HarmonyOS 6智能家居实战：基于悬浮导航与沉浸光感的“光影智家“全屋智能控制系统

想你依然心痛2026-04-21 8:57

文章目录

    • 每日一句正能量
    • [一、前言：当智能家居遇上HarmonyOS 6新特性](#一、前言：当智能家居遇上HarmonyOS 6新特性)
    • 二、智能家居场景下的特性适配设计
      • [2.1 空间-导航-光效映射体系](#2.1 空间-导航-光效映射体系)
      • [2.2 设备状态-光效编码协议](#2.2 设备状态-光效编码协议)
    • 三、核心组件实战
      • [3.1 空间感知悬浮导航（SpatialFloatNav.ets）](#3.1 空间感知悬浮导航（SpatialFloatNav.ets）)
      • [3.2 设备控制光效面板（DeviceControlPanel.ets）](#3.2 设备控制光效面板（DeviceControlPanel.ets）)
      • [3.3 场景切换沉浸过渡（SceneTransition.ets）](#3.3 场景切换沉浸过渡（SceneTransition.ets）)
    • 四、主页面集成
      • [4.1 智能家居主页面（SmartHomePage.ets）](#4.1 智能家居主页面（SmartHomePage.ets）)
    • 五、关键技术总结
      • [5.1 空间-导航-光效协同架构](#5.1 空间-导航-光效协同架构)
      • [5.2 设备状态可视化编码](#5.2 设备状态可视化编码)
      • [5.3 分布式设备同步](#5.3 分布式设备同步)
    • 六、调试与适配建议
    • 七、结语

每日一句正能量

放弃很容易，但坚持一定很酷。在想放弃的那一刻，想想当初为什么出发。成功往往就躲在"再坚持一下"的拐角处。咬紧牙关，跨过那道坎，你会感谢那个死磕到底的自己。早上好！

一、前言：当智能家居遇上HarmonyOS 6新特性

随着HarmonyOS生态在IoT领域的深度布局，智能家居控制应用正从"功能堆砌"向"场景化体验"演进。HarmonyOS 6（API 23）带来的**悬浮导航（Float Navigation）与沉浸光感（Immersive Light Effects）**特性，为智能家居控制提供了全新的交互维度。

传统智能家居APP采用固定的底部Tab导航，在控制多设备时需要频繁切换页面，打断操作流。HarmonyOS 6的悬浮导航允许控制面板以"空间悬浮"的方式叠加在场景视图上，配合沉浸光感实现"房间即界面"------客厅暖光、卧室柔光、书房冷光，每个空间都有独特的视觉氛围，设备状态通过光效直观呈现。

本文将构建一款名为**"光影智家"**的全屋智能控制中心，展示如何：

  • 空间感知悬浮导航：根据当前所在房间自动切换导航内容和光效主题
  • 设备状态光效编码：灯光亮度、空调温度、窗帘开合度转化为可视化光效
  • 场景化沉浸控制："观影模式""阅读模式"等场景一键切换，全屏光效过渡
  • 多设备协同光效：多个HarmonyOS设备间的控制状态同步与光效联动

二、智能家居场景下的特性适配设计

2.1 空间-导航-光效映射体系

房间类型 主色调 导航位置 光效特征 设备优先级
客厅 暖橙 #F5A623 底部悬浮 温馨呼吸光 灯光/电视/空调
卧室 柔紫 #9B59B6 侧边迷你 舒缓渐变 灯光/窗帘/净化器
书房 冷蓝 #4A90E2 右侧轨道 专注稳定 台灯/电脑/音响
厨房 明黄 #FFE66D 顶部快捷 明亮清晰 烟机/冰箱/灯具
浴室 青绿 #4ECDC4 底部防水 清新脉冲 浴霸/热水器/除湿

2.2 设备状态-光效编码协议

将设备运行状态映射为光效参数，实现"一眼即知"：

typescript 复制代码
// 设备状态-光效映射
export const DeviceStateLightMap = {
  light: {
    off: { color: '#333333', pulse: 0, intensity: 0 },
    dim: { color: '#FFE4B5', pulse: 8000, intensity: 0.3 },
    normal: { color: '#FFF8DC', pulse: 6000, intensity: 0.6 },
    bright: { color: '#FFFFFF', pulse: 4000, intensity: 1.0 }
  },
  ac: {
    off: { color: '#666666', pulse: 0, intensity: 0 },
    cool: { color: '#00D2FF', pulse: 3000, intensity: 0.7 },
    heat: { color: '#FF6B6B', pulse: 3000, intensity: 0.7 },
    auto: { color: '#2ECC71', pulse: 5000, intensity: 0.5 }
  },
  curtain: {
    closed: { color: '#2C3E50', pulse: 0, intensity: 0.2 },
    half: { color: '#F39C12', pulse: 6000, intensity: 0.4 },
    open: { color: '#F1C40F', pulse: 4000, intensity: 0.8 }
  }
};

三、核心组件实战

3.1 空间感知悬浮导航（SpatialFloatNav.ets）

代码亮点：这是本应用的核心创新组件。它通过HarmonyOS分布式能力感知用户当前所在房间（通过路由器信号强度、设备蓝牙信标或手机定位），自动切换导航内容和光效主题。导航形态根据房间功能动态调整------客厅底部展开、卧室侧边迷你、书房右侧轨道，实现"空间即导航"的沉浸体验。

typescript 复制代码
// entry/src/main/ets/components/SpatialFloatNav.ets
import { distributedDeviceManager } from '@kit.DistributedServiceKit';
import { geolocation } from '@kit.LocationKit';

// 房间类型
export enum RoomType {
  LIVING_ROOM = 'living_room',
  BEDROOM = 'bedroom',
  STUDY = 'study',
  KITCHEN = 'kitchen',
  BATHROOM = 'bathroom',
  BALCONY = 'balcony'
}

// 房间配置
interface RoomConfig {
  type: RoomType;
  name: string;
  primaryColor: string;
  ambientColor: string;
  glowColor: string;
  navPosition: 'bottom' | 'left' | 'right' | 'top';
  navSize: number;
  devicePriority: string[];
}

// 导航项
interface RoomNavItem {
  id: string;
  icon: Resource;
  label: string;
  deviceType: string;
  roomId: string;
  isActive: boolean;
  quickActions: string[];
}

@Component
export struct SpatialFloatNav {
  // 回调
  onDeviceSelect?: (device: RoomNavItem) => void;
  onSceneSelect?: (scene: string) => void;
  onRoomChange?: (room: RoomConfig) => void;

  @State currentRoom: RoomConfig = this.getRoomConfig(RoomType.LIVING_ROOM);
  @State detectedRoom: RoomType = RoomType.LIVING_ROOM;
  @State navItems: RoomNavItem[] = [];
  @State isExpanded: boolean = true;
  @State currentLightColor: string = '#F5A623';
  @State ambientIntensity: number = 0.6;
  @State showRoomSwitcher: boolean = false;
  @State activeDeviceId: string = '';

