导购电商平台用户行为分析系统：基于Flink的实时数据处理架构

大家好，我是省赚客APP研发者阿宝！在"省赚客"导购返利平台中，用户点击、浏览、下单、分享等行为数据是优化推荐算法、提升转化率的关键。为实现秒级响应的用户画像更新与实时营销触发，我们构建了基于Apache Flink的流式处理系统，从Kafka摄入原始事件，经清洗、聚合、关联后写入ClickHouse与Redis，支撑BI看板与实时策略引擎。

事件采集与Kafka Topic设计

前端SDK通过HTTP上报用户行为至Nginx日志，Logstash采集后写入Kafka。核心Topic如下：

user_click_events：用户点击商品/任务
user_order_events：订单创建/完成
user_share_events：分享成功事件

每条消息为JSON格式，包含userId, eventType, itemId, timestamp, sessionId等字段。

Flink作业主干结构

Flink作业使用Java编写，主类位于juwatech.cn.flink.UserBehaviorAnalysisJob：

java 复制代码

package juwatech.cn.flink;

import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
import org.apache.flink.streaming.api.windowing.time.Time;

public class UserBehaviorAnalysisJob {
    public static void main(String[] args) throws Exception {
        StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
        env.enableCheckpointing(10000); // 每10秒checkpoint

        // 1. 读取Kafka点击流
        var clickStream = KafkaSourceBuilder.buildClickSource(env);

        // 2. 清洗并转换为内部对象
        var cleanClicks = clickStream
            .filter(event -> event.getUserId() != null && event.getItemId() != null)
            .map(new ClickEventMapper());

        // 3. 实时统计PV/UV（5分钟窗口）
        var pvuv = cleanClicks
            .keyBy(click -> "global")
            .window(TumblingProcessingTimeWindows.of(Time.minutes(5)))
            .aggregate(new PvUvAgg(), new PvUvResultWindowFunction());

        // 4. 写入ClickHouse
        pvuv.addSink(new ClickHouseSink());

        // 5. 用户实时偏好计算
        var userPreference = cleanClicks
            .keyBy(ClickEvent::getUserId)
            .process(new UserPreferenceProcessFunction());

        userPreference.addSink(new RedisUserPreferenceSink());

        env.execute("UserBehaviorAnalysisJob");
    }
}

自定义ProcessFunction实现用户偏好更新

我们通过KeyedProcessFunction维护每个用户的最近点击品类，并滑动更新偏好权重：

java 复制代码

package juwatech.cn.flink.function;

import org.apache.flink.api.common.state.ValueState;
import org.apache.flink.api.common.state.ValueStateDescriptor;
import org.apache.flink.configuration.Configuration;
import org.apache.flink.streaming.api.functions.KeyedProcessFunction;
import org.apache.flink.util.Collector;
import juwatech.cn.flink.model.ClickEvent;
import juwatech.cn.flink.model.UserPreference;

public class UserPreferenceProcessFunction
    extends KeyedProcessFunction<String, ClickEvent, UserPreference> {

    private ValueState<UserPreference> preferenceState;

    @Override
    public void open(Configuration parameters) {
        preferenceState = getRuntimeContext().getState(
            new ValueStateDescriptor<>("userPref", UserPreference.class)
        );
    }

    @Override
    public void processElement(ClickEvent event, Context ctx, Collector<UserPreference> out) {
        UserPreference current = preferenceState.value();
        if (current == null) {
            current = new UserPreference(event.getUserId());
        }

        // 衰减旧权重，累加新点击
        current.decayAndAdd(event.getCategoryId(), 0.95, 1.0);
        preferenceState.update(current);
        out.collect(current);

        // 注册10分钟后清理（防僵尸用户）
        ctx.timerService().registerProcessingTimeTimer(ctx.timerService().currentProcessingTime() + 600_000L);
    }

    @Override
    public void onTimer(long timestamp, OnTimerContext ctx, Collector<UserPreference> out) {
        preferenceState.clear();
    }
}

其中decayAndAdd方法对历史品类权重指数衰减，确保近期行为占主导。

维表关联：商品信息补全

点击事件仅含itemId，需关联商品维度表获取类目、价格等信息。我们使用AsyncFunction异步查询MySQL：

java 复制代码

package juwatech.cn.flink.async;

import org.apache.flink.streaming.api.functions.async.ResultFuture;
import org.apache.flink.streaming.api.functions.async.RichAsyncFunction;
import java.util.Collections;
import java.util.concurrent.CompletableFuture;

public class ItemInfoAsyncLookup
    extends RichAsyncFunction<ClickEvent, EnrichedClickEvent> {

    private transient JdbcItemService itemService;

    @Override
    public void open(Configuration parameters) {
        itemService = new JdbcItemService("jdbc:mysql://meta.juwatech.cn:3306/item_db");
    }

    @Override
    public void asyncInvoke(ClickEvent input, ResultFuture<EnrichedClickEvent> resultFuture) {
        CompletableFuture.supplyAsync(() -> {
            ItemInfo item = itemService.getById(input.getItemId());
            return new EnrichedClickEvent(input, item);
        }).thenAccept(enriched -> {
            resultFuture.complete(Collections.singletonList(enriched));
        }).exceptionally(e -> {
            resultFuture.completeExceptionally(e);
            return null;
        });
    }
}

主流程中调用：

java 复制代码

var enrichedClicks = AsyncDataStream.unorderedWait(
    cleanClicks,
    new ItemInfoAsyncLookup(),
    2000, TimeUnit.MILLISECONDS,
    100
);

结果输出：ClickHouse与Redis

聚合指标写入ClickHouse供BI查询：

java 复制代码

package juwatech.cn.flink.sink;

import ru.yandex.clickhouse.ClickHouseConnectionImpl;
import org.apache.flink.streaming.api.functions.sink.RichSinkFunction;

public class ClickHouseSink extends RichSinkFunction<PvUvResult> {
    private ClickHouseConnection conn;

    @Override
    public void open(Configuration parameters) {
        conn = new ClickHouseConnectionImpl("jdbc:clickhouse://ch.juwatech.cn:8123/analytics");
    }

    @Override
    public void invoke(PvUvResult value, Context context) {
        String sql = "INSERT INTO user_behavior_metrics (window_end, pv, uv) VALUES (?, ?, ?)";
        try (var stmt = conn.createStatement()) {
            stmt.execute(sql.replaceFirst("\\?", String.valueOf(value.getWindowEnd()))
                         .replaceFirst("\\?", String.valueOf(value.getPv()))
                         .replaceFirst("\\?", String.valueOf(value.getUv())));
        } catch (Exception e) {
            throw new RuntimeException(e);
        }
    }
}

用户偏好实时写入Redis Hash：

java 复制代码

// 在 RedisUserPreferenceSink.invoke() 中
jedis.hset("user:pref:" + pref.getUserId(), "category_weights",
           JsonUtil.toJson(pref.getCategoryWeights()));
jedis.expire("user:pref:" + pref.getUserId(), 86400); // 24小时过期

本文著作权归聚娃科技省赚客app开发者团队，转载请注明出处！
