Agent与工具调用:让大模型拥有行动能力
一、什么是Agent?
1.1 Agent vs 普通LLM
python
import numpy as np
import matplotlib.pyplot as plt
from IPython.display import display, Markdown
import warnings
warnings.filterwarnings('ignore')
print("=" * 60)
print("Agent:让LLM拥有行动能力")
print("=" * 60)
# 普通LLM vs Agent对比
comparison = """
╔══════════════════╦══════════════════════════════════════════════════════════════╗
║ 普通LLM ║ Agent ║
╠══════════════════╬══════════════════════════════════════════════════════════════╣
║ 只能生成文本 ║ 可以执行行动 ║
║ 被动回答问题 ║ 主动完成任务 ║
║ 无记忆(单轮) ║ 有记忆(多轮交互) ║
║ 无法使用工具 ║ 可以调用工具(搜索、计算、API) ║
║ 一次性输出 ║ 循环思考-行动-观察 ║
╚══════════════════╩══════════════════════════════════════════════════════════════╝
"""
print(comparison)
# 可视化对比
fig, axes = plt.subplots(1, 2, figsize=(12, 5))
# 普通LLM
ax1 = axes[0]
ax1.axis('off')
ax1.set_title('普通LLM:一次性输出', fontsize=12)
ax1.text(0.5, 0.7, '用户问题', ha='center', fontsize=10,
bbox=dict(boxstyle='round', facecolor='lightblue'))
ax1.annotate('', xy=(0.5, 0.55), xytext=(0.5, 0.65),
arrowprops=dict(arrowstyle='->', lw=2))
ax1.text(0.5, 0.45, 'LLM', ha='center', fontsize=10,
bbox=dict(boxstyle='round', facecolor='lightgreen'))
ax1.annotate('', xy=(0.5, 0.3), xytext=(0.5, 0.4),
arrowprops=dict(arrowstyle='->', lw=2))
ax1.text(0.5, 0.2, '最终答案', ha='center', fontsize=10,
bbox=dict(boxstyle='round', facecolor='lightcoral'))
# Agent
ax2 = axes[1]
ax2.axis('off')
ax2.set_title('Agent:循环思考-行动-观察', fontsize=12)
# 循环节点
nodes = [
("用户问题", 0.5, 0.85),
("思考\n(Thought)", 0.5, 0.65),
("行动\n(Action)", 0.25, 0.45),
("观察\n(Observation)", 0.5, 0.45),
("工具执行", 0.75, 0.45),
("最终答案", 0.5, 0.2)
]
for label, x, y in nodes:
circle = plt.Circle((x, y), 0.08, color='lightblue', ec='black')
ax2.add_patch(circle)
ax2.text(x, y, label, ha='center', va='center', fontsize=7)
# 连接线
ax2.annotate('', xy=(0.5, 0.77), xytext=(0.5, 0.73), arrowprops=dict(arrowstyle='->', lw=1))
ax2.annotate('', xy=(0.33, 0.57), xytext=(0.42, 0.62), arrowprops=dict(arrowstyle='->', lw=1))
ax2.annotate('', xy=(0.5, 0.53), xytext=(0.58, 0.57), arrowprops=dict(arrowstyle='->', lw=1))
ax2.annotate('', xy=(0.5, 0.37), xytext=(0.5, 0.28), arrowprops=dict(arrowstyle='->', lw=1))
# 循环箭头
ax2.annotate('', xy=(0.42, 0.62), xytext=(0.58, 0.62),
arrowprops=dict(arrowstyle='->', connectionstyle='arc3,rad=0.3', lw=1, color='red'))
ax2.text(0.5, 0.1, '循环直到任务完成', ha='center', fontsize=9,
bbox=dict(boxstyle='round', facecolor='lightyellow'))
plt.suptitle('普通LLM vs Agent', fontsize=14)
plt.tight_layout()
plt.show()
print("\n💡 Agent的核心能力:")
print(" 1. 推理 (Reasoning): 思考如何解决问题")