  // 房间配置库
  private roomConfigs: Map<RoomType, RoomConfig> = new Map([
    [RoomType.LIVING_ROOM, {
      type: RoomType.LIVING_ROOM,
      name: '客厅',
      primaryColor: '#F5A623',
      ambientColor: '#5C3D1E',
      glowColor: '#FFD93D',
      navPosition: 'bottom',
      navSize: 80,
      devicePriority: ['light', 'tv', 'ac', 'curtain', 'speaker']
    }],
    [RoomType.BEDROOM, {
      type: RoomType.BEDROOM,
      name: '卧室',
      primaryColor: '#9B59B6',
      ambientColor: '#4A235A',
      glowColor: '#E056FD',
      navPosition: 'left',
      navSize: 72,
      devicePriority: ['light', 'curtain', 'purifier', 'humidifier', 'alarm']
    }],
    [RoomType.STUDY, {
      type: RoomType.STUDY,
      name: '书房',
      primaryColor: '#4A90E2',
      ambientColor: '#1E3A5F',
      glowColor: '#6BB6FF',
      navPosition: 'right',
      navSize: 64,
      devicePriority: ['desk_lamp', 'computer', 'speaker', 'ac', 'monitor']
    }],
    [RoomType.KITCHEN, {
      type: RoomType.KITCHEN,
      name: '厨房',
      primaryColor: '#FFE66D',
      ambientColor: '#5C4D1E',
      glowColor: '#FFF5B7',
      navPosition: 'top',
      navSize: 72,
      devicePriority: ['hood', 'fridge', 'light', 'oven', 'kettle']
    }],
    [RoomType.BATHROOM, {
      type: RoomType.BATHROOM,
      name: '浴室',
      primaryColor: '#4ECDC4',
      ambientColor: '#1E4D4A',
      glowColor: '#7EDDD6',
      navPosition: 'bottom',
      navSize: 64,
      devicePriority: ['heater', 'water_heater', 'dehumidifier', 'light', 'fan']
    }]
  ]);

  // 设备数据（模拟）
  private deviceDatabase: RoomNavItem[] = [
    { id: 'light_01', icon: $r('app.media.ic_light'), label: '主灯', deviceType: 'light', roomId: 'living_room', isActive: true, quickActions: ['on', 'off', 'dim', 'bright'] },
    { id: 'tv_01', icon: $r('app.media.ic_tv'), label: '电视', deviceType: 'tv', roomId: 'living_room', isActive: false, quickActions: ['on', 'off', 'volume'] },
    { id: 'ac_01', icon: $r('app.media.ic_ac'), label: '空调', deviceType: 'ac', roomId: 'living_room', isActive: true, quickActions: ['cool', 'heat', 'auto', 'off'] },
    { id: 'curtain_01', icon: $r('app.media.ic_curtain'), label: '窗帘', deviceType: 'curtain', roomId: 'living_room', isActive: false, quickActions: ['open', 'half', 'close'] },
    { id: 'speaker_01', icon: $r('app.media.ic_speaker'), label: '音响', deviceType: 'speaker', roomId: 'living_room', isActive: false, quickActions: ['play', 'pause', 'volume'] },
    { id: 'light_02', icon: $r('app.media.ic_light'), label: '床头灯', deviceType: 'light', roomId: 'bedroom', isActive: true, quickActions: ['on', 'off', 'dim', 'bright'] },
    { id: 'curtain_02', icon: $r('app.media.ic_curtain'), label: '窗帘', deviceType: 'curtain', roomId: 'bedroom', isActive: false, quickActions: ['open', 'half', 'close'] },
    { id: 'purifier_01', icon: $r('app.media.ic_purifier'), label: '净化器', deviceType: 'purifier', roomId: 'bedroom', isActive: true, quickActions: ['auto', 'sleep', 'turbo', 'off'] }
  ];

  aboutToAppear(): void {
    this.startRoomDetection();
    this.loadRoomDevices(this.currentRoom.type);
  }

  // 启动房间检测（分布式设备感知）
  private startRoomDetection(): void {
    // 方法1：通过分布式设备信号强度检测
    try {
      const devices = distributedDeviceManager.getAvailableDeviceListSync();
      // 分析设备信号强度判断最近房间
      this.analyzeDeviceProximity(devices);
    } catch (error) {
      console.error('Device detection failed:', error);
    }

    // 方法2：定时检测房间变化
    setInterval(() => {
      this.detectCurrentRoom();
    }, 10000);
  }

  private analyzeDeviceProximity(devices: any[]): void {
    // 简化实现：根据设备ID前缀判断房间
    // 实际应基于RSSI信号强度计算
    const roomSignals: Map<RoomType, number> = new Map();

    devices.forEach(device => {
      const deviceName = device.deviceName || '';
      if (deviceName.includes('living')) {
        roomSignals.set(RoomType.LIVING_ROOM, (roomSignals.get(RoomType.LIVING_ROOM) || 0) + 1);
      } else if (deviceName.includes('bedroom')) {
        roomSignals.set(RoomType.BEDROOM, (roomSignals.get(RoomType.BEDROOM) || 0) + 1);
      }
      // ... 其他房间
    });

    // 选择信号最强的房间
    let maxSignal = 0;
    let detectedRoom = RoomType.LIVING_ROOM;
    roomSignals.forEach((signal, room) => {
      if (signal > maxSignal) {
        maxSignal = signal;
        detectedRoom = room;
      }
    });

    if (detectedRoom !== this.detectedRoom) {
      this.detectedRoom = detectedRoom;
      this.switchRoom(detectedRoom);
    }
  }

  private detectCurrentRoom(): void {
    // 模拟房间检测（实际应结合多种传感器）
    const rooms = Array.from(this.roomConfigs.keys());
    const randomRoom = rooms[Math.floor(Math.random() * rooms.length)];

    if (randomRoom !== this.detectedRoom) {
      this.detectedRoom = randomRoom;
      this.switchRoom(randomRoom);
    }
  }

  private switchRoom(roomType: RoomType): void {
    const config = this.roomConfigs.get(roomType);
    if (config) {
      this.currentRoom = config;
      this.currentLightColor = config.primaryColor;
      this.loadRoomDevices(roomType);
      this.onRoomChange?.(config);

      // 同步光效
      AppStorage.setOrCreate('current_room_color', config.primaryColor);
      AppStorage.setOrCreate('room_changed', Date.now());
    }
  }

  private loadRoomDevices(roomType: RoomType): void {
    const roomId = roomType.toString();
    this.navItems = this.deviceDatabase.filter(d => d.roomId === roomId);

    // 按房间优先级排序
    const priority = this.currentRoom.devicePriority;
    this.navItems.sort((a, b) => {
      return priority.indexOf(a.deviceType) - priority.indexOf(b.deviceType);
    });
  }

  build() {
    Stack({ alignContent: Alignment.Bottom }) {
      // 内容层
      this.contentBuilder()

      // 房间切换器（顶部）
      if (this.showRoomSwitcher) {
        this.buildRoomSwitcher()
      }

      // 空间感知导航层
      if (this.currentRoom.navPosition === 'bottom') {
        this.buildBottomNav()
      } else if (this.currentRoom.navPosition === 'left') {
        this.buildLeftNav()
      } else if (this.currentRoom.navPosition === 'right') {
        this.buildRightNav()
      } else if (this.currentRoom.navPosition === 'top') {
        this.buildTopNav()
      }

      // 环境光效层
      this.buildAmbientLightLayer()
    }
    .width('100%')
    .height('100%')
  }

