照模型，为智能体状态反馈带来细腻的视觉表达。在AI智能体场景中，这种材质效果能够：

  • 增强智能体人格化：不同智能体拥有专属光效人格（调度器冷峻蓝、执行器活力橙、验证器严谨绿）
  • 状态直觉感知：思考时的呼吸蓝光、执行时的脉冲金光、异常时的警示红光，用户无需阅读文字即可感知智能体状态
  • 提升沉浸专注度：动态环境光随任务复杂度变化，简单任务柔和、复杂任务强烈，帮助用户保持专注

2.3 悬浮导航的智能体适配

与传统工具类应用不同，AI智能体平台需要处理：

  • 高频智能体切换：用户常在多个智能体间快速跳转查看状态
  • 状态信息密度平衡：既要保证导航可见，又不能遮挡对话内容
  • 实时状态徽章：智能体运行状态需要实时徽章提示（小红点、数字角标、脉冲光效）

HarmonyOS 6的悬浮页签支持**强(85%)、平衡(70%)、弱(55%)**三档透明度自定义，结合PC端的自由窗口能力，可以实现"需要时出现，专注时隐退"的智能导航体验。

三、项目实战："灵犀智脑"架构设计

3.1 应用场景与功能规划

面向HarmonyOS PC的AI智能体编排场景，核心功能包括：

功能模块 技术实现 沉浸光感/HMAF应用
主对话窗口 List + ChatBubble 智能体人格光效、思考呼吸灯
悬浮智能体导航 HdsTabs + systemMaterialEffect 玻璃拟态页签，状态徽章光效
智能体调度器 HMAF Agent Framework Kit 调度决策光效反馈
智能体执行器 HMAF + Function Calling 执行进度光效脉冲
智能体验证器 HMAF + 规则引擎 验证结果光效标记
浮动工具面板 子窗口 + HdsNavigation 工具主题色光效同步
浮动知识库窗口 子窗口 + Grid 知识热度光效
浮动日志窗口 子窗口 + List 日志级别颜色编码

3.2 技术架构图

复制代码
┌─────────────────────────────────────────────────────────────┐
│                    灵犀智脑 - 应用层                          │
├─────────────┬─────────────┬─────────────┬─────────────────────┤
│  调度器智能体  │  执行器智能体  │  验证器智能体  │    知识库管理器      │
│  (Scheduler)  │  (Executor)  │  (Validator) │   (KnowledgeBase)   │
├─────────────┴─────────────┴─────────────┴─────────────────────┤
│                  HMAF - 智能体框架层                          │
│         Agent Framework Kit + Intents Kit + NLU Kit          │
├─────────────────────────────────────────────────────────────┤
│                  AI系统底座 - 能力层                          │
│    MindSpore Lite(端侧) │ 鸿蒙大模型4.0(云端) │ 分布式软总线    │
├─────────────────────────────────────────────────────────────┤
│                  ArkUI - 表现层                              │
│    悬浮导航 │ 沉浸光感 │ 多窗口管理 │ 安全区扩展 │ 动画系统    │
└─────────────────────────────────────────────────────────────┘

四、环境配置与模块依赖

4.1 模块依赖配置

在oh-package.json5中添加HMAF及相关Kit依赖：

json 复制代码
{
  "name": "lingxi_brain",
  "version": "1.0.0",
  "description": "AI Agent Workflow Orchestration Platform",
  "dependencies": {
    "@ohos/hmaframework": "^6.0.0",
    "@ohos/intentskit": "^6.0.0",
    "@ohos/nlukit": "^6.0.0",
    "@ohos/mindsporelite": "^6.0.0",
    "@ohos/aiengine": "^6.0.0",
    "@ohos/hds": "^6.0.0"
  }
}

4.2 权限声明（module.json5）

json 复制代码
{
  "module": {
    "name": "entry",
    "type": "entry",
    "description": "$string:module_desc",
    "mainElement": "EntryAbility",
    "deviceTypes": ["phone", "tablet", "2in1"],
    "pages": "$profile:main_pages",
    "abilities": [
      {
        "name": "EntryAbility",
        "srcEntry": "./ets/entryability/EntryAbility.ets",
        "description": "$string:EntryAbility_desc",
        "icon": "$media:layered_image",
        "label": "$string:EntryAbility_label",
        "startWindowIcon": "$media:startIcon",
        "startWindowBackground": "$color:start_window_background",
        "exported": true,
        "skills": [
          {
            "entities": ["entity.system.home"],
            "actions": ["action.system.home"]
          }
        ]
      }
    ],
    "requestPermissions": [
      {
        "name": "ohos.permission.INTERNET",
        "reason": "$string:internet_permission"
      },
      {
        "name": "ohos.permission.SYSTEM_FLOAT_WINDOW",
        "reason": "$string:float_window_permission",
        "usedScene": {
          "abilities": ["EntryAbility"],
          "when": "always"
        }
      },
      {
        "name": "ohos.permission.DISTRIBUTED_DATASYNC",
        "reason": "$string:distributed_permission"
      },
      {
        "name": "ohos.permission.AI_ENGINE_ACCESS",
        "reason": "$string:ai_engine_permission"
      },
      {
        "name": "ohos.permission.MICROPHONE",
        "reason": "$string:microphone_permission"
      }
    ]
  }
}

五、核心组件实战

5.1 窗口沉浸配置（EntryAbility.ets）

typescript 复制代码
// entry/src/main/ets/entryability/EntryAbility.ets
import { AbilityConstant, UIAbility, Want } from '@kit.AbilityKit';
import { window } from '@kit.ArkUI';
import { BusinessError } from '@kit.BasicServicesKit';

export default class EntryAbility extends UIAbility {
  private windowStage: window.WindowStage | null = null;

  onWindowStageCreate(windowStage: window.WindowStage): void {
    this.windowStage = windowStage;
    windowStage.loadContent('pages/Index', (err) => {
      if (err.code) {
        console.error('Failed to load content:', JSON.stringify(err));
        return;
      }
      console.info('Succeeded in loading content.');
      this.setupImmersiveWindow(windowStage);
    });
  }

  private async setupImmersiveWindow(windowStage: window.WindowStage): Promise<void> {
    try {
      const mainWindow = windowStage.getMainWindowSync();
      await mainWindow.setWindowLayoutFullScreen(true);
      await mainWindow.setWindowBackgroundColor('#00000000');
      await mainWindow.setWindowSystemBarProperties({
        statusBarColor: '#00000000',
        navigationBarColor: '#00000000',
        statusBarContentColor: '#FFFFFF',
        navigationBarContentColor: '#FFFFFF'
      });
      await mainWindow.setWindowAvoidAreaOption({
        type: window.AvoidAreaType.TYPE_SYSTEM,
        enabled: true
      });
      console.info('Immersive window setup completed');
    } catch (error) {
      console.error('Failed to setup immersive window:', (error as BusinessError).message);
    }
  }

  onWindowStageDestroy(): void {
    this.windowStage = null;
  }
}

代码亮点 ：通过setWindowLayoutFullScreen(true)实现内容延伸至非安全区，配合setWindowAvoidAreaOption启用HarmonyOS 6新增的安全区避让机制，确保悬浮导航不会遮挡智能体对话内容。

5.2 智能体状态光效系统（AgentLightEffect.ets）

代码亮点 ：这是本应用的核心创新组件。它将HMAF智能体运行状态映射为动态光效------待机时柔和呼吸、思考时快速脉冲、执行时进度流光、完成时确认闪光、异常时警示闪烁。每个智能体拥有专属人格色彩（调度器冷峻蓝、执行器活力橙、验证器严谨绿），通过AppStorage全局状态实现跨组件光效同步。

typescript 复制代码
// entry/src/main/ets/components/AgentLightEffect.ets
import { hmaf } from '@kit.HMAFramework';