print(" 2. 行动 (Acting): 调用工具执行操作")
print(" 3. 观察 (Observing): 获取工具执行结果")
print(" 4. 记忆 (Memory): 记住历史交互")
二、ReAct模式
2.1 ReAct原理
python
def react_pattern():
"""ReAct模式详解"""
print("\n" + "=" * 60)
print("ReAct:Reasoning + Acting")
print("=" * 60)
# ReAct循环可视化
fig, ax = plt.subplots(figsize=(12, 8))
ax.axis('off')
# 绘制ReAct循环
import matplotlib.patches as patches
# 中心圆
center = plt.Circle((0.5, 0.5), 0.15, color='lightblue', ec='black')
ax.add_patch(center)
ax.text(0.5, 0.5, 'ReAct\n循环', ha='center', va='center', fontsize=10, fontweight='bold')
# 三个节点
nodes = [
("Thought\n(思考)", 0.2, 0.7),
("Action\n(行动)", 0.8, 0.7),
("Observation\n(观察)", 0.8, 0.3),
]
for label, x, y in nodes:
circle = plt.Circle((x, y), 0.12, color='lightgreen', ec='black')
ax.add_patch(circle)
ax.text(x, y, label, ha='center', va='center', fontsize=9)
# 箭头
ax.annotate('', xy=(0.38, 0.62), xytext=(0.32, 0.58),
arrowprops=dict(arrowstyle='->', lw=2))
ax.annotate('', xy=(0.68, 0.62), xytext=(0.62, 0.58),
arrowprops=dict(arrowstyle='->', lw=2))
ax.annotate('', xy=(0.68, 0.42), xytext=(0.62, 0.38),
arrowprops=dict(arrowstyle='->', lw=2))
# 循环箭头回到思考
ax.annotate('', xy=(0.32, 0.42), xytext=(0.38, 0.38),
arrowprops=dict(arrowstyle='->', lw=2, color='red'))
ax.text(0.5, 0.15, '循环直到获得最终答案', ha='center', fontsize=10,
bbox=dict(boxstyle='round', facecolor='lightyellow'))
ax.set_xlim(0, 1)
ax.set_ylim(0, 1)
ax.set_title('ReAct模式:思考 → 行动 → 观察', fontsize=14)
plt.tight_layout()
plt.show()
# 示例
print("\n📝 ReAct示例(查询天气):")
print("""
Question: 北京今天天气怎么样?
Thought 1: 我需要查询北京的天气信息
Action 1: search[北京天气]
Observation 1: 北京今天晴,温度15-25°C
Thought 2: 我已经获得了天气信息,可以回答用户了
Action 2: finish[北京今天晴天,温度15-25°C]
""")
react_pattern()
2.2 简单Agent实现
python
class SimpleAgent:
"""简单的ReAct Agent实现"""
def __init__(self, llm, tools):
self.llm = llm
self.tools = {tool.name: tool for tool in tools}
self.max_iterations = 5
self.memory = []
def run(self, question):
"""运行Agent"""
print(f"\n📝 用户问题: {question}")
print("-" * 50)
current_question = question
iteration = 0
while iteration < self.max_iterations:
iteration += 1
print(f"\n🔄 迭代 {iteration}")
# 1. 思考
thought = self._think(current_question)
print(f"💭 思考: {thought}")
# 2. 决定行动
action, action_input = self._decide_action(thought)
print(f"🎯 行动: {action}({action_input})")
# 3. 检查是否完成
if action == "finish":
print(f"✅ 最终答案: {action_input}")
return action_input
# 4. 执行工具
if action in self.tools:
observation = self.tools[action].run(action_input)
print(f"👁️ 观察: {observation}")
current_question = f"之前的问题: {question}\n观察结果: {observation}\n下一步?"
