这是一个基于 Streamlit 的内网视频通话应用。让我为您详细解读代码的各个部分：
代码结构分析
1. 导入模块
import streamlit as st # 主框架
import av # 音视频处理
from streamlit_webrtc import webrtc_streamer, WebRtcMode # WebRTC集成
import sqlite3 # 数据库2. 数据库设计
创建了5个核心表：
-
• devices：设备信息（类型、屏幕尺寸等）
-
• users：用户信息和在线状态
-
• messages：聊天记录
-
• call_invitations：通话邀请管理
-
• notifications：通知系统
3. 设备管理
def get_or_create_device_id():
# 基于硬件信息生成唯一设备ID
device_info = f"{platform.platform()}_{socket.gethostname()}"
device_id = str(uuid.uuid5(uuid.NAMESPACE_DNS, device_info))4. 核心功能模块
用户认证系统
-
• 侧边栏用户名输入
-
• 自动设备注册
-
• 在线状态管理
通话管理系统
def create_call_invitation(conn, from_user, to_user, call_type, room_id):
# 创建通话邀请并生成房间ID通知系统
-
• 实时通知铃铛显示
-
• 模态框接听界面
-
• 通知标记已读
聊天系统
-
• 实时消息显示
-
• 对话历史记录
-
• 支持富文本渲染
5. WebRTC 视频通话
webrtc_ctx = webrtc_streamer(
key=f"video-{room_id}",
mode=WebRtcMode.SENDRECV, # 双向音视频
rtc_configuration=RTC_CONFIGURATION,
media_stream_constraints={"video": True, "audio": True}
)6. 响应式设计
CSS媒体查询适配不同设备：
-
• 手机：垂直布局，触摸优化
-
• 平板：自适应网格
-
• 桌面：多列布局
工作流程
-
- 用户注册 → 输入用户名自动注册设备
-
- 查看在线用户 → 显示可通话对象
-
- 发起通话 → 创建邀请并发送通知
-
- 接听邀请 → 弹出模态框选择接听/拒绝
-
- 视频通话 → 建立WebRTC连接
-
- 结束通话 → 清理资源返回主界面
import streamlit as st
import av
import threading
import queue
import json
import logging
import uuid
import time
import sqlite3
from datetime import datetime, timedelta
from streamlit_webrtc import webrtc_streamer, WebRtcMode, RTCConfiguration
import socket
import platform
import asyncio
from typing import Optional, Dict, List配置日志
logging.basicConfig(level=logging.INFO)
logger = logging.getLogger(name)页面配置 - 响应式设计
st.set_page_config(
page_title="内网视频通话",
page_icon="📹",
layout="wide",
initial_sidebar_state="expanded"
)修复Python 3.12的SQLite日期时间适配器警告
def adapt_datetime(val):
return val.isoformat()def convert_datetime(val):
try:
return datetime.fromisoformat(val.decode())
except (ValueError, AttributeError):
return datetime.now()sqlite3.register_adapter(datetime, adapt_datetime)
sqlite3.register_converter("TIMESTAMP", convert_datetime)初始化数据库
def init_db():
conn = sqlite3.connect('video_chat.db', check_same_thread=False, detect_types=sqlite3.PARSE_DECLTYPES)
c = conn.cursor()# 创建设备表 c.execute('''CREATE TABLE IF NOT EXISTS devices (id TEXT PRIMARY KEY, device_name TEXT, username TEXT, device_type TEXT, screen_width INTEGER, screen_height INTEGER, user_agent TEXT, first_seen TIMESTAMP, last_seen TIMESTAMP)''') # 创建用户表 c.execute('''CREATE TABLE IF NOT EXISTS users (id TEXT PRIMARY KEY, username TEXT UNIQUE, device_id TEXT, status TEXT, last_active TIMESTAMP, FOREIGN KEY (device_id) REFERENCES devices (id))''') # 创建消息表 c.execute('''CREATE TABLE IF NOT EXISTS messages (id TEXT PRIMARY KEY, from_user TEXT, to_user TEXT, content TEXT, timestamp TIMESTAMP, is_read BOOLEAN)''') # 创建通话邀请表 c.execute('''CREATE TABLE IF NOT EXISTS call_invitations (id TEXT PRIMARY KEY, from_user TEXT, to_user TEXT, call_type TEXT, status TEXT, room_id TEXT, created_at TIMESTAMP, responded_at TIMESTAMP)''') # 创建通知表 c.execute('''CREATE TABLE IF NOT EXISTS notifications (id TEXT PRIMARY KEY, user_id TEXT, title TEXT, message TEXT, notification_type TEXT, is_read BOOLEAN, created_at TIMESTAMP, related_call_id TEXT)''') conn.commit() return conn获取或创建设备ID
def get_or_create_device_id():
if 'device_id' not in st.session_state:
# 生成基于硬件和浏览器的唯一标识
device_info = f"{platform.platform()}_{socket.gethostname()}"