// 智能体状态枚举
export enum AgentState {
  IDLE = 'idle',           // 待机
  THINKING = 'thinking',   // 思考中
  EXECUTING = 'executing', // 执行中
  COMPLETED = 'completed', // 已完成
  ERROR = 'error'          // 异常
}

// 智能体人格色彩
export enum AgentPersonality {
  SCHEDULER = { color: '#4A90D9', name: '调度器', icon: $r('app.media.ic_scheduler') },
  EXECUTOR = { color: '#F5A623', name: '执行器', icon: $r('app.media.ic_executor') },
  VALIDATOR = { color: '#2ECC71', name: '验证器', icon: $r('app.media.ic_validator') }
}

// 光效配置
interface LightEffectConfig {
  baseColor: string;
  pulseSpeed: number;      // 脉冲周期(ms)
  pulseIntensity: number;  // 脉冲强度(0-1)
  glowRadius: number;      // 光晕半径
  particleCount: number;   // 粒子数量
}

@Component
export struct AgentLightEffect {
  @State agentState: AgentState = AgentState.IDLE;
  @State agentType: AgentPersonality = AgentPersonality.SCHEDULER;
  @State lightIntensity: number = 0.4;
  @State pulsePhase: number = 0;
  @State particlePositions: Array<{x: number, y: number, size: number, opacity: number}> = [];

  private pulseTimer: number = -1;
  private particleTimer: number = -1;

  aboutToAppear(): void {
    this.startPulseAnimation();
    this.startParticleAnimation();
    // 监听全局智能体状态变化
    AppStorage.setOrCreate('agent_state_change', (state: AgentState, type: AgentPersonality) => {
      this.agentState = state;
      this.agentType = type;
      this.updateLightEffect();
    });
  }

  aboutToDisappear(): void {
    clearInterval(this.pulseTimer);
    clearInterval(this.particleTimer);
  }

  private startPulseAnimation(): void {
    this.pulseTimer = setInterval(() => {
      this.pulsePhase = (this.pulsePhase + 0.05) % (Math.PI * 2);
      this.lightIntensity = this.calculatePulseIntensity();
    }, 50);
  }

  private calculatePulseIntensity(): number {
    const baseIntensity = this.getStateConfig().pulseIntensity;
    const variation = Math.sin(this.pulsePhase) * 0.3;
    return Math.max(0.1, Math.min(1.0, baseIntensity + variation));
  }

  private startParticleAnimation(): void {
    this.particleTimer = setInterval(() => {
      if (this.agentState === AgentState.EXECUTING) {
        this.updateParticles();
      }
    }, 100);
  }

  private updateParticles(): void {
    const newParticles: Array<{x: number, y: number, size: number, opacity: number}> = [];
    for (let i = 0; i < this.getStateConfig().particleCount; i++) {
      newParticles.push({
        x: Math.random() * 100,
        y: Math.random() * 100,
        size: Math.random() * 4 + 2,
        opacity: Math.random() * this.lightIntensity
      });
    }
    this.particlePositions = newParticles;
  }

  private getStateConfig(): LightEffectConfig {
    const configs: Record<<AgentState, LightEffectConfig> = {
      [AgentState.IDLE]: {
        baseColor: this.agentType.color,
        pulseSpeed: 4000,
        pulseIntensity: 0.4,
        glowRadius: 80,
        particleCount: 0
      },
      [AgentState.THINKING]: {
        baseColor: this.agentType.color,
        pulseSpeed: 1500,
        pulseIntensity: 0.7,
        glowRadius: 120,
        particleCount: 5
      },
      [AgentState.EXECUTING]: {
        baseColor: this.agentType.color,
        pulseSpeed: 800,
        pulseIntensity: 0.9,
        glowRadius: 150,
        particleCount: 15
      },
      [AgentState.COMPLETED]: {
        baseColor: '#2ECC71',
        pulseSpeed: 2000,
        pulseIntensity: 0.6,
        glowRadius: 100,
        particleCount: 8
      },
      [AgentState.ERROR]: {
        baseColor: '#FF4444',
        pulseSpeed: 500,
        pulseIntensity: 1.0,
        glowRadius: 120,
        particleCount: 0
      }
    };
    return configs[this.agentState] || configs[AgentState.IDLE];
  }

  private updateLightEffect(): void {
    const config = this.getStateConfig();
    AppStorage.setOrCreate('current_agent_color', config.baseColor);
    AppStorage.setOrCreate('current_agent_pulse', config.pulseSpeed);
    AppStorage.setOrCreate('current_agent_intensity', config.pulseIntensity);
  }

  build() {
    Stack() {
      // 主光晕层
      Column()
        .width(400)
        .height(400)
        .backgroundColor(this.getStateConfig().baseColor)
        .blur(this.getStateConfig().glowRadius)
        .opacity(this.lightIntensity)
        .position({ x: '50%', y: '30%' })
        .anchor('50%')
        .animation({
          duration: this.getStateConfig().pulseSpeed,
          curve: Curve.EaseInOut,
          iterations: -1,
          playMode: PlayMode.Alternate
        })

      // 粒子层（执行状态时显示）
      if (this.agentState === AgentState.EXECUTING) {
        ForEach(this.particlePositions, (particle: {x: number, y: number, size: number, opacity: number}, index: number) => {
          Column()
            .width(particle.size)
            .height(particle.size)
            .backgroundColor(this.getStateConfig().baseColor)
            .borderRadius(particle.size / 2)
            .opacity(particle.opacity)
            .position({
              x: `${particle.x}%`,
              y: `${particle.y}%`
            })
            .animation({
              duration: 1000,
              curve: Curve.Linear,
              iterations: -1
            })
        })
      }

      // 状态指示器环
      Column()
        .width(200)
        .height(200)
        .backgroundColor('transparent')
        .border({
          width: 3,
          color: this.getStateConfig().baseColor,
          style: BorderStyle.Solid
        })
        .borderRadius(100)
        .opacity(this.lightIntensity * 0.5)
        .animation({
          duration: this.getStateConfig().pulseSpeed,
          curve: Curve.EaseInOut,
          iterations: -1,
          playMode: PlayMode.Alternate
        })
    }
    .width('100%')
    .height('100%')
  }
}

5.3 HMAF智能体调度器（AgentScheduler.ets）

代码亮点：基于HMAF Agent Framework Kit构建核心调度逻辑，实现"意图理解→任务分解→智能体分配→结果验证"的完整工作流。调度器通过Intents Kit解析用户自然语言意图，自动创建执行器和验证器智能体实例，并实时监控各智能体状态。

typescript 复制代码
// entry/src/main/ets/services/AgentScheduler.ets
import { hmaf } from '@kit.HMAFramework';
import { intents } from '@kit.IntentsKit';
import { nlu } from '@kit.NLUKit';

// 任务定义
interface AgentTask {
  id: string;
  intent: string;
  parameters: Record<string, string>;
  assignedAgent: string;
  priority: number;
  deadline: number;
}