else:
print(f"❌ 未知工具: {action}")
break
print("❌ 达到最大迭代次数")
return None
def _think(self, question):
"""模拟思考过程"""
# 简化实现,实际应调用LLM
if "天气" in question:
return "需要查询天气信息"
elif "计算" in question or "多少" in question:
return "需要进行计算"
else:
return "可以直接回答"
def _decide_action(self, thought):
"""决定下一步行动"""
if "查询" in thought:
return ("search", "北京天气")
elif "计算" in thought:
return ("calculate", "2 + 2")
else:
return ("finish", "这是最终答案")
# 定义工具
class Tool:
def __init__(self, name, func, description):
self.name = name
self.func = func
self.description = description
def run(self, input_str):
return self.func(input_str)
def search_tool(query):
"""模拟搜索工具"""
if "天气" in query:
return "北京今天晴天,温度15-25°C"
return f"搜索结果: 关于'{query}'的信息"
def calculate_tool(expression):
"""模拟计算工具"""
try:
result = eval(expression)
return f"{expression} = {result}"
except:
return f"无法计算: {expression}"
# 测试简单Agent
print("\n" + "=" * 60)
print("简单Agent测试")
print("=" * 60)
tools = [
Tool("search", search_tool, "搜索信息"),
Tool("calculate", calculate_tool, "数学计算")
]
agent = SimpleAgent(llm=None, tools=tools)
agent.run("北京今天天气怎么样?")
三、工具定义与调用
3.1 常用工具类型
python
def tools_overview():
"""常用工具类型"""
print("\n" + "=" * 60)
print("Agent常用工具")
print("=" * 60)
tools_list = {
"🔍 搜索工具": "Google搜索、Bing搜索、Wikipedia",
"🧮 计算工具": "数学计算、代码执行",
"📁 文件工具": "读写文件、数据处理",
"🌐 API工具": "调用外部API(天气、新闻、股票)",
"💾 数据库工具": "查询SQL数据库",
"📧 通信工具": "发送邮件、消息",
"🤖 其他AI": "调用其他AI模型"
}
for tool, examples in tools_list.items():
print(f"\n {tool}: {examples}")
# 工具定义示例
print("\n📐 工具定义示例:")
print("""
from typing import Optional, Type
from pydantic import BaseModel, Field
class WeatherInput(BaseModel):
city: str = Field(description="城市名称")
unit: Optional[str] = Field("celsius", description="温度单位")
def get_weather(city: str, unit: str = "celsius") -> str:
\"\"\"获取城市天气\"\"\"
# 调用天气API
return f"{city}天气: 晴天, 25°C"
# LangChain工具定义
from langchain.tools import tool
@tool
def search(query: str) -> str:
\"\"\"搜索网络信息\"\"\"
return search_api(query)
""")
tools_overview()
3.2 工具调用流程
python
def tool_calling_flow():
"""工具调用流程"""
print("\n" + "=" * 60)
print("工具调用流程")
print("=" * 60)
# 可视化工具调用流程
fig, ax = plt.subplots(figsize=(12, 6))
ax.axis('off')
# 流程节点
steps = [
("用户输入", 0.05, 0.5),
("LLM决策", 0.25, 0.5),
("解析工具调用", 0.45, 0.5),
("执行工具", 0.65, 0.5),
("返回结果", 0.85, 0.5),
]
for label, x, y in steps:
box = plt.Rectangle((x-0.07, y-0.08), 0.14, 0.16,
facecolor='lightblue', ec='black')
ax.add_patch(box)
ax.text(x, y, label, ha='center', va='center', fontsize=8)
if x < 0.85:
ax.annotate('', xy=(x+0.08, 0.5), xytext=(x+0.05, 0.5),
arrowprops=dict(arrowstyle='->', lw=2))
ax.set_xlim(0, 1)
ax.set_ylim(0, 1)
ax.set_title('工具调用流程', fontsize=12)
plt.tight_layout()
plt.show()
# 工具调用格式
print("\n📐 OpenAI Function Calling格式:")
print("""
# 定义工具
tools = [
{
"type": "function",
"function": {
"name": "get_weather",
"description": "获取指定城市的天气",
"parameters": {
"type": "object",
"properties": {
"city": {
"type": "string",
"description": "城市名称"
}
},
"required": ["city"]
}
}
}
]
# LLM响应
response = {
"role": "assistant",
"content": None,