  @Builder
  contentBuilder(): void {
    Column() {
      Text('智能家居控制区域')
        .fontSize(16)
        .fontColor('rgba(255,255,255,0.3)')
    }
    .width('100%')
    .height('100%')
    .justifyContent(FlexAlign.Center)
  }

  // 底部导航（客厅/浴室）
  @Builder
  buildBottomNav(): void {
    Column() {
      // 房间指示器（可点击切换）
      Row() {
        Text(this.currentRoom.name)
          .fontSize(12)
          .fontColor(this.currentLightColor)
          .fontWeight(FontWeight.Medium)

        Image($r('app.media.ic_chevron_up'))
          .width(16)
          .height(16)
          .fillColor(this.currentLightColor)
          .rotate({ angle: this.showRoomSwitcher ? 180 : 0 })
          .animation({ duration: 200 })
      }
      .height(32)
      .padding({ left: 16, right: 16 })
      .backgroundColor('rgba(30, 30, 40, 0.6)')
      .backdropFilter($r('sys.blur.15'))
      .borderRadius(16)
      .onClick(() => {
        this.showRoomSwitcher = !this.showRoomSwitcher;
      })
      .margin({ bottom: 8 })

      // 设备导航栏
      Column() {
        Row({ space: 12 }) {
          ForEach(this.navItems, (item: RoomNavItem) => {
            this.buildDeviceButton(item)
          })

          // 场景快捷按钮
          this.buildSceneButton()
        }
        .width('100%')
        .height(72)
        .padding({ left: 16, right: 16 })
        .justifyContent(FlexAlign.SpaceAround)
      }
      .width('94%')
      .height(80)
      .backgroundColor('rgba(30, 30, 40, 0.8)')
      .backdropFilter($r('sys.blur.25'))
      .borderRadius(24)
      .shadow({
        radius: 20,
        color: 'rgba(0, 0, 0, 0.3)',
        offsetX: 0,
        offsetY: -4
      })
    }
    .width('100%')
    .height(120)
    .padding({ bottom: 12 })
    .animation({
      duration: 300,
      curve: Curve.EaseInOut
    })
  }

  // 左侧导航（卧室）
  @Builder
  buildLeftNav(): void {
    Row() {
      Column() {
        // 房间标识
        Column() {
          Text(this.currentRoom.name.substring(0, 1))
            .fontSize(20)
            .fontWeight(FontWeight.Bold)
            .fontColor(this.currentLightColor)
        }
        .width(48)
        .height(48)
        .backgroundColor(`${this.currentLightColor}20`)
        .borderRadius(24)
        .margin({ bottom: 16 })
        .onClick(() => {
          this.showRoomSwitcher = !this.showRoomSwitcher;
        })

        // 设备列表
        List({ space: 8 }) {
          ForEach(this.navItems, (item: RoomNavItem) => {
            ListItem() {
              this.buildDeviceIcon(item)
            }
          })
        }
        .width('100%')
        .layoutWeight(1)

        // 场景按钮
        Button() {
          Image($r('app.media.ic_scene'))
            .width(24)
            .height(24)
            .fillColor(this.currentLightColor)
        }
        .type(ButtonType.Circle)
        .backgroundColor(`${this.currentLightColor}20`)
        .width(48)
        .height(48)
        .onClick(() => {
          this.showScenePanel();
        })
      }
      .width(this.isExpanded ? 200 : 64)
      .height('70%')
      .backgroundColor('rgba(30, 30, 40, 0.8)')
      .backdropFilter($r('sys.blur.25'))
      .borderRadius({ topRight: 24, bottomRight: 24 })
      .padding(12)
      .animation({
        duration: 250,
        curve: Curve.EaseInOut
      })
      .onHover((isHover: boolean) => {
        this.isExpanded = isHover;
      })
    }
    .width(this.isExpanded ? 200 : 64)
    .height('100%')
    .position({ x: 0, y: 0 })
    .padding({ top: 100, bottom: 100 })
  }

  // 右侧导航（书房）
  @Builder
  buildRightNav(): void {
    Column() {
      Column() {
        // 设备图标列表
        List({ space: 12 }) {
          ForEach(this.navItems, (item: RoomNavItem) => {
            ListItem() {
              this.buildDeviceIcon(item)
            }
          })
        }
        .width('100%')
        .layoutWeight(1)

        // 房间切换
        Button() {
          Text(this.currentRoom.name.substring(0, 1))
            .fontSize(16)
            .fontWeight(FontWeight.Bold)
            .fontColor(this.currentLightColor)
        }
        .type(ButtonType.Circle)
        .backgroundColor(`${this.currentLightColor}20`)
        .width(44)
        .height(44)
        .onClick(() => {
          this.showRoomSwitcher = !this.showRoomSwitcher;
        })
      }
      .width(60)
      .height('60%')
      .backgroundColor('rgba(30, 30, 40, 0.75)')
      .backdropFilter($r('sys.blur.20'))
      .borderRadius({ topLeft: 20, bottomLeft: 20 })
      .padding({ top: 16, bottom: 16 })
      .shadow({
        radius: 20,
        color: 'rgba(0, 0, 0, 0.25)',
        offsetX: -4,
        offsetY: 0
      })
    }
    .width(60)
    .height('100%')
    .position({ x: '100%', y: 0 })
    .anchor('100%')
    .padding({ top: 80, bottom: 80 })
  }

  // 顶部导航（厨房）
  @Builder
  buildTopNav(): void {
    Column() {
      Row({ space: 16 }) {
        // 房间标识
        Row({ space: 8 }) {
          Image($r('app.media.ic_home'))
            .width(20)
            .height(20)
            .fillColor(this.currentLightColor)

          Text(this.currentRoom.name)
            .fontSize(16)
            .fontWeight(FontWeight.Medium)
            .fontColor(this.currentLightColor)
        }
        .onClick(() => {
          this.showRoomSwitcher = !this.showRoomSwitcher;
        })

        // 设备快捷按钮
        ForEach(this.navItems, (item: RoomNavItem) => {
          this.buildDeviceChip(item)
        })

        // 场景按钮
        Button('场景')
          .height(36)
          .backgroundColor(`${this.currentLightColor}20`)
          .fontColor(this.currentLightColor)
          .fontSize(13)
          .borderRadius(18)
          .onClick(() => {
            this.showScenePanel();
          })
      }
      .width('100%')
      .height(64)
      .padding({ left: 16, right: 16 })
      .backgroundColor('rgba(30, 30, 40, 0.8)')
      .backdropFilter($r('sys.blur.25'))
      .borderRadius({ bottomLeft: 20, bottomRight: 20 })
      .shadow({
        radius: 15,
        color: 'rgba(0, 0, 0, 0.2)',
        offsetX: 0,
        offsetY: 4
      })
    }
    .width('100%')
    .height(80)
    .position({ x: 0, y: 0 })
    .padding({ top: 40 })
  }

  // 设备按钮（底部导航用）
  @Builder
  buildDeviceButton(item: RoomNavItem): void {
    Column() {
      Stack() {
        // 激活光效
        if (item.isActive) {
          Column()
            .width(48)
            .height(48)
            .backgroundColor(this.currentLightColor)
            .opacity(0.2)
            .blur(10)
            .borderRadius(24)
        }

        Image(item.icon)
          .width(24)
          .height(24)
          .fillColor(item.isActive ? this.currentLightColor : '#B0B0B0')
      }
      .width(48)
      .height(48)