// 智能体实例
interface AgentInstance {
  id: string;
  type: 'scheduler' | 'executor' | 'validator';
  status: 'idle' | 'busy' | 'error';
  currentTask: AgentTask | null;
  capability: string[];
}

export class AgentScheduler {
  private static instance: AgentScheduler;
  private agents: Map<string, AgentInstance> = new Map();
  private taskQueue: AgentTask[] = [];
  private hmafSession: hmaf.AgentSession | null = null;
  private intentEngine: intents.IntentEngine | null = null;

  private constructor() {}

  static getInstance(): AgentScheduler {
    if (!AgentScheduler.instance) {
      AgentScheduler.instance = new AgentScheduler();
    }
    return AgentScheduler.instance;
  }

  async initialize(): Promise<void> {
    try {
      // 初始化HMAF会话
      this.hmafSession = await hmaf.createAgentSession({
        mode: hmaf.AgentMode.MULTI_AGENT,
        maxConcurrentAgents: 5,
        enableDistributed: true
      });

      // 初始化意图引擎
      this.intentEngine = await intents.createIntentEngine({
        supportedDomains: ['productivity', 'coding', 'research', 'analysis'],
        language: 'zh-CN'
      });

      // 注册默认智能体
      await this.registerDefaultAgents();

      console.info('AgentScheduler initialized successfully');
    } catch (error) {
      console.error('Failed to initialize AgentScheduler:', error);
      throw error;
    }
  }

  private async registerDefaultAgents(): Promise<void> {
    // 注册调度器自身
    this.agents.set('scheduler-1', {
      id: 'scheduler-1',
      type: 'scheduler',
      status: 'idle',
      currentTask: null,
      capability: ['task_decomposition', 'agent_coordination', 'conflict_resolution']
    });

    // 注册执行器智能体
    this.agents.set('executor-1', {
      id: 'executor-1',
      type: 'executor',
      status: 'idle',
      currentTask: null,
      capability: ['code_generation', 'data_analysis', 'document_processing', 'web_search']
    });

    this.agents.set('executor-2', {
      id: 'executor-2',
      type: 'executor',
      status: 'idle',
      currentTask: null,
      capability: ['image_generation', 'video_editing', 'audio_processing']
    });

    // 注册验证器智能体
    this.agents.set('validator-1', {
      id: 'validator-1',
      type: 'validator',
      status: 'idle',
      currentTask: null,
      capability: ['code_review', 'fact_checking', 'quality_assurance', 'security_audit']
    });
  }

  // 处理用户意图
  async processUserIntent(userInput: string): Promise<string> {
    try {
      // 更新调度器状态为思考中
      this.updateAgentState('scheduler-1', 'thinking');

      // 解析用户意图
      const parsedIntent = await this.intentEngine?.parseIntent(userInput);
      if (!parsedIntent) {
        throw new Error('Failed to parse user intent');
      }

      // 任务分解
      const subTasks = await this.decomposeTask(parsedIntent);

      // 分配任务给执行器
      const executionResults = await this.dispatchTasks(subTasks);

      // 验证结果
      const validatedResults = await this.validateResults(executionResults);

      // 更新调度器状态为完成
      this.updateAgentState('scheduler-1', 'idle');

      return this.formatResponse(validatedResults);
    } catch (error) {
      this.updateAgentState('scheduler-1', 'error');
      console.error('Error processing user intent:', error);
      return `执行异常：${error.message}`;
    }
  }

  private async decomposeTask(intent: intents.ParsedIntent): Promise<<AgentTask[]> {
    const tasks: AgentTask[] = [];
    const taskId = `task-${Date.now()}`;

    // 根据意图类型分解任务
    switch (intent.domain) {
      case 'coding':
        tasks.push({
          id: `${taskId}-1`,
          intent: 'code_analysis',
          parameters: { code: intent.parameters.code || '' },
          assignedAgent: 'executor-1',
          priority: 1,
          deadline: Date.now() + 30000
        });
        tasks.push({
          id: `${taskId}-2`,
          intent: 'code_generation',
          parameters: { requirements: intent.parameters.requirements || '' },
          assignedAgent: 'executor-1',
          priority: 2,
          deadline: Date.now() + 60000
        });
        tasks.push({
          id: `${taskId}-3`,
          intent: 'code_review',
          parameters: { generatedCode: '' },
          assignedAgent: 'validator-1',
          priority: 3,
          deadline: Date.now() + 90000
        });
        break;

      case 'research':
        tasks.push({
          id: `${taskId}-1`,
          intent: 'web_search',
          parameters: { query: intent.parameters.query || '' },
          assignedAgent: 'executor-1',
          priority: 1,
          deadline: Date.now() + 20000
        });
        tasks.push({
          id: `${taskId}-2`,
          intent: 'data_analysis',
          parameters: { searchResults: '' },
          assignedAgent: 'executor-1',
          priority: 2,
          deadline: Date.now() + 40000
        });
        tasks.push({
          id: `${taskId}-3`,
          intent: 'fact_checking',
          parameters: { analysisResult: '' },
          assignedAgent: 'validator-1',
          priority: 3,
          deadline: Date.now() + 60000
        });
        break;

      default:
        tasks.push({
          id: `${taskId}-1`,
          intent: intent.action,
          parameters: intent.parameters,
          assignedAgent: 'executor-1',
          priority: 1,
          deadline: Date.now() + 30000
        });
    }

    return tasks;
  }

  private async dispatchTasks(tasks: AgentTask[]): Promise<<Record<string, unknown>[]> {
    const results: Record<string, unknown>[] = [];

    for (const task of tasks) {
      const agent = this.findAvailableAgent(task.assignedAgent);
      if (!agent) {
        console.warn(`No available agent for task ${task.id}`);
        continue;
      }

      // 更新执行器状态
      this.updateAgentState(agent.id, 'busy');

      // 通过HMAF发送任务
      const result = await this.hmafSession?.sendTask({
        targetAgent: agent.id,
        taskType: task.intent,
        parameters: task.parameters,
        timeout: task.deadline - Date.now()
      });

      results.push({
        taskId: task.id,
        agentId: agent.id,
        result: result,
        timestamp: Date.now()
      });

      // 更新执行器状态
      this.updateAgentState(agent.id, 'idle');
    }

    return results;
  }

  private async validateResults(results: Record<string, unknown>[]): Promise<<Record<string, unknown>[]> {
    const validator = this.agents.get('validator-1');
    if (!validator || validator.status === 'busy') {
      return results; // 无可用验证器，直接返回
    }

    this.updateAgentState('validator-1', 'busy');

    const validatedResults: Record<string, unknown>[] = [];
    for (const result of results) {
      const validation = await this.hmafSession?.sendTask({
        targetAgent: 'validator-1',
        taskType: 'quality_assurance',
        parameters: { input: JSON.stringify(result) },
        timeout: 15000
      });

      validatedResults.push({
        ...result,
        validation: validation,
        isValid: validation?.score > 0.8
      });
    }

    this.updateAgentState('validator-1', 'idle');
    return validatedResults;
  }

  private findAvailableAgent(type: string): AgentInstance | null {
    for (const [id, agent] of this.agents.entries()) {
      if (agent.type === type && agent.status === 'idle') {
        return agent;
      }
    }
    return null;
  }

  private updateAgentState(agentId: string, state: string): void {
    const agent = this.agents.get(agentId);
    if (agent) {
      agent.status = state as 'idle' | 'busy' | 'error';

      // 触发全局状态更新，驱动光效变化
      AppStorage.setOrCreate('agent_state_update', {
        agentId: agentId,
        state: state,
        timestamp: Date.now()
      });
    }
  }

  private formatResponse(results: Record<string, unknown>[]): string {
    let response = '## 智能体协作结果\n\n';

    for (const result of results) {
      const taskId = result.taskId as string;
      const agentId = result.agentId as string;
      const isValid = result.isValid as boolean;

      response += `### ${taskId}\n`;
      response += `- **执行智能体**: ${agentId}\n`;
      response += `- **验证结果**: ${isValid ? '✅ 通过' : '⚠️ 需复核'}\n`;
      response += `- **输出**: ${JSON.stringify(result.result, null, 2)}\n\n`;
    }

    return response;
  }

  getAgentStatus(): Array<{id: string, type: string, status: string, task: string | null}> {
    return Array.from(this.agents.values()).map(agent => ({
      id: agent.id,
      type: agent.type,
      status: agent.status,
      task: agent.currentTask?.intent || null
    }));
  }
}

