Elasticsearch：运用 JINA 来实现多模态搜索的 RAG

Jina Embeddings v4 是一个 38 亿参数的通用向量模型，用于多模态多语言检索，支持单向量和多向量输出。那么我们该如何使用它对图片及文字进行搜索，并最终对搜索的结果做 RAG。

下载源码

闲话少说，我们直接到地址 https://github.com/liu-xiao-guo/jina_multimodal_rag 下载源码。

复制代码

git clone https://github.com/liu-xiao-guo/jina_multimodal_rag

$ pwd
/Users/liuxg/python/jina_multimodal_rag
$ tree -L 3
.
├── README.md
├── app.py
├── images
│   ├── bladerunner-city.jpg
│   ├── images (1).jpeg
│   ├── images (2).jpeg
│   ├── images (3).jpeg
│   ├── matrix-code.jpg
│   ├── starwars-lightsaber.jpg
│   └── tfa_poster_wide_header-1536x864-324397389357.0.0.1537961254.webp
├── pics
│   ├── pic1.png
│   ├── pic2.png
│   └── pic3.png
├── requirements.txt
└── texts
    ├── 1.txt
    ├── 10.txt
    ├── 2.txt
    ├── 3.txt
    ├── 4.txt
    ├── 5.txt
    ├── 6.txt
    ├── 7.txt
    ├── 8.txt
    └── 9.txt

如上所示，我们代码在 app.py 里。我们可以把所有需要向量化的图片放入到 images 目录下。把所有的需要向量化的文字放入到 texts 里文件中。

除了上面的文件之外，还有一个叫做 .env 的文件：

.env

复制代码

ES_URL="<Your ES_URL>"
ES_API_KEY="Your ES_API_Key"
GEMINI_FLASH_API_KEY="<Your Gemini Flash API Key>"

我们需要根据自己的配置填入相应的设置。在今天的使用中，我们使用 https://openrouter.ai/ 来调用 Gemini 3 Flash multimodal LLM 来完成我们的 RAG。

代码设计

为了方便我们的代码设计，我们使用 streamlit 来设计界面：

app.py

复制代码

import os
import torch
import streamlit as st
from PIL import Image
from transformers import AutoModel
from elasticsearch import Elasticsearch
from dotenv import load_dotenv
import openai
import base64
from io import BytesIO

# Load environment variables from .env if exists
load_dotenv()

# -------------------------
# Config
# -------------------------
INDEX_NAME = "multimodal-index"
IMAGE_FOLDER = "./images"  # local image folder
TEXT_FOLDER = "./texts"    # local text folder
ES_URL = os.getenv("ES_URL", "https://localhost:9200")
ES_API_KEY = os.getenv("ES_API_KEY", "")
OPENROUTER_API_KEY = os.getenv("GEMINI_FLASH_API_KEY")

# -------------------------
# Elasticsearch
# -------------------------
@st.cache_resource
def get_es():
    return Elasticsearch(ES_URL, verify_certs=False, api_key=ES_API_KEY)

es = get_es() # Initialize Elasticsearch client

# -------------------------
# Model loading
# -------------------------
@st.cache_resource
def load_model():
    device = (
        "mps" if torch.backends.mps.is_available()
        else "cuda" if torch.cuda.is_available()
        else "cpu"
    )

    model = AutoModel.from_pretrained(
        "jinaai/jina-embeddings-v4",
        trust_remote_code=True,
        torch_dtype=torch.float32,
    ).to(device)
    model.eval()
    return model, device

model, device = load_model()

# -------------------------
# LLM Client loading (OpenRouter)
# -------------------------
@st.cache_resource
def load_llm_client():
    if not OPENROUTER_API_KEY:
        st.error("GEMINI_FLASH_API_KEY not found in environment variables.")
        return None

    client = openai.OpenAI(
        base_url="https://openrouter.ai/api/v1",
        api_key=OPENROUTER_API_KEY,
    )
    return client

llm_client = load_llm_client()
LLM_MODEL_NAME = "google/gemini-3-flash-preview"