      Text(item.label)
        .fontSize(10)
        .fontColor(item.isActive ? '#FFFFFF' : 'rgba(255,255,255,0.6)')
        .margin({ top: 2 })
    }
    .onClick(() => {
      this.activeDeviceId = item.id;
      this.onDeviceSelect?.(item);
    })
    .onLongPress(() => {
      this.showQuickActions(item);
    })
  }

  // 设备图标（侧边导航用）
  @Builder
  buildDeviceIcon(item: RoomNavItem): void {
    Stack() {
      if (item.isActive) {
        Column()
          .width(44)
          .height(44)
          .backgroundColor(this.currentLightColor)
          .opacity(0.2)
          .blur(8)
          .borderRadius(22)
      }

      Image(item.icon)
        .width(22)
        .height(22)
        .fillColor(item.isActive ? this.currentLightColor : '#B0B0B0')
    }
    .width(44)
    .height(44)
    .onClick(() => {
      this.activeDeviceId = item.id;
      this.onDeviceSelect?.(item);
    })
  }

  // 设备芯片（顶部导航用）
  @Builder
  buildDeviceChip(item: RoomNavItem): void {
    Row({ space: 6 }) {
      Image(item.icon)
        .width(16)
        .height(16)
        .fillColor(item.isActive ? this.currentLightColor : '#B0B0B0')

      if (item.isActive) {
        Text(item.label)
          .fontSize(12)
          .fontColor('#FFFFFF')
      }
    }
    .height(32)
    .padding({ left: 10, right: 10 })
    .backgroundColor(item.isActive ? `${this.currentLightColor}30` : 'rgba(255,255,255,0.05)')
    .borderRadius(16)
    .onClick(() => {
      this.activeDeviceId = item.id;
      this.onDeviceSelect?.(item);
    })
  }

  // 场景按钮
  @Builder
  buildSceneButton(): void {
    Column() {
      Stack() {
        Column()
          .width(48)
          .height(48)
          .backgroundColor('linear-gradient(135deg, #667eea 0%, #764ba2 100%)')
          .opacity(0.3)
          .blur(10)
          .borderRadius(24)

        Image($r('app.media.ic_magic'))
          .width(24)
          .height(24)
          .fillColor('#FFFFFF')
      }
      .width(48)
      .height(48)

      Text('场景')
        .fontSize(10)
        .fontColor('rgba(255,255,255,0.8)')
        .margin({ top: 2 })
    }
    .onClick(() => {
      this.showScenePanel();
    })
  }

  // 房间切换器
  @Builder
  buildRoomSwitcher(): void {
    Column() {
      Row({ space: 12 }) {
        ForEach(Array.from(this.roomConfigs.values()), (config: RoomConfig) => {
          Column({ space: 8 }) {
            Column()
              .width(56)
              .height(56)
              .backgroundColor(config.primaryColor)
              .opacity(0.2)
              .borderRadius(16)
              .border({
                width: config.type === this.currentRoom.type ? 2 : 0,
                color: config.primaryColor
              })

            Text(config.name)
              .fontSize(12)
              .fontColor(config.type === this.currentRoom.type ? config.primaryColor : 'rgba(255,255,255,0.6)')
          }
          .onClick(() => {
            this.switchRoom(config.type);
            this.showRoomSwitcher = false;
          })
        })
      }
      .width('100%')
      .height(100)
      .padding(16)
      .backgroundColor('rgba(30, 30, 40, 0.9)')
      .backdropFilter($r('sys.blur.30'))
      .borderRadius(20)
      .shadow({
        radius: 20,
        color: 'rgba(0, 0, 0, 0.4)',
        offsetX: 0,
        offsetY: 10
      })
    }
    .width('92%')
    .position({ x: '50%', y: 100 })
    .anchor('50%')
    .animation({
      duration: 300,
      curve: Curve.Spring
    })
  }

  // 环境光效层
  @Builder
  buildAmbientLightLayer(): void {
    Column() {
      // 顶部环境光
      Column()
        .width('100%')
        .height(200)
        .backgroundColor(this.currentLightColor)
        .blur(120)
        .opacity(this.ambientIntensity * 0.15)
        .position({ x: 0, y: 0 })

      // 底部环境光
      Column()
        .width('100%')
        .height(150)
        .backgroundColor(this.currentLightColor)
        .blur(100)
        .opacity(this.ambientIntensity * 0.1)
        .position({ x: 0, y: '100%' })
        .anchor('100%')

      // 设备状态光效粒子
      ForEach(this.navItems.filter(i => i.isActive), (item: RoomNavItem, index: number) => {
        Column()
          .width(80 + index * 20)
          .height(80 + index * 20)
          .backgroundColor(this.getDeviceLightColor(item))
          .blur(60)
          .opacity(0.2)
          .position({
            x: `${20 + index * 15}%`,
            y: `${30 + index * 10}%`
          })
          .animation({
            duration: 4000 + index * 1000,
            curve: Curve.EaseInOut,
            iterations: -1,
            playMode: PlayMode.Alternate
          })
      })
    }
    .width('100%')
    .height('100%')
    .pointerEvents(PointerEvents.None)
  }

  private getDeviceLightColor(item: RoomNavItem): string {
    const stateMap: Record<string, Record<string, string>> = {
      light: { on: '#FFE4B5', off: '#333333' },
      ac: { cool: '#00D2FF', heat: '#FF6B6B', auto: '#2ECC71' },
      curtain: { open: '#F1C40F', half: '#F39C12', close: '#2C3E50' }
    };
    return stateMap[item.deviceType]?.on || this.currentLightColor;
  }

  private showQuickActions(item: RoomNavItem): void {
    // 显示快捷操作面板
    AppStorage.setOrCreate('quick_actions_device', JSON.stringify(item));
    AppStorage.setOrCreate('show_quick_actions', true);
  }

  private showScenePanel(): void {
    // 显示场景面板
    AppStorage.setOrCreate('show_scene_panel', true);
  }
}

3.2 设备控制光效面板（DeviceControlPanel.ets）

代码亮点：实现"设备即光效"的控制理念。每个设备的调节滑块、开关按钮都带有动态光效反馈------调节灯光亮度时，背景光效实时同步变化；调节空调温度时，冷暖气色渐变呈现。这种即时视觉反馈让用户"看见"控制效果，而非仅依赖数字。

typescript 复制代码
// entry/src/main/ets/components/DeviceControlPanel.ets

// 设备控制项
interface ControlItem {
  id: string;
  type: 'slider' | 'switch' | 'button_group' | 'color_picker';
  label: string;
  value: number | boolean | string;
  min?: number;
  max?: number;
  step?: number;
  unit?: string;
  options?: string[];
  icon: Resource;
}