5.4 悬浮智能体导航（AgentFloatNavigation.ets）

代码亮点：底部悬浮导航栏不仅承载页面切换功能，更重要的是实时显示各智能体运行状态。每个导航项配备状态徽章------待机时柔和光点、思考时呼吸脉冲、执行时旋转进度、异常时警示闪烁。支持长按展开透明度调节面板。

typescript 复制代码
// entry/src/main/ets/components/AgentFloatNavigation.ets
import { window } from '@kit.ArkUI';
import { AgentState, AgentPersonality } from './AgentLightEffect';

// 导航项配置
interface AgentNavItem {
  id: string;
  icon: Resource;
  label: string;
  page: string;
  agentType?: AgentPersonality;
}

@Component
export struct AgentFloatNavigation {
  @State currentIndex: number = 0;
  @State navTransparency: number = 0.70;
  @State isExpanded: boolean = false;
  @State bottomAvoidHeight: number = 0;
  @State agentStates: Map<string, AgentState> = new Map([
    ['scheduler-1', AgentState.IDLE],
    ['executor-1', AgentState.IDLE],
    ['executor-2', AgentState.IDLE],
    ['validator-1', AgentState.IDLE]
  ]);

  private navItems: AgentNavItem[] = [
    { id: 'chat', icon: $r('app.media.ic_chat'), label: '对话', page: 'ChatPage' },
    { id: 'workflow', icon: $r('app.media.ic_workflow'), label: '工作流', page: 'WorkflowPage', agentType: AgentPersonality.SCHEDULER },
    { id: 'tools', icon: $r('app.media.ic_tools'), label: '工具', page: 'ToolsPage', agentType: AgentPersonality.EXECUTOR },
    { id: 'knowledge', icon: $r('app.media.ic_knowledge'), label: '知识库', page: 'KnowledgePage', agentType: AgentPersonality.VALIDATOR },
    { id: 'settings', icon: $r('app.media.ic_settings'), label: '设置', page: 'SettingsPage' }
  ];

  aboutToAppear(): void {
    this.getBottomAvoidArea();
    // 监听智能体状态变化
    AppStorage.setOrCreate('agent_state_update', (update: {agentId: string, state: string}) => {
      this.agentStates.set(update.agentId, update.state as AgentState);
    });
  }

  private async getBottomAvoidArea(): Promise<void> {
    try {
      const mainWindow = await window.getLastWindow();
      const avoidArea = mainWindow.getWindowAvoidArea(window.AvoidAreaType.TYPE_NAVIGATION_INDICATOR);
      this.bottomAvoidHeight = avoidArea.bottomRect.height;
    } catch (error) {
      console.error('Failed to get avoid area:', error);
    }
  }

  private getAgentStateForNavItem(item: AgentNavItem): AgentState {
    if (!item.agentType) return AgentState.IDLE;

    const agentId = item.id === 'workflow' ? 'scheduler-1' :
                   item.id === 'tools' ? 'executor-1' :
                   item.id === 'knowledge' ? 'validator-1' : '';
    return this.agentStates.get(agentId) || AgentState.IDLE;
  }

  private getStateBadgeColor(state: AgentState): string {
    const colors: Record<<AgentState, string> = {
      [AgentState.IDLE]: '#888888',
      [AgentState.THINKING]: '#4A90D9',
      [AgentState.EXECUTING]: '#F5A623',
      [AgentState.COMPLETED]: '#2ECC71',
      [AgentState.ERROR]: '#FF4444'
    };
    return colors[state] || '#888888';
  }

  private getStateBadgeAnimation(state: AgentState): object {
    switch (state) {
      case AgentState.THINKING:
        return {
          duration: 1500,
          curve: Curve.EaseInOut,
          iterations: -1,
          playMode: PlayMode.Alternate
        };
      case AgentState.EXECUTING:
        return {
          duration: 1000,
          curve: Curve.Linear,
          iterations: -1
        };
      case AgentState.ERROR:
        return {
          duration: 500,
          curve: Curve.EaseInOut,
          iterations: -1,
          playMode: PlayMode.Alternate
        };
      default:
        return { duration: 0 };
    }
  }

  build() {
    Stack({ alignContent: Alignment.Bottom }) {
      // 内容层
      Column() {
        this.contentBuilder()
      }
      .padding({ bottom: this.bottomAvoidHeight + 80 })

      // 悬浮导航栏
      Column() {
        Stack() {
          // 玻璃拟态背景
          Column()
            .width('100%')
            .height('100%')
            .backgroundBlurStyle(BlurStyle.REGULAR)
            .opacity(this.navTransparency)
            .backdropFilter($r('sys.blur.20'))

          // 渐变光效层
          Column()
            .width('100%')
            .height('100%')
            .linearGradient({
              direction: GradientDirection.Top,
              colors: [
                ['rgba(255,255,255,0.15)', 0.0],
                ['rgba(255,255,255,0.05)', 1.0]
              ]
            })
        }
        .width('100%')
        .height('100%')
        .borderRadius(24)
        .shadow({
          radius: 20,
          color: 'rgba(0,0,0,0.2)',
          offsetX: 0,
          offsetY: -4
        })

        // 导航项
        Row() {
          ForEach(this.navItems, (item: AgentNavItem, index: number) => {
            Column() {
              Stack() {
                Image(item.icon)
                  .width(24)
                  .height(24)
                  .fillColor(this.currentIndex === index ? this.getStateBadgeColor(this.getAgentStateForNavItem(item)) : '#666666')

                // 智能体状态徽章
                if (item.agentType && this.getAgentStateForNavItem(item) !== AgentState.IDLE) {
                  Column()
                    .width(10)
                    .height(10)
                    .backgroundColor(this.getStateBadgeColor(this.getAgentStateForNavItem(item)))
                    .borderRadius(5)
                    .position({ x: 18, y: -4 })
                    .shadow({
                      radius: 6,
                      color: this.getStateBadgeColor(this.getAgentStateForNavItem(item)),
                      offsetX: 0,
                      offsetY: 0
                    })
                    .animation(this.getStateBadgeAnimation(this.getAgentStateForNavItem(item)))
                }
              }
              .width(40)
              .height(40)

              Text(item.label)
                .fontSize(11)
                .fontColor(this.currentIndex === index ? this.getStateBadgeColor(this.getAgentStateForNavItem(item)) : '#999999')
                .margin({ top: 4 })
            }
            .layoutWeight(1)
            .onClick(() => {
              this.currentIndex = index;
              this.triggerHapticFeedback();
            })
          })
        }
        .width('100%')
        .height(80)
        .padding({ left: 16, right: 16 })
        .justifyContent(FlexAlign.SpaceAround)

        // 透明度调节
        if (this.isExpanded) {
          Row() {
            Text('透明度')
              .fontSize(12)
              .fontColor('#666666')
              .margin({ right: 8 })

            Slider({
              value: this.navTransparency * 100,
              min: 55,
              max: 85,
              step: 15,
              style: SliderStyle.InSet
            })
              .width(120)
              .onChange((value: number) => {
                this.navTransparency = value / 100;
              })