"tool_calls": [
{
"id": "call_123",
"type": "function",
"function": {
"name": "get_weather",
"arguments": '{"city": "北京"}'
}
}
]
}
""")
tool_calling_flow()
四、多Agent协作
4.1 多Agent架构
python
def multi_agent_architecture():
"""多Agent协作架构"""
print("\n" + "=" * 60)
print("多Agent协作")
print("=" * 60)
fig, ax = plt.subplots(figsize=(12, 8))
ax.axis('off')
# 主Agent
main = plt.Circle((0.5, 0.7), 0.1, color='lightcoral', ec='black')
ax.add_patch(main)
ax.text(0.5, 0.7, '主Agent\n(协调者)', ha='center', va='center', fontsize=8)
# 子Agent
sub_agents = [
("搜索Agent", 0.2, 0.4),
("计算Agent", 0.5, 0.4),
("代码Agent", 0.8, 0.4),
]
for name, x, y in sub_agents:
circle = plt.Circle((x, y), 0.08, color='lightgreen', ec='black')
ax.add_patch(circle)
ax.text(x, y, name, ha='center', va='center', fontsize=7)
# 连接到主Agent
ax.annotate('', xy=(x, y+0.08), xytext=(0.5, 0.6),
arrowprops=dict(arrowstyle='->', lw=1))
# 用户输入
user = plt.Rectangle((0.35, 0.85), 0.3, 0.08,
facecolor='lightblue', ec='black')
ax.add_patch(user)
ax.text(0.5, 0.89, '用户输入', ha='center', va='center', fontsize=8)
ax.annotate('', xy=(0.5, 0.8), xytext=(0.5, 0.85),
arrowprops=dict(arrowstyle='->', lw=1))
# 最终输出
output = plt.Rectangle((0.35, 0.1), 0.3, 0.08,
facecolor='lightyellow', ec='black')
ax.add_patch(output)
ax.text(0.5, 0.14, '最终输出', ha='center', va='center', fontsize=8)
ax.annotate('', xy=(0.5, 0.2), xytext=(0.5, 0.25),
arrowprops=dict(arrowstyle='->', lw=1))
ax.set_xlim(0, 1)
ax.set_ylim(0, 1)
ax.set_title('多Agent协作架构', fontsize=14)
plt.tight_layout()
plt.show()
print("\n💡 多Agent模式:")
print(" 1. 层级式: 主Agent分配任务给子Agent")
print(" 2. 对等式: Agent之间平等协作")
print(" 3. 流水线式: 依次处理")
print(" 4. 辩论式: 多个Agent讨论达成共识")
multi_agent_architecture()
4.2 AutoGPT/BabyAGI原理
python
def autogpt_principle():
"""AutoGPT/BabyAGI原理"""
print("\n" + "=" * 60)
print("AutoGPT/BabyAGI原理")
print("=" * 60)
print("\n📐 AutoGPT核心组件:")
components = {
"任务列表": "存储待完成的任务",
"执行器": "执行具体任务",
"记忆系统": "存储历史信息",
"优先级排序": "决定下一步做什么"
}
for name, desc in components.items():
print(f" • {name}: {desc}")
# AutoGPT循环
fig, ax = plt.subplots(figsize=(12, 6))
ax.axis('off')
# 循环节点
nodes = [
("获取\n任务", 0.15, 0.5),
("执行\n任务", 0.35, 0.5),
("观察\n结果", 0.55, 0.5),
("记忆\n存储", 0.75, 0.5),
("创建\n新任务", 0.75, 0.2),
("任务\n列表", 0.35, 0.2),
]
for label, x, y in nodes:
circle = plt.Circle((x, y), 0.08, color='lightblue', ec='black')
ax.add_patch(circle)
ax.text(x, y, label, ha='center', va='center', fontsize=7)
# 连接线
ax.annotate('', xy=(0.23, 0.5), xytext=(0.27, 0.5), arrowprops=dict(arrowstyle='->', lw=1))
ax.annotate('', xy=(0.43, 0.5), xytext=(0.47, 0.5), arrowprops=dict(arrowstyle='->', lw=1))
ax.annotate('', xy=(0.63, 0.5), xytext=(0.67, 0.5), arrowprops=dict(arrowstyle='->', lw=1))
ax.annotate('', xy=(0.75, 0.42), xytext=(0.75, 0.28), arrowprops=dict(arrowstyle='->', lw=1))
ax.annotate('', xy=(0.67, 0.2), xytext=(0.43, 0.2), arrowprops=dict(arrowstyle='->', lw=1))
ax.annotate('', xy=(0.35, 0.28), xytext=(0.35, 0.42), arrowprops=dict(arrowstyle='->', lw=1))
ax.set_xlim(0, 1)
ax.set_ylim(0, 1)
ax.set_title('AutoGPT循环', fontsize=12)
plt.tight_layout()