@Component
export struct DeviceControlPanel {
  @Prop deviceName: string = '';
  @Prop deviceType: string = 'light';
  @State controls: ControlItem[] = [];
  @State panelColor: string = '#F5A623';
  @State lightIntensity: number = 0.6;
  @State isOn: boolean = true;

  aboutToAppear(): void {
    this.initializeControls();
    this.syncPanelColor();
  }

  private initializeControls(): void {
    // 根据设备类型初始化控制项
    switch (this.deviceType) {
      case 'light':
        this.controls = [
          { id: 'power', type: 'switch', label: '开关', value: true, icon: $r('app.media.ic_power') },
          { id: 'brightness', type: 'slider', label: '亮度', value: 80, min: 0, max: 100, step: 1, unit: '%', icon: $r('app.media.ic_brightness') },
          { id: 'color_temp', type: 'slider', label: '色温', value: 4000, min: 2700, max: 6500, step: 100, unit: 'K', icon: $r('app.media.ic_temperature') },
          { id: 'color', type: 'color_picker', label: '颜色', value: '#FFE4B5', icon: $r('app.media.ic_color') }
        ];
        break;
      case 'ac':
        this.controls = [
          { id: 'power', type: 'switch', label: '开关', value: true, icon: $r('app.media.ic_power') },
          { id: 'temperature', type: 'slider', label: '温度', value: 24, min: 16, max: 30, step: 0.5, unit: '°C', icon: $r('app.media.ic_temperature') },
          { id: 'mode', type: 'button_group', label: '模式', value: 'cool', options: ['cool', 'heat', 'dry', 'fan', 'auto'], icon: $r('app.media.ic_mode') },
          { id: 'fan_speed', type: 'slider', label: '风速', value: 2, min: 1, max: 5, step: 1, unit: '档', icon: $r('app.media.ic_fan') }
        ];
        break;
      case 'curtain':
        this.controls = [
          { id: 'position', type: 'slider', label: '开合度', value: 50, min: 0, max: 100, step: 1, unit: '%', icon: $r('app.media.ic_curtain') },
          { id: 'preset', type: 'button_group', label: '预设', value: 'half', options: ['open', 'half', 'close'], icon: $r('app.media.ic_preset') }
        ];
        break;
    }
  }

  private syncPanelColor(): void {
    // 同步房间主色
    const roomColor = AppStorage.get('current_room_color') as string;
    if (roomColor) {
      this.panelColor = roomColor;
    }
  }

  private getControlColor(control: ControlItem): string {
    if (control.id === 'temperature' && this.deviceType === 'ac') {
      const temp = control.value as number;
      // 温度色温映射：低温蓝->高温红
      if (temp < 20) return '#00D2FF';
      if (temp < 24) return '#2ECC71';
      if (temp < 26) return '#F5A623';
      return '#FF6B6B';
    }
    if (control.id === 'brightness' && this.deviceType === 'light') {
      const brightness = control.value as number;
      return `rgba(255, 228, 181, ${brightness / 100})`;
    }
    return this.panelColor;
  }

  build() {
    Column({ space: 20 }) {
      // 面板头部
      this.buildPanelHeader()

      // 设备状态光效预览
      this.buildDevicePreview()

      // 控制项列表
      List({ space: 16 }) {
        ForEach(this.controls, (control: ControlItem) => {
          ListItem() {
            this.buildControlItem(control)
          }
        })
      }
      .width('100%')
      .layoutWeight(1)

      // 底部快捷场景
      this.buildQuickScenes()
    }
    .width('100%')
    .height('100%')
    .padding(24)
    .backgroundColor('rgba(20, 20, 30, 0.95)')
    .backdropFilter($r('sys.blur.30'))
    .borderRadius({ topLeft: 24, topRight: 24 })
  }

  @Builder
  buildPanelHeader(): void {
    Row({ space: 12 }) {
      // 设备图标（带光效）
      Stack() {
        Column()
          .width(48)
          .height(48)
          .backgroundColor(this.panelColor)
          .opacity(0.2)
          .blur(10)
          .borderRadius(24)

        Image($r('app.media.ic_device'))
          .width(24)
          .height(24)
          .fillColor(this.panelColor)
      }
      .width(48)
      .height(48)

      Column({ space: 4 }) {
        Text(this.deviceName)
          .fontSize(18)
          .fontWeight(FontWeight.Bold)
          .fontColor('#FFFFFF')

        Text(this.isOn ? '运行中' : '已关闭')
          .fontSize(12)
          .fontColor(this.isOn ? this.panelColor : 'rgba(255,255,255,0.4)')
      }
      .alignItems(HorizontalAlign.Start)
      .layoutWeight(1)

      // 关闭面板按钮
      Button() {
        Image($r('app.media.ic_close'))
          .width(20)
          .height(20)
          .fillColor('rgba(255,255,255,0.6)')
      }
      .type(ButtonType.Circle)
      .backgroundColor('rgba(255,255,255,0.05)')
      .width(36)
      .height(36)
    }
    .width('100%')
    .height(60)
  }

  @Builder
  buildDevicePreview(): void {
    Column() {
      // 设备光效预览
      Column() {
        // 模拟灯光效果
        Column()
          .width(120)
          .height(120)
          .backgroundColor(this.isOn ? this.panelColor : '#333333')
          .blur(this.isOn ? 40 : 0)
          .opacity(this.isOn ? 0.6 : 0.3)
          .borderRadius(60)
          .shadow({
            radius: this.isOn ? 30 : 0,
            color: this.panelColor,
            offsetX: 0,
            offsetY: 0
          })
          .animation({ duration: 300 })

        // 状态文字
        if (this.isOn) {
          Text('ON')
            .fontSize(14)
            .fontColor(this.panelColor)
            .fontWeight(FontWeight.Bold)
            .margin({ top: 12 })
        }
      }
      .width('100%')
      .height(180)
      .backgroundColor('rgba(255,255,255,0.02)')
      .borderRadius(20)
      .justifyContent(FlexAlign.Center)
    }
    .width('100%')
  }

  @Builder
  buildControlItem(control: ControlItem): void {
    Column({ space: 12 }) {
      // 标签行
      Row({ space: 8 }) {
        Image(control.icon)
          .width(18)
          .height(18)
          .fillColor('rgba(255,255,255,0.6)')

        Text(control.label)
          .fontSize(14)
          .fontColor('rgba(255,255,255,0.8)')
          .layoutWeight(1)

        if (control.type === 'slider') {
          Text(`${control.value}${control.unit || ''}`)
            .fontSize(14)
            .fontColor(this.getControlColor(control))
            .fontVariant(FontVariant.TabNums)
        }
      }
      .width('100%')

      // 控制组件
      if (control.type === 'switch') {
        Toggle({ type: ToggleType.Switch, isOn: control.value as boolean })
          .selectedColor(this.panelColor)
          .onChange((isOn: boolean) => {
            this.isOn = isOn;
            control.value = isOn;
            this.syncDeviceState();
          })
      } else if (control.type === 'slider') {
        Slider({
          value: control.value as number,
          min: control.min || 0,
          max: control.max || 100,
          step: control.step || 1,
          style: SliderStyle.OutSet
        })
          .width('100%')
          .selectedColor(this.getControlColor(control))
          .blockColor('#FFFFFF')
          .trackColor('rgba(255,255,255,0.1)')
          .onChange((value: number) => {
            control.value = value;
            this.syncDeviceState();
          })