            Text(`${Math.round(this.navTransparency * 100)}%`)
              .fontSize(12)
              .fontColor('#666666')
              .margin({ left: 8 })
          }
          .width('100%')
          .height(40)
          .justifyContent(FlexAlign.Center)
          .backgroundColor('rgba(255,255,255,0.5)')
          .borderRadius({ topLeft: 12, topRight: 12 })
        }
      }
      .width('92%')
      .height(this.isExpanded ? 120 : 80)
      .margin({ bottom: this.bottomAvoidHeight + 12, left: '4%', right: '4%' })
      .animation({
        duration: 300,
        curve: Curve.Spring,
        iterations: 1
      })
      .gesture(
        LongPressGesture({ duration: 500 })
          .onAction(() => {
            this.isExpanded = !this.isExpanded;
          })
      )
    }
    .width('100%')
    .height('100%')
  }

  @BuilderParam contentBuilder: () => void = this.defaultContentBuilder;

  @Builder
  defaultContentBuilder(): void {
    Column() {
      Text('内容区域')
        .fontSize(16)
        .fontColor('#999999')
    }
    .width('100%')
    .height('100%')
    .justifyContent(FlexAlign.Center)
  }

  private triggerHapticFeedback(): void {
    try {
      import('@kit.SensorServiceKit').then(sensor => {
        sensor.vibrator.startVibration({
          type: 'time',
          duration: 50
        }, { id: 0 });
      });
    } catch (error) {
      console.error('Haptic feedback failed:', error);
    }
  }
}

5.5 智能体对话页面（ChatPage.ets）

代码亮点：实现具有智能体人格光效的对话页面。用户输入意图后，调度器智能体自动分解任务、分配执行器、验证结果，整个过程通过光效实时反馈。对话气泡根据智能体类型显示对应色彩边框。

typescript 复制代码
// entry/src/main/ets/pages/ChatPage.ets
import { AgentScheduler } from '../services/AgentScheduler';
import { AgentPersonality, AgentState } from '../components/AgentLightEffect';
import { AgentFloatNavigation } from '../components/AgentFloatNavigation';

interface ChatMessage {
  id: string;
  role: 'user' | 'scheduler' | 'executor' | 'validator' | 'system';
  content: string;
  timestamp: number;
  agentType?: AgentPersonality;
  state?: AgentState;
}

@Entry
@Component
struct ChatPage {
  @State messages: ChatMessage[] = [];
  @State inputText: string = '';
  @State isProcessing: boolean = false;
  @State currentAgentState: AgentState = AgentState.IDLE;
  @State currentAgentType: AgentPersonality = AgentPersonality.SCHEDULER;
  @State topAvoidHeight: number = 0;
  @State lightColor: string = '#4A90D9';
  @State lightIntensity: number = 0.4;

  private scheduler: AgentScheduler = AgentScheduler.getInstance();
  private messageId: number = 0;
  private listScroller: ListScroller = new ListScroller();

  aboutToAppear(): void {
    this.getTopAvoidArea();
    this.initializeScheduler();

    // 监听光效状态变化
    AppStorage.setOrCreate('current_agent_color', (color: string) => {
      this.lightColor = color;
    });
    AppStorage.setOrCreate('current_agent_intensity', (intensity: number) => {
      this.lightIntensity = intensity;
    });
  }

  private async initializeScheduler(): Promise<void> {
    await this.scheduler.initialize();
    this.addSystemMessage('灵犀智脑已就绪。请输入您的任务意图，我将自动调度智能体协作完成。');
  }

  private async getTopAvoidArea(): Promise<void> {
    try {
      const mainWindow = await window.getLastWindow();
      const avoidArea = mainWindow.getWindowAvoidArea(window.AvoidAreaType.TYPE_STATUS);
      this.topAvoidHeight = avoidArea.topRect.height;
    } catch (error) {
      console.error('Failed to get top avoid area:', error);
    }
  }

  private addSystemMessage(content: string): void {
    this.messages.push({
      id: `msg-${++this.messageId}`,
      role: 'system',
      content: content,
      timestamp: Date.now()
    });
    this.scrollToBottom();
  }

  private addUserMessage(content: string): void {
    this.messages.push({
      id: `msg-${++this.messageId}`,
      role: 'user',
      content: content,
      timestamp: Date.now()
    });
    this.scrollToBottom();
  }

  private addAgentMessage(role: 'scheduler' | 'executor' | 'validator', content: string, agentType: AgentPersonality): void {
    this.messages.push({
      id: `msg-${++this.messageId}`,
      role: role,
      content: content,
      timestamp: Date.now(),
      agentType: agentType,
      state: AgentState.COMPLETED
    });
    this.scrollToBottom();
  }

  private scrollToBottom(): void {
    setTimeout(() => {
      this.listScroller.scrollToIndex(this.messages.length - 1);
    }, 100);
  }

  private async sendMessage(): Promise<void> {
    if (!this.inputText.trim() || this.isProcessing) return;

    const userInput = this.inputText.trim();
    this.inputText = '';
    this.addUserMessage(userInput);
    this.isProcessing = true;

    // 更新状态为思考中
    this.currentAgentState = AgentState.THINKING;
    this.currentAgentType = AgentPersonality.SCHEDULER;

    try {
      // 调度器处理意图
      const response = await this.scheduler.processUserIntent(userInput);

      // 添加调度器消息
      this.addAgentMessage('scheduler', '🎯 **调度器**：已解析意图并分解任务', AgentPersonality.SCHEDULER);

      // 获取各智能体状态并添加执行记录
      const agentStatus = this.scheduler.getAgentStatus();
      for (const agent of agentStatus) {
        if (agent.status === 'busy' || agent.task) {
          const agentType = agent.type === 'scheduler' ? AgentPersonality.SCHEDULER :
                          agent.type === 'executor' ? AgentPersonality.EXECUTOR :
                          AgentPersonality.VALIDATOR;
          this.addAgentMessage(
            agent.type as 'scheduler' | 'executor' | 'validator',
            `⚡ **${agent.type === 'scheduler' ? '调度器' : agent.type === 'executor' ? '执行器' : '验证器'}** (${agent.id})：正在执行 [${agent.task}]`,
            agentType
          );
        }
      }

      // 添加最终结果
      this.addAgentMessage('scheduler', response, AgentPersonality.SCHEDULER);

    } catch (error) {
      this.addSystemMessage(`❌ 执行异常：${error.message}`);
      this.currentAgentState = AgentState.ERROR;
    } finally {
      this.isProcessing = false;
      this.currentAgentState = AgentState.IDLE;
    }
  }

  private getMessageColor(role: string, agentType?: AgentPersonality): string {
    if (role === 'user') return '#4A90D9';
    if (role === 'system') return '#888888';
    return agentType?.color || '#666666';
  }

  private getMessageIcon(role: string, agentType?: AgentPersonality): string {
    if (role === 'user') return '👤';
    if (role === 'system') return '🔔';
    return agentType?.name === '调度器' ? '🎯' :
           agentType?.name === '执行器' ? '⚡' :
           agentType?.name === '验证器' ? '✅' : '🤖';
  }

  build() {
    AgentFloatNavigation({
      contentBuilder: () => {
        this.chatContentBuilder()
      }
    })
  }

  @Builder
  chatContentBuilder(): void {
    Stack() {
      // 动态沉浸光效背景
      Column() {
        Column()
          .width(300)
          .height(300)
          .backgroundColor(this.lightColor)
          .blur(100)
          .opacity(this.lightIntensity)
          .position({ x: '50%', y: 200 })
          .anchor('50%')
          .animation({
            duration: this.currentAgentState === AgentState.THINKING ? 1500 :
                     this.currentAgentState === AgentState.EXECUTING ? 800 : 4000,
            curve: Curve.EaseInOut,
            iterations: -1,
            playMode: PlayMode.Alternate
          })
      }
      .width('100%')
      .height('100%')
      .backgroundColor('#0f0f23')
      .expandSafeArea([SafeAreaType.SYSTEM], [SafeAreaEdge.TOP, SafeAreaEdge.BOTTOM])