plt.show()
autogpt_principle()
五、实战:构建智能助手
5.1 完整Agent实现
python
import json
import requests
from typing import List, Dict, Any, Callable
from dataclasses import dataclass
from enum import Enum
class Role(Enum):
USER = "user"
ASSISTANT = "assistant"
TOOL = "tool"
@dataclass
class Message:
role: Role
content: str
tool_calls: List[Dict] = None
tool_call_id: str = None
class ToolCallAgent:
"""完整的工具调用Agent"""
def __init__(self, model_name="gpt-3.5-turbo"):
self.model_name = model_name
self.tools = {}
self.messages = []
self.max_iterations = 10
def register_tool(self, name: str, func: Callable, description: str, parameters: Dict):
"""注册工具"""
self.tools[name] = {
"func": func,
"description": description,
"parameters": parameters
}
def _get_tools_schema(self):
"""获取工具schema"""
tools_schema = []
for name, tool in self.tools.items():
tools_schema.append({
"type": "function",
"function": {
"name": name,
"description": tool["description"],
"parameters": tool["parameters"]
}
})
return tools_schema
def _call_llm(self, messages):
"""调用LLM(模拟)"""
# 实际应用中这里调用OpenAI API
# 这里用模拟实现
last_message = messages[-1].content
# 简单的意图识别
if "天气" in last_message:
return {
"content": None,
"tool_calls": [{
"function": {"name": "get_weather", "arguments": '{"city": "北京"}'}
}]
}
elif "计算" in last_message:
return {
"content": None,
"tool_calls": [{
"function": {"name": "calculate", "arguments": '{"expression": "2+2"}'}
}]
}
else:
return {
"content": "我是AI助手,有什么可以帮您的?",
"tool_calls": None
}
def _execute_tool(self, tool_name, arguments):
"""执行工具"""
if tool_name not in self.tools:
return f"错误: 未找到工具 {tool_name}"
tool = self.tools[tool_name]
try:
args = json.loads(arguments)
result = tool["func"](**args)
return str(result)
except Exception as e:
return f"执行错误: {e}"
def run(self, user_input: str):
"""运行Agent"""
# 添加用户消息
self.messages.append(Message(role=Role.USER, content=user_input))
iteration = 0
while iteration < self.max_iterations:
iteration += 1
print(f"\n🔄 迭代 {iteration}")
# 调用LLM
response = self._call_llm(self.messages)
# 处理响应
if response["tool_calls"]:
# 有工具调用
for tool_call in response["tool_calls"]:
tool_name = tool_call["function"]["name"]
arguments = tool_call["function"]["arguments"]
print(f"🔧 调用工具: {tool_name}({arguments})")
result = self._execute_tool(tool_name, arguments)
print(f"📊 结果: {result}")
# 添加工具结果到消息
self.messages.append(Message(
role=Role.TOOL,
content=result,
tool_call_id=tool_call.get("id", "unknown")
))
else:
# 直接响应
answer = response["content"]
print(f"✅ 最终答案: {answer}")
self.messages.append(Message(role=Role.ASSISTANT, content=answer))
return answer
print("❌ 达到最大迭代次数")
return None
# 定义工具函数
def get_weather(city: str, unit: str = "celsius") -> str:
"""获取天气信息"""
weather_data = {
"北京": "晴天,温度25°C",
"上海": "多云,温度22°C",
"广州": "雨天,温度28°C"
}
return weather_data.get(city, f"{city}天气: 晴,温度20°C")
def calculate(expression: str) -> str:
"""数学计算"""
try:
result = eval(expression)
return f"{expression} = {result}"
except:
return f"计算错误: {expression}"
def search(query: str) -> str:
"""搜索信息"""
return f"关于'{query}'的搜索结果: 找到相关信息..."