device_id = str(uuid.uuid5(uuid.NAMESPACE_DNS, device_info))
st.session_state.device_id = device_idreturn st.session_state.device_id检测设备类型
def detect_device_type():
try:
user_agent = st.query_params.get('user_agent', '')
if any(device in user_agent.lower() for device in ['mobile', 'android', 'iphone']):
return "mobile"
elif any(device in user_agent.lower() for device in ['tablet', 'ipad']):
return "tablet"
else:
return "desktop"
except:
return "desktop"注册或更新设备信息
def register_device(conn, username):
device_id = get_or_create_device_id()
device_type = detect_device_type()c = conn.cursor() # 检查设备是否已存在 c.execute("SELECT * FROM devices WHERE id = ?", (device_id,)) existing_device = c.fetchone() current_time = datetime.now() if existing_device: # 更新设备信息 c.execute('''UPDATE devices SET username = ?, last_seen = ? WHERE id = ?''', (username, current_time, device_id)) else: # 插入新设备 c.execute('''INSERT INTO devices (id, device_name, username, device_type, screen_width, screen_height, user_agent, first_seen, last_seen) VALUES (?, ?, ?, ?, ?, ?, ?, ?, ?)''', (device_id, f"{device_type}_{device_id[:8]}", username, device_type, 1920, 1080, "streamlit_app", current_time, current_time)) # 更新用户信息 user_id = str(uuid.uuid4()) c.execute('''INSERT OR REPLACE INTO users (id, username, device_id, status, last_active) VALUES (?, ?, ?, ?, ?)''', (user_id, username, device_id, "online", current_time)) conn.commit() return device_id, user_id获取在线用户列表
def get_online_users(conn, exclude_user=None):
c = conn.cursor()if exclude_user: c.execute('''SELECT u.username, d.device_type, u.last_active FROM users u JOIN devices d ON u.device_id = d.id WHERE u.status = 'online' AND u.username != ? ORDER BY u.last_active DESC''', (exclude_user,)) else: c.execute('''SELECT u.username, d.device_type, u.last_active FROM users u JOIN devices d ON u.device_id = d.id WHERE u.status = 'online' ORDER BY u.last_active DESC''') return c.fetchall()创建通话邀请
def create_call_invitation(conn, from_user, to_user, call_type="video", room_id=None):
if room_id is None:
room_id = f"room_{uuid.uuid4().hex[:8]}"call_id = str(uuid.uuid4()) current_time = datetime.now() c = conn.cursor() c.execute('''INSERT INTO call_invitations (id, from_user, to_user, call_type, status, room_id, created_at) VALUES (?, ?, ?, ?, ?, ?, ?)''', (call_id, from_user, to_user, call_type, "pending", room_id, current_time)) # 创建通知 notification_id = str(uuid.uuid4()) c.execute('''INSERT INTO notifications (id, user_id, title, message, notification_type, is_read, created_at, related_call_id) VALUES (?, ?, ?, ?, ?, ?, ?, ?)''', (notification_id, to_user, "视频通话邀请", f"{from_user} 向您发起了视频通话邀请", "call_invitation", False, current_time, call_id)) conn.commit() return call_id, room_id获取待处理的通知
def get_pending_notifications(conn, username):
c = conn.cursor()
c.execute('''SELECT id, title, message, notification_type, created_at, related_call_id
FROM notifications
WHERE user_id = ? AND is_read = FALSE
ORDER BY created_at DESC''', (username,))
return c.fetchall()标记通知为已读
def mark_notification_read(conn, notification_id):
c = conn.cursor()
c.execute('''UPDATE notifications SET is_read = TRUE WHERE id = ?''', (notification_id,))
conn.commit()处理通话邀请响应
def respond_to_call_invitation(conn, call_id, response, username):
"""响应通话邀请：accept 或 reject"""
c = conn.cursor()