# -------------------------
# Index setup
# -------------------------
def create_index():
    if es.indices.exists(index=INDEX_NAME):
        return

    mapping = {
        "mappings": {
            "properties": {
                "filename": {"type": "keyword"},
                "path": {"type": "keyword"},
                "caption": {"type": "text"},
                "vector_field": {
                    "type": "dense_vector",
                    "dims": 2048,
                    "index": True,
                    "similarity": "cosine"
                }
            }
        }
    }
    es.indices.create(index=INDEX_NAME, body=mapping)

create_index()

# -------------------------
# Embedding helpers
# -------------------------
def embed_image(pil_image):
    with torch.inference_mode():
        vec = model.encode_image(
            images=[pil_image],
            task="retrieval",
            return_numpy=True
        )
    return vec[0]

def embed_text(text):
    with torch.inference_mode():
        vec = model.encode_text(
            texts=[text],
            task="retrieval",
            prompt_name="query",
            return_numpy=True
        )
    return vec[0]

# -------------------------
# Batch ingestion for images
# -------------------------
def ingest_image_folder(folder):
    docs = []
    for fname in os.listdir(folder):
        if not fname.lower().endswith((".png", ".jpg", ".jpeg", ".webp")):
            continue

        path = os.path.join(folder, fname)
        image = Image.open(path).convert("RGB")
        vec = embed_image(image)

        docs.append({
            "_index": INDEX_NAME,
            "_source": {
                "filename": fname,
                "path": path,
                "caption": fname.replace("_", " "),
                "vector_field": vec.tolist(),
            }
        })

    if docs:
        from elasticsearch.helpers import bulk
        bulk(es, docs)

# -------------------------
# Batch ingestion for text files
# -------------------------
def ingest_text_folder(folder):
    docs = []
    for fname in os.listdir(folder):
        if not fname.lower().endswith(".txt"):
            continue

        path = os.path.join(folder, fname)
        with open(path, "r", encoding="utf-8") as f:
            text = f.read().strip()
        vec = embed_text(text)

        docs.append({
            "_index": INDEX_NAME,
            "_source": {
                "filename": fname,
                "path": path,
                "caption": text[:500],
                "vector_field": vec.tolist(),
            }
        })

    if docs:
        from elasticsearch.helpers import bulk
        bulk(es, docs)

# -------------------------
# KNN search only
# -------------------------
def knn_search(query, k=10):
    vec = embed_text(query)
    body = {
        "size": k,
        "query": {
            "knn": {
                "field": "vector_field",
                "query_vector": vec.tolist(),
                "k": k,
                "num_candidates": 50
            }
        }
    }
    res = es.search(index=INDEX_NAME, body=body)
    return res["hits"]["hits"]

# -------------------------
# Image to Base64 helper
# -------------------------
def pil_to_base64(image, format="jpeg"):
    buffered = BytesIO()
    image.save(buffered, format=format)
    img_str = base64.b64encode(buffered.getvalue()).decode()

# -------------------------
# RAG Augmentation
# -------------------------
def generate_rag_response(user_query: str, k: int = 3):
    """
    Retrieves top K documents, creates a multimodal prompt, and generates a response from Gemini via OpenRouter.
    """
    st.write(f"Searching for top {k} relevant documents for RAG...")
    results = knn_search(user_query, k=k)

    if not results:
        st.warning("No relevant documents found for RAG.")
        return