        // 滑块光效反馈
        Column()
          .width('100%')
          .height(2)
          .backgroundColor(this.getControlColor(control))
          .blur(10)
          .opacity(0.5)
      } else if (control.type === 'button_group' && control.options) {
        Row({ space: 8 }) {
          ForEach(control.options, (option: string) => {
            Button(option)
              .height(36)
              .backgroundColor(control.value === option ?
                `${this.panelColor}40` : 'rgba(255,255,255,0.05)')
              .fontColor(control.value === option ? this.panelColor : 'rgba(255,255,255,0.6)')
              .fontSize(13)
              .borderRadius(18)
              .layoutWeight(1)
              .onClick(() => {
                control.value = option;
                this.syncDeviceState();
              })
          })
        }
        .width('100%')
      } else if (control.type === 'color_picker') {
        this.buildColorPicker(control)
      }
    }
    .width('100%')
    .padding(16)
    .backgroundColor('rgba(255,255,255,0.03)')
    .borderRadius(16)
  }

  @Builder
  buildColorPicker(control: ControlItem): void {
    Row({ space: 8 }) {
      // 预设颜色
      ForEach(['#FFE4B5', '#FFD93D', '#FF6B6B', '#6BB6FF', '#E056FD', '#2ECC71'], (color: string) => {
        Button()
          .width(36)
          .height(36)
          .backgroundColor(color)
          .borderRadius(18)
          .border({
            width: control.value === color ? 3 : 0,
            color: '#FFFFFF'
          })
          .onClick(() => {
            control.value = color;
            this.panelColor = color;
            this.syncDeviceState();
          })
      })
    }
    .width('100%')
    .justifyContent(FlexAlign.SpaceAround)
  }

  @Builder
  buildQuickScenes(): void {
    Column({ space: 12 }) {
      Text('快捷场景')
        .fontSize(14)
        .fontColor('rgba(255,255,255,0.6)')
        .width('100%')

      Row({ space: 8 }) {
        ForEach(['阅读', '观影', '睡眠', '离家'], (scene: string) => {
          Button(scene)
            .height(40)
            .backgroundColor('rgba(255,255,255,0.05)')
            .fontColor('rgba(255,255,255,0.8)')
            .fontSize(13)
            .borderRadius(20)
            .layoutWeight(1)
            .onClick(() => {
              this.applyScene(scene);
            })
        })
      }
      .width('100%')
    }
    .width('100%')
    .padding({ top: 16 })
    .border({
      width: { top: 1 },
      color: 'rgba(255,255,255,0.05)'
    })
  }

  private syncDeviceState(): void {
    // 同步设备状态到后端/分布式设备
    const state = {
      deviceType: this.deviceType,
      isOn: this.isOn,
      controls: this.controls
    };
    AppStorage.setOrCreate('device_state_change', JSON.stringify(state));
  }

  private applyScene(scene: string): void {
    // 应用场景预设
    const sceneConfigs: Record<string, Partial<ControlItem>[]> = {
      '阅读': [
        { id: 'brightness', value: 100 },
        { id: 'color_temp', value: 4000 }
      ],
      '观影': [
        { id: 'brightness', value: 20 },
        { id: 'color_temp', value: 2700 }
      ],
      '睡眠': [
        { id: 'power', value: false }
      ],
      '离家': [
        { id: 'power', value: false }
      ]
    };

    const config = sceneConfigs[scene];
    if (config) {
      config.forEach(update => {
        const control = this.controls.find(c => c.id === update.id);
        if (control && update.value !== undefined) {
          control.value = update.value;
        }
      });
      this.syncDeviceState();
    }
  }
}

3.3 场景切换沉浸过渡（SceneTransition.ets）

代码亮点：实现"一键场景"的沉浸过渡效果。当用户切换"观影模式""睡眠模式"时，整个屏幕被场景主题色光效填满，设备图标以动画形式重新排列，营造"空间转换"的仪式感。这是HarmonyOS 6沉浸光感在场景化控制中的极致应用。

typescript 复制代码
// entry/src/main/ets/components/SceneTransition.ets

// 场景配置
interface SceneConfig {
  id: string;
  name: string;
  icon: Resource;
  primaryColor: string;
  secondaryColor: string;
  ambientColor: string;
  transitionDuration: number;
  deviceStates: Record<string, any>;
}

@Component
export struct SceneTransition {
  @State isTransitioning: boolean = false;
  @State progress: number = 0;
  @State fromColor: string = '#000000';
  @State toColor: string = '#000000';
  @State currentScene: SceneConfig | null = null;

  // 场景库
  private scenes: SceneConfig[] = [
    {
      id: 'home',
      name: '回家模式',
      icon: $r('app.media.ic_home'),
      primaryColor: '#F5A623',
      secondaryColor: '#FFD93D',
      ambientColor: '#5C3D1E',
      transitionDuration: 1500,
      deviceStates: { light: 'on', ac: 'auto', curtain: 'half' }
    },
    {
      id: 'movie',
      name: '观影模式',
      icon: $r('app.media.ic_movie'),
      primaryColor: '#9B59B6',
      secondaryColor: '#E056FD',
      ambientColor: '#4A235A',
      transitionDuration: 2000,
      deviceStates: { light: 'dim', tv: 'on', curtain: 'close' }
    },
    {
      id: 'sleep',
      name: '睡眠模式',
      icon: $r('app.media.ic_sleep'),
      primaryColor: '#4ECDC4',
      secondaryColor: '#7EDDD6',
      ambientColor: '#1E4D4A',
      transitionDuration: 3000,
      deviceStates: { light: 'off', ac: 'sleep', curtain: 'close' }
    },
    {
      id: 'wake',
      name: '起床模式',
      icon: $r('app.media.ic_sun'),
      primaryColor: '#FFE66D',
      secondaryColor: '#FFF5B7',
      ambientColor: '#5C4D1E',
      transitionDuration: 2000,
      deviceStates: { light: 'dim', curtain: 'open', purifier: 'on' }
    },
    {
      id: 'away',
      name: '离家模式',
      icon: $r('app.media.ic_away'),
      primaryColor: '#95A5A6',
      secondaryColor: '#BDC3C7',
      ambientColor: '#2C3E50',
      transitionDuration: 1000,
      deviceStates: { light: 'off', ac: 'off', curtain: 'close' }
    }
  ];

  async triggerScene(sceneId: string): Promise<void> {
    const scene = this.scenes.find(s => s.id === sceneId);
    if (!scene || this.isTransitioning) return;

    this.currentScene = scene;
    this.toColor = scene.primaryColor;
    this.isTransitioning = true;
    this.progress = 0;

    // 执行过渡动画
    await this.runTransition(scene.transitionDuration);

    // 应用设备状态
    this.applyDeviceStates(scene.deviceStates);

    // 完成
    this.isTransitioning = false;
    this.fromColor = scene.primaryColor;
  }

  private async runTransition(duration: number): Promise<void> {
    const startTime = Date.now();

    return new Promise(resolve => {
      const animate = () => {
        const elapsed = Date.now() - startTime;
        this.progress = Math.min(1, elapsed / duration);

        if (this.progress < 1) {
          requestAnimationFrame(animate);
        } else {
          resolve();
        }
      };
      animate();
    });
  }

  private applyDeviceStates(states: Record<string, any>): void {
    // 同步设备状态
    AppStorage.setOrCreate('scene_device_states', JSON.stringify(states));
    AppStorage.setOrCreate('scene_applied', this.currentScene?.id);
  }

  build() {
    Stack() {
      // 过渡遮罩层
      if (this.isTransitioning) {
        Column()
          .width('100%')
          .height('100%')
          .backgroundColor(this.toColor)
          .opacity(this.getTransitionOpacity())
          .blur(this.getTransitionBlur())
          .animation({ duration: 50 })