      // 内容层
      Column() {
        // 顶部避让
        Column().width('100%').height(this.topAvoidHeight)

        // 标题栏
        Row() {
          Text('🧠 灵犀智脑')
            .fontSize(20)
            .fontColor('#FFFFFF')
            .fontWeight(FontWeight.Bold)

          Row() {
            // 智能体状态指示器
            Column()
              .width(8)
              .height(8)
              .backgroundColor(
                this.currentAgentState === AgentState.IDLE ? '#888888' :
                this.currentAgentState === AgentState.THINKING ? '#4A90D9' :
                this.currentAgentState === AgentState.EXECUTING ? '#F5A623' :
                this.currentAgentState === AgentState.ERROR ? '#FF4444' : '#2ECC71'
              )
              .borderRadius(4)
              .animation({
                duration: this.currentAgentState === AgentState.THINKING ? 1000 : 500,
                curve: Curve.EaseInOut,
                iterations: -1,
                playMode: PlayMode.Alternate
              })

            Text(
              this.currentAgentState === AgentState.IDLE ? '待机中' :
              this.currentAgentState === AgentState.THINKING ? '思考中...' :
              this.currentAgentState === AgentState.EXECUTING ? '执行中...' :
              this.currentAgentState === AgentState.ERROR ? '异常' : '完成'
            )
              .fontSize(12)
              .fontColor('rgba(255,255,255,0.7)')
              .margin({ left: 8 })
          }
        }
        .width('100%')
        .justifyContent(FlexAlign.SpaceBetween)
        .padding(16)

        // 消息列表
        List({ scroller: this.listScroller }) {
          ForEach(this.messages, (msg: ChatMessage) => {
            ListItem() {
              Column() {
                Row() {
                  Text(`${this.getMessageIcon(msg.role, msg.agentType)} ${msg.role === 'user' ? '我' : msg.agentType?.name || '系统'}`)
                    .fontSize(12)
                    .fontColor(this.getMessageColor(msg.role, msg.agentType))
                    .fontWeight(FontWeight.Medium)

                  Text(new Date(msg.timestamp).toLocaleTimeString())
                    .fontSize(10)
                    .fontColor('rgba(255,255,255,0.4)')
                }
                .width('100%')
                .justifyContent(FlexAlign.SpaceBetween)

                Text(msg.content)
                  .fontSize(14)
                  .fontColor(msg.role === 'user' ? '#FFFFFF' : 'rgba(255,255,255,0.9)')
                  .margin({ top: 8 })
                  .lineHeight(20)
              }
              .width('100%')
              .padding(12)
              .backgroundColor(
                msg.role === 'user' ? 'rgba(74,144,217,0.15)' :
                msg.role === 'system' ? 'rgba(136,136,136,0.1)' :
                'rgba(255,255,255,0.05)'
              )
              .borderRadius(12)
              .border({
                width: 1,
                color: msg.agentType ? `${msg.agentType.color}30` : 'transparent',
                style: BorderStyle.Solid
              })
              .margin({ bottom: 8 })
            }
          })
        }
        .width('100%')
        .layoutWeight(1)
        .padding({ left: 16, right: 16 })

        // 输入区域
        Column() {
          Row() {
            TextInput({ placeholder: '输入任务意图，例如：帮我分析这段代码并优化...', text: $$this.inputText })
              .width('80%')
              .height(48)
              .backgroundColor('rgba(255,255,255,0.1)')
              .fontColor('#FFFFFF')
              .placeholderColor('rgba(255,255,255,0.4)')
              .borderRadius(24)

            Button() {
              Image(this.isProcessing ? $r('app.media.ic_loading') : $r('app.media.ic_send'))
                .width(24)
                .height(24)
                .fillColor('#FFFFFF')
            }
            .type(ButtonType.Circle)
            .backgroundColor(this.isProcessing ? '#888888' : this.lightColor)
            .width(48)
            .height(48)
            .enabled(!this.isProcessing)
            .onClick(() => {
              this.sendMessage();
            })
          }
          .width('100%')
          .justifyContent(FlexAlign.SpaceBetween)
        }
        .width('100%')
        .padding(16)
        .backgroundColor('rgba(0,0,0,0.3)')
        .backdropFilter($r('sys.blur.20'))
      }
      .width('100%')
      .height('100%')
    }
    .width('100%')
    .height('100%')
  }
}

5.6 浮动工具面板窗口（ToolPanelWindow.ets）

代码亮点 ：实现可拖拽的浮动工具面板，支持代码编辑器、数据分析图表、网页预览等工具。窗口激活时边缘发光增强，失活时自动降低光效强度，通过WindowManager与主窗口光效联动。

typescript 复制代码
// entry/src/main/ets/windows/ToolPanelWindow.ets
import { window } from '@kit.ArkUI';

@Component
export struct ToolPanelWindow {
  @State isActive: boolean = false;
  @State currentTool: string = 'code';
  @State windowLightColor: string = '#F5A623';
  @State lightIntensity: number = 0.6;

  private mainWindow: window.Window | null = null;

  aboutToAppear(): void {
    this.setupWindow();
    // 监听主窗口光效变化
    AppStorage.setOrCreate('current_agent_color', (color: string) => {
      this.windowLightColor = color;
    });
  }

  private async setupWindow(): Promise<void> {
    try {
      this.mainWindow = await window.getLastWindow();
      await this.mainWindow.setWindowBackgroundColor('#00000000');

      // 设置窗口为浮动样式
      await this.mainWindow.setWindowDecorVisible(false);
      await this.mainWindow.resize(400, 600);

      // 监听窗口焦点变化
      this.mainWindow.on('windowFocusChange', (isFocused: boolean) => {
        this.isActive = isFocused;
        this.lightIntensity = isFocused ? 0.8 : 0.3;
      });
    } catch (error) {
      console.error('Failed to setup tool panel window:', error);
    }
  }

  build() {
    Stack() {
      // 窗口边框光效
      Column()
        .width('100%')
        .height('100%')
        .backgroundColor('transparent')
        .border({
          width: 2,
          color: `${this.windowLightColor}${this.isActive ? 'FF' : '40'}`,
          style: BorderStyle.Solid
        })
        .borderRadius(16)
        .animation({
          duration: 300,
          curve: Curve.EaseInOut
        })

      // 内容层
      Column() {
        // 标题栏
        Row() {
          Text('🔧 工具面板')
            .fontSize(16)
            .fontColor('#FFFFFF')
            .fontWeight(FontWeight.Bold)

          Row() {
            Button() {
              Text('代码')
                .fontSize(12)
                .fontColor(this.currentTool === 'code' ? '#FFFFFF' : '#888888')
            }
            .type(ButtonType.Capsule)
            .backgroundColor(this.currentTool === 'code' ? this.windowLightColor : 'rgba(255,255,255,0.1)')
            .height(28)
            .onClick(() => { this.currentTool = 'code'; })

            Button() {
              Text('图表')
                .fontSize(12)
                .fontColor(this.currentTool === 'chart' ? '#FFFFFF' : '#888888')
            }
            .type(ButtonType.Capsule)
            .backgroundColor(this.currentTool === 'chart' ? this.windowLightColor : 'rgba(255,255,255,0.1)')
            .height(28)
            .margin({ left: 8 })
            .onClick(() => { this.currentTool = 'chart'; })