    # Build the multimodal prompt for OpenAI-compatible API
    content_parts = []
    text_context = "Based on the following information:\n"

    for hit in results:
        src = hit["_source"]
        path = src.get("path", "")
        if path and os.path.exists(path) and path.lower().endswith((".png", ".jpg", ".jpeg", ".webp")):
            text_context += f"- Image: {src.get('filename', 'N/A')}\n"
            try:
                img = Image.open(path).convert("RGB")
                base64_image = pil_to_base64(img)
                content_parts.append({
                    "type": "image_url",
                    "image_url": {"url": base64_image}
                })
            except Exception as e:
                st.error(f"Could not load image {path}: {e}")
        else:
            text_context += f"- Text Content: {src.get('caption', 'N/A')}\n"

    text_context += f"\nAnswer the question: {user_query}"
    content_parts.insert(0, {"type": "text", "text": text_context})

    messages = [{"role": "user", "content": content_parts}]

    st.subheader("Gemini Flash Multimodal Prompt:")
    st.json(messages)

    if llm_client:
        with st.spinner("Gemini Flash is generating a response via OpenRouter..."):
            try:
                response = llm_client.chat.completions.create(
                    model=LLM_MODEL_NAME,
                    messages=messages,
                    max_tokens=1024,
                )
                st.markdown("**LLM Generated Response:**")
                st.markdown(response.choices[0].message.content)
            except Exception as e:
                st.error(f"Error generating response from OpenRouter: {e}")

# -------------------------
# Streamlit UI
# -------------------------
st.title("🖼️📄 Multimodal Image & Text KNN Search")

# Batch ingestion buttons
st.subheader("Ingest Data")
if st.button("📥 Ingest image folder"):
    ingest_image_folder(IMAGE_FOLDER)
    st.success("Images ingested successfully")

if st.button("📥 Ingest text folder"):
    ingest_text_folder(TEXT_FOLDER)
    st.success("Text files ingested successfully")

col1, col2 = st.columns([3, 1])
with col2:
    if st.button("⚠️ Delete & Re-ingest All"):
        with st.spinner("Deleting index and re-ingesting all data..."):
            if es.indices.exists(index=INDEX_NAME):
                es.indices.delete(index=INDEX_NAME)
                st.toast(f"Index '{INDEX_NAME}' deleted.")

            create_index()
            st.toast("Index created.")
            ingest_image_folder(IMAGE_FOLDER)
            st.toast("Images ingested.")
            ingest_text_folder(TEXT_FOLDER)
            st.toast("Texts ingested.")
        st.success("All data has been re-ingested successfully!")

# Search box for typing text queries
st.subheader("Search")
user_query = st.text_input("Type your search query here", key="search_query")
k_value = st.slider("Number of results to retrieve (K)", min_value=1, max_value=10, value=4)

if user_query:
    st.subheader(f"Retrieval Results (Top {k_value})")
    retrieval_results = knn_search(user_query, k=k_value)

    if retrieval_results:
        cols_per_row = 3
        for i in range(0, len(retrieval_results), cols_per_row):
            row = retrieval_results[i:i + cols_per_row]
            cols = st.columns(len(row), gap="medium")

            for col, hit in zip(cols, row):
                src = hit["_source"]
                path = src.get("path", "")

                if path and os.path.exists(path) and path.lower().endswith((".png", ".jpg", ".jpeg", ".webp")):
                    col.image(path, caption=f"{src.get('filename', '')}", width=200)
                else:
                    col.write(f"**[TEXT]**\n\n{src.get('caption', '')}")

                col.write(f"Score: {hit['_score']:.3f}")
    else:
        st.info("No relevant documents found in the index.")

    st.subheader("RAG System Output")
    st.write("---")
    generate_rag_response(user_query, k=k_value)

代码不是很长。

运行代码：

我们需要在虚拟环境中使用如下的命令来安装所需要的库：

复制代码

pip install -r requirements.txt

我们使用如下的命令来执行：

复制代码

streamlit run app.py

首次运行，我们可以直接点击 Delete & Re-ingest All 按钮来写入所有的 images 及 texts。当然我们也可以分别使用 ingest image folder 及 ingest text folder 来完成文件的写入。值得注意的是：它们并不会删除之前的索引数据，而且重新写入 images 或 texts 目录里的文件。如果多次点击这个按钮，它会对该文件夹中的文件多次写入。

如下是搜索的结果：

当我们搜索 Star wars：