        // 场景图标放大动画
        if (this.currentScene) {
          Column() {
            Image(this.currentScene.icon)
              .width(80 * (1 + this.progress * 2))
              .height(80 * (1 + this.progress * 2))
              .fillColor('#FFFFFF')
              .opacity(1 - this.progress)
              .blur(this.progress * 10)

            Text(this.currentScene.name)
              .fontSize(24)
              .fontColor('#FFFFFF')
              .fontWeight(FontWeight.Bold)
              .margin({ top: 20 })
              .opacity(1 - this.progress)
              .translate({ y: this.progress * 50 })
          }
          .animation({ duration: 50 })
        }

        // 设备状态飞入动画
        if (this.currentScene && this.progress > 0.5) {
          ForEach(Object.entries(this.currentScene.deviceStates), ([device, state], index) => {
            Column() {
              Image($r(`app.media.ic_${device}`))
                .width(32)
                .height(32)
                .fillColor('#FFFFFF')

              Text(`${device}: ${state}`)
                .fontSize(12)
                .fontColor('rgba(255,255,255,0.8)')
            }
            .position({
              x: `${20 + index * 15}%`,
              y: `${40 + Math.sin(index) * 20}%`
            })
            .opacity((this.progress - 0.5) * 2)
            .scale({ x: this.progress, y: this.progress })
            .animation({ duration: 50 })
          })
        }
      }
    }
    .width('100%')
    .height('100%')
    .pointerEvents(this.isTransitioning ? PointerEvents.Auto : PointerEvents.None)
  }

  private getTransitionOpacity(): number {
    // 前半段渐入，后半段渐出
    if (this.progress < 0.5) {
      return this.progress * 2 * 0.9;
    } else {
      return (1 - this.progress) * 2 * 0.9;
    }
  }

  private getTransitionBlur(): number {
    // 中间最模糊
    return Math.sin(this.progress * Math.PI) * 50;
  }
}

四、主页面集成

4.1 智能家居主页面（SmartHomePage.ets）

typescript 复制代码
// entry/src/main/ets/pages/SmartHomePage.ets
import { SpatialFloatNav, RoomType } from '../components/SpatialFloatNav';
import { DeviceControlPanel } from '../components/DeviceControlPanel';
import { SceneTransition } from '../components/SceneTransition';

@Entry
@Component
struct SmartHomePage {
  @State currentRoom: RoomType = RoomType.LIVING_ROOM;
  @State selectedDevice: {name: string, type: string} | null = null;
  @State showDevicePanel: boolean = false;
  @State showSceneTransition: boolean = false;
  @State currentScene: string = '';
  @State roomColor: string = '#F5A623';

  // 场景过渡控制器
  private sceneTransitionRef: SceneTransition | null = null;

  aboutToAppear(): void {
    // 监听场景触发
    AppStorage.watch('show_scene_panel', () => {
      this.showSceneTransition = true;
    });
  }

  build() {
    Stack() {
      // 背景层
      Column()
        .width('100%')
        .height('100%')
        .backgroundColor('#0a0a0f')

      // 房间内容层
      this.buildRoomContent()

      // 空间感知导航
      SpatialFloatNav({
        onDeviceSelect: (device) => {
          this.selectedDevice = { name: device.label, type: device.deviceType };
          this.showDevicePanel = true;
        },
        onSceneSelect: (scene) => {
          this.triggerScene(scene);
        },
        onRoomChange: (room) => {
          this.roomColor = room.primaryColor;
        }
      })

      // 设备控制面板（底部弹出）
      if (this.showDevicePanel && this.selectedDevice) {
        DeviceControlPanel({
          deviceName: this.selectedDevice.name,
          deviceType: this.selectedDevice.type
        })
        .height('70%')
        .position({ x: 0, y: '100%' })
        .anchor('100%')
        .animation({
          duration: 300,
          curve: Curve.Spring
        })
        .gesture(
          SwipeGesture({ direction: SwipeDirection.Down })
            .onAction(() => {
              this.showDevicePanel = false;
            })
        )
      }

      // 场景过渡层
      SceneTransition()
    }
    .width('100%')
    .height('100%')
    .expandSafeArea([SafeAreaType.SYSTEM], [SafeAreaEdge.TOP, SafeAreaEdge.BOTTOM])
  }

  @Builder
  buildRoomContent(): void {
    Column({ space: 20 }) {
      // 房间标题
      Row({ space: 12 }) {
        Text(this.getRoomName(this.currentRoom))
          .fontSize(32)
          .fontWeight(FontWeight.Bold)
          .fontColor('#FFFFFF')

        // 在线设备数
        Row({ space: 4 }) {
          Column()
            .width(8)
            .height(8)
            .backgroundColor('#2ECC71')
            .borderRadius(4)

          Text('5 设备在线')
            .fontSize(14)
            .fontColor('rgba(255,255,255,0.5)')
        }
      }
      .width('100%')
      .padding({ top: 60, left: 24, right: 24 })

      // 场景快捷入口
      this.buildSceneShortcuts()

      // 设备网格
      this.buildDeviceGrid()
    }
    .width('100%')
    .height('100%')
  }

  @Builder
  buildSceneShortcuts(): void {
    Row({ space: 12 }) {
      ForEach(['回家', '观影', '睡眠', '离家'], (scene: string) => {
        Button() {
          Column({ space: 4 }) {
            Image($r(`app.media.ic_scene_${scene}`))
              .width(24)
              .height(24)
              .fillColor('#FFFFFF')

            Text(scene)
              .fontSize(12)
              .fontColor('#FFFFFF')
          }
        }
        .width(72)
        .height(72)
        .backgroundColor('rgba(255,255,255,0.05)')
        .borderRadius(16)
        .border({
          width: 1,
          color: 'rgba(255,255,255,0.1)'
        })
        .onClick(() => {
          this.triggerScene(scene);
        })
      })
    }
    .width('100%')
    .padding({ left: 24, right: 24 })
  }

  @Builder
  buildDeviceGrid(): void {
    Grid() {
      GridItem() {
        this.buildDeviceCard('主灯', 'light', true, '80%')
      }

      GridItem() {
        this.buildDeviceCard('空调', 'ac', true, '24°C')
      }

      GridItem() {
        this.buildDeviceCard('窗帘', 'curtain', false, '已关')
      }

      GridItem() {
        this.buildDeviceCard('电视', 'tv', false, '待机')
      }
    }
    .columnsTemplate('1fr 1fr')
    .columnsGap(12)
    .rowsGap(12)
    .padding(24)
    .layoutWeight(1)
  }

  @Builder
  buildDeviceCard(name: string, type: string, isOn: boolean, status: string): void {
    Column({ space: 12 }) {
      Row({ space: 8 }) {
        Image($r(`app.media.ic_${type}`))
          .width(24)
          .height(24)
          .fillColor(isOn ? this.roomColor : 'rgba(255,255,255,0.4)')

        Column()
          .width(8)
          .height(8)
          .backgroundColor(isOn ? '#2ECC71' : 'rgba(255,255,255,0.2)')
          .borderRadius(4)
      }
      .width('100%')
      .justifyContent(FlexAlign.SpaceBetween)