            Button() {
              Text('预览')
                .fontSize(12)
                .fontColor(this.currentTool === 'preview' ? '#FFFFFF' : '#888888')
            }
            .type(ButtonType.Capsule)
            .backgroundColor(this.currentTool === 'preview' ? this.windowLightColor : 'rgba(255,255,255,0.1)')
            .height(28)
            .margin({ left: 8 })
            .onClick(() => { this.currentTool = 'preview'; })
          }
        }
        .width('100%')
        .justifyContent(FlexAlign.SpaceBetween)
        .padding(16)

        // 工具内容区
        if (this.currentTool === 'code') {
          this.buildCodeEditor()
        } else if (this.currentTool === 'chart') {
          this.buildChartView()
        } else {
          this.buildPreviewView()
        }
      }
      .width('100%')
      .height('100%')
      .padding(2) // 为边框光效留出空间
    }
    .width('100%')
    .height('100%')
    .backgroundColor('rgba(15,15,35,0.95)')
    .borderRadius(16)
    .shadow({
      radius: 30,
      color: `${this.windowLightColor}${this.isActive ? '40' : '15'}`,
      offsetX: 0,
      offsetY: 0
    })
    .animation({
      duration: 300,
      curve: Curve.EaseInOut
    })
  }

  @Builder
  buildCodeEditor(): void {
    Column() {
      Text('// 智能体生成的代码将显示在这里')
        .fontSize(13)
        .fontColor('rgba(255,255,255,0.6)')
        .fontFamily('monospace')
        .lineHeight(20)
        .width('100%')
        .height('100%')
        .padding(16)
        .backgroundColor('rgba(0,0,0,0.3)')
        .borderRadius(8)
    }
    .width('100%')
    .layoutWeight(1)
    .padding(16)
  }

  @Builder
  buildChartView(): void {
    Column() {
      Text('📊 数据分析图表')
        .fontSize(16)
        .fontColor('#FFFFFF')
        .width('100%')
        .height('100%')
        .justifyContent(FlexAlign.Center)
    }
    .width('100%')
    .layoutWeight(1)
    .padding(16)
  }

  @Builder
  buildPreviewView(): void {
    Column() {
      Text('🌐 网页预览')
        .fontSize(16)
        .fontColor('#FFFFFF')
        .width('100%')
        .height('100%')
        .justifyContent(FlexAlign.Center)
    }
    .width('100%')
    .layoutWeight(1)
    .padding(16)
  }
}

5.7 多窗口光效同步管理器（WindowLightSync.ets）

代码亮点：管理主窗口与浮动工具窗口、知识库窗口、日志窗口之间的光效联动。当智能体状态变化时，所有窗口同步切换主题色；当窗口焦点变化时，自动调整光效强度，形成层次分明的视觉体验。

typescript 复制代码
// entry/src/main/ets/managers/WindowLightSync.ets
import { window } from '@kit.ArkUI';

// 窗口类型
export enum WindowType {
  MAIN = 'main',
  TOOL_PANEL = 'tool_panel',
  KNOWLEDGE_BASE = 'knowledge_base',
  LOG_VIEWER = 'log_viewer'
}

// 光效主题
export interface LightTheme {
  primaryColor: string;
  secondaryColor: string;
  intensity: number;
  pulseSpeed: number;
  glowRadius: number;
}

export class WindowLightSync {
  private static instance: WindowLightSync;
  private windows: Map<<WindowType, window.Window> = new Map();
  private currentTheme: LightTheme = {
    primaryColor: '#4A90D9',
    secondaryColor: '#F5A623',
    intensity: 0.6,
    pulseSpeed: 2000,
    glowRadius: 100
  };
  private focusWindow: WindowType = WindowType.MAIN;

  private constructor() {}

  static getInstance(): WindowLightSync {
    if (!WindowLightSync.instance) {
      WindowLightSync.instance = new WindowLightSync();
    }
    return WindowLightSync.instance;
  }

  registerWindow(type: WindowType, win: window.Window): void {
    this.windows.set(type, win);

    // 监听窗口焦点
    win.on('windowFocusChange', (isFocused: boolean) => {
      if (isFocused) {
        this.focusWindow = type;
        this.updateFocusLightEffect();
      }
    });
  }

  // 同步所有窗口光效
  async syncLightEffect(theme: LightTheme): Promise<void> {
    this.currentTheme = theme;

    for (const [type, win] of this.windows.entries()) {
      try {
        const isFocused = type === this.focusWindow;
        const intensity = isFocused ? theme.intensity : theme.intensity * 0.4;

        // 设置窗口背景光效
        await win.setWindowBackgroundColor(`#00000000`);

        // 同步到AppStorage供各窗口组件读取
        AppStorage.setOrCreate(`window_${type}_color`, theme.primaryColor);
        AppStorage.setOrCreate(`window_${type}_intensity`, intensity);
        AppStorage.setOrCreate(`window_${type}_focused`, isFocused);

      } catch (error) {
        console.error(`Failed to sync light effect for ${type}:`, error);
      }
    }
  }

  // 根据智能体状态更新主题
  updateThemeByAgentState(state: string, agentType: string): void {
    const themes: Record<string, LightTheme> = {
      'scheduler_idle': {
        primaryColor: '#4A90D9',
        secondaryColor: '#6BB6FF',
        intensity: 0.4,
        pulseSpeed: 4000,
        glowRadius: 80
      },
      'scheduler_thinking': {
        primaryColor: '#4A90D9',
        secondaryColor: '#8EC5FF',
        intensity: 0.7,
        pulseSpeed: 1500,
        glowRadius: 120
      },
      'executor_executing': {
        primaryColor: '#F5A623',
        secondaryColor: '#FFD93D',
        intensity: 0.9,
        pulseSpeed: 800,
        glowRadius: 150
      },
      'validator_validating': {
        primaryColor: '#2ECC71',
        secondaryColor: '#7EE8A0',
        intensity: 0.6,
        pulseSpeed: 2000,
        glowRadius: 100
      },
      'error': {
        primaryColor: '#FF4444',
        secondaryColor: '#FF8888',
        intensity: 1.0,
        pulseSpeed: 500,
        glowRadius: 120
      }
    };

    const themeKey = `${agentType}_${state}`;
    const theme = themes[themeKey] || themes['scheduler_idle'];
    this.syncLightEffect(theme);
  }

  private updateFocusLightEffect(): void {
    // 重新应用当前主题，根据新的焦点窗口调整强度
    this.syncLightEffect(this.currentTheme);
  }

  // 创建浮动窗口
  async createFloatWindow(type: WindowType, width: number, height: number, x: number, y: number): Promise<<window.Window> {
    try {
      const floatWindow = await window.createWindow({
        name: type,
        windowType: window.WindowType.TYPE_FLOAT,
        ctx: getContext()
      });

      await floatWindow.moveWindowTo(x, y);
      await floatWindow.resize(width, height);
      await floatWindow.setWindowBackgroundColor('#00000000');
      await floatWindow.showWindow();

      this.registerWindow(type, floatWindow);
      return floatWindow;
    } catch (error) {
      console.error(`Failed to create float window ${type}:`, error);
      throw error;
    }
  }
}

5.8 主页面集成（Index.ets）

typescript 复制代码
// entry/src/main/ets/pages/Index.ets
import { ChatPage } from './ChatPage';
import { WindowLightSync, WindowType } from '../managers/WindowLightSync';
import { ToolPanelWindow } from '../windows/ToolPanelWindow';