current_time = datetime.now()# 更新邀请状态 c.execute('''UPDATE call_invitations SET status = ?, responded_at = ? WHERE id = ? AND to_user = ?''', (response, current_time, call_id, username)) # 获取房间ID c.execute('''SELECT room_id FROM call_invitations WHERE id = ?''', (call_id,)) result = c.fetchone() room_id = result[0] if result else None conn.commit() return room_id if response == "accepted" else None获取待处理的通话邀请
def get_pending_call_invitations(conn, username):
c = conn.cursor()
c.execute('''SELECT id, from_user, call_type, room_id, created_at
FROM call_invitations
WHERE to_user = ? AND status = 'pending'
ORDER BY created_at DESC''', (username,))
return c.fetchall()检查媒体权限状态
def check_media_permissions():
# 简化处理，实际部署时应该通过前端检测
video_permission = st.session_state.get('video_permission', False)
audio_permission = st.session_state.get('audio_permission', False)return video_permission, audio_permission请求媒体权限
def request_media_permissions():
st.warning("请允许摄像头和麦克风权限")col1, col2 = st.columns(2) with col1: if st.button("授予摄像头和麦克风权限"): st.session_state.video_permission = True st.session_state.audio_permission = True st.rerun() with col2: if st.button("稍后再说"): st.session_state.video_permission = False st.session_state.audio_permission = FalseWebRTC配置
RTC_CONFIGURATION = RTCConfiguration(
{"iceServers": [{"urls": ["stun:stun.l.google.com:19302"]}]}
)初始化数据库连接
conn = init_db()
响应式CSS
st.markdown("""
<style> /* 响应式设计 */ @media (max-width: 768px) { .main-header { font-size: 1.5rem !important; } .user-card { padding: 8px !important; margin: 4px 0 !important; } .video-container { height: 200px !important; } .notification-bell { font-size: 1.2rem !important; } }@media (min-width: 769px) and (max-width: 1024px) {
.video-container { height: 300px !important; }
}@media (min-width: 1025px) {
.video-container { height: 400px !important; }
}/* 通用样式 */
.user-card {
border: 1px solid #ddd;
border-radius: 10px;
padding: 12px;
margin: 8px 0;
cursor: pointer;
transition: all 0.3s ease;
}.user-card:hover {
background-color: #f5f5f5;
transform: translateY(-2px);
}.user-online {
border-left: 4px solid #28a745;
}.user-offline {
border-left: 4px solid #6c757d;
}.chat-window {
border: 1px solid #ddd;
border-radius: 10px;
padding: 15px;
margin: 10px 0;
max-height: 400px;
overflow-y: auto;
}.video-container {
border: 2px solid #007bff;
border-radius: 10px;
margin: 10px 0;
background-color: #000;
}.notification-bell {
position: relative;
display: inline-block;
font-size: 1.5rem;
}.notification-badge {
position: absolute;
top: -5px;
right: -5px;
background-color: #ff4b4b;
color: white;
border-radius: 50%;
width: 20px;
height: 20px;
display: flex;
align-items: center;
justify-content: center;
font-size: 0.8rem;
}.notification-item {
border-left: 4px solid #007bff;
padding: 10px;
margin: 5px 0;
background-color: #f8f9fa;
border-radius: 5px;
}.call-invitation {
border-left: 4px solid #28a745;
background-color: #e8f5e8;
}.modal-overlay {
position: fixed;
top: 0;
left: 0;
width: 100%;
height: 100%;
background-color: rgba(0,0,0,0.5);
display: flex;
justify-content: center;
align-items: center;
z-index: 1000;
}.modal-content {
background: white;
padding: 20px;
border-radius: 10px;
width: 300px;
text-align: center;
}
</style>
""", unsafe_allow_html=True)应用标题和通知区域
col1, col2 = st.columns([4, 1])
with col1:
st.markdown('📹 内网视频通话应用
', unsafe_allow_html=True)
st.markdown("支持多设备适配的实时视频通信平台")with col2:
# 通知铃铛
pending_notifications = get_pending_notifications(conn, st.session_state.get('username', ''))
notification_count = len(pending_notifications)st.markdown(f''' <div class="notification-bell"> 🔔 {f'<span class="notification-badge">{notification_count}</span>' if notification_count > 0 else ''} </div> ''', unsafe_allow_html=True) if st.button("查看通知", use_container_width=True): st.session_state.show_notifications = not st.session_state.get('show_notifications', False)显示通知面板
if st.session_state.get('show_notifications', False) and st.session_state.get('username'):
st.subheader("📢 通知中心")
notifications = get_pending_notifications(conn, st.session_state.username)if notifications: for notif_id, title, message, notif_type, created_at, call_id in notifications: with st.container(): col1, col2 = st.columns([4, 1]) with col1: st.markdown(f"**{title}**") st.markdown(f"{message}") st.caption(f"时间: {created_at.strftime('%H:%M:%S') if hasattr(created_at, 'strftime') else created_at}") with col2: if notif_type == "call_invitation": col2_1, col2_2 = st.columns(2) with col2_1: if st.button("接听", key=f"accept_{notif_id}"): room_id = respond_to_call_invitation(conn, call_id, "accepted", st.session_state.username) mark_notification_read(conn, notif_id) st.session_state.call_active = True st.session_state.current_room = room_id st.session_state.show_notifications = False st.rerun() with col2_2: if st.button("拒绝", key=f"reject_{notif_id}"): respond_to_call_invitation(conn, call_id, "rejected", st.session_state.username) mark_notification_read(conn, notif_id) st.session_state.show_notifications = False st.rerun() else: if st.button("标记已读", key=f"read_{notif_id}"): mark_notification_read(conn, notif_id) st.session_state.show_notifications = False st.rerun() st.markdown("---") else: st.info("暂无新通知")用户注册和登录
with st.sidebar:
st.header("👤 用户设置")# 用户名输入 username = st.text_input("用户名", placeholder="请输入您的用户名", key="username_input") if username and username.strip(): st.session_state.username = username.strip() # 注册设备 device_id, user_id = register_device(conn, st.session_state.username) device_type = detect_device_type() st.success(f"设备已注册: {device_type.upper()}") st.info(f"设备ID: {device_id[:8]}...") # 通话设置 st.header("⚙️ 通话设置") call_id = st.text_input("房间ID", value=f"room_{uuid.uuid4().hex[:8]}", key="room_input") # 媒体权限检查 video_permission, audio_permission = check_media_permissions() if not video_permission or not audio_permission: request_media_permissions() else: video_enabled = st.checkbox("启用视频", value=video_permission, key="video_check") audio_enabled = st.checkbox("启用音频", value=audio_permission, key="audio_check") # 通话控制 st.header("📞 通话控制") col1, col2 = st.columns(2) with col1: start_call = st.button("加入通话", type="primary", use_container_width=True, key="join_call") with col2: end_call = st.button("离开通话", type="secondary", use_container_width=True, key="leave_call")主内容区域
if not st.session_state.get('username'):
st.warning("请在侧边栏输入用户名开始使用")
st.stop()初始化会话状态
if 'current_chat' not in st.session_state:
st.session_state.current_chat = None
if 'call_active' not in st.session_state:
st.session_state.call_active = False
if 'messages' not in st.session_state:
st.session_state.messages = {}
if 'current_room' not in st.session_state:
st.session_state.current_room = None
if 'pending_invitation' not in st.session_state:
st.session_state.pending_invitation = None
if 'show_invitation_modal' not in st.session_state:
st.session_state.show_invitation_modal = False检查是否有待处理的通话邀请
if st.session_state.username and not st.session_state.call_active:
pending_invitations = get_pending_call_invitations(conn, st.session_state.username)
if pending_invitations and not st.session_state.get('show_invitation_modal', False):
st.session_state.pending_invitation = pending_invitations[0]
st.session_state.show_invitation_modal = True显示通话邀请模态框
if st.session_state.get('show_invitation_modal', False) and st.session_state.pending_invitation:
invitation_id, from_user, call_type, room_id, created_at = st.session_state.pending_invitation# 使用Streamlit原生组件创建模态框 st.markdown(""" <div class="modal-overlay"> <div class="modal-content"> """, unsafe_allow_html=True) st.info(f"📞 {from_user} 邀请您视频通话") accept_col, reject_col = st.columns(2) with accept_col: if st.button("接听通话", type="primary", use_container_width=True, key="modal_accept"): room_id = respond_to_call_invitation(conn, invitation_id, "accepted", st.session_state.username) st.session_state.call_active = True st.session_state.current_room = room_id st.session_state.show_invitation_modal = False st.session_state.pending_invitation = None st.rerun() with reject_col: if st.button("拒绝通话", type="secondary", use_container_width=True, key="modal_reject"): respond_to_call_invitation(conn, invitation_id, "rejected", st.session_state.username) st.session_state.show_invitation_modal = False st.session_state.pending_invitation = None st.rerun() st.markdown("</div></div>", unsafe_allow_html=True)在线用户列表
st.header("👥 在线用户")
online_users = get_online_users(conn, exclude_user=st.session_state.username)if online_users:
cols = st.columns(3)
for i, (user, dev_type, last_active) in enumerate(online_users):
with cols[i % 3]:
try:
if isinstance(last_active, str):
last_active = datetime.strptime(last_active, '%Y-%m-%d %H:%M:%S.%f')
time_diff = (datetime.now() - last_active).seconds
status_text = "刚刚" if time_diff < 60 else f"{time_diff//60}分钟前"
except:
status_text = "未知"st.markdown(f''' <div class="user-card user-online"> <strong>{user}</strong><br> <small>{dev_type.upper()} • {status_text}</small> </div> ''', unsafe_allow_html=True) call_col, chat_col = st.columns(2) with call_col: if st.button("视频通话", key=f"call_{user}", use_container_width=True): # 创建通话邀请 call_id, room_id = create_call_invitation(conn, st.session_state.username, user) st.session_state.current_chat = user st.session_state.current_room = room_id st.success(f"已向 {user} 发送通话邀请") with chat_col: if st.button("发起聊天", key=f"chat_{user}", use_container_width=True): st.session_state.current_chat = userelse:
st.info("暂无其他在线用户")聊天窗口
if st.session_state.current_chat:
st.header(f"💬 与 {st.session_state.current_chat} 的对话")# 初始化聊天记录 if st.session_state.current_chat not in st.session_state.messages: st.session_state.messages[st.session_state.current_chat] = [] # 显示聊天消息 chat_container = st.container() with chat_container: for msg in st.session_state.messages[st.session_state.current_chat]: alignment = "right" if msg['from'] == st.session_state.username else "left" bg_color = "#007bff" if msg['from'] == st.session_state.username else "#f1f1f1" text_color = "white" if msg['from'] == st.session_state.username else "black" st.markdown(f""" <div style="text-align: {alignment}; margin: 5px 0;"> <div style="background: {bg_color}; color: {text_color}; display: inline-block; padding: 8px 12px; border-radius: 18px; max-width: 70%;"> {msg['content']} </div> <div style="font-size: 0.8em; color: #666; margin-top: 2px;"> {msg['time']} </div> </div> """, unsafe_allow_html=True) # 消息输入和视频通话按钮 col1, col2, col3 = st.columns([3, 1, 1]) with col1: new_message = st.text_input("输入消息", label_visibility="collapsed", placeholder="输入消息...", key="message_input") with col2: if st.button("发送", use_container_width=True, key="send_message") and new_message: timestamp = datetime.now().strftime("%H:%M") st.session_state.messages[st.session_state.current_chat].append({ 'from': st.session_state.username, 'content': new_message, 'time': timestamp }) st.rerun() with col3: if st.button("视频通话", type="primary", use_container_width=True, key="start_video_chat"): # 创建通话邀请 call_id, room_id = create_call_invitation(conn, st.session_state.username, st.session_state.current_chat) st.session_state.call_active = True st.session_state.current_room = room_id st.success(f"已向 {st.session_state.current_chat} 发起视频通话")视频通话界面
if st.session_state.call_active:
st.header("📹 视频通话中")
st.info(f"房间ID: {st.session_state.current_room or '默认房间'}")# 检查媒体权限 video_permission, audio_permission = check_media_permissions() if not video_permission or not audio_permission: st.error("需要摄像头和麦克风权限才能进行视频通话") request_media_permissions() else: # 视频通话布局 col1, col2 = st.columns(2) with col1: st.subheader("本地视频") try: webrtc_ctx = webrtc_streamer( key=f"video-{st.session_state.current_room or 'default'}", mode=WebRtcMode.SENDRECV, rtc_configuration=RTC_CONFIGURATION, media_stream_constraints={ "video": True, "audio": True, }, ) except Exception as e: st.error(f"视频流初始化失败: {str(e)}") st.info("请确保浏览器已授予摄像头和麦克风权限") with col2: st.subheader("远程视频") if st.session_state.current_chat: st.info(f"等待 {st.session_state.current_chat} 接听...") else: st.info("等待对方接听...") # 通话控制按钮 st.markdown("---") col1, col2, col3 = st.columns([1, 2, 1]) with col2: if st.button("结束通话", type="secondary", use_container_width=True, key="end_call"): st.session_state.call_active = False st.session_state.current_room = None st.rerun()设备信息显示
with st.expander("📱 设备信息"):
device_info = f"""
- 设备类型: {detect_device_type().upper()}
- 设备ID: {get_or_create_device_id()}
- 用户名: {st.session_state.username}
- 在线用户数: {len(online_users) + 1}
- 当前时间: {datetime.now().strftime('%Y-%m-%d %H:%M:%S')}
"""
st.markdown(device_info)使用说明
with st.expander("❓ 使用说明"):
st.markdown("""
### 使用指南：
1. 用户注册: 在侧边栏输入用户名自动注册设备
2. 用户列表: 查看在线用户，点击用户发起通话或聊天
3. 通话邀请: 收到邀请时会弹出通知，可选择接听或拒绝
4. 权限管理: 首次使用需要授权摄像头和麦克风### 通知功能： - 🔔 右上角通知铃铛显示未读通知数量 - 📞 收到通话邀请时会自动弹出接听界面 - 💬 聊天过程中可随时发起视频通话 ### 设备适配： - 📱 **手机**: 垂直布局，优化触摸操作 - 📟 **平板**: 自适应网格布局 - 💻 **电脑**: 多列布局，功能完整展示 """)自动刷新页面以检查新通知
if st.session_state.get('username'):
# 每10秒自动刷新一次以检查新通知
if 'last_refresh' not in st.session_state:
st.session_state.last_refresh = time.time()current_time = time.time() if current_time - st.session_state.last_refresh > 10: # 10秒刷新一次 st.session_state.last_refresh = current_time st.rerun()应用退出时清理资源
def cleanup():
if 'conn' in locals():
conn.close()import atexit
atexit.register(cleanup)