      Column({ space: 4 }) {
        Text(name)
          .fontSize(16)
          .fontColor('#FFFFFF')
          .fontWeight(FontWeight.Medium)

        Text(status)
          .fontSize(13)
          .fontColor(isOn ? this.roomColor : 'rgba(255,255,255,0.4)')
      }
      .width('100%')
      .alignItems(HorizontalAlign.Start)

      // 设备光效指示
      if (isOn) {
        Column()
          .width('100%')
          .height(3)
          .backgroundColor(this.roomColor)
          .borderRadius(2)
          .shadow({
            radius: 4,
            color: this.roomColor,
            offsetX: 0,
            offsetY: 0
          })
      }
    }
    .width('100%')
    .height(140)
    .padding(16)
    .backgroundColor('rgba(255,255,255,0.03)')
    .backdropFilter($r('sys.blur.10'))
    .borderRadius(20)
    .border({
      width: 1,
      color: isOn ? `${this.roomColor}30` : 'rgba(255,255,255,0.05)'
    })
    .onClick(() => {
      this.selectedDevice = { name, type };
      this.showDevicePanel = true;
    })
  }

  private getRoomName(room: RoomType): string {
    const names: Record<string, string> = {
      living_room: '客厅',
      bedroom: '卧室',
      study: '书房',
      kitchen: '厨房',
      bathroom: '浴室'
    };
    return names[room] || '客厅';
  }

  private triggerScene(scene: string): void {
    const sceneMap: Record<string, string> = {
      '回家': 'home',
      '观影': 'movie',
      '睡眠': 'sleep',
      '离家': 'away'
    };
    const sceneId = sceneMap[scene];
    if (sceneId) {
      this.currentScene = sceneId;
      // 触发场景过渡
      AppStorage.setOrCreate('trigger_scene', sceneId);
    }
  }
}

五、关键技术总结

5.1 空间-导航-光效协同架构

复制代码
空间感知层
    ├── 分布式设备信号检测
    ├── 蓝牙信标定位
    └── 用户手动选择
            ↓
导航适配层
    ├── 客厅 → 底部横条导航
    ├── 卧室 → 左侧迷你轨道
    ├── 书房 → 右侧工具轨道
    ├── 厨房 → 顶部快捷栏
    └── 浴室 → 底部防水导航
            ↓
光效渲染层
    ├── 房间主题色环境光
    ├── 设备状态光效粒子
    └── 场景过渡全屏光效

5.2 设备状态可视化编码

设备类型 状态维度 光效编码 视觉反馈
灯光 亮度 光晕半径+不透明度 亮度越高光晕越大
灯光 色温 颜色冷暖渐变 2700K暖黄->6500K冷白
空调 模式 脉冲颜色 制冷蓝/制热红/除湿绿
空调 温度 色彩渐变 16°C深蓝->30°C深红
窗帘 开合度 光效位置 关闭底部暗->打开顶部亮

5.3 分布式设备同步

typescript 复制代码
// 设备状态同步
class DeviceStateSync {
  async syncToDistributedDevices(state: DeviceState): Promise<void> {
    // 1. 获取同账号下的所有HarmonyOS设备
    const devices = await distributedDeviceManager.getTrustedDeviceListSync();

    // 2. 筛选在线的家居控制设备
    const onlineDevices = devices.filter(d => d.deviceType === 'smartHome');

    // 3. 同步状态
    for (const device of onlineDevices) {
      await this.sendStateToDevice(device.networkId, state);
    }

    // 4. 同步光效主题
    AppStorage.setOrCreate('sync_light_theme', {
      color: state.color,
      intensity: state.intensity,
      timestamp: Date.now()
    });
  }
}

六、调试与适配建议

  1. 多设备信号测试：在不同房间测试分布式设备信号强度，校准房间边界判定算法
  2. 光效功耗优化：夜间模式降低光效刷新率，延长OLED屏幕寿命
  3. 无障碍支持：为视障用户提供语音播报设备状态，光效切换时播放提示音
  4. 隐私保护：房间定位数据本地处理，不上传云端，支持一键清除定位历史

七、结语

HarmonyOS 6的悬浮导航与沉浸光感特性，为智能家居控制带来了从"功能操作"到"空间体验"的范式转变。通过"光影智家"的实战案例，我们展示了如何：

  • 构建空间感知的自适应导航，根据用户所在房间自动切换控制界面和光效主题
  • 实现设备状态的"光效编码"，让设备运行状态通过视觉直观呈现
  • 打造场景切换的沉浸过渡，一键切换时全屏光效营造仪式感
  • 利用分布式能力实现多设备间的控制状态同步与光效联动

这些技术不仅提升了智能家居APP的操控效率，更让科技真正融入生活空间，创造"无感交互、有光相伴"的未来居住体验。期待HarmonyOS生态中的IoT开发者们能够利用这些新特性，创造出更多温暖人心的智能空间。

转载自：https://blog.csdn.net/u014727709/article/details/160312432

欢迎 👍点赞✍评论⭐收藏，欢迎指正*

相关推荐
雪芽蓝域zzs2 小时前
uni-app x 中使用 UTS 语言实现兼容鸿蒙的加密
华为·uni-app·harmonyos
条tiao条2 小时前
鸿蒙 ArkTS 学习入门
学习·华为·harmonyos
Francek Chen2 小时前
【华为Pura90系列】新品发布：Pura 90系列影像领衔，Pura X Max开启大阔折叠新赛道
人工智能·华为·harmonyos·pura 90
特立独行的猫a2 小时前
HarmonyOS / OpenHarmony 鸿蒙PC平台三方库移植：使用 Lycium 移植 pngquant 的实践总结
华为·harmonyos·pngquant·三方库移植·鸿蒙pc·lycim
摄影图2 小时前
智能家居科技单品图片素材 解锁便捷智慧居家体验
网络·科技·aigc·智能家居·贴图·插画
liulian09164 小时前
【Flutter for OpenHarmony第三方库】Flutter for OpenHarmony 多语言国际化适配实战指南
flutter·华为·学习方法·harmonyos
nashane12 小时前
HarmonyOS 6学习：解决异步场景下Toast提示框无法弹出的UI上下文丢失问题
学习·ui·harmonyos·harmony app
星辰徐哥15 小时前
鸿蒙金融理财全栈项目——上线与运维、用户反馈、持续迭代优化
运维·金融·harmonyos
枫叶丹415 小时前
【HarmonyOS Next之旅】DevEco Studio使用指南(三十八) -＞ 构建HAR
华为·harmonyos·deveco studio·harmonyos next
热门推荐
012026年4月技术前沿：AI大模型爆发、智能体革命与量子安全新纪元02GitHub 镜像站点032026 年 AI 编程助手全面对比评测：Cursor vs Copilot vs Claude Code vs GitHub Copilot Free04Claude Code Windows 兼容性问题：指定版本 2.1.112 可解决052026年4月AI大事件深度解读：大模型竞争进入“深水区“06AI Weekly | 2026年4月第二周 · GitHub热门项目与AI发展趋势深度解析07UBUNTU Claude Code 报错 claude native binary not installed08从限购到畅通：GLM-5.1 Coding Plan接入攻略09GPT-6发布日深度解析-Symphony架构200万Token实战10从零部署 Hermes Agent：一只"会成长的 AI 马"保姆级安装教程