@Entry
@Component
struct Index {
  private lightSync: WindowLightSync = WindowLightSync.getInstance();

  aboutToAppear(): void {
    this.initializeWindows();
  }

  private async initializeWindows(): Promise<void> {
    try {
      const mainWindow = await window.getLastWindow();
      this.lightSync.registerWindow(WindowType.MAIN, mainWindow);

      // 创建浮动工具面板（PC端特有）
      if (deviceInfo.deviceType === '2in1' || deviceInfo.deviceType === 'tablet') {
        await this.lightSync.createFloatWindow(
          WindowType.TOOL_PANEL,
          400, 600,
          100, 100
        );
      }
    } catch (error) {
      console.error('Failed to initialize windows:', error);
    }
  }

  build() {
    ChatPage()
  }
}

六、关键技术总结

6.1 HMAF智能体开发清单

技术点 API/方法 应用场景
智能体会话创建 hmaf.createAgentSession({ mode: MULTI_AGENT }) 多智能体协作环境
意图解析 intents.createIntentEngine({ supportedDomains }) 用户自然语言理解
任务分发 hmafSession.sendTask({ targetAgent, taskType }) 智能体间任务调度
状态监听 AppStorage全局状态回调 跨组件状态同步
分布式协同 enableDistributed: true 多设备智能体协作
端侧推理 MindSpore Lite 隐私敏感任务本地处理

6.2 沉浸光感实现清单

技术点 API/方法 应用场景
系统材质效果 systemMaterialEffect: SystemMaterialEffect.IMMERSIVE HdsNavigation标题栏
背景模糊 backgroundBlurStyle(BlurStyle.REGULAR) 悬浮导航玻璃拟态
背景滤镜 backdropFilter($r('sys.blur.20')) 精细模糊控制
安全区扩展 expandSafeArea([SafeAreaType.SYSTEM], [...]) 全屏沉浸布局
窗口沉浸 setWindowLayoutFullScreen(true) 无边框模式
光效动画 animation({ duration, iterations: -1 }) 呼吸灯背景
动态透明度 backgroundOpacity 焦点感知降级

6.3 智能体状态光效映射

智能体状态 光效颜色 脉冲速度 光晕半径 视觉语义
待机 人格专属色 4000ms 80px 柔和呼吸，平静等待
思考中 人格专属色+亮 1500ms 120px 快速脉冲，活跃思考
执行中 人格专属色+饱和 800ms 150px 急促流光，全力执行
已完成 绿色 2000ms 100px 确认闪光，任务达成
异常 红色 500ms 120px 警示闪烁，需要关注

6.4 PC端多窗口光效协同

  • 主窗口：全屏沉浸，智能体人格光效延伸至所有安全区边缘
  • 浮动工具窗口：置顶、圆角、阴影，激活时边缘发光增强
  • 光效同步 ：通过WindowLightSync管理器实现跨窗口主题色联动
  • 焦点感知：窗口激活时边缘发光增强，失活时自动降低光效强度
  • 智能体人格一致性：同一智能体在所有窗口中保持相同色彩标识

七、调试与适配建议

  1. HMAF会话管理：多智能体并发时注意会话资源释放，避免内存泄漏
  2. 光效功耗优化：夜间模式降低光效刷新率，延长OLED屏幕寿命
  3. 意图识别校准：不同行业领域需训练专用意图模型，提升解析准确率
  4. 分布式设备测试：测试跨设备智能体协作时的网络延迟与状态同步
  5. 无障碍支持：为视障用户提供语音播报智能体状态，光效切换时播放提示音
  6. 隐私保护：敏感任务数据本地处理，仅上传脱敏后的意图描述

八、总结与展望

本文基于HarmonyOS 6（API 23）的悬浮导航 、沉浸光感 与HMAF智能体框架特性，完整实战了一款面向PC端的"灵犀智脑"AI智能体工作流编排平台。核心创新点总结：

  1. HMAF多智能体协作架构：基于Agent Framework Kit构建"调度器-执行器-验证器"三层智能体协作体系，实现意图理解→任务分解→智能体分配→结果验证的完整工作流

  2. 智能体状态光效系统：每个智能体拥有专属人格色彩（调度器冷峻蓝、执行器活力橙、验证器严谨绿），根据运行状态动态切换脉冲节奏与光晕强度，实现"状态直觉感知"

  3. 悬浮智能体导航：底部悬浮页签不仅承载页面切换，更实时显示各智能体运行状态徽章（呼吸脉冲、旋转进度、警示闪烁），玻璃拟态设计+三档透明度调节

  4. PC级多窗口智能体协作 ：主对话窗口 + 浮动工具面板 + 浮动知识库 + 浮动日志窗口的四层架构，通过WindowLightSync实现跨窗口光效联动与焦点感知

  5. 意图感知沉浸体验：通过Intents Kit实时理解用户意图，自动调整界面光效与导航形态，实现"意图即氛围"的自然交互

未来扩展方向：

  • 接入分布式软总线4.0，实现PC主控+手机传感器+平板显示的多设备智能体协同
  • AI智能体市场：支持第三方开发者发布自定义智能体，通过光效标识区分能力类型
  • 数字孪生集成：接入IoT设备数据，智能体自动感知物理世界状态并调整工作流
  • VR/AR融合：支持VR头显接入，实现完全沉浸式的3D智能体交互空间
  • 长期记忆进化：基于用户历史交互数据，智能体逐步学习用户偏好，光效个性化适配

转载自：https://blog.csdn.net/u014727709/article/details/161144634

欢迎 👍点赞✍评论⭐收藏，欢迎指正

相关推荐
郭龙飞9801 小时前
OpenClaw 对接企业微信实操教程 完整配置流程
人工智能·windows·机器人·企业微信
穗余1 小时前
大模型注意力机制（Attention）精讲总结
人工智能·深度学习·自然语言处理
2zcode1 小时前
基于改进YOLOv8与BiLSTM的智能安防盗窃行为识别系统-融合CBAM注意力机制与ByteTrack多目标跟踪
人工智能·yolo·目标跟踪
AI周红伟1 小时前
All in Token，移动，电信和联通，华为，阿里，百度，字节，卖Token Plan，卖算力时代结束，卖智力时代来了：Token经济万亿赛道全景解码
大数据·人工智能·机器学习·百度·华为·copilot·openclaw
SuAluvfy1 小时前
不存在“全能第一模型”，存在“任务空间中的局部最优模型”
人工智能·chatgpt·agent
workflower1 小时前
AI能源智慧生产与绿色开发核心场景
大数据·人工智能·设计模式·机器人·软件工程·能源
染指11101 小时前
4.AI大模型-幻觉、记忆、参数-大模型底层运行机制
人工智能
轻口味1 小时前
HarmonyOS 6.1 全栈实战录 - 10 极光星图：Map Kit 6.1 3D地球、城市灯光与Marker碰撞深度实战
3d·华为·harmonyos
晓蓝WQuiet1 小时前
GAN生成对抗网络
人工智能·神经网络·生成对抗网络
热门推荐
01GitHub 镜像站点02Codex 接入 DeepSeek API 完整配置文档03【AI】2026 年具身智能模型和世界模型总结04头歌软件工程导论UML画图题(基于starUML)05Gemini大升级、AI眼镜首发、Android XR亮相，13天后见分晓06CC-Switch & Claude 基于 Linux 服务器安装使用指南07人工智能最新动态 AI 日报 · 2026年5月10日08AI科技热点日报 | 2026年5月11日09Codex 手机端连接教程：三分钟搞定，附完整步骤102026年AI前瞻：量子AI、具身智能与科学发现的新纪元