# 测试Agent
print("\n" + "=" * 60)
print("智能助手Agent测试")
print("=" * 60)
agent = ToolCallAgent()
# 注册工具
agent.register_tool(
"get_weather",
get_weather,
"获取城市天气信息",
{
"type": "object",
"properties": {
"city": {"type": "string", "description": "城市名称"},
"unit": {"type": "string", "description": "温度单位"}
},
"required": ["city"]
}
)
agent.register_tool(
"calculate",
calculate,
"数学计算",
{
"type": "object",
"properties": {
"expression": {"type": "string", "description": "数学表达式"}
},
"required": ["expression"]
}
)
# 测试
agent.run("北京今天天气怎么样?")
六、最佳实践与总结
python
def best_practices():
"""Agent最佳实践"""
print("\n" + "=" * 60)
print("Agent最佳实践")
print("=" * 60)
practices = """
📌 设计原则:
1. 工具设计
- 每个工具职责单一
- 提供清晰的描述
- 定义明确的输入输出
2. 提示工程
- 清晰说明可用工具
- 给出使用示例
- 限制最大迭代次数
3. 错误处理
- 工具调用失败要有fallback
- 添加超时机制
- 记录执行日志
4. 安全考虑
- 限制工具权限
- 沙箱执行代码
- 敏感操作需确认
5. 性能优化
- 并行执行独立工具
- 缓存常用结果
- 异步处理长任务
"""
print(practices)
# 总结
print("\n" + "=" * 60)
print("Agent核心要点总结")
print("=" * 60)
summary = """
╔══════════════════╦══════════════════════════════════════════════════════════════╗
║ 概念 ║ 说明 ║
╠══════════════════╬══════════════════════════════════════════════════════════════╣
║ ReAct ║ 思考-行动-观察循环,让LLM自主决策 ║
║ Tool ║ 赋予LLM外部能力(搜索、计算、API) ║
║ Memory ║ 记住历史交互,实现多轮对话 ║
║ Multi-Agent ║ 多个Agent协作完成复杂任务 ║
║ AutoGPT ║ 自动分解任务、执行、创建子任务 ║
╚══════════════════╩══════════════════════════════════════════════════════════════╝
"""
print(summary)
best_practices()
七、总结
| 概念 | 作用 | 关键点 |
|---|---|---|
| ReAct | 决策循环 | Thought → Action → Observation |
| Tool | 扩展能力 | 搜索、计算、API调用 |
| Memory | 上下文记忆 | 短期记忆、长期记忆 |
| Multi-Agent | 协作分工 | 主从式、对等式 |
Agent开发流程:
定义目标 → 设计工具 → 编写提示 → 实现循环 → 测试优化
记住:
- Agent让LLM从"说话"变成"做事"
- 工具是Agent能力的边界
- ReAct是实现自主决策的经典模式
- 安全性和可控性很重要
